JVC FS-G5J User Manual
COMPACT COMPONENT SYSTEM
FS-G5
—Consists of CA-FSG5 and SP-FSG5
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1349-001B
[J]
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
(standby/on)
For U.S.A.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
G-1
CAUTION
Changes or modifications not approved by JVC
could void the user’s authority to operate the
equipment.
For the main unit:
Declaration of Conformity
Model Number: FS-G5
Trade Name: JVC
Responsible Party: JVC Americas Corp.
Address: 1700 Valley Road, Wayne
New Jersey 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
For Canada/pour le Canada
CAUTION:
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
ATTENTION:
ELECTRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQUAU FOND.
TO PREVENT ELECTRIC SHOCK,
POUR EVITER LES CHOCS
Note to CATV system installer:
This reminder is provided to call the CATV system
installer’s attention to section 820-40 of the NEC
which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED
THE CLASS B LIMITS FOR RADIO NOISE
EMISSIONS FROM DIGITAL APPARATUS AS SET
OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED “DIGITAL
APPARATUS,” ICES-003 OF THE DEPARTMENT
OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES
LIMITES DE BRUITS RADIOELECTRIQUES
APPLICABLES AUX APPAREILS NUMIRIQUES DE
CLASSE B PRESCRITES DANS LA NORME SUR LE
MATERIEL BROUILLEUR; “APPAREILS
NUMERIQUES”, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm
or more.
Attention: Aération correcte
Pour prévenir tout risque de décharge électrique ou d’incendie et éviter toute détérioration, installez l’appareil de la manière
suivante:
1. Avant: Bien dégagé de tout objet.
2. Côtés/dessus/dessous: Assurez-vous que rien ne bloque les espaces indiqués sur le schéma ci-dessous.
3. Dessous: Posez l’appareil sur une surface plane et horizontale. Veillez à ce que sa ventilation correcte puisse se faire en le
plaçant sur un support d’au moins dix centimètres de hauteur.
Front
Face
*
About the cooling fan
A cooling fan is mounted on the rear panel of the unit to prevent abnormal temperature inside the unit, thus assuring normal
operation of the unit. The cooling fan automatically starts rotating to intake external cool air when the volume is increased
up to more than a certain level.
*
À propos du ventilateur de refroidissement
Un ventilateur de refroidissement se trouve sur le panneau arrière de l’appareil afin d’éviter la création d’une température
anormale à l’intérieur de l’appareil et permettre ainsi un fonctionnement normal de l’appareil. Le ventilateur de
refroidissement commence à tourner et à aspirer de l’air frais automatiquement quand le volume est augmenté au-dessus
d’un certain niveau.
15 cm
SP-FSG5
1 cm
15 cm
CA-FSG5
1 cm
SP-FSG5
15 cm
10 cm
Side
Côté
15 cm
15 cm
CA-FSG5
G-2
G-3
Contents
Introduction........................................................ 2
Precautions.......................................................................... 2
How to Read This Manual.................................................. 2
Getting Started ................................................... 3
Step 1: Unpack.................................................................... 3
Step 2: Prepare the Remote Control ...................................3
Step 3: Hook Up .................................................................4
Before Operating the System ............................ 7
Daily Operations—Playback............................. 8
Listening to the Radio......................................................... 9
Playing Back a Disc.......................................................... 10
Playing Back from the PC ................................................11
Playing Back from Other Equipment ...............................12
Daily Operations
—Sound & Other Adjustments ................... 13
Adjusting the Volume....................................................... 13
Adjusting the Sound .........................................................13
Changing the Display Brightness .....................................14
Setting the Clock .............................................................. 14
Turning Off the Power Automatically.............................. 14
Advanced Disc Operations .............................. 15
Programming the Playing Order—Program Play............. 15
Playing at Random—Random Play.................................. 16
Playing Repeatedly—Repeat Play.................................... 17
Prohibiting Disc Ejection—Child Lock ........................... 17
Timer Operations............................................. 18
Setting the Timer ..............................................................18
Additional Information ................................... 20
Learning More about This System ...................................20
Troubleshooting................................................................ 21
Maintenance...................................................................... 21
Specifications.................................................................... 22
Parts Index ........................................................................22
1
Introduction
Remote
ONLY
Main Unit
ONLY
Precautions
Installation
• Install in a place which is level, dry and neither too hot nor
too cold—between 5°C and 35°C (41°F and 95°F).
• Install the System in a location with adequate ventilation to
prevent internal heat buildup inside the System.
DO NOT install the System in a location near
heat sources, or in a place subject to direct
sunlight, excessive dust or vibration.
• Leave sufficient distance between the System and the TV.
• Keep the speakers away from the TV to avoid interference
with TV.
Power sources
• When unplugging the System from the wall outlet, always
pull on the plug, not the AC power cord.
DO NOT handle the AC power cord with wet
hands.
Moisture condensation
Moisture may condense on the lenses inside the System in
the following cases:
• After starting to heat the room
• In a damp room
• If the System is brought directly from a cold to a warm
place
Should this occur, the System may malfunction. In this case,
leave the System turned on for a few hours until the moisture
evaporates, unplug the AC power cord, then plug it in again.
Internal heat
•A cooling fan is mounted on the rear panel to prevent heat
buildup inside the main unit (see page G-2).
For safety, observe the following carefully:
• Make sure there is good ventilation around
the main unit. Poor ventilation could
overheat and damage the System.
• DO NOT block the cooling fan and the
ventilation openings or holes. If they are
blocked by a newspaper or cloth, etc., the
heat may not be able to get out.
• If you are not going to operate the System for an extended
period of time, unplug the AC power cord from the wall outlet.
If anything goes wrong, unplug the AC power cord and
consult your dealer.
How to Read This Manual
To make this manual as simple and easy-to-understand as
possible, we have adapted the following methods:
• Button and control operations are explained as listed in the
table below. In this manual, the operations using the remote
control is mainly explained; however, you can use the
buttons and controls on the main unit if they have the same
(or similar) name and marks.
•
Some related tips and notes are explained later in the
sections “Learning More about This System” and
“Troubleshooting,” but not in the same section
explaining the operations.
the functions, or if you have a doubt about the functions, go
to these sections and you will find the answers.
2 sec.
If you want to know more about
Indicates that you press the button
.
briefly
Indicates that you press the button
briefly and repeatedly
you want is selected.
Indicates that you press one of the
buttons.
Indicates that you
button for specified seconds.
• The number inside the arrow
indicates the period of press (in this
example, 2 seconds).
• If no number is inside the arrow,
press and hold until the entire
procedure is complete or until you
get a result you want.
Indicates that you turn the control
toward the specified direction(s).
until an option
press and hold
the
Others
• Should any metallic object or liquid fall into the System,
unplug the AC power cord and consult your dealer before
operating any further.
DO NOT disassemble the System since there
are no user serviceable parts inside.
2
Indicates that this operation is only possible
using the remote control.
Indicates that this operation is only possible
using the buttons and controls on the main
unit.
Getting Started
Step 1:Unpack the package and
check the accessories.
Step 2: Prepare the remote control.
Step 1: Unpack
After unpacking, check to be sure that you have all the
following items. The number in parentheses indicates the
quantity of each piece supplied.
• FM antenna (1)
• AM loop antenna (1)
• Remote control (1)
• Batteries (2)
If any item is missing, consult your dealer immediately.
Step 2: Prepare the Remote Control
Insert the batteries into the remote control by matching the
polarity (+ and –) correctly.
1
2
Step 3: Hook up the components such
as AM/FM antennas, speakers,
etc. (see pages 4 to 6).
ANTENNA
AM
EXT
AM
LOOP
GND
Finally plug the AC power cord.
Now you can operate the System.
R6(SUM-3)/AA(15F)
3
• DO NOT use an old battery together with a
new one.
• DO NOT use different types of batteries
together.
• DO NOT expose batteries to heat or flame.
• DO NOT leave the batteries in the battery
compartment when you are not going to use
the remote control for an extended period of
time. Otherwise, the remote control will be
damaged from battery leakage.
3
Step 3: Hook Up
If you need more detailed information, see page 6.
Illustrations of the input/output terminals below are typical
examples.
When you connect other components, refer also to their
manuals since the terminal names actually printed on the rear
may vary.
Turn the power off to all components before connections.
For better FM/AM reception
Outdoor FM
antenna
(not supplied)
White
AM
LOOP
ANTENNA
AM
AM
EXT
EXT
GND
GND
AM loop antenna
Keep it connected.
Vynile-covered wire (not supplied)
Extend it horizontally.
Disconnect the supplied FM antenna, and connect to an outdoor FM
antenna using a 75 Ω wire with coaxial type connector.
To a wall outlet
Plug the AC power cord only after all connections are complete.
4
FM antenna (supplied)
Extend it so that
you can obtain
the best
reception.
LOOP
AM
AM
EXT
GND
AM loop antenna (supplied)
Turn it until the best reception is
obtained.
ANTENNA
Black stripe
Non-stripe
5
To assemble and connect the AM loop antenna
To assemble the AM loop antenna
To connect the AM loop antenna
Make sure to connect the wire correctly: The white end to
AM EXT, the black end to GND.
1 Hold
2 Insert
• If the AM loop antenna wire or speaker cords are covered
with vinyl, remove the vinyl to expose the tip of the
antenna by twisting the vinyl.
• Make sure the antenna conductors do not touch any other
terminals, connecting cords and power cord. Also, keep the
antennas away from metallic parts of the System,
connecting cords, and the AC power cord. This could cause
poor reception.
3 Release
To connect the speaker cords
Make sure the both speakers are connected correctly and
firmly.
3 Release
1 Hold
2 Insert
When connecting the speaker cords, match the polarity of
the speaker terminals: The cord with black stripe to (–), the
cord without stripe to (+).
• DO NOT connect more than one speaker to
each terminal.
• DO NOT allow the conductor of the speaker
cords to be in touch with the metallic parts of
the System.
6
Before Operating the System
The indications on the display teach you a lot of things while you are operating the System.
Before operating the System, be familiar with when and how the indicator illuminates on the display.
1
Disc tray indicators
12 3 4 5
GR.
1CD
ALL
6
SOUND TURBO AHB PRO
RANDOMPRGM A.STANDBY
7
Indications on the main display
• While listening to radio:
REC
ST
Band
Frequency
• While playing a CD:
REC
REC
Track number
Elapsed playing time
• While playing an MP3*:
MP3
Current track number Elapsed playing time
REC
• While disc play is stopped:
CD:
Total track number
MP3:
MP3
REC
MONO STMP3
8
• While selecting USB:
Source name
• While selecting AUX:
REC
Total playing time
MP3
GR.
REC
SLEEP
9
123
REC
REC
REC
• 1–5: Disc tray number
•: Tray indicator
– Lights when the disc is detected.
– Blinking while playing back a disc.
– Goes off when there is no disc in the tray.
•: Shows the current disc.
2
MP3 indicator
• Lights when an MP3 disc is detected.
3
SOUND TURBO indicator
• Lights when the SOUND TURBO is activated (see
page 13).
4
AHB PRO (Active Hyper Bass Pro) indicator
• Lights when the AHB PRO is activated.
5
FM reception indicators
• MONO: Lights while the FM monaural mode is
activated.
• ST (stereo): Lights while an FM stereo station with
sufficient signal strength is tuned in.
6
Play mode indicators
• RANDOM: Lights when Random Play mode is
activated.
• PRGM (program): Lights when Program Play mode is
activated.
•: Lights when Repeat mode is activated.
–1:Repeats the one track.
– CD: Repeats the one disc
– ALL: Repeats all the discs.
– GR.: Repeats all the tracks in the selected group.
7
Main display
8
A(auto). STANDBY indicator
• Lights when Auto Standby is activated.
• Flashes when disc playback stops with Auto Standby
activated.
9
Timer indicators
•: Lights when Daily Timer stands by; flashes while
working.
• 1/2/3: Lights when a Daily Timer (1, 2, or 3) stands by;
flashes while setting or working.
• SLEEP: Lights when the Sleep Timer is activated.
Total track number
Total group
number
Total track
number
* When you start playing an MP3 disc, the group number,
track number, track name, (and ID3 Tag) will be shown
before the elapsed playing time appears.
7
Numeric
STANDBY/ON
buttons
4/1,
7,¡/¢
Disc selection
buttons
FM MODE/
MP3
Daily Operations
1
Turn on the power.
The STANDBY lamp on the main unit turns off.
• Without pressing STANDBY/ON , the System
1
SET
DISPLAY
PRESET UP,
PRESET DOWN
2
3
turns on by pressing one of the source selecting
buttons in the next step.
2
Select the source.
Playback automatically starts if the selected source is
ready to start.
• If you press AUX or USB, start playback source on
the external component.
3
Adjust the volume.
Operate the target source as explained
4
later.
To turn off (stand by) the System
—Playback
The STANDBY lamp on the main unit
lights up.
•A small amount of power is always
consumed even while on standby.
1
2
3
4
VOLUME
STANDBY/ON
REC
For private listening
Connect a pair of headphones to the PHONES jack on the
main unit. The sound will no longer come out of the
speakers. Be sure to turn down the volume before
connecting or putting the headphones.
• Disconnecting the headphones will activate the
speakers again.
DO NOT turn off (stand by) the System with
the volume set to an extremely high level;
otherwise, the sudden blast of sound can
damage your hearing, speakers and/or
headphones when you turn on the System or
start playback.
To turn off the clock indication to
Remote
ONLY
save the power
While the System is turned off...
DISPLAY
• Press the button again, to display the
clock indication.
8
Listening to the Radio
To select the band (FM or AM)
FM AM
Remote
To preset the stations
ONLY
You can preset 30 FM and 15 AM stations.
1
Tune in to a station you want to preset.
Activate the preset number entry mode.
2
SET
REC
To tune in to a station
While FM or AM is selected...
Remote control: Main unit:
1 sec.
Frequency starts changing on the display.
When a station (frequency) with sufficient signal strength is
tuned in, the frequency stops changing.
• When you repeatedly press the button, the frequency
changes step by step.
To stop searching manually,
press either button.
If the received FM station is hard to listen
FM MODE/
MP3
The MONO indicator lights on the display.
Reception will improve though stereo
effect is lost—Monaural reception mode.
To restore the stereo effect,
button again (the MONO indicator goes
off).
DOWN
1 sec.
UP
Remote
ONLY
press the
• Finish the following process while the indication on the
display is flashing.
3
Select a preset number for the station you store.
Examples:
3
To select preset number 5, press
5.
6
To select preset number 15, press
+10, then 5.
9
To select preset number 30, press
+10, +10, then 10.
10
1
2
5
4
8
7
10
• You can also use the PRESET UP/PRESET DOWN
buttons.
4
Store the station.
SET
REC
9
To tune in to a preset station
Remote
ONLY
To select a disc to be played back
Select a band (FM or AM).
1
FM AM
Select a preset number for the station you store.
2
• You can also use the
3
6
9
PRESET UP or
PRESET DOWN.
10
1
2
5
4
8
7
10
Playing Back a Disc
This System can play back the following discs—regular CD
and CD-R/CD-RW (recorded either in the audio CD or MP3
format).
• Caution for DualDisc playback
The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Digital Audio” standard. Therefore, the
use of Non-DVD side of a DualDisc on this product may
not be recommended.
CD 1 CD 2 CD 3
CD 4 CD 5
To start:
To pause: To stop:
To release, press again.
To select a track/group*
Increases the track/group*
numbers.
Decreases the track/group*
numbers.
* For details about the group selection, see “For MP3
playback” on page 11.
To locate a particular portion
While playing a disc, press and hold until the portion you
want is reached.
Main Unit
To insert a disc
ONLY
You can insert discs while playing another source.
0
To close the disc tray,
• When the current disc tray is open, pressing CD 6
press the same 0
again.
closes
the tray and the playback starts.
• When you press 0
for the next tray you want to place
another disc onto, the first disc tray automatically closes
and then the next tray comes out.
10
Fast-forwards the track.
Fast-reverses the track.
To locate a track directly and
start play
Examples:
1
4
7
10
3
2
To select track number 5, press
5.
5
6
To select track number 15, press
+10, then 5.
9
8
To select track number 30, press
+10, +10, then 10.
10
Remote
ONLY
For MP3 playback
According to the MP3 playback mode, 4/1 /
¡/¢ or number buttons work for the group
selection or the track selection.
Examples:
When the MP3 play back mode is “GROUP.”
GR. (Group) indicator
MP3
GR.
Total group number Total track number
You can change the MP3 playback mode
by pressing FM MODE/MP3.
• Each time you press the button, the MP3
playback mode changes as follows:
TRACK GROUP
TRACK:
GROUP:
4/1, ¡/¢, and number
buttons work for the track selection of
the MP3 discs.
4/1, ¡/¢, and number
buttons work for the group selection
of the MP3 discs.
REC
FM MODE/
MP3
Playing Back from the PC
This System is equipped with a USB terminal on the front
panel of the main unit. You can connect your PC to this
terminal and enjoy sound reproduced through your PC.
When you connect your PC for the first time, follow the
procedure below.
• Remember you cannot send any signal or data to your PC
from this System.
How to install the USB drivers
The following procedure is described using the English
version of WindowsRXP. If your PC is running on a
different version of operation system or language, the
screens shown on your PC’s monitor will differ from the
ones used in the following procedure.
Turn on your PC and start running WindowsR 98,
1
WindowsR 98SE, WindowsR Me, WindowsR 2000, or
Windows
• If the PC has been turned on, quit all the applications
now running.
2
Select USB as the source.
3
Set the volume to minimum.
Connect the System to the PC using a USB cable (not
4
supplied).
R
XP.
(front panel)
USB cable
PC
MP3 groups/tracks configuration
This System plays back MP3 tracks as follows.
Level 1 Level 2 Level 3 Level 4 Level 5
ROOT
01
1
Hierarchy
01
03 04
7
3
02
1
2
Group with its play order
MP3 track with its play order
4
8
5
05
6
9
10
11
12
•
Use “USB series A plug to B plug” cable when
connecting.
IMPORTANT
• Always set volume to “VOL-MIN” when connecting or
disconnecting the other equipment.
11
5
The USB drivers are installed automatically.
• If the USB drivers are not installed automatically,
install the USB drivers following the instructions on the
PC’s monitor.
Check if the drivers are correctly installed.
6
1 Open the Control Panel on your PC: Select [Start] =
[Control Panel]
2 Click [System] =
=
[Sound, video and game controllers] and
[Universal Serial Bus controllers]
• The following window appears, and you can check
whether the drivers are installed.
[Hardware] =
[Device Manager]
Playing Back from other equipment
To connect other equipment
By using an stereo mini plug cord (not supplied), you can
connect equipment with analog audio output jacks such as an
MD player, or a TV, etc.
Stereo mini plug cord (not supplied)
AUX
(front panel)
If the audio output on the other equipment is not stereo
mini plug type,
Use a plug adapter to convert the stereo mini plug to the
corresponding plug of the audio output.
Refer to the manuals supplied with the other equipment.
IMPORTANT
• Always set volume to “VOL-MIN” when connecting or
disconnecting the other equipment.
Portable audio
device,
Game machine, etc.
To play back sounds on the PC
Press USB, then start playback from PC.
Refer to the manuals supplied with the sound reproduction
application installed in the PC.
12
Daily Operations
VOLUME
VOLUME
—Sound & Other Adjustments
Remote control
CLOCK/
TIMER
4/1,
7,¡/¢
DIMMER
A.STANDBY
SLEEP
SOUND
TURBO
AHB PRO
SET
CANCEL
DISPLAY
PRESET UP,
PRESET DOWN
FADE
MUTING
VOLUME
+/–
BASS/
TREBLE
Adjusting the Volume
You can adjust the volume level from level 0 (VOL-MIN) to
level 31 (VOL-MAX).
Remote control:
To drop the volume in a moment
FADE MUTING
To restore the volume,
Main unit:
Remote
ONLY
press again, or
adjust the volume level.
Adjusting the Sound
To emphasize the sound—SOUND TURBO
This function emphasizes the sound.
SOUND
TURBO
S-TURBO
OFF
(Canceled)
Main unit
4/¢
DIMMER
SOUND
TURBO
VOLUME +/–
To reinforce the bass sound
Remote
ONLY
—AHB PRO
You can reinforce the bass sound to maintain rich, full bass
at low volume.
AHB PRO
To adjust the tone—BASS/TREBLE
You can adjust the bass and treble level from 0 to +5.
To adjust the bass
BASS/
TREBLE
To adjust the treble
BASS/
TREBLE
BASS
Canceled
BASS
Canceled
AHB PRO
(Canceled)
TREBLE
TREBLE
OFF
Remote
ONLY
PRESET UP
PRESET DOWN
PRESET UP
PRESET DOWN
13
Loading...
