D-ILA PROJECTOR

DLA-X950R DLA-X750R DLA-X550R

Getting Started Set up Operate Adjust/Set Maintenance Troubleshooting Others

INSTRUCTIONS

Not suitable for household room illumination.

B5A-1144-13

Safety Precautions

IMPORTANT INFORMATION

This product has a High Intensity Dis-charge (HID) lamp that contains mercury. Manage in accord with disposal laws. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information, please contact your local authorities or for USA, the Electronic Industries Alliance: http://www.eiae.org. or call 1-800-252-5722(For USA) or 1-800-964-2650(For Canada).

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

FCC INFORMATION (U.S.A. only) CAUTION:

Changes or modification not approved by JVC could void the user’s authority to operate the equipment.

About the installation place

Do not install the projector in a place that cannot support its weight securely. If the installation place is not sturdy enough, the projector could fall or overturn, possibly causing personal injury.

Reorient or relocate the receiving antenna. Increase the separation between the equipment

and receiver.

Consult the dealer or an experienced radio/TV technician for help.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

NOTE:

This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec tion against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruc tions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encourage to try to correct the interference by one or more of the following measures:

WARNING:

THIS APPARATUS MUST BE EARTHED.

CAUTION:

To reduce the risk of electric shock, do not remove cover. Refer servicing to qualified service personnel.

This projector is equipped with a 3-blade grounding type plug to satisfy FCC rule. If you are unable to insert the plug into the outlet, contact your electrician.

⹣晼㯡婌♟㒷

For the customers in Taiwan only

NOISE EMISSION DECLARATION

The sound pressure level at the operator position is equal or less than 30dB(A) according to ISO7779.

Model Number: DLA-X950RBU, DLA-X750RBU, DLA-X550RBU Trade Name: JVC Responsible party: JVCKENWOOD USA Corporation

Address: 1700 Valley Road Wayne, N. J. 07470 Telephone Number: 973-317-5000 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Declaration of Conformity

Getting Started

PORTABLE CART WARNING (symbol provided by RETAC)

S3126A

IMPORTANT SAFEGUARDS

Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order not to defeat the safeguards incorporated into this product, observe the following basic rules for its installation, use and service. Please read these Important Safeguards carefully before use.

All the safety and operating instructions should be read before the product is operated. The safety and operating instructions should be retained for future reference. All warnings on the product and in the operating instructions should be adhered to. All operating instructions should be followed. Place the projector near a wall outlet where the plug can be easily unplugged. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. Do not use attachments not recommended by the product manufacturer as they may be hazardous. Do not use this product near water. Do not use immediately after moving from a low temperature to high temperature, as this causes condensation, which may result in fire, electric shock, or other hazards. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product. The product should be mounted according to the manufacturer’s instructions, and should use a mount recommended by the manufacturer. When the product is used on a cart, care should be taken to avoid quick stops, excessive force, and uneven surfaces which may cause the product and cart to overturn, damaging equipment or causing possible injury to the operator. Slots and openings in the cabinet are provided for ventilation. These ensure reliable operation of the product and protect it from overheating. These openings must not be blocked or covered. (The openings should never be blocked by placing the product on bed, sofa, rug, or similar surface. It should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided and the manufacturer’s instructions have been adhered to.) To allow better heat dissipation, keep a clearance between this unit and its surrounding as shown below. When this unit is enclosed in a space of dimensions as shown below, use an air-conditioner so that the internal and external temperatures are the same. Overheating can cause damage.

a) b)

c) d)

When the power supply cord or plug is damaged. If liquid has been spilled, or objects have fallen on the product. If the product has been exposed to rain or water. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the Operation Manual, as an improper adjustment of controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation. If the product has been dropped or damaged in any way. When the product exhibits a distinct change in performance, this indicates a need for service.

When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or with same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards. Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition. The product should be placed more than one foot away from heat sources such as radiators, heat registers, stoves, and other products (including amplifiers) that produce heat. When connecting other products such as VCR’s, and DVD players, you should turn off the power of this product for protection against electric shock.

Power source indicated on the label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. This product is equipped with a three-wire plug. This plug will fit only into a grounded power outlet. If you are unable to insert the plug into the outlet, contact your electrician to install the proper outlet. Do not defeat the safety purpose of the grounded plug. Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular attention to cords at doors, plugs, receptacles, and the point where they exit from the product. For added protection of this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable system. This will prevent damage to the product due to lightning and power line surges. Do not overload wall outlets, extension cords, or convenience receptacles on other equipment as this can result in a risk of fire or electric shock. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltages and other hazards. Refer all service to qualified service personnel. Unplug this product from the wall outlet and refer service to qualified service personnel under the following conditions:

Getting Started

Do not place combustibles behind the cooling fan. For example, cloth, paper, matches, aerosol cans or gas lighters that present special hazards when over heated. Do not look into the projection lens while the illumination lamp is turned on. Exposure of your eyes to the strong light can result in impaired eyesight. Do not look into the inside of this unit through vents (ventilation holes), etc. Do not look at the illumination lamp directly by opening the cabinet while the illumination lamp is turned on. The illumination lamp also contains ultraviolet rays and the light is so powerful that your eyesight can be impaired. Do not drop, hit, or damage the light-source lamp (lamp unit) in any way. It may cause the light-source lamp to break and lead to injuries. Do not use a damaged light source lamp. If the light-source lamp is broken, ask your dealer to repair it. Fragments from a broken light-source lamp may cause injuries. The light-source lamp used in this projector is a high pressure mercury lamp. Be careful when disposing of the light-source lamp. If anything is unclear, please consult your dealer. Do not ceiling-mount the projector to a place which tends to vibrate; otherwise, the attaching fixture of the projector could be broken by the vibration, possibly causing it to fall or overturn, which could lead to personal injury. Use only the accessory cord designed for this product to prevent shock. For health reasons, please take a break of about 5-15 minutes every 30-60 minutes and let your eyes rest. Please refrain from watching any 3D-images when you feel tired, unwell or if you feel any other discomfort. Moreover, in case you see a double image, please adjust the equipment and software for proper display. Please stop using the unit if the double image is still visible after adjustment. Once every three years, please perform an internal test. This unit is provided with replacement parts needed to maintain its function (such as cooling fans). Estimated replacement time of parts can vary greatly depending on frequency of use and the respective environment. For replacement, please consult your dealer, or the nearest authorized JVC service center. When fixing the unit to the ceiling, Please note that we do not take any responsibility, even during the warranty period, if the product is damaged due to use of metal fixtures used for fixation to the ceiling other than our own or if the installation environment of said metal fixtures is not appropriate. If the unit is suspended from the ceiling during use, please be careful in regard to the ambient temperature of the unit. If you use a central heating, the temperature close to the ceiling will be higher than normally expected. Video images can burn into the electronic com ponent parts. Please do not display screens with still images of high brightness or high contrast, such as found in video games and computer programs. Over a long period of time it might stick to the picture element. There is no problem with the playback of moving images, e.g. normal video footage.

Video images can burn into the electronic com ponent parts. Please do not display screens with still images of high brightness or high contrast, such as found in video games and computer programs. Over a long period of time it might stick to the picture element. There is no problem with the playback of moving images, e.g. normal video footage. Not using the unit for a long time can lead to malfunction. Please power it on and let it run occasionally. Please avoid using the unit in a room where cigarettes are smoked. It is impos sible to clean optical component parts if they are contaminated by nicotine or tar. This might lead to performance degradation. Please watch from a distance three times the height of the projected image size. Persons with photosensitivity, any kind of heart disease, or weak health should not use 3D glasses. Watching 3D-images might be cause of illness. If you feel any change in your physical condition, please stop watching immediately and consult a physician if necessary. When watching 3D images, it is recommended to take regular breaks. As the length and frequency of the required breaks differ for every person, please judge according to your own condition. If your child watches while wearing 3D glasses, it should be accompanied by its parents or an adult guardian. The adult guardian should be careful to avoid situations where the child’s eyes might become tired, as responses to tiredness and discomfort, etc., are hard to detect, and it is possible for the physical condition to deteriorate very quickly. As the visual sense is not yet fully developed in children under the age of 6, please consult a physician in regard to any problem concerning 3D-images if necessary. Note that when using the 3D feature, the video output may appear different from the original video image due to image conversion on the device.

* DO NOT allow any unqualified person to install the unit.

Be sure to ask your dealer to install the unit (e.g.attaching it to the ceiling) since special technical knowledge and skills are required for installation. If installation is performed by an unqualified person, it may cause personal injury or electrical shock.

Getting Started

Power cord

For European continent countries

For United Kingdom

Green-and-yellow Blue Brown

Fuse

: Earth : Neutral : Live

POWER CONNECTION

WARNING:

Do not cut off the main plug from this equipment.

The power supply voltage rating of this product is AC100V – AC240V. Use only the power cord designated by our dealer to ensure Safety and EMC. Ensure that the power cable used for the projector is the correct type for the AC outlet in your country. Consult your product dealer.

If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or adapter or consult your dealer. If nonetheless the mains plug is cut off, dispose of the plug immediately, to avoid a possible shock hazard by inadvertent connection to the main supply. If a new main plug has to be fitted, then follow the instruction given below.

Dear Customer,

This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of JVC KENWOOD Corporation is: JVC Technical Services Europe GmbH Konrad-Adenauer-Allee 1-11 61118 Bad Vilbel Germany

INFORMATION Manufacturer:

JVC KENWOOD Corporation 3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN

Importer (EU only):

JVC KENWOOD U.K. Limited 12 Priestley Way, London, NW2 7BA UNITED KINGDOM

For more details, please refer to our website. http://www.jvc.net/

THIS APPARATUS MUST BE EARTHED.

IMPORTANT (Europe only):

The wires in the mains lead on this product are colored Vert et jaune in accordance with the following cord:

IMPORTANT (Europe only):

POWER CONNECTION (United Kingdom only)

When replacing the fuse, be sure to use only a correctly rated approved type, re-fit the fuse cover.

IF IN DOUBT —— CONSULT A COMPETENT ELECTRICIAN.

Open the fuse compartment with the blade screwdriver, and replace the fuse. (* An example is shown in the illustration below.)

As these colors may not correspond with the colored making identifying the terminals in your plug, proceed as follows: The wire which is colored green-and-yellow must be connected to the terminal which is marked M with the letter E or the safety earth or colored green or green-and-yellow. The wire which is colored blue must be connected to the terminal which is marked with the letter N or colored black. The wire which is colored brown must be connected to the terminal which is marked with the letter L or colored red.

For USA and Canada only Use only the following power cord.

Getting Started

ENGLISH

Information for Users on Disposal of Old Equipment and Batteries

[European Union only]

These symbols indicate that equipment with these symbols should not be disposed of as general household waste. If you want to dispose of the product or battery, please consider the collection systems or facilities for appropriate recycling.

Notice:

The sign Pb below the symbol for batteries indicates that this battery contains lead.

Benutzerinformationen zur Entsorgung alter Geräte und Batterien

[Nur Europäische Union]

Diese Symbole zeigen an, dass derartig gekennzeichnete Geräte nicht als normaler Haushaltsabfall entsorgt werden dürfen. Wenden Sie sich zur Entsorgung des Produkts oder der Batterie an die hierfür vorgesehenen Sammelstellen oder Einrichtungen, damit eine fachgerechte Wiederverwertung möglich ist.

Hinweis:

Notification:

Das Zeichen Pb unterhalb des Batteriesymbols gibt an, dass diese Batterie Blei enthält.

Informations relatives à l’élimination des appareils et des piles usagés, à l’intention des utilisateurs

[Union européenne seulement]

Si ces symboles figurent sur les produits, cela signifie qu’ils ne doivent pas être jetés comme déchets ménagers. Si vous voulez jeter ce produit ou cette pile, veuillez considérer le système de collecte des déchets ou les centres de recyclage appropriés.

La symbole Pb en dessous du symbole des piles indique que cette pile contient du plomb.

Informatie voor gebruikers over het verwijderen van oude apparatuur en batterijen

[Alleen Europese Unie]

Deze symbolen geven aan dat appara tuur met dit symbool niet mag worden weggegooid als algemeen huishoudelijk afval. Als u het product of de batterij wilt weggooien, kun t u inzamelsystemen of faciliteiten voor een geschikte recycling gebruiken.

Opmerking:

Het teken Pb onder het batterijsymboo l geeft aan dat deze batterij lood bevat.

Battery

Products

Batterie

Produkte

Pile

Produits

Batterij

Producten

DEUTSCH

FRANÇAIS

NEDERLANDS

Información para los usuarios sobre la eliminación de baterías/pilas usadas

[Sólo Unión Europea]

Estos símbolos indican que el equipo con estos símbolos no debe desecharse con la basura doméstica. Si desea desechar el producto o batería/pila, acuda a los sistemas o centros de recogida para que los reciclen debidamente.

Atención: La indicación Pb debajo del símbolo de batería/pila indica que ésta

contiene plomo.

Baterías/pilas

Productos

ESPAÑOL / CASTELLANO

ITALIANO

Informazioni per gli utenti sullo smaltimento delle apparecchiature e batterie obsolete

[Solo per l’Unione Europea]

Questi simboli indicano che le apparecchiature a cui sono relativi non devono essere smaltite tra i rifiuti domestici generici. Se si desidera smaltire questo prodotto o questa batteria, prendere in considerazione i sistem i o le strutture di raccolta appropriati per il riciclaggio corretto.

Nota:

Il simbolo Pb sotto il simbolo delle batter ie indica che questa batteria contiene piombo.

Batteria

Prodotti

Getting Started

As with any bright light source, do not stare into the beam, RG2 IEC 62471-5:2015

Location information of the labels

Getting Started

Contents

Getting Started

Safety Precautions .................................................. 2

Accessories/Optional Accessories ..........................

Check the Accessories ........................................ 9

Optional Accessories ........................................... 9

Controls and Features ........................................... 10

Main Unit - Front ................................................ 10

Main Unit - Bottom ............................................. 10

Main Unit - Rear ................................................. 11

Main Unit - Input Terminals ................................ 12

Remote Control ................................................. 13

Loading Batteries into the Remote Control ........ 14

Effective Range of Remote Control Unit ............ 14

Set up

Installing the Projector ........................................... 15

Precautions during Installation ........................... 15

Precautions during Mounting ............................. 16

Adjusting the Position ........................................ 17

Connecting the Projector ....................................... 18

Connecting to the HDMI Input Terminal (Digital

Input) ................................................................. 18

Connecting to the LAN Terminal ........................ 19

Connecting to the RS-232C Terminal ................ 19

Connecting to the TRIGGER Terminal ............... 20

Connecting the Power Cord (Supplied Accessory)

Operate

Viewing Videos ...................................................... 21

Adjusting the Projector Screen .............................. 23

Adjusting the Lens According to the Projection

Position .............................................................. 23

Saving and Retrieving Adjustment Settings ....... 24

Setting Screen Correction .................................. 26

Adjusting the Screen Size (Aspect) ................... 27

Viewing 3D Movies ................................................ 28

Installing the 3D SYNCHRO EMITTER .............. 28

Viewing 3D Movies ............................................ 29

Adjusting 3D Movies .......................................... 29

Adjust/Set

Selecting an Image Quality According to the Video

Type ...................................................................... 30

Setting the Picture Mode ................................... 30

Setting the Color Profile ..................................... 31

Adjusting to the Preferred Color (Color

Management) .................................................... 33

Adjusting Movies for Increased Expressiveness

(Multiple Pixel Control) .......................................... 34

...... 20

Fine-tuning the Image Quality ............................... 36

Adjusting the Output Value of the Projected Image

(Gamma)

Fine-tuning to the Preferred Gamma Setting ..... 37

Reducing the After-image of Fast-moving Images (Blur Reduction)

Viewing High Contrast Images (Lens Aperture) . 40

Adjustments and Settings in the Menu .................. 41

List of Menu Items ............................................. 41

Picture Adjust .................................................... 43

Input Signal ........................................................ 46

Installation ......................................................... 48

Display Setup .................................................... 54

Function ............................................................. 54

Information ......................................................... 56

........................................................... 36

................................................. 39

Maintenance

Replacing the Lamp .............................................. 57

Lamp Replacement Procedure .......................... 57

Resetting the Lamp Time ................................... 59

Maintaining the Cabinet and Remote Control ........ 59

Cleaning and Replacing the Filter ......................... 60

Troubleshooting

Troubleshooting .................................................... 61

When the following messages appear... ................ 65

Others

External Control .................................................... 66

RS-232C Specifications ..................................... 66

TCP/IP Connection ............................................ 66

Command Format .............................................. 67

Remote Control Code ........................................ 68

Communications Example ................................. 69

Specifications ........................................................ 70

Index ..................................................................... 77

Symbols used in this manual

indicates a function that is supported by DLA-X950R.

indicates a function that is supported by DLA-X750R.

indicates a function that is supported by DLA-X550R.

Items not marked with any of the above symbols are supported by all models.

Accessories/Optional Accessories

Check the Accessories

Lens cover 6 .................................................................... 1 piece

* It is attached to the main unit at the time of shipment.

Remote control ....................................................................... 1 piece

Getting Started

AAA-size batteries (for operational check) ............................ 2 pieces

Power cord (for USA) (about. 2 m) ......................................... 1 piece

Power cord (for UK) (about. 2 m) ............................................ 1 piece

Power cord (for EU) (about. 2 m) ............................................ 1 piece

Quick User Guide, safety precautions, warranty card, and other printed material are also included.

Be sure to read the “Safety Precautions” before using this projector.

Optional Accessories

Replacement lamp: product no. PK-L2615U

3D GLASSES: model PK-AG3

3D SYNCHRO EMITTER: model PK-EM2

Compatibility Chart for 3D SYNCHRO EMITTER and 3D GLASSES

3D GLASSES

3D SYNCHRO EMITTER PK-EM1 *

(Communication

Method: IR (Infrared))

PK-EM2

(Communication

Method: RF (Radio

frequency))

* Discontinued product

Please check with your authorized dealer for details.

PK-AG1 *

(Communication

Method: IR (Infrared))

X X —

— — X

(Communication

Method: IR (Infrared))

PK-AG2 *

PK-AG3

(Communication

Method: RF (Radio

frequency))

Controls and Features

ABC

Getting Started

Main Unit - Front

Lens

This is a projection lens. Do not look through the lens while an image is projected.

Lens cover 4 5

The lens cover opens/closes when the power supply is turned on/off. (P. 48)

For 6, attach the lens cover when the unit is not in use.

Remote Sensor (front)

aim

Please it.

* There is also a remote sensor at the rear.

the

remote

at this area when using

control

Main Unit - Bottom

Indicator

Refer to “Indicator Display on the Main Unit”P. 74.

Exhaust vent

Warm air is discharged to cool down the internal temperature. Do not block the vents.

Inlets (at 3 points on the rear/bottom)

The inlets take in air to cool down the internal temperature. Do not block or prevent the outflow of hot air. Doing so may cause the unit to malfunction.

* There

are two inlets on

Manual button for lens cover 4 5

The lens cover can be opened when pressed down. It is used for maintenance purposes. You can also make use of it when you need to open the lens cover urgently.

Feet

The height and angle of the projector can be adjusted by turning the foot. (0 to 5 mm) (P. 17)

When the foot is removed, it can be used as the mounting holes for the ceiling mount bracket.

the right and left sides at the rear of the unit.

Main Unit - Rear

IKLM

[MENU]: Displays the menu

[BACK]: Returns to the previous menu

[JKH I] keys: Selects an item

[OK]: Confirms a selection

[INPUT]: Switches the input

A [STANDBY/ON]: Turns “on”/“off” the power

Getting Started

Input terminals

In addition to the video input terminal, there are also other connection terminals for devices such as controllers and optional equipment.

Please see more details about the terminals.

Lamp cover

When replacing the light source lamp, remove this cover.

Operation panel

For more details, please refer to the “Operation panel” in the diagram below.

“Main Unit - Input Terminals”P. 12 for

Operation panel

Remote Sensor (rear)

aim the

Please it.

* There is also a remote sensor at the front.

Power input terminal

Connect the supplied power cord to this terminal.

remote control at this area when using

Main Unit - Input Terminals

A B C

Enlarged View of Rear Face

Getting Started

[HDMI 1] input terminal

[HDMI 2] input terminal

For connecting to devices that support HDMI output. (P.

18)

It is fitted to the M3 lock hole. The depth of the screw hole is 3 mm.

[LAN] terminal (RJ-45)

The projector can be controlled by connecting it to a PC through the computer network for control commands to be sent to the projector.

[RS-232C] terminal (D-sub 9-pin male)

projector

The this terminal.

[3D SYNCHRO] terminal

By connecting a 3D SYNCHRO EMITTER (sold separately) to this terminal, you can view 3D movies.

controlled by connecting a PC to

can

[TRIGGER] terminal (E)

terminal for DC 12 V, 100 mA power supply. It

Output is used for sending output signals to control devices such as an elevating screen that is equipped with a trigger function.

Note that improper connection may damage the projector. (Tip=DC +12 V, Sleeve=GND)

Remote Control

HDMI 1

INPUT

LENS MEMORY

PICTURE MODE

HDMI 2 INFO.

FILM CINEMA ANIME.

NATURAL

THX USER

MEMORY

MEMORY1 MEMORY2

ADVANCED

FORMAT

PIC.

ADJ.

COLOR

TEMP.

GAMMA

P.ANALYZER

MPC

LENS

CONTROL

LENS AP.

C.M.D.

PICTURE MODE

CINEMA ANIME.

NATURAL

USER1 USER2 USER3

W X

F G

M N O

Getting Started

B [STAND BY]

Turns off the power. (

C [ON]

Turns on the power. (

[INPUT]

Select an input from [HDMI 1] and [HDMI 2]. (P. 21)

[INFO.]

Displays the information menu. (P. 56)

[MEMORY MENU]

Switches between saving, retrieving, and editing of the lens memory. (P. 24)

[MEMORY 1]

Retrieves LENS MEMORY 1.

[MEMORY 2]

Retrieves LENS MEMORY 2.

[LENS CONTROL]

For adjusting focus, zoom, and shift. (P. 23)

[LENS AP.]

For setting the lens aperture. (P. 40)

[C.M.D.]

For setting frame interpolation. (P. 39)

[HIDE]

Hides the image temporarily. (P. 21)

[LIGHT]

Illuminates the buttons on the remote control.

[JKH I] keys

For selecting an item.

[OK]

Confirms a selected item.

P. 22)

P. 21)

[MENU]

Displays the menu, or hides the menu if it is displayed.

[BACK]

Returns to the previous menu.

[PICTURE MODE]

Switches the Picture mode to [FILM]*1, [CINEMA], [ANIME.], [NATURAL], [THX]*1, or [USER]*2. (

*1 4 5 only

*2 [USER1], [USER2] and

[USER3] are available for

[ADVANCED MENU]

Pressing the button each time switches the menu in the following sequence: “Picture Mode” " “Color Profile” " “Color Temp.” " “Gamma”

[MPC]

For setting the MPC level. (P. 34)

[P.ANALYZER]

Turns on/off the analysis screen. (P. 35)

[GAMMA]

For setting the gamma level. (P. 36)

[COLOR TEMP.]

For setting the color temperature. (P. 44)

[3D FORMAT]

Switches the 3D format. (P. 29)

[PIC. ADJ.]

Switches the items for adjusting the image quality, such as contrast, brightness, etc. (P. 45)

P. 30)

Loading Batteries into the Remote Control

30°

20°

Remote Control

This unit

30°

20°

Screen

Remote Control

This unit

Getting Started

Loading the batteries

If the remote control has to be brought closer to the projector to operate, it means that the batteries are wearing out. Replace the batteries with new ones (AAA).

Insert the batteries according to the t s marks. Be sure to insert the s end first. When removing the battery, do so from the t end.

If an error occurs while using the remote control, remove the batteries and wait for five minutes. Load the batteries again and operate the remote control.

Removing the batteries

Effective Range of Remote Control Unit

When aiming the remote control toward the sensor on this

(front or rear), ensure

unit

that the distance to the sensor is within 7 m. If the remote control fails to work properly, move closer to this unit.

Control through reflection off a screen, etc.

Ensure that the total of distance A (between this unit and the screen) and distance B (between the remote control and the screen) is within 7 m.

CAUTION

Do not put the remote control in a place with an exposure to direct sun light or high temperature. It may deformed due to heat, or the internal components may be adversely affected resulting in fire hazard.

Remove the batteries from the remote control when storing the remote control. Storing the remote control for a prolonged period without removing the batteries can cause battery leakage.

As the efficiency of signals reflected from the remote

control unit varies with the type of screen used, the operable distance may decrease.

CAUTION

Remove the batteries from the remote control when storing the remote control. Storing the remote control for a prolonged period without removing the batteries can cause battery leakage.

Installing the Projector

Front

150 mm and above

200 mm and above

300 mm and above

150 mm and above

5° 5°

15°

Screen

Front

Precautions during Installation

Please read the following carefully before installing this unit.

Do not install at the following

This unit is a precision device. Please refrain from installing or using it at

the following locations. Otherwise,

it may cause fire or malfunction.

Dusty, wet and humid places

Places subject to oily smoke or cigarette smoke

On top of a carpet or bedding, or other soft surfaces

Places exposed to direct sunlight

Places with a high or low temperature

Do not install this unit in a room that is oily or subject

cigarette smoke. Even a

small quantity of smoke or

oiliness can have a long-term impact on this unit.

* This unit produces a great amount of heat, and is

designed to take in cool air to cool its optical components. Using the unit at the above locations may cause dirt to attach to the light path, thereby resulting in dark images or dull colors.

* Dirt that sticks to the optical components cannot be

removed.

Maintain clearance from the wall, etc.

As the unit discharges a large amount of heat, install it with adequate clearance from the surroundings as shown below.

Using the projector

This unit uses a projection in use. Please refrain from projecting in the following circumstances. Otherwise, it may cause fire or malfunction.

Projection with the unit stood vertically

Projection with the unit inclined at an angle

Horizontal inclination: within ± 5 °

Vertical inclination: within ± 15 °

Malfunction may occur if the abovementioned range.

lamp, which will heat up when

angle is not set within the

Set up

Leave the front area of the unit unblocked. If there is any obstructing object in front of the exhaust vent, hot air will flow back to the unit and cause it to heat up. Hot air flowing out of the unit may cast shadows on the screen (heat haze phenomenon).

Installing the screen

Install the unit and the screen such that they are perpendicular to each other.

Please choose a screen material with non-uniform patterns. Uniform patterns such as

checks may cause

interference patterns to occur.

In this case, you can

change the size of the screen to

make the interference patterns less noticeable.

Using the projector at a high altitude

When using this unit at a location that is higher than 900 m above sea level (low air pressure), set the “High Altitude Mode” to “On”. (P. 50)

Precautions during Mounting

Air Inlets

4 Locations

Securing (mounting) the projector

Set up

When this unit is to

be mounted to a fixed position for

use, install it horizontally.

Make sure to secure the main unit to prevent accidents such as during an earthquake.

Securing with screws

Securing the projector (ceiling mount)

Be sure to ask your dealer to install the unit for you. Installing the unit on your own may cause the unit to fall resulting in injury.

Take the necessary actions to prevent the main unit from falling off such as during an earthquake.

Regardless of the warranty period, JVC is not liable

any product damage caused

for with non-JVC ceiling fittings or to an environment that is not suited for ceiling mount.

When using the unit with it suspended from a ceiling, pay attention to the surrounding temperature. When a heater is in use, the temperature around the ceiling may be higher than expected.

attach the unit to

the ceiling mount bracket, set the torque between the range of 1.5N m to 2.0N m. Tightening with torque exceeding the above range may cause damage to the unit, which may result the unit to fall.

Install the outlet at an

accessible height to unplug from the wall. Or install the circuit breaker at an accessible height to shut down the projector. If you need information, please consult your authorized dealer or specialist.

by mounting the unit

Remove the four feet at the bottom, and fasten using the screws (M5 screws, 13 to 23 mm).

* Using screws other than those

designated may cause

the unit to break down.

* Leave a clearance of at least 10 mm from the bottom

surface of the unit to allow it to take in cool air.

Adjusting the Position

ContractExtend

Feet

0 10 3020 40

Lens movement range

Horizontal lens shift (%)

Vertical lens shift (%)

Lens shift Range

Up to about 80% of the projected image

Horizontal Position: 0 % (Center)

Vertical Position

Up to about 34% of the projected image

Vertical Position: 0% (Center)

Horizontal Position

■

Adjusting the elevation angle of the projector

The height and inclination of the unit (0 to 5 mm) can be adjusted by turning the feet. Lift the unit and adjust the four feet.

Adjusting the position of the image

By using the lens shift feature of this unit, you can shift the image upward/downward or to the left/right. Set it to your preferred position.

Æ “Adjusting the Lens According to the Projection Position” (P. 23)

Set up

The maximum vertical shift varies with the amount of horizontal shift. Similarly, the maximum horizontal shift also changes with the amount of vertical shift.

The

values

the

are intended as a guide. Use

graph

them for reference during installation.

Connecting the Projector

HDMI Output Terminal

BD/DVD Recorder, etc.

Laptop, etc.

HDMI Cable (Sold Separately)

This Unit

To [HDMI 1] or [HDMI 2] input terminal

HDMI Cable

(Sold Separately)

BD/DVD Recorder, etc.

HDMI Cable (Sold Separately)

This Unit

To [HDMI 1] or [HDMI 2] input terminal

Speaker Cable (Sold Separately)

Speakers

AV Amplifier

Do not turn on the power until connection is complete.

The connection procedures differ according to the device used. For details, please refer to the instruction manual of the device to be connected.

This projector is used for projecting images. To output the audio of connected devices, please connect a separate audio output device, such as an amplifier or speaker.

The images may not be displayed depending on the devices and cables to be connected. A high speed HDMI cable (sold separately) that is HDMI-certified is recommended. When using a standard cable, you are recommended to set the resolution of the equipment transmitting the video to 1080i or lower.

Set up

Also, please refer to

Some cables cannot be connected to this unit due to the size of their connector cover.

Connecting to the HDMI Input Terminal (Digital Input)

Connecting via HDMI cable

“HDMI2 EDID”P. 47.

If noise occurs, move the laptop away from this unit.

Connecting through an AV amplifier

If the source device is

connected to the projector through an intermediate device such as an AV amplifier or divider, the video image may not appear depending on the specifications of the intermediate device. In this case, connect the source device directly to the projector, and check whether the video image is displayed.

Connecting via HDMI-DVI conversion cable



HDMI-DVI Conversion Cable (Sold Separately)

To [HDMI 1] or [HDMI 2] input terminal

This Unit

DVI Output Terminal

Desktop PC, etc.

Server

Hub

Network

Connection Cable (Sold Separately)

This Unit

To [LAN] Terminal

RS-232C Terminal

Laptop, etc.

RS-232C Connection Cable (Sold Separately)

To [RS-232C] Terminal

This Unit

If noise occurs, move the desktop PC away from this unit.

If the video is not displayed, try to reduce the length of the cable or lower the resolution of the video transmitting equipment.

Connecting to the LAN Terminal

Set up

The network is used to control this unit. It is not used for sending or receiving video signals.

Please contact your network administrator for information concerning the network connection.

Set “ECO Mode” to “Off” if LAN communication is performed in the Standby mode. (

For more information on control, please refer to [@TREX“External Control”P. 66.

P. 55)

Connecting to the RS-232C Terminal

Set “ECO Mode” to “Off” if RS-232C communication is performed in the Standby mode. (P. 55)

For more information on control, please refer to [@TREX“External Control”P. 66.

Connecting to the TRIGGER Terminal

Trigger Input Terminal (Ø3.5)

Screen

Trigger Cable (Sold Separately)

To [TRIGGER] Terminal

This Unit

Power Cord (Supplied)

Set up

Do not use it to supply power to other devices.

Connecting to the audio terminal of another device may cause the device to malfunction or break down.

Using beyond the rated value will cause the unit to malfunction.

The trigger terminal outputs a voltage of 12 V. Exercise adequate caution to prevent short circuit.

The factory setting is “Off”. To change the setting, configure the “Trigger” item in the menu (

Connecting the Power Cord (Supplied Accessory)

P. 54).

Connect

the power cord supplied

to the power input terminal on

the main unit

Insert the supplied power plug into the wall outlet.

Precautions to prevent fire and electric shock

The power consumption of this unit is large. Please connect it directly to the wall outlet.

When you are not using the projector, please unplug the power cord from the outlet.

Connect it using only the power cord supplied.

Do not use a voltage other than the indicated power voltage.

Do not damage, break or modify the power cord. Do not place a heavy object on the power cord, or heat or pull it. Doing so may damage the power cord.

Do not unplug the power cord with wet hands.

Viewing Videos

LAMP WARNING

STANDBY/ON

LAMP WARNING

STANDBY/ON

During lamp startup

“STANDBY/ON” lights up (green)

In standby state

“STANDBY/ON” lights up (red)

LAMP WARNING

STANDBY/ON

HDMI 1

INPUT

LENS MEMORY

HDMI 2 INFO.

MEMORY

MEMORY1 MEMORY2

1 3

This unit

Remote Control

MEMO

When you are using 6, be sure to remove the lens cover.

Connect the power cord, and ensure that the “STANDBY/ON” indicator lights up in red.

Turn on the power

Remote control: press the C [ON] button Projector unit: press the A [STANDBY/ON] button

The “STANDBY/ON” indicator light switches goes off after the unit starts up).

(4 5) The lens cover opens.

Choose the image to project

Remote control: press the [HDMI 1] or [HDMI 2] button

Projector unit: press the [INPUT] button to switch the input

Play back the selected device to project the image.

To hide the image temporarily

Press the [HIDE] button on the projector unit or remote control

The “STANDBY/ON” indicator light starts to blink in green.

Press the [HIDE] button again to resume display of the image.

The power cannot be turned off when the image is temporarily hidden.

from red to green (light

Operate

LAMP WARNING

STANDBY/ON

LAMP

WARNING

STANDBY/ON

In standby state

“STANDBY/ON” lights up (red)

In the Cool-down mode

“STANDBY/ON” blinking (red)

Turn off the power

Remote control: press the B [STAND BY] button Projector unit: press the A [STANDBY/ON] button

While the “Are you sure you want to turn off?” message is displayed, press the button again.

The lamp turns off, and the “STANDBY/ON” indicator switches from a green light to a red blinking light.

After the light goes off, the fan will run for about 100 seconds to cool down the lamp (Cool-down mode). Do not disconnect the power cable while cooling is in progress.

After about 100 seconds, the “STANDBY/ON” indicator switches from a blinking red to a solid red light.

For 6, attach the lens cover manually.

For 4 5, the lens cover closes upon power off.

Operate

CAUTION

The power cannot be turned off within approximately 60 seconds after it has been turned on.

The power cannot be turned on again while cooling is in progress (100 seconds).

Pull out the power plug when the unit is not to be used for a prolonged period of time.

the indication of indicator

differs from the description, refer to “Indicator Display on the Main Unit”P. 74 for details.

Adjusting the Projector Screen

Focus

Shift (Screen Position)

Adjustment

Zoom (Screen Size)

Adjustment

ABCD

Focus Adjustment

HDMI 1

INPUT

LENS MEMORY

PICTURE MODE

HDMI 2 INFO.

FILM CINEMA ANIME.

NATURAL

THX USER

MEMORY

MEMORY1 MEMORY2

ADVANCED

FORMAT

PIC.

ADJ.

COLOR TEMP.

GAMMA

P.ANALYZER

MPC

LENS

CONTROL

LENS AP.

C.M.D.

Adjusting the Lens According to the Projection Position

Press the [LENS CONTROL] button, and use the [JKH I]

to adjust Focus, Zoom

keys

(screen size), and Shift (screen

position)

Pressing the [LENS CONTROL] or [OK] button each time switches the mode

in the following sequence: “Focus” " “Zoom” " “Shift” " “Focus”...

Operation of the lens control feature is disabled when the lens lock is set to “On”.

For more detailed information, please refer to “Lens Control”P. 48.

Operate

Press the [MENU] button once, or the [BACK] twice, to end

adjustment.

Saving and Retrieving Adjustment Settings

MEMORY

BACK

-----

Back

Operate

Select

Exit

Lens Memory Save

Installation

HDMI 1

INPUT

LENS MEMORY

PICTURE MODE

HDMI 2 INFO.

FILM CINEMA ANIME.

NATURAL

THX USER

MEMORY

MEMORY1 MEMORY2

ADVANCED

FORMAT

PIC.

ADJ.

COLOR TEMP.

GAMMA

P.ANALYZER

MPC

LENS

CONTROL

LENS AP.

C.M.D.

The Focus, Zoom, and Shift settings can be saved or retrieved, so you can switch easily to a different aspect ratio (screen size) according to the image.

In a state where no adjustment settings are saved (factory default), only “Lens Memory Save” is displayed.

Operate

Operation

Saving an adjustment data

Adjust focus, zoom, or shift (P. 23)

Press the [MEMORY MENU] button to display “Lens

Memory Save”

lens

the

You can also save an adjustment data by selecting “Installation”"“Lens

control

Control”"“Lens Memory Save” from the menu.

feature is disabled when the lens lock is set to “On”.

Select the item to save, and press the [OK] button

The adjustment data is saved.

Items with no adjustment data saved are displayed as [----].

you have selected an

item for which an adjustment data has already been

saved, the old data will be overwritten.

You can change the name when saving an item. (P. 25)

The maximum number

of items

can be saved is 10 for 4 5 and 5 for

Press the [MENU] button to exit

Retrieving an adjustment data

BACK

-----

MEMORY2

-----

MEMORY1

MEMORY

Back

Operate

Select

Exit

Lens Memory Select

Installation

BACK

-----

MEMORY2

-----

MEMORY1

MEMORY

Lens Memory Name Edit

Back

Operate

Select

Exit

Installation

MEMORY1

}

{

]

[

)

(

;

SPACE

OKAll ClearClear

Name

Character List

Selection Cursor

Input Cursor

BACK

Back

Operate

Select

Exit

Lens Memory Name Edit

Installation

Press the [MEMORY MENU] button to display “Lens Memory Select”

You can also retrieve an adjustment data by selecting “Installation”"“Lens Control”"“Lens Memory Select” from the menu.

MEMORY1 and 2 can also be retrieved using the direct keys on the remote control.

Select the adjustment data to retrieve, and press the [OK] button

The retrieved data is adjusted automatically.

If no adjustment data has been saved, the item will be grayed out and cannot be selected.

Renaming an adjustment data

Press the [MEMORY MENU] button to display “Lens Memory Name Edit”

You can also edit an adjustment data by selecting “Installation”"“Lens Control”"“Lens Memory Name Edit” from the menu.

Operate

Select the adjustment data to edit, and press the [OK] button

An edit screen appears.

You can input up to 10 characters.

Characters that are usable include alphabets (upper or lower case), numeric characters, and symbols.

Pressing the [Back] button cancels the content that is currently being edited, and exits the edit mode.

After renaming, select “OK” and press the [OK] button

Press the [MENU] button to exit

Setting Screen Correction

BACK

3 21

Back

Operate

Select

Exit

Off

Front

Screen No.

Screen Adjust

High Altitude Mode

Anamorphic

Keystone

Installation Style

Pixel Adjust

Lens Control

Installation

Set Screen Adjust

By selecting the optimal correction mode according to the characteristics of the screen in use, corrections can be performed to reproduce natural images with balanced colors.

Operate

This item is not available set to “Off”.

For information on the screen and the corresponding correction mode, please visit website.

http://www3.jvckenwood.com/english/projector/screen/

when “Color Profile” is

our

MEMO

You can utilize the optional optical sensor and dedicated projector calibration software to adjustments. For details on the dedicated projector calibration software, please visit our website.

http://www3.jvckenwood.com/english/download/ index.html

make finer

Adjusting the Screen Size (Aspect)

BACK

Auto

16:9

Auto

Picture Position

3D Setting

Progressive

Mask

Aspect

Color Space

Input Level

Input Signal

Auto

HDMI2 EDID

Back

Operate

Select

Exit

Zoom

16:9

4:3

2.35:1

(Cinema

Scope)

Setting

Input Image

Output Image

1280×1024

Full

Just

Auto

Setting

Output Image

Input Image

The screen size of the projected image can be adjusted optimally according to the original screen size (aspect) that has been input.

Press the [MENU] button to display

the menu

Select “Input Signal”"“Aspect” from

the menu

Setting Description

4:3 Sets the screen size to 4:3. For

HD signals, the two sides are reduced.

16:9 Sets the screen size to 16:9.

For SD signals, the two sides are expanded.

Zoom Enlarges the entire image.

* Not selectable in the case

HD signals.

Auto Positions the image at the

center with the entire image enlarged.

Just Displays the input image in the

actual size.

Full Fills the entire screen with the

image with the size (aspect) the input image ignored.

This item is grayed out and cannot be adjusted when there is no signal, signal is out of range, or during 3D or 4K input.

Displayed only during video signal input.

Displayed only during PC signal input.

Example of input image and screen size

HDMI Signal Input

PC Signal Input

Operate

Press the [MENU] button to exit

Viewing 3D Movies

3D GLASSES

3D SYNCHRO EMITTER PK-EM2

This Unit

PK-AG3

By using the 3D GLASSES (PK-AG1, PK-AG2, or PK-AG3) and 3D SYNCHRO EMITTER (PK-EM1 or PK-EM2), both sold separately, you can enjoy 3D video images.

For 3D GLASSES and 3D SYNCHRO EMITTER that are compatible with this unit, please refer to Accessories”P. 9.

Installing the 3D SYNCHRO EMITTER

Connect 3D SYNCHRO EMITTER to the [3D SYNCHRO] terminal on the main unit

Installation Example

Operate

“Optional

CAUTION

If PK-EM1 is used, adjust the position of the 3D SYNCHRO EMITTER such that the 3D GLASSES can receive the signal from the 3D SYNCHRO EMITTER. For more details, please refer to the instruction manual of PK-EM1.

Viewing 3D Movies

PICTURE MODE

FILM CINEMA ANIME.

NATURAL

THX USER

ADVANCED

FORMAT

PIC. ADJ.

COLOR

TEMP.

GAMMA

P.ANALYZER

MPC

FORMAT

Connect this unit to a 3D-compatible

HDMI device, and turn on the power to play back the 3D video image

details on how to

For please refer to the instruction manual of the player or recorder in use.

When 3D signals are received, switches automatically to the 3D format.

This unit supports the following 3D formats.

- Frame packing

- Side-by-side

- Top-and-bottom

the default setting, “3D

In for automatic projection of 3D images.

If the image does not switch to 3D automatically

Select “3D Format”

Pressing the [3D FORMAT] button each time switches the mode in the following sequence: “Auto” " “Side by Side” " “Top and Bottom” " “2D” " “Auto”...

You can also perform setting from “Input Signal”"“3D Setting”"“3D Format” in the menu.

play back 3D video images,

the video image

Format” is set to “Auto”

Format Description

Auto The format is detected and

configured automatically.

Side by Side Select this setting if the 3D input

signal is of the side-by-side format.

Top and Bottom Select this setting if the 3D input

signal is of the top-and-bottom format.

2D Select this setting if 2D images

are falsely recognized as 3D ones.

* If a signal cannot be displayed as 3D image,

selecting the format does not switch the signal to a 3D image. For more information on possible input signals, please refer to (“Types of Possible Input Signals”P. 73).

Turn of the power of the 3D GLASSES

and put them on

The PK-AG1 powers on automatically.

Operate

Adjusting 3D Movies

3D video images may appear differently to different viewers. It may also be affected by your physical condition at the time of viewing. You are therefore recommended to adjust the video images accordingly.

Select “Input Signal”"“3D Setting”

from the menu

Adjusting parallax (Parallax)

Adjust the displacement of the image for the left and right eyes separately to obtain the best 3D effect.

To do so, use the H I keys to move the cursor.

Setting range: -15 to +15

Adjusting crosstalk (Crosstalk Cancel)

Double images (overlapping of the left image with the one on the right or vice versa) can be reduced to deliver a clear quality.

To do so, use the H I keys to move the cursor.

Setting range: -8 to +8

Press the [MENU] button to exit

Selecting an Image Quality According to the

HDMI 1

INPUT

LENS MEMORY

PICTURE MODE

HDMI 2 INFO.

FILM CINEMA ANIME.

NATURAL

THX USER

MEMORY

MEMORY1 MEMORY2

ADVANCED

FORMAT

PIC.

ADJ.

COLOR TEMP.

GAMMA

P.ANALYZER

MPC

LENS

CONTROL

LENS AP.

C.M.D.

Video Type

Setting the Picture Mode

You can adjust the image quality according to the type of video image you are viewing.

Press the [PICTURE MODE] button to select “Picture

Mode”

You can also perform setting from “Picture Adjust”"“Picture Mode” in the menu.

Item Description

Adjust/Set

Film*1 4 5

Cinema*1 Reproduces the image in vivid colors. Suitable for all

Animation*1 Suitable for animated works.

Natural*1

THX*1 4 5 Image quality certified by THX.

User 1 to User 6 *2 *3 Enables user-defined image quality data to be saved and

*1 For Picture modes with the *1 mark, the optimal settings for 2D and 3D signals

are stored separately and applied

Edited settings will also be saved separately.

No changes will be made to the Picture mode name.

*2 For 6, “User 4” to “User

button. Configure the setting using “Picture Adjust”"“Picture Mode” in the menu.

*3 To view videos that support the x.v.Color format, select a user setting (“User 1”

to “User 6”) in “Picture Mode”, and set “Color Profile” to “x.v.Color”.

Reproduces faithfully the texture of movie films.

movies.

Image quality that focuses on natural color and gradation reproduction. Suitable for drama footage, etc.

retrieved.

automatically according to the selected mode.

6” cannot be configured from the [PICTURE MODE]

Setting the Color Profile

By setting the “Color Profile” (color space information) according to the “Picture Mode”, you can fine-tune the image quality according to the movie you are viewing.

Configure “Picture Mode” (P. 30), then select “Picture Adjust”"“Color Profile” in the

The selectable “Color Profile” settings vary according to the “Picture Mode” and also whether the signal is 2D or 3D.

List of “Color Profile” for “Picture Mode” 6

Picture Mode 2D Signal Input 3D Signal Input Description

Cinema Cinema

Standard Standard Color space of the HDTV standard. *1

—

Animation Animation

Standard Standard Color space of the HDTV standard. *1

—

Natural Video

Standard Standard Color space of the HDTV standard. *1

—

User 1 to User 6 Standard When “Picture Mode” is set to any of the settings from “User 1” to “User

Cinema

Video

Natural

3D Cinema

3D Video

3D Animation

x.v.Color*2*3 Color space that is close to that of the x.v.Color standard.

Off Disables color space adjustment.

BT.2020 Color space that is suitable for BT.2020. *4

Custom 2 to Custom 6 Saves the auto calibration values.

*1 HDTV is the abbreviation for High Definition Television. *2 To view videos that support the x.v.Color format, select a user setting (“User 1” to “User 6”) in “Picture Mode”,

and set “Color Profile” to “x.v.Color”.

x.v.Color is a wide color space standard for used in videos; it includes wider color gamut than the HDTV standard.

*4 Depending on the version of the image quality data (P. 56), “Custom 1” instead of “BT.2020” is displayed. In

this case, you can set an optimum color profile for the BT.2020 color gamut using the import function of the projector calibration software. For more details, refer to http://www3.jvckenwood.com/english/download/dlax950r_x750r_x550r_x9000_x7000_x5000_xc7890r_xc6890r_xc5890r_rs600_rs500_rs400_uhd.html.

—

3D Cinema Color space suitable for all 3D movies.

—

3D Animation Color space suitable for 3D animation works.

—

3D Video Color space suitable for 3D broadcasts.

Color space suitable for all movies.

Color space that is suitable for animated works.

Color space that is suitable for drama footage, etc.

6”, you can select one of the “Color Profile” shown on the left.

See above for the description of the respective “Color Profile”.

To perform auto calibration, you need to get ready a commercially available optical sensor and the projector calibration software program. For more details, please refer to our website.

Adjust/Set

List of “Color Profile” for “Picture Mode” 4 5

Picture Mode 2D Signal Input 3D Signal Input Description

Film Film 1

Film 2

Film 3

—

Cinema Cinema 1 3D Cinema Original JVC cinema-specific color gamut that achieves a balance between increased

Cinema 2

Standard Standard Color space of the HDTV standard. *2

—

Animation Anime 1 3D Animation Color space that is suitable for CG animation works. Ideal for animated works with

Anime 2

Standard Standard Color space of the HDTV standard. *2

—

Natural Video 3D Video Color space that is suitable for drama footage, etc. making use of the increased

Standard Standard Color space of the HDTV standard. *2

Reference

—

Adjust/Set

THX THX*3 3D THX*3 Color space of the THX standard.

User 1 to User 6 Standard When “Picture Mode” is set to any of the settings from “User 1” to “User 6”, you can

Cinema 1

Cinema 2

Anime 1

Anime 2

Video

Reference

3D Cinema

3D Video

3D Animation

x.v.Color*4*5 Color space of the x.v.Color standard.

Off Disables color space adjustment.

BT.2020 Color space that is suitable for BT.2020. *6

Custom 2 to Custom 6 Saves the auto calibration values.

*1 The value is fixed during 3D signal input, and selection cannot be made. *2 HDTV is the abbreviation for High Definition Television.

Color Profile is fixed when “THX” is selected as the “Picture Mode”.

*3 *4 To view videos that support the x.v.Color format, select a user setting (“User 1” to “User 6”) in “Picture Mode”,

and set “Color Profile” to “x.v.Color”. *5 x.v.Color is a wide color space standard for used in videos; it includes wider color gamut than the HDTV standard. *6 Depending on the version of the image quality data (P. 56), “Custom 1” instead of “BT.2020” is displayed. In

this case, you can set an optimum color profile for the BT.2020 color gamut using the import function of the

projector calibration software. For more details, refer to http://www3.jvckenwood.com/english/download/dla-

x950r_x750r_x550r_x9000_x7000_x5000_xc7890r_xc6890r_xc5890r_rs600_rs500_rs400_uhd.html.

—

3D Film*1 Color space suitable for 3D movies recorded in film.

—

3D Cinema Color space suitable for all 3D movies.

—

3D Animation Color space suitable for 3D animation works.

—

3D Video Color space suitable for 3D video materials.

Color space that is close to the characteristics of Eastman Kodak Company movie films.

Color space that is close to the characteristics of FUJIFILM Corporation movie films.

Color space suitable for digitally remastered piece of art based on a Technicolor film.

brightness and color vividness.

Color space that is close to that of the DCI standard.

bright colors.

Color space that is suitable for cel animation works. Ideal for animated works with light colors.

brightness.

Color space that faithfully reproduces the video as it is.

select one of the “Color Profile” shown on the left.

See above for the description of the respective “Color Profile”.

To perform auto calibration, you need to get ready a commercially available optical sensor and the projector calibration software program. For more details, please refer to our website.

Adjusting to the Preferred Color (Color Management)

BACK

Back

Operate

Select

Exit

Red

Film 1

Before

Brightness

Saturation

Hue

Axis Position

Color Selection

Color Management

Color Profile

Picture Adjust

Color Profile

Reset

Off

BACK

MagentaBlue

Cyan

Green Yellow

Red

Clockwise rotation: -

Counterclockwise rotation: +

Axis Position (Image)

Adjustable range when Red is selected: ± 30° with Red as the center

Back

Operate

Select

Exit

Red

Film 1

Before

Reset

Brightness

Saturation

Hue

Axis Position

Color Selection

Color Management

Color Profile

Picture Adjust

Color Profile

Based on the setting of the selected “Color Profile”, you can adjust each of the following colors according to your preference: Red, Yellow, Green, Cyan, Blue, and Magenta.

Press the [ADVANCED MENU] button to display the “Color Profile” menu

Set “Color Management” to “On”, and press the [OK]

button

You can also perform setting Management” in the menu.

Adjust to the preferred color.

Select “Color Selection”, and press the H I keys to select the color to adjust

For color adjustment, select the color from the following:

“Red”, “Yellow”, “Green”, “Cyan”, “Blue”,

“Magenta”.

Adjust the selected color

from “Picture Adjust”"“Color Profile”"“Color

Item

Axis Position -30 to 30 Fine-tune the position

Hue -30 to 30 Adjusts the hue (color

Saturation -30 to 30 Adjusts the color

Brightness -30 to 30 Adjusts the

Selecting “Reset” resets all the adjustment data.

Pressing enables you to check the image before adjustment.

Press the [MENU] button to exit

Setting Range

the [HIDE] button on

Description

of the central axis of the selected color.

tone).

saturation (vividness).

-30 (dull) to +30 (vivid)

brightness.

-30 (dark) to +30 (bright)

the remote control

Adjust/Set

Adjusting Movies for Increased

BACK

PICTURE MODE

FILM CINEMA ANIME.

NATURAL

THX USER

ADVANCED

FORMAT

PIC. ADJ.

COLOR TEMP.

GAMMA

P.A N A LY Z E R

MPC

Back

Operate

Select

Exit

Auto

Before Reset

Smoothing

Dynamic Contrast

Enhance

Original Resolution

4K e-shift

MPC Level

Picture Adjust

Expressiveness (Multiple Pixel Control)

The new image-processing algorithm developed by JVC helps to create a natural impression that is sharper at areas in focus, and softer at areas that are not in focus, enabling you to enjoy highly expressive 4K images with a greater sense of depth.

Press the [MPC] button to display the

adjustment menu

You can also perform setting from “Picture Adjust”"“MPC Level” in the menu.

Adjust/Set

Make adjustments according to your

preference based on the setting

selected “Picture Mode”

* The factory setting varies with the “Picture

Mode”.

of the

In the default “Original Resolution”

setting (“Auto”), the

resolution is set automatically.

By increasing the setting range, you can expect enhanced effects.

Images are displayed in the original resolution (2K) when “4K e-shift” is set to “Off”.

“Original and

Resolution”, “Enhance”, “Dynamic Contrast”,

“NR” can be adjusted even when “4K e-shift” is set

to “Off”.

“4K e-shift” is fixed at “On” during 4K signal input.

“Original Resolution” is fixed at “Auto” during 4K

signal input. “Dynamic Contrast”,

50/60p

“Smoothing”

and “NR” are grayed out.

“4K e-shift” is fixed at “Off” during 3D signal input.

Press the [MENU] button to exit

Toggling between the States before and during Adjustment

Pressing the [HIDE] button on you to toggle between the states before adjustment and during adjustment.

the remote control enables

Item Setting Description

4K e-shift On (4K)/Off

(2K)

Original Resolution

Auto/4K/ 1080p

Switches the display resolution.

For selecting a resolution for the content you are viewing.

Enhance* 0 to 10 Enhances the sharpness of

the image.

Dynamic Contrast

0 to 10 Enhances the contrast of the

image.

Smoothing 0 to 10 Enhances the blurriness of

the image for a softer effect.

NR 0 to 10 For reducing the noise of the

video image.

* In the case of 4K 50/60p and other input signals, the

respective setting values are saved.

About the analysis screen

Low High

Red Yellow Green Cyan

Blue

Frequency

Purple

Pressing the [P.ANALYZER] button on the remote control displays the analysis screen. The operation varies with the state of the OSD.

The analysis screen is not displayed during 4K 50/60p signal input.

Press the [P.ANALYZER] button

The frequency components of the input image are displayed.

The frequency components are distinguished using different colors.

When setting the “Original Resolution” manually, select “4K” if high-frequency components constitute the majority, and a lower resolution if there are more low-frequency components.

Make adjustments while looking at the analysis screen

Press the [MPC] button to display the adjustment menu

You can also perform setting from “Picture Adjust”"“MPC Level” in the menu.

Make adjustments according to your preference based on the setting of the selected “Picture Mode”*

With “Enhance” selected, pressing the [P.ANALYZER] button displays the analysis screen and the area where the “Enhance” effect is applied appears in “cyan” color.

“Dynamic Contrast” selected, pressing

With area where the “Dynamic Contrast” effect is applied appears in “yellow” color.

With “Smoothing” and “NR” selected, pressing the [P.ANALYZER] button displays the analysis screen and the area where the “Smoothing” and “NR” effects are applied appears in “magenta” color.

* You can make adjustments with the analysis screen displayed.

Increasing the value enhances the effect and the color displayed is darker.

the [P.ANALYZER] button displays the analysis screen and the

Adjust/Set

Press the [P.ANALYZER] to exit the analysis screen

Fine-tuning the Image Quality

255

0 255

The photos are for illustrative purposes only.

Input Value

Output Value

255

0 255

The photos are for illustrative purposes only.

Input Value

Output Value

PICTURE MODE

FILM CINEMA ANIME.

NATURAL

THX USER

ADVANCED

FORMAT

PIC. ADJ.

COLOR

TEMP.

GAMMA

P.ANALYZER

MPC

GAMMA

Adjusting the Output Value of the Projected Image (Gamma)

You can adjust the output value of the projected image with respect to the video signal input.

Example of gamma adjustment

The overall image appear brighter with respect to the original image, making the dark areas more visible.

Increases the contrast with respect to the original image, creating a greater sense of depth.

Adjust/Set

Press the [GAMMA] button

Pressing the [GAMMA] button each time switches the setting in sequence.

You can also perform setting from “Picture Adjust”"“Gamma” in the menu.

*1 The setting value varies with the model in use, as well as the “Picture

Mode”. If HDR (high dynamic range) signal is detected, the setting value may

automatically switch to “D”. If the setting value does not switch automatically when viewing HDR contents, try to set to “D” manually. If the image appears dark after switching to “D”, it is recommended to adjust the image according

to the procedures in “Procedures for adjusting

the image when gamma is set to “D””P. 39.

Gamma Settings for Different “Color Profile” 6

Color Profile Selectable Settings Description

Standard Cinema Animation Video 3D Cinema 3D Video 3D Animation Off

x.v.Color Normal* Recommended setting for normal viewing.

* When “Color Profile” is set to “x.v.Color”, the setting is fixed at “Normal”.

Normal Recommended setting for normal viewing.

A Places more emphasis on the gradation compared to the Normal

setting.

B Places more emphasis on the contrast compared to the Normal

setting.

C Places more emphasis on the brightness compared to the Normal

setting.

D Gamma suitable for viewing HDR (High Dynamic Range) content.

Custom 1 to Custom 3 Fine-tunes the gamma setting according to the user’s preference.

Gamma Settings for Different “Color Profile” 4 5

BACK

Back

Operate

Select

Exit

White

2.2

Custom 1

Reset

Bright Level

Dark Level

Picture Tone

Color Selection

Correction Value

Gamma

Picture Adjust

Gamma

Color Profile Selectable Settings Description

Film 1 Film 1 Image is close to the characteristics of Eastman Kodak

Film 2 Places more emphasis on the gradation compared to the

Custom 1 to Custom 3 Fine-tunes the gamma setting according to the user’s

Film 2 Film 1 Places more emphasis on the contrast compared to the “Film

Film 2 Image is close to the characteristics of FUJIFILM Corporation

Custom 1 to Custom 3 Fine-tunes the gamma setting according to the user’s

Film 3 Film 1 Places emphasis on the contrast.

Film 2 Places emphasis on the gradation.

Custom 1 to Custom 3 Fine-tunes the gamma setting according to the user’s

3D Film Film 1 Places emphasis on the contrast.

Film 2 Places emphasis on the gradation.

Custom 1 to Custom 3 Fine-tunes the gamma setting according to the user’s

Standard Cinema 1/Cinema 2 Anime 1/Anime 2

Normal Recommended setting for normal viewing.

A Places more emphasis on the gradation compared to the

Video Reference

B Places more emphasis on the contrast compared to the 3D Cinema 3D Video 3D Animation

C Places more emphasis on the brightness compared to the Off

D Gamma suitable for viewing HDR (High Dynamic Range)

Custom 1 to Custom 3 Fine-tunes the gamma setting according to the user’s

x.v.Color Normal*1 Recommended setting for normal viewing.

THX

THX*2 Video of the THX standard. 3D THX

*1 When “Color Profile” is set to “x.v.Color”, the setting is fixed at “Normal”.

*2 When “Color Profile” is set to “THX”/“3D THX”, the setting is fixed at “THX”.

Company movie films.

“Film 1” setting.

preference.

2” setting.

movie films.

preference.

Normal setting.

content.

preference.

Adjust/Set

Fine-tuning to the Preferred Gamma Setting

You can perform fine adjustments based on the selected gamma adjustment setting.

Press the [ADVANCED MENU] button to display the gamma menu

You can also perform setting from “Picture Adjust”"“Gamma” in the menu.

Adjust to the preferred setting

0 255

255

D”

Gamma Curve

Input Value

Output Value

Dark

Bright

Item Description Setting

Color Selection Select “Color Selection”, and select the color to adjust White/Red/Green/Blue

Picture Tone Adjusts the overall brightness automatically for a well-balanced

result without compromising the gradation of the image.

-16 (darkens image for an underexposed effect) to +16 (brightens


for

effect)

Dark Level

Adjusts the dark areas of the input image. (Each of White/Red/ Green/Blue can be adjusted.)

To do so, use the H I keys to move the cursor.

Bright Level Adjusts the bright areas of the input image. (Each of White/Red/

Green/Blue can be adjusted.)

To do so, use the H I keys to move the cursor.

-7 (darkens the shadows) to +7 (brightens the shadows)

-7 (darkens the highlights) to +7 (brightens the highlights)

* Adjustment cannot be made when “Color Profile” is set to “x.v.Color”.

Selecting the Default Value for Making Adjustments

When one of “Custom 1” to “Custom 3” is selected in “Gamma”, you can select a “Correction Value”.

Select “Correction Value”, and press the H I keys to select a correction value (setting value) as a base value for adjustment.

For details on the correction value (setting value), please refer to

Normal, A, B, C, D, 1.8, 1.9, 2.0, 2.1, 2.2, 2.3, 2.4, 2.5, 2.6, Import

4 5

Adjust/Set

When “Picture Mode” is set to “Film”: Film 1, Film 2, Import When “Picture Mode” is set to a value other than “Film”: Normal, A, B, C, D, 1.8, 1.9, 2.0, 2.1, 2.2, 2.3, 2.4, 2.5, 2.6, Import

The smaller the value, the brighter the dark areas of the image will become. At the same time, the bright areas will appear blown out.

Selecting “Import” enables you to select the gamma data created externally. The factory setting for “Import” is the same as the “Normal” setting.

You can use the projector calibration software to customize the gamma data adjustment, and import the created gamma data.

For more details, please refer to our website. http://www3.jvckenwood.com/english/download/index.html

P. 36 and P. 37.

overexposed

About gamma adjustment

When the gamma curve is a straight line: The brightness and contrast of the video input will be the same as that of the video output.

Area for which the gamma curve is above the straight line (A): Video output appears brighter than the input.

Area for which the gamma curve is below the straight line (B): Video output appears darker than the input.

Area for which the slope of the gamma curve is steep (midtone) (C): The grayscale range of the video output becomes wider, and the contrast increases (D"D’).

Procedures for adjusting the image when gamma is set to “D”

Intermediate Frame GenerationIntermediate Frame Generation

Interpolation Enabled

Original Image

HDMI 1

INPUT

LENS MEMORY

HDMI 2 INFO.

MEMORY

MEMORY1 MEMORY2

LENS

CONTROL

LENS AP.

C.M.D.

If the image appears dark when gamma is set to “D”, it is recommended to adjust the image according to the following procedures.

While checking the overall image, adjust the setting value of “Picture Tone” in the + direction.

Focus on the bright area of the image and adjust the setting value of “Bright Level” in the + direction until the bright area appears appropriate.

Focus on the dark area

of the image and adjust the setting value of “Dark Level” in the + or - direction until the dark

area appears appropriate.

Reducing the After-image of Fast-moving Images (Blur Reduction)

Clear Motion Drive (C.M.D.)

Optimal interpolation according to the content is made possible with the new high-definition image interpolation technique that supports 3D images. For some scenes, interpolation may cause distortion in the image. In this case, set to “Off”.

Adjust/Set

Press the [C.M.D.] button

Pressing the [C.M.D.] button each time switches the mode in the following sequence: “Off”"“Low”"“High”"“Inverse Telecine”"“Off”...

Setting Description

Off Interpolation is not performed.

Low Softens the image quality.

High Image quality becomes softer than that of the “Low” setting.

Inverse Telecine 60i/60p video images such as those of TVs and DVDs.

Suitable for original images that

Does not function for 24p video images.

are 24-frame film sources.

* C.M.D. is the abbreviation for Clear Motion Drive.

Motion Enhance

HDMI 1

INPUT

LENS MEMORY

HDMI 2 INFO.

MEMORY

MEMORY1 MEMORY2

LENS

CONTROL

LENS AP.

C.M.D.

Optimal image quality with reduced image blurring is made possible by enhancing the responsiveness of the liquid crystal panel. If the image outline is unnatural, set this item to “Off”.

Select “Picture Adjust”"“Blur Reduction”"“Motion Enhance” from the menu

Setting Description

Off Does not perform correction.

Low Reduces image blurring.

High Further reduces image blurring than “Low”.

If “Keystone” is set to a value other than “0”, the “Motion Enhance” is set to “Off” and grayed out.

If “Anamorphic” is set to other than “Off”, the “Motion Enhance” is set to “Off” and grayed out.

Viewing High Contrast Images (Lens Aperture)

JVC has developed an image analysis algorithm, which analyzes the state of the video image in real time, and controls the aperture dynamically according to the image information. This technology enables viewers to enjoy video images with enhanced contrast.

Press the [LENS AP.] button

Pressing the [LENS AP.] button each time switches the setting in sequence.

Adjust/Set

Setting Description

Auto 1 Image contrast is enhanced.

Auto 2 Places emphasis on the gradation.

Manual Does not perform dynamic control.

Select this setting to perform adjustment manually.

*1 Manual adjustment is disabled in the “Auto 1” and “Auto 2” setting.

To perform adjustment manually, select “Manual”.

*2 When the setting is changed to Auto after performing manual adjustment, the

value set manually will be used as the aperture value for Auto.

Adjustments and Settings in the Menu

Pressing the [MENU] button displays the menu. Press the [JKH I] keys to select an item, followed by pressing the [OK] button to confirm the selection.

List of Menu Items

Picture Adjust

I Picture Mode ................................................................................................................................................... P. 30

9 Clear Black ................................................................................................................................................. P.

9 Lamp Power ............................................................................................................................................... P. 43

9 Lens Aperture ............................................................................................................................................. P. 43

9 User Name Edit .......................................................................................................................................... P. 43

I Color Profile ..................................................................................................................................................... P. 31

Color Management ......................................................................................................................................... P. 33

I Color Temp. ..................................................................................................................................................... P. 44

I Gamma ............................................................................................................................................................ P. 36

Picture Tone .................................................................................................................................................... P. 38

Dark Level/Bright Level ................................................................................................................................... P. 38

I MPC Level ....................................................................................................................................................... P. 34

I Blur Reduction ................................................................................................................................................. P. 39

I Brightness ....................................................................................................................................................... P. 45

I Contrast ........................................................................................................................................................... P. 45

I Color ................................................................................................................................................................ P. 46

I Tint .................................................................................................................................................................. P. 46

Adjust/Set

Input Signal

I Input Level ....................................................................................................................................................... P. 46

I Color Space ..................................................................................................................................................... P. 46

Aspect ............................................................................................................................................................. P. 47

I Progressive ...................................................................................................................................................... P. 47

I Mask ................................................................................................................................................................ P. 47

I 3D Setting ........................................................................................................................................................ P. 28

I Picture Position ................................................................................................................................................ P. 47

IHDMI2 EDID ..................................................................................................................................................... P. 47

Installation

I Lens Control .................................................................................................................................................... P. 23

9 Focus ......................................................................................................................................................... P. 23

Zoom .......................................................................................................................................................... P. 23

9 Shift ............................................................................................................................................................ P. 23

9 Image Pattern ............................................................................................................................................. P. 48

9 Lock ........................................................................................................................................................... P. 48

9 Lens Memory Select ................................................................................................................................... P. 25

9 Lens Memory Save .................................................................................................................................... P. 24

9 Lens Memory Name Edit ............................................................................................................................ P. 25

9 Lens Center ................................................................................................................................................ P. 48

9 Lens Cover 4 5 .......................................................................................................................... P. 48

I Pixel Adjust ...................................................................................................................................................... P. 49

I Installation Style ............................................................................................................................................... P. 50

I Keystone ......................................................................................................................................................... P. 50

I Anamorphic ..................................................................................................................................................... P. 50

I High Altitude Mode .......................................................................................................................................... P. 50

I Screen Adjust .................................................................................................................................................. P. 26

Display Setup

I Back Color ....................................................................................................................................................... P. 54

I Menu Position .................................................................................................................................................. P. 54

Signal Display .................................................................................................................................................. P. 54

I Logo ................................................................................................................................................................ P. 54

I Language ........................................................................................................................................................ P. 54

Adjust/Set

Function

I Trigger ............................................................................................................................................................. P. 54

I Off Timer .......................................................................................................................................................... P. 54

I ECO Mode ....................................................................................................................................................... P.

I Network ........................................................................................................................................................... P. 55

I Remote Code .................................................................................................................................................. P. 56

I Lamp Reset ..................................................................................................................................................... P. 59

Information

I Information .......................................................................................................................................................

Picture Adjust

BACK

User 1

}

{

]

[

)

(

;

SPACE

Name

After entry is complete, select “OK” and press the [OK] button

Selection Cursor

Input Cursor

Back

Operate

Select

Exit

OKAll ClearClear

User Name Edit

Picture Adjust

Picture Mode

You can adjust the image quality according to the type of video image you are viewing.

Æ “Setting the Picture Mode” (P. 30)

Clear Black

Adjusts the difference in brightness in an image electrically to produce an image with contrast.

Setting Description

Off Does not perform correction.

Low Mode with a mild effect.

High Mode with a strong effect.

Lamp Power

The brightness of the lamp can be set to “Low” or “High”.

The factory setting varies with the “Picture Mode”.

Continuous use at the “High” setting may cause the lamp to darken faster.

Lens Aperture

Æ “Viewing High Contrast Images (Lens Aperture)” (P.

Stopping down the aperture reduces the brightness and increases the contrast.

Setting range: -15 (stops down) to 0 (opens up)

40)

Adjust/Set

User Name Edit

You can edit the “User 1” to “User 6” names in the Picture mode.

Characters that are usable include alphabets (upper or lower case), numeric characters, and symbols.

Enter not more than 10 characters.

Color Profile

By setting the “Color Profile” (color space information) according to the “Picture Mode”, you can fine-tune the image quality according to the movie you are viewing.

Æ “Setting the Color Profile” (P. 31)

Color Management

Each of the colors is adjustable according to the user’s preference.

Æ “Adjusting to the Preferred Color (Color Management)” (P. 33)

Color Temp.

For setting the color temperature of the video image.

When “Picture Mode” is set to “THX” and when “Color Profile” is set to “x.v.Color”, the setting is fixed at 6500K.

Preset

Setting Description

Xenon 1 to Xenon 3 4 5

* Selectable when “Picture Mode” is set to

“Film” or “Cinema”.

5500K, 6500K, 7500K, 9300K Increasing the value enhances the blue tone of the video image, while

Adjust/Set

Custom 1 to Custom 3 The color temperature of video images can be adjusted manually and

High Bright Color temperature that gives priority to brightness.

Color temperature that reproduces

the characteristics of a xenon lamp

used in cinemas.

Xenon 1: A light source color that is emitted by a film projector

2: A light source

Xenon

color emitted by a projector used for digital

cinema

Xenon 3: A light source color that looks cooler than that of “Xenon 2”

decreasing the value enhances the red tone.

saved as one of the three customized settings.

Custom

Setting Description

Gain Red, Gain Green, Gain Blue Adjusts each color in the bright parts of the video image.

Setting range: -255 (reduces the red/green/blue tone) to 0 (enhances the red/green/blue tone)

Offset Red, Offset Green, Offset Blue Adjusts each color in the dark areas of the video image.

Setting range: -50 (reduces the red/green/blue tone) to +50 (enhances the red/green/blue tone)

Gamma

You can adjust the output value of the projected image with respect to the video signal input.

Æ “Adjusting the Output Value of the Projected Image (Gamma)” (P. 36)

Picture Tone

Adjusts the overall

Æ “Fine-tuning to the Preferred Gamma Setting” (P. 38)

brightness automatically for a well-balanced result without compromising the gradation of the image.

Dark Level/Bright Level

You can adjust the image quality to produce a sharp contrast in the brightness.

Æ “Fine-tuning to the Preferred Gamma Setting” (P. 38)

MPC Level

You can enjoy natural, expressive 4K images with a stronger sense of depth.

Æ “Adjusting Movies for Increased Expressiveness (Multiple Pixel Control)” (P. 34)

4K e-shift

Switches the display resolution.

Setting values: On (4K), Off (2K)

Original Resolution

For selecting a resolution for the content you are viewing.

Setting values: Auto, 4K and 1080p

default “Original Resolution”

* The

setting is “Auto”, which switches the resolution automatically according to the type

of signal input.

Enhance

For adjusting the high-frequency areas. Increasing the value enhances the definition for a sharper image quality.

Setting range: 0 to 10

In the case of 4K 50/60p and other input signals, the respective setting values are saved.

Dynamic Contrast

For adjusting the medium-frequency areas. Increasing the value enhances the contrast for a more dynamic image quality.

Setting range: 0 to 10

Smoothing

For adjusting the low-frequency areas. Increasing the value enhances the blurriness of the image for a softer effect.

Setting range: 0 to 10

Adjust/Set

Prevents noise from becoming too pronounced.

Setting range: 0 (weak) to 10 (strong)

MEMO

“4K e-shift” is fixed at “On” during 4K signal input.

“Original grayed out.

“4K e-shift” is fixed at “Off” during 3D signal input.

Blur Reduction

For reducing the after-image, which occurs in a fast-moving scene.

Æ “Reducing the After-image of Fast-moving Images (Blur Reduction)” (P. 39)

Brightness

For adjusting the brightness of the video image.

Setting range: -50 (darker) to +50 (brighter)

* Adjustment cannot be made when “Color Profile” is set to “x.v.Color”.

Contrast

For adjusting the difference in brightness to produce an image with contrast.

Setting range: -50 (little difference in brightness) to +50 (large difference in brightness)

* Adjustment cannot be made when “Color Profile” is set to “x.v.Color”.

Resolution” is fixed at

“Auto” during 4K 50/60p signal input. “Dynamic Contrast”, “Smoothing” and “NR” are

Color

For adjusting the color density of the video image.

Setting range: -50 (lighter) to +50 (deeper)

* Adjustment cannot be made when “Color Profile” is set to “x.v.Color”.

Tint

For adjusting the hue of the video image.

Setting range: -50 (reddish) to +50 (greenish)

* Adjustment cannot be made when “Color Profile” is set to “x.v.Color”.

Input Signal

Input Level

For setting the dynamic range (gradation) of the video input. If the image is not displayed properly even after selecting “Auto”, select an appropriate setting.

If the dynamic range is not appropriate, the bright areas become overexposed, and the dark areas become underexposed.

Setting Description

Auto Sets the input signal level automatically.

Standard Select this setting if you are inputting video signals (dynamic range: 16 - 235).

Adjust/Set

Enhanced Select this setting if you are inputting PC signals (dynamic range: 0 - 255).

Super White Select this setting when inputting Super White-compatible device signals (dynamic

range: 16 - 255).

* When Picture Mode is set to “THX”, the setting is fixed at “Super White”.

Color Space

For setting the color space of the input signal. If the image is not displayed properly even after selecting “Auto”, select an appropriate setting.

Setting Description

Auto Detects “YCbCr (4:4:4)”, “YCbCr (4:2:2)”, and “RGB” automatically.

YCbCr (4:4:4) Select this setting when inputting YCbCr (4:4:4) video signals.

YCbCr (4:2:2) Select this setting when inputting YCbCr (4:2:2) video signals.

RGB Select this setting when inputting RGB video signals.

Aspect

Mask: black strip around the periphery

Off

The screen size of the projected image can be adjusted optimally according to the original screen size (aspect) that has been input.

Æ “Adjusting the Screen Size (Aspect)” (P. 27)

Progressive

For setting the interpolation method for the interlaced signals. If the image outline is unnatural, set this item to “Off”.

Setting Description

Auto Performs interpolation by automatically detecting whether the interlaced signals

are converted from 24p video images, such as those in film movies, or interlaced signals of video materials.

Off Interpolates video images as interlaced signals of video materials, etc.

Mask

For hiding the peripheral area of the image with a mask (black strip).

Setting Description

Off Not masked.

Custom 1 to Custom 3 Masks about 0 to 220 pixels of the four sides of the

image.

* The pixel count is 1920 pixels in the horizontal

direction and 1080 pixels in the vertical direction.

Adjust/Set

3D Setting

For setting 3D movies for viewing.

Æ “Viewing 3D Movies” (P. 28)

Picture Position (Horiz./Vert.)

Adjust the position if the edges of the image are partially missing due to the timing of horizontal and vertical synchronization signals.

* Adjustment cannot be made during 4K, 3D and 1080i signal input.

HDMI2 EDID

For changing the EDID mode of the [HDMI 2] terminal. Set to “A” under normal condition.

Images with resolution 1920x1080 or lower may not be displayed when some old devices are used. In that case, connect to the [HDMI 2] terminal and set “HDMI2 EDID” to “B”.

EDID (Extended Display Identification Data) refers to the information, such as supported resolutions, exchanged

between devices.

Installation

Lens Control

Focus / Zoom / Shift

For adjusting the lens according to the projection position

Æ “Adjusting the Lens According to the Projection Position” (P. 23)

Image Pattern

Setting Description

On Displays the lens adjustment pattern.

Off Displays external signals, and does not display the lens adjustment pattern.

Lock

Setting Description

On Locks the lens to prevent any erroneous operation on the adjustments.

Operation of the lens control feature is disabled when “On” is selected.

Off Does not lock the lens.

Lens Memory Select / Lens Memory Save / Lens Memory Name Edit

The Focus, Zoom, and Shift settings can be saved or retrieved, so you can switch easily to a different aspect ratio

Adjust/Set

(screen size) according to the image.

Æ “Saving and Retrieving Adjustment Settings” (P. 24)

Lens Center

Returns the lens position to the center.

Lens Cover 4

Setting Description

Auto Opens/closes the lens cover according to the power on/off operation.

Open Leaves the lens cover open regardless of the power on/off mode.

Pixel Adjust

Adjust

For setting the adjustment feature to On (Memory 1 or Memory 2) or Off.

* You can save the settings separately when an anamorphic lens is used and when you are using the projector with

a screen.

Adjust Area

Setting Description

Whole Adjusts the entire image.

Zone Enables fine adjustment of each zone by dividing the screen into 11 vertical x 11

horizontal zones.

Adjust Color

For selecting the color to adjust (“Red” or “Blue”).

Adjust Pattern Color

For setting the adjustment pattern color to “White” or “Yellow / Cyan”.

Adjust (Pixel)

When “Adjust Area” is set to “Whole”, adjustment can be made by moving in units of one pixel on the screen of the color selected in “Adjust Color”.

Æ “Whole Adjust (Pixel) Operation Procedure” (P.

* Adjustment cannot be made when “Adjust Area” is set to “Zone”.

Setting Description

H (Horizontal) Setting range: -2 (moves red/blue to the left) to +2 (moves red/blue to the right)

V (Vertical) Setting range: -2 (moves red/blue downward) to +2 (moves red/blue upward)

51)

Adjust/Set

Adjust (Fine)

When “Adjust Area” is set to “Whole”, adjustment can be made by moving in units of 1/16 pixel on the screen of the color selected in “Adjust Color”.

Æ “Whole Adjust (Fine) Operation Procedure” (P. 52)

When “Adjust Area” each zone is possible.

Æ “Zone Adjust Operation Procedure” (P. 53)

H (Horizontal) Setting range: -31 (moves red/blue to the left) to +31 (moves red/blue to the right)

V (Vertical) Setting range: -31 (moves red/blue downward) to +31 (moves red/blue upward)

is set to “Zone”, the screen is divided into 11 vertical x 11 horizontal zones, and fine adjustment of

Setting Description

Reset

Restores all pixel adjustment data to the factory default.

Installation Style

For setting to “Front”, “Ceiling Mount (F)”, “Rear”, or “Ceiling Mount (R)” according to the installation status of the projector.

“Front” or “Ceiling Mount (F)” is set when projector is installed in the front with respect to the screen.

“Rear” or “Ceiling Mount (R)” is set when projector is installed in the rear with respect to the screen.

Keystone

For correcting any keystone distortion that occurs when the projector is installed at an angle with respect to the screen.

Vertical setting range: -16 to +16

*1 Increasing the value changes the aspect slightly.

*2 Adjustment cannot be made during 4K 50/60p signal input.

Anamorphic

Configure this setting when an anamorphic lens is used.

Setting Description

A Projects the 2.35:1 image with it stretched in the vertical direction only.

B Projects the 16:9 image with it compressed in the horizontal direction only.

Off Projects the 2.35:1 image without any changes.

High Altitude Mode

Set to “On” when using the projector at a location of low atmospheric pressure (higher than 900 m above sea level).

Adjust/Set

Screen Adjust

By selecting the optimal correction mode according to the characteristics of the screen in use, corrections can be performed to reproduce natural images with balanced colors.

Æ “Setting Screen Correction” (P. 26

)

Whole Adjust (Pixel) Operation Procedure

Color A.

GAMMA

BACK

Adjust.

COLOR

Color P.3DA. Area

PIC.

TEMP FORMAT ADJ.

H 0 V 0

Red

Pixel Adjust

Back

Operate

Select

Whole Adjust (Pixel)

V (Vertical)

H (Horizontal)

Adjustment (Pixel) Window

Adjustment Pattern

Color A.

GAMMA

BACK

Adjust.

COLOR

Color P.3DA. Area

PIC.

TEMP FORMAT ADJ.

H 0 V 0

Red

Pixel Adjust

Back

Operate

Select

Whole Adjust (Pixel)

Remote Control Operation Guide

Color for Adjustment

Pixel Adjustment Setting

For making general adjustments to slight color fringing in the horizontal/vertical directions of the video image.

Set “Adjust Area” to “Whole”

Select “Adjust Color” and “Adjust Pattern Color”

Select “Adjust (Pixel)”, and press the [OK] button

The selected adjustment pattern and Adjustment (Pixel) window are displayed.

Press the [OK] button to enter the Adjustment mode

Use

the [JKH

The adjustment setting appears at the center of the Adjustment (Pixel) window.

] keys to move and adjust the pixels in the vertical and horizontal directions across the entire screen.

After adjustment is complete, press the [BACK] button to exit the Adjustment mode

Remote Control Operation Guide

Button Name Description of Operation

[GAMMA] Changes “Adjust Color”.

[COLOR TEMP.] Switches between “Adjust (Pixel)” and “Adjust (Fine)”.

Switches to “Adjust (Pixel)” when “Adjust Area” is set to “Zone”.

[3D FORMAT] Changes “Adjust Pattern Color”.

[PIC ADJ.] Switches “Adjust Area”.

A zone cursor appears on the adjustment pattern when the “Zone” setting is selected.

Adjust/Set

Whole Adjust (Fine) Operation Procedure

Color A.

GAMMA

BACK

Adjust.

COLOR

Color P.3DA. Area

PIC.

TEMP FORMAT ADJ.

0 ( 0 / 0 ) 0 ( 0 / 0 )

Red

Whole Adjust (Fine)

Pixel Adjust

Back

Operate

Select

V (Vertical)

H (Horizontal)

Fine Window

Adjustment Pattern

H −20 （−20 / −20） V 5 （ 5 / 5）

Color A.

GAMMA

BACK

Adjust.

COLOR

Color P.3DA. Area

PIC.

TEMP FORMAT ADJ.

0 ( 0 / 0 ) 0 ( 0 / 0 )

Red

Whole Adjust (Fine)

Pixel Adjust

Indicates the maximum and minimum misalignment value of the entire screen.(Max. / Min.)

Adjustment Setting

Remote Control Operation Guide

Color for Adjustment

Pixel Adjustment Setting

Back

Operate

Select

For making general adjustments on the misalignment of the entire screen using “Adjust (Pixel)”, followed by making fine adjustments.

Set “Adjust Area” to “Whole”

Select “Adjust Color” and “Adjust Pattern Color”

Select Adjust (Fine), and press the [OK] button

The selected adjustment pattern and Fine window are displayed.

The adjustable range may be smaller depending on the pixels being adjusted on the entire screen.

Press the [OK] button to enter the Adjustment mode

Use the [JKH I

Adjust/Set

The adjustment setting appears at the center of the Fine window.

] keys to move and adjust the pixels in the vertical and horizontal directions across the entire screen.

After adjustment is complete, press the [BACK] button to exit the Adjustment mode

MEMO

If both the maximum overall screen misalignment of H (horizontal direction) and V (vertical direction) are “31”, you cannot select a value that is larger than the displayed setting even when the adjustment setting is lower than the maximum value.

If the minimum overall screen misalignment is “-31”, you cannot select a value that is smaller than the displayed setting even when the adjustment setting is higher than the minimum value.

Zone Adjust Operation Procedure

Color A.

GAMMA

BACK

Adjust.

COLOR

Color P.3DA. Area

PIC.

TEMP FORMAT ADJ.

0 / 0

Position

Red

Zone Adjust

Pixel Adjust

V (Vertical)

H (Horizontal)

Zone Adjustment Window

Zone Cursor

Adjustment Pattern

Back

Operate

Select

H −31 V 7

Color A.

GAMMA

BACK

Adjust.

COLOR

Color P.3DA. Area

PIC.

TEMP FORMAT ADJ.

0 / 0

8 / 5

Position

Red

Zone Adjust

Pixel Adjust

Position

Adjustment Setting

Cursor Position

Remote Control Operation Guide

Color for Adjustment

Pixel Adjustment Setting

Back

Operate

Select

For fine-tuning misalignments on a part of the screen after adjusting the overall screen misalignment using “Adjust (Pixel)” and “Adjust (Fine)”.

The screen can be divided vertically and horizontally into 10 sections for partial adjustments to be made.

Set “Adjust Area” to “Zone”

Select “Adjust Color” and “Adjust Pattern Color”

Select Adjust (Fine), and press the [OK] button

The selected adjustment pattern and Zone Adjustment window are displayed.

The adjustable range may be smaller depending on the pixels being adjusted on the entire screen.

Press the [JKH I] keys to move the cursor to the point to be adjusted

Press the [OK] button to enter the Adjustment mode

Use the [JKH I

The adjustment setting appears at the center of the Zone Adjustment window.

] keys to move and adjust the pixels in the vertical and horizontal directions across the entire screen.

Adjust/Set

After adjustment is complete, press the [BACK] button to exit the Adjustment mode

Display Setup

Back Color

For setting the color of the background to “Blue” or “Black” when there is no signal input.

Menu Position

For setting the display position of the menu.

Signal Display

Setting Description

On Shows the input terminal for 5 seconds when input is switched.

Off Not displayed.

Logo

Setting Description

On Displays the “D-ILA” logo for 5 seconds during startup.

Off Not displayed.

Adjust/Set

Language

For setting the display language to “日本語”, “English”, “Deutsch”, “Español”, “Italiano”, “Français”, “Português”, “Nederlands”, “Svenska”, “Norsk”, “Русский”, “中文”, or “繁體中文”.

Function

Trigger

For setting whether to supply a 12 V output to devices such as an external screen equipped with a trigger function.

Setting Description

Off No output.

On (Power) Outputs control signals (12 V) from the trigger terminal when the power is turned

on.

When the power is turned off, the control signal output is stopped when the cooling function starts.

On (Anamo) Outputs control signals when the “Anamorphic” setting is switched from “Off” to “A”

or “B”.

Off Timer

For setting the duration before the power turns off automatically when the projector is not operated.

Setting values: “Off”, “1 Hour”, “2 Hours”, “3 Hours” and “4 Hours”

ECO Mode

Setting Description

On Enables “ECO Mode” to minimize power consumption in the Standby mode.

RS-232C / LAN communication cannot be used in the Standby mode.

If there is no signal transmission and operation for 20 minutes while an image

projected,

is standby mode.

Off Select this option to control via RS-232C / LAN communication in the Standby

mode or if Control4 is to be used.

the

power

management

switches the equipment automatically into

Network

Specify the settings below during external control such as from a PC or smartphone.

Setting Description

DHCP Client On Obtains the IP address automatically from the DHCP server inside the connected

network.

Off For configuring the network settings manually.

IP Address For configuring the IP address.

Subnet Mask For configuring the subnet mask.

Default Gateway For configuring the default gateway.

MAC Address Displays the MAC address of the unit.

Set Applies the network settings.

Control4 Set to “On” to allow Control4 SDDP to detect this unit.

this unit is not

When and Control4 SDDP from the Control4 Corporation, set this to “Off”.

connected to an environment under the control of the controller

Adjust/Set

Glossary of Network Terminology

DHCP : Abbreviation for Dynamic

to assign an IP address automatically to the connected device. IP Address : Numeric characters for identifying the device that is connected to the network. Subnet Mask : Numeric characters that define the bit count used for the network address that is a

segment of the IP address. Default Gateway : Server for communicating beyond the network that is divided by the subnet mask. MAC Address : Abbreviation for Media Access Control address. This is a number that is unique to each

network adapter. Each of the network adapters is assigned with a unique MAC address.

Host Configuration Protocol. This is a protocol for the network

Remote Code

For changing the remote control code.

You need to configure the remote control according to the settings of this unit. On the remote control unit, press the [MENU] and [BACK] buttons at the same time for three seconds or longer to switch the code.

The backlight of the remote control blinks 3 times: change the remote control code to “A”

The backlight of the remote control blinks 2 times: change the remote control code to “B”

Setting Description

A Change the remote control code from “B” to “A”.

B Change the remote control code from “A” to “B”.

Lamp Reset

For resetting the lamp time to “0”.

Æ “Resetting the Lamp Time” (P. 59)

Information

Setting Description

Input Displays video input terminal.

Source (Displayed only during video signal input)

Resolution

Adjust/Set

(Displayed only during PC signal input)

H Frequency (Displayed only during PC signal input)

V Frequency (Displayed only during PC signal input)

Deep Color Displays the color bit depth of the input video signal.

Color Space Displays the color space of the input signal.

Lamp Time Displays the lamp time.

Soft Ver. Displays the firmware version.

PS Ver. Displays the version of image quality data.

Displays the input source.

Displays the image resolution.

Displays the horizontal frequency.

Displays the vertical frequency.

Not displayed when YCbCr (4:2:2) is input.

Displayed when Deep Color information is received from the source device.

Replacing the Lamp

The lamp is a consumable item. If the image appears dark or the lamp goes out, replace the lamp unit.

When the lamp replacement time approaches, the user is notified with a message displayed on the screen and by the indicator. (

Lamp Replacement Procedure

CAUTION

Do not insert your hands into the lamp compartment. This could cause significant deterioration in the performance of the equipment, or lead to injury and electric shock.

not replace the lamp immediately after the unit has

Do been used. Allow a cooling period of at least one hour before replacement. The temperature of the lamp is still high, and may cause burn injuries.

Do not subject the lamp unit to shock. Doing so may cause lamp blowout.

not use a flammable

Do parts of the unit. Doing so may cause fire.

Use only genuine replacement parts Also, never attempt to reuse an old lamp unit. This may cause the unit to malfunction.

Do not touch the surface shorten the lamp life and cause lamp blowout.

When replacing the lamp, be careful not to injure yourself as the lamp may be broken.

When replacing the lamp of a projector suspended from the ceiling, work at height is required. This is a dangerous operation. Please consult our service center.

P. 74)

air duster to clean the internal

for the lamp unit.

of a new lamp. Doing so may

Loosen the screws of the lamp unit

Loosen the screws with a t screwdriver.

Pull out the lamp unit

Hold the lamp unit at the dents at the top and bottom, and pull it out.

Maintenance

Pull out the power plug from the power

outlet

Remove the lamp cover

Remove the screw of the lamp cover with a t screwdriver.

Install the new lamp unit

MEMO

Usable lamp life

When the lamp is used with “Lamp Power” set to

the lamp life on

“Low”, hours. This is the average usable time and not a guaranteed value.

The lamp life may not the operating conditions.

When the lamp has reached deterioration progresses rapidly.

When the video image appears dark, when the color tone looks unnatural, or when the image flickers, replace the lamp unit with a new one promptly.

this unit is approximately 4500

reach 4500 hours depending on

the end of its usable life,

Tighten the screws of the new lamp

unit

Tighten the screws with a t screwdriver.

Maintenance

Attach the lamp cover

Insert the two tabs at the top and bottom of the lamp cover into the unit.

Tighten the screws with a t screwdriver.

Purchasing a lamp unit

Please consult your authorized dealer or nearby service center.

Lamp unit Product no.: PK-L2615U

* Not suitable for household room illumination.

Lamps with a different product number or those for

other projector models cannot be used.

Information about the lamp

An ultra-high pressure mercury lamp with a high internal pressure is used in the projector.

Due to the characteristics of this lamp, it may blow out with a loud noise or go out when it is subject to shock or after

using

for a prolonged

period of time (the time before the lamp blows out or goes out varies considerably with each lamp as well as the operating conditions).

After replacing the lamp

Do not place the removed lamp unit at a place that is within reach by children or anywhere near inflammable items.

Dispose used lamp units in the same way as fluorescent

lamps. Follow the regulations

community for disposal.

of your local

Resetting the Lamp Time

BACK

Back

Operate

Select

Exit

Off

Lamp Reset

Remote Code

Network

ECO Mode

Off Timer

Trigger

Function

Off

NoYes

Reset Lamp Time?

Press for 2

seconds or longer

Reset the lamp time when you have replaced the lamp. It provides an estimated timing for lamp replacement

Resetting the lamp time from the menu screen

Press the [MENU] button to display

the menu

Select “Function”"“Lamp Reset”

from the menu

On the “Reset Lamp Time?” screen,

select “Yes” and press the

The lamp time is reset to zero.

[OK] button

Resetting the lamp time using the remote control

Insert the power plug into the power

outlet

Make sure that you operate the remote control in the Standby mode

(the power plug is inserted into the outlet, but the power is not turned on)

Press in the order as shown.

Make sure that you press a button within two seconds after the last button is pressed. Press the last button for at least two seconds.

The “LAMP” indicator and “STANDBY/ON” indicator blink alternately for three seconds. After that, the unit switches to the Standby mode.

MEMO

Reset the lamp time only when you have replaced the lamp. If the lamp time is reset while a lamp is in use, you may lose track of the timing for replacing the lamp. Doing so may result in using the lamp beyond the estimated limit, thereby causing lamp blowout.

Maintaining the Cabinet and Remote Control

Gently wipe off dirt on the cabinet with a soft cloth.

If it is extremely dirty, wet a cloth in water, wring dry and use it to wipe off the dirt, followed by wiping again with a dry cloth.

Pay attention to the following as the cabinet may deteriorate in condition or the paint may come off.

Do not wipe with thinner or benzine

Do not allow prolonged contact with rubber or plastic products

Do not spray volatile chemicals such as insecticide

Maintenance

Cleaning and Replacing the Filter

Pull out while pushing down the tab

Check that the left and right tabs are locked onto the unit

Clean the filter regularly Otherwise, the air intake efficiency may deteriorate, and malfunction may occur.

CAUTION

Make sure that you pull out the power plug from the outlet before cleaning or replacing the filter.

Before turning this unit upside the floor or a table, make sure that you lay a soft rag in advance to prevent the projector from being scratched.

down and placing it on

Reinstall the inner filter

Remove the inner filter

Clean the filter

Maintenance

Wash the filter with water and dry it in a shaded area.

If the filter is extremely dirty, clean it with a neutral detergent. Put on rubber gloves when using a neutral detergent.

After washing the filter with water, make sure that it is completely dry before reinstalling. Otherwise, electric shock or malfunction may occur.

Do not clean the filter with a vacuum cleaner or air duster. The filter is soft and may be easily damaged.

If the filter is damaged or too dirty to be cleaned

Replace with a new filter. A dirty filter will dirty the internal parts of the unit on the video image.

To purchase a new filter or when there is dirt in the internal parts of the unit, consult your authorized dealer or nearby service center.

Inner filter (exchangeable filter) Product no.: PC010661199

and cause shadows to appear

Troubleshooting

Before sending the unit to your authorized dealer for repair, please check the following points. The following symptoms are not malfunctions.

You do not need to worry about the following symptoms if there is no abnormality on the screen.

A part of the top or front surface of the unit is hot.

A creaking sound is heard from the unit.

An operating sound is heard from the inside of the unit.

Color smear occurs on some screens.

This unit is a digital device. This unit may become unable to operate normally due to external static or noise. Perform the following operations when such malfunctions occur.

If the unit is in the Standby mode, pull out the power plug, followed by inserting it again

Press the A [STANDBY/ON] button on the main unit to turn on the power again

When “High Altitude Mode” is set to “On”, and “Lamp Power” is set to “High” during 3D mode, the fan will make louder noise than usual since it is designed to run at high speed in 3D mode.

Power is not supplied

Check Action Refer to

Is the power cord disconnected? Insert the power cord (plug) firmly. P. 20

Is the lamp cover properly shut? If the unit is in the Standby mode, remove the power plug

and close the lamp cover again.

Is the lamp in the Cool-down mode? After exiting the Cool-down mode, turn on the power again. P. 22

properly. After that, insert the plug

P. 58

Power shuts down automatically

Check Action Refer to

Has “ECO Mode” been configured? Set “ECO Mode” to “Off”. P. 55

Has “Off Timer” been configured? Set “Off Timer” to “Off”. P. 54

Are the air inlets and exhaust vent blocked?

Is the filter dirty? Clean the filter. P. 60

Leave proper clearance when installing the unit. P. 10, 11

P. 15

Troubleshooting

Video image does not appear

Check Action Refer to

Is the correct external input selected? Select the correct external input terminal. P. 21

Is the power of the AV device turned on? Turn on the power of the AV device and play the video. P. 18

Is the AV device properly connected? Connect the AV device properly. P. 18

Are the correct signals being output from the AV device?

Is the cable in use an HDMI-certified cable?

Is an intermediate device (AV amplifier, divider, etc.) in use?

Is an old source device in use? Change the resolution setting of the source device. For

Set the AV device properly. P. 18

Use an HDMI-certified high-speed cable. Also, use as short a cable as possible.

Change the sequence of turning on the source device, intermediate device and the projector. each device, ensure that the signal output is stable before turning on the next device.

details on how to change the setting, please refer to the instruction manual of the source device. Or, try connecting to the HDMI2 terminal and set “HDMI2 EDID” to “B”.

And after turning on

3D images do not appear

Check Action Refer to

Do you see two images displayed side by side?

Is an intermediate device (AV amplifier, divider, etc.) in use?

Is the cable in use an HDMI-certified cable?

Is the power of the 3D GLASSES turned on?

Are the 3D GLASSES charged? Check whether the PK-AG1 battery of the 3D GLASSES

Are the 3D GLASSES and 3D SYNCHRO EMITTER too far away from each other?

Is the 3D GLASSES and 3D SYNCHRO

Troubleshooting

EMITTER combination correct?

Set “3D Format” to “Side by Side” Video images in the “Side by Side” format may not be recognized automatically in the case of 3D video images.

Connect the source device to the projector directly, and check whether there is any improvement in the condition. If the condition improves, it is likely that this is not caused by malfunction of the projector.

Use an HDMI-certified high-speed cable. Also, use as short a cable as possible.

If you are using the PK-AG2 or PK-AG33D GLASSES, turn on the power manually.

has run out, and whether PK-AG2 and PK-AG3 are charged.

Position them at an appropriate distance.

Check the model name of 3D GLASSES and 3D SYNCHRO EMITTER, and use the correct combination.

P. 18

P. 47

P. 29

P. 18

Check the instruction manual of the 3D GLASSES and 3D SYNCHRO EMITTER.

P. 9

3D video image looks unnatural

Check Action Refer to

Are there overlapping video images? If there are overlapping video images partially, this is due

to the crosstalk phenomenon. In this case, adjust “Crosstalk Cancel” accordingly.

If there are overlapping video images partially, this is due to the crosstalk phenomenon. This phenomenon often occurs when there are drastic changes in the brightness. In this case, set Lamp Power to “High”

P. 29

P. 43

Video image looks unnatural

Colors are unnatural

Check Action Refer to

Is the color space of the input signal correctly set?

Is the image correctly adjusted? Adjust “Color” and “Tint” accordingly. P. 46

Is the AV device properly connected? Connect the AV device properly. P. 18

* The video image may appear slightly reddish immediately after starting up. This is not a malfunction.

The color may turn out unnatural when the input signal is different from that in the projector setting. Set the “Color Space” for “Input Signal” correctly.

P. 46

Video image is fuzzy

Check Action Refer to

Is the focus correctly adjusted? Adjust the focus. P. 23

Is the unit placed too near or too far away from the screen?

Set the unit at a correct distance from the screen. P. 71

Video image flickers

Check Action Refer to

Do you see horizontally-extended, overlapping video images?

Are you viewing the video images under a fluorescent light?

Is “Lens Aperture” set to “Auto 1” or “Auto 2”?

* Flickers may sometimes occur upon starting up the projector unit, or immediately after the projector is changed from

floor-standing to ceiling mounted. This is attributable to the lamp or drive mechanism, and is likely not caused by malfunction of the projector.

In this case, set “3D Format” to “Auto” P. 29

This is caused by interference between the 3D glasses with the flickers of the fluorescent light. View with the fluorescent light turned off.

Set “Lens Aperture” to “Manual” P. 40

—

Projected image is dark

Check Action Refer to

Is the lamp near exhaustion? Check the lamp time in the “Information” menu. Prepare a

new lamp unit or replace as soon as possible when the lamp is near exhaustion.

Is the aperture closed? Set “Lens Aperture” to “Auto 1” or “Auto 2”, or set to

“Manual” and open up the aperture manually.

Is “Lamp Power” set to “Low”? Set “Lamp Power” to “High” P. 43

P. 56 P. 57

P. 40

Video image appears horizontally (vertically) extended

Check Action Refer to

Is “3D Format” set to “Side by Side”? Set “3D Format” to “Auto” P. 29

Is “Anamorphic” set to a setting other than “Off”?

Set “Anamorphic” to “Off” P. 50

Troubleshooting

Striped patterns appear on the screen

Check Action Refer to

Does the fabric of the screen have a regular pattern?

Interference fringes may sometimes occur between the fabric pattern and the pixels. dealer.

Please consult the authorized

Video images are missing

Check Action Refer to

Has screen mask been configured? Set “Mask” to “Off”. P. 47

Is the display position misaligned? Alter the “Picture Position” value so that the entire image

appears on the screen.

P. 47

Remote control does not work

Check Action Refer to

Are the batteries correctly loaded? Match the polarities (t s) correctly when loading the

batteries.

Are the batteries exhausted? Replace with new batteries. P. 14

Is there an obstructing object between the remote control and remote sensor?

Is the remote control held too far away from the unit?

Are the IR (infrared) 3D GLASSES and 3D SYNCHRO EMITTER in use?

Remove any obstructing object. P. 14

Hold the remote control closer to the sensor during use. P. 14

As there is a possibility of signal interference, when you are using the IR (infrared) 3D GLASSES together with the 3D SYNCHRO EMITTER, try adjusting the orientation of the 3D SYNCHRO EMITTER.

P. 14

P. 28

—

The lens cover does not close 4 5

Check Action Refer to

Is “Lens Cover” set to “Open”? Set “Lens Cover” under “Lens Control” in the setting menu

to “Auto”.

P. 48

Noise is heard

Check Action Refer to

Is the exhaust vent blocked?

Troubleshooting

Is the unit used near a heater or airconditioner?

Are you viewing 3D video images? “Lamp Power” is set automatically to “High” to ease viewing

Is the “Picture Mode” or “Color Profile” changed?

4 5 only

Did you change the “4K e-shift” setting for “MPC Level”?

Check the installation condition of the projector. When the surrounding temperature of the projector is high, the fan revolution speed increases to protect the projector unit, hence a louder operating sound.

of 3D video images, hence a louder fan operating sound. If you are bothered by the sound, set it to “Low”.

Operating sound is generated by the cinema filter. This is not a malfunction.

Switching sound is generated. This is not a malfunction.

P. 15

P. 43

There are small black or colored dots on the screen

The D-ILA device is manufactured using high-precision technologies, but there may be some (less than 0.01%) missing pixels or pixels that remain permanently lit. This is not a malfunction.

—

When the following messages appear...

No Input

HDMI-1

BACK

Back

Lamp replacement

Message Description Action

No device is connected to the input

terminal.

The input terminal is connected but there is no signal.

A video signal that cannot be used with

this unit has been input (The names of input terminals such as “HDMI-1” and “HDMI-2” will be displayed in yellow).

Indicates that the lamp needs to be replaced soon.

clear

To button on the operation panel of the

message,

the

press

the [BACK]

projector unit or the remote control.

Input the video signals.

Input video signals that can be used.

73)

(P.

Get ready a new lamp unit and replace as soon as possible. Reset the lamp time after replacing the lamp. (P. 57, 59)

Troubleshooting

External Control

This Unit

D6 D7D4 D5D2 D3D0 D1

Stop bitStart bit

Projector Control

Connection Authentication Procedure

PJA CK

PJ RE Q

PJ _O K

Within 5 Seconds

Controlling PC

3-way Handshake

TCP Port No. 20554

Establishment of TCP Connection

Projector

It is possible to control this unit by connecting it to a PC using an RS-232C cross cable (D-sub 9-pin). The projector can be controlled by connecting it to a PC through the computer network with a LAN cable for control commands to be sent to the projector. Æ “ Network ” (P. 55)

Please use it after you have gained proper understanding from professional books or consulting the system administrator.

RS-232C Specifications

Pin No. Signal Function Signal Direction

2 RxD Receive data PC " This unit

3 TxD Transmission data This unit " PC

5 GND Signal ground

1, 4, 6 - 9 N/C

PC refers to the controller, such as a personal computer.

— —

Mode Non-synchronous

Character length 8 bit

Parity None

Start bit 1

Stop bit 1

Data rate 19200 bps

Data format Binary

—

TCP/IP Connection

Before controlling via LAN, it is necessary to establish connection of the TCP layer by a “3-way handshake”, followed by sending out “PJREQ” and authentication. If you are unable to complete sending within five seconds, or when “PJ_NG” or “PJNAK” is received, check the operating status of the projector, followed by performing the steps again starting from establishment of a TCP connection.

Others

receiving “PJACK” within five seconds after the projector sends out “PJ_OK” for connection

Command Format

The command between this unit and the computer consists of “Header”, “Unit ID”, “Command”, “Data” and “End”.

Header (1 byte), Unit ID (2 bytes), Command (2 bytes), Data (n bytes), End (1 byte)

Header

This binary code indicates the start of communication.

Binary Code Type Description

21 Operating command PC " This unit

3F Reference command PC " This unit

40 Response command

06 ACK This unit " PC (returns to PC after the command is accepted without

Unit ID

This is a code that specifies the unit. The binary code is fixed at “8901”.

Command and data

This unit " PC

error)

Operating command and data (binary code)

Command

0000

5057 Power

4950 Input When power is on

5243 Remote

Type Description

Connection check

supply

control

Check whether communication is enabled between this unit and the PC during standby.

During standby 31: Turns on the power When power is on 30: Turns off the power (Standby mode)

36: HDMI 1 37: HDMI 2

Sends the same code as the supplied remote control.

“Remote Control Code”P. 68

Reference command and data (binary code)

Command

5057 Power

4950 Input When power is on

Type Description

supply

End

This code indicates the end of communication. The binary code is fixed at “0A”.

During standby or when power is on 30: Standby mode 31: When power is on 32: In the Cool-down mode 34: When error occurs on

36: HDMI 1 37: HDMI 2

this unit

Others

Remote Control Code

Binary code is sent during communication.

following applies to the

The of the code.

case when the remote control code is “A”. In the case of “B”, add “36” to the beginning

Remote Control Button Name Binary Code

STAND BY 37 33 30 36

ON 37 33 30 35

HDMI 1 37 33 37 30

HDMI 2 37 33 37 31

INFO. 37 33 37 34

C.M.D. 37 33 38 41

LENS CONTROL 37 33 33 30

MEMORY MENU 37 33 44 34

MEMORY 1 37 33 44 38

MEMORY 2 37 33 44 39

LENS AP. 37 33 32 30

MPC 37 33 46 30

P.ANALYZER 37 33 35 43

HIDE 37 33 31 44

OK 37 33 32 46

37 33 30 31

37 33 30 32

37 33 33 34

37 33 33 36

Remote Control Button Name Binary Code

MENU 37 33 32 45

BACK 37 33 30 33

FILM 4 5 37 33 36 39

CINEMA 37 33 36 38

ANIME. 37 33 36 36

THX 4 5 37 33 36 46

USER 37 33 44 37

USER1 37 33 36 43

USER2 37 33 36 44

USER3 37 33 36 45

3D FORMAT 37 33 44 36

ADVANCED MENU 37 33 37 33

GAMMA 37 33 37 35

COLOR TEMP. 37 33 37 36

COLOR PROFILE 37 33 38 38

PIC. ADJ. 37 33 37 32

Others

Communications Example

This section shows the communication examples of RS-232C.

Operating command

Type Command Description

Connection check PC " This unit: 21 89 01 00 00 0A

This unit " PC: 06 89 01 00 00 0A

Power (On) PC " This unit: 21 89 01 50 57 31 0A

This unit "

Power (Off) PC " This unit: 21 89 01 50 57 30 0A

This unit "

Remote control (MENU)

PC " This unit: 21 89 01 52 43 37 33 32 45 0A This unit " PC: 06 89 01 52 43 0A

Reference command

Type Command Description

Power (On) PC " This unit: 3F 89 01 50 57 0A

This unit " PC: 06 89 01 50 57 0A This unit " PC: 40 89 01 50 57 31 0A

Input (HDMI 1) PC " This unit: 3F 89 01 49 50 0A

This unit " PC: 06 89 01 49 50 0A This unit " PC: 40 89 01 49 50 36 0A

PC: 06 89 01 50 57 0A

Connection check

When power is turned on from the Standby mode

When power is mode) from power-on mode

When the same operation as pressing the remote control is performed

When information state is acquired

When information on HDMI 1 input is acquired

turned off (Standby

[MENU] button on the

on the power-on

Others

Specifications

Product Name D-ILA Projector

Model Name DLA-X950RB, DLA-X750RB, DLA-X550RB*1

Display Panel/Size D-ILA device *2, 3

0.7" (1920 x 1080 pixels) x 3 (total no. of pixels: approx. 6.22 million)

Projection Lens 2.0 x power zoom lens (1.4:1 to 2.8:1), motorized zoom and focus

Light-source Lamp 265 W ultra-high pressure mercury lamp [product no.: PK-L2615U]

Average lifespan: 4500 hours (“Low” mode)

Screen Size Approx. 60" to 200" (Aspect ratio of 16:9)

Brightness 1900 lm 4

1800 lm 5 1700 lm 6

Projection Distance Refer to P. 71.

Input Compatibility Signal Refer to P. 73.

Display Resolution 3840 x 2160 pixels *4

Input Terminal HDMI Input Dual, HDMI 19-pin x 2 (HDCP 2.2-compatible) *5

Output Terminal Trigger Terminal 1 system, Ø 3.5 mm DC Power Jack (E)

DC OUT 12 V, 0.1 A

3D synchro Dedicated terminal for 3D SYNCHRO EMITTER (1 system, mini-DIN

3-pin)

Control Terminal RS-232C Terminal 1 system, D-sub 9-pin (male) (external control)

LAN Terminal 1 system, RJ-45 plug

Power Requirements AC 100 V to 240 V, 50 Hz/60 Hz

Power Consumption 380 W (during networked standby: 1.5 W *6, during standby: 0.4 W *7)

Operation Environment Temperature: 5°C to 35°C; humidity: 20% to 80%; storage

temperature: -10°C to 60°C

Installation Height Below 5,000 ft (1524 m)

Dimensions (Width x Height x Depth) Approx. 455 mm x 179 mm x 472 mm (excluding feet and protrusions)

Mass 15.6 kg (4 5)

15.4 kg (6)

Accessories Refer to P. 9.

*1 “B” indicates that the main unit is black in color.

*2 D-ILA is the abbreviation for Direct drive Image Light Amplifier.

*3 D-ILA devices are

Only 0.01% or less of the pixels are either missing or would remain permanently lit.

*4 During 3D playback, the pixel is set to 1920 x 1080.

*5 HDCP is the abbreviation for High-bandwidth Digital Content Protection system. The image of the HDMI input

terminal may not be displayed in some cases due to changes in the HDCP specifications.

*6 The power consumption of this product during networked standby when all wired network ports are connected

Others

is 1.5 W.

*7 “During standby” refers to Eco Mode standby (P. 55).

Design and specifications are subject to change without prior notice.

note that some of

Please to aid comprehension. Images may differ from the actual product.

manufactured using extremely high-precision technology with a pixel effectiveness of 99.99%.

the pictures and illustrations may have been abridged, enlarged or contextualized in order

For 4 5, a “THX 3D Display Certification” by THX has been obtained.

In addition to 2D movies, you can also enjoy faithful reproduction of images in a “quality as intended by the filmmaker” during playback of 3D movies.

The THX 3D certification is “an indication of high definition and high resolution”, which is granted to products that have cleared more than 400 image quality tests.

4 5 are isf-certified, so calibration can be performed by an isf-certified trainer. After calibration is performed, an isf mode is added to the Picture mode.

For more details, please refer to the isf website. http://www.imagingscience.com/

About Trademarks and Copyrights

HDMI, HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LCC.

“x.v.Color” and the “x.v.Color” logo are trademarks of Sony Corporation

Screen Size and Projection Distance

When a 16:9 screen is used

Screen Size Projection Distance

Diagonal (Model) Width (mm) Height (mm) Wide-end (m) Tele-end (m)

60 1328 747 1.78 3.66

70 1549 872 2.09 4.28

80 1771 996 2.4 4.89

90 1992 1121 2.7 5.51

100 2214 1245 3.01 6.13

110 2435 1370 3.31 6.75

120 2656 1494 3.62 7.36

130 2878 1619 3.92 7.98

140 3099 1743 4.23 8.60

150 3320 1868 4.53 9.22

160 3542 1992 4.84 9.84

170 3763 2117 5.14 10.45

180 3984 2241 5.45 11.07

190 4206 2366 5.75 11.68

200 4427 2490 6.06 12.30

Others

When a 4:3 screen is used

Screen Size Projection Distance

Diagonal (Model) Width (mm) Height (mm) Wide-end (m) Tele-end (m)

60 1219 914 2.22 4.49

70 1422 1067 2.60 5.24

80 1626 1219 2.98 6.00

90 1829 1372 3.36 6.75

100 2032 1524 3.74 7.51

110 2235 1676 4.11 8.26

120 2438 1829 4.49 9.02

130 2642 1981 4.87 9.77

140 2845 2134 5.25 10.53

150 3048 2286 5.63 11.28

160 3251 2438 6.00 12.04

* Projection to a 4:3 screen larger than 163" is equivalent to a size that is larger than 200" in the 16:9 format, and is

beyond our guarantee coverage.

When a 2.35:1 screen is used

Screen Size Projection Distance

Diagonal (Model) Width (mm) Height (mm) Wide-end (m) Tele-end (m)

60 1402 597 1.95 3.91

70 1636 696 2.28 4.56

80 1870 796 2.60 5.21

90 2103 895 2.93 5.86

100 2337 995 3.26 6.51

110 2571 1094 3.58 7.16

120 2805 1193 3.91 7.81

130 3038 1293 4.23 8.47

140 3272 1392 4.56 9.12

150 3506 1492 4.88 9.77

160 3740 1591 5.21 10.42

170 3973 1691 5.53 11.07

180 4207 1790 5.86 11.72

190 4441 1890 6.19 12.37

200 4674 1989 6.51 13.02

Others

Types of Possible Input Signals

4096

3840

2160

Display Area

Video

Digital Video Signal 480p, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz, 1080p/24

Hz, 1080p/50 Hz, 1080p/60 Hz, 3840×2160/24Hz, 3840×2160/25Hz, 3840×2160/30Hz, 3840×2160/50Hz*1, 3840×2160/60Hz*1, 4096×2160/24Hz*2, 4096×2160/25Hz*2, 4096×2160/30Hz*2, 4096×2160/50Hz*1, 2, 4096×2160/60Hz*1, 2

3D Signal Frame Packing 720p/50 Hz, 720p/60 Hz, 1080p/24 Hz

Side-by-side 1080i/60 Hz, 1080p/60 Hz, 1080i/50 Hz, 1080p/50 Hz, 1080p/24 Hz,

720p/50 Hz, 720p/60 Hz

Top-and-bottom 720p/50 Hz, 720p/60 Hz, 1080p/24 Hz

*1 When the color space is RGB/YCbCr(4:4:4), only 8-bit input is supported.

*2 The display image when the input signal is 4096×2160

PC signal (HDMI)

No. Designation Resolution fh [kHz] fv [Hz]

1 VGA 60 640×480 31.500 60.000 25.200 800 525 640 480

2 VGA 59.94 640×480 31.469 59.940 25.175 800 525 640 480

3 SVGA 60 800×600 37.879 60.317 40.000 1,056 628 800 600

4 XGA 60 1024×768 48.363 60.004 65.000 1,344 806 1,024 768

5 WXGA 60 1280×768 47.760 60.000 79.998 1,675 796 1,280 768

6 WXGA+ 60 1440×900 55.919 59.999 106.470 1,904 932 1,440 900

7 SXGA 60 1280×1024 63.981 60.020 108.000 1.688 1,066 1,280 1,024

8 WSXGA+ 60 1680×1050 65.222 60.002 147.140 2,256 1,087 1,680 1,050

* Even when signals can be input, video images may not be projected properly depending on the PC or cable in use.

When this occurs, switching in some cases.

to another compatible resolution or changing the cable may help to resolve the problem

dot CLK

[MHz]

Total No.

of Dots

[dot]

Total No.

of Lines

[line]

No. of

Effective

Dots [dot]

No. of

Effective

Lines

[line]

Others

Indicator Display on the Main Unit

The indicator appears blinking.

The indicator lights up.

LAMP WARNING

STANDBY/ON

LAMP WARNING

STANDBY/ON

LAMP WARNING

STANDBY/ON

LAMP WARNING

STANDBY/ON

LAMP

WARNING

STANDBY/ON

LAMP WARNING

STANDBY/ON

When the video image is temporarily hidden (HIDE is on)

During projection

All lights off

In the Cool-down mode

“STANDBY/ON” blinking (red)

During lamp startup

“STANDBY/ON” lights up (green)

In standby state

“STANDBY/ON” lights up (red)

“STANDBY/ON” blinking (green)

LAMP WARNING

STANDBY/ON

“LAMP” lights up (orange)

When lamp replacement is near

Meaning of the lighting figures

Operation mode display

Displays using the different colors and solid/blinking light of the “STANDBY/ON” indicator.

Estimated timing for lamp replacement

Displays using the solid/blinking light of the “LAMP” indicator. The “STANDBY/ON” indicator, which shows the operating mode of the unit, is displayed simultaneously as described above.

Others

Warning display

LAMP WARNING

STANDBY/ON

(Red)(*)Mode

Display

LAMP WARNING

STANDBY/ON

Blinking

Simultaneously

(Red)

(Orange)

Mode

Display

LAMP WARNING

STANDBY/ON

(Red)

(Orange)

Mode

Display

You can tell the details of a warning from the (repeated) displays of the “WARNING” and “LAMP” indicators. The “STANDBY/ON” indicator, which shows the

The Warning mode is activated once the message is displayed. Projection is interrupted, and the cooling fan is turned on for about 100 seconds.

The power cannot be turned on again while cooling is in progress. Check the following after cooling is complete.

operating mode of the unit, is displayed simultaneously as described above.

Indicator Status (Solid/Blinking)

Blinking

Frequency

Description Check and Countermeasure

x1 Abnormality in the power supply

x2 Cooling fan stopped abnormally

x3 Internal temperature is abnormally

high

x4 External temperature is too high

x5 Abnormal circuit operation

Check that nothing is blocking the air inlets.

Check that the external temperature is normal.

Countermeasure: Leave the unit unoperated until it cools down. After

that,

turn

the

power again.

x1 Abnormal circuit operation

x4 Abnormal operation of the lens

cover

Check that nothing is blocking the lens cover.

Countermeasure: Turn on the power again.

x1 Lamp does not light up and unit is

unable to project

x2 Lamp goes out during projection

x3 When the lamp cover is removed

Check that the lamp unit and lamp cover are correctly installed.

Countermeasure: Turn on the power again.

If the Warning mode is activated again, wait for the cooling fan to stop, followed by pulling out the power plug from the outlet. Request for repair at your authorized dealer or a nearby service center.

(*) If the scheduled time for lamp replacement is exceeded, the indicator may light up.

Others

Dimensions

472

455

Lens

Ø60

103.5

178.5

227.5

Lens Center

33759

91 290

Lens

92110

32 110

Lamp Cover

(Unit: mm)

Top Surface

Front

Bottom Surface

Rear Surface

Others

The dimensions are identical for all the models.

Index

Accessories ........................................................... 9

Adjusting Distortion of the Projection Screen ....... 23

Adjustment and Setting by the Menu ................... 41

Adjustment of the Image Quality

ADVANCED MENU ............................................. 13

Anamorphic ......................................................... 50

Aspect ................................................................. 27

Back Color ........................................................... 54

Brightness ............................................................ 45

Ceiling Mount ....................................................... 16

Cleaning and Replacing the Filter

Clear Black .......................................................... 43

Clear Motion Drive

Clear Motion Drive ............................................... 39

Color Density ....................................................... 46

Color Management .............................................. 33

COLOR P.FILE .................................................... 31

Color Profile ......................................................... 31

Color Shade ......................................................... 46

Color Space ......................................................... 46

Color Temperature ............................................... 44

Connection .......................................................... 18

Contrast ............................................................... 45

Controls and Features ......................................... 10

Custom Gamma ................................................... 37

Dimensions .......................................................... 76

Display Position ................................................... 47

Eco Mode ............................................................ 55

External Control ................................................... 66

Filter Product no. ................................................. 60

Filter Replacement

Focus ................................................................... 24

Frame Interpolation .............................................. 39

Frame Packing

GAMMA ............................................................... 36

Gamma Adjustment ............................................. 36

HDMI Color Space ............................................... 46

HDMI Input Level

HDMI Input Terminal ............................................ 18

HIDE .................................................................... 21

High Altitude Mode

Indicator Display .................................................. 74

INFO .................................................................... 13

Input Resolution ............................................. 56, 73

............................................... 39

...............................................

..................................................... 29

................................................. 46

.............................................. 50

.......................... 43

........................ 60

Input Signal .................................................... 56, 73

Input terminals ..................................................... 12

Installation Method

Installing the 3D Syncro Emitter ...........................

Keystone Correction ............................................ 50

Lamp ..................................................................... 9

Lamp Power

Lamp Time ........................................................... 56

Language Selection

Lens ..................................................................... 10

LENS AP. ............................................................. 13

Lens Aperture ................................................ 40, 43

Lens Control ........................................................ 23

Lens cover ........................................................... 10

Lens Cover ............................................................ 9

Lens Memory ....................................................... 23

Lens Shift ............................................................. 23

Line Display ......................................................... 54

Logo Display ........................................................ 54

Menu Items .......................................................... 41

Menu Position ...................................................... 54

MPC LEVEL ......................................................... 34

Network ............................................................... 55

NR ....................................................................... 45

Off Timer

Optional Accessories .............................................

P.ANALYZER ...................................................... 13

PIC. ADJ.

Picture Mode ....................................................... 30

Picture Tone

Pixel Adjustment .................................................. 49

Precautions during Installation ............................. 15

Progressive .......................................................... 47

Projection Distance .............................................. 71

Remote Control ................................................... 13

Replacing the Lamp ............................................. 57

Resetting the Lamp .............................................. 56

RGB ..................................................................... 46

RS-232C

Screen Correction ................................................ 26

Screen Mask ........................................................ 47

Screen Size and Projection Distance ................... 71

Shadow/Highlight Correction ...............................

Shift ..................................................................... 24

.............................................................. 54

............................................................. 45

.............................................................. 19

.............................................. 15

......................................................... 43

............................................. 54

........................................................ 44

Others

Side by Side ........................................................ 29

Signal Display ...................................................... 56

Software Ver. ....................................................... 56

Specifications ...................................................... 70

THX ..................................................................... 71

Top and Bottom ...................................................

Trigger ................................................................. 54

Troubleshooting ................................................... 61

User Name Edit ................................................... 43

When the following messages appear... .............. 65

Zoom ................................................................... 24

Symbol

3D Crosstalk Cancel

3D Format ............................................................ 29

3D Glasses ...................................................... 9, 28

3D Setting ............................................................

3D Synchro Emitter .......................................... 9, 28

............................................ 29

Viewing 3D Movies ..............................................

Viewing Videos

.................................................... 21

Others

DLA-X950R

DLA-X750R

DLA-X550R

D-ILA PROJECTOR

JVC DLA-X550R, DLA-X950R, DLA-X750R User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Precautions

Getting Started

Accessories/Optional Accessories

Check the Accessories

Optional Accessories

Controls and Features

Main Unit - Front

Main Unit - Bottom

Main Unit - Rear

Main Unit - Input Terminals

Remote Control

Loading Batteries into the Remote Control

Effective Range of Remote Control Unit

Installing the Projector

Precautions during Installation

Set up

Precautions during Mounting

Adjusting the Position

Connecting the Projector

Connecting to the HDMI Input Terminal (Digital Input)

Connecting to the LAN Terminal

Connecting to the RS-232C Terminal

Connecting to the TRIGGER Terminal

Connecting the Power Cord (Supplied Accessory)

Viewing Videos

Operate

Adjusting the Projector Screen

Adjusting the Lens According to the Projection Position

Saving and Retrieving Adjustment Settings

Setting Screen Correction

Adjusting the Screen Size (Aspect)

Viewing 3D Movies

Installing the 3D SYNCHRO EMITTER

Viewing 3D Movies

Adjusting 3D Movies

Setting the Picture Mode

Adjust/Set

Setting the Color Profile

Adjusting to the Preferred Color (Color Management)

Fine-tuning the Image Quality

Adjusting the Output Value of the Projected Image (Gamma)

Fine-tuning to the Preferred Gamma Setting

Reducing the After-image of Fast-moving Images (Blur Reduction)

Viewing High Contrast Images (Lens Aperture)

Adjustments and Settings in the Menu

List of Menu Items

Picture Adjust

Input Signal

Installation

Display Setup

Function

Information

Replacing the Lamp

Lamp Replacement Procedure

Maintenance

Resetting the Lamp Time

Maintaining the Cabinet and Remote Control

Cleaning and Replacing the Filter

Troubleshooting

Troubleshooting

When the following messages appear...

External Control

RS-232C Specifications

TCP/IP Connection

Others

Command Format

Remote Control Code

Communications Example

Specifications
