JVC DXT-9-J Service manual

SERVICE MANUAL

COMPACT COMPONENT SYSTEM

MB51320063

DX-T9J

SP-XCT9

CA-DXT9SP-XT7 SP-XT7SP-WT9 SP-WT9

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

SP-XST9SP-XST9

TABLE OF CONTENTS

1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11

No.MB513

2006/3

Please refer to "DX-T9 (No.MB368)" about this section.

SPECIFIC SERVICE INSTRUCTIONS

DX-T9J

Parts list(General assembly) [P3-4 Block NO.M1MM]

Item Parts name

1 FRONT PANEL ASY GV10276-004A GV10276-012A 1

5 TRAY FITTING 1 GV30699-002A GV30699-004A 1

6 TRAY FITTING 2 GV30700-002A GV30700-004A 1

7 TRAY FITTING 3 GV30701-002A GV30701-004A 1

8 TRAY FITTING 4 GV30702-002A GV30702-004A 1

9 TRAY FITTING 5 GV30703-002A GV30703-004A 1

15 REMOTE LENS GV40600-002A ----------- 0

30 SWING CAM BKT GV40589-001A GV40589-002A 2

33 TAP SCREW QYSBSF3010ZA QYSBSF3008ZA 2

39 CASS.HOLDER(B) GV10261-001A GV10261-002A 1

50 TAPPING SCREW E65923-009 QYSBSF3008ZA 2

52 TAP SCREW QYSBSFG3008ZA QYSBSF3008ZA 3

53 SCREW GV40035-002A QYSDSF2608ZA 1

56 TAP SCREW QYSBSF3010ZA QYSBSF3008ZA 2

58 SUPPORT BKT GV30706-001A GV30706-001A 2

59 TAP SCREW QYSBSG3006ZA QYSBSG3006ZA 2

63 POWER CORD QMPK210-205-JN QMPD330-200-JD 1

67 TAP SCREW QYSBSGG3008EA QYSBSG3008ZA 1

70 SPACER GV30349-025A ----------- 0

71 TAP SCREW QYSBSF3008ZA ----------- 0

79 REAR PANEL GV10255-020A GV10255-042A 1

80 REAR COVER GV10263-002A GV10263-003A 1

81 TUNER QAU0307-003 QAU0346-001 1

87 TAP SCREW QYSBSGY3008EA ----------- 0

89 TAP SCREW QYSBSGY3008EA ----------- 0

95 TAP SCREW QYSBSF3012EA ----------- 0

98 LASER CAUTION LV41843-002A ----------- 0

102 LED HOLDER GV40531-001A GV40531-002A 1

103 POWER TRANSF QQT0477-001 QQT0477-002 1

104 FUSE QMFZ051-8R0-J8 QMF51U1-100-J8 1

105 FUSE QMF51W2-6R3-J8 ----------- 0

106 FUSE QMF51W2-6R3-J8 QMF51U1-8R0-J8 1

107 FUSE QMF51W2-6R3-J8 QMF51U1-8R0-J8 1

108 FUSE QMF51W2-1R25-J8 QMF51U1-1R6-J8 1

109 FUSE QMF51W2-3R15-J8 QMF51U1-3R0-J8 1

110 FUSE QMF51W2-5R0-J8 QMF51U1-8R0-J8 1

111 FUSE QMF51W2-5R0-J8 QMF51U1-8R0-J8 1

SECTION 1

PRECAUTION

SECTION 2

DX-T9_US DX-T9J

Parts number

Q'ty

1-4 (No.MB513)

Item Parts name

112 FUSE QMF51W2-5R0-J8 QMF51U1-8R0-J8 1

113 FUSE QMF51W2-5R0-J8 QMF51U1-8R0-J8 1

114 FFC WIRE QUQH12-0910BJ-E QUQR12-0910BJ-E 1

115 FFC WIRE QUQH12-1010BJ-E QUQR12-1010BJ-E 1

116 FFC WIRE QUQH12-2512AJ-E QUQR12-2512AJ-E 1

117 FFC WIRE QUQH12-1916AJ-E QUQR12-1916AJ-E 1

118 FFC WIRE QUQH12-0808AJ-E QUQR12-0808AJ-E 1

119 FFC WIRE QUQH10-1910AJ-E QUQW10-1910AJ-E 1

120 FFC WIRE QUQH10-2823AJ-E QUQW10-2828AJ-E 1

121 FFC WIRE QUQH10-1016AJ-E QUQW10-1016AJ-E 1

122 FFC WIRE QUQH10-0814AJ-E QUQW10-0814AJ-E 1

123 FFC WIRE QUQH12-1118AJ-E QUQR12-1118AJ-E 1

124 FFC WIRE QUQH12-0516BJ-E QUQR12-0516BJ-E 1

125 FFC WIRE QUQH12-0813AJ-E QUQR12-0813AJ-E 1

126 FFC WIRE QUQH12-1118AJ-E QUQR12-1118AJ-E 1

129 HEAD SHIELD ----------- GV30071-001A 1

130 SCREW ----------- QYSDSF2608ZA 2

131 SPACER ----------- GV30349-061A 1

132 PROTECT SHEET ----------- GV40698-001A 1

133 SPECIAL SCREW ----------- QYSBSGY3008EA 1

134 SPECIAL SCREW ----------- QYSBSGY3008EA 1

135 HEAT SINK ----------- GV40620-003A 1

136 T.SCREW ----------- QYSBSG3010ZA 1

DX-T9_US DX-T9J

Parts number

Q'ty

(No.MB513)1-5

56

120

56

122

133

91

94

86

85

86

97

132

88

80

134

92

93

Cassette B

48

49

131

129

121

130

136

135

59

58

Bridge board

58

59

1-6 (No.MB513)

Parts list(Amplifier board) [P3-24 Block NO.01]

Item Parts name

CN402 CONNECTOR QGF1205C1-08 QGF1205C2-08 1

D4401 DIODE 1SS119-041-T2 1SS133-T2 1

R4405 UNF C RESISTOR QRJ146J-470X QRJ146J-150X 1

R4408 UNF C RESISTOR QRJ146J-470X QRJ146J-150X 1

D4901 DIODE 1SS119-041-T2 1SS133-T2 1

D4601 DIODE 1SS119-041-T2 1SS133-T2 1

D4701 DIODE 1SS119-041-T2 1SS133-T2 1

D4101 DIODE 1SS119-041-T2 1SS133-T2 1

D4201 DIODE 1SS119-041-T2 1SS133-T2 1

CN302 CONNECTOR QGF1205C1-19 QGF1205C2-19 1

CN303 CONNECTOR QGF1205F1-11 QGF1205F2-11 1

FW301 FLAT WIRE ----------- QUM155-16Z4Z4-E 1

W305 WIRE ----------- QJK046-040802-E 1

IC304 IC KIA7810API KIA7809API 1

R3821 MF RESISTOR ----------- QRT01DJ-3R9X 1

IC303 IC KIA7805API ----------- 0

R3831 C RESISTOR QRE141J-102Y ----------- 0

C3831 E CAPACITOR QETN1EM-476Z ----------- 0

C3832 E CAPACITOR QETN1CM-107Z ----------- 0

D3831 DIODE 1SS119-041-T2 ----------- 0

D3832 Z DIODE MTZJ6.2B-T2 ----------- 0

IC307 IC KIA317PI KIA7806API 1

R3903 C RESISTOR QRE141J-470Y ----------- 0

R3904 C RESISTOR QRE141J-221Y ----------- 0

R3905 C RESISTOR QRE141J-242Y ----------- 0

D3902 DIODE 1SS119-041-T2 1SS133-T2 1

D3903 Z DIODE ----------- MTZJ6.2B-T2 1

D3101 DIODE 1SS119-041-T2 1SS133-T2 1

R3105 UNF C RESISTOR QRJ146J-470X QRJ146J-150X 1

R3108 UNF C RESISTOR QRJ146J-470X QRJ146J-150X 1

D3401 DIODE 1SS119-041-T2 1SS133-T2 1

D3501 DIODE 1SS119-041-T2 1SS133-T2 1

D3601 DIODE 1SS119-041-T2 1SS133-T2 1

CN500 CONNECTOR QGF1036F1-19 QGF1036F2-19 1

C5008 C CAPACITOR ----------- QCBB1HK-103Y 1

R5050 C RESISTOR ----------- QRE141J-103Y 1

DX-T9_US DX-T9J

Parts number

Q'ty

(No.MB513)1-7

Parts list(Main board) [P3-26 Block NO.02]

Item Parts name

CN720 CONNECTOR QGF1036C1-19 QGF1036C2-19 1

CN730 CONNECTOR QGF1205C1-25 QGF1205C2-25 1

CN740 CONNECTOR QGF1205F1-05 QGF1205F2-05 1

CN750 CONNECTOR QGF1205F1-11 QGF1205F2-11 1

CN760 CONNECTOR QGF1205C1-08 QGF1205C2-08 1

CN788 CONNECTOR QGF1205C1-05 QGF1205C2-05 1

CN800 CONNECTOR QGF1036C1-10 QGF1036C2-10 1

CN810 CONNECTOR QGF1036C1-08 QGF1036C2-08 1

CN820 CONNECTOR QGF1205C1-08 QGF1205C2-08 1

CN830 CONNECTOR QGF1205C1-19 QGF1205C2-19 1

C8503 M CAPACITOR QFLC1HJ-154Z QFVF1HJ-154Z 1

C8576 M CAPACITOR QFLC1HJ-154Z QFVF1HJ-154Z 1

C8577 E CAPACITOR QETN1HM-104Z ----------- 0

C8580 M CAPACITOR QFLC1HJ-154Z QFVF1HJ-154Z 1

R8507 MG RESISTOR NRSA63J-104X NRSA63J-473X 1

R8511 MG RESISTOR NRSA63J-243X NRSA63J-183X 1

R8512 MG RESISTOR NRSA63J-243X NRSA63J-473X 1

C8183 E CAPACITOR QETN1HM-224Z QUY150-050Y 1

C7000 E CAPACITOR QETN0JM-477Z ----------- 0

R7001 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7002 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7003 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7004 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7005 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7006 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7011 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7012 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7013 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7014 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7015 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

R7016 OMF RESISTOR QRL01DJ-151X QRL01DJ-101X 1

C7050 E CAPACITOR QETN1HM-475Z QETN1CM-107Z 1

D7330 SI DIODE 1N4003S-T5 ----------- 0

D7350 SI DIODE 1N4003S-T5 ----------- 0

C7527 C CAPACITOR ----------- QCBB1HK-103Y 1

IC770 MASK ROM MN101C49GFS1 MN101C49GFS3 1

R7809 F RESISTOR ----------- NRSA63J-332X 1

R7789 MG RESISTOR NRSA63J-222X NRSA63J-102X 1

C8234 M CAPACITOR ----------- QFLC1HJ-682Z 1

R8231 MG RESISTOR NRSA63J-103X NRSA63J-912X 1

R8099 C.RESISTOR ----------- QRE141J-105Y 1

R8199 C.RESISTOR ----------- QRE141J-105Y 1

CN901 CONNECTOR QGF1205F1-05 QGF1205F2-05 1

C9000 C CAPACITOR NCB21HK-473X NCB31CK-473X 1

R9017 MG RESISTOR NRSA63J-104X ----------- 1

J910 HEADPHONE JACK QNS0170-001 QNS0266-001 1

C9100 C CAPACITOR QDGB1HK-102Y ----------- 0

D9100 Z DIODE MTZJ2.4B-T2 ----------- 0

DX-T9_US DX-T9J

Parts number

Q'ty

1-8 (No.MB513)

Parts list(Packing accessories) [P3-51 Block NO.M4MM]

Item Parts name

A1 INST BOOK

A3 KARAOKE SHEET GV40633-001A GVT0161-001A 1

A4 ERRATA SHEET GV40639-001A ----------- 0

A5 COMPUTER LABEL CL0020-001 GV30892-001A 1

A7 PLUG ADAPTER QAM0112-002 ----------- 0

A26 USER MANUAL YOM800001-0243 ----------- 0

A28 SAFETY INST. ----------- YU20333 1

P1 CARTON ASSY. GV20352-004A GV20434-001A 1

P2 CUSHION (BOTTOM) GV10272-001A GV10354-001A 1

P3 CUSHION (TOP) GV10271-001A GV10353-001A 1

P16 PACKING CASE ICC8PDXT9-EB10 ICC8PDXT9-EB70 1

P17 CARTON SPACER ----------- GV30897-001A 1

P18 CARTON SPACER ----------- GV30897-002A 1

P19 SHEET ----------- GV40168-014A 1

P20 SHEET ----------- GV40168-015A 1

Parts number

DX-T9_US DX-T9J

GVT0147-001A

(ENGCHI(PEKIN))

GVT0147-007A

(ENG)

Q'ty

1

(No.MB513)1-9

P16

P18

P5

A28

P17

P20

P19

1-10 (No.MB513)

PARTS LIST

[ DX-T9 ] [ DX-T7 ]

[ DX-T5 ]

* All printed circuit boards and its assemblies are not available as service parts.

DX-T9,DX-T7

Area suffix

A ------------------------- Australia US ---------------------- Singapore UW ---------- Brazil,Mexico,Peru UX ------------------- Saudi Arabia UG - Turkey,South Africa,Egypt UN ----------------------------Asean

Area suffix

US ---------------------- Singapore UW ---------- Brazil,Mexico,Peru UX ------------------- Saudi Arabia UY ----------------------- Argentina UG - Turkey,South Africa,Egypt UN ----------------------------Asean

DX-T5

- Contents -

Exploded view of general assembly and parts list (Block No.M1) (DX-T9)

Exploded view of general assembly and parts list (Block No.M2) (DX-T7) Exploded view of general assembly and parts list (Block No.M3) (DX-T5) DVD mechanism assembly and parts list (Block No.MJ) (Common)

DVD changer mechanism assembly and parts list (Block No.MK) (FMU-SM1-1M) (DX-T9,DX-T7) DVD changer mechanism assembly and parts list (Block No.MS) (FMU-SM1-11M) (DX-T5) Cassette mechanism assembly and parts list (Block No.MP) (SLC-S401M)

- Cassette A (Common)

Cassette mechanism assembly and parts list (Block No.MQ) (SLC-S302M)

- Cassette B (Common) Electrical parts list (Block No.01~17) Packing materials and accessories parts list (Block No.M4) (DX-T9) Packing materials and accessories parts list (Block No.M5) (DX-T7) Packing materials and accessories parts list (Block No.M6) (DX-T5)

3- 2 3- 6 3-10 3-14

3-16

3-18

3-20

3-22 3-24 3-52 3-54 3-56

No.MB368

3-1

Exploded view of general assembly and parts list

7

8

Block No.

(DX-T9)

96

61

E

96

9

M

1

M

120

56

41

40

38

39

24

23

25

47

128

44

37

3

37

4

43

96

D

C

96

8

7

126

121

6

5

g

D

24

20

96

A

23

25

FL board

101

100

17

C

B

Pr

17

6

17

11

12

17

29

26

115

29

26

2

21

45

10

1

11

15

34

36

32

22

B

21

F

13

14

35

36

31

22

49

34

31

100

Cassette A

33

30

48

32

102

99

46

114

F

46

35

33

G

52

30

49

48

G

52

a

Cassette B

42

18

16

18

t

52

54

53

Microphone amplifier board

124

3-2

56

B

17

102

6

114

46

29

assette B

29

C

17

120

115

26

56

122

121

Primary board

17

71

17

67

17

119

e

26

51

46

28

109

51

k

j

50

116

f

112

111

108

46

27

50

m

125

Video board

Amplifier 1 board

70

76

113

75

n

104

110

106

59

107

58

57

65

74

105

s

62

84

123

83

127

94

98

b

89

E

90

h

91

97

86

88

81

94

82

85

86

95

80

92

87

h

g

79

93

73

q

117

66

118

d

c

Amplifier 2 board

78

77

t

62

p

19

r

s

62

59

103

A

p

q

r

59

69

Bridge board

58

60

19

n

58

63

64

Surround terminal board

b

m

j k

c

d

e

f

Main board

72

a

68

70

3-3

General Assembly (DX-T9)



Symbol No. Part No. Part Name Description Local

1 GV10276-004A FRONT PANEL ASY 2 GV40077-002A JVC BADGE 3 GV30697-006A FL LENS 4 GV30698-004A BUTTON LENS 5 GV30699-002A TRAY FITTING 1 6 GV30700-002A TRAY FITTING 2 7 GV30701-002A TRAY FITTING 3 8 GV30702-002A TRAY FITTING 4 9 GV30703-002A TRAY FITTING 5 10 GV10273-001A CENTER BUTTON 11 GV40586-003A V.ILLUMINATION 12 GV40587-001A POWER INDICATOR 13 GV40588-001A RHYTM.INDICATOR 14 GV40628-001A SPACER 15 GV40600-002A REMOTE LENS 16 GV40608-001A MIC.VOL KNOB 17 QYSDSF2608ZA TAP SCREW M2.6 x 8mm(x11) 18 GV40313-001A FELT SPACER (x2) 19 GV40313-002A FELT SPACER (x2) 20 GV10260-001A MECHA CHASSIS 21 QYSSSF3010ZA TAP SCREW M3 x 10mm(x2) 22 GV40584-001A METAL COVER BKT (x2) 23 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 24 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 25 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 26 GV30124-001A TRANS SHIELD (x2) 27 GV30349-046A SPACER 28 GV30349-047A SPACER 29 GV30349-049A SPACER (x2) 30 GV40589-001A SWING CAM BKT (x2) 31 GV40501-002A SWING CAM (x2) 32 GV40502-002A SPRING (x2) 33 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 34 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 35 GV40503-001A WASHER (x2) 36 GV40504-002A SCREW (x2) 37 GV40515-001A METAL PIN (x2) 38 GV10262-001A CASS.HOLDER(A) 39 GV10261-001A CASS.HOLDER(B) 40 GV20344-001A CASS.LENS (A) 41 GV20343-001A CASS.LENS (B) 42 GV30705-001A LENS ORNAMENT 43 GV40596-001A DOOR SPRING(B) 44 GV40619-001A DOOR SPRING(A) 45 GV40034-001A DAMPER ASSY. (x2) 46 QYSBSF3010ZA TAP SCREW M3 x 10mm(x8) 47 VKY4180-401 CASSETTE SPRING (x4) 48 VKL7850-002 EJECT SAFTY(R) (x2) 49 VKW5258-003 TORSION SPRING (x2) 50 E65923-009 TAPPING SCREW (x2) 51 GV40618-001A SLC BRACKET (x2) 52 QYSBSFG3008ZA TAP SCREW M3 x 8mm(x3) 53 GV40035-002A SCREW 54 GV30349-050A SPACER 56 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 57 GV10253-004A BOTTOM CHASSIS 58 GV30706-001A SUPPORT BKT. (x3) 59 QYSBSG3006ZA TAP SCREW M3 x 6mm(x3) 60 QYSBSG3006ZA TAP SCREW M3 x 6mm 61 GV10254-003A/S/ METAL COVER 62 QYSDSTL4008EA TAP SCREW M4 x 8mm(x4)



63 QMPG150-244-JC POWER CORD(AST) 2.44m BLACK A



63 QMPK210-205-JN POWER CORD(EU) 2.05m BLACK UG,UN,US,UW



63 QMPN240-200-JD POWER CORD(EU) 2m BLACK UX



64 QZW0033-001 STRAIN RELIEF 65 QYSSST3008ZA TAP SCREW M3 x 8mm(x2) 66 QYSBSF3008ZA TAP SCREW M3 x 8mm 67 QYSBSGG3008EA TAP SCREW M3 x 8mm 68 QYSBSGG3008EA TAP SCREW M3 x 8mm 69 QYSBSGG3008EA TAP SCREW M3 x 8mm 70 GV30349-025A SPACER (x3) 71 QYSBSF3008ZA TAP SCREW M3 x 8mm 72 QYSBSF3008ZA TAP SCREW M3 x 8mm 73 GV30694-004A HEAT SINK

Block No. [M][1][M][M]

3-4



Symbol No. Part No. Part Name Description Local

74 GV40488-001A LEAF SPRING 75 QYSBSG3016EA TAP SCREW M3 x 16mm(x2) 76 QYSBSG3016EA TAP SCREW M3 x 16mm(x2) 77 QYSBSG3016EA TAP SCREW M3 x 16mm(x2) 78 QYSBSG3016EA TAP SCREW M3 x 16mm(x2) 79 GV10255-022A REAR PANEL A 79 GV10255-020A REAR PANEL UN,US 79 GV10255-019A REAR PANEL UW 79 GV10255-021A REAR PANEL UG,UX 80 GV10263-002A REAR COVER 81 QAU0307-003 TUNER 82 GV30686-001A FAN BKT. 83 QAR0317-001 FAN 84 GV30349-026A SPACER 85 QYSBSGY3008EA TAP SCREW AUX 86 QYSBSGY3008EA TAP SCREW HEAT SINK(x4) 87 QYSBSGY3008EA TAP SCREW EARTH PLATE 88 QYSBSGY3008EA TAP SCREW OPTICAL JACK 89 QYSBSGY3008EA TAP SCREW COMP. JACK(x2) 90 QYSBSGY3008EA TAP SCREW TUNNER PACK(x2) 91 QYSBSGY3008EA TAP SCREW VIDEO JACK 92 QYSBSGY3008EA TAP SCREW SPK. JACK(x2) 93 QYSBSGY3008EA TAP SCREW SPK. JACK(x2) 94 QYSBSGY3008EA TAP SCREW MECHA CHASSIS(x2) 95 QYSBSF3012EA TAP SCREW VOL. SELECTOR(x2) 96 QYSBSGY3008EA TAP SCREW METAL COVER(x8) 97 QYSBSGY3008EA TAP SCREW REAR COVER 98 LV41843-002A LASER CAUTION 99 GV30687-002A FL HOLDER 100 GV30349-021A SPACER (x2) 101 GV30349-049A SPACER 102 GV40531-001A LED HOLDER



103 QQT0477-001 POWER TRANSF T 1001



104 QMFZ051-8R0-J8 FUSE F 1001 8A



105 QMF51W2-6R3-J8 FUSE F 1002 6.3A AC250V



106 QMF51W2-6R3-J8 FUSE F 1003 6.3A AC250V



107 QMF51W2-6R3-J8 FUSE F 1004 6.3A AC250V



108 QMF51W2-1R25-J8 FUSE F 1005 1.25A AC250V



109 QMF51W2-3R15-J8 FUSE F 1006 3.15A AC250V



110 QMF51W2-5R0-J8 FUSE F 1007 5A AC250V



111 QMF51W2-5R0-J8 FUSE F 1008 5A AC250V



112 QMF51W2-5R0-J8 FUSE F 1009 5A AC250V



113 QMF51W2-5R0-J8 FUSE F 1010 5A AC250V 114 QUQH12-0910BJ-E FFC WIRE 9pin 10cm 115 QUQH12-1010BJ-E FFC WIRE 10pin 10cm 116 QUQH12-2512AJ-E FFC WIRE 25pin 12cm 117 QUQH12-1916AJ-E FFC WIRE 19pin 16cm 118 QUQH12-0808AJ-E FFC WIRE 8pin 8cm 119 QUQH10-1910AJ-E FFC WIRE 19pin 10cm 120 QUQH10-2823AJ-E FFC WIRE 28pin 23cm 121 QUQH10-1016AJ-E FFC WIRE 10pin 16cm 122 QUQH10-0814AJ-E FFC WIRE 8pin 14cm 123 QUQH12-1118AJ-E FFC WIRE 11pin 18cm 124 QUQH12-0516BJ-E FFC WIRE 5pin 16cm 125 QUQH12-0813AJ-E FFC WIRE 8pin 13cm 126 QUQH12-1118AJ-E FFC WIRE 11pin 18cm 127 GV40641-001A NOM LABEL UW 128 GV40642-001A CAUTION LABEL UW

3-5

Exploded view of general assembly and parts list

7

8

1

Block No.

(DX-T7)

96

61

E

96

9

M

2

M

121

56

41

40

38

39

24

23

25

47

129

44

37

3

37

4

43

96

D

C

96

8

7

127

6

5

g

D

24

20

96

A

23

25

FL board

102

101

17

C

B

Pr

17

6

17

12

17

29

26

116

29

26

2

21

45

10

1

11

15

34

36

32

22

B

21

13

14

35

31

22

F

36

31

Cassette A

33

30

49

34

32

101

48

103

99

46

115

F

46

35

33

G

52

30

49

48

G

52

a

Cassette B

42

18

16

18

t

52

54

53

Microphone amplifier board

125

3-6

56

B

17

103

6

115

46

29

assette B

29

C

17

121

116

26

56

123

122

Primary board

17

71

17

67

17

120

e

26

51

46

28

110

51

k

j

50

117

f

Amplifier 1 board

113

112

109

46

27

50

m

Video board

114

75

n

107

59

108

58

57

76

105

65

126

111

65

74

106

s

62

84

124

83

128

98

b

94

89

E

90

h

91

97

86

88

81

94

82

85

86

95

80

92

87

h

g

79

93

73

q

118

66

119

d

c

77

Amplifier 2 board

100

78

t

62

p

19

r

s

62

59

104

A

p

q

r

59

69

Bridge board

58

60

19

n

58

63

64

Surround terminal board

b

m

j k

c

d

e

f

Main board

72

a

68

70

3-7

General Assembly (DX-T7)



Symbol No. Part No. Part Name Description Local

1 GV10276-004A FRONT PANEL ASY 2 GV40077-002A JVC BADGE 3 GV30697-005A FL LENS 4 GV30698-004A BUTTON LENS 5 GV30699-001A TRAY FITTING 1 6 GV30700-001A TRAY FITTING 2 7 GV30701-001A TRAY FITTING 3 8 GV30702-001A TRAY FITTING 4 9 GV30703-001A TRAY FITTING 5 10 GV10273-001A CENTER BUTTON 11 GV40586-003A V.ILLUMINATION 12 GV40587-001A POWER INDICATOR 13 GV40588-001A RHYTM.INDICATOR 14 GV40628-001A SPACER 15 GV40600-002A REMOTE LENS 16 GV40608-001A MIC.VOL KNOB 17 QYSDSF2608ZA TAP SCREW M2.6 x 8mm(x11) 18 GV40313-001A FELT SPACER (x2) 19 GV40313-002A FELT SPACER (x2) 20 GV10260-001A MECHA CHASSIS 21 QYSSSF3010ZA TAP SCREW M3 x 10mm(x2) 22 GV40584-001A METAL COVER BKT (x2) 23 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 24 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 25 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 26 GV30124-001A TRANS SHIELD (x2) 27 GV30349-046A SPACER 28 GV30349-047A SPACER 29 GV30349-049A SPACER (x2) 30 GV40589-001A SWING CAM BKT (x2) 31 GV40501-002A SWING CAM (x2) 32 GV40502-002A SPRING (x2) 33 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 34 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 35 GV40503-001A WASHER (x2) 36 GV40504-002A SCREW (x2) 37 GV40515-001A METAL PIN (x2) 38 GV10262-001A CASS.HOLDER(A) 39 GV10261-001A CASS.HOLDER(B) 40 GV20344-001A CASS.LENS (A) 41 GV20343-001A CASS.LENS (B) 42 GV30705-001A LENS ORNAMENT 43 GV40596-001A DOOR SPRING(B) 44 GV40619-001A DOOR SPRING(A) 45 GV40034-001A DAMPER ASSY. (x2) 46 QYSBSF3010ZA TAP SCREW M3 x 10mm(x8) 47 VKY4180-401 CASSETTE SPRING (x4) 48 VKL7850-002 EJECT SAFTY(R) (x2) 49 VKW5258-003 TORSION SPRING (x2) 50 E65923-009 TAPPING SCREW (x2) 51 GV40618-001A SLC BRACKET (x2) 52 QYSBSFG3008ZA TAP SCREW M3 x 8mm(x3) 53 GV40035-002A SCREW 54 GV30349-050A SPACER 56 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 57 GV10253-004A BOTTOM CHASSIS 58 GV30706-001A SUPPORT BKT. (x3) 59 QYSBSG3006ZA TAP SCREW M3 x 6mm(x3) 60 QYSBSG3006ZA TAP SCREW M3 x 6mm 61 GV10254-003A/S/ METAL COVER 62 QYSDSTL4008EA TAP SCREW M4 x 8mm(x4)



63 QMPG150-244-JC POWER CORD(AST) 2.44m BLACK A



63 QMPK210-205-JN POWER CORD(EU) 2.05m BLACK UG,UN,US,UW,UX



64 QZW0033-001 STRAIN RELIEF 65 QYSSST3008ZA TAP SCREW M3 x 8mm(x2) 66 QYSBSF3008ZA TAP SCREW M3 x 8mm 67 QYSBSGG3008EA TAP SCREW M3 x 8mm 68 QYSBSGG3008EA TAP SCREW M3 x 8mm 69 QYSBSGG3008EA TAP SCREW M3 x 8mm 70 GV30349-025A SPACER 71 QYSBSF3008ZA TAP SCREW M3 x 8mm 72 QYSBSF3008ZA TAP SCREW M3 x 8mm 73 GV30694-002A HEAT SINK 74 GV40488-001A LEAF SPRING

Block No. [M][2][M][M]

3-8



Symbol No. Part No. Part Name Description Local

75 QYSBSG3016EA TAP SCREW M3 x 16mm(x2) 76 QYSBSG3016EA TAP SCREW M3 x 16mm(x2) 77 QYSBSG3016EA TAP SCREW M3 x 16mm(x2) 78 QYSBSG3016EA TAP SCREW M3 x 16mm 79 GV10255-023A REAR PANEL A 79 GV10255-017A REAR PANEL UN,US 79 GV10255-024A REAR PANEL UW 79 GV10255-018A REAR PANEL UG,UX 80 GV10263-002A REAR COVER 81 QAU0307-003 TUNER 82 GV30686-001A FAN BKT. 83 QAR0317-001 FAN 84 GV30349-026A SPACER 85 QYSBSGY3008EA TAP SCREW AUX 86 QYSBSGY3008EA TAP SCREW HEAT SINK(x4) 87 QYSBSGY3008EA TAP SCREW EARTH PLATE 88 QYSBSGY3008EA TAP SCREW OPTICAL JACK 89 QYSBSGY3008EA TAP SCREW COMP. JACK(x2) 90 QYSBSGY3008EA TAP SCREW TUNNER PACK(x2) 91 QYSBSGY3008EA TAP SCREW VIDEO JACK 92 QYSBSGY3008EA TAP SCREW SPK. JACK(x2) 93 QYSBSGY3008EA TAP SCREW SPK. JACK(x2) 94 QYSBSGY3008EA TAP SCREW MECHA CHASSIS(x2) 95 QYSBSF3012EA TAP SCREW VOL. SELECTOR(x2) 96 QYSBSGY3008EA TAP SCREW METAL COVER(x8) 97 QYSBSGY3008EA TAP SCREW REAR COVER 98 LV41843-002A LASER CAUTION 99 GV30687-002A FL HOLDER 101 GV30349-021A SPACER (x2) 102 GV30349-049A SPACER 103 GV40531-001A LED HOLDER



104 QQT0476-001 POWER TRANSF T 1001



105 QMF51W2-6R3-J8 FUSE F 1001 6.3A AC250V



106 QMF51W2-5R0-J8 FUSE F 1002 5A AC250V



107 QMF51W2-6R3-J8 FUSE F 1003 6.3A AC250V



108 QMF51W2-6R3-J8 FUSE F 1004 6.3A AC250V



109 QMF51W2-1R25-J8 FUSE F 1005 1.25A AC250V



110 QMF51W2-3R15-J8 FUSE F 1006 3.15A AC250V



111 QMF51W2-4R0-J8 FUSE F 1007 4A AC250V



112 QMF51W2-4R0-J8 FUSE F 1008 4A AC250V



113 QMF51W2-4R0-J8 FUSE F 1009 4A AC250V



114 QMF51W2-4R0-J8 FUSE F 1010 4A AC250V 115 QUQH12-0910BJ-E FFC WIRE 9pin 10cm 116 QUQH12-1010BJ-E FFC WIRE 10pin 10cm 117 QUQH12-2512AJ-E FFC WIRE 25pin 12cm 118 QUQH12-1916AJ-E FFC WIRE 19pin 16cm 119 QUQH12-0808AJ-E FFC WIRE 8pin 8cm 120 QUQH10-1910AJ-E FFC WIRE 19pin 10cm 121 QUQH10-2823AJ-E FFC WIRE 28pin 23cm 122 QUQH10-1016AJ-E FFC WIRE 10pin 16cm 123 QUQH10-0814AJ-E FFC WIRE 8pin 14cm 124 QUQH12-1118AJ-E FFC WIRE 11pin 18cm 125 QUQH12-0516BJ-E FFC WIRE 5pin 16cm 126 QUQH12-0813AJ-E FFC WIRE 8pin 13cm 127 QUQH12-1118AJ-E FFC WIRE 11pin 18cm 128 GV40641-001A NOM LABEL UW 129 GV40642-001A CAUTION LABEL UW

3-9

Exploded view of general assembly and parts list

5

6

8

1

Block No.

(DX-T5)

92

59

E

92

9

M

3

M

114

55

41

40

38

39

24

23

25

47

121

44

37

3

37

4

43

92

D

C

92

8

7

119

6

5

g

D

24

20

92

A

FL board

23

25

97

96

17

C

B

Pr

17

6

17

11

12

98

29

17

29

26

109

26

2

21

45

1

10

11

15

22

B

14

21

13

F

34

36

35

31

36

32

22

Cassette A

49

34

31

32

33

30

48

96

95

46

108

F

46

35

33

G

52

30

49

48

G

52

a

Cassette B

42

18

16

18

t

52

54

53

Microphone amplifier board

117

3-10

55

B

17

98

6

108

46

29

assette B

29

C

17

114

109

26

55

115

Primary board

17

69

17

65

17

113

e

26

51

46

28

105

51

j

50

110

f

Video board

Amplifier 1 board

107

104

46

27

50

56

103

n

102

m

73

58

57

100

63

118

106

63

72

101

s

60

80

116

79

120

94

b

89

85

E

86

h

87

93

82

84

77

89

78

81

82

91

76

88

83

h

g

75

90

71

q

111

64

112

d

c

Amplifier 2 board

74

t

60

p

r

s

60

58

Bridge board

n

57

61

62

b

99

m

j

Main board

70

19

c

d

e

f

57

19

A

p

q

58

r

67

a

66

68

3-11

General Assembly (DX-T5)



Symbol No. Part No. Part Name Description Local

1 GV10276-003A FRONT PANEL ASY 2 GV40077-002A JVC BADGE 3 GV30697-004A FL LENS 4 GV30698-003A BUTTON LENS 5 GV30699-001A TRAY FITTING 1 6 GV30700-001A TRAY FITTING 2 7 GV30701-001A TRAY FITTING 3 8 GV30702-001A TRAY FITTING 4 9 GV30703-001A TRAY FITTING 5 10 GV10273-002A CENTER BUTTON 11 GV40586-004A V.ILLUMINATION 12 GV40587-001A POWER INDICATOR 13 GV40588-001A RHYTM.INDICATOR 14 GV40628-001A SPACER 15 GV40600-002A REMOTE LENS 16 GV40608-001A MIC.VOL KNOB 17 QYSDSF2608ZA TAP SCREW M2.6 x 8mm(x11) 18 GV40313-001A FELT SPACER (x2) 19 GV40313-002A FELT SPACER (x2) 20 GV10260-001A MECHA CHASSIS 21 QYSSSF3010ZA TAP SCREW M3 x 10mm(x2) 22 GV40584-001A METAL COVER BKT (x2) 23 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 24 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 25 QYSDSG3008NA TAP SCREW M3 x 8mm(x2) 26 GV30124-001A TRANS SHIELD (x2) 27 GV30349-046A SPACER 28 GV30349-047A SPACER 29 GV30349-049A SPACER (x2) 30 GV40589-001A SWING CAM BKT (x2) 31 GV40501-002A SWING CAM (x2) 32 GV40502-002A SPRING (x2) 33 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 34 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 35 GV40503-001A WASHER (x2) 36 GV40504-002A SCREW (x2) 37 GV40515-001A METAL PIN (x2) 38 GV10262-001A CASS.HOLDER(A) 39 GV10261-001A CASS.HOLDER(B) 40 GV20344-001A CASS.LENS (A) 41 GV20343-001A CASS.LENS (B) 42 GV30705-002A LENS ORNAMENT 43 GV40596-001A DOOR SPRING(B) 44 GV40619-001A DOOR SPRING(A) 45 GV40034-001A DAMPER ASSY. (x2) 46 QYSBSF3010ZA TAP SCREW M3 x 10mm(x8) 47 VKY4180-401 CASSETTE SPRING (x4) 48 VKL7850-002 EJECT SAFTY(R) (x2) 49 VKW5258-003 TORSION SPRING (x2) 50 E65923-009 TAPPING SCREW (x2) 51 GV40618-001A SLC BRACKET (x2) 52 QYSBSFG3008ZA TAP SCREW M3 x 8mm(x3) 53 GV40035-002A SCREW 54 GV30349-050A SPACER 55 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2) 56 GV10253-004A BOTTOM CHASSIS 57 GV30706-001A SUPPORT BKT. (x3) 58 QYSBSG3006ZA TAP SCREW M3 x 6mm(x3) 59 GV10254-003A/S/ METAL COVER 60 QYSDSTL4008EA TAP SCREW M4 x 8mm(x4)



61 QMPK210-205-JN POWER CORD(EU) 2.05m BLACK UG,UN,US,UW,UX



61 QMPR300-200-JC POWER CORD(EU) 2m BLACK UY



62 QZW0033-001 STRAIN RELIEF 63 QYSSST3008ZA TAP SCREW M3 x 8mm(x2) 64 QYSBSF3008ZA TAP SCREW M3 x 8mm 65 QYSBSGG3008EA TAP SCREW M3 x 8mm 66 QYSBSGG3008EA TAP SCREW M3 x 8mm 67 QYSBSGG3008EA TAP SCREW M3 x 8mm 68 GV30349-025A SPACER 69 QYSBSF3008ZA TAP SCREW M3 x 8mm 70 QYSBSF3008ZA TAP SCREW M3 x 8mm 71 GV30694-004A HEAT SINK 72 GV40488-001A LEAF SPRING 73 QYSBSG3016EA TAP SCREW M3 x 16mm(x2)

Block No. [M][3][M][M]

3-12



Symbol No. Part No. Part Name Description Local

74 QYSBSG3016EA TAP SCREW M3 x 16mm(x2) 75 GV10255-015A REAR PANEL UN,US 75 GV10255-013A REAR PANEL UW 75 GV10255-016A REAR PANEL UG,UX 75 GV10255-014A REAR PANEL UY 76 GV10263-002A REAR COVER 77 QAU0307-003 TUNER 78 GV30686-001A FAN BKT. 79 QAR0317-001 FAN 80 GV30349-026A SPACER 81 QYSBSGY3008EA TAP SCREW AUX 82 QYSBSGY3008EA TAP SCREW HEAT SINK(x4) 83 QYSBSGY3008EA TAP SCREW EARTH PLATE 84 QYSBSGY3008EA TAP SCREW OPTICAL JACK 85 QYSBSGY3008EA TAP SCREW COMP. JACK(x2) 86 QYSBSGY3008EA TAP SCREW TUNNER PACK(x2) 87 QYSBSGY3008EA TAP SCREW VIDEO JACK 88 QYSBSGY3008EA TAP SCREW SPK. JACK(x2) 89 QYSBSGY3008EA TAP SCREW MECHA CHASSIS(x2) 90 QYSBSGY3008EA TAP SCREW SUB WOOFER 91 QYSBSF3012EA TAP SCREW VOL. SELECTOR(x2) 92 QYSBSGY3008EA TAP SCREW METAL COVER(x8) 93 QYSBSGY3008EA TAP SCREW REAR COVER 94 LV41843-002A LASER CAUTION 95 GV30687-002A FL HOLDER 96 GV30349-021A SPACER (x2) 97 GV30349-049A SPACER 98 GV40531-001A LED HOLDER



99 QQT0475-001 POWER TRANSF T 1001



100 QMF51W2-6R3-J8 FUSE F 1001 6.3A AC250V



101 QMF51W2-3R15-J8 FUSE F 1002 3.15A AC250V



102 QMF51W2-6R3-J8 FUSE F 1003 6.3A AC250V



103 QMF51W2-6R3-J8 FUSE F 1004 6.3A AC250V



104 QMF51W2-1R25-J8 FUSE F 1005 1.25A AC250V



105 QMF51W2-3R15-J8 FUSE F 1006 3.15A AC250V



106 QMF51W2-6R3-J8 FUSE F 1007 6.3A AC250V



107 QMF51W2-6R3-J8 FUSE F 1008 6.3A AC250V 108 QUQH12-0910BJ-E FFC WIRE 9pin 10cm 109 QUQH12-1010BJ-E FFC WIRE 10pin 10cm 110 QUQH12-2512AJ-E FFC WIRE 25pin 12cm 111 QUQH12-1316AJ-E FFC WIRE 13pin 16cm 112 QUQH12-0808AJ-E FFC WIRE 8pin 8cm 113 QUQH10-1910AJ-E FFC WIRE 19pin 10cm 114 QUQH10-2823AJ-E FFC WIRE 28pin 23cm 115 QUQH10-1016AJ-E FFC WIRE 10pin 16cm 116 QUQH12-1118AJ-E FFC WIRE 11pin 18cm 117 QUQH12-0516BJ-E FFC WIRE 5pin 16cm 118 QUQH12-0813AJ-E FFC WIRE 8pin 13cm 119 QUQH12-1118AJ-E FFC WIRE 11pin 18cm 120 GV40641-001A NOM LABEL UW 120 LV42938-001A LABEL UY 121 GV40642-001A CAUTION LABEL UW

3-13

DVD mechanism assembly and parts list

(Common)

FXL-D8-1M

Grease

=JVG-31N =JVS-1003

Block No.

11

12

M

J

13

M

Letter side

18

4

5

Letter side

14

15

16

19

14

10

1

17

2.4mm + 0.1mm

8

APPLY AREA

9

-

20

6

7

7.0mm + 0.1mm

-

21

3

2

21

Reverse side

The parts without symbol number are not service.

3-14

DVD mechanism (Common)



Symbol No. Part No. Part Name Description Local

1 LV10985-001A C.TM CHASSIS 2 QAR0334-002 S.MOTOR 3 QYSPSPU1740ZA SCREW M1.7 x 4mm(x3) 4 QAR0144-003 MOTOR 5 VKS5557-001 F.M. GEAR 6 QYSPSPT2025ZA SCREW M2 x 2.5mm 7 LV35461-002A MIDDLE GEAR 8 LV44040-001A SCREW SHAFT 9 LV35462-001A SCREW SHAFT GEA 10 QAL0667-001 DVD PICK 11 LV21869-001A RACK ARM 12 LV35463-001A RACK ARM SPRING 13 QYSPSFU1740ZA TAP SCREW M1.7 x 4mm(x2) 14 LV44041-001A GUIDE SHAFT (x2) 15 LV35464-001A G.SHAFT ADJ.SP 16 QYSDSF2005ZA TAP SCREW M2 x 5mm 17 LV35465-001A THRUST SPRING 18 LV44042-001A ROD SPRING 19 LV35467-001A FEED BRACKET 20 QYSDSF2005ZA TAP SCREW M2 x 5mm 21 LV44046-001A ADJUST SCREW (x4)

Block No. [M][J][M][M]

3-15

DVD changer mechanism assembly and parts list (DX-T9,DX-T7)

M

K

Grease

=JVG-31N =JVS-1003

FMU-SM1-1M

CH5-BASE-1M

Block No.

37

36

35

M

24

13

8

27

26

C

34

F

31

11

12

3

2

16

15

20

29

22

E

B

25

27

9

A

10

23

21

B

33

6

d

1

7

c

47

C

A

G

E

G

b

F

5

d

4

6.5mm 0.1mm

4

38

a

41

e

32

46

30

14

17

18

19

40

28

f

40

44

39

43

3-16

42

44

e

f

b

c

a

45

The parts without symbol number are not service.

45

DVD changer mechanism(FMU-SM1-1M) (DX-T9,DX-T7)



Symbol No. Part No. Part Name Description Local

1 LV10913-004A LOADER ASSY 2 QVY0027-B14 S V RESISTOR 3 QYSDST2004ZA TAP SCREW M2 x 4mm 4 QAR0164-001 MOTOR (x2) 5 LV42340-001A MOTOR PULLEY (x2) 6 LV41431-002A BELT (x2) 7 QYSPSPU1725NA SCREW M1.7 x 2.5mm(x2) 8 LV33965-004A LIFTER ASSY 9 LV33963-001A HOOK 10 LV33964-002A HOOK STOPPER 11 LV43285-001A ROD (L) 12 LV21408-002A RAIL(R) 13 LV21409-002A RAIL(L) 14 LV21520-004A SIDE(R) ASSY 15 LV33974-002A SELECT LEVER 16 LV33977-002A CLICK SPRING 17 LV33975-001A GEAR COVER 18 LV33976-002A ELEVATOR CAM 19 LV43287-001A ELEVATOR SPRING 20 QYSDST2605ZA TAP SCREW M2.6 x 5mm(x3) 21 LV10749-002A SIDE(L) 22 LV33980-002A OPEN DET.LEVER 23 QYSDST2605ZA TAP SCREW M2.6 x 5mm(x2) 24 LV10746-006A TRAY ASSY (x5) 25 LV10750-003A TOP COVER 26 LV43289-003A ROD (x2) 27 QYSDSF2608ZA TAP SCREW M2.6 x 8mm(x2) 28 QYSDST2605ZA TAP SCREW M2.6 x 5mm(x2) 29 QYSDSF2608ZA TAP SCREW M2.6 x 8mm 30 QYSDST2605ZA TAP SCREW M2.6 x 5mm 31 QYSDST2004ZA TAP SCREW M2 x 4mm 32 WJM0330-002A-E E-SI C WIRE C-F 33 WJM0331-001A-E E-SI C WIRE C-F 34 LV32417-001A CLAMPER 35 LV42930-003A P.C.MAGNET 36 LV33992-001A DVD YOKE 37 LV41741-003A SPECIAL SCREW 38 QUQ110-1508BJ FFC WIRE 15pin 8cm 39 LV44043-002A INSULATOR (x2) 40 LV44043-003A INSULATOR (x2) 41 LV44045-001A SPECIAL SCREW (x4) 42 LV44092-002A PICK FFC 43 LV10986-001A TRAMECHA HOLDER 44 QYSDST2605ZA TAP SCREW M2.6 x 5mm(x3) 45 LV44209-001A WASHER SCREW (x2) 46 ------------------ DVD TRAMECHA 47 QYSDST2605ZA SCREW M2.6 x 5 mm

Block No. [M][K][M][M]

3-17

DVD changer mechanism assembly and parts list (DX-T5)

Block No.

Grease

=JVG-31N =JVS-1003

FMU-SM1-11M

CH5-BASE-1M

37

36

35

M

S

24

13

8

27

26

C

34

F

31

11

12

3

2

16

15

20

29

22

E

B

25

27

9

A

10

23

21

B

33

6

d

1

7

c

47

C

A

G

E

G

b

F

5

d

4

6.5mm 0.1mm

4

38

a

41

e

32

46

30

14

17

18

19

40

28

f

40

44

39

43

3-18

42

44

e

f

b

c

a

45

The parts without symbol number are not service.

45

DVD changer mechanism(FMU-SM1-11M) (DX-T5)



Symbol No. Part No. Part Name Description Local

1 LV10913-004A LOADER ASSY 2 QVY0027-B14 S V RESISTOR 3 QYSDST2004ZA TAP SCREW M2 x 4mm 4 QAR0164-001 MOTOR (x2) 5 LV42340-001A MOTOR PULLEY (x2) 6 LV41431-002A BELT (x2) 7 QYSPSPU1725NA SCREW M1.7 x 2.5mm(x2) 8 LV33965-004A LIFTER ASSY 9 LV33963-001A HOOK 10 LV33964-002A HOOK STOPPER 11 LV43285-001A ROD (L) 12 LV21408-002A RAIL(R) 13 LV21409-002A RAIL(L) 14 LV21520-004A SIDE(R) ASSY 15 LV33974-002A SELECT LEVER 16 LV33977-002A CLICK SPRING 17 LV33975-001A GEAR COVER 18 LV33976-002A ELEVATOR CAM 19 LV43287-001A ELEVATOR SPRING 20 QYSDST2605ZA TAP SCREW M2.6 x 5mm(x3) 21 LV10749-002A SIDE(L) 22 LV33980-002A OPEN DET.LEVER 23 QYSDST2605ZA TAP SCREW M2.6 x 5mm(x2) 24 LV10746-006A TRAY ASSY (x5) 25 LV10750-003A TOP COVER 26 LV43289-003A ROD (x2) 27 QYSDSF2608ZA TAP SCREW M2.6 x 8mm(x2) 28 QYSDST2605ZA TAP SCREW M2.6 x 5mm(x2) 29 QYSDSF2608ZA TAP SCREW M2.6 x 8mm 30 QYSDST2605ZA TAP SCREW M2.6 x 5mm 31 QYSDST2004ZA TAP SCREW M2 x 4mm 32 WJM0330-002A-E E-SI C WIRE C-F 33 WJM0331-001A-E E-SI C WIRE C-F 34 LV32417-001A CLAMPER 35 LV42930-003A P.C.MAGNET 36 LV33992-001A DVD YOKE 37 LV41741-003A SPECIAL SCREW 38 QUQ110-1508BJ FFC WIRE 15pin 8cm 39 LV44043-002A INSULATOR (x2) 40 LV44043-003A INSULATOR (x2) 41 LV44045-001A SPECIAL SCREW (x4) 42 LV44092-002A PICK FFC 43 LV10986-001A TRAMECHA HOLDER 44 QYSDST2605ZA TAP SCREW M2.6 x 5mm(x3) 45 LV44209-001A WASHER SCREW (x2) 46 ------------------- DVD TRAMECHA 47 QYSDST2605ZA SCREW M2.6 x 5 mm

Block No. [M][S][M][M]

3-19

Cassette mechanism assembly and parts list

Cassette A (Common)

Grease

= EM-30L =UD-24 =LEN-320M =MOBIL-1

8

2

3

SLC-S401M

2

15

10

16

14

9

Block No.

M

P

M

11

34

13

27

1

12

23

3

4

7

29

C

11

1

6

5

The lower side

24

5

6

25

22

17

Switch board

30

18

21

B

A

19

20

3-20

28

31

26

C

36

A

32

33

B

Head amplifier board

35

33

32

0.1

0.15 mm

_

+

8.7

The parts without symbol number are not service.

Cassette mechanism(SLC-S401M)-Cassette A (Common)



Symbol No. Part No. Part Name Description Local

1 VKS1165-00N CHASSIS B. ASSY 2 VKS2274-002 REEL GEAR (x2) 3 VKW5286-002 B.T. SPRING (x2) 4 VKS5559-001 PLAY IDLE GEAR 5 VKS5595-002 BLIND 6 VKS5560-003 FR IDLE GEAR 7 LV42013-001A EARTH SPRING 8 VKS2279-00GSS HEAD MOUNT ASSY 9 VKY3149-002 CASSETTE SP. 10 LV31786-004A PLAY SW LEVER 11 VKS1166-003 CONTROL CAM 12 VKW5279-002 HEAD BASE SP(R) 13 VKW5280-001 HEAD BASE SP(L) 14 LV41584-001A BRAKE(R) 15 LV41585-003A BRAKE(L) 16 LV44098-001A SPECIAL SCREW 17 VKS5603-00H MAIN PULLEY ASS 18 VKS3785-001MM FR ARM 19 VKW5284-002 SWING SPRING 20 VKS2278-003 TRIGGER ARM 21 VKW5301-001 FR SPRING 22 VKW5266-001 ELEVATOR SPRING 23 WDL214025 WASHER 24 QYSBSF2005ZA TAP SCREW M2 x 5mm 25 VKS3786-00G CLUTCH ASSY 26 VKF3205-00B F.WHEEL ASSY(R) 27 WDL183425 SLIT WASHER 28 VKF3207-00C F.WHEEL ASSY(L) 29 WDL173525-6 SLIT WASHER 30 VKZ3174-00B DC SOLENOID 31 LV42836-001A CAPSTAN BELT 32 QAR0309-001 D.C.MOTOR 33 VKR4761-003 MOTOR PULLEY 34 QYSPSP2604ZA SCREW M2.6 x 4mm(x2) 35 QYSBSF2608ZA TAP SCREW M2.6 x 8mm(x3) 36 QUQH12-0906BF FFC WIRE 9pin 6cm

Block No. [M][P][M][M]

3-21

Cassette mechanism assembly and parts list

Cassette B (Common)

SLC-S302M

2

15

10

Grease

= EM-30L =UD-24 =LEN-320M =MOBIL-1

8

2

3

16

14

Block No.

9

M

Q

11

34

13

27

1

12

23

3

4

11

7

29

C

1

6

5

The lower side

24

5

6

25

22

17

Switch board

30

18

21

A

B

19

20

3-22

28

31

26

C

36

A

32

33

B

35

Head amplifier board

35

33

32

0.1

0.15 mm

_

+

8.7

The parts without symbol number are not service.

Cassette mechanism(SLC-S302M)-CassetteB (Common)



Symbol No. Part No. Part Name Description Local

1 VKS1165-00N CHASSIS B. ASSY 2 VKS2274-002 REEL GEAR (x2) 3 VKW5286-002 B.T. SPRING (x2) 4 VKS5559-001 PLAY IDLE GEAR 5 VKS5595-002 BLIND 6 VKS5560-003 FR IDLE GEAR 7 LV42013-001A EARTH SPRING 8 SLC-RP4SVM HEAD MOUNT ASSY 9 VKY3149-002 CASSETTE SP. 10 LV31786-002A PLAY LEVER 11 VKS1166-003 CONTROL CAM 12 VKW5279-002 HEAD BASE SP(R) 13 VKW5280-001 HEAD BASE SP(L) 14 LV41584-001A BRAKE(R) 15 LV41585-003A BRAKE(L) 16 QYSBSF2005Z SCREW 2mm x 5mm 17 VKS5603-00G MAIN PULLEY ASS 18 VKS3785-001MM FR ARM 19 VKW5284-002 SWING SPRING 20 VKS2278-003 TRIGGER ARM 21 VKW5301-001 FR SPRING 22 VKW5266-001 ELEVATOR SPRING 23 WDL214025 WASHER 24 QYSBSF2005Z SCREW 2mm x 5mm 25 VKS3786-00G CLUTCH ASSY 26 VKF3205-00B F.WHEEL ASSY(R) 27 WDL183425 SLIT WASHER 28 VKF3207-00C F.WHEEL ASSY(L) 29 WDL173525-6 SLIT WASHER 30 VKZ3174-00B DC SOLENOID 31 LV42836-001A CAPSTAN BELT 32 MSI-5U2LWA D.C.MOTOR 33 VKR4761-003 MOTOR PULLEY 34 QYSPSP2604Z SCREW 2.6mm x 4mm(x2) 35 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x3) 36 QUQH12-0906BF WIRE

Block No. [M][Q][M][M]

3-23

Electrical parts list

Amplifier board (DX-T9)



Symbol No.



IC301 STK413-430 IC



IC302 KIA7809API IC



IC303 KIA7805API IC



IC304 KIA7810API IC



IC305 KIA278R05PI TRANSISTOR



IC306 KIA278R09PI TRANSISTOR



IC307 KIA317PI IC



IC308 KIA7805API IC



IC401 STK412-430 POWER I.C



IC402 STK412-430 POWER I.C IC500 PT6305 FL DRIVER IC510 GP1UM281XKVF IR DETECT UNIT

Q3101 KTC3200/GL/-T TRANSISTOR Q3102 KTA1023/OY/-T TRANSISTOR Q3103 KTA1268/GL/-T TRANSISTOR Q3104 KTC1027/OY/-T TRANSISTOR Q3401 KTC3199/GL/-T TRANSISTOR Q3501 KTC3199/GL/-T TRANSISTOR Q3601 KTC3199/GL/-T TRANSISTOR Q3901 KTC3203/OY/-T TRANSISTOR Q3902 KRC102M-T DIGI TRANSISTOR Q4101 KTC3199/GL/-T TRANSISTOR Q4201 KTC3199/GL/-T TRANSISTOR Q4401 KTC3200/GL/-T TRANSISTOR Q4402 KTA1023/OY/-T TRANSISTOR Q4403 KTA1268/GL/-T TRANSISTOR Q4404 KTC1027/OY/-T TRANSISTOR Q4601 KTC3199/GL/-T TRANSISTOR Q4701 KTC3199/GL/-T TRANSISTOR Q4901 KTC1027/OY/-T TRANSISTOR Q4902 KTA1023/OY/-T TRANSISTOR Q4903 KTC3199/GL/-T TRANSISTOR Q4904 KTA1023/OY/-T TRANSISTOR Q5004 KRC102M-T DIGI TRANSISTOR Q5005 KRC102M-T DIGI TRANSISTOR Q5006 KRC102M-T DIGI TRANSISTOR Q5007 KRC102M-T DIGI TRANSISTOR Q5008 KTA1023/OY/-T TRANSISTOR Q5009 KRC102M-T DIGI TRANSISTOR Q5010 KRC110M-T TRANSISTOR Q5011 KTC3199/GL/-T TRANSISTOR

D3101 1SS119-041-T2 DIODE D3301 MTZJ15B-T2 Z DIODE D3302 MTZJ15B-T2 Z DIODE D3303 MTZJ36A-T2 Z DIODE D3304 MTZJ36A-T2 Z DIODE D3401 1SS119-041-T2 DIODE D3501 1SS119-041-T2 DIODE D3601 1SS119-041-T2 DIODE D3701 MTZJ5.6C-T2 Z DIODE D3811 MTZJ11B-T2 Z DIODE D3821 MTZJ11C-T2 Z DIODE D3831 1SS119-041-T2 DIODE D3832 MTZJ6.2B-T2 Z DIODE D3841 MTZJ11B-T2 Z DIODE D3901 MTZJ15A-T2 Z DIODE D3902 1SS119-041-T2 DIODE D4001 MTZJ15B-T2 Z DIODE D4002 MTZJ15B-T2 Z DIODE D4003 MTZJ36A-T2 Z DIODE D4004 MTZJ36A-T2 Z DIODE D4101 1SS119-041-T2 DIODE D4201 1SS119-041-T2 DIODE D4401 1SS119-041-T2 DIODE D4501 MTZJ15B-T2 Z DIODE D4502 MTZJ15B-T2 Z DIODE D4503 MTZJ36A-T2 Z DIODE D4504 MTZJ36A-T2 Z DIODE D4601 1SS119-041-T2 DIODE D4701 1SS119-041-T2 DIODE

Part No. Part Name Description Local

Block No. [0][1]



Symbol No.

D4901 1SS119-041-T2 DIODE D5004 SLI-343URC-W-T LED D5005 SLI-343URC-W-T LED D5006 SELU2E10C-P LED D5007 SLR-343VC-T LED

C3101 QETN1AM-107Z E CAPACITOR 100uF 10V M C3102 QFZ0212-104Z M CAPACITOR 0.1uF C3103 QFZ0212-104Z M CAPACITOR 0.1uF C3104 QETN1HM-105Z E CAPACITOR 1uF 50V M C3201 QCBB1HK-221Y C CAPACITOR 220pF 50V K C3202 QETN1HM-106Z E CAPACITOR 10uF 50V M C3203 QCBB1HK-471Y C CAPACITOR 470pF 50V K C3211 QCBB1HK-221Y C CAPACITOR 220pF 50V K C3212 QETN1HM-106Z E CAPACITOR 10uF 50V M C3213 QCBB1HK-471Y C CAPACITOR 470pF 50V K C3221 QCBB1HK-221Y C CAPACITOR 220pF 50V K C3222 QETN1HM-106Z E CAPACITOR 10uF 50V M C3223 QCBB1HK-471Y C CAPACITOR 470pF 50V K C3402 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C3403 QETN1JM-476Z E CAPACITOR 47uF 63V M C3404 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C3405 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C3502 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C3503 QETN1JM-476Z E CAPACITOR 47uF 63V M C3504 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C3505 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C3602 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C3603 QETN1JM-476Z E CAPACITOR 47uF 63V M C3604 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C3605 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C3701 QETN1EM-476Z E CAPACITOR 47uF 25V M C3702 QETN1CM-107Z E CAPACITOR 100uF 16V M C3811 QETN1EM-476Z E CAPACITOR 47uF 25V M C3812 QETN1CM-107Z E CAPACITOR 100uF 16V M C3821 QETN1EM-476Z E CAPACITOR 47uF 25V M C3822 QETN1CM-107Z E CAPACITOR 100uF 16V M C3831 QETN1EM-476Z E CAPACITOR 47uF 25V M C3832 QETN1CM-107Z E CAPACITOR 100uF 16V M C3841 QETN1EM-476Z E CAPACITOR 47uF 25V M C3842 QETN1CM-107Z E CAPACITOR 100uF 16V M C3851 QETN1EM-476Z E CAPACITOR 47uF 25V M C3852 QETN1CM-107Z E CAPACITOR 100uF 16V M C4102 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C4103 QETN1JM-476Z E CAPACITOR 47uF 63V M C4104 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4105 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4202 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C4203 QETN1JM-476Z E CAPACITOR 47uF 63V M C4204 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4205 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4301 QCBB1HK-221Y C CAPACITOR 220pF 50V K C4302 QTE1V06-106Z E CAPACITOR 10uF 35V C4311 QCBB1HK-221Y C CAPACITOR 220pF 50V K C4312 QTE1V06-106Z E CAPACITOR 10uF 35V C4313 QCBB1HK-471Y C CAPACITOR 470pF 50V K C4401 QETN1AM-107Z E CAPACITOR 100uF 10V M C4402 QFZ0212-104Z M CAPACITOR 0.1uF C4403 QFZ0212-104Z M CAPACITOR 0.1uF C4404 QETN1HM-105Z E CAPACITOR 1uF 50V M C4405 QETN1HM-105Z E CAPACITOR 1uF 50V M C4602 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C4603 QETN1JM-476Z E CAPACITOR 47uF 63V M C4604 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4605 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4702 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C4703 QETN1JM-476Z E CAPACITOR 47uF 63V M C4704 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4705 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4801 QCBB1HK-221Y C CAPACITOR 220pF 50V K C4802 QTE1V06-106Z E CAPACITOR 10uF 35V C4803 QCBB1HK-101Y C CAPACITOR 100pF 50V K C4811 QCBB1HK-221Y C CAPACITOR 220pF 50V K C4812 QTE1V06-106Z E CAPACITOR 10uF 35V C4813 QCBB1HK-101Y C CAPACITOR 100pF 50V K C4901 QETN1HM-106Z E CAPACITOR 10uF 50V M

Part No. Part Name Description Local

3-24



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C4902 QETN1CM-476Z E CAPACITOR 47uF 16V M C4903 QETN1HM-106Z E CAPACITOR 10uF 50V M C5000 QETN1HM-226Z E CAPACITOR 22uF 50V M C5001 QETN1HM-226Z E CAPACITOR 22uF 50V M C5002 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C5003 QEKC1EM-106Z E CAPACITOR 10uF 25V M C5004 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C5005 QCBB1HK-101Y C CAPACITOR 100pF 50V K C5006 QEKC1AM-107Z E CAPACITOR 100uF 10V M C5007 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K

R3101 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R3102 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R3103 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R3104 QRE141J-103Y C RESISTOR 10kΩ 1/4W J



R3105 QRJ146J-470X UNF C RESISTOR 47Ω 1/4W J R3106 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R3107 QRE141J-103Y C RESISTOR 10kΩ 1/4W J



R3108 QRJ146J-470X UNF C RESISTOR 47Ω 1/4W J R3201 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R3202 QRE141J-102Y C RESISTOR 1k R3203 QRE141J-102Y C RESISTOR 1k R3204 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R3205 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R3206 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R3301 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R3302 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R3303 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R3304 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J



R3305 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R3306 QRE141J-333Y C RESISTOR 33kΩ 1/4W J



R3401 QRZ0224-R22 EMIT RESISTOR 0.22 R3402 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R3403 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R3404 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R3405 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R3406 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R3407 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R3408 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J



R3409 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R3410 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R3411 QRE141J-202Y C RESISTOR 2kΩ 1/4W J



R3501 QRZ0224-R22 EMIT RESISTOR 0.22 R3502 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R3503 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J



R3504 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R3505 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R3506 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R3507 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R3508 QRE141J-562Y C RESISTOR 5.6k



R3509 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R3510 QRE141J-104Y C RESISTOR 100k R3511 QRE141J-202Y C RESISTOR 2k



R3601 QRZ0224-R22 EMIT RESISTOR 0.22 R3602 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R3603 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R3604 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R3605 QRE141J-102Y C RESISTOR 1k R3606 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R3607 QRE141J-473Y C RESISTOR 47k R3608 QRE141J-562Y C RESISTOR 5.6k



R3609 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R3610 QRE141J-104Y C RESISTOR 100k R3611 QRE141J-202Y C RESISTOR 2k R3701 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R3831 QRE141J-102Y C RESISTOR 1k



R3901 QRJ146J-4R7X UNF C RESISTOR 4.7Ω 1/4W J R3902 QRE141J-242Y C RESISTOR 2.4k R3903 QRE141J-470Y C RESISTOR 47 R3904 QRE141J-221Y C RESISTOR 220Ω 1/4W J R3905 QRE141J-242Y C RESISTOR 2.4k R3906 QRE141J-103Y C RESISTOR 10k R3907 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R3908 QRE141J-103Y C RESISTOR 10k R4001 QRE141J-682Y C RESISTOR 6.8k R4002 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R4003 QRE141J-682Y C RESISTOR 6.8k R4004 QRE141J-682Y C RESISTOR 6.8k

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J



R4005 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4006 QRE141J-333Y C RESISTOR 33kΩ 1/4W J



R4101 QRZ0224-R22 EMIT RESISTOR 0.22 R4102 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R4103 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4104 QRJ146J-100X UNF C RESISTOR 10 R4105 QRE141J-102Y C RESISTOR 1k R4106 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R4107 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R4108 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R4109 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R4110 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R4111 QRE141J-202Y C RESISTOR 2kΩ 1/4W J



R4201 QRZ0224-R22 EMIT RESISTOR 0.22 R4202 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R4203 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4204 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4205 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R4206 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R4207 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R4208 QRE141J-562Y C RESISTOR 5.6k R4209 QRJ146J-681X UNF C RESISTOR 680 R4210 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R4211 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R4302 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R4311 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R4312 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R4401 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R4402 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R4403 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R4404 QRE141J-103Y C RESISTOR 10kΩ 1/4W J



R4405 QRJ146J-470X UNF C RESISTOR 47Ω 1/4W J R4406 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R4407 QRE141J-103Y C RESISTOR 10kΩ 1/4W J



R4408 QRJ146J-470X UNF C RESISTOR 47Ω 1/4W J R4501 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R4502 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R4503 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R4504 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J



R4505 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4506 QRE141J-333Y C RESISTOR 33kΩ 1/4W J



R4601 QRZ0224-R22 EMIT RESISTOR 0.22 R4602 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R4603 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4604 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4605 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R4606 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R4607 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R4608 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J



R4609 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R4610 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R4611 QRE141J-202Y C RESISTOR 2k



R4701 QRZ0224-R22 EMIT RESISTOR 0.22 R4702 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R4703 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J



R4704 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4705 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R4706 QRE141J-202Y C RESISTOR 2k R4707 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R4708 QRE141J-562Y C RESISTOR 5.6k



R4709 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R4710 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R4711 QRE141J-202Y C RESISTOR 2k R4801 QRE141J-102Y C RESISTOR 1k R4802 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R4811 QRE141J-102Y C RESISTOR 1k R4812 QRE141J-563Y C RESISTOR 56k R4901 QRE141J-103Y C RESISTOR 10k R4902 QRE141J-104Y C RESISTOR 100k R4903 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R4904 QRE141J-104Y C RESISTOR 100k R4905 QRE141J-103Y C RESISTOR 10k R4906 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R5000 QRE141J-102Y C RESISTOR 1k R5001 QRE141J-102Y C RESISTOR 1k R5002 QRE141J-122Y C RESISTOR 1.2kΩ 1/4W J R5003 QRE141J-152Y C RESISTOR 1.5k R5004 QRE141J-222Y C RESISTOR 2.2k

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

3-25



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R5005 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5006 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5007 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R5008 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R5009 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5010 QRE141J-102Y C RESISTOR 1k R5011 QRE141J-122Y C RESISTOR 1.2k R5012 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5013 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R5014 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5015 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5016 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5017 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5018 QRE141J-122Y C RESISTOR 1.2kΩ 1/4W J R5019 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5020 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R5021 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5022 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5023 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R5024 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5025 QRE141J-102Y C RESISTOR 1k R5026 QRE141J-122Y C RESISTOR 1.2k R5027 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5028 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R5029 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5030 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5035 QRE141J-161Y C RESISTOR 160Ω 1/4W J R5036 QRE141J-161Y C RESISTOR 160Ω 1/4W J R5037 QRE141J-560Y C RESISTOR 56Ω 1/4W J R5038 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5039 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5040 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5041 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5042 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R5043 QRE141J-271Y C RESISTOR 270Ω 1/4W J R5044 QRE141J-821Y C RESISTOR 820Ω 1/4W J R5045 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R5046 QRE141J-104Y C RESISTOR 100kΩ 1/4W J

L3401 QQLZ035-R39 COIL 0.39uH L3501 QQLZ035-R39 COIL 0.39uH L3601 QQLZ035-R39 COIL 0.39uH L4101 QQLZ035-R39 COIL 0.39uH L4201 QQLZ035-R39 COIL 0.39uH L4601 QQLZ035-R39 COIL 0.39uH L4701 QQLZ035-R39 COIL 0.39uH

CN301 QGB2510K2-20 CONNECTOR B-B (1-20) CN302 QGF1205C1-19 CONNECTOR FFC/FPC (1-19) CN303 QGF1205F1-11 CONNECTOR FFC/FPC (1-11) CN304 QGA2501F1-03 CONNECTOR W-B (1-3) CN401 QGB2510K2-16 CONNECTOR B-B (1-16) CN402 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN500 QGF1036F1-19 CONNECTOR FFC/FPC (1-19) CN990 QGB2510J1-06 CONNECTOR B-B (1-6) FL500 QLF0150-001 FL TUBE FW401 QUM154-10Z4Z4-E FLAT WIRE FW500 QUM153-18DGZ4-E FLAT WIRE J990 QNB0263-001 SPK TERMINAL S5000 QSW1121-001Z PUSH SW I.M S5001 QSW1121-001Z PUSH SW I.M S5002 QSW1121-001Z PUSH SW I.M S5003 QSW1121-001Z PUSH SW I.M S5004 QSW1121-001Z PUSH SW I.M S5005 QSW1121-001Z PUSH SW I.M S5006 QSW1121-001Z PUSH SW I.M S5007 QSW1121-001Z PUSH SW I.M S5008 QSW1121-001Z PUSH SW I.M S5009 QSW1121-001Z PUSH SW I.M S5010 QSW1121-001Z PUSH SW I.M S5011 QSW1121-001Z PUSH SW I.M S5012 QSW1121-001Z PUSH SW I.M S5013 QSW1121-001Z PUSH SW I.M S5014 QSW1121-001Z PUSH SW I.M S5015 QSW1121-001Z PUSH SW I.M S5016 QSW1121-001Z PUSH SW I.M S5017 QSW1121-001Z PUSH SW I.M S5018 QSW1121-001Z PUSH SW I.M

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

S5019 QSW1121-001Z PUSH SW I.M S5020 QSW1121-001Z PUSH SW I.M S5021 QSW1121-001Z PUSH SW I.M S5022 QSW1121-001Z PUSH SW I.M S5023 QSW1121-001Z PUSH SW I.M S5024 QSW1121-001Z PUSH SW I.M S5025 QSW1121-001Z PUSH SW I.M S5026 QSW1121-001Z PUSH SW I.M S5027 QSW1121-001Z PUSH SW I.M S5028 QSW1121-001Z PUSH SW I.M S5029 QSW1121-001Z PUSH SW I.M S5030 QSW1121-001Z PUSH SW I.M S5031 QSW1121-001Z PUSH SW I.M S5032 QSW1121-001Z PUSH SW I.M S5033 QSW1121-001Z PUSH SW I.M S5034 QSW1121-001Z PUSH SW I.M SP500 GV40205-004A IC HOLDER

Main board (DX-T9)



Symbol No.

IC760 SN74AHCT08NS-X IC IC770 MN101C49GFS1 MASK ROM IC771 BR24L02F-W-X IC IC800 RC4558D-X IC IC801 RC4558D-X IC IC810 CD4066BM-X IC IC820 LC75342M-X IC IC830 RC4558D-X IC IC850 M65851FP IC IC860 JCV8011-X IC IC870 LC75341M-X IC IC880 LC75341M-X IC IC881 RC4558D-X IC IC901 RC4580ID-X IC

Q7000 KTC3199/GL/-T TRANSISTOR Q7010 KTC3199/GL/-T TRANSISTOR Q7080 KRC107S-X DIGI TRANSISTOR Q7081 KRC111S-X TRANSISTOR Q7788 KRA102S-X DIGI TRANSISTOR Q7794 KRA102S-X DIGI TRANSISTOR Q7798 KRA102S-X DIGI TRANSISTOR Q8000 2SD2114K/VW/-X TRANSISTOR Q8030 KTC3875/YG/-X SI TRANSISTOR Q8031 KTC3875/YG/-X SI TRANSISTOR Q8032 KTC3875/YG/-X SI TRANSISTOR Q8040 2SD2114K/VW/-X TRANSISTOR Q8070 2SD2114K/VW/-X TRANSISTOR Q8071 2SD2114K/VW/-X TRANSISTOR Q8080 2SD2114K/VW/-X TRANSISTOR Q8081 2SD2114K/VW/-X TRANSISTOR Q8100 2SD2114K/VW/-X TRANSISTOR Q8130 KTC3875/YG/-X SI TRANSISTOR Q8131 KTC3875/YG/-X SI TRANSISTOR Q8132 KTC3875/YG/-X SI TRANSISTOR Q8140 2SD2114K/VW/-X TRANSISTOR Q8170 2SD2114K/VW/-X TRANSISTOR Q8171 2SD2114K/VW/-X TRANSISTOR Q8180 2SD2114K/VW/-X TRANSISTOR Q8211 KRC104S-X TRANSISTOR Q8212 KRC104S-X TRANSISTOR Q8260 KTC3199/GL/-T TRANSISTOR Q8524 KTC1027/OY/-T TRANSISTOR Q8900 KRA104S-X DIGI TRANSISTOR Q9001 2SD2114K/VW/-X TRANSISTOR Q9002 2SD2114K/VW/-X TRANSISTOR Q9003 KRC111S-X TRANSISTOR Q9004 KTA1504/YG/-X SI TRANSISTOR Q9100 KRA111S-X D. TRANSISTOR Q9101 2SD2114K/VW/-X TRANSISTOR Q9102 2SD2114K/VW/-X TRANSISTOR

Part No. Part Name Description Local

Block No. [0][2]

3-26



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

Q9103 2SD2114K/VW/-X TRANSISTOR Q9104 2SD2114K/VW/-X TRANSISTOR

D7000 1SS133-T2 SI DIODE D7001 1SS133-T2 SI DIODE D7011 1SS133-T2 SI DIODE D7012 1SS133-T2 SI DIODE D7050 MTZJ5.1B-T2 Z DIODE D7080 1SS133-T2 SI DIODE D7081 MTZJ4.7B-T2 Z DIODE D7082 1SS133-T2 SI DIODE D7151 1SS133-T2 SI DIODE D7152 1SS133-T2 SI DIODE D7153 1SS133-T2 SI DIODE D7154 1SS133-T2 SI DIODE D7155 1SS133-T2 SI DIODE D7156 1SS133-T2 SI DIODE D7157 1SS133-T2 SI DIODE D7330 1N4003S-T5 SI DIODE D7350 1N4003S-T5 SI DIODE D7390 1SS133-T2 SI DIODE D7711 1SS133-T2 SI DIODE D7713 1N4003S-T5 SI DIODE D8230 1SS133-T2 SI DIODE D8524 MTZJ5.6B-T2 Z DIODE D8900 1SS133-T2 SI DIODE D8901 1SS133-T2 SI DIODE D9001 1SS133-T2 SI DIODE D9002 1SS133-T2 SI DIODE D9100 MTZJ2.4B-T2 Z DIODE

C7050 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C7080 NCB31HK-102X C CAPACITOR 1000pF 50V K C7082 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C7083 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7084 QETN0JM-227Z E CAPACITOR 220uF 6.3V M C7085 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M C7710 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C7711 QETN1CM-107Z E CAPACITOR 100uF 16V M C7712 NCS31HJ-180X C CAPACITOR 18pF 50V J C7713 NCS31HJ-180X C CAPACITOR 18pF 50V J C7788 QETN1HM-106Z E CAPACITOR 10uF 50V M C7794 QETN1EM-476Z E CAPACITOR 47uF 25V M C7798 QETN1AM-227Z E CAPACITOR 220uF 10V M C8000 QTE1V06-106Z E CAPACITOR 10uF 35V C8001 QTE1V06-106Z E CAPACITOR 10uF 35V C8002 QTE1V06-106Z E CAPACITOR 10uF 35V C8003 NCS31HJ-151X C CAPACITOR 150pF 50V J C8020 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8021 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8022 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8023 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8025 QTE1H28-106Z E CAPACITOR 10uF 50V C8026 QFLC1HJ-562Z M CAPACITOR 5600pF 50V J C8027 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8028 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8030 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J C8031 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8032 QTE1C06-226Z E CAPACITOR 22uF 16V C8060 QTE1V06-106Z E CAPACITOR 10uF 35V C8061 QTE1V06-106Z E CAPACITOR 10uF 35V C8062 QTE1V06-106Z E CAPACITOR 10uF 35V C8070 QETN1HM-106Z E CAPACITOR 10uF 50V M C8072 QETN1HM-106Z E CAPACITOR 10uF 50V M C8074 QETN1HM-105Z E CAPACITOR 1uF 50V M C8076 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8080 QETN1HM-106Z E CAPACITOR 10uF 50V M C8082 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8083 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8084 QETN1HM-105Z E CAPACITOR 1uF 50V M C8086 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8092 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J C8100 QTE1V06-106Z E CAPACITOR 10uF 35V C8101 QTE1V06-106Z E CAPACITOR 10uF 35V C8102 QTE1V06-106Z E CAPACITOR 10uF 35V C8103 NCS31HJ-151X C CAPACITOR 150pF 50V J C8120 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8121 QETN1HM-475Z E CAPACITOR 4.7uF 50V M

C8122 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8123 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8125 QTE1H28-106Z E CAPACITOR 10uF 50V C8126 QFLC1HJ-562Z M CAPACITOR 5600pF 50V J C8127 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8128 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8130 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J C8131 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8132 QTE1C06-226Z E CAPACITOR 22uF 16V C8160 QTE1V06-106Z E CAPACITOR 10uF 35V C8161 QTE1V06-106Z E CAPACITOR 10uF 35V C8162 QTE1V06-106Z E CAPACITOR 10uF 35V C8170 QETN1HM-106Z E CAPACITOR 10uF 50V M C8172 QETN1HM-106Z E CAPACITOR 10uF 50V M C8173 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8174 QETN1HM-105Z E CAPACITOR 1uF 50V M C8176 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8180 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J C8181 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8183 QETN1HM-224Z E CAPACITOR 0.22uF 50V M C8184 QETN1HM-106Z E CAPACITOR 10uF 50V M C8185 QTE1V06-106Z E CAPACITOR 10uF 35V C8192 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J C8202 QETN1HM-106Z E CAPACITOR 10uF 50V M C8203 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8204 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8221 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C8222 QTE1C06-107Z E CAPACITOR 100uF 16V C8230 QETN1EM-476Z E CAPACITOR 47uF 25V M C8232 QETN1HM-105Z E CAPACITOR 1uF 50V M C8233 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8261 QETN1EM-476Z E CAPACITOR 47uF 25V M C8262 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8263 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8264 QETN1HM-106Z E CAPACITOR 10uF 50V M C8265 QETN1HM-106Z E CAPACITOR 10uF 50V M C8266 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8267 QETN1EM-336Z E CAPACITOR 33uF 25V M C8268 QETN1HM-224Z E CAPACITOR 0.22uF 50V M C8269 QETN1HM-105Z E CAPACITOR 1uF 50V M C8272 QETN1CM-107Z E CAPACITOR 100uF 16V M C8282 QETN1CM-107Z E CAPACITOR 100uF 16V M C8360 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8361 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8362 QETN1HM-474Z E CAPACITOR 0.47uF 50V M C8363 QETN1EM-476Z E CAPACITOR 47uF 25V M C8501 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J C8503 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8504 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J C8506 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8508 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8509 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J C8512 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8513 QETN1HM-105Z E CAPACITOR 1uF 50V M C8514 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8515 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8516 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8517 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8518 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8520 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8522 QETN1EM-476Z E CAPACITOR 47uF 25V M C8523 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8524 QETN1CM-107Z E CAPACITOR 100uF 16V M C8525 QETN1CM-107Z E CAPACITOR 100uF 16V M C8530 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8539 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8540 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8541 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8542 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8544 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8545 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8546 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8548 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8550 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8551 QETN1HM-105Z E CAPACITOR 1uF 50V M C8553 QETN1HM-106Z E CAPACITOR 10uF 50V M C8554 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8555 QETN1CM-107Z E CAPACITOR 100uF 16V M

3-27



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C8572 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8574 QTE1V06-106Z E CAPACITOR 10uF 35V C8575 QTE1V06-106Z E CAPACITOR 10uF 35V C8576 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8577 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8578 QETN1HM-105Z E CAPACITOR 1uF 50V M C8579 QETN1HM-105Z E CAPACITOR 1uF 50V M C8580 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8900 QETN1HM-105Z E CAPACITOR 1uF 50V M C8902 QETN1HM-106Z E CAPACITOR 10uF 50V M C8903 QETN1HM-106Z E CAPACITOR 10uF 50V M C9000 NCB21HK-473X C CAPACITOR 0.047uF 50V K C9001 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C9002 NCS31HJ-681X C CAPACITOR 680pF 50V J C9003 QEKC1HM-105Z E CAPACITOR 1uF 50V M C9004 QEKC1HM-104Z E CAPACITOR 0.1uF 50V M C9005 QEKC1HM-335Z E CAPACITOR 3.3uF 50V M C9006 QETN1EM-336Z E CAPACITOR 33uF 25V M C9007 QEKC1HM-104Z E CAPACITOR 0.1uF 50V M C9008 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C9009 QETN1EM-476Z E CAPACITOR 47uF 25V M C9010 QEKC1CM-107Z E CAPACITOR 100uF 16V M C9021 NCB31HK-102X C CAPACITOR 1000pF 50V K C9022 NCB31HK-102X C CAPACITOR 1000pF 50V K C9100 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9101 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9102 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9103 QDXB1CM-392Y C CAPACITOR 3900pF 16V M C9104 QDXB1CM-392Y C CAPACITOR 3900pF 16V M C9105 QDGB1HK-102Y C CAPACITOR 1000pF 50V K

R7000 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7001 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7002 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7003 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7004 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7005 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7006 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7010 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7011 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7012 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7013 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7014 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7015 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7016 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7050 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R7080 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R7081 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7082 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7083 NRSA63J-222X MG RESISTOR 2.2k R7084 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R7085 NRSA63J-681X MG RESISTOR 680 R7151 QRE141J-123Y C RESISTOR 12k R7152 QRE141J-123Y C RESISTOR 12kΩ 1/4W J R7153 QRE141J-123Y C RESISTOR 12k R7154 QRE141J-123Y C RESISTOR 12k R7155 QRE141J-123Y C RESISTOR 12kΩ 1/4W J R7156 QRE141J-123Y C RESISTOR 12k R7157 QRE141J-123Y C RESISTOR 12kΩ 1/4W J R7200 NRSA63J-273X MG RESISTOR 27k R7251 QRE141J-222Y C RESISTOR 2.2k R7252 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7253 QRE141J-222Y C RESISTOR 2.2k R7254 QRE141J-272Y C RESISTOR 2.7k R7255 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R7256 QRE141J-272Y C RESISTOR 2.7k R7257 QRE141J-222Y C RESISTOR 2.2k R7702 NRSA63J-222X MG RESISTOR 2.2k R7703 NRSA63J-102X MG RESISTOR 1k R7704 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7705 NRSA63J-102X MG RESISTOR 1k R7706 NRSA63J-102X MG RESISTOR 1k R7707 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7708 NRSA63J-222X MG RESISTOR 2.2k R7709 NRSA63J-103X MG RESISTOR 10k R7715 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7717 NRSA63J-103X MG RESISTOR 10k R7718 QRE141J-102Y C RESISTOR 1k

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/16W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

R7719 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R7720 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R7721 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7722 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7723 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7724 NRSA63J-122X MG RESISTOR 1.2k R7725 NRSA63J-122X MG RESISTOR 1.2k R7726 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7728 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7731 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7732 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7735 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7737 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7738 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7739 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7740 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7742 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7743 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7744 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7745 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7746 NRSA63J-102X MG RESISTOR 1k R7747 NRSA63J-0R0X MG RESISTOR 0 R7748 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7749 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7751 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7752 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7756 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7759 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7760 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7761 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7762 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7763 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7764 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7765 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7766 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7767 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7768 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7769 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7770 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7771 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R7772 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7773 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7774 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R7775 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7776 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7777 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7778 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7779 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7780 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7781 NRSA63J-222X MG RESISTOR 2.2k R7786 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7788 NRSA63J-222X MG RESISTOR 2.2k R7789 NRSA63J-222X MG RESISTOR 2.2k R7790 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7791 NRSA63J-102X MG RESISTOR 1k R7792 NRSA63J-102X MG RESISTOR 1k R7794 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7796 NRSA63J-222X MG RESISTOR 2.2k R7797 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7798 NRSA63J-102X MG RESISTOR 1k R7803 NRSA63J-103X MG RESISTOR 10k R7804 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7805 NRSA63J-103X MG RESISTOR 10k R7806 NRSA63J-103X MG RESISTOR 10k R7807 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7808 NRSA63J-103X MG RESISTOR 10k R7809 NRSA63J-273X MG RESISTOR 27k R7809 NRSA63J-153X MG RESISTOR 15k R7821 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7823 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7824 NRSA63J-222X MG RESISTOR 2.2k R7825 NRSA63J-222X MG RESISTOR 2.2k R7852 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7867 NRSA63J-103X MG RESISTOR 10k R7871 NRSA63J-104X MG RESISTOR 100k R7875 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7876 NRSA63J-103X MG RESISTOR 10k R7878 NRSA63J-104X MG RESISTOR 100k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J UW

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

UG,UX

3-28



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R7879 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7881 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R7886 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7892 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7897 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7899 NRSA63J-103X MG RESISTOR 10k R8000 NRSA63J-473X MG RESISTOR 47k R8001 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8002 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8003 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8004 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R8005 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8007 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8020 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R8021 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8030 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R8031 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R8032 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R8033 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J R8034 NRSA63J-473X MG RESISTOR 47k R8035 NRSA63J-101X MG RESISTOR 100 R8036 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8042 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R8043 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8046 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J R8060 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R8061 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8062 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8070 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8071 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8072 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8073 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8074 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8075 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8080 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8081 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8082 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8083 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8084 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8085 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8090 QRE141J-153Y C RESISTOR 15kΩ 1/4W J R8091 QRE141J-154Y C RESISTOR 150kΩ 1/4W J R8092 NRSA63J-133X MG RESISTOR 13kΩ 1/16W J R8093 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8094 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J R8095 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8100 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8101 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8102 NRSA63J-223X MG RESISTOR 22k R8103 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8104 NRSA63J-222X MG RESISTOR 2.2k R8105 NRSA63J-103X MG RESISTOR 10k R8106 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8107 NRSA63J-223X MG RESISTOR 22k R8120 NRSA63J-392X MG RESISTOR 3.9k R8121 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8130 NRSA63J-472X MG RESISTOR 4.7k R8131 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R8132 NRSA63J-123X MG RESISTOR 12k R8133 NRSA63J-154X MG RESISTOR 150k R8134 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8135 NRSA63J-101X MG RESISTOR 100 R8136 NRSA63J-101X MG RESISTOR 100 R8142 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R8143 NRSA63J-103X MG RESISTOR 10k R8146 NRSA63J-474X MG RESISTOR 470k R8160 QRE141J-472Y C RESISTOR 4.7k R8161 NRSA63J-103X MG RESISTOR 10k R8162 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8170 NRSA63J-102X MG RESISTOR 1k R8171 NRSA63J-103X MG RESISTOR 10k R8172 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8173 NRSA63J-103X MG RESISTOR 10k R8174 NRSA63J-102X MG RESISTOR 1k R8175 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8180 NRSA63J-223X MG RESISTOR 22k R8182 NRSA63J-163X MG RESISTOR 16k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R8183 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8184 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8186 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8187 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8189 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8190 QRE141J-153Y C RESISTOR 15k R8191 QRE141J-154Y C RESISTOR 150k R8192 NRSA63J-133X MG RESISTOR 13kΩ 1/16W J R8193 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8194 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J R8195 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8202 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8203 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8204 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8205 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8206 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8211 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8212 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8223 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8224 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8225 NRSA63J-0R0X MG RESISTOR 0 R8230 NRSA63J-752X MG RESISTOR 7.5k R8231 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8232 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R8235 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R8260 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J R8261 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J R8262 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8263 NRSA63J-475X MG RESISTOR 4.7MΩ 1/16W J R8264 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R8265 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R8266 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R8267 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8268 NRSA63J-622X MG RESISTOR 6.2kΩ 1/16W J R8269 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R8293 QRE141J-393Y C RESISTOR 39kΩ 1/4W J R8335 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R8507 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8508 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8509 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8510 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8511 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8512 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8513 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8514 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8521 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8523 QRZ9006-4R7X F.RESISTOR 4.7Ω 1/4W J R8524 QRE141J-561Y C RESISTOR 560Ω 1/4W J R8529 NRSA63J-113X MG RESISTOR 11kΩ 1/16W J R8539 QRE141J-822Y C RESISTOR 8.2k R8551 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8574 NRSA63J-223X MG RESISTOR 22k R8575 NRSA63J-223X MG RESISTOR 22k R8578 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R8579 NRSA63J-103X MG RESISTOR 10k R8888 NRSA63J-0R0X MG RESISTOR 0 R8900 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R9000 NRSA63J-103X MG RESISTOR 10k R9001 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R9002 NRSA63J-102X MG RESISTOR 1k R9003 NRSA63J-124X MG RESISTOR 120k R9004 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R9005 NRSA63J-102X MG RESISTOR 1k R9006 NRSA63J-103X MG RESISTOR 10k R9007 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R9008 NRSA63J-102X MG RESISTOR 1k R9009 NRSA63J-473X MG RESISTOR 47k R9010 NRSA63J-473X MG RESISTOR 47k R9011 NRSA63J-473X MG RESISTOR 47k R9012 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9013 NRSA63J-103X MG RESISTOR 10k R9014 NRSA63J-103X MG RESISTOR 10k R9015 QRE141J-221Y C RESISTOR 220Ω 1/4W J R9017 NRSA63J-104X MG RESISTOR 100k R9021 NRSA63J-472X MG RESISTOR 4.7k R9022 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9101 NRSA63J-472X MG RESISTOR 4.7k R9102 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/4W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-29



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R9103 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9104 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J VR901 QVQ0306-B24 V RESISTOR

L9100 QQL231K-2R2Y COIL 2.2uH K L9101 QQL231K-470Y COIL 47uH K L9102 QQL231K-470Y COIL 47uH K

CN720 QGF1036C1-19 CONNECTOR FFC/FPC (1-19) CN730 QGF1205C1-25 CONNECTOR FFC/FPC (1-25) CN740 QGF1205F1-05 CONNECTOR FFC/FPC (1-5) CN750 QGF1205F1-11 CONNECTOR FFC/FPC (1-11) CN760 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN788 QGF1205C1-05 CONNECTOR FFC/FPC (1-5) CN800 QGF1036C1-10 CONNECTOR FFC/FPC (1-10) CN810 QGF1036C1-08 CONNECTOR FFC/FPC (1-8) CN820 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN830 QGF1205C1-19 CONNECTOR FFC/FPC (1-19) CN850 QGB2510J1-15 CONNECTOR B-B (1-15) CN860 QGB2510K2-06 CONNECTOR B-B (1-6) CN901 QGF1205F1-05 CONNECTOR FFC/FPC (1-5) FW910 QUM153-21DGZ4-E FLAT WIRE J700 QNB0261-003 SPK TERMINAL J800 QNN0732-001 AUX JACK J901 QNS0252-001 MIC JACK J902 QNS0252-001 MIC JACK J910 QNS0170-001 HEADPHONE JACK K8000 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K8001 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K9100 QQR0621-001Z FERRATE BEADS RY712 QSK0109-001 RELAY RY734 QSK0109-001 RELAY RY750 QSK0109-001 RELAY RY767 QSK0109-001 RELAY X7700 QAX0711-002Z CRYSTAL 8.000000MHz

Primary board (DX-T9)

Block No. [0][3]



Symbol No.

IC920 BH7868FS-X IC IC930 GP1FAV30TK0F OPTICAL JACK

Q1000 KTC2026/Y/ TRANSISTOR Q1001 KTC3203/OY/-T TRANSISTOR Q2007 KTA1046/Y/ TRANSISTOR Q2008 KTC3199/GL/-T TRANSISTOR Q2009 KTC3199/GL/-T TRANSISTOR Q9300 KRA110M-T TRANSISTOR Q9301 KRC110M-T TRANSISTOR Q9303 KTC3199/GL/-T TRANSISTOR



D1000 1N5402M-20 DIODE



D1001 1N5402M-20 DIODE



D1002 1N5402M-20 DIODE



D1003 1N5402M-20 DIODE



D1004 6A10E2 SI DIODE



D1005 6A10E2 SI DIODE



D1006 6A10E2 SI DIODE



D1007 6A10E2 SI DIODE



D1008 6A10E2 SI DIODE



D1009 6A10E2 SI DIODE



D1010 6A10E2 SI DIODE



D1011 6A10E2 SI DIODE D1012 MTZJ6.2B-T2 Z DIODE D1013 MTZJ18B-T2 Z DIODE D1014 MTZJ18B-T2 Z DIODE D1015 1N4003S-T5 SI DIODE D1016 1N4003S-T5 SI DIODE D1017 1N4003S-T5 SI DIODE



D2001 6A10E2 SI DIODE



D2002 6A10E2 SI DIODE



D2003 6A10E2 SI DIODE

Part No. Part Name Description Local



D2004 6A10E2 SI DIODE D2008 2A02-M DIODE D2009 MTZJ5.1C-T2 Z DIODE D2013 1SS133-T2 SI DIODE D9300 2A02-M DIODE D9301 MTZJ3.3B-T2 Z DIODE D9302 MTZJ2.0A-T2 Z DIODE D9303 MTZJ3.9B-T2 Z DIODE D9310 MTZJ3.0B-T2 Z DIODE D9311 1N4003S-T5 SI DIODE D9312 1N4003S-T5 SI DIODE D9313 1N4003S-T5 SI DIODE

C1002 QETN1HM-226Z E CAPACITOR 22uF 50V M C1003 QETN1HM-226Z E CAPACITOR 22uF 50V M C1004 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M C1005 QETN1HM-106Z E CAPACITOR 10uF 50V M C1010 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1011 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1013 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C1014 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C1015 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K C1016 QETN2AM-476Z E CAPACITOR 47uF 100V M C1017 QETN1HM-107Z E CAPACITOR 100uF 50V M C2000 QEZ0706-568 E CAPACITOR 5600uF C2004 QEZ0706-568 E CAPACITOR 5600uF C2005 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J C2006 QETM1HM-478 E CAPACITOR 4700uF 50V M C2007 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J C2008 QETM1HM-478 E CAPACITOR 4700uF 50V M C2009 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C2010 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C2011 QCBB1HK-221Y C CAPACITOR 220pF 50V K C2012 QETM1CM-478 E CAPACITOR 4700uF 16V M C2013 QETM1EM-688 E CAPACITOR 6800uF 25V M C9200 QETN1AM-477Z E CAPACITOR 470uF 10V M C9201 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C9204 QETN1HM-105Z E CAPACITOR 1uF 50V M C9206 QETN1HM-105Z E CAPACITOR 1uF 50V M C9209 QETN1CM-226Z E CAPACITOR 22uF 16V M C9211 QETN1HM-105Z E CAPACITOR 1uF 50V M C9213 QETN1HM-105Z E CAPACITOR 1uF 50V M C9215 QETN1HM-105Z E CAPACITOR 1uF 50V M C9216 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C9218 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9221 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9224 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9227 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9230 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9232 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9300 QETN0JM-107Z E CAPACITOR 100uF 6.3V M C9303 QETN1CM-107Z E CAPACITOR 100uF 16V M



R1000 QRK126J-470X UNF C RESISTOR 47Ω 1/2W J R1001 QRE141J-753Y C RESISTOR 75k R1002 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R1003 QRE141J-104Y C RESISTOR 100k R1005 QRE141J-753Y C RESISTOR 75kΩ 1/4W J R2000 QRE141J-104Y C RESISTOR 100k R2001 QRE141J-104Y C RESISTOR 100k R2002 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R2003 QRE141J-104Y C RESISTOR 100k R2004 QRE141J-681Y C RESISTOR 680 R2005 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R2006 QRE141J-681Y C RESISTOR 680 R2007 QRE141J-472Y C RESISTOR 4.7k R2008 QRE141J-102Y C RESISTOR 1k R2009 QRE141J-102Y C RESISTOR 1k R2010 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R2011 QRL01DJ-471X OMF RESISTOR 470 R2012 QRL01DJ-471X OMF RESISTOR 470 R2014 QRE141J-273Y C RESISTOR 27kΩ 1/4W J R9201 QRE141J-391Y C RESISTOR 390 R9202 QRE141J-391Y C RESISTOR 390 R9203 QRE141J-361Y C RESISTOR 360Ω 1/4W J R9204 QRE141J-131Y C RESISTOR 130 R9205 QRE141J-361Y C RESISTOR 360

Ω

1/4W J

Ω Ω

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1W J

Ω

1W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

1/4W J 1/4W J

1/4W J

3-30



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R9206 QRE141J-131Y C RESISTOR 130Ω 1/4W J R9207 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9208 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9209 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9210 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9218 QRE141J-750Y C RESISTOR 75 R9221 QRE141J-750Y C RESISTOR 75 R9224 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9227 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9230 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9232 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9300 QRT017J-2R2 MF RESISTOR 2.2Ω 1W J R9301 QRE141J-681Y C RESISTOR 680Ω 1/4W J R9302 QRZ9006-4R7X F.RESISTOR 4.7Ω 1/4W J R9303 QRE141J-271Y C RESISTOR 270Ω 1/4W J R9310 QRE141J-470Y C RESISTOR 47Ω 1/4W J

CN100 QGA7901C1-02 CONNECTOR W-B (1-2) CN101 QGA7901C1-04 CONNECTOR W-B (1-4) CN102 QGA7901C1-03 CONNECTOR W-B (1-3) CN103 QGA3901F1-08 CONNECTOR W-B (1-8) CN104 QGB2510J1-13 CONNECTOR B-B (1-13) CN105 QGD2503F1-03 CONNECTOR (1-3) CN106 QGA3901F1-03 CONNECTOR W-B (1-3) CN200 QGB2510J1-16 CONNECTOR B-B (1-16) CN201 QGB2510J1-20 CONNECTOR B-B (1-20) CN202 QGD2504C1-03Z CONNECTOR (1-3) CN203 QGB2510K2-15 CONNECTOR B-B (1-15) CN204 QGB2510K2-13 CONNECTOR B-B (1-13) CN920 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN930 QGF1036C1-28 CONNECTOR FFC/FPC (1-28) CN931 QGF1205C1-11 CONNECTOR FFC/FPC (1-11) EP201 E409182-001SM GRAND TERMINAL H2001 GV40577-001A HEAT SINK IH920 GV40397-003A IC HOLDER J920 QNN0624-001 PIN JACK J921 QNN0557-002 PIN JACK PP201 QZW0038-001 WIRE CLAMP PP202 QZW0038-001 WIRE CLAMP



S1000 QSW0812-001 VOLTAGE SWITCH Z1001 QNG0003-001Z FUSE CLIP Z1002 QNG0003-001Z FUSE CLIP Z1003 QNG0003-001Z FUSE CLIP Z1004 QNG0003-001Z FUSE CLIP Z1005 QNG0003-001Z FUSE CLIP Z1006 QNG0003-001Z FUSE CLIP Z1007 QNG0003-001Z FUSE CLIP Z1008 QNG0003-001Z FUSE CLIP Z1009 QNG0003-001Z FUSE CLIP Z1010 QNG0003-001Z FUSE CLIP Z1011 QNG0003-001Z FUSE CLIP Z1012 QNG0003-001Z FUSE CLIP Z1013 QNG0003-001Z FUSE CLIP Z1014 QNG0003-001Z FUSE CLIP Z1015 QNG0003-001Z FUSE CLIP Z1016 QNG0003-001Z FUSE CLIP Z1017 QNG0003-001Z FUSE CLIP Z1018 QNG0003-001Z FUSE CLIP Z1019 QNG0003-001Z FUSE CLIP Z1020 QNG0003-001Z FUSE CLIP

Ω

1/4W J

Ω

1/4W J

Amplifier board (DX-T7)

Block No. [0][4]



Symbol No.

IC500 PT6305 FL DRIVER IC510 GP1UM281XKVF IR DETECT UNIT



IC601 STK402-240 IC



IC602 KIA7809API IC



IC603 KIA7805API IC



IC604 KIA7809API IC



IC605 KIA278R05PI TRANSISTOR



IC606 KIA278R09PI TRANSISTOR

Part No. Part Name Description Local



IC607 KIA317PI IC



IC608 KIA7805API IC



IC650 STK413-430 IC

Q5004 KRC102M-T DIGI TRANSISTOR Q5005 KRC102M-T DIGI TRANSISTOR Q5006 KRC102M-T DIGI TRANSISTOR Q5007 KRC102M-T DIGI TRANSISTOR Q5008 KTA1023/OY/-T TRANSISTOR Q5009 KRC102M-T DIGI TRANSISTOR Q5010 KRC110M-T TRANSISTOR Q5011 KTC3199/GL/-T TRANSISTOR Q6001 KRC102M-T DIGI TRANSISTOR Q6002 KTA1267/YG/-T TRANSISTOR Q6211 KTC3199/GL/-T TRANSISTOR Q6221 KTC3199/GL/-T TRANSISTOR Q6231 KTC3199/GL/-T TRANSISTOR Q6351 KTC3203/OY/-T TRANSISTOR Q6352 KRC102M-T DIGI TRANSISTOR Q6511 KTC3199/GL/-T TRANSISTOR Q6521 KTC3199/GL/-T TRANSISTOR Q6531 KTC3199/GL/-T TRANSISTOR Q6601 KTC3200/GL/-T TRANSISTOR Q6602 KTA1023/OY/-T TRANSISTOR Q6603 KTA1268/GL/-T TRANSISTOR Q6604 KTC1027/OY/-T TRANSISTOR Q6701 KTC1027/OY/-T TRANSISTOR Q6702 KTA1023/OY/-T TRANSISTOR Q6703 KTC3199/GL/-T TRANSISTOR Q6704 KTA1023/OY/-T TRANSISTOR

D5004 SLI-343URC-W-T LED D5005 SLI-343URC-W-T LED D5006 SELU2E10C-P LED D5007 SLR-343VC-T LED D6001 MTZJ9.1B-T2 Z DIODE D6002 MTZJ9.1B-T2 Z DIODE D6211 1SS119-041-T2 DIODE D6221 1SS119-041-T2 DIODE D6231 1SS119-041-T2 DIODE D6311 MTZJ11B-T2 Z DIODE D6321 MTZJ5.6C-T2 Z DIODE D6331 MTZJ11B-T2 Z DIODE D6341 1SS119-041-T2 DIODE D6342 MTZJ6.2B-T2 Z DIODE D6351 MTZJ11B-T2 Z DIODE D6352 1SS119-041-T2 DIODE D6361 MTZJ11B-T2 Z DIODE D6511 1SS119-041-T2 DIODE D6521 1SS119-041-T2 DIODE D6531 1SS119-041-T2 DIODE D6601 1SS119-041-T2 DIODE D6701 1SS119-041-T2 DIODE D6801 MTZJ15B-T2 Z DIODE D6802 MTZJ15B-T2 Z DIODE D6803 MTZJ36B-T2 Z DIODE D6804 MTZJ36B-T2 Z DIODE

C5000 QETN1HM-226Z E CAPACITOR 22uF 50V M C5001 QETN1HM-226Z E CAPACITOR 22uF 50V M C5002 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C5003 QEKC1EM-106Z E CAPACITOR 10uF 25V M C5004 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C5005 QCBB1HK-101Y C CAPACITOR 100pF 50V K C5006 QEKC1AM-107Z E CAPACITOR 100uF 10V M C5007 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C6001 QETN1HM-107Z E CAPACITOR 100uF 50V M C6002 QETN1HM-106Z E CAPACITOR 10uF 50V M C6003 QETN1HM-106Z E CAPACITOR 10uF 50V M C6004 QETN1HM-107Z E CAPACITOR 100uF 50V M C6005 QETN1HM-105Z E CAPACITOR 1uF 50V M C6111 QCBB1HK-221Y C CAPACITOR 220pF 50V K C6112 QETN1HM-106Z E CAPACITOR 10uF 50V M C6113 QCBB1HK-471Y C CAPACITOR 470pF 50V K C6121 QCBB1HK-221Y C CAPACITOR 220pF 50V K C6122 QETN1HM-106Z E CAPACITOR 10uF 50V M C6123 QCBB1HK-471Y C CAPACITOR 470pF 50V K C6131 QCBB1HK-221Y C CAPACITOR 220pF 50V K

3-31



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C6132 QETN1HM-106Z E CAPACITOR 10uF 50V M C6133 QCBB1HK-471Y C CAPACITOR 470pF 50V K C6211 QETN1JM-476Z E CAPACITOR 47uF 63V M C6212 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C6213 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6214 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6221 QETN1JM-476Z E CAPACITOR 47uF 63V M C6222 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C6223 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6224 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6231 QETN1JM-476Z E CAPACITOR 47uF 63V M C6232 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C6233 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6234 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6311 QETN1EM-476Z E CAPACITOR 47uF 25V M C6312 QETN1CM-107Z E CAPACITOR 100uF 16V M C6321 QETN1EM-476Z E CAPACITOR 47uF 25V M C6322 QETN1CM-107Z E CAPACITOR 100uF 16V M C6331 QETN1EM-476Z E CAPACITOR 47uF 25V M C6332 QETN1CM-107Z E CAPACITOR 100uF 16V M C6341 QETN1EM-476Z E CAPACITOR 47uF 25V M C6342 QETN1CM-107Z E CAPACITOR 100uF 16V M C6361 QETN1EM-476Z E CAPACITOR 47uF 25V M C6362 QETN1CM-107Z E CAPACITOR 100uF 16V M C6401 QETN1EM-476Z E CAPACITOR 47uF 25V M C6402 QETN1CM-107Z E CAPACITOR 100uF 16V M C6511 QETN1JM-476Z E CAPACITOR 47uF 63V M C6512 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C6513 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6514 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6521 QETN1JM-476Z E CAPACITOR 47uF 63V M C6522 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C6523 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6524 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6531 QETN1JM-476Z E CAPACITOR 47uF 63V M C6532 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C6533 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6534 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C6601 QETN1AM-107Z E CAPACITOR 100uF 10V M C6602 QFZ0212-104Z M CAPACITOR 0.1uF C6603 QFZ0212-104Z M CAPACITOR 0.1uF C6604 QETN1HM-105Z E CAPACITOR 1uF 50V M C6701 QETN1HM-106Z E CAPACITOR 10uF 50V M C6702 QETN1CM-476Z E CAPACITOR 47uF 16V M C6703 QETN1HM-106Z E CAPACITOR 10uF 50V M C6911 QCBB1HK-221Y C CAPACITOR 220pF 50V K C6912 QTE1V06-106Z E CAPACITOR 10uF 35V C6913 QCBB1HK-101Y C CAPACITOR 100pF 50V K C6921 QCBB1HK-221Y C CAPACITOR 220pF 50V K C6922 QTE1V06-106Z E CAPACITOR 10uF 35V C6923 QCBB1HK-101Y C CAPACITOR 100pF 50V K C6931 QCBB1HK-221Y C CAPACITOR 220pF 50V K C6932 QTE1V06-106Z E CAPACITOR 10uF 35V C6933 QCBB1HK-471Y C CAPACITOR 470pF 50V K

Ω

R5000 QRE141J-102Y C RESISTOR 1k R5001 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5002 QRE141J-122Y C RESISTOR 1.2k R5003 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5004 QRE141J-222Y C RESISTOR 2.2k R5005 QRE141J-272Y C RESISTOR 2.7k R5006 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5007 QRE141J-562Y C RESISTOR 5.6k R5008 QRE141J-103Y C RESISTOR 10k R5009 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5010 QRE141J-102Y C RESISTOR 1k R5011 QRE141J-122Y C RESISTOR 1.2k R5012 QRE141J-152Y C RESISTOR 1.5k R5013 QRE141J-222Y C RESISTOR 2.2k R5014 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5015 QRE141J-392Y C RESISTOR 3.9k R5016 QRE141J-102Y C RESISTOR 1k R5017 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5018 QRE141J-122Y C RESISTOR 1.2k R5019 QRE141J-152Y C RESISTOR 1.5k R5020 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R5021 QRE141J-272Y C RESISTOR 2.7k R5022 QRE141J-392Y C RESISTOR 3.9k

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

R5023 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R5024 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5025 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5026 QRE141J-122Y C RESISTOR 1.2kΩ 1/4W J R5027 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5028 QRE141J-222Y C RESISTOR 2.2k R5029 QRE141J-272Y C RESISTOR 2.7k R5030 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5035 QRE141J-161Y C RESISTOR 160Ω 1/4W J R5036 QRE141J-161Y C RESISTOR 160Ω 1/4W J R5037 QRE141J-560Y C RESISTOR 56Ω 1/4W J R5038 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5039 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5040 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5041 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5042 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R5043 QRE141J-271Y C RESISTOR 270Ω 1/4W J R5044 QRE141J-821Y C RESISTOR 820Ω 1/4W J R5045 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R5046 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6001 QRJ146J-101X UNF C RESISTOR 100 R6002 QRJ146J-101X UNF C RESISTOR 100 R6003 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R6004 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R6005 QRE141J-333Y C RESISTOR 33kΩ 1/4W J R6006 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6111 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R6112 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R6121 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R6122 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R6131 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R6132 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R6211 QRT01DJ-R22X MF RESISTOR 0.22Ω 1W J R6212 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R6213 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6214 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6215 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R6216 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R6217 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R6218 QRJ146J-821X UNF C RESISTOR 820Ω 1/4W J R6219 QRE141J-104Y C RESISTOR 100kΩ 1/4W J



R6221 QRT01DJ-R22X MF RESISTOR 0.22Ω 1W J R6222 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R6223 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J



R6224 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6225 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R6226 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R6227 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R6228 QRJ146J-821X UNF C RESISTOR 820Ω 1/4W J R6229 QRE141J-104Y C RESISTOR 100k



R6231 QRT01DJ-R22X MF RESISTOR 0.22Ω 1W J R6232 QRE141J-563Y C RESISTOR 56k



R6233 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6234 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6235 QRE141J-102Y C RESISTOR 1k R6236 QRE141J-562Y C RESISTOR 5.6k R6237 QRE141J-473Y C RESISTOR 47kΩ 1/4W J



R6238 QRJ146J-821X UNF C RESISTOR 820Ω 1/4W J R6239 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6321 QRE141J-103Y C RESISTOR 10k R6342 QRE141J-102Y C RESISTOR 1k



R6351 QRJ146J-4R7X UNF C RESISTOR 4.7Ω 1/4W J R6352 QRE141J-242Y C RESISTOR 2.4k R6353 QRE141J-100Y C RESISTOR 10 R6354 QRE141J-271Y C RESISTOR 270Ω 1/4W J R6355 QRE141J-242Y C RESISTOR 2.4k R6356 QRE141J-103Y C RESISTOR 10k R6357 QRE141J-102Y C RESISTOR 1k R6358 QRE141J-103Y C RESISTOR 10k R6501 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R6502 QRE141J-202Y C RESISTOR 2k R6503 QRE141J-202Y C RESISTOR 2k R6510 QRE141J-102Y C RESISTOR 1kΩ 1/4W J



R6511 QRZ0224-R22 EMIT RESISTOR 0.22 R6512 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R6513 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6514 QRJ146J-100X UNF C RESISTOR 10 R6515 QRE141J-202Y C RESISTOR 2k

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

3-32



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R6516 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R6517 QRE141J-473Y C RESISTOR 47kΩ 1/4W J



R6518 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R6519 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6520 QRE141J-102Y C RESISTOR 1kΩ 1/4W J



R6521 QRZ0224-R22 EMIT RESISTOR 0.22 R6522 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R6523 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J



R6524 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6525 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R6526 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R6527 QRE141J-473Y C RESISTOR 47kΩ 1/4W J



R6528 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R6529 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6530 QRE141J-102Y C RESISTOR 1kΩ 1/4W J



R6531 QRZ0224-R22 EMIT RESISTOR 0.22 R6532 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R6533 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6534 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6535 QRE141J-202Y C RESISTOR 2kΩ 1/4W J R6536 QRE141J-562Y C RESISTOR 5.6k R6537 QRE141J-473Y C RESISTOR 47k



R6538 QRJ146J-681X UNF C RESISTOR 680Ω 1/4W J R6539 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6601 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R6602 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6603 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R6604 QRE141J-103Y C RESISTOR 10kΩ 1/4W J



R6605 QRJ146J-470X UNF C RESISTOR 47Ω 1/4W J R6606 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R6607 QRE141J-103Y C RESISTOR 10kΩ 1/4W J



R6608 QRJ146J-470X UNF C RESISTOR 47Ω 1/4W J R6701 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R6702 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6703 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R6704 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6705 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R6706 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R6801 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R6802 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R6803 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R6804 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J



R6805 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R6806 QRE141J-333Y C RESISTOR 33kΩ 1/4W J R6911 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R6912 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R6921 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R6922 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R6931 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R6932 QRE141J-563Y C RESISTOR 56k

L6211 QQLZ035-R39 COIL 0.39uH L6221 QQLZ035-R39 COIL 0.39uH L6231 QQLZ035-R39 COIL 0.39uH L6511 QQLZ035-R39 COIL 0.39uH L6521 QQLZ035-R39 COIL 0.39uH L6531 QQLZ035-R39 COIL 0.39uH

CN500 QGF1036F1-19 CONNECTOR FFC/FPC (1-19) CN601 QGB2510K2-20 CONNECTOR B-B (1-20) CN602 QGF1205C1-19 CONNECTOR FFC/FPC (1-19) CN603 QGF1205F1-11 CONNECTOR FFC/FPC (1-11) CN604 QGA2501F1-03 CONNECTOR W-B (1-3) CN651 QGB2510K2-16 CONNECTOR B-B (1-16) CN652 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN970 QGB2510J1-04 CONNECTOR B-B (1-4) FL500 QLF0150-001 FL TUBE FW500 QUM153-18DGZ4-E FLAT WIRE J970 QNB0262-001 SPK TERMINAL S5000 QSW1121-001Z PUSH SW I.M S5001 QSW1121-001Z PUSH SW I.M S5002 QSW1121-001Z PUSH SW I.M S5003 QSW1121-001Z PUSH SW I.M S5004 QSW1121-001Z PUSH SW I.M S5005 QSW1121-001Z PUSH SW I.M S5006 QSW1121-001Z PUSH SW I.M S5007 QSW1121-001Z PUSH SW I.M S5008 QSW1121-001Z PUSH SW I.M

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

S5009 QSW1121-001Z PUSH SW I.M S5010 QSW1121-001Z PUSH SW I.M S5011 QSW1121-001Z PUSH SW I.M S5012 QSW1121-001Z PUSH SW I.M S5013 QSW1121-001Z PUSH SW I.M S5014 QSW1121-001Z PUSH SW I.M S5015 QSW1121-001Z PUSH SW I.M S5016 QSW1121-001Z PUSH SW I.M S5017 QSW1121-001Z PUSH SW I.M S5018 QSW1121-001Z PUSH SW I.M S5019 QSW1121-001Z PUSH SW I.M S5020 QSW1121-001Z PUSH SW I.M S5021 QSW1121-001Z PUSH SW I.M S5022 QSW1121-001Z PUSH SW I.M S5023 QSW1121-001Z PUSH SW I.M S5024 QSW1121-001Z PUSH SW I.M S5025 QSW1121-001Z PUSH SW I.M S5026 QSW1121-001Z PUSH SW I.M S5027 QSW1121-001Z PUSH SW I.M S5028 QSW1121-001Z PUSH SW I.M S5029 QSW1121-001Z PUSH SW I.M S5030 QSW1121-001Z PUSH SW I.M S5031 QSW1121-001Z PUSH SW I.M S5032 QSW1121-001Z PUSH SW I.M S5033 QSW1121-001Z PUSH SW I.M S5034 QSW1121-001Z PUSH SW I.M SP500 GV40205-004A IC HOLDER

Main board (DX-T7)



Symbol No.

IC760 SN74AHCT08NS-X IC IC770 MN101C49GFS1 MASK ROM IC771 BR24L02F-W-X IC IC800 RC4558D-X IC IC801 RC4558D-X IC IC810 CD4066BM-X IC IC820 LC75342M-X IC IC830 RC4558D-X IC IC850 M65851FP IC IC860 JCV8011-X IC IC870 LC75341M-X IC IC880 LC75341M-X IC IC881 RC4558D-X IC IC901 RC4580ID-X IC

Q7000 KTC3199/GL/-T TRANSISTOR Q7010 KTC3199/GL/-T TRANSISTOR Q7080 KRC107S-X DIGI TRANSISTOR Q7081 KRC111S-X TRANSISTOR Q7788 KRA102S-X DIGI TRANSISTOR Q7794 KRA102S-X DIGI TRANSISTOR Q7798 KRA102S-X DIGI TRANSISTOR Q8000 2SD2114K/VW/-X TRANSISTOR Q8030 KTC3875/YG/-X SI TRANSISTOR Q8031 KTC3875/YG/-X SI TRANSISTOR Q8032 KTC3875/YG/-X SI TRANSISTOR Q8040 2SD2114K/VW/-X TRANSISTOR Q8070 2SD2114K/VW/-X TRANSISTOR Q8071 2SD2114K/VW/-X TRANSISTOR Q8080 2SD2114K/VW/-X TRANSISTOR Q8081 2SD2114K/VW/-X TRANSISTOR Q8100 2SD2114K/VW/-X TRANSISTOR Q8130 KTC3875/YG/-X SI TRANSISTOR Q8131 KTC3875/YG/-X SI TRANSISTOR Q8132 KTC3875/YG/-X SI TRANSISTOR Q8140 2SD2114K/VW/-X TRANSISTOR Q8170 2SD2114K/VW/-X TRANSISTOR Q8171 2SD2114K/VW/-X TRANSISTOR Q8180 2SD2114K/VW/-X TRANSISTOR Q8211 KRC104S-X TRANSISTOR Q8212 KRC104S-X TRANSISTOR

Part No. Part Name Description Local

Block No. [0][5]

3-33



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

Q8260 KTC3199/GL/-T TRANSISTOR Q8524 KTC1027/OY/-T TRANSISTOR Q8900 KRA104S-X DIGI TRANSISTOR Q9001 2SD2114K/VW/-X TRANSISTOR Q9002 2SD2114K/VW/-X TRANSISTOR Q9003 KRC111S-X TRANSISTOR Q9004 KTA1504/YG/-X SI TRANSISTOR Q9100 KRA111S-X D. TRANSISTOR Q9101 2SD2114K/VW/-X TRANSISTOR Q9102 2SD2114K/VW/-X TRANSISTOR Q9103 2SD2114K/VW/-X TRANSISTOR Q9104 2SD2114K/VW/-X TRANSISTOR

D7000 1SS133-T2 SI DIODE D7001 1SS133-T2 SI DIODE D7010 1SS133-T2 SI DIODE D7012 1SS133-T2 SI DIODE D7050 MTZJ5.1B-T2 Z DIODE D7080 1SS133-T2 SI DIODE D7081 MTZJ4.7B-T2 Z DIODE D7082 1SS133-T2 SI DIODE D7151 1SS133-T2 SI DIODE D7152 1SS133-T2 SI DIODE D7153 1SS133-T2 SI DIODE D7154 1SS133-T2 SI DIODE D7155 1SS133-T2 SI DIODE D7156 1SS133-T2 SI DIODE D7390 1SS133-T2 SI DIODE D7711 1SS133-T2 SI DIODE D7713 1N4003S-T5 SI DIODE D8230 1SS133-T2 SI DIODE D8524 MTZJ5.6B-T2 Z DIODE D8900 1SS133-T2 SI DIODE D8901 1SS133-T2 SI DIODE D9001 1SS133-T2 SI DIODE D9002 1SS133-T2 SI DIODE D9100 MTZJ2.4B-T2 Z DIODE

C7050 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C7080 NCB31HK-102X C CAPACITOR 1000pF 50V K C7082 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C7083 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7084 QETN0JM-227Z E CAPACITOR 220uF 6.3V M C7085 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M C7101 QCBB1HK-101Y C CAPACITOR 100pF 50V K C7710 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C7711 QETN1CM-107Z E CAPACITOR 100uF 16V M C7712 NCS31HJ-180X C CAPACITOR 18pF 50V J C7713 NCS31HJ-180X C CAPACITOR 18pF 50V J C7788 QETN1HM-106Z E CAPACITOR 10uF 50V M C7794 QETN1EM-476Z E CAPACITOR 47uF 25V M C7798 QETN1AM-227Z E CAPACITOR 220uF 10V M C8000 QTE1V06-106Z E CAPACITOR 10uF 35V C8001 QTE1V06-106Z E CAPACITOR 10uF 35V C8002 QTE1V06-106Z E CAPACITOR 10uF 35V C8003 NCS31HJ-151X C CAPACITOR 150pF 50V J C8020 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8021 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8022 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8023 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8025 QTE1H28-106Z E CAPACITOR 10uF 50V C8026 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J C8027 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8028 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8030 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8031 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8032 QTE1C06-226Z E CAPACITOR 22uF 16V C8060 QTE1V06-106Z E CAPACITOR 10uF 35V C8061 QTE1V06-106Z E CAPACITOR 10uF 35V C8062 QTE1V06-106Z E CAPACITOR 10uF 35V C8070 QETN1HM-106Z E CAPACITOR 10uF 50V M C8072 QETN1HM-106Z E CAPACITOR 10uF 50V M C8074 QETN1HM-105Z E CAPACITOR 1uF 50V M C8076 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8080 QETN1HM-106Z E CAPACITOR 10uF 50V M C8082 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8083 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8084 QETN1HM-105Z E CAPACITOR 1uF 50V M

C8086 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8092 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J C8100 QTE1V06-106Z E CAPACITOR 10uF 35V C8101 QTE1V06-106Z E CAPACITOR 10uF 35V C8102 QTE1V06-106Z E CAPACITOR 10uF 35V C8103 NCS31HJ-151X C CAPACITOR 150pF 50V J C8120 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8121 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8122 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8123 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8125 QTE1H28-106Z E CAPACITOR 10uF 50V C8126 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J C8127 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8128 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8130 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8131 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8132 QTE1C06-226Z E CAPACITOR 22uF 16V C8160 QTE1V06-106Z E CAPACITOR 10uF 35V C8161 QTE1V06-106Z E CAPACITOR 10uF 35V C8162 QTE1V06-106Z E CAPACITOR 10uF 35V C8170 QETN1HM-106Z E CAPACITOR 10uF 50V M C8172 QETN1HM-106Z E CAPACITOR 10uF 50V M C8173 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8174 QETN1HM-105Z E CAPACITOR 1uF 50V M C8176 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8180 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J C8181 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8183 QETN1HM-224Z E CAPACITOR 0.22uF 50V M C8184 QETN1HM-106Z E CAPACITOR 10uF 50V M C8185 QTE1V06-106Z E CAPACITOR 10uF 35V C8192 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J C8202 QETN1HM-106Z E CAPACITOR 10uF 50V M C8203 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8204 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8221 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C8222 QTE1C06-107Z E CAPACITOR 100uF 16V C8230 QETN1EM-476Z E CAPACITOR 47uF 25V M C8232 QETN1HM-105Z E CAPACITOR 1uF 50V M C8233 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8261 QETN1EM-476Z E CAPACITOR 47uF 25V M C8262 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8263 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8264 QETN1HM-106Z E CAPACITOR 10uF 50V M C8265 QETN1HM-106Z E CAPACITOR 10uF 50V M C8266 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8267 QETN1EM-336Z E CAPACITOR 33uF 25V M C8268 QETN1HM-224Z E CAPACITOR 0.22uF 50V M C8269 QTE1H28-106Z E CAPACITOR 10uF 50V C8272 QETN1CM-107Z E CAPACITOR 100uF 16V M C8282 QETN1CM-107Z E CAPACITOR 100uF 16V M C8360 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8361 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8362 QETN1HM-474Z E CAPACITOR 0.47uF 50V M C8363 QETN1EM-476Z E CAPACITOR 47uF 25V M C8501 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J C8503 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8504 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J C8506 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8508 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8509 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J C8512 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8513 QETN1HM-105Z E CAPACITOR 1uF 50V M C8514 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8515 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8516 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8517 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8518 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8520 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8522 QETN1EM-476Z E CAPACITOR 47uF 25V M C8523 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8524 QETN1CM-107Z E CAPACITOR 100uF 16V M C8525 QETN1CM-107Z E CAPACITOR 100uF 16V M C8530 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8539 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8540 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8541 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8542 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8544 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J

3-34



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C8545 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8546 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8548 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8550 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8551 QETN1HM-105Z E CAPACITOR 1uF 50V M C8553 QETN1HM-106Z E CAPACITOR 10uF 50V M C8554 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8555 QETN1CM-107Z E CAPACITOR 100uF 16V M C8572 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8574 QTE1V06-106Z E CAPACITOR 10uF 35V C8575 QTE1V06-106Z E CAPACITOR 10uF 35V C8576 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8577 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8578 QETN1HM-105Z E CAPACITOR 1uF 50V M C8579 QETN1HM-105Z E CAPACITOR 1uF 50V M C8580 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8900 QETN1HM-105Z E CAPACITOR 1uF 50V M C8902 QETN1HM-106Z E CAPACITOR 10uF 50V M C8903 QETN1HM-106Z E CAPACITOR 10uF 50V M C9000 NCB21HK-473X C CAPACITOR 0.047uF 50V K C9001 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C9002 NCS31HJ-681X C CAPACITOR 680pF 50V J C9003 QEKC1HM-105Z E CAPACITOR 1uF 50V M C9004 QEKC1HM-104Z E CAPACITOR 0.1uF 50V M C9005 QEKC1HM-335Z E CAPACITOR 3.3uF 50V M C9006 QETN1EM-336Z E CAPACITOR 33uF 25V M C9007 QEKC1HM-104Z E CAPACITOR 0.1uF 50V M C9008 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C9009 QETN1EM-476Z E CAPACITOR 47uF 25V M C9010 QEKC1CM-107Z E CAPACITOR 100uF 16V M C9021 NCB31HK-102X C CAPACITOR 1000pF 50V K C9022 NCB31HK-102X C CAPACITOR 1000pF 50V K C9100 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9101 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9102 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9103 QDXB1CM-392Y C CAPACITOR 3900pF 16V M C9104 QDXB1CM-392Y C CAPACITOR 3900pF 16V M C9105 QDGB1HK-102Y C CAPACITOR 1000pF 50V K

R7000 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7001 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7002 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7003 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7004 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7005 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7006 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7010 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7011 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7012 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7013 QRL01DJ-151X OMF RESISTOR 150 R7014 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7015 QRL01DJ-151X OMF RESISTOR 150 R7016 QRL01DJ-151X OMF RESISTOR 150 R7050 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R7080 NRSA63J-223X MG RESISTOR 22k R7081 NRSA63J-103X MG RESISTOR 10k R7082 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7083 NRSA63J-222X MG RESISTOR 2.2k R7084 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R7085 NRSA63J-681X MG RESISTOR 680 R7151 QRE141J-123Y C RESISTOR 12k R7152 QRE141J-123Y C RESISTOR 12kΩ 1/4W J R7153 QRE141J-123Y C RESISTOR 12k R7154 QRE141J-123Y C RESISTOR 12k R7155 QRE141J-123Y C RESISTOR 12kΩ 1/4W J R7156 QRE141J-123Y C RESISTOR 12k R7200 NRSA63J-273X MG RESISTOR 27k R7251 QRE141J-222Y C RESISTOR 2.2k R7252 QRE141J-222Y C RESISTOR 2.2k R7253 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7254 QRE141J-272Y C RESISTOR 2.7k R7255 QRE141J-272Y C RESISTOR 2.7k R7256 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R7702 NRSA63J-222X MG RESISTOR 2.2k R7703 NRSA63J-102X MG RESISTOR 1k R7704 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7705 NRSA63J-102X MG RESISTOR 1k R7706 NRSA63J-102X MG RESISTOR 1k

Ω

1W J

Ω

1W J

Ω

1W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/16W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R7707 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7708 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7709 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7715 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7717 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7718 QRE141J-102Y C RESISTOR 1k R7719 QRE141J-102Y C RESISTOR 1k R7720 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R7721 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7722 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7723 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7724 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7725 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7726 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7728 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7731 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7732 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7735 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7737 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7738 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7739 NRSA63J-102X MG RESISTOR 1k R7740 NRSA63J-102X MG RESISTOR 1k R7742 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7743 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7744 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7745 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7746 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7747 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7748 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7749 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7751 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7752 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7756 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7759 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7760 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7761 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7762 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7763 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7764 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7765 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7766 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7767 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7768 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7769 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7770 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7771 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R7772 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7773 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7774 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R7775 NRSA63J-222X MG RESISTOR 2.2k R7776 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7777 NRSA63J-102X MG RESISTOR 1k R7778 NRSA63J-222X MG RESISTOR 2.2k R7779 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7780 NRSA63J-222X MG RESISTOR 2.2k R7781 NRSA63J-222X MG RESISTOR 2.2k R7786 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7788 NRSA63J-222X MG RESISTOR 2.2k R7789 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7790 NRSA63J-102X MG RESISTOR 1k R7791 NRSA63J-102X MG RESISTOR 1k R7792 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7794 NRSA63J-222X MG RESISTOR 2.2k R7796 NRSA63J-222X MG RESISTOR 2.2k R7797 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7798 NRSA63J-102X MG RESISTOR 1k R7803 NRSA63J-103X MG RESISTOR 10k R7804 NRSA63J-103X MG RESISTOR 10k R7805 NRSA63J-103X MG RESISTOR 10k R7806 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7807 NRSA63J-103X MG RESISTOR 10k R7808 NRSA63J-103X MG RESISTOR 10k R7809 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J UW R7809 NRSA63J-153X MG RESISTOR 15k R7821 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7823 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7824 NRSA63J-222X MG RESISTOR 2.2k R7825 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/4W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

UG,UX

3-35



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R7852 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7867 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7871 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7875 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7876 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7878 NRSA63J-104X MG RESISTOR 100k R7879 NRSA63J-103X MG RESISTOR 10k R7881 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R7886 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7892 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7897 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7899 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8000 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8001 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8002 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8003 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8004 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R8005 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8007 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8020 NRSA63J-392X MG RESISTOR 3.9k R8021 NRSA63J-104X MG RESISTOR 100k R8030 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R8031 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R8032 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R8033 NRSA63J-114X MG RESISTOR 110kΩ 1/16W J R8034 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8035 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8036 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8042 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R8043 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8046 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J R8060 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R8061 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8062 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8070 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8071 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8072 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8073 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8074 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8075 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8080 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8081 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8082 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8083 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8084 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8085 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8090 QRE141J-153Y C RESISTOR 15kΩ 1/4W J R8091 QRE141J-154Y C RESISTOR 150kΩ 1/4W J R8092 NRSA63J-133X MG RESISTOR 13k R8093 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8094 NRSA63J-303X MG RESISTOR 30k R8095 NRSA63J-0R0X MG RESISTOR 0 R8100 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8101 NRSA63J-473X MG RESISTOR 47k R8102 NRSA63J-223X MG RESISTOR 22k R8103 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8104 NRSA63J-222X MG RESISTOR 2.2k R8105 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8106 NRSA63J-103X MG RESISTOR 10k R8107 NRSA63J-223X MG RESISTOR 22k R8120 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R8121 NRSA63J-104X MG RESISTOR 100k R8130 NRSA63J-472X MG RESISTOR 4.7k R8131 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R8132 NRSA63J-123X MG RESISTOR 12k R8133 NRSA63J-114X MG RESISTOR 110k R8134 NRSA63J-473X MG RESISTOR 47k R8135 NRSA63J-101X MG RESISTOR 100 R8136 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8142 NRSA63J-392X MG RESISTOR 3.9k R8143 NRSA63J-103X MG RESISTOR 10k R8146 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J R8160 QRE141J-472Y C RESISTOR 4.7k R8161 NRSA63J-103X MG RESISTOR 10k R8162 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8170 NRSA63J-102X MG RESISTOR 1k R8171 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R8172 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8173 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8174 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8175 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8180 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8182 NRSA63J-163X MG RESISTOR 16k R8183 NRSA63J-223X MG RESISTOR 22k R8184 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8186 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8187 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R8189 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8190 QRE141J-153Y C RESISTOR 15kΩ 1/4W J R8191 QRE141J-154Y C RESISTOR 150kΩ 1/4W J R8192 NRSA63J-133X MG RESISTOR 13kΩ 1/16W J R8193 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8194 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J R8195 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8202 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8203 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8204 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8205 NRSA63J-243X MG RESISTOR 24k R8206 NRSA63J-103X MG RESISTOR 10k R8211 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8212 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8223 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8224 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8225 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8230 NRSA63J-752X MG RESISTOR 7.5kΩ 1/16W J R8231 NRSA63J-302X MG RESISTOR 3kΩ 1/16W J R8232 QRE141J-753Y C RESISTOR 75kΩ 1/4W J R8235 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R8260 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J R8261 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J R8262 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8263 NRSA63J-475X MG RESISTOR 4.7MΩ 1/16W J R8264 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R8265 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R8266 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R8267 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8268 NRSA63J-622X MG RESISTOR 6.2kΩ 1/16W J R8269 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R8293 QRE141J-393Y C RESISTOR 39kΩ 1/4W J R8335 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R8507 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8508 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8509 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8510 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8511 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8512 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8513 NRSA63J-243X MG RESISTOR 24k R8514 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8521 NRSA63J-243X MG RESISTOR 24k R8523 QRZ9006-4R7X F.RESISTOR 4.7 R8524 QRE141J-561Y C RESISTOR 560Ω 1/4W J R8529 NRSA63J-113X MG RESISTOR 11k R8539 QRE141J-822Y C RESISTOR 8.2k R8551 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8574 NRSA63J-223X MG RESISTOR 22k R8575 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8578 NRSA63J-681X MG RESISTOR 680 R8579 NRSA63J-103X MG RESISTOR 10k R8888 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8900 QRE141J-102Y C RESISTOR 1k R9000 NRSA63J-103X MG RESISTOR 10k R9001 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R9002 NRSA63J-102X MG RESISTOR 1k R9003 NRSA63J-124X MG RESISTOR 120k R9004 NRSA63J-222X MG RESISTOR 2.2k R9005 NRSA63J-102X MG RESISTOR 1k R9006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9007 NRSA63J-104X MG RESISTOR 100k R9008 NRSA63J-102X MG RESISTOR 1k R9009 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9010 NRSA63J-473X MG RESISTOR 47k R9011 NRSA63J-473X MG RESISTOR 47k R9012 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9013 NRSA63J-103X MG RESISTOR 10k R9014 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-36



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R9015 QRE141J-221Y C RESISTOR 220Ω 1/4W J R9017 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R9021 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9022 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9101 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9102 NRSA63J-472X MG RESISTOR 4.7k R9103 NRSA63J-472X MG RESISTOR 4.7k R9104 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J VR901 QVQ0306-B24 V RESISTOR

L9100 QQL231K-2R2Y COIL 2.2uH K L9101 QQL231K-470Y COIL 47uH K L9102 QQL231K-470Y COIL 47uH K

CN720 QGF1036C1-19 CONNECTOR FFC/FPC (1-19) CN730 QGF1205C1-25 CONNECTOR FFC/FPC (1-25) CN740 QGF1205F1-05 CONNECTOR FFC/FPC (1-5) CN750 QGF1205F1-11 CONNECTOR FFC/FPC (1-11) CN760 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN788 QGF1205C1-05 CONNECTOR FFC/FPC (1-5) CN799 QGF1210G1-06 CONNECTOR FFC/FPC (1-6) CN800 QGF1036C1-10 CONNECTOR FFC/FPC (1-10) CN810 QGF1036C1-08 CONNECTOR FFC/FPC (1-8) CN820 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN830 QGF1205C1-19 CONNECTOR FFC/FPC (1-19) CN850 QGB2510J1-13 CONNECTOR B-B (1-13) CN860 QGB2510K2-04 CONNECTOR B-B (1-4) CN901 QGF1205F1-05 CONNECTOR FFC/FPC (1-5) FW910 QUM153-21DGZ4-E FLAT WIRE J700 QNB0261-002 SPK TERMINAL J800 QNN0732-001 AUX JACK J901 QNS0252-001 MIC JACK J902 QNS0252-001 MIC JACK J910 QNS0170-001 HEADPHONE JACK K8000 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K8001 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K9100 QQR0621-001Z FERRATE BEADS RY712 QSK0109-001 RELAY RY734 QSK0109-001 RELAY RY756 QSK0109-001 RELAY RY767 QSK0109-001 RELAY X7700 QAX0711-002Z CRYSTAL 8.000000MHz

Ω

1/16W J

Ω

1/16W J

Primary board (DX-T7)

Block No. [0][6]



Symbol No.

IC920 BH7868FS-X IC IC930 GP1FAV30TK0F OPTICAL JACK



Q1000 KTC2026/Y/ TRANSISTOR Q1001 KTC3203/OY/-T TRANSISTOR



Q2007 KTA1046/Y/ TRANSISTOR Q2008 KTC3199/GL/-T TRANSISTOR Q2009 KTC3199/GL/-T TRANSISTOR Q9300 KRA110M-T TRANSISTOR Q9301 KRC110M-T TRANSISTOR Q9303 KTC3199/GL/-T TRANSISTOR



D1000 1N5402M-20 DIODE



D1001 1N5402M-20 DIODE



D1002 1N5402M-20 DIODE



D1003 1N5402M-20 DIODE



D1004 6A10E2 SI DIODE



D1005 6A10E2 SI DIODE



D1006 6A10E2 SI DIODE



D1007 6A10E2 SI DIODE



D1008 6A10E2 SI DIODE



D1009 6A10E2 SI DIODE



D1010 6A10E2 SI DIODE



D1011 6A10E2 SI DIODE D1012 MTZJ6.2B-T2 Z DIODE D1013 MTZJ18B-T2 Z DIODE

Part No. Part Name Description Local

D1014 MTZJ18B-T2 Z DIODE D1015 1N4003S-T5 SI DIODE D1016 1N4003S-T5 SI DIODE D1017 1N4003S-T5 SI DIODE



D2001 6A10E2 SI DIODE



D2002 6A10E2 SI DIODE



D2003 6A10E2 SI DIODE



D2004 6A10E2 SI DIODE D2008 2A02-M DIODE D2009 MTZJ5.1C-T2 Z DIODE D2013 1SS133-T2 SI DIODE D9300 2A02-M DIODE D9301 MTZJ3.3B-T2 Z DIODE D9302 MTZJ2.0A-T2 Z DIODE D9303 MTZJ3.9B-T2 Z DIODE D9310 MTZJ3.0B-T2 Z DIODE D9311 1N4003S-T5 SI DIODE D9312 1N4003S-T5 SI DIODE D9313 1N4003S-T5 SI DIODE

C1002 QETN1HM-226Z E CAPACITOR 22uF 50V M C1003 QETN1HM-226Z E CAPACITOR 22uF 50V M C1004 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M C1005 QETN1HM-106Z E CAPACITOR 10uF 50V M C1010 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1011 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1013 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C1014 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C1015 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K C1016 QETN2AM-476Z E CAPACITOR 47uF 100V M C1017 QETN1HM-107Z E CAPACITOR 100uF 50V M C2000 QEZ0706-478 E CAPACITOR 4700uF C2004 QEZ0706-478 E CAPACITOR 4700uF C2005 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J C2006 QETM1HM-338 E CAPACITOR 3300uF 50V M C2007 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J C2008 QETM1HM-338 E CAPACITOR 3300uF 50V M C2009 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C2010 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C2011 QCBB1HK-221Y C CAPACITOR 220pF 50V K C2012 QETM1CM-478 E CAPACITOR 4700uF 16V M C2013 QETM1EM-688 E CAPACITOR 6800uF 25V M C9200 QETN1AM-477Z E CAPACITOR 470uF 10V M C9201 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C9204 QETN1HM-105Z E CAPACITOR 1uF 50V M C9206 QETN1HM-105Z E CAPACITOR 1uF 50V M C9209 QETN1CM-226Z E CAPACITOR 22uF 16V M C9211 QETN1HM-105Z E CAPACITOR 1uF 50V M C9213 QETN1HM-105Z E CAPACITOR 1uF 50V M C9215 QETN1HM-105Z E CAPACITOR 1uF 50V M C9216 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C9218 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9221 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9224 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9227 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9230 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9232 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9300 QETN0JM-107Z E CAPACITOR 100uF 6.3V M C9303 QETN1CM-107Z E CAPACITOR 100uF 16V M



R1000 QRK126J-470X UNF C RESISTOR 47Ω 1/2W J R1001 QRE141J-753Y C RESISTOR 75k R1002 QRE141J-104Y C RESISTOR 100k R1003 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R1005 QRE141J-753Y C RESISTOR 75k R2000 QRE141J-104Y C RESISTOR 100k R2001 QRE141J-104Y C RESISTOR 100k R2002 QRE141J-104Y C RESISTOR 100k R2003 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R2004 QRE141J-681Y C RESISTOR 680 R2005 QRE141J-272Y C RESISTOR 2.7k R2006 QRE141J-681Y C RESISTOR 680Ω 1/4W J R2007 QRE141J-472Y C RESISTOR 4.7k R2008 QRE141J-102Y C RESISTOR 1k R2009 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R2010 QRE141J-102Y C RESISTOR 1k R2011 QRL01DJ-471X OMF RESISTOR 470

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1W J

3-37



Symbol No.

R2012 QRL01DJ-471X OMF RESISTOR 470Ω 1W J R2014 QRE141J-273Y C RESISTOR 27kΩ 1/4W J R9201 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9202 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9203 QRE141J-361Y C RESISTOR 360Ω 1/4W J R9204 QRE141J-131Y C RESISTOR 130 R9205 QRE141J-361Y C RESISTOR 360 R9206 QRE141J-131Y C RESISTOR 130Ω 1/4W J R9207 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9208 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9209 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9210 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9218 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9221 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9224 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9227 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9230 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9232 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9300 QRT017J-2R2 MF RESISTOR 2.2Ω 1W J R9301 QRE141J-681Y C RESISTOR 680Ω 1/4W J R9302 QRZ9006-4R7X F.RESISTOR 4.7 R9303 QRE141J-271Y C RESISTOR 270 R9310 QRE141J-470Y C RESISTOR 47Ω 1/4W J

CN100 QGA7901C1-02 CONNECTOR W-B (1-2) CN101 QGA7901C1-04 CONNECTOR W-B (1-4) CN102 QGA7901C1-03 CONNECTOR W-B (1-3) CN103 QGA3901F1-08 CONNECTOR W-B (1-8) CN104 QGB2510J1-13 CONNECTOR B-B (1-13) CN105 QGD2503F1-03 CONNECTOR (1-3) CN106 QGA3901F1-03 CONNECTOR W-B (1-3) CN200 QGB2510J1-16 CONNECTOR B-B (1-16) CN201 QGB2510J1-20 CONNECTOR B-B (1-20) CN202 QGD2504C1-03Z CONNECTOR (1-3) CN203 QGB2510K2-13 CONNECTOR B-B (1-13) CN204 QGB2510K2-13 CONNECTOR B-B (1-13) CN920 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN930 QGF1036C1-28 CONNECTOR FFC/FPC (1-28) CN931 QGF1205C1-11 CONNECTOR FFC/FPC (1-11) EP201 E409182-001SM GRAND TERMINAL H2001 GV40577-001A HEAT SINK IH920 GV40397-003A IC HOLDER J920 QNN0624-001 PIN JACK J921 QNN0557-002 PIN JACK PP201 QZW0038-001 WIRE CLAMP PP202 QZW0038-001 WIRE CLAMP



S1000 QSW0812-001 VOLTAGE SWITCH Z1001 QNG0003-001Z FUSE CLIP Z1002 QNG0003-001Z FUSE CLIP Z1003 QNG0003-001Z FUSE CLIP Z1004 QNG0003-001Z FUSE CLIP Z1005 QNG0003-001Z FUSE CLIP Z1006 QNG0003-001Z FUSE CLIP Z1007 QNG0003-001Z FUSE CLIP Z1008 QNG0003-001Z FUSE CLIP Z1009 QNG0003-001Z FUSE CLIP Z1010 QNG0003-001Z FUSE CLIP Z1011 QNG0003-001Z FUSE CLIP Z1012 QNG0003-001Z FUSE CLIP Z1013 QNG0003-001Z FUSE CLIP Z1014 QNG0003-001Z FUSE CLIP Z1015 QNG0003-001Z FUSE CLIP Z1016 QNG0003-001Z FUSE CLIP Z1017 QNG0003-001Z FUSE CLIP Z1018 QNG0003-001Z FUSE CLIP Z1019 QNG0003-001Z FUSE CLIP Z1020 QNG0003-001Z FUSE CLIP

Part No. Part Name Description Local

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Amplifier board (DX-T5)

Block No. [0][7]



Symbol No.



IC302 KIA7809API IC



IC303 KIA7805API IC



IC304 KIA7809API IC



IC305 KIA278R05PI TRANSISTOR



IC306 KIA278R09PI TRANSISTOR



IC307 KIA317PI IC IC308 KIA7805API IC



IC401 STK412-430 POWER I.C IC500 PT6305 FL DRIVER IC510 GP1UM281XKVF IR DETECT UNIT



Q3901 KTC3203/OY/-T TRANSISTOR Q3902 KRC102M-T DIGI TRANSISTOR Q4401 KTC3200/GL/-T TRANSISTOR Q4402 KTA1023/OY/-T TRANSISTOR Q4403 KTA1268/GL/-T TRANSISTOR Q4404 KTC1027/OY/-T TRANSISTOR Q4601 KTC3199/GL/-T TRANSISTOR Q4701 KTC3199/GL/-T TRANSISTOR Q4901 KTC1027/OY/-T TRANSISTOR Q4902 KTA1023/OY/-T TRANSISTOR Q4903 KTC3199/GL/-T TRANSISTOR Q4904 KTA1023/OY/-T TRANSISTOR Q5004 KRC102M-T DIGI TRANSISTOR Q5005 KRC102M-T DIGI TRANSISTOR Q5006 KRC102M-T DIGI TRANSISTOR Q5007 KRC102M-T DIGI TRANSISTOR Q5008 KTA1023/OY/-T TRANSISTOR Q5009 KRC102M-T DIGI TRANSISTOR Q5010 KRC110M-T TRANSISTOR Q5011 KTC3199/GL/-T TRANSISTOR

D3701 MTZJ5.6C-T2 Z DIODE D3811 MTZJ11B-T2 Z DIODE D3821 MTZJ11B-T2 Z DIODE D3831 1SS119-041-T2 DIODE D3832 MTZJ6.2B-T2 Z DIODE D3841 MTZJ11B-T2 Z DIODE D3901 MTZJ11B-T2 Z DIODE D3902 1SS119-041-T2 DIODE D4401 1SS119-041-T2 DIODE D4501 MTZJ15B-T2 Z DIODE D4502 MTZJ15B-T2 Z DIODE D4503 MTZJ36A-T2 Z DIODE D4504 MTZJ36A-T2 Z DIODE D4601 1SS119-041-T2 DIODE D4701 1SS119-041-T2 DIODE D4901 1SS119-041-T2 DIODE D5004 SLI-343URC-W-T LED D5005 SLI-343URC-W-T LED D5006 SLI-343URC3F LED D5007 SLR-343VC-T LED

C3701 QETN1EM-476Z E CAPACITOR 47uF 25V M C3702 QETN1CM-107Z E CAPACITOR 100uF 16V M C3811 QETN1EM-476Z E CAPACITOR 47uF 25V M C3812 QETN1CM-107Z E CAPACITOR 100uF 16V M C3821 QETN1EM-476Z E CAPACITOR 47uF 25V M C3822 QETN1CM-107Z E CAPACITOR 100uF 16V M C3831 QETN1EM-476Z E CAPACITOR 47uF 25V M C3832 QETN1CM-107Z E CAPACITOR 100uF 16V M C3841 QETN1EM-476Z E CAPACITOR 47uF 25V M C3842 QETN1CM-107Z E CAPACITOR 100uF 16V M C3851 QETN1EM-476Z E CAPACITOR 47uF 25V M C3852 QETN1CM-107Z E CAPACITOR 100uF 16V M C4401 QETN1AM-107Z E CAPACITOR 100uF 10V M C4402 QFZ0212-104Z M CAPACITOR 0.1uF C4403 QFZ0212-104Z M CAPACITOR 0.1uF C4404 QETN1HM-105Z E CAPACITOR 1uF 50V M C4602 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C4603 QETN1JM-476Z E CAPACITOR 47uF 63V M C4604 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4605 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4702 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K

Part No. Part Name Description Local

3-38



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C4703 QETN1JM-476Z E CAPACITOR 47uF 63V M C4704 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4705 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C4801 QCBB1HK-221Y C CAPACITOR 220pF 50V K C4802 QTE1V06-106Z E CAPACITOR 10uF 35V C4803 QCBB1HK-101Y C CAPACITOR 100pF 50V K C4811 QCBB1HK-221Y C CAPACITOR 220pF 50V K C4812 QTE1V06-106Z E CAPACITOR 10uF 35V C4813 QCBB1HK-101Y C CAPACITOR 100pF 50V K C4901 QETN1HM-106Z E CAPACITOR 10uF 50V M C4902 QETN1CM-476Z E CAPACITOR 47uF 16V M C4903 QETN1HM-106Z E CAPACITOR 10uF 50V M C5000 QETN1HM-226Z E CAPACITOR 22uF 50V M C5001 QETN1HM-226Z E CAPACITOR 22uF 50V M C5002 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C5003 QEKC1EM-106Z E CAPACITOR 10uF 25V M C5004 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C5005 QCBB1HK-101Y C CAPACITOR 100pF 50V K C5006 QEKC1AM-107Z E CAPACITOR 100uF 10V M C5007 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K

R3701 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R3831 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R3901 QRJ146J-4R7X UNF C RESISTOR 4.7Ω 1/4W J R3902 QRE141J-242Y C RESISTOR 2.4kΩ 1/4W J R3903 QRE141J-100Y C RESISTOR 10Ω 1/4W J R3904 QRE141J-271Y C RESISTOR 270Ω 1/4W J R3905 QRE141J-242Y C RESISTOR 2.4kΩ 1/4W J R3906 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R3907 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R3908 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R4401 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R4402 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R4403 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R4404 QRE141J-103Y C RESISTOR 10kΩ 1/4W J



R4405 QRJ146J-470X UNF C RESISTOR 47Ω 1/4W J R4406 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R4407 QRE141J-103Y C RESISTOR 10kΩ 1/4W J



R4408 QRJ146J-470X UNF C RESISTOR 47Ω 1/4W J R4501 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R4502 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R4503 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R4504 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J



R4505 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4506 QRE141J-333Y C RESISTOR 33kΩ 1/4W J



R4601 QRZ0224-R22 EMIT RESISTOR 0.22 R4602 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R4603 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4604 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4605 QRE141J-102Y C RESISTOR 1k R4606 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R4607 QRE141J-473Y C RESISTOR 47k R4608 QRE141J-562Y C RESISTOR 5.6k



R4609 QRJ146J-821X UNF C RESISTOR 820Ω 1/4W J R4610 QRE141J-104Y C RESISTOR 100k



R4701 QRZ0224-R22 EMIT RESISTOR 0.22 R4702 QRE141J-563Y C RESISTOR 56kΩ 1/4W J



R4703 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J



R4704 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J R4705 QRE141J-102Y C RESISTOR 1k R4706 QRE141J-102Y C RESISTOR 1k R4707 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R4708 QRE141J-562Y C RESISTOR 5.6k



R4709 QRJ146J-821X UNF C RESISTOR 820Ω 1/4W J R4710 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R4801 QRE141J-102Y C RESISTOR 1k R4802 QRE141J-563Y C RESISTOR 56k R4811 QRE141J-102Y C RESISTOR 1k R4812 QRE141J-563Y C RESISTOR 56k R4901 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R4902 QRE141J-104Y C RESISTOR 100k R4903 QRE141J-103Y C RESISTOR 10k R4904 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R4905 QRE141J-103Y C RESISTOR 10k R4906 QRE141J-104Y C RESISTOR 100k R5000 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5001 QRE141J-102Y C RESISTOR 1k R5002 QRE141J-122Y C RESISTOR 1.2k

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

R5003 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5004 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R5005 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5006 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5007 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J R5008 QRE141J-103Y C RESISTOR 10k R5009 QRE141J-102Y C RESISTOR 1k R5010 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5011 QRE141J-122Y C RESISTOR 1.2kΩ 1/4W J R5012 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5013 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R5014 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5015 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5016 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5017 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5018 QRE141J-122Y C RESISTOR 1.2kΩ 1/4W J R5019 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5020 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R5021 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5022 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5023 QRE141J-562Y C RESISTOR 5.6k R5024 QRE141J-102Y C RESISTOR 1k R5025 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5026 QRE141J-122Y C RESISTOR 1.2kΩ 1/4W J R5027 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J R5028 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R5029 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R5030 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J R5035 QRE141J-161Y C RESISTOR 160Ω 1/4W J R5036 QRE141J-161Y C RESISTOR 160Ω 1/4W J R5037 QRE141J-131Y C RESISTOR 130Ω 1/4W J R5038 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5039 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5040 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5041 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R5042 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R5043 QRE141J-271Y C RESISTOR 270Ω 1/4W J R5044 QRE141J-821Y C RESISTOR 820Ω 1/4W J R5045 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R5046 QRE141J-104Y C RESISTOR 100kΩ 1/4W J

L4601 QQLZ035-R39 COIL 0.39uH L4701 QQLZ035-R39 COIL 0.39uH

CN301 QGB2510K2-09 CONNECTOR B-B (1-9) CN302 QGF1205C1-13 CONNECTOR FFC/FPC (1-13) CN303 QGF1205F1-11 CONNECTOR FFC/FPC (1-11) CN304 QGA2501F1-03 CONNECTOR W-B (1-3) CN401 QGB2510K2-12 CONNECTOR B-B (1-12) CN402 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN500 QGF1036F1-19 CONNECTOR FFC/FPC (1-19) FL500 QLF0150-001 FL TUBE FW401 QUM154-10Z4Z4-E FLAT WIRE FW500 QUM153-18DGZ4-E FLAT WIRE S5000 QSW1121-001Z PUSH SW I.M S5001 QSW1121-001Z PUSH SW I.M S5002 QSW1121-001Z PUSH SW I.M S5003 QSW1121-001Z PUSH SW I.M S5004 QSW1121-001Z PUSH SW I.M S5005 QSW1121-001Z PUSH SW I.M S5006 QSW1121-001Z PUSH SW I.M S5007 QSW1121-001Z PUSH SW I.M S5008 QSW1121-001Z PUSH SW I.M S5009 QSW1121-001Z PUSH SW I.M S5010 QSW1121-001Z PUSH SW I.M S5011 QSW1121-001Z PUSH SW I.M S5012 QSW1121-001Z PUSH SW I.M S5013 QSW1121-001Z PUSH SW I.M S5014 QSW1121-001Z PUSH SW I.M S5015 QSW1121-001Z PUSH SW I.M S5016 QSW1121-001Z PUSH SW I.M S5017 QSW1121-001Z PUSH SW I.M S5018 QSW1121-001Z PUSH SW I.M S5019 QSW1121-001Z PUSH SW I.M S5020 QSW1121-001Z PUSH SW I.M S5021 QSW1121-001Z PUSH SW I.M S5022 QSW1121-001Z PUSH SW I.M S5023 QSW1121-001Z PUSH SW I.M

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

3-39



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

S5024 QSW1121-001Z PUSH SW I.M S5025 QSW1121-001Z PUSH SW I.M S5026 QSW1121-001Z PUSH SW I.M S5027 QSW1121-001Z PUSH SW I.M S5028 QSW1121-001Z PUSH SW I.M S5029 QSW1121-001Z PUSH SW I.M S5030 QSW1121-001Z PUSH SW I.M S5031 QSW1121-001Z PUSH SW I.M S5032 QSW1121-001Z PUSH SW I.M S5033 QSW1121-001Z PUSH SW I.M S5034 QSW1121-001Z PUSH SW I.M SP500 GV40205-004A IC HOLDER

Main board (DX-T5)



Symbol No.

IC760 SN74AHCT08NS-X IC IC770 MN101C49GFS1 MASK ROM IC771 BR24L02F-W-X IC IC810 CD4066BM-X IC IC820 LC75342M-X IC IC830 RC4558D-X IC IC850 M65851FP IC IC860 JCV8011-X IC IC881 RC4558D-X IC IC901 RC4580ID-X IC

Q7000 KTC3199/GL/-T TRANSISTOR Q7010 KTC3199/GL/-T TRANSISTOR Q7080 KRC107S-X DIGI TRANSISTOR Q7081 KRC111S-X TRANSISTOR Q7788 KRA102S-X DIGI TRANSISTOR Q7798 KRA102S-X DIGI TRANSISTOR Q8000 2SD2114K/VW/-X TRANSISTOR Q8030 KTC3875/YG/-X SI TRANSISTOR Q8031 KTC3875/YG/-X SI TRANSISTOR Q8032 KTC3875/YG/-X SI TRANSISTOR Q8037 KTC3875/YG/-X SI TRANSISTOR Q8038 KTC3875/YG/-X SI TRANSISTOR Q8040 2SD2114K/VW/-X TRANSISTOR Q8100 2SD2114K/VW/-X TRANSISTOR Q8130 KTC3875/YG/-X SI TRANSISTOR Q8131 KTC3875/YG/-X SI TRANSISTOR Q8132 KTC3875/YG/-X SI TRANSISTOR Q8137 KTC3875/YG/-X SI TRANSISTOR Q8138 KTC3875/YG/-X SI TRANSISTOR Q8140 2SD2114K/VW/-X TRANSISTOR Q8211 KRC104S-X TRANSISTOR Q8212 KRC104S-X TRANSISTOR Q8260 KTC3199/GL/-T TRANSISTOR Q8524 KTC1027/OY/-T TRANSISTOR Q8900 KRA104S-X DIGI TRANSISTOR Q8910 2SD1328/ST/-X TRANSISTOR Q8911 2SD1328/ST/-X TRANSISTOR Q9001 2SD2114K/VW/-X TRANSISTOR Q9002 2SD2114K/VW/-X TRANSISTOR Q9003 KRC111S-X TRANSISTOR Q9004 KTA1504/YG/-X SI TRANSISTOR Q9100 KRA111S-X D. TRANSISTOR Q9101 2SD2114K/VW/-X TRANSISTOR Q9102 2SD2114K/VW/-X TRANSISTOR Q9103 2SD2114K/VW/-X TRANSISTOR Q9104 2SD2114K/VW/-X TRANSISTOR

D7000 1SS133-T2 SI DIODE D7010 1SS133-T2 SI DIODE D7050 MTZJ5.1B-T2 Z DIODE D7080 1SS133-T2 SI DIODE D7081 MTZJ4.7B-T2 Z DIODE D7082 1SS133-T2 SI DIODE D7151 1SS133-T2 SI DIODE D7152 1SS133-T2 SI DIODE

Part No. Part Name Description Local

Block No. [0][8]

D7390 1SS133-T2 SI DIODE D7711 1SS133-T2 SI DIODE D7713 1N4003S-T5 SI DIODE D7784 MTZJ3.9B-T2 Z DIODE D7785 MTZJ3.9B-T2 Z DIODE D8230 1SS133-T2 SI DIODE D8524 MTZJ5.6B-T2 Z DIODE D8900 1SS133-T2 SI DIODE D8901 1SS133-T2 SI DIODE D9001 1SS133-T2 SI DIODE D9002 1SS133-T2 SI DIODE D9100 MTZJ2.4B-T2 Z DIODE

C7001 QETN1HM-476Z E CAPACITOR 47uF 50V M C7002 QETN1HM-476Z E CAPACITOR 47uF 50V M C7050 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C7080 NCB31HK-102X C CAPACITOR 1000pF 50V K C7082 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C7083 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7084 QETN0JM-227Z E CAPACITOR 220uF 6.3V M C7085 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M C7710 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C7711 QETN1CM-107Z E CAPACITOR 100uF 16V M C7712 NCS31HJ-180X C CAPACITOR 18pF 50V J C7713 NCS31HJ-180X C CAPACITOR 18pF 50V J C7788 QETN1HM-106Z E CAPACITOR 10uF 50V M C7798 QETN1HM-106Z E CAPACITOR 10uF 50V M C8001 QTE1V06-106Z E CAPACITOR 10uF 35V C8002 QTE1V06-106Z E CAPACITOR 10uF 35V C8020 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8021 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8022 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8023 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8025 QTE1H28-106Z E CAPACITOR 10uF 50V C8026 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J C8027 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8028 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8030 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J C8031 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J C8032 QTE1C06-226Z E CAPACITOR 22uF 16V C8062 QTE1V06-106Z E CAPACITOR 10uF 35V C8101 QTE1V06-106Z E CAPACITOR 10uF 35V C8102 QTE1V06-106Z E CAPACITOR 10uF 35V C8120 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8121 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8122 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8123 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8125 QTE1H28-106Z E CAPACITOR 10uF 50V C8126 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J C8127 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8128 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8130 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J C8131 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J C8132 QTE1C06-226Z E CAPACITOR 22uF 16V C8162 QTE1V06-106Z E CAPACITOR 10uF 35V C8182 QFLC1HJ-471Z M CAPACITOR 470pF 50V J C8221 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C8222 QTE1C06-107Z E CAPACITOR 100uF 16V C8230 QETN1EM-476Z E CAPACITOR 47uF 25V M C8232 QETN1HM-105Z E CAPACITOR 1uF 50V M C8233 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8261 QETN1EM-476Z E CAPACITOR 47uF 25V M C8262 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J C8263 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8264 QETN1HM-106Z E CAPACITOR 10uF 50V M C8265 QETN1HM-106Z E CAPACITOR 10uF 50V M C8266 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8267 QETN1EM-336Z E CAPACITOR 33uF 25V M C8268 QETN1HM-224Z E CAPACITOR 0.22uF 50V M C8269 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8360 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8361 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C8362 QETN1HM-474Z E CAPACITOR 0.47uF 50V M C8363 QETN1EM-476Z E CAPACITOR 47uF 25V M C8501 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J C8503 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8504 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J C8506 QETN1HM-225Z E CAPACITOR 2.2uF 50V M

3-40



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C8508 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8509 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J C8512 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C8513 QETN1HM-105Z E CAPACITOR 1uF 50V M C8514 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8515 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8516 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8517 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8518 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8520 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8522 QETN1EM-476Z E CAPACITOR 47uF 25V M C8523 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8524 QETN1CM-107Z E CAPACITOR 100uF 16V M C8525 QETN1CM-107Z E CAPACITOR 100uF 16V M C8530 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8540 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8541 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8542 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8544 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8545 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8546 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J C8548 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J C8550 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C8552 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J C8554 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C8555 QETN1CM-107Z E CAPACITOR 100uF 16V M C8563 QTE1V06-106Z E CAPACITOR 10uF 35V C8564 QTE1V06-106Z E CAPACITOR 10uF 35V C8574 QTE1V06-106Z E CAPACITOR 10uF 35V C8575 QTE1V06-106Z E CAPACITOR 10uF 35V C8576 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8577 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C8578 QETN1HM-105Z E CAPACITOR 1uF 50V M C8579 QETN1HM-105Z E CAPACITOR 1uF 50V M C8580 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J C8900 QETN1HM-105Z E CAPACITOR 1uF 50V M C8910 QETN1HM-226Z E CAPACITOR 22uF 50V M C9000 NCB21HK-473X C CAPACITOR 0.047uF 50V K C9001 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C9002 NCS31HJ-681X C CAPACITOR 680pF 50V J C9003 QEKC1HM-105Z E CAPACITOR 1uF 50V M C9004 QEKC1HM-104Z E CAPACITOR 0.1uF 50V M C9005 QEKC1HM-335Z E CAPACITOR 3.3uF 50V M C9006 QETN1EM-336Z E CAPACITOR 33uF 25V M C9007 QEKC1HM-104Z E CAPACITOR 0.1uF 50V M C9008 QETN1HM-104Z E CAPACITOR 0.1uF 50V M C9009 QETN1EM-476Z E CAPACITOR 47uF 25V M C9010 QEKC1CM-107Z E CAPACITOR 100uF 16V M C9021 NCB31HK-102X C CAPACITOR 1000pF 50V K C9022 NCB31HK-102X C CAPACITOR 1000pF 50V K C9100 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9101 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9102 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C9103 QDXB1CM-392Y C CAPACITOR 3900pF 16V M C9104 QDXB1CM-392Y C CAPACITOR 3900pF 16V M C9105 QDGB1HK-102Y C CAPACITOR 1000pF 50V K

R7000 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7001 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7002 QRL01DJ-151X OMF RESISTOR 150 R7003 QRL01DJ-151X OMF RESISTOR 150 R7010 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7011 QRL01DJ-151X OMF RESISTOR 150 R7012 QRL01DJ-151X OMF RESISTOR 150 R7013 QRL01DJ-151X OMF RESISTOR 150Ω 1W J R7050 QRE141J-563Y C RESISTOR 56k R7080 NRSA63J-223X MG RESISTOR 22k R7081 NRSA63J-103X MG RESISTOR 10k R7082 NRSA63J-102X MG RESISTOR 1k R7083 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7084 NRSA63J-681X MG RESISTOR 680 R7085 NRSA63J-681X MG RESISTOR 680 R7151 QRE141J-123Y C RESISTOR 12kΩ 1/4W J R7152 QRE141J-123Y C RESISTOR 12k R7200 NRSA63J-273X MG RESISTOR 27k R7251 QRE141J-242Y C RESISTOR 2.4kΩ 1/4W J R7252 QRE141J-242Y C RESISTOR 2.4k R7702 NRSA63J-222X MG RESISTOR 2.2k

Ω

1W J

Ω

1W J

Ω

1W J

Ω

1W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

R7703 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7704 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7705 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7706 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7707 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7708 NRSA63J-222X MG RESISTOR 2.2k R7709 NRSA63J-103X MG RESISTOR 10k R7715 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7717 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7718 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R7719 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R7720 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R7721 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7722 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7723 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7724 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7725 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R7726 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7728 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7731 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7732 NRSA63J-103X MG RESISTOR 10k R7735 NRSA63J-102X MG RESISTOR 1k R7737 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7738 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7739 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7740 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7742 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7743 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7744 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7745 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7746 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7747 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7748 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7749 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7751 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7752 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7756 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7759 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7760 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7761 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7762 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7763 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7764 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7765 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7766 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7767 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7768 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7769 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7770 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7771 QRE141J-104Y C RESISTOR 100k R7772 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R7773 QRE141J-222Y C RESISTOR 2.2k R7774 QRE141J-102Y C RESISTOR 1k R7775 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7776 NRSA63J-222X MG RESISTOR 2.2k R7777 NRSA63J-102X MG RESISTOR 1k R7778 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7779 NRSA63J-222X MG RESISTOR 2.2k R7780 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7781 NRSA63J-222X MG RESISTOR 2.2k R7786 NRSA63J-222X MG RESISTOR 2.2k R7788 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7789 NRSA63J-222X MG RESISTOR 2.2k R7790 NRSA63J-102X MG RESISTOR 1k R7791 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7792 NRSA63J-102X MG RESISTOR 1k R7796 NRSA63J-222X MG RESISTOR 2.2k R7797 NRSA63J-102X MG RESISTOR 1k R7798 NRSA63J-102X MG RESISTOR 1k R7799 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7803 NRSA63J-103X MG RESISTOR 10k R7804 NRSA63J-103X MG RESISTOR 10k R7805 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7806 NRSA63J-103X MG RESISTOR 10k R7807 NRSA63J-103X MG RESISTOR 10k R7808 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7809 NRSA63J-273X MG RESISTOR 27k R7809 NRSA63J-153X MG RESISTOR 15k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J UW

Ω

1/16W J

UG,UX

3-41



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R7809 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J UY R7821 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7823 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7824 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7825 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7852 NRSA63J-104X MG RESISTOR 100k R7867 NRSA63J-103X MG RESISTOR 10k R7871 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7875 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7876 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7878 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7879 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7881 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R7886 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7892 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7897 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8004 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R8005 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R8006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8020 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R8021 NRSA63J-104X MG RESISTOR 100k R8030 NRSA63J-302X MG RESISTOR 3k R8031 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R8032 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R8033 NRSA63J-204X MG RESISTOR 200kΩ 1/16W J R8035 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8036 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8037 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J R8038 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8039 QRE141J-823Y C RESISTOR 82kΩ 1/4W J R8042 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R8043 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8046 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J R8060 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J R8061 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8062 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8088 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R8090 QRE141J-183Y C RESISTOR 18kΩ 1/4W J R8091 QRE141J-823Y C RESISTOR 82kΩ 1/4W J R8092 NRSA63J-133X MG RESISTOR 13kΩ 1/16W J R8093 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R8094 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8095 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8104 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R8105 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R8106 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8120 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R8121 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8130 NRSA63J-302X MG RESISTOR 3kΩ 1/16W J R8131 NRSA63J-122X MG RESISTOR 1.2k R8132 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R8133 NRSA63J-204X MG RESISTOR 200k R8135 NRSA63J-101X MG RESISTOR 100 R8136 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8137 NRSA63J-393X MG RESISTOR 39k R8138 NRSA63J-243X MG RESISTOR 24k R8139 QRE141J-823Y C RESISTOR 82kΩ 1/4W J R8142 NRSA63J-392X MG RESISTOR 3.9k R8143 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8146 NRSA63J-393X MG RESISTOR 39k R8160 QRE141J-332Y C RESISTOR 3.3k R8161 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8162 NRSA63J-103X MG RESISTOR 10k R8181 NRSA63J-473X MG RESISTOR 47k R8182 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R8188 NRSA63J-224X MG RESISTOR 220k R8190 QRE141J-183Y C RESISTOR 18k R8191 QRE141J-823Y C RESISTOR 82k R8192 NRSA63J-133X MG RESISTOR 13k R8193 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R8194 NRSA63J-243X MG RESISTOR 24k R8195 NRSA63J-0R0X MG RESISTOR 0 R8211 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8212 NRSA63J-103X MG RESISTOR 10k R8223 NRSA63J-0R0X MG RESISTOR 0 R8224 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8225 NRSA63J-0R0X MG RESISTOR 0 R8230 NRSA63J-752X MG RESISTOR 7.5k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R8231 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R8232 QRE141J-274Y C RESISTOR 270kΩ 1/4W J R8235 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R8237 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8238 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8260 NRSA63J-474X MG RESISTOR 470k R8261 NRSA63J-474X MG RESISTOR 470k R8262 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8263 NRSA63J-475X MG RESISTOR 4.7MΩ 1/16W J R8264 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R8265 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R8266 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R8267 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8268 NRSA63J-622X MG RESISTOR 6.2kΩ 1/16W J R8269 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R8335 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R8337 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8338 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R8507 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8508 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8509 NRSA63J-243X MG RESISTOR 24k R8510 NRSA63J-243X MG RESISTOR 24k R8511 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8512 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8513 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8514 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8521 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R8523 QRZ9006-4R7X F.RESISTOR 4.7Ω 1/4W J R8524 QRE141J-561Y C RESISTOR 560Ω 1/4W J R8529 NRSA63J-113X MG RESISTOR 11kΩ 1/16W J R8578 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J R8579 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R8900 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R8910 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R8911 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R8912 NRSA63J-470X MG RESISTOR 47Ω 1/16W J R8913 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R8915 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9000 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9001 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R9002 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R9003 NRSA63J-824X MG RESISTOR 820kΩ 1/16W J R9004 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R9005 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R9006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9007 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R9008 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R9009 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9010 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9011 NRSA63J-473X MG RESISTOR 47k R9012 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9013 NRSA63J-103X MG RESISTOR 10k R9014 NRSA63J-103X MG RESISTOR 10k R9015 QRE141J-221Y C RESISTOR 220Ω 1/4W J R9017 NRSA63J-104X MG RESISTOR 100k R9021 NRSA63J-472X MG RESISTOR 4.7k R9022 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9101 NRSA63J-472X MG RESISTOR 4.7k R9102 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9103 NRSA63J-472X MG RESISTOR 4.7k R9104 NRSA63J-472X MG RESISTOR 4.7k VR901 QVQ0306-B24 V RESISTOR

L9100 QQL231K-2R2Y COIL 2.2uH K L9101 QQL231K-470Y COIL 47uH K L9102 QQL231K-470Y COIL 47uH K

CN720 QGF1036C1-19 CONNECTOR FFC/FPC (1-19) CN730 QGF1205C1-25 CONNECTOR FFC/FPC (1-25) CN740 QGF1205F1-05 CONNECTOR FFC/FPC (1-5) CN750 QGF1205F1-11 CONNECTOR FFC/FPC (1-11) CN760 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN788 QGF1205C1-05 CONNECTOR FFC/FPC (1-5) CN799 QGF1210G1-06 CONNECTOR FFC/FPC (1-6) CN800 QGF1036C1-10 CONNECTOR FFC/FPC (1-10) CN820 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN830 QGF1205C1-13 CONNECTOR FFC/FPC (1-13) CN850 QGB2510J1-06 CONNECTOR B-B (1-6)

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-42



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

CN901 QGF1205F1-05 CONNECTOR FFC/FPC (1-5) FW910 QUM153-21DGZ4-E FLAT WIRE J700 QNB0261-001 SPK TERMINAL J800 QNN0732-001 AUX JACK J880 QNN0284-001 PIN JACK J901 QNS0252-001 MIC JACK J902 QNS0252-001 MIC JACK J910 QNS0170-001 HEADPHONE JACK K8000 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K8001 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K9100 QQR0621-001Z FERRATE BEADS RY712 QSK0109-001 RELAY RY756 QSK0109-001 RELAY X7700 QAX0711-002Z CRYSTAL 8.000000MHz

Primary board (DX-T5)

Block No. [0][9]



Symbol No.

IC920 BH7868FS-X IC IC930 GP1FAV30TK0F OPTICAL JACK

Q1000 KTC2026/Y/ TRANSISTOR Q1001 KTC3203/OY/-T TRANSISTOR Q2007 KTA1046/Y/ TRANSISTOR Q2008 KTC3199/GL/-T TRANSISTOR Q2009 KTC3199/GL/-T TRANSISTOR Q9300 KRA110M-T TRANSISTOR Q9301 KRC110M-T TRANSISTOR Q9303 KTC3199/GL/-T TRANSISTOR



D1000 1N5402M-20 DIODE



D1001 1N5402M-20 DIODE



D1002 1N5402M-20 DIODE



D1003 1N5402M-20 DIODE



D1006 6A10E2 SI DIODE



D1007 6A10E2 SI DIODE



D1010 6A10E2 SI DIODE



D1011 6A10E2 SI DIODE D1012 MTZJ6.2B-T2 Z DIODE D1013 MTZJ18B-T2 Z DIODE D1014 MTZJ18B-T2 Z DIODE D1015 1N4003S-T5 SI DIODE D1016 1N4003S-T5 SI DIODE D1017 1N4003S-T5 SI DIODE



D2001 6A10E2 SI DIODE



D2002 6A10E2 SI DIODE



D2003 6A10E2 SI DIODE



D2004 6A10E2 SI DIODE D2008 2A02-M DIODE D2009 MTZJ5.1C-T2 Z DIODE D2013 1SS133-T2 SI DIODE D9300 2A02-M DIODE D9301 MTZJ3.3B-T2 Z DIODE D9302 MTZJ2.0A-T2 Z DIODE D9303 MTZJ3.9B-T2 Z DIODE D9310 MTZJ3.0B-T2 Z DIODE D9311 1N4003S-T5 SI DIODE D9312 1N4003S-T5 SI DIODE D9313 1N4003S-T5 SI DIODE

C1002 QETN1HM-226Z E CAPACITOR 22uF 50V M C1003 QETN1HM-226Z E CAPACITOR 22uF 50V M C1004 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M C1005 QETN1HM-106Z E CAPACITOR 10uF 50V M C1010 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1011 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J C1013 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C1014 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C1015 QFKC2EK-103Z MM CAPACITOR 0.01uF 250V K C1016 QETN2AM-476Z E CAPACITOR 47uF 100V M C1017 QETN1HM-107Z E CAPACITOR 100uF 50V M

Part No. Part Name Description Local

C2000 QEZ0706-478 E CAPACITOR 4700uF C2004 QEZ0706-478 E CAPACITOR 4700uF C2005 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J C2006 QETM1HM-228 E CAPACITOR 2200uF 50V M C2007 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J C2008 QETM1HM-228 E CAPACITOR 2200uF 50V M C2009 QFKC2EK-104Z MM CAPACITOR 0.1uF 250V K C2010 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C2011 QCBB1HK-221Y C CAPACITOR 220pF 50V K C2012 QETM1CM-478 E CAPACITOR 4700uF 16V M C2013 QETM1EM-478 E CAPACITOR 4700uF 25V M C9200 QETN1AM-477Z E CAPACITOR 470uF 10V M C9201 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C9204 QETN1HM-105Z E CAPACITOR 1uF 50V M C9206 QETN1HM-105Z E CAPACITOR 1uF 50V M C9209 QETN1CM-226Z E CAPACITOR 22uF 16V M C9211 QETN1HM-105Z E CAPACITOR 1uF 50V M C9213 QETN1HM-105Z E CAPACITOR 1uF 50V M C9215 QETN1HM-105Z E CAPACITOR 1uF 50V M C9216 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C9218 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9221 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9224 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9227 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9230 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9232 QETN0JM-477Z E CAPACITOR 470uF 6.3V M C9300 QETN0JM-107Z E CAPACITOR 100uF 6.3V M C9303 QETN1CM-107Z E CAPACITOR 100uF 16V M



R1000 QRK126J-470X UNF C RESISTOR 47Ω 1/2W J R1001 QRE141J-753Y C RESISTOR 75kΩ 1/4W J R1002 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R1003 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R1005 QRE141J-753Y C RESISTOR 75kΩ 1/4W J R2000 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R2001 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R2002 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R2003 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R2004 QRE141J-681Y C RESISTOR 680Ω 1/4W J R2005 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R2006 QRE141J-681Y C RESISTOR 680Ω 1/4W J R2007 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R2008 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R2009 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R2010 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R2011 QRL01DJ-471X OMF RESISTOR 470Ω 1W J R2012 QRL01DJ-471X OMF RESISTOR 470Ω 1W J R2014 QRE141J-273Y C RESISTOR 27kΩ 1/4W J R9201 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9202 QRE141J-391Y C RESISTOR 390 R9203 QRE141J-361Y C RESISTOR 360Ω 1/4W J R9204 QRE141J-131Y C RESISTOR 130 R9205 QRE141J-361Y C RESISTOR 360 R9206 QRE141J-131Y C RESISTOR 130Ω 1/4W J R9207 QRE141J-391Y C RESISTOR 390 R9208 QRE141J-391Y C RESISTOR 390 R9209 QRE141J-391Y C RESISTOR 390Ω 1/4W J R9210 QRE141J-391Y C RESISTOR 390 R9218 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9221 QRE141J-750Y C RESISTOR 75 R9224 QRE141J-750Y C RESISTOR 75 R9227 QRE141J-750Y C RESISTOR 75Ω 1/4W J R9230 QRE141J-750Y C RESISTOR 75 R9232 QRE141J-750Y C RESISTOR 75 R9300 QRT017J-2R2 MF RESISTOR 2.2Ω 1W J R9301 QRE141J-681Y C RESISTOR 680 R9302 QRZ9006-4R7X F.RESISTOR 4.7 R9303 QRE141J-271Y C RESISTOR 270 R9310 QRE141J-470Y C RESISTOR 47

CN100 QGA7901C1-02 CONNECTOR W-B (1-2) CN101 QGA7901C1-04 CONNECTOR W-B (1-4) CN102 QGA7901C1-03 CONNECTOR W-B (1-3) CN103 QGA3901F1-08 CONNECTOR W-B (1-8) CN104 QGB2510J1-13 CONNECTOR B-B (1-13) CN105 QGD2503F1-03 CONNECTOR (1-3) CN106 QGA3901F1-03 CONNECTOR W-B (1-3) CN200 QGB2510J1-12 CONNECTOR B-B (1-12)

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

3-43



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

CN201 QGB2510J1-09 CONNECTOR B-B (1-9) CN202 QGD2504C1-03Z CONNECTOR (1-3) CN203 QGB2510K2-06 CONNECTOR B-B (1-6) CN204 QGB2510K2-13 CONNECTOR B-B (1-13) CN920 QGF1205C1-08 CONNECTOR FFC/FPC (1-8) CN930 QGF1036C1-28 CONNECTOR FFC/FPC (1-28) CN931 QGF1205C1-11 CONNECTOR FFC/FPC (1-11) EP201 E409182-001SM GRAND TERMINAL H2001 GV40577-001A HEAT SINK IH920 GV40397-003A IC HOLDER J920 QNN0624-001 PIN JACK J921 QNN0557-002 PIN JACK PP201 QZW0038-001 WIRE CLAMP PP202 QZW0038-001 WIRE CLAMP



S1000 QSW0812-001 VOLTAGE SWITCH Z1001 QNG0003-001Z FUSE CLIP Z1002 QNG0003-001Z FUSE CLIP Z1003 QNG0003-001Z FUSE CLIP Z1004 QNG0003-001Z FUSE CLIP Z1005 QNG0003-001Z FUSE CLIP Z1006 QNG0003-001Z FUSE CLIP Z1007 QNG0003-001Z FUSE CLIP Z1008 QNG0003-001Z FUSE CLIP Z1009 QNG0003-001Z FUSE CLIP Z1010 QNG0003-001Z FUSE CLIP Z1011 QNG0003-001Z FUSE CLIP Z1012 QNG0003-001Z FUSE CLIP Z1013 QNG0003-001Z FUSE CLIP Z1014 QNG0003-001Z FUSE CLIP Z1015 QNG0003-001Z FUSE CLIP Z1016 QNG0003-001Z FUSE CLIP

DVD servo board(FMU-SM1-1M) (DX-T9,DX-T7)

Block No. [1][0]



Symbol No.

IC201 LA6502-X IC IC301 MN2DS0009AA IC IC302 MM1701CH-X IC IC305 MM1563BF-X IC 3.1V Regulator IC451 MN101C61GNW IC IC452 BR93L56RFV-W-X IC IC453 S-80827CNNB-G-W IC IC505 K4S641632H-UC75 IC IC505 or HY57V641620ETP7 IC(DIGITAL) IC509 SG32M90TFIR3 IC(MICRO C ROM) IC510 BR24L16FV-W-X IC IC701 AK4384VT-X IC IC701 or AK4384ET-X IC IC702 AK4384VT-X IC IC702 or AK4384ET-X IC IC703 AK4384VT-X IC IC703 or AK4384ET-X IC IC704 AK5357VT-X IC IC704 or AK5357ET-X IC IC705 MM1615AN-X IC

Q101 KTA1001/Y/-X TRANSISTOR Q101 or 2SB1424/R/-W TRANSISTOR Q102 2SC4617/R/-X TRANSISTOR Q103 KTA1001/Y/-X TRANSISTOR Q103 or 2SB1424/R/-W TRANSISTOR Q104 2SC4617/R/-X TRANSISTOR Q105 UN2119-X TRANSISTOR Q105 or KRA116S-X TRANSISTOR

C101 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C102 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C103 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C104 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C105 NEAF0JM-476X E CAPACITOR 47uF 6.3V M

Part No. Part Name Description Local

C106 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M C107 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C108 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M C201 NDC31HJ-221X C CAPACITOR 220pF 50V J C202 NDC31HJ-221X C CAPACITOR 220pF 50V J C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K C204 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C205 NCB31HK-271X C CAPACITOR 270pF 50V K C206 NDC31HJ-151X C CAPACITOR 150pF 50V J C210 NCF31AZ-105X C CAPACITOR 1uF 10V Z C211 NCB31EK-223X C CAPACITOR 0.022uF 25V K C217 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K C257 NCB31HK-822X C CAPACITOR 8200pF 50V K C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K C260 NCB31HK-223X C CAPACITOR 0.022uF 50V K C261 NCB31HK-223X C CAPACITOR 0.022uF 50V K C262 NCB31HK-223X C CAPACITOR 0.022uF 50V K C300 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C301 NEAF0GM-476X E CAPACITOR 47uF 4V M C302 NEAF0GM-476X E CAPACITOR 47uF 4V M C303 NEAF0GM-476X E CAPACITOR 47uF 4V M C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K C305 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C306 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C307 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C308 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C309 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K C311 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C312 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C313 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C314 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C315 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C316 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C318 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C319 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K C324 NCB30JK-105X C CAPACITOR 1uF 6.3V K C325 NDC31HJ-120X C CAPACITOR 12pF 50V J C326 NDC31HJ-100X C CAPACITOR 10pF 50V J C328 NCB31HK-103X C CAPACITOR 0.01uF 50V K C329 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C330 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C331 NCB31CK-333X C CAPACITOR 0.033uF 16V K C332 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C333 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C334 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C335 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C337 NCB31CK-183X C CAPACITOR 0.018uF 16V K C338 NCB31HK-562X C CAPACITOR 5600pF 50V K C339 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M C340 NCB30JK-105X C CAPACITOR 1uF 6.3V K C341 NCB30JK-105X C CAPACITOR 1uF 6.3V K C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K C349 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C350 NCB31HK-103X C CAPACITOR 0.01uF 50V K C351 NCB31HK-103X C CAPACITOR 0.01uF 50V K C352 NCB31CK-153X C CAPACITOR 0.015uF 16V K C353 NCB31HK-561X C CAPACITOR 560pF 50V K C354 NCB31HK-561X C CAPACITOR 560pF 50V K C356 NCB30JK-105X C CAPACITOR 1uF 6.3V K C359 NCB30JK-105X C CAPACITOR 1uF 6.3V K C371 NCF31AZ-105X C CAPACITOR 1uF 10V Z C372 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C373 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C374 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C375 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C376 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C377 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C378 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C379 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z

3-44



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C380 NCB21CK-105X C CAPACITOR 1uF 16V K C381 NCB21AK-225X C CAPACITOR 2.2uF 10V K C382 NCB31HK-471X C CAPACITOR 470pF 50V K C383 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C386 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C393 NCB31HK-103X C CAPACITOR 0.01uF 50V K C451 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C452 NCB31CK-104X C CAPACITOR 0.1uF 16V K C453 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C454 NCB31HK-103X C CAPACITOR 0.01uF 50V K C455 NCB31HK-103X C CAPACITOR 0.01uF 50V K C551 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C554 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C555 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C556 NCF31AZ-105X C CAPACITOR 1uF 10V Z C557 NCB31HK-102X C CAPACITOR 1000pF 50V K C558 NEAF0GM-476X E CAPACITOR 47uF 4V M C559 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C560 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C563 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C564 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C701 NCB21CK-105X C CAPACITOR 1uF 16V K C702 NCB31HK-103X C CAPACITOR 0.01uF 50V K C703 NCB30JK-105X C CAPACITOR 1uF 6.3V K C704 NCF31AZ-105X C CAPACITOR 1uF 10V Z C705 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C706 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C707 NEAF1CM-106X E CAPACITOR 10uF 16V M C708 NEAF1CM-106X E CAPACITOR 10uF 16V M C709 NEAF0JM-476X E CAPACITOR 47uF 6.3V M C712 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C713 NEAF1CM-106X E CAPACITOR 10uF 16V M C714 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C715 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C716 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C717 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C718 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C722 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z

R101 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R102 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R103 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R104 NRSA63J-432X MG RESISTOR 4.3kΩ 1/16W J R105 NRS181J-180X MG RESISTOR 18Ω 1/8W J R106 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J R107 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R108 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R109 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R111 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R112 NRSA63J-432X MG RESISTOR 4.3k R113 NRS181J-180X MG RESISTOR 18Ω 1/8W J R114 NRSA63J-2R2X MG RESISTOR 2.2 R115 NRSA63J-102X MG RESISTOR 1k R116 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R117 NRSA63J-331X MG RESISTOR 330 R125 NRSA63J-1R0X MG RESISTOR 1 R126 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R127 NRSA63J-432X MG RESISTOR 4.3k R128 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R202 NRSA63J-102X MG RESISTOR 1k R204 NRSA63J-273X MG RESISTOR 27k R205 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R206 NRSA63J-303X MG RESISTOR 30k R207 NRSA63J-473X MG RESISTOR 47k R213 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R214 NRSA63J-103X MG RESISTOR 10k R219 NRSA63J-183X MG RESISTOR 18k R220 NRSA63J-243X MG RESISTOR 24k R221 NRSA63J-682X MG RESISTOR 6.8k R251 NRS125J-R39X MG RESISTOR 0.39Ω 1/2W J R259 NRSA63J-103X MG RESISTOR 10k R301 NRS181J-0R0X MG RESISTOR 0 R303 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R306 NRSA63J-102X MG RESISTOR 1k R307 NRSA63J-102X MG RESISTOR 1k R308 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R309 NRSA63J-104X MG RESISTOR 100k R310 NRSA63J-101X MG RESISTOR 100

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R316 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R319 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R324 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R325 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R326 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R327 NRSA63J-331X MG RESISTOR 330 R330 NRSA63J-331X MG RESISTOR 330 R331 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R332 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R334 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R335 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R336 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R337 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R338 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R339 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R340 NRSA63D-303X MG RESISTOR 30kΩ 1/16W D R341 NRSA63D-512X MG RESISTOR 5.1kΩ 1/16W D R342 NRSA63D-242X MG RESISTOR 2.4kΩ 1/16W D R345 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R346 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R347 NRSA63J-203X MG RESISTOR 20k R348 NRSA63J-151X MG RESISTOR 150 R349 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R350 NRSA63J-751X MG RESISTOR 750Ω 1/16W J R351 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R352 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J R353 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R357 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R358 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R359 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R360 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R362 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R367 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R372 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R373 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R374 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R375 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R376 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R377 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R378 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R383 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R384 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R385 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R392 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R393 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R394 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R452 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R453 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R454 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R455 NRSA63J-103X MG RESISTOR 10k R456 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R457 NRSA63J-101X MG RESISTOR 100 R458 NRSA63J-102X MG RESISTOR 1k R461 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R463 NRSA63J-101X MG RESISTOR 100 R464 NRSA63J-101X MG RESISTOR 100 R465 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R535 NRSA63J-473X MG RESISTOR 47k R541 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R701 NRSA63J-2R2X MG RESISTOR 2.2 R703 NRSA63J-471X MG RESISTOR 470 R704 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R705 NRSA63J-471X MG RESISTOR 470 R706 NRSA63J-471X MG RESISTOR 470 R707 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R708 NRSA63J-471X MG RESISTOR 470 R714 NRSA63J-101X MG RESISTOR 100 R715 NRSA63J-101X MG RESISTOR 100 R716 NRSA63J-471X MG RESISTOR 470 R717 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R719 NRSA63J-5R1X MG RESISTOR 5.1 R720 NRSA63J-473X MG RESISTOR 47k R722 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R731 NRSA63J-102X MG RESISTOR 1k R732 NRSA63J-471X MG RESISTOR 470

CN101 QGF0523F1-25W CONNECTOR FFC/FPC (1-25) CN201 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-45



Symbol No.

CN451 QGF1016F2-15W CONNECTOR FFC/FPC (1-15) CN452 QGA2001F2-02X CONNECTOR W-B (1-2) CN453 QGA2001F2-03X CONNECTOR W-B (1-3) CN701 QGF1016F2-28W CONNECTOR FFC/FPC (1-28) CN702 QGF1016F2-10W CONNECTOR FFC/FPC (1-10) CN703 QGF1016F2-08W CONNECTOR FFC/FPC (1-8) K351 NQR0502-001X FERRITE BEADS K352 NQR0502-001X FERRITE BEADS K454 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K455 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K456 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K501 NQR0502-001X FERRITE BEADS K710 NQR0022-002X FERRITE BEADS K732 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K733 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K734 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K735 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K736 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K737 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K738 NQR0022-005X FERRITE BEADS K741 NQR0022-002X FERRITE BEADS K744 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K748 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K749 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K750 NQR0022-002X FERRITE BEADS K752 NQR0022-002X FERRITE BEADS K754 NQR0022-002X FERRITE BEADS K756 NQR0022-002X FERRITE BEADS K758 NQR0022-002X FERRITE BEADS TH301 NAD0025-103X N THERMISTOR 10k X301 NAX0741-001X CRYSTAL X451 NAX0248-001X C OSCILLATOR 8.000MHz

Part No. Part Name Description Local

Ω

Loading board(FMU-SM1-1M) (DX-T9,DX-T7)

Block No. [1][1]



Symbol No.

IC1 LB1641 IC IC2 LB1641 IC

D1 MTZJ6.2A-T2 Z DIODE

C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K

CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15) CN2 QGB2024K1-07S CONNECTOR B-B (1-7) CN3 QGB2024J1-07S CONNECTOR B-B (1-7) SW1 QSW0844-001 PUSH SWITCH SW2 QSW0844-001 PUSH SWITCH SW3 QSW0844-001 PUSH SWITCH SW4 QSW0844-001 PUSH SWITCH SW5 QSW0844-001 PUSH SWITCH SW6 QSW0854-002 PUSH SW SW8 QSW0923-001 DETECT SWITCH

Part No. Part Name Description Local

DVD servo board(FMU-SM1-11M) (DX-T5)

Block No. [1][2]



Symbol No.

IC201 LA6502-X IC IC301 MN2DS0009AA IC IC302 MM1701CH-X IC IC305 MM1563BF-X IC 3.1V Regulator IC451 MN101C61GNW IC IC452 BR93L56RFV-W-X IC IC453 S-80827CNNB-G-W IC IC505 K4S641632H-UC75 IC IC505 or HY57V641620ETP7 IC(DIGITAL) IC509 SG32M90TFIR3 IC(MICRO C ROM) IC510 BR24L16FV-W-X IC IC701 AK4384VT-X IC IC701 or AK4384ET-X IC IC705 MM1615AN-X IC

Q101 KTA1001/Y/-X TRANSISTOR Q101 or 2SB1424/R/-W TRANSISTOR Q102 2SC4617/R/-X TRANSISTOR Q103 KTA1001/Y/-X TRANSISTOR Q103 or 2SB1424/R/-W TRANSISTOR Q104 2SC4617/R/-X TRANSISTOR Q105 UN2119-X TRANSISTOR Q105 or KRA116S-X TRANSISTOR

C101 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C102 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C103 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C104 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C105 NEAF0JM-476X E CAPACITOR 47uF 6.3V M C106 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M C107 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C108 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M C201 NDC31HJ-221X C CAPACITOR 220pF 50V J C202 NDC31HJ-221X C CAPACITOR 220pF 50V J C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K C204 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C205 NCB31HK-271X C CAPACITOR 270pF 50V K C206 NDC31HJ-151X C CAPACITOR 150pF 50V J C210 NCF31AZ-105X C CAPACITOR 1uF 10V Z C211 NCB31EK-223X C CAPACITOR 0.022uF 25V K C217 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K C257 NCB31HK-822X C CAPACITOR 8200pF 50V K C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K C260 NCB31HK-223X C CAPACITOR 0.022uF 50V K C261 NCB31HK-223X C CAPACITOR 0.022uF 50V K C262 NCB31HK-223X C CAPACITOR 0.022uF 50V K C300 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C301 NEAF0GM-476X E CAPACITOR 47uF 4V M C302 NEAF0GM-476X E CAPACITOR 47uF 4V M C303 NEAF0GM-476X E CAPACITOR 47uF 4V M C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K C305 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C306 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C307 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C308 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C309 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K C311 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C312 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C313 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C314 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C315 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C316 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C318 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C319 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K C324 NCB30JK-105X C CAPACITOR 1uF 6.3V K C325 NDC31HJ-120X C CAPACITOR 12pF 50V J

Part No. Part Name Description Local

3-46



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C326 NDC31HJ-100X C CAPACITOR 10pF 50V J C328 NCB31HK-103X C CAPACITOR 0.01uF 50V K C329 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C330 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C331 NCB31CK-333X C CAPACITOR 0.033uF 16V K C332 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C333 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C334 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C335 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C337 NCB31CK-183X C CAPACITOR 0.018uF 16V K C338 NCB31HK-562X C CAPACITOR 5600pF 50V K C339 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M C340 NCB30JK-105X C CAPACITOR 1uF 6.3V K C341 NCB30JK-105X C CAPACITOR 1uF 6.3V K C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K C349 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C350 NCB31HK-103X C CAPACITOR 0.01uF 50V K C351 NCB31HK-103X C CAPACITOR 0.01uF 50V K C352 NCB31CK-153X C CAPACITOR 0.015uF 16V K C353 NCB31HK-561X C CAPACITOR 560pF 50V K C354 NCB31HK-561X C CAPACITOR 560pF 50V K C356 NCB30JK-105X C CAPACITOR 1uF 6.3V K C359 NCB30JK-105X C CAPACITOR 1uF 6.3V K C371 NCF31AZ-105X C CAPACITOR 1uF 10V Z C372 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C373 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C374 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C375 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C376 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C377 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C378 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C379 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C380 NCB21CK-105X C CAPACITOR 1uF 16V K C381 NCB21AK-225X C CAPACITOR 2.2uF 10V K C382 NCB31HK-471X C CAPACITOR 470pF 50V K C383 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C386 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C393 NCB31HK-103X C CAPACITOR 0.01uF 50V K C451 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C452 NCB31CK-104X C CAPACITOR 0.1uF 16V K C453 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C454 NCB31HK-103X C CAPACITOR 0.01uF 50V K C455 NCB31HK-103X C CAPACITOR 0.01uF 50V K C551 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C554 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C555 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C556 NCF31AZ-105X C CAPACITOR 1uF 10V Z C557 NCB31HK-102X C CAPACITOR 1000pF 50V K C558 NEAF0GM-476X E CAPACITOR 47uF 4V M C559 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C560 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C563 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C564 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C701 NCB21CK-105X C CAPACITOR 1uF 16V K C702 NCB31HK-103X C CAPACITOR 0.01uF 50V K C703 NCB30JK-105X C CAPACITOR 1uF 6.3V K C709 NEAF0JM-476X E CAPACITOR 47uF 6.3V M C712 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C713 NEAF1CM-106X E CAPACITOR 10uF 16V M C714 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z C722 NCF31EZ-104X C CAPACITOR 0.1uF 25V Z

R101 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R102 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R103 NRSA63J-562X MG RESISTOR 5.6k R104 NRSA63J-432X MG RESISTOR 4.3k R105 NRS181J-180X MG RESISTOR 18 R106 NRSA63J-2R2X MG RESISTOR 2.2 R107 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R108 NRSA63J-471X MG RESISTOR 470 R109 NRSA63J-331X MG RESISTOR 330 R111 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R112 NRSA63J-432X MG RESISTOR 4.3k R113 NRS181J-180X MG RESISTOR 18 R114 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J R115 NRSA63J-102X MG RESISTOR 1k R116 NRSA63J-471X MG RESISTOR 470

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

R117 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R125 NRSA63J-1R0X MG RESISTOR 1Ω 1/16W J R126 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R127 NRSA63J-432X MG RESISTOR 4.3kΩ 1/16W J R128 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R202 NRSA63J-102X MG RESISTOR 1k R204 NRSA63J-273X MG RESISTOR 27k R205 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R206 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J R207 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R213 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R214 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R219 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J R220 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J R221 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R251 NRS125J-R39X MG RESISTOR 0.39Ω 1/2W J R259 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R301 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J R303 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R306 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R307 NRSA63J-102X MG RESISTOR 1k R308 NRSA63J-103X MG RESISTOR 10k R309 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R310 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R316 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R319 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R324 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R325 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R326 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R327 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R334 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R335 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R336 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R337 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R338 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R339 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R340 NRSA63D-303X MG RESISTOR 30kΩ 1/16W D R341 NRSA63D-512X MG RESISTOR 5.1kΩ 1/16W D R342 NRSA63D-242X MG RESISTOR 2.4kΩ 1/16W D R345 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R346 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R347 NRSA63J-203X MG RESISTOR 20kΩ 1/16W J R348 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R349 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R350 NRSA63J-751X MG RESISTOR 750Ω 1/16W J R351 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R352 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J R353 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R357 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R358 NRSA63J-221X MG RESISTOR 220 R362 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R367 NRSA63J-221X MG RESISTOR 220 R372 NRSA63J-103X MG RESISTOR 10k R373 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R374 NRSA63J-102X MG RESISTOR 1k R375 NRSA63J-102X MG RESISTOR 1k R376 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R377 NRSA63J-102X MG RESISTOR 1k R378 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R383 NRSA63J-101X MG RESISTOR 100 R384 NRSA63J-102X MG RESISTOR 1k R385 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R392 NRSA63J-103X MG RESISTOR 10k R393 NRSA63J-0R0X MG RESISTOR 0 R394 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R452 NRSA63J-222X MG RESISTOR 2.2k R453 NRSA63J-103X MG RESISTOR 10k R454 NRSA63J-103X MG RESISTOR 10k R455 NRSA63J-103X MG RESISTOR 10k R456 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R457 NRSA63J-101X MG RESISTOR 100 R458 NRSA63J-102X MG RESISTOR 1k R461 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R463 NRSA63J-101X MG RESISTOR 100 R464 NRSA63J-101X MG RESISTOR 100 R465 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R535 NRSA63J-473X MG RESISTOR 47k R541 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-47



Symbol No.

R701 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J R703 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R704 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R717 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R731 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R732 NRSA63J-471X MG RESISTOR 470

CN101 QGF0523F1-25W CONNECTOR FFC/FPC (1-25) CN201 QGF1016F2-08W CONNECTOR FFC/FPC (1-8) CN451 QGF1016F2-15W CONNECTOR FFC/FPC (1-15) CN452 QGA2001F2-02X CONNECTOR W-B (1-2) CN453 QGA2001F2-03X CONNECTOR W-B (1-3) CN701 QGF1016F2-28W CONNECTOR FFC/FPC (1-28) CN702 QGF1016F2-10W CONNECTOR FFC/FPC (1-10) K351 NQR0502-001X FERRITE BEADS K352 NQR0502-001X FERRITE BEADS K454 NRSA63J-0R0X MG RESISTOR 0 K455 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K456 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K501 NQR0502-001X FERRITE BEADS K710 NQR0022-002X FERRITE BEADS K732 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K733 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K734 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K735 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K736 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K737 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K738 NQR0022-005X FERRITE BEADS K744 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K748 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K749 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K750 NQR0022-002X FERRITE BEADS K752 NQR0022-002X FERRITE BEADS K754 NQR0022-002X FERRITE BEADS K756 NQR0022-002X FERRITE BEADS K758 NQR0022-002X FERRITE BEADS TH301 NAD0025-103X N THERMISTOR 10k X301 NAX0741-001X CRYSTAL X451 NAX0248-001X C OSCILLATOR 8.000MHz

Part No. Part Name Description Local

Ω

1/16W J

Ω

1/16W J

Ω

Loading board(FMU-SM1-11M) (DX-T5)

Block No. [1][3]



Symbol No.

IC1 LB1641 IC IC2 LB1641 IC

D1 MTZJ6.2A-T2 Z DIODE

C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K

CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15) CN2 QGB2024K1-07S CONNECTOR B-B (1-7) CN3 QGB2024J1-07S CONNECTOR B-B (1-7) SW1 QSW0844-001 PUSH SWITCH SW2 QSW0844-001 PUSH SWITCH SW3 QSW0844-001 PUSH SWITCH SW4 QSW0844-001 PUSH SWITCH SW5 QSW0844-001 PUSH SWITCH SW6 QSW0854-002 PUSH SW SW8 QSW0923-001 DETECT SWITCH

Part No. Part Name Description Local

Cassette switch board(SLC-S401M)

-Cassette A (Common)

Block No. [1][4]



Symbol No.

IC1 SG-105F3/Z1/ PHOTO SENSER IC41 NJM4565D IC IC43 CD4094BE IC

CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9) CN41 QGF1205F1-09 CONNECTOR FFC/FPC (1-9) CN45 QGF1205F1-25 CONNECTOR FFC/FPC (1-25) CN46 QGF1210G1-09 CONNECTOR FFC/FPC (1-9) CN47 QGF1210G1-10 CONNECTOR FFC/FPC (1-10) CN48 QGF1205F1-06 CONNECTOR FFC/FPC (1-6) FW100 QUM024-07A2Z3 PARA RIBON WIRE P1 QNZ0104-001 POST PIN SW2 QSW0832-001 CASS.SWITCH SW6 QSW0859-001 DETECT SWITCH

Part No. Part Name Description Local

Head amplifier board(SLC-S401M)

-Cassette A (Common)

Block No. [1][5]



Symbol No.

Q460 2SC3576-JVC-T TRANSISTOR Q461 2SC3576-JVC-T TRANSISTOR Q481 KTA1271/OY/-T TRANSISTOR Q482 KRC107M-T DIGI TRANSISTOR Q485 2SB562/C/-T TRANSISTOR Q486 KTC3199/GL/-T TRANSISTOR

D1 1SR139-400-T2 SI DIODE D482 1SS133-T2 SI DIODE D483 1SS133-T2 SI DIODE D485 MTZJ5.1B-T2 Z DIODE

C449 QEKJ1CM-476Z E CAPACITOR 47uF 16V M C450 QDGB1HK-821Y C CAPACITOR 820pF 50V K C451 QDGB1HK-821Y C CAPACITOR 820pF 50V K C452 QCBB1HK-101Y C CAPACITOR 100pF 50V K C453 QCBB1HK-101Y C CAPACITOR 100pF 50V K C458 QEKJ1AM-107Z E CAPACITOR 100uF 10V M C459 QCBB1HK-391Y C CAPACITOR 390pF 50V K C460 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C461 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K C462 QEKJ1AM-107Z E CAPACITOR 100uF 10V M C463 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M C465 QEKJ1AM-107Z E CAPACITOR 100uF 10V M C466 QCBB1HK-391Y C CAPACITOR 390pF 50V K C467 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M C468 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M C469 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M C480 QEKJ1CM-476Z E CAPACITOR 47uF 16V M C481 QEKJ1AM-107Z E CAPACITOR 100uF 10V M C484 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M C486 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K

R371 QRE141J-123Y C RESISTOR 12kΩ 1/4W J R449 QRE141J-221Y C RESISTOR 220 R452 QRE141J-563Y C RESISTOR 56k R453 QRE141J-101Y C RESISTOR 100 R454 QRE141J-101Y C RESISTOR 100 R456 QRE141J-133Y C RESISTOR 13kΩ 1/4W J R457 QRE141J-133Y C RESISTOR 13k R458 QRE141J-472Y C RESISTOR 4.7k R459 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R460 QRE141J-334Y C RESISTOR 330k R461 QRE141J-334Y C RESISTOR 330k R462 QRE141J-101Y C RESISTOR 100Ω 1/4W J R463 QRE141J-563Y C RESISTOR 56k

Part No. Part Name Description Local

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

3-48



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R465 QRE141J-101Y C RESISTOR 100Ω 1/4W J R466 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R467 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R468 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R469 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R470 QRE141J-472Y C RESISTOR 4.7k R471 QRE141J-473Y C RESISTOR 47k R480 QRE141J-123Y C RESISTOR 12kΩ 1/4W J R481 QRE141J-183Y C RESISTOR 18kΩ 1/4W J R482 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R483 QRE141J-681Y C RESISTOR 680Ω 1/4W J R485 QRE141J-151Y C RESISTOR 150Ω 1/4W J R486 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R487 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J R488 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J R489 QRE141J-243Y C RESISTOR 24kΩ 1/4W J VR37 QVP0077-103Z TRIM RESISTOR 10k

Ω

1/4W J

Ω

1/4W J

Ω

Cassette board(SLC-S302M)

-Cassette B (Common)

Block No. [1][6]



Symbol No.

IC1 SG-105F3-BB,C PHOTO SENSER

D1 1SR139-400-T2 SI DIODE

R371 QRE141J-123Y C RESISTOR 12kΩ 1/4W J VR37 QVP0077-103Z TRIM RESISTOR 10k

CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9) FW100 QUM024-07A2Z3 PARA RIBON WIRE P1 QNZ0104-001 POST PIN SW1 QSW0832-001 CASS.SWITCH SW2 QSW0832-001 CASS.SWITCH SW5 QSW0832-001 CASS.SWITCH SW6 QSW0859-001 DETECT SWITCH

Part No. Part Name Description Local

Ω

Head amplifier board(SLC-S302M)

-Cassette B (Common)

Block No. [1][7]



Symbol No.

IC32 HA12238F IC R/P Equalizer

IC33 CD4094BC IC

Q302 2SC2001/K/-T TRANSISTOR Q305 2SC2001/K/-T TRANSISTOR Q342 KRA111M-T DIGI TRANSISTOR Q343 2SC3576-JVC-T TRANSISTOR Q344 2SC3576-JVC-T TRANSISTOR Q345 2SC3576-JVC-T TRANSISTOR Q346 2SC3576-JVC-T TRANSISTOR Q347 KRC107M-T DIGI TRANSISTOR Q371 KTA1271/OY/-T TRANSISTOR Q372 KRC107M-T DIGI TRANSISTOR Q375 2SB562/C/-T TRANSISTOR Q376 KTC3199/GL/-T TRANSISTOR

D340 MTZJ5.1B-T2 Z DIODE D375 MTZJ5.1B-T2 Z DIODE

C101 QDGB1HK-821Y C CAPACITOR 820pF 50V K C102 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M C103 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J

Part No. Part Name Description Local

Serial to parallel port extension

C104 QCBB1HK-221Y C CAPACITOR 220pF 50V K C105 QCBB1HK-391Y C CAPACITOR 390pF 50V K C106 QERF1HM-225Z E CAPACITOR 2.2uF 50V M C107 QCBB1HK-271Y C CAPACITOR 270pF 50V K C109 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M C110 QDYB1CM-682Y C CAPACITOR 6800pF 16V M C113 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J C120 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C121 QCBB1HK-331Y C CAPACITOR 330pF 50V K C201 QDGB1HK-821Y C CAPACITOR 820pF 50V K C202 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M C203 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J C204 QCBB1HK-221Y C CAPACITOR 220pF 50V K C205 QCBB1HK-391Y C CAPACITOR 390pF 50V K C206 QERF1HM-225Z E CAPACITOR 2.2uF 50V M C207 QCBB1HK-271Y C CAPACITOR 270pF 50V K C209 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M C210 QDYB1CM-682Y C CAPACITOR 6800pF 16V M C213 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J C220 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K C221 QCBB1HK-331Y C CAPACITOR 330pF 50V K C300 QEKJ1HM-105Z E CAPACITOR 1uF 50V M C301 QEKJ1AM-107Z E CAPACITOR 100uF 10V M C304 QEKJ1CM-106Z E CAPACITOR 10uF 16V M C306 FQETJ1AM-227Z E CAPACITOR C307 QDGB1HK-102Y C CAPACITOR 1000pF 50V K C308 QDXB1CM-152Y C CAPACITOR 1500pF 16V M C310 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K C313 QEKJ1AM-107Z E CAPACITOR 100uF 10V M C314 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z C316 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J C319 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J C331 QEKJ1CM-476Z E CAPACITOR 47uF 16V M C340 QEKJ1CM-476Z E CAPACITOR 47uF 16V M C341 QEKJ1HM-105Z E CAPACITOR 1uF 50V M C342 QEKJ1CM-476Z E CAPACITOR 47uF 16V M C371 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M C374 QEKJ1AM-107Z E CAPACITOR 100uF 10V M C376 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M

R101 QRE141J-512Y C RESISTOR 5.1kΩ 1/4W J R102 QRE141J-512Y C RESISTOR 5.1kΩ 1/4W J R104 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R105 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R106 QRE141J-113Y C RESISTOR 11kΩ 1/4W J R107 QRE141J-912Y C RESISTOR 9.1kΩ 1/4W J R108 QRE141J-273Y C RESISTOR 27kΩ 1/4W J R110 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R116 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R121 QRE141J-153Y C RESISTOR 15k R201 QRE141J-512Y C RESISTOR 5.1kΩ 1/4W J R202 QRE141J-512Y C RESISTOR 5.1k R204 QRE141J-222Y C RESISTOR 2.2k R205 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R206 QRE141J-113Y C RESISTOR 11k R207 QRE141J-912Y C RESISTOR 9.1k R208 QRE141J-273Y C RESISTOR 27kΩ 1/4W J R210 QRE141J-103Y C RESISTOR 10k R216 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R221 QRE141J-153Y C RESISTOR 15k R301 QRE141J-221Y C RESISTOR 220 R302 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R303 QRE141J-222Y C RESISTOR 2.2k



R304 QRJ146J-101X UNF C RESISTOR 100Ω 1/4W J R305 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R306 QRE141J-472Y C RESISTOR 4.7k



R310 QRJ146J-4R7X UNF C RESISTOR 4.7Ω 1/4W J R313 QRE141J-2R2Y C RESISTOR 2.2 R314 QRE141J-153Y C RESISTOR 15k R315 QRE141J-101Y C RESISTOR 100Ω 1/4W J R327 QRE141J-474Y C RESISTOR 470k R335 QRE141J-222Y C RESISTOR 2.2k R336 QRE141J-223Y C RESISTOR 22kΩ 1/4W J R337 QRE141J-332Y C RESISTOR 3.3k R338 QRE141J-392Y C RESISTOR 3.9k R339 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R340 QRE141J-681Y C RESISTOR 680 R341 QRE141J-123Y C RESISTOR 12k

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

3-49



Symbol No.

R342 QRE141J-243Y C RESISTOR 24kΩ 1/4W J R343 QRE141J-183Y C RESISTOR 18kΩ 1/4W J R344 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R345 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R346 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R347 QRE141J-103Y C RESISTOR 10k



R353 QRZ9005-100X FUSI RESISTOR 10 R372 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R375 QRE141J-151Y C RESISTOR 150Ω 1/4W J R376 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J VR31 QVP0008-203Z TRIM RESISTOR 20k

L301 QQR1118-002 OSC COIL(BIAS) L303 QQL244K-100Z COIL 10uH K

CN31 QGF1205F1-06 CONNECTOR FFC/FPC (1-6) CN32 QGF1205F1-09 CONNECTOR FFC/FPC (1-9) CN33 QGF1205F1-09 CONNECTOR FFC/FPC (1-9) CN34 QGF1201F3-10 CONNECTOR FFC/FPC (1-10) H32 GV40397-002A IC HOLDER

Part No. Part Name Description Local

Ω

1/4W J

Ω

3-50

< MEMO >

3-51

Packing materials and accessories parts list

A

(DX-T9)

No additional / supplemental order of WARRANTY CARDs are available

Block No.

M

4

M

P5

1,A2,A3,

A4,A6,A7,

8,A9,

A10,

A12,

A11, A13,

P1

A17

P3

P2

A1

P4

A5

A3

A2

A13

A17

A15

A4

A19

A25

P12

P14

A19

A20

A25

A26

P6

P14 A19 P11

P7

A18

A22

A21

A24

A23

A20

P15

A21

P8

P10

P9

P13

A18

P10

P15

A21

3-52

A23

P16

Packing and Accessories (DX-T9)



Symbol No. Part No. Part Name Description Local

A 1 GVT0147-003A INST BOOK ENG A A 1 GVT0147-001A INST BOOK ENG CHI(PEKIN) UN,US A 1 GVT0147-004A INST BOOK ENG SPA POR UW A 1 GVT0147-002A INST BOOK ENG ARA PER UG,UX A 2 GV40634-001A DEMO SHEET A 3 GV40633-001A KARAOKE SHEET UG,UN,US,UX A 4 GV40639-001A ERRATA SHEET UG,UN,US,UX A 5 CL0020-001 COMPUTER LABEL A 6 QAL0014-001 AM LOOP ANT



A 7 QAM0112-002 PLUG ADAPTOR UN,US,UW A 8 QAM0216-001 SIGNAL CORD A 9 RM-SDXT9U REMOCON A 10 QAL0457-001 ANT.WIRE A 11 ------------------- BATTERY (x2) A 12 ------------------- WARRANTY CARD BT-56012-1 A A 13 GV40636-001A VOL-SEL.SHEET UN A 15 GV40641-002A NOM LABEL UW A 15 GV40597-001A SASO LABEL UX A 17 GV40633-002A KARAOKE SHEET UG,UX A 18 ASL8MDXT7-EB10 SPEAKER BOX MAIN SPEAKER(x2) A 19 ASL8SDXT9-EB10 SPEAKER BOX SURROUND SPEAKER(x2) A 20 ASL8CDXT9-EB10 SPEAKER BOX CENTER SPEAKER A 21 ASL8WDXT9-EB10 SPEAKER BOX SUBWOOFER(x2) A 22 ASW803302-0001 SPK NET ASSY (x2) A 23 DUF803001-0001 LEG CUSHION (x16) A 24 DUF803001-0002 LEG CUSHION (x3) A 25 DUF803001-0003 LEG CUSHION (x8) A 26 YOM800001-0243 USER MANUAL A,UN,US,UW A 26 YOM800001-0244 USER MANUAL UG,UX P 1 GV20352-004A CARTON ASSY. UN,US P 1 GV20352-005A CARTON ASSY. A,UW P 1 GV20352-007A CARTON ASSY. UX P 1 GV20352-006A CARTON ASSY. UG P 2 GV10272-001A CUSHION (BOTTOM) P 3 GV10271-001A CUSHION (TOP) P 4 QPC07507530P POLY BAG 75cm x 75cm P 5 QPC02503515P POLY BAG 25cm x 35cm P 6 ITF830347-0001 TOP CUSHION P 7 ITF830347-0002 CENTER CUSHION P 8 ITF830347-0003 BOTTOM CUSHION P 9 IVH803001-0006 MIRAMAT SHEET (x2) P 10 IVH803001-0007 MIRAMAT SHEET (x2) P 11 IVH803001-0008 MIRAMAT SHEET (x2) P 12 IVA803101-0023 HDPE BAG CENTER SPEAKER P 13 IVA803101-0024 HDPE BAG MAIN SPEAKER(x2) P 14 IVA803101-0027 HDPE BAG SURROUND SPEAKER(x2) P 15 IVA803101-0025 HDPE BAG SUBWOOFER(x2) P 16 ICC8PDXT9-EB10 PACKING CASE UG,UN,US P 16 ICC8PDXT9-EB30 PACKING CASE A,UX,UW

Block No. [M][4][M][M]

3-53

Packing materials and accessories parts list

A

(DX-T7)

No additional / supplemental order of WARRANTY CARDs are available

Block No.

M

5

M

P5

1,A2,A3,

A4,A5,A6,

7,A8,

A9,

A12,

A10, A13,

P1

A14

P2

P3

A1

P4

A3

A11

A2

A14

A13

A15

A4

A20

P11

A17

A21

A22

P6

A24

P10

A18

A23

P8

A19

A18

P12

A18

P12

P14

A20

P9

P13

A17

P7

3-54

P15

Packing and Accessories (DX-T7)



Symbol No. Part No. Part Name Description Local

A 1 GVT0147-003A INST BOOK ENG A A 1 GVT0147-001A INST BOOK ENG CHI(PEKIN) UN,US A 1 GVT0147-004A INST BOOK ENG SPA POR UW A 1 GVT0147-002A INST BOOK ENG ARA PER UG,UX A 2 GV40634-001A DEMO SHEET A 3 GV40633-001A KARAOKE SHEET UG,UN,US,UX A 4 GV40639-001A ERRATA SHEET UG,UN,US,UX A 5 QAL0014-001 AM LOOP ANT



A 6 QAM0112-002 PLUG ADAPTOR UN,US,UW A 7 QAM0216-001 SIGNAL CORD A 8 RM-SDXT9U REMOCON A 9 QAL0457-001 ANT.WIRE A 10 ----------------- BATTERY (x2) A 11 CL0020-001 COMPUTER LABEL A 12 ----------------- WARRANTY CARD BT-56012-1 A A 13 GV40633-002A KARAOKE SHEET UG,UX A 14 GV40636-001A VOL-SEL.SHEET UN A 15 GV40641-002A NOM LABEL UW A 17 ASL8MDXT7-EB10 SPEAKER BOX MAIN SPEAKER(x2) A 18 ASL8SDXT7-EB10 SPEAKER BOX SURROUND SPEAKER(x2) A 19 ASL8CDXT7-EB10 SPEAKER BOX CENTER SPEAKER A 20 ASL8WDXT7-EB10 SPEAKER BOX SUBWOOFER A 21 ASW803302-0001 SPK NET ASSY (x2) A 22 DUF803001-0001 LEG CUSHION (x12) A 23 DUF803001-0002 LEG CUSHION (x9) A 24 YOM800001-0241 USER MANUAL A,UN,US,UW A 24 YOM800001-0242 USER MANUAL UG,UX P 1 GV20353-004A CARTON ASSY. UN,US P 1 GV20353-005A CARTON ASSY. A,UW P 1 GV20353-006A CARTON ASSY. UG,UX P 2 GV10271-001A CUSHION (TOP) P 3 GV10272-001A CUSHION (BOTTOM P 4 QPC07507530P POLY BAG 75cm x 75cm P 5 QPC02503515P POLY BAG 25cm x 35cm P 6 ITF830346-0001 TOP CUSHION P 7 ITF830346-0002 BOTTOM CUSHION P 8 ITF830346-0003 CUSHION P 9 ITF830346-0004 CUSHION P 10 IVH803001-0006 MIRAMAT SHEET MAIN SPEAKER(x2) A,UN,US,UW P 11 IVH803001-0007 MIRAMAT SHEET SUBWOOFER UG,UX P 12 IVA803101-0023 HDPE BAG CENTER&SURROUND SPEAKER(x3) P 13 IVA803101-0024 HDPE BAG MAIN SPEAKER(x2) P 14 IVA803101-0025 HDPE BAG SUBWOOFER P 15 ICC8PDXT7-EB10 PACKING CASE UG,UN,US P 15 ICC8PDXT7-EB30 PACKING CASE A,UW,UX

Block No. [M][5][M][M]

3-55

Packing materials and accessories parts list

(DX-T5)

P6

A17

P10

A17

P7

P9

P10

A17

A20

P9

P5

A1,A2,A3, A4,A5,A6, A7,A8, A10, A13,

A9,

A12,

A14

P2

Block No.

A1

M

A3

6

A2

M

A14

A13

A12

A4

M

P11

A16

P8

A16

A18

A19

P11

A16

P4

P3

A11

A15

3-56

P1

Packing and Accessories (DX-T5)



Symbol No. Part No. Part Name Description Local

A 1 GVT0146-001A INST BOOK ENG CHI(PEKIN) UN,US A 1 GVT0146-004A INST BOOK ENG SPA POR UW A 1 GVT0146-002A INST BOOK ENG ARA PER UG,UX A 1 GVT0146-005A INST BOOK SPA UY A 2 GV40634-001A DEMO SHEET A 3 GV40633-001A KARAOKE SHEET UG,UN,US,UX A 4 GV40639-001A ERRATA SHEET UG,UN,US,UX A 5 QAL0014-001 AM LOOP ANT



A 6 QAM0112-002 PLUG ADAPTOR UN,US,UW A 7 QAM0216-001 SIGNAL CORD A 8 RM-SDXT5U REMOCON A 9 QAL0457-001 ANT.WIRE A 10 ----------------- BATTERY (x2) A 11 CL0020-001 COMPUTER LABEL A 12 GV40638-001A ERRATA SHEET UG A 13 GV40633-002A KARAOKE SHEET UG,UX A 14 GV40636-001A VOL-SEL.SHEET UN A 15 GV40641-002A NOM LABEL UW A 15 LV30259-003A UY LABEL UY A 16 ASL8MDXT5-EB10 SPEAKER BOX MAIN SPEAKER(x2) A 17 ASL8SDXT5-EB10 SPEAKER BOX SURROUND SPEAKER(x2) A 18 ASW803302-0001 SPK NET ASSY (x2) A 19 DUF803001-0001 LEG CUSHION (x8) A 20 DUF803001-0002 LEG CUSHION SURROUND SPEAKER(x6) P 1 GV20354-008A CARTON ASSY. UN,US P 1 GV20354-009A CARTON ASSY. UG,UX P 1 GV20354-007A CARTON ASSY. UW,UY P 2 GV10269-001A CUSHION (TOP) P 3 GV10270-001A CUSHION (BOTTOM) P 4 QPC07507530P POLY BAG 75cm x 75cm P 5 QPC02503515P POLY BAG 25cm x 35cm P 6 ITF830345-0001 TOP CUSHION P 7 ITF830345-0002 CENTER CUSHION P 8 ITF830345-0003 BOTTOM CUSHION P 9 IVH803001-0006 MIRAMAT SHEET (x2) P 10 IVA803101-0023 HDPE BAG SURROUND SPEAKER(x2) P 11 IVA803101-0024 HDPE BAG (x2)

Block No. [M][6][M][M]

3-57

JVC DXT-9-J Service manual

Specifications and Main Features

Frequently Asked Questions

User Manual

General Assembly (DX-T9)

General Assembly (DX-T7)

General Assembly (DX-T5)

DVD mechanism (Common)

DVD changer mechanism(FMU-SM1-1M) (DX-T9,DX-T7)

DVD changer mechanism(FMU-SM1-11M) (DX-T5)

Cassette mechanism(SLC-S401M)-Cassette A (Common)

Cassette mechanism(SLC-S302M)-CassetteB (Common)

Electrical parts list

Amplifier board (DX-T9)

Main board (DX-T9)

Primary board (DX-T9)

Amplifier board (DX-T7)

Main board (DX-T7)

Primary board (DX-T7)

Amplifier board (DX-T5)

Main board (DX-T5)

Primary board (DX-T5)

DVD servo board(FMU-SM1-1M) (DX-T9,DX-T7)

Loading board(FMU-SM1-1M) (DX-T9,DX-T7)

DVD servo board(FMU-SM1-11M) (DX-T5)

Loading board(FMU-SM1-11M) (DX-T5)

< MEMO >

Packing and Accessories (DX-T9)

Packing and Accessories (DX-T7)

Packing and Accessories (DX-T5)
