JVC DLA-HX2E, DLA-HX2U User Manual

®

®

PROJECTOR

DLA-HX2U/DLA-HX2E

OPERATE

PC VIDEO

W

DIGITAL

V-KEYSTONE H-KEYSTONE

SCREEN

ZOOM

S

FREEZE

VOLUME

FOCUS

QUICK ALIGN.

MENU EXIT

ENTER

PRESET HIDE

INSTRUCTIONS

For customer Use:

Enter below the Serial No. which is located
on the side panel of the cabinet. Retain
this information for future reference.

Model No.

DLA-HX2U

Serial No.

SAFETY PRECAUTIONS

IMPORTANT INFORMATION

NOTICE (For USA)

Language for Manuals of Products using HID Lamps
(that contains mercury)

This product has a High Intensity Discharge (HID) lamp that
contains a small amount of mercury. It also contains lead in
some components.
Disposal of these materials may be regulated in your com­munity due to environmental considerations. For disposal or
recycling information please contact your local authorities,
or the Electronics Industries Alliance: http://www.eiae.org.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EX­POSE THIS APPLIANCE TO RAIN OR MOISTURE.

WARNING:

THIS APPARATUS MUST BE EARTHED.

CAUTION:

To reduce the risk of electric shock, do not remove cover.
Refer servicing to qualified service personnel.

This projector is equipped with a 3-blade grounding type
plug to satisfy FCC rule. If you are unable to insert the plug
into the outlet, contact your electrician.

FCC INFORMATION (U.S.A. only)

CAUTION:

Changes or modification not approved by JVC could void
the user’s authority to operate the equipment.

NOTE:

This equipment has been tested and found to comply with
the limits for Class B digital devices, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide rea­sonable protection against harmful interference in a resi­dential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful in­terference to radio communications. However, there is no
guarantee that interference will not occur in a particular in­stallation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encourage to
try to correct the interference by one or more of the follow­ing measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and re­ceiver.

• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician
for help.

About burning-in of the D-ILA device

Do not allow the same still picture to be projected for a long
time or an abnormally bright video picture to be projected.
Do not project video images with high-intensity or high contrast
on a screen. The video image could be burnt into the D-ILA
device.
Use special care when projecting video games or computer pro­gram images. There is no problem with ordinary video-cassette
playback images.

About the installation place

Do not install the projector in a place that cannot support its
weight securely.
If the installation place is not sturdy enough, the projector could
fall or overturn, possibly causing personal injury.

IMPORTANT SAFEGUARDS

Electrical energy can perform many useful functions. This unit
has been engineered and manufactured to assure your per­sonal safety. But IMPROPER USE CAN RESULT IN POTEN-
TIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order not
to defeat the safeguards incorporated into this product, observe
the following basic rules for its installation, use and service.
Please read these Important Safeguards carefully before use.
– All the safety and operating instructions should be read be-

fore the product is operated.

– The safety and operating instructions should be retained for

future reference.

– All warnings on the product and in the operating instructions

should be adhered to.
– All operating instructions should be followed.
– Place the projector near a wall outlet where the plug can be

easily unplugged.
– Unplug this product from the wall outlet before cleaning. Do

not use liquid cleaners or aerosol cleaners. Use a damp cloth

for cleaning.
– Do not use attachments not recommended by the product

manufacturer as they may be hazardous.
– Do not use this product near water. Do not use immediately

after moving from a low temperature to high temperature, as

this causes condensation, which may result in fire, electric

shock, or other hazards.
– Do not place this product on an unstable cart, stand, or table.

The product may fall, causing serious injury to a child or adult,

and serious damage to the product. The product should be

mounted according to the manufacturer’s instructions, and

should use a mount recommended by the manufacturer.
– When the product is used on a cart, care should be taken

to avoid quick stops, excessive force, and

uneven surfaces which may cause the prod-

uct and cart to overturn, damaging equip-

ment or causing possible injury to the op-

erator.

PORTABLE CART WARNING

(symbol provided by RETAC)

S3126A

MACHINE NOISE INFORMATION (Germany only)

Changes Machine Noise Information Ordinance 3.
GSGV, January 18, 1991: The sound pressure level at the
operator position is equal or less than 70 dB (A) according
to ISO 7779.

2

Safety Precaution

– Slots and openings in the cabinet are provided for ventilation.

These ensure reliable operation of the product and protect it
from overheating. These openings must not be blocked or
covered. (The openings should never be blocked by placing
the product on bed, sofa, rug, or similar surface. It should not
be placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided and the manufacturer’s
instructions have been adhered to.)
For proper ventilation, separate the product from other equip­ment, which may prevent ventilation and keep a distance of
more than 11-7/8" (30 cm).

– This product should be operated only with the type of power

source indicated on the label. If you are not sure of the type of
power supply to your home, consult your product dealer or
local power company.

– This product is equipped with a three-wire plug. This plug will

fit only into a grounded power outlet. If you are unable to in­sert the plug into the outlet, contact your electrician to install
the proper outlet. Do not defeat the safety purpose of the
grounded plug.

–Power-supply cords should be routed so that they are not

likely to be walked on or pinched by items placed upon or
against them. Pay particular attention to cords at doors, plugs,
receptacles, and the point where they exit from the product.

–For added protection of this product during a lightning storm,

or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the cable
system. This will prevent damage to the product due to light­ning and power line surges.

– Do not overload wall outlets, extension cords, or convenience

receptacles on other equipment as this can result in a risk of
fire or electric shock.

–Never push objects of any kind into this product through open-

ings as they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.

– Do not attempt to service this product yourself as opening or

removing covers may expose you to dangerous voltages and
other hazards. Refer all service to qualified service person­nel.

– Unplug this product from the wall outlet and refer service to

qualified service personnel under the following conditions:
a) When the power supply cord or plug is damaged.
b) If liquid has been spilled, or objects have fallen on the

product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the Operation Manual, as an improper adjust-

ment of controls may result in damage and will often re-

quire extensive work by a qualified technician to restore

the product to normal operation.
e) If the product has been dropped or damaged in any way.
f) When the product exhibits a distinct change in performance

- this indicates a need for service.

– When replacement parts are required, be sure the service

technician has used replacement parts specified by the manu­facturer or with same characteristics as the original part. Un­authorized substitutions may result in fire, electric shock, or
other hazards.

– Upon completion of any service or repairs to this product, ask

the service technician to perform safety checks to determine
that the product is in proper operating condition.

– The product should be placed more than one foot away from

heat sources such as radiators, heat registers, stoves, and
other products (including amplifiers) that produce heat.

– When connecting other products such as VCR’s, and per-

sonal computers, you should turn off the power of this prod­uct for protection against electric shock.

– Do not place combustibles behind the cooling fan. For ex-

ample, cloth, paper, matches, aerosol cans or gas lighters
that present special hazards when over heated.

– Do not look into the projection lens while the illumination lamp

is turned on. Exposure of your eyes to the strong light can
result in impaired eyesight.

– Do not look into the inside of this unit through vents (ventila-

tion holes), etc. Do not look at the illumination lamp directly
by opening the cabinet while the illumination lamp is turned
on. The illumination lamp also contains ultraviolet rays and
the light is so powerful that your eyesight can be impaired.

– Do not drop, hit, or damage the light-source lamp (lamp unit)

in any way. It may cause the light-source lamp to break and
lead to injuries. Do not use a damaged light source lamp. If
the light-source lamp is broken, ask your dealer to repair it.
Fragments from a broken light-source lamp may cause inju­ries.

– The light-source lamp used in this projector is a high pres-

sure mercury lamp. Be careful when disposing of the light­source lamp. If anything is unclear, please consult your dealer.

– Do not ceiling-mount the projector to a place which tends to

vibrate; otherwise, the attaching fixture of the projector could
be broken by the vibration, possibly causing it to fall or over­turn, which could lead to personal injury.

– Use only the accessory cord designed for this product to pre-

vent shock.
The power supply voltage rating of this product is AC 120 V,
AC 100 V - AC 240 V, the power cord attached conforms to
the following power supply voltage. Use only the power cord
designated by our dealer to ensure Safety and EMC.
When it is used by other power supply voltage, power cable
must be changed.
Ensure that the power cable used for the projector is the cor­rect type for the AC outlet in your country.
Consult your product dealer.

Power cord

For United
Kingdom

Power cord

Power supply voltage: AC 120 V

For European
continent countries

*DO NOT allow any unqualified person to install the unit.

Be sure to ask your dealer to install the unit (e.g. attaching it
to the ceiling) since special technical knowledge and skills
are required for installation.
If installation is performed by an unqualified person, it may
cause personal injury or electrical shock.

3

Safety Precaution

POWER CONNECTION

WARNING:

Do not cut off the main plug from this equipment.

If the plug fitted is not suitable for the power points in your
home or the cable is too short to reach a power point, then
obtain an appropriate safety approved extension lead or
adapter or consult your dealer.
If nonetheless the mains plug is cut off, remove the fuse
and dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the main supply.
If a new main plug has to be fitted, then follow the instruc­tion given below:

WARNING:

THIS APPARATUS MUST BE EARTHED. IMPORTANT:
The wires in the mains lead on this product are colored in
accordance with the following cord:
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As these colors may not correspond with the colored mak­ing identifying the terminals in your plug, proceed as fol­lows:

The wire which is colored green-and-yellow must be connected
to the terminal which is marked with the letter E or the safety
earth or colored green or green-and-yellow.
The wire which is colored blue must be connected to the termi­nal which is marked with the letter N or colored black.
The wire which is colored brown must be connected to the ter­minal which is marked with the letter L or colored red.
When replacing the fuse, be sure to use only a correctly rated
approved type, re-fit the fuse cover.

IF IN DOUBT —— CONSULT A COMPETENT ELECTRICIAN.
How To Replace The Fuse

Open the fuse compartment with the blade screwdriver, and
replace the fuse.
(* An example is shown in the illustration below.)

POWER CONNECTION (United Kingdom only)

WARNING:

Do not cut off the main plug from this equipment.

If the plug fitted is not suitable for the power points in your
home or the cable is too short to reach a power point, then
obtain an appropriate safety approved extension lead or
adapter or consult your dealer.

If nonetheless the mains plug is cut off, remove the fuse
and dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the main supply.

If a new main plug has to be fitted, then follow the instruc­tion given below:

WARNING:

THIS APPARATUS MUST BE EARTHED.

IMPORTANT:

The wires in the mains lead on this product are coloured in
accordance with the following cord:
Green-and-yellow : Earth
Blue : Neutral
Brown : Live

As these colours may not correspond with the coloured mak­ing identifying the terminals in your plug, proceed as fol­lows:

The wire which is coloured green-and-yellow must be con­nected to the terminal which is marked
or the safety earth or coloured green or green-and-yellow.

The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.

When replacing the fuse, be sure to use only a correctly
rated approved type, re-fit the fuse cover.

with the letter E

IF IN DOUBT —— CONSULT A COMPETENT

ELECTRICIAN.

How To Replace The Fuse

Open the fuse compartment with the blade screwdriver, and
replace the fuse.
(* An example is shown in the illustration below.)

Fuse

4

Caution

About burning-in of the D-ILA device

● Do not allow the same still picture to be projected for a
long time or an abnormally bright video image to be pro­jected.

Do not project video images with high-intensity or high con­trast on a screen. The video image could be burnt into the
D-ILA device.
Use special care when projecting video games or computer
program images.
There is no problem with ordinary video cassette playback
images.

Viewing conditions

● Brightness of the room

Please avoid having sunshine or light shine directly onto the
screen. Images can only be well projected if the room is
dark.

● Do not view the screen continually for a long time

Looking at the screen continually for a long time will cause
your eyes to be tired. Please rest your eyes sometimes.

● Image flicker due to installation condition or the environ­ment

Please do not view flickering images for too long as this
causes poor eyesight.

Using the projector

● Remove the Lens Cap when using the projector

Please use the projector after removing the lens cap.
The cap may become deformed and this unit may break
down due to heat.

How to use the [SCREEN TRIGGER] terminal cable

● It may cause short circuit if the supplied [SCREEN TRIG­GER] terminal cable is used directly. When using the ca­ble, connect it to the screen before connecting to this
unit.

The [SCREEN TRIGGER] terminal of this unit outputs a DC
+12 V / max. 100 mA signal. Short circuit will result in dam­age, fire or electrical shock.

● Leave the connection of the screen to the installation
contractor.

It will result in damage, fire or electrical shock.

Care

● Dirt in the cabinet

Please wipe the cabinet clean with a soft cloth. In case of
heavy soiling, please wipe it with a damp cloth soaked with
a neutral detergent.

● Since the cabinet may in time, get damaged or deterio­rate in condition, (e.g. peeling paint):

• Do not wipe with a stiff cloth.

• Do not wipe with force.

• Do not wipe with thinner or benzene.

• Do not spray chemicals like insecticide.

• Do not allow it to come into contact with rubber or vinyl

materials for an extended period of time.

● Cleaning the lens

• Please use lens-cleaning paper (of the kind for cleaning

spectacles, cameras etc) sold in the market for cleaning.

• Please do not use liquid-type cleansers as it may cause

the coating mask on the surface to peel off.

• Please do not knock the surface of the lens as it damages

easily.

Using the screen mode switch function

• This projector is equipped with a screen mode switch function that sets the screen size (aspect ratio and resize). If the set
screen aspect ratio and size differs from that of the inputted images (e.g. images from TV programs), the projected image
screen will differ from the original. Please bear this in mind when you choose the screen mode.

• Please keep in mind that making use of the screen mode switch function to alter screen images (aspect ratio and resize) in
restaurants/ hotels etc, for public viewing, in the pursuit of profit may constitute an infringement of the Copyright Act.

5

Contents

SAFETY PRECAUTIONS ............................................ 2

Caution ........................................................................ 5

Accessories ................................................................ 6

Controls and Features ............................................... 7

Front Side/ Top Surface/ Left Side ......................................... 7

Rear Side/ Right Side/ Bottom Surface ..................................8

Connector Panel .................................................................... 9

Control Panel on the Projector ............................................. 10

Indicator Display on the Control Panel ................................ 10

Remote Control Unit ............................................................. 12

Loading Batteries into the Remote Control ..........................14

Installing the Projector ............................................ 15

Precautions for Installation ................................................... 15

Installing the Projector against the Screen .......................... 16

Mounting the Projector ......................................................... 16

Projection Distance and Screen Size................................... 17

Effective Range and Distance of the

Remote Control Unit ............................................................. 18

Connecting to Various Devices............................... 19

Signals that can be input into the Projector .........................19

Connecting to Devices......................................................... 21

Connecting the Power Cord (supplied) ............................... 24

Basic Operations...................................................... 25

Basic Operation Procedures................................................ 25

1. Power On .................................................................... 25

2. Selecting the image to be projected .......................... 25

3. Adjusting the Zoom Ring (the screen size) ................ 26

4. Adjusting the Focus Ring (Focus) .............................. 26

5. Adjusting the Sound Volume....................................... 27

6. Power Off .................................................................... 27

Frequently used Convenient Functions ............................... 28

Enlarging the Image ....................................................... 28

Turning Off Image and Sound......................................... 29

Displaying a Still Picture ................................................. 29

Removing the Trapezoidal Distortion of the Image ......... 30

Using the Quick Alignment function ............................... 31

Adjustments and Settings Using Menus ............... 32

The Menu Structure.............................................................. 32

The Menu Operation Buttons ...............................................35

The Procedure for Menu Operation ..................................... 36

The Menu Configuration....................................................... 37

1 “Image adj.” menu ...................................................... 37

2 “Color temp.” menu .................................................... 37

3 “Set up” menu ............................................................ 37

4 “Position” menu .......................................................... 38

5 “Aspect ratio” menu ................................................... 38

6 “Decoder” menu ......................................................... 38

7 “Resize” menu ............................................................ 38

8 “Logo” menu ............................................................... 38

9 “Capture menu” .......................................................... 38

p “Capture start” ............................................................ 39

q “Options” menu (“Page 1”) ......................................... 39

w “Color profile” menu ................................................... 39

e “Options” menu (“Page 2”) ......................................... 39

r “Language” menu ...................................................... 39

t “Information” menu ..................................................... 40

Setting “Aspect ratio” and “Resize” ....................... 41

Setting the “Aspect ratio” ..................................................... 41

Setting the “Resize” ............................................................. 43

Editing and Projecting Logo ................................... 45

Replacing the Lamp ................................................. 47

The light source lamp and its lamp time .............................. 47

The procedure for lamp replacement ..................................47

Resetting the lamp time ....................................................... 49

Cleaning and Replacing the Filter .......................... 50

Troubleshooting ....................................................... 51

What to do when these messages are displayed....

53

Warning Indication ................................................... 55

Specifications ........................................................... 56

Accessories

The following accessories are packed together with this projector.
Please confirm all items. If any item is missing, please contact your dealer.

Quick Guide ........................................................................................................................................ x 1

Instructions (CD-ROM) .......................................................................................................................x 1

Guarantee ...........................................................................................................................................x 1

Power Cord ......................................................................................................................................... x 1

Remote Control (RM-MSX21G) ..........................................................................................................x 1

[AA/R6]-size Battery (for operation confirmation) ...............................................................................x 2

AV connection cable (approximately 2 m: RCA Pin Plug) ...................................................................x 1

[SCREEN TRIGGER] terminal cable* ................................................................................................. x 1

* Cable for controlling roll-up screen that supports [SCREEN TRIGGER]. Connect the connector of the cable to the [SCREEN

TRIGGER] terminal of this unit. Consult the installation contractor for connection to the screen.
In addition, read ‘How to use the [SCREEN TRIGGER] terminal cable’ on page 5 when using the cable.

 Optional Accessories

❈ Please ask your authorized dealer for the details.

• Replacement lamp (lamp unit) BHL5006-S

• Replacement filter

Inner filter : LC32058-001C
Lower filter : LC32087-002A

6

Controls and Features

Front Side/ Top Surface/ Left Side

1 Control Panel

p Zoom Ring

9 Focus Ring

2 AC Power Input

Te r minal

3 Carrying Handle

4 Foot Lever

Using the Carrying Handle

1 Control Panel

For details, See ‘Control Panel on the Projector’.
(☞ page 10, 11)

2 AC Power Input Terminal

This is where the supplied power cord is connected to.
(☞ page 24)

3 Carrying Handle

Use this handle when carrying the projector.

4 Foot Lever (for front adjustable foot)

Use when extending and retracting the front foot.
(☞ page 15)

8 Remote Sensor (Front)

7 Air Inlet
4 Foot Lever

(for front adjustable foot)

6 Lens Cap

5 Lens

(for front adjustable foot)

7 Air Inlets (on the front, right, and bottom side of

projector)

The air inlets absorb air to cool the internal components of
the projector. Do not block or allow warm air to blow into
them as it may cause damage.

• The air inlet filter on the right side cannot be removed.
Please clean the filter regularly with, for example, a
vacuum cleaner.

8 Remote Sensor (Front)

When operating with the remote control, aim it towards this
sensor. (☞ page 18)

•A remote sensor is also provided at the rear of the pro­jector.

5 Lens

The lens is a 1.3 x (zoom ratio) manual zoom lens.
Before projection, remove the lens cap. (☞ page 17, 24)

6 Lens Cap

It is recommended that the cap be fitted on the lens to pre­vent it from becoming dirty when the projector is not in use.
(☞ page 24)

9 Focus Ring

Used to manually focus the projected image on the screen.
(☞ page 26)

p Zoom Ring

Used to manually zoom the projected image on the screen.
(☞ page 26)

7

Controls and Features

Rear Side/ Right Side/ Bottom Surface

q Connector Panel

w Speaker

7 Air Inlet

e Lamp Cover

t Remote Sensor (Rear)

r Exhaust Vent

Bottom Surface

y Front Adjustable

Foot

7 Air Inlet

q Connector Panel

For details, refer to ‘Connector Panel’. (☞ page 9)

w Speaker

Built-in speaker located here.

e Lamp Cover

Remove this cover when replacing the lamp. (☞ page 47)

r Exhaust Vent

Warm air is expelled through these vents to keep the sys­tem cool. Please do not block the exhaust vents.

u Filter

i Rear Fixed

Foot

Blocked as it is not in use.
Opening it forcibly will cause
damage to the machine.

t Remote Sensor (Rear)

When operating with the remote control, aim it towards this
sensor. (☞ page 18)

•A remote sensor is also provided at the front of the pro­jector.

y Front Adjustable Foot (for adjusting the height and

angle)

It is set at the lowest position when shipped from the fac­tory. The foot can be adjusted to a maximum angle of +6°
and a maximum length of 31 mm. (☞ page 15)

u Filter

Cleans air drawn in from the air inlet. Please clean the filter
regularly with e.g., a vacuum cleaner. (☞ page 50)

i Rear Fixed Foot

8

Connector Panel

Controls and Features

1 [PC2] Input Terminal

PR/C

R

R

SCREEN

TRIGGER

Y

G

AUDIO IN

4 [SCREEN

TRIGGER]
Te r minal

5 [AUDIO IN]

Te r minal

1 [PC2] Input terminal (BNC x 5)

This is an input terminal for component signals (Y, CB, CR)
or DTV-format (Y, P
ponent signal output terminals can be connected. This ter­minal can also be used as multipurpose video input termi­nals that allow input of the following signals: analog RGB
signals, vertical sync (V) signals, and horizontal sync (H)
signals/ composite signals (Cs). Devices which have ana­log RGB signals output terminals can be connected.
(☞ page 21, 22)
To use this terminal, the “PC2(BNC)” item in the “Options”
menu must be set correctly according to the input signals.
(☞ page 39)

• Input of external sync signals is automatically detected.
Detection of H/V signals or Cs signals causes automatic
switching to external sync. The priority order is H/V>Cs.

• When computer signals are input, the uppermost edge
of the image may appear to bow if the sync signal input is
a composite sync (Cs) or G on sync signal. In this case,
please use separate sync signals for vertical sync (V)
and horizontal sync (H).

• Input signals of 720p (50Hz) are not supported.

B, PR) signals. Devices which have com-

2 [PC1] Input terminal (D-sub 3 rows 15 pin)

This is an input terminal dedicated to computer signals (RGB
Video signals and sync signals).
Connect the display output terminal of the computer to this
terminal. When a Macintosh computer is to be connected,
please use the conversion adapter (sold separately) for Mac.
(☞ page 22)

• When computer signals are input, the uppermost edge
of the image may appear to bow if the sync signal input is
a composite sync (Cs) or G on sync signal. In this case,
please use separate sync signals for vertical sync(V) and
horizontal sync(H).

3 [PC3] Input terminal (DVI-D 24 Pin Single)

HDCP compatible video signals (480p, 576p, 720p 50/59/
60 Hz, 1080i 50/59/60 Hz) and input terminal for personal
computer (PC) signal. Connect the display output terminal
of the computer to this terminal. (☞ page 22)

• The menu screen for HDCP compatible signal input is
the same as when PC input is selected.

PB/C

B

B

PC2

REMOTE

6 [REMOTE]

Te r minal

4 [SCREEN TRIGGER] Terminal

5 [AUDIO IN] (audio) Terminal (mini jack)

6 [REMOTE] Terminal (stereo mini jack)

7 [CONTROL RS232C IN/OUT] Terminal

8 [Y/C] Input Terminal (Mini DIN 4 Pin)

9 [VIDEO] Input Terminal (RCA pin jack)

2 [PC1] Input Terminal

VDVIH/C

S

PC1

RS-232C OUT RS-232C IN Y/C VIDEO

CONTROL VIDEO IN

3 [PC3] Input Terminal

PC3

8 [Y/C] Input

Te r minal

7 [CONTROL RS232C

IN/OUT] Terminal

The signal output for controlling roll-up screen that sup­ports [SCREEN TRIGGER]. Outputs DC 12 V / max. 100 mA
when power is on.
(Tip = DC +12 V, Sleeve = Gnd)

Before using the supplied cable, read ‘How to use the
[SCREEN TRIGGER] terminal cable’ on page 5.

This is the audio input terminal for devices connected to
[PC1], [PC2], [PC3], [VIDEO] or [Y/C]. Connect the audio
output terminal of the device to this terminal.
(☞ page 21, 22)

• When [PC1], [PC2], [PC3], [VIDEO] or [Y/C] input is be­ing selected, the inputted audio signals will be reproduced
by the projector speaker.
(Audio output for this projector is monaural.)

When the remote control is unable to work due to rear pro­jection etc., the [REMOTE] terminal can be used to connect
an external sensor to the projector. The external sensor is
not generally sold. Please check with your authorized dealer.

(D-sub 9 Pin)

This is the RS-232C interface-specific terminal. The pro­jector can be controlled by a computer connected exter­nally. More than one projector can be controlled using both
the [RS-232C IN] and [RS-232C OUT] terminals.
(☞ page 23)

•For details, please check with your dealer.

This is the input terminal for Y/C (S-Video) signals. Con­nect this terminal to the S-video output terminal of a video
deck, etc. (☞ page 21)

This is an input terminal for composite video signals. Con­nect this terminal to the composite video output terminal of
a VCR, etc. (☞ page 21)

9 [VIDEO] Input

Te r minal

9

Controls and Features

Control Panel on the Projector

8 [TEMP] indicator
9 [LAMP] indicator

p [VIDEO] button
q [PC] button

w [H-KEYSTONE] button

e [V-KEYSTONE] button

r [MENU] button
t Cursor button

(

 /  /  / )

y [PRESET] button

LAMP

PC

V-KEYSTONE

MENU

PRESET

STAND BY

TEMP

OPERATE

VIDEO

H-KEYSTONE VOL.

EXIT

ENTER

HIDE

1 [STAND BY] indicator

2 [OPERATE] indicator

3 [OPERATE] button

4 [VOL.] (volume) button

5 [EXIT] button

6 [ENTER] button

7 [HIDE] button

Indicator Display on the Control Panel

Stand-by, operate and cool down modes, together with other operational activities are indicated by differing combinations of Indica­tors appearing on the Control Panel.

• Please refer to Page 47 for explanations on warning indication for *

1

, and Page 55 for *2.

[STAND BY] light on

Projector is in stand by mode

STAND BY

LAMP TEMP

[LAMP] blinking*

Lamp life has expired
(Lamp time over 2000 hours)

LAMP TEMP

OPERATE

1

STAND BY

OPERATE

[LAMP] and [OPERATE] blinking
simultaneously*

Lamp has turned off during projection

LAMP TEMP

[TEMP] blinking*

Internal temperature is abnormally high
(Abnormal internal temperature)

LAMP TEMP

1, *2

STAND BY

OPERATE

2

STAND BY

OPERATE

[OPERATE] light on

Projector is in operate mode
(In operation/ during projection)

LAMP TEMP

[LAMP] light on*

The time to replace the lamp is near
(Lamp usage time over 1900 hours)

LAMP TEMP

[LAMP] and [TEMP] blinking*

Circuits are not functioning properly
(Abnormal circuit functioning)

LAMP TEMP

STAND BY

OPERATE

1

STAND BY

OPERATE

2

STAND BY

OPERATE

[TEMP] and [STAND BY] blinking*

Temperature at exhaust vents is high
(Abnormal external temperature)

STAND BY

LAMP TEMP

OPERATE

[STAND BY] blinking

Projector is in cool down mode
(when cooling lamp)

STAND BY

LAMP TEMP

OPERATE

[LAMP] and [STAND BY] blink-

2

ing*

Lamp does not light up and projector is unable
to project

LAMP TEMP

STAND BY

OPERATE

[LAMP] and [OPERATE] blinking
alternately*

Lamp cover has been removed

LAMP TEMP

2

All blinking*

When inner fan has stopped (fan lock)

LAMP TEMP

2

STAND BY

OPERATE

2

STAND BY

OPERATE

10

Control Panel on the Projector

Controls and Features

1 [STAND BY] Indicator

Light on : In stand by mode.
Blinking : In cool down mode.

2 [OPERATE] Indicator

Light on : During projection.

3 [OPERATE] button

When this projector is in standby mode, pressing this but­ton for more than 1 second will turn the projector on and
cause the [OPERATE] indicator to light up. Press it one sec­ond or more again, and the projector goes into the cool
down mode and finally into stand by mode. (☞ page 25)

• The [OPERATE] button will not work within approximately
1 minute of the light-source lamp being turned on. Hence
wait about 1 minute before pressing.

4 [VOL.] ª / · buttons

Use these buttons to adjust the sound volume.
(☞ page 27)

5 [EXIT] button

Press this button to display the previous menu (For exam­ple, from sub menu to main menu). Pressing this button
when the main menu is displayed will erase the menu.
(☞ page 35)

6 [ENTER] button

Press this button to show the next menu (For example, from
main menu to sub-menu). It is also used when [ENTER] is
displayed against an item on the menu screen, or to choose
the “Reset” option etc. (☞ page 35)

9 [LAMP] Indicator

Light on : Indicates the lamp has been used for more than

1900 hours.

Blinking : Indicates the lamp has been used for more than

2000 hours.
Please change the lamp. (☞ page 10, 47, 55)

p [VIDEO] button

Use this button to select a device such as a video con­nected to the [VIDEO IN] terminal ([VIDEO] or [Y/C] Input
terminal) of the projector. (☞ page 25)

q [PC] button

Use this button to select a device connected to the [PC1],
[PC2] or [PC3] terminals. (☞ page 26)

w [H-KEYSTONE] button

Use this button to remove the horizontal trapezoidal distor­tion of the image projected on the screen. (☞ page 30)

e [V-KEYSTONE] button

Use this button to remove the vertical trapezoidal distortion
of the image projected on the screen. (☞ page 30)

r [MENU] button

Use this button to enter or exit the menu mode. When the
main menu is displayed, pressing this button will cause the
menu to disappear. (☞ page 35)

t Cursor (  /  /  /  ) buttons

These buttons are used in the menu mode to select an
item, adjust the value etc. (☞ page 35)

7 [HIDE] button

Use this button to temporarily halt the audio and video out­put. Press again to resume. (☞ page 29)

8 [TEMP] Indicator

Blinking : Indicates the temperature inside the projector is

abnormally high.

About Cool Down mode

After projection, the heated lamp will go through a 90 sec­onds cool-down period known as the cool down mode. This
function is to prevent heat from the heated lamp causing
damage and deformation to the internal components of the
projector. It also prevents lamp breakage and shortened lamp
life.
The Cool down mode is indicated by the blinking [STAND
BY] indicator. During the cool down mode, pressing the
[OPERATE] button will not turn on the projector.
After the cool down process is completed, the projector will
automatically change to stand by mode.

y [PRESET] button

This [PRESET] button only works as a reset button for the
[VOL.], [V-KEYSTONE] and [H-KEYSTONE] adjustments
done on the control panel and the [VOLUME], [V-KEY­STONE], [H-KEYSTONE] and [DIGITAL ZOOM] adjust­ments done on the remote control. (☞ page 28, 30)
When adjusting the volume, keystone or digital zoom (when
the setting is displayed on the screen) the adjusted value is
reset to that which was set when the projector was shipped
from the factory. This button does not work for the menu
(submenu) items.

Note

Please do not pull out the plug from the power outlet during
cool down mode. Please also do not block the exhaust vent
by standing the projector on its end or laying it on its side.

11

Controls and Features

Remote Control Unit

q [VIDEO] button

w [PC] button

e [H-KEYSTONE] button

r [V-KEYSTONE] button

t [VOLUME] button

y [FOCUS] button

(Not functional on this unit.)

u [MENU] button

W

SCREEN

S

OPERATE

DIGITAL

FREEZE

QUICK ALIGN.

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

FOCUS

MENU EXIT

ENTER

ZOOM

1 Remote Control’s signal transmitter

2 [OPERATE] button

3 [SCREEN] button

(Not functional on this unit.)

4 [DIGITAL ZOOM] button

5 [FREEZE] button

6 [QUICK ALIGN.] (quick alignment)

button

7 [EXIT] button

8 [ENTER] button

i [PRESET] button

PRESET HIDE

9 [HIDE] button

p Cursor (



/  /  / ) button

12

Controls and Features

1 Remote Control’s signal transmitter

(☞ page 18)

2 [OPERATE] button

When the projector is in standby mode, pressing this but­ton for one second or more will turn on the projector and
light up the [OPERATE] indicator. Press it one second or
more again and the projector will turn off, cool down and
finally enter the standby mode. (☞ page 25)

• The [OPERATE] button will not work for approximately 1
minute from when the light-source lamp is turned on. Wait
approximately 1 minute before pressing.

3 [SCREEN] „ / Í button

Not functional on this unit.

4 [DIGITAL ZOOM] ª / · buttons

This digital zoom function can magnify the image by up to
four times on the screen. (☞ page 28)

• There will however be some inevitable loss of image qual­ity when images are enlarged.

5 [FREEZE] button

This button allows the image to be retained in the projector
memory and stills the picture on the screen. Press the but­ton once to freeze the picture and again to de-freeze.
(☞ page 29)

6 [QUICK ALIGN.] (quick alignment) button

Use this button to automatically adjust the projected im­age’s (i)horizontal and vertical position, (ii) Width and dis­play area, etc. During alignment, the message “QUICK
ALIGN...” appears on the screen and disappears when align­ment is complete. (☞ page 31)

• The Quick Alignment function only works when the sig­nal is input from either the [PC1] or [PC2] terminal. It does
not work when the signal is input from the [VIDEO] input
terminal or the [Y/C] input terminal.

• When input signal from [PC3] input terminal is received,
“QUICK ALIGN...” is displayed but it is not functional.

7 [EXIT] button

Press this button to display the previous hierarchical menu
(For example, from sub-menu to main menu). When the
main menu is displayed, pressing this button will cause the
menu to disappear. (☞ page 35)

8 [ENTER] button

Press this button to show the next hierarchical menu (For
example, from main menu to sub menu). It is also used
when [ENTER] is displayed against the item on the menu
screen or to select the “Reset” menu. (☞ page 35)

9 [HIDE] button

Use this button to temporarily halt the audio and visual out­put. Press again to resume.
(☞ page 29)

p Cursor (

These buttons are used in the menu mode to select an
item, adjust the value etc. (☞ page 35)



/  /  / ) button

q [VIDEO] button

Use this button to select a device such as a video con­nected to the [VIDEO IN] terminal ([VIDEO] or [Y/C] Input
terminal) of the projector. (☞ page 25)

w [PC] button

Use this button to select a device connected to the [PC1],
[PC2] or [PC3] terminal of the projector. (☞ page 26)

e [H-KEYSTONE] button

Use this button to remove the horizontal trapezoidal distor­tion of the image projected on the screen. (☞ page 30)

r [V-KEYSTONE] button

Use this button to remove the vertical trapezoidal distortion
of the image projected on the screen. (☞ page 30)

t [VOLUME] ª / · button

Use these buttons to adjust the sound volume.
(☞ page 27)

y [FOCUS] ª / · button

Not functional on this unit.

u [MENU] button

Use this button to enter or exit the menu mode. When the
main menu is displayed, press this button and it will disap­pear. (☞ page 35)

i [PRESET] button

This [PRESET] button only works as a reset button for the
[VOL.], [V-KEYSTONE] and [H-KEYSTONE] adjustments
done on the control panel and the [VOLUME], [V-KEY­STONE], [H-KEYSTONE] and [DIGITAL ZOOM] adjust­ments done on the remote control. (☞ page 28, 30)
When adjusting the volume, keystone or digital zoom (when
the setting is displayed on the screen) the adjusted value is
reset to that which was set when the projector was shipped
from the factory. This button does not work for the menu
(submenu) items.

13

Controls and Features

Loading Batteries into the Remote Control

Please load batteries into the remote control. If the remote control starts to work erratically, replace the batteries.

1.

Open the back cover

• Push the hook on the back cover lightly in the direc­tion of the arrow and lift it up.

2.

Load the batteries

• Place the two supplied batteries (AA/R6-size) into
the remote control as illustrated below. To prevent
short circuit, be sure to insert the minus · end of
the battery first.

Precautions for using batteries

If batteries are used incorrectly, they may crack or leak. This
could cause fire, burn, malfunction, staining or damaging of
the surroundings.

Beware of the following:

• Do not mix new and old batteries.

• Do not mix different types of batteries as they are differ­ent in characteristics.

• Place batteries so they match the polarities indicated on
the cartridge.

• Be sure to insert the minus · end in first to avoid short­circuiting.

• Do not put batteries into a fire or try to recharge them.

• Use only designated batteries.

• Remove the batteries if the remote control is not to be
used for a prolonged period.

Battery Life

Batteries run for six months to one year in normal use. How­ever, the batteries supplied are for confirming operation and
may not run that long. When the remote control starts failing
to work properly, replace the batteries with new ones.

Battery Leakage

When the batteries are totally exhausted and can no longer
be used, replace them immediately.
Leaving the batteries in the battery compartment causes
battery leakage which in turn causes malfunction.
Further, in cases where the leakage comes to contact with
the skin, wipe it away with a cloth, otherwise skin problems
may occur.

14

3.

Close the back cover

• Close the back cover by inserting the end first and
pressing down until a click is heard.

Installing the Projector

Precautions for Installation

Please read the following properly when installing the projector.

Installation Environment

Please do not install or use this projector in the follow­ing places. The projector is a precision device and do­ing so could cause a fire or malfunction.

• Where there is water, humidity or dust

• Where the projector may be subjected to oil, smoke or
cigarette smoke

• On a soft surface such as a carpet or cushion

• Where the projector may be subjected to direct sunlight

• Where temperature is high or low
Allowable operation temperature range : +5 °C to +35 °C
Allowable relative humidity range : 20 % to 80 %

(no condensa­tion)

Allowable storage temperature range : –10 °C to +60 °C

•Any room in which there is smoke and grease
Even where smoke and grease levels are minimal, pro­longed exposure will affect the projector. The projector
emits heat and optical components are cooled down by
taking in large amount of air. The optical path being soiled
by grease/dirt can cause images to become dark and the
color projection to deteriorate. After soiling, removing
grease/dirt totally from the optical parts is not possible.

Precaution for Usage

This projector uses a light-source lamp which reaches
high temperatures when projecting.
Please DO NOT use it in the following ways as doing so
may result in fire or malfunction.

• Projecting images while the projector is on its side.

• Projecting images outside the specified angle.
Do not use the projector while it is set more than ±5°
horizontally (left/right), or more than ±25° vertically (up/
down). This could cause color variation or shorten the
lamp life.

• Use while blocking the exhaust vents.

Minimum Space Required

Do not use a cover which may enclose the projector
air-tight or block the exhaust vents. Allow sufficient
space around the projector. When the projector is en­closed in a space of the following dimensions, use an
air conditioner so that internal and external tempera­tures are the same.

300 mm

150 mm

300 mm

150 mm

500 mm

Adjusting the Inclination of the Projector

The vertical angle and leveling of the projector can be adjusted with the adjustable feet at the bottom of the projector.

 Vertical angle adjustment range

+6˚

Adjusting the vertical angle of the projector

• While pushing the lever upward, raise the pro­jector. The maximum extension is approximately
31 mm. To retract the foot, push the lever and
lower the projector slowly; the projector is fixed
at the position where you release the lever.

Foot
Lever

Front Adjustable Foot

Adjusting the level of the projector minutely

• Lift the projector, rotate the front adjustable foot,
and adjust the horizontal angle until the projec­tor is level.

ShortenExtend

15

Installing the Projector

Installing the Projector against the Screen

The picture quality may deteriorate when performing KEYSTONE compensation. It is recommended to place the projector perpen­dicularly to the screen.

 Side View  Top View

•Trapezoidal-distortion can be corrected using the [KEYSTONE]*
buttons on the projector. (☞ page 30)

Up to approximately 10° upward and

Up to approximately 30° upward
and downward from the horizontal
line.

* If the KEYSTONE compensation is used simultaneously for upper/lower/left/right directions, the compensating range will

decrease.

downward from the vertical line.

Mounting the Projector

When mounting of the projector is required, do it using the embedded three screw holes (M6 nuts) at the bottom of the projector.

Precaution for ceiling-mount

•To ceiling-mount and adjust the projector, special exper­tise and techniques are necessary. Be sure to ask your
dealer or specialist to perform the work.

• Do not mount on places that will be subjected to knocks
and vibrations.

• As the depth of the screw holes is 10 mm, use screws
shorter than 10 mm but longer than 6 mm. Otherwise, the
screws will damage the internal parts of the projector caus­ing malfunction.

• Install at a safe place in case this unit or a part of it may
drop. If the light-source lamp is broken, small pieces of
glass from the mesh of the filter may appear outside this
unit.

16

Installing the Projector

Projection Distance and Screen Size

• This projector uses 1.3x manual zoom lens for projection.

• Although the focusable projection distance is about 1.6 m - 12 m, the projection distance recommendable for performance is
about 2 m - 8 m. Install the projector within this range and adjust the screen size when the aspect ratio of the screen is 16:9.

• If the KEYSTONE is adjusted, the screen becomes smaller. (☞ page 30)

 Screen installation

16:9 and 4:3 Screen

Screen

A

A 4:3 aspect-ratio picture is projected based
on the width of the range in which a 16:9
aspect-ratio picture is projected. The diagonal
length of a 4:3 aspect-ratio screen is about

81.7 % that of a 16:9 aspect-ratio screen.

B

90˚

90˚

A:B = 30:1

 Relationship between projection distance and projection screen size

Projection screen size of 16:9 aspect Ratio

(Diagonal length)

Type 36.7 (approx. 93.2 cm)

Type 40 (approx. 101.6 cm)

Type 60 (approx. 152.4 cm)

Type 80 (approx. 203.2 cm)

Type 100 (approx. 254.0 cm)

Type 120 (approx. 304.8 cm)

Type 140 (approx. 355.6 cm)

Type 160 (approx. 406.4 cm)

Type 180 (approx. 457.2 cm)

Type 200 (approx. 508.0 cm)

Type 220 (approx. 558.8 cm)

Type 240 (approx. 609.6 cm)

Type 260 (approx. 660.4 cm)

Type 275 (approx. 698.5 cm)

Approximate projecting distance

W (Wide) - T (Tele-)

(approx. 1.56 m) - (approx. 2.05 m)

(approx. 1.71 m) - (approx. 2.24 m)

(approx. 2.59 m) - (approx. 3.38 m)

(approx. 3.47 m) - (approx. 4.53 m)

(approx. 4.35 m) - (approx. 5.67 m)

(approx. 5.23 m) - (approx. 6.82 m)

(approx. 6.11 m) - (approx. 7.96 m)

(approx. 6.99 m) - (approx. 9.11 m)

(approx. 7.87 m) - (approx. 10.25 m)

(approx. 8.75 m) - (approx. 11.40 m)

(approx. 9.64 m) - —

(approx. 10.52 m) - —

(approx. 11.40 m) - —

(approx. 12.06 m) - —

• The projection screen sizes and projecting distances in the table above are provided only as a guide (reference). Please use
them during installation. The projected image size may vary depending on the manufacturing tolerance of the projection lens.
Please use the ‘Wide side’ for sizes bigger than Type 200.

17

Installing the Projector

Effective Range and Distance of the Remote Control Unit

 Using as a wireless remote control unit

The operable distance of the remote control unit is about 7 m for direct reception. The remote control unit can be used by having
the transmission signal reflected off a screen. In this case, please set the total distance A + B where A is the distance from
projector to screen and B is the distance from screen to remote control, within 7 m. The operable angles of the remote
control unit are 30˚ right and left, and 20˚ up and down.

• As the effect of signals reflected from the remote control

unit differ with the type of screen used, effective range
and distance may decrease.

Screen

• Aim the remote control unit towards the remote
sensor on the front or rear of the projector. The
operable distance of the remote control unit is
about 7 m for direct reception. If the remote
control fails to work properly, move closer to
the projector.

• If the fluorescent lamp is lit, the remote control
unit might not function properly.

30˚

20˚

20˚

A

B

P

C
V
I

D
E

O

O
P
E

R
A
T
E

W

V

-K
EYSTON

E
H-K
EYS

TON

E
S
C
R

E
E

N

D
I

G
I
T
A

L

Z

S

O
O
M

F

R

V

E

O

E

L

Z

U

E

M
E

FOCUS

Q
U
I
C

K
A

L
I
G
N

.

M
E
N

U

E

X
I
T

E
N

T
E
R

P

R
E
S

E
T

H
I
D

E

Remote Control Unit

30˚

Projector Projector

Remote Control Sensor
(rear)

20˚

20˚

30˚

30˚

PC

VIDEO

O
N
E

H

­K
E

Y
S
T

O

O

P

N

W

E

E
R
A

S

T

C

E

R
E

S

E
N

D
I
G

Z
O

I
T
O
A
M

L

FRE

EZE

Remote Control Unit

 Using as a wired Remote Control

By connecting a separately sold wired remote control via remote cable to the [REMOTE] terminal, the remote control can be
used as a wired control unit.

• When connected to the remote cable, the supplied remote control’s transmitter and the projector’s sensor do not function.

• Please keep within the range of the remote cable length. Warranty is not extended to the case where an extension cord is
used.

REMOTE

RS-232C OUT

CONTROL

V

­K
E
Y
S
T

V
O
L

U
M
E

FO
CU

MENU

S

Q
UICK ALIGN.

PRES

E
NT

ET

E

R

EXIT

HIDE

Projector

QUICK
ALIGN.

PC VIDEO

DIGITAL

ZOOM

PRESET

VOLUME

Wired remote
control

OPERATE

(sold separately)
RM-M3010

HIDE

FREEZE

MENU

❈ The [ESCAPE] button on the separately sold remote control (RM-M3010) is equivalent

Remote Cable (sold separately)
QAM0081-001 (approx. 3 m)
QAM0247-001 (approx. 15 m)

to the [EXIT] button on the supplied remote control unit. There is no equivalent to the [H­KEYSTONE], [V-KEYSTONE] and [FOCUS] buttons found on the supplied remote con-

ESCAPE ENTER

trol.

When the remote control unit fails to work properly

• When the batteries in the remote control unit are exhausted, improper functioning will occur. Please replace with new
batteries.

• When either the remote control unit or projector alone is connected to the remote cable, the item connected will not be
able to work. Please check the cable connection.

• When a remote cable is connected to the projector, the supplied remote control becomes inoperable.
When operating via the supplied remote control, confirm that the cable is not connected to the projector.

18

Connecting to Various Devices

Signals that can be input into the Projector

The following signals can be input to the projector.

 Video signals

(1) Response to Decoder

Input terminal

[VIDEO]

[Y/C]

[Y], [PB/CB], [PR/CR]*

[G], [B], [R], [H/Cs], [V]*

Decoder

3

4

NTSC

O
O
O*
O*

NTSC4.43

O

1

2

2

O*
O*
O*

2

2

PA L

O
O
O*
O*

SECAM

O

–––––

2

2

O*
O*

*1: Responds if Y/C output is available.
*2: Signifies that component signals (Y, PB, PR/Y, B-Y, R-Y/G, B, R, H/Cs, V) conform to the signal timing (synchronization and

video period) of each decoder. The decoders are used for convenience.

3

:To use these signals, it is required to set the “PC2(BNC)” item in the “Options” menu to “YPBPR”. (☞ page 39)

*
*4:To use these signals, it is required to set the “PC2(BNC)” item in the “Options” menu to “RGB”. (☞ page 39)

(2) Responds to double density*5, high-vision signals.

Input terminal

[Y], [PB/CB], [PR/CR]*

[G], [B], [R], [H/Cs], [V]*

Decoder

8

9

*5: Signals of which density of scanning lines per field is twice as high.

6

: Responds to signals of which the horizontal scanning frequency is 31.47 kHz. NTSC can be made twice as dense by a line

*

doubler (separately available: recommended article). It can also respond to fully-specified, decoded wide-clear-vision sig­nals and decoded 525p progressive signals.

7

: Responds to signals of which the horizontal scanning frequency is 31.25 kHz. PAL can be made twice as dense by a line

*

doubler (separately available: recommended article).

*8:To use these signals, it is required to set the “PC2(BNC)” item in the “Options” menu to “YPBPR”. (☞ page 39)

9

:To use these signals, it is required to set the “PC2(BNC)” item in the “Options” menu to “RGB”. (☞ page 39)

*

NTSC*

O
O

6

PAL*

O
O

7

High-vision signal

O
O

2

2

(3) Response to DTV-format signals

DTV-format signals (480i, 480p, 576p, 720p (Excluding 50 Hz), 1080i) can be input to the [Y], [PB/CB], [PR/CR]*10 input terminals.
*10: To use these signals, it is required to set the “PC2(BNC)” item in the “Options” menu to “YPBPR”. (☞ page 39)

 Computer signals

11

Computer signals can be input to the [PC1], [PC2] ([G], [B], [R], [H/Cs], [V])*

11

: It is required to set the “PC2(BNC)” item in the “Options” menu to “RGB”. (☞ page 39)

*

Scanning frequencies in the following ranges can be inputted.

Horizontal scanning frequency : 15 kHz - 120 kHz
Ver tical scanning frequency : 24 Hz, 25 Hz, 30 Hz, 50 Hz - 120 Hz

Be sure that the computer used meets the following conditions.

• The computer has a video signal output port.

Confirm if the computer has a video signal output port by consulting the computer’s manual.
The video signal output port is generally called RGB port, monitor port, or video port.
In the case where the computer comes with a built-in monitor, e.g.; a notebook, an external output port may need to be
purchased. Also, note that an external output port cannot be installed in some computers.

• The resolution and the scanning frequencies are within the range specified in the table on page 20.

Be sure that the resolution and the scanning frequencies of the video signal are within this range.
Video signals out of this range should not be used.
(Out of range signals can be projected but the image may not turn out sharp. Signals within the range may occasionally
require adjustment, depending on the video board used). When signals other than those listed in the table on page 20 are
input, the image could be partially erased or unwanted folds-over the image could appear.
Some signals within the frequency range may not be displayed normally depending on the type of the signal.
Composite sync (Cs) and G on Sync signals cannot be handled depending on the devices connected.

or [PC3] (DVI-D) terminals.

 HDCP compatible signal

[PC3 DVI] input terminal can accept HDCP compatible video signals (480p, 576p, 720p 50/59/60 Hz, 1080i 50/59/60 Hz). The
menu is same as when PC input is selected.

19

Connecting to Various Devices

 Allowable input signals

PC98

PC/AT

DOS/V

DVI *

PC system

Mac

Video

DVI *

(HDCP)

VIDEO system

Signal

VESA350
PC98
VGA 60 Hz*
VGA 72 Hz
VGA 75 Hz
VGA 85 Hz
SVGA 56 Hz
SVGA 60 Hz*
SVGA 72 Hz
SVGA 75 Hz
SVGA 85 Hz
XGA 43 Hz
XGA 60 Hz*
XGA 70 Hz
XGA 75 Hz
XGA 85 Hz
SXGA 43 Hz
SXGA 60 Hz*
SXGA 75 Hz
SXGA 85 Hz
SXGA+60 Hz*
MAC13
MAC16
MAC19
MAC21
HDTV (1035i) 60 Hz
HDTV (1035i) 59 Hz
480p*
576p 50 Hz*
720p 60 Hz*
720p 59 Hz*
720p 50 Hz*
1080i 60 Hz*
1080i 59 Hz*
1080i 50 Hz
1080 30SF/30P
1080 25SF/25P
1080 24SF/24P
NTSC
PA L
SECAM

Horizontal resolution

Hor (Pixels)

640
640
640
640
640
640
800
800
800
800

800
1024
1024
1024
1024
1024
1280
1280
1280
1280
1400

640

832
1024
1152

720

720
1280
1280
1280
1920
1920
1920
1920
1920
1920

Vertical resolution

Ver (Lines)

350
400
480
480
480
480
600
600
600
600
600

768/2

768
768
768
768

1024/2

1024
1024
1024
1050

480
624
768
870

483
576
720
720

720
1080/2
1080/2
1080/2

1080
1080
1080

Horizontal frequency

H (kHz)

37.86

24.83

31.47

37.86

37.50

43.27

35.16

37.88

48.08

46.88

53.67

35.52

48.36

56.48

60.02

68.68

46.43

63.98

79.98

91.15

64.02

35.00

49.73

60.24

68.68

33.75

33.72

31.47

31.25

45.00

44.96

37.50

33.75

33.72

28.13

33.75

28.13

27.00

15.73

15.63

15.63

Vertical frequency

V (Hz)

84.13

56.42

59.94

72.81

75.00

85.01

56.25

60.32

72.19

75.00

85.06

43.48

60.00

70.07

75.03

85.00

43.44

60.02

75.03

85.02

60.00

66.67

74.55

74.93

75.06

60.00

59.94

59.94

50.00

60.00

59.94

50.00

60.00

59.94

50.00
60/30
50/25
48/24

59.94

50.00

50.00

• The resolutions for the input signals are listed in the table above.

• Certain types of signals in the frequency range may not be displayed normally.

• When a signal other than those listed above is input, the image could be partially erased or unwanted folds-over the image may appear.

• Some signals other than those listed above can be displayed. However, they may require adjustment.

• Some of the signals listed above may require adjustment depending on the video board used.

• Composite sync (Cs) and G on Sync signals cannot sometimes be handled depending on the devices connected.

•VGA signals from the PC could at times be displayed in the video 480p mode.
(In this case, the projector enters the video menu when the [MENU] button is pressed.)

• The motion picture may be distorted when projecting motion picture from computer.

• The image of [DVI-D] input terminal might not be displayed due to HDCP specification change.

20

Connecting to Various Devices

Connecting to Devices

Before connection, be sure to turn off both the projector and the device.

 Connecting to Video Devices

• Thoroughly read the manual that comes with each video device.

• Use the supplied AV connection cable. S-video (Y/C) cable, BNC cable, DVI cable and PC Audio cables are not supplied.

Right side of projector

PC Audio cable

(sold separately)

PR/C

R

SCREEN

TRIGGER

R

GYB

AUDIO IN

PB/C

PC2

REMOTE

BNC Cable (sold separately)

B

VDVIH/C

S

PC1

RS-232C OUT RS-232C IN Y/C VIDEO

CONTROL VIDEO IN

S-video cable

(sold separately)

DVI Cable
(sold separately)

PC3

AV connection cable
(supplied)

Video Device 1

Video Device 2

VCR (Video cassette recorder)

DVD player

D-VHS or DVD player etc.

Image input

• Connect to component signal output
device, DTV format signal output device,
HDCP compatible video signal output de-

Camcorder

vice, etc.

• When the [PC2] input terminal is used,
the “PC2(BNC)” item in “Options” menu
must be correctly set. (☞ page 39)

Image input

• Connect a composite image signal output
device or Y/C (S-video) image output device.

Sound input

• Connect to [AUDIO IN] terminal.

• When the [PC3] input terminal is used,
the “PC3(HDCP)” item in “Options” menu
must be correctly set. (☞ page 39)

Sound input

• Connect to [AUDIO IN] terminal.

Connection

• When connecting a video device, please use a TBC along with it, or use one with a built-in TBC.

• Use of an extension cable to connect a video device and the projector could cause image deterioration or projection
failure.

• When a signal with much jitter is reproduced on a VCR, or special-effect playbacks are performed, the upper part of the
image or the screen may be interrupted, erased or distorted.

21

Connecting to Various Devices

 Connecting to Computers

• Thoroughly read the manuals that come with the computer used.

• Prepare cables for connecting the devices.

• When the [PC2] input terminal is used, “PC2(BNC)” must be selected from the
“Options” menu. (☞ page 39)

Desktop type (DOS/V, etc.)

• When connecting an audio output terminal such as a computer sound source to
the projector, connect to the [AUDIO IN] terminal using the separately available
audio cable.

• When connecting to PC-9800 Series computers, a separately available conver­sion adapter is necessary. Please confirm the monitor connector type before use.

Personal Computer connector cable (sold separately)

Desktop type (DOS/V, PC-9800 etc.)

Desktop type
(Macintosh)

Conversion
adapter for MAC
(sold separately)

To monitor
connector

To monitor
connector

Separated cable (sold separately)

To [PC2]

PR/C

R

SCREEN

TRIGGER

R

GYB

AUDIO IN

PB/C

B

S

PC2

RS-232C OUT RS-232C IN Y/C VIDEO

REMOTE

Right side of projector

To [PC1]

VDVIH/C

PC1

CONTROL VIDEO IN

To [DVI]

PC3

Notebook Type

To monitor
connector

❈ There are some notebook type computers that do not

allow the computer’ s LCD to work if an external
display device is connected. With such computers, the
LCD display and external display output need to be
switched.

Desktop type

22

Connecting to Various Devices

 Control from external device

It is possible to control the projector with a computer by connecting the computer to the [CONTROL RS232C IN] terminal of the
projector.

• Please request a connection cable from us if needed.

•For more information, please contact your authorized dealer.

Notebook type

PR/CR

R

SCREEN

TRIGGER

GYB

AUDIO IN

RS-232C connection cable

PB/CB

PC2

REMOTE

VH/C

S

PC1

RS-232C OUT RS-232C IN

CONTROL

(sold separately)
(Cross cable)

Connection for controlling more than one projector

By using the [CONTROL] terminal, more than one projector can be controlled simultaneously by one computer.
Connect these projectors in series by connecting the [OUT] terminal of the first projector to the [IN] terminal of the second
projector, then the [OUT] terminal of the second projector to the [IN] terminal of the third projector, etc.

Second projectorProjector

RS-232C connection cable (sold separately)
(Cross cable)

PB/CB

B

PC2

REMOTE

VH/C

S

PC1

RS-232C OUT RS-232C IN

CONTROL

N

PB/CB

B

PC2

REMOTE

VH/C

S

PC1

RS-232C OUT RS-232C IN

CONTROL

Connect to Computer Connect to the [IN]

terminal of third projector

23

Connecting to Various Devices

Connecting the Power Cord (supplied)

After all devices have been connected, connect the supplied power cord.

1.

Connect the supplied power cord to the power in­put terminal of the projector

1

2.

Insert the main plug of the supplied power cord into
the wall outlet

2

Power cord (supplied)

(e.g.)

Cautions Against Fire and Electric Shock

● Since the power requirement of the projector is high, please insert the power plug directly into a wall outlet.

● When not using devices, remove the power plug from the wall outlets.

● Do not use power cords other than those supplied.

● Do not use a power voltage different from that which is indicated.

● Do not cut, tear or modify the power cords. Also, do not put a heavy object on, heat, or stretch the power cords, otherwise they

may be damaged.

● Do not insert or pull out the plugs with a wet hand.

 When using the projector, remove the Lens Cap

• Be sure to fit the lens cap on when the projector is not in use
to keep out dirt.

• Do not project with the lens cap attached. The lens cap may
be deformed by heat or this may cause malfunction.

Lens Cap

24

Basic Operations

VIDEO

VIDEO

If projector set up is not yet complete, please read ‘Adjustments and Settings Using Menus’ on page 32 and perform the necessary
settings.

Basic Operation Procedures

Once the basic settings are done, follow the procedures below:

1.

Power On

1 Insert the power cord into the wall outlet

• The [STAND BY] indicator lights up when the main power is

LAMP

TEMP

STAND BY

OPERATE

inputted.

LAMP TEMP

Light on

STAND BY

OPERATE

VIDEO

PC

V-KEYSTONE

H-KEYSTONE VOL.

MENU

ENTER

PC VIDEO

FOCUS

ENTER

W

SCREEN

S

V-KEYSTONE H-KEYSTONE

VOLUME

MENU EXIT

PRESET HIDE

EXIT

OPERATE

DIGITAL

ZOOM

FREEZE

QUICK ALIGN.

1­2

1­2

2

2

Projector: Indicator

2 Press the [OPERATE] button on the projector (or the [OP-

ERATE] button on the remote control unit) for one second
or more

• The [OPERATE] indicator lights up and the projected image
slowly appears.

OPERATE

Projector:
Control panel

Notes

• Upon projection, the image may flicker for a few seconds, but
this is not a malfunction.

• When the lamp is turned on, it will slowly become brighter. It
will take more than a minute for the brightness to stabilize.

2.

Selecting the image to be projected

 Press [VIDEO] to select which of the image devices of those

connected to the [VIDEO IN] ([VIDEO] or [Y/C]) terminals is
output

OPERATE

Remote
control unit

LAMP TEMP

Projector: Indicator

Light on

STAND BY

OPERATE

Note

• Messages are displayed in the language set
by the user in the “Language” menu. The pre­set language upon purchase is “English”. The
user can choose from 8 national languages.
(☞ page 39)
However, the input mode ([PC1], [PC2],
[PC3], [Y/C], [VIDEO]) and button indications
([FREEZE], [D.ZOOM], [EXIT]) are only dis­played in English irrespective of the display
language setting.

Projector:
Control panel

Remote
control unit

• Each time you press either button, the selected input changes
as follows.

[VIDEO]: Image from the input [VIDEO]

[VIDEO]

[Y/C]

terminal on the right hand side
of projector will be projected.

[Y/C] : Image from the input [Y/C] ter-

minal on the right hand side of
the projector will be projected.

Notes

• Sound is formed from sound signals connected to the [AU­DIO IN] terminal.

• When no image is input to the selected input terminal, the
message “No Input” is displayed on the screen. (☞ page 53)

25

Basic Operations

 Display using the direct buttons

The direct buttons enable direct switching and op­eration without having to go through the menu.

Input mode can be selected
by pressing the [PC] button or
the [VIDEO] button.

Audio-Vol 12

Digital zoom x1.2

Vert.keystone

0

PC 1

PC 2
PC 3

Y/C

VIDEO

When “Line display” (☞ page 39) is set

VIDEO

Screen display

to “5sec” : After changing an input , the
new selection will appear on the screen
for about 5 seconds.

 To select a computer or other devices connected to [PC1],

[PC2] or [PC3]: Press [PC]

PC

PC

Projector:
Control panel

• Upon pressing the button, the input mode changes as follows.

PC1 PC2 PC3

Remote
control unit

[PC1]: Projects image from [PC1] input terminal on

the right hand side of the projector.

[PC2]: Projects image from [PC2] input terminal on

the right hand side of the projector

[PC3]: Projects image from [PC3] input terminal on

the right hand side of the projector.

Horiz.Keystone

0

When the [DIGITAL ZOOM], [VOLUME], [V-KEY­STONE] or [H-KEYSTONE] buttons are pressed,
the level bar of the function is displayed.

‘Tele side’

3.

‘Wide side’

‘Near side’

4.

‘Far side’

PC1

Screen display

When “Line display” (☞ page 39) is set
to “5sec”: After changing an input, the
new selection will appear on the screen
for about 5 seconds.

Notes

• Sound is formed from sound signals connected to the [AUDIO IN]
terminal.

• When no image is input to the selected input terminal, the mes­sage “No Input” is displayed on the screen. (☞ page 53)

• When the [PC2] input terminal is used, “PC2(BNC)” must be se­lected from the “Options” item in the main menu. (☞ page 39)

3.

Adjusting the Zoom Ring (the screen size)

 To enlarge the screen size:Turn the zoom ring towards the

‘Wide side’

 To reduce the screen size:Turn the zoom ring towards ‘Tele

side’

26

4.

Adjusting the Focus Ring (Focus)

 To focus on nearer points:Turn the focus ring towards the

‘Near side’

 To focus on farther points:Turn the focus ring towards the

‘Far side’

Basic Operations

5.

Adjusting the Sound Volume

 To increase the volume : press [VOLUME] ª (0 ➞ 50)
 To lower the volume : press [VOLUME] · (50 ➞ 0)

LAMP

TEMP

PC

VIDEO

V-KEYSTONE

H-KEYSTONE VOL.

MENU

ENTER

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

FOCUS

MENU EXIT

W

SCREEN

S

STAND BY

OPERATE

EXIT

OPERATE

DIGITAL

ZOOM

FREEZE

QUICK ALIGN.

6-

5

6-

5

1

1

VOL.

Projector:
Control panel

VOLUME

Remote
control unit

When “Menu display” (☞ page 39)
is set to “15sec”, after pressing the
[VOLUME] button, the sound vol­ume display will appear on the
screen for about 15 seconds.
(Press [EXIT] button to immedi­ately remove the “Audio-Vol” dis-

Audio-Vol 12

play.)

Audio-Vol 12

Screen display

Note

• When the sound volume is displayed on the screen, pressing
the [PRESET] button will reset the set value to “0”.

6.

Power Off

1 Press the [OPERATE] button on the projector (or the [OP-

ERATE] button on the remote control unit ) for 1 second or
more

• The [OPERATE] indicator will disappear, the [STAND BY] in-

dicator starts to blink, and the projector goes into the cool­down mode. The [STAND BY] indicator will continue blinking
for approximately 90 seconds as the temperature of the light
source lamp cools (Cool Down Mode).

ENTER

PRESET HIDE

Tu r n off

OPERATE

Projector:
Control panel

OPERATE

Remote
control unit

LAMP TEMP

Projector: Indicator

Note

• The [OPERATE] button will not work for approximately 1 minute
from when the light-source lamp is turned on. Wait approxi­mately 1 minute before pressing.

2 Plug out the power cord from wall outlet

Caution

• Please do not pull out the plug from the power source when
the [STAND BY] indicator is blinking. It will shorten the life of
the lamp and cause a malfunction.

Blink

STAND BY

OPERATE

27

Basic Operations

Frequently used Convenient Functions

FOCUS

ENTER

W

SCREEN

S

OPERATE

DIGITAL

ZOOM

FREEZE

QUICK ALIGN.

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

MENU EXIT

PRESET HIDE

 “Digital zoom” Display

Direction buttons available

Digital zoom X1.2

When an image is projected onto the screen, the following operations
can be performed directly without going through the menu operation.
(☞ page 27 for VOLUME operation.)

DIGITAL ZOOM
HIDE
FREEZE
KEYSTONE
QUICK ALIGN. (quick alignment)

Enlarging the Image

We can zoom in while not changing the size of the projected image. After
zooming, the position of the image displayed can be moved.

• This cannot be done using the projector buttons. Please use the re­mote control unit.

1.

Press [DIGITAL ZOOM] ª

• The “Digital zoom” display appears on the screen and the projec­tor changes to the Digital Zoom Mode.

• The image on the screen can be enlarged in 8 stages by pressing
this button (including the standard size).

DIGITAL

ZOOM

Direction buttons available

Digital zoom X1.2

“x2.0”

Direction buttons available

Digital zoom X2.0

1 Magnifying power display

“x1.0”: 1 time (standard) “x2.0”: 2 times
“x1.2”: 1.2 times “x2.5”: 2.5 times
“x1.4”: 1.4 times “x3.2”: 3.2 times
“x1.6”: 1.6 times “x4.0”: 4 times

2 Level Display

Level shown is based on selected magnification.

Note

• The quality of the zoomed image is reduced
in comparison with the original.

Remote
control unit

2.

While “Digital zoom” display appears on the screen, you
can move the zoomed image with the cursor buttons on
the remote control

 To see the upper part of zoomed image:

Press 

 To see the lower part of zoomed image:

ENTER

Press 

 To see the right part of zoomed image:

Press 

 To see the left part of zoomed image:

Remote control unit

Direction buttons available

Digital zoom X2.0

Press 

Direction buttons available

Digital zoom X2.0

To reduce the size of the image

When the [DIGITAL ZOOM] · button is pressed, the pre­viously enlarged image will be reduced progressively until

DIGITAL

ZOOM

it returns to the original size.

28

To reduce the image to the original size

When the [PRESET] button is pressed, the image will re­turn to its original size and position.

PRESET

(Please operate while “Digital zoom” is displayed.)

Basic Operations

Turning Off Image and Sound

Video images and audio output can be turned off temporarily.

Press the [HIDE] button once

• Images and audio output turned off.

HIDE

MENU

ENTER

PRESET

PC VIDEO

FOCUS

ENTER

W

SCREEN

S

V-KEYSTONE H-KEYSTONE

VOLUME

MENU EXIT

PRESET HIDE

EXIT

HIDE

OPERATE

DIGITAL

ZOOM

FREEZE

QUICK ALIGN.

HIDE

Projector:
Control panel

Remote
control unit

Press the [HIDE] button again.

Images and audio output turn on again

Note

• When the projected image input is changed, the HIDE function is
cancelled and image and sound return.

Displaying a Still Picture

The projected image can be paused temporarily.

• This operation cannot be operated by the projector buttons. Please
use the remote control unit.

Press the [FREEZE] button

• The image pauses after the [FREEZE] button is pressed for a few sec­onds and a message “Frozen” is shown in the center of the screen. An
icon indicating [FREEZE] mode will be displayed on the top right cor­ner of the screen.

FREEZE

Frozen

Digital zoom available

Remote control unit

FREEZE

[FREEZE] icon

To de-freeze the image

When you press the [FREEZE] button again, the image de-freezes and
resumes.

Notes

• After de-freezing a still image, note that the projector will not play

the image that comes immediately after. (Should you want to play
the image that comes immediately after that at which the [FREEZE]
button was pressed, please pause the image using the controls at
the input device.)

• [MENU], [QUICK ALIGN.], [H-KEYSTONE] and [V-KEYSTONE]

buttons do not function when the image is still.

• The “Frozen” message will disappear after 5 seconds. To forcibly

clear “Frozen”, please press the [EXIT] button.

29

Basic Operations

V-KEYSTONEPCH-KEYSTONE VOL.

MENU

VIDEO

EXIT

Removing the Trapezoidal Distortion of the Image

Depending on the angle of projection onto the screen, the image may get
distorted in a trapezoid form sometimes.
When installing the projector or screen for the first time, or when reinstall­ing in other rooms, etc., Keystone adjustments need to be made to re­move trapezoid distortions.

1.

Press [V-KEYSTONE] / to adjust the trapezoid form in
the vertical direction

•A “Vert.keystone” display appears on the screen, and the projec­tor goes into the KEYSTONE MODE.
Press button (
form.

V-KEYSTONE

/ ) in the direction that corrects the trapezoid

V-KEYSTONE

V-KEYSTONE

V-KEYSTONE

PC VIDEO

FOCUS

ENTER

W

SCREEN

V-KEYSTONE H-KEYSTONE

VOLUME

MENU EXIT

PRESET HIDE

 “Vert.keystone” Display

Vert.keystone

–12

2

S

QUICK ALIGN.

OPERATE

DIGITAL

ZOOM

FREEZE

Projector:
Control panel

2.

Press [H-KEYSTONE] / to adjust the trapezoid form in

Remote
control unit

Projector:
Control panel

Remote
control unit

the horizontal direction

•A “Horiz.Keystone” display appears on the screen, and the pro­jector goes into the KEYSTONE MODE.
Press button (
form.

H-KEYSTONE

Projector:
Control panel

1

/ ) in the direction that corrects the trapezoid

H-KEYSTONE

Remote
control unit

H-KEYSTONE

Projector:
Control panel

H-KEYSTONE

Remote
control unit

1 Adjusted value

range: –100 - 0 - 100

2 Level displayed

level displayed is based on the adjustment value.

 “Horiz.Keystone” Display

Horiz.Keystone

12

1 Adjusted value

range: –40 - 0 - 40

2 Level displayed

level displayed is based on the adjustment value.

1

2

30

Notes

• The range where the trapezoidal distortion can be rectified is 30˚
vertically and 10˚ horizontally with respect to the projector screen.

However, when both are rendered together, the range of effective
rectification will be narrower.

• The picture quality may deteriorate when performing KEYSTONE
compensation. It is recommended to place the projector perpen­dicularly to the screen.

• Depending on the signal inputted, the keystone adjustment range
may narrow or parts of the image may disappear. This is not a
malfunction.

• Interference patterns may appear on the screen when adjusting
the keystone. This is not a malfunction.

•To restore the original set value, press the [PRESET] button when
adjusting the [V-KEYSTONE] and [H-KEYSTONE]. (Adjusted value:

0)

• During startup of projector, the KEYSTONE adjustment is not re­flected in the D-ILA logo, user-set logo (when user-set logo is se­lected) display and the no signal blue back display.

Basic Operations

Using the Quick Alignment function

FOCUS

ENTER

W

SCREEN

S

OPERATE

DIGITAL

FREEZE

QUICK ALIGN.

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

MENU EXIT

PRESET HIDE

The Quick Alignment function automatically adjusts (sets) the screen set­tings of the image input from the [PC1] or [PC2] input terminal.

• This can only be performed with the remote control.

ZOOM

Press the [QUICK ALIGN.] (Quick Alignment) button.

• During automatic alignment, “QUICK ALIGN...” appears on the screen,
and disappears after alignment is complete.

Notes

• The Quick Alignment function only works when computer sig-

nals are input into either the [PC1] or [PC2] input terminal.

· It does not work when signals are input via a [VIDEO IN] terminal
(The [VIDEO] or [Y/C] input terminal).

· When input signal from [PC3] input terminal is received, “QUICK
ALIGN...” is displayed but it is not functional.

• The Quick Alignment function.

· This automatically adjusts “Horiz. disp. pos.”, “Vert. disp. pos.”,
“Phase”, “Tracking”, etc.

• Using the Quick Alignment function for automatic adjustments.

· Please use with bright still-pictures. This function may not work
correctly on a dark picture or a motion-video.
If adjustment with the Quick Alignment function is not satisfac­tory, adjust “Horiz. disp. pos.” and “Vert. disp. pos.”, “Phase” and
“Tracking” individually.

31

Adjustments and Settings Using Menus

ENTER

ENTER

ENTER

The menus displayed on the screen are used to setup the projector and perform adjustments.

The Menu Structure

The menus of the projector have the following structure.

When video input is selected

Main menu

Image adj.

Set up

Logo

Options

Language

A

Information

Contrast
Brightness
Color
Tint
Sharpness
Color temp.
Reset

12
12
12
12

1

ENTER

ENTER

1 Main: “Image adj.” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Position
Deinterlace
HDTV
Aspect ratio
Decoder
Phase

ENTER

Auto OFF

1080i 1035i sF

ENTER

ENTER

12

3 Main: “Set up” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Logo disp.

Logo pos.
Back color

Logo delete

Capture menu

OFF ON

Blue Black

ENTER

ENTER

Submenu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Color temp.

RED
GREEN
BLUE

D65

2 “Color temp.” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Position

Menu pos.

Horiz.disp.pos.

Vert.disp.pos.

Horiz.DIST pos.

4 “Position” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Decoder

NTSC

NTSC4.43

SECAM

6 “Decoder” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Capture menu

Menu pos.

Horiz.move

Vert.move

Horiz.size

Vert.size

Capture start

HIGH User

12

12

1

(NTSC)AUTO

PAL

(-) (+)

12

(-) (+)

12

ENTER

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Aspect ratio

4:3 16:9 Zoom

5 “Aspect ratio” menu

Capt.in prog.(approx. 2min)

Signal can not be captured

Reduce capt.size

8 Main: “Logo” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Color profile
Menu display
Line display
Flip H
Flip V
Page 2

q Main: “Options” menu (“Page 1”)

Image adj.

Set up

Logo

Options

Language

A

Information

English

Deutsch

Español

Italiano

Français

Português

r Main: “Language” menu

Image adj.

Set up

Logo

Options

Language

A

Information

Input
Switcher
Source

Lamp time

t Main: “Information” menu

32

ENTER

15sec ON

5sec OFF

OFF ON

OFF ON

ENTER

VIDEO

CH.0

NTSC

1234 h

9 “Capture menu”

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Color profile

HDTV

MacRGB

NTSC

PAL

EXIT

w “Color profile” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Sleep time[min]

Menu color
PC2(BNC)
DIST
SCART
RS-232C[bps]
SXGA
PC3

6015 30 OFF

OFF ON

RGB YPbPr

OFF ON

OFF ON

9600

19200

1280

1400

PC

HDCP

e Main: “Options” menu (“Page 2”)

Notes

• The display language of the menus is set to “English” when
the projector is bought. The display language can be se­lected from among 8 languages. (☞ page 39)

However, certain phrases and nouns, etc., are displayed

only in English.

• The menu screen for HDCP compatible signal input is
the same as when PC input is selected.

p “Capture start”

When PC input is selected

Adjustments and Settings Using Menus

SubmenuMain menu

Image adj.

Set up

Logo

Options

Language

A

Information

Contrast
Brightness
Color
Tint
Sharpness
Color temp.
Reset

12
12
12
12

1

ENTER

ENTER

1 Main: “Image adj.” menu

Image adj.

Set up

R

Logo

GB

Options

A

Language

Information

Position
Tracking
Phase
Resize
Clamp

Sync level

ENTER

123

12

ENTER

ST BP

Low Std High

3 Main: “Set up” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Logo disp.

Logo pos.
Back color

Logo delete

Capture menu

OFF ON

Blue Black

ENTER

ENTER

8 Main: “Logo” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Color temp.

RED
GREEN
BLUE

D65

2 “Color temp.” menu

Position

Menu pos.

Horiz.disp.pos.

Vert.disp.pos.

Horiz.DIST pos.

R

GB

A

Image adj.

Set up

Logo

Options

Language

Information

4 “Position” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Resize

1:1 Panel ZoomAspect

7 “Resize” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Capture menu

Menu pos.

Horiz.move

Vert.move

Horiz.size

Vert.size

Capture start

(-) (+)

(-) (+)

9 “Capture menu”

HIGH User

12

12

1

12

12

ENTER

Capt.in prog.(approx. 2min)

Signal can not be captured

Reduce capt.size

p “Capture start”

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Color profile
Menu display
Line display
Flip H
Flip V
Page 2

ENTER

15sec

5sec OFF

OFF ON

OFF ON

ENTER

ON

q Main: “Options” menu (“Page 1”)

Image adj.

Set up

Logo

Options

Language

A

Information

English

Deutsch

Español

Italiano

Français

Português

r Main: “Language” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Input

Switcher

Resolution

Frequency H

Frequency V

Lamp time

PC1

CH.0

1280 X 1024

63.98kHz

60.02 Hz

1234 h

t Main: “Information” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Color profile

HDTV

MacRGB

NTSC

PAL

EXIT

w “Color profile” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Sleep time[min]

Menu color
PC2(BNC)
DIST
SCART
RS-232C[bps]
SXGA
PC3

6015 30 OFF

OFF ON

RGB YPbPr

OFF ON

OFF ON

9600

19200

1400

1280

PC

HDCP

e Main: “Options” menu (“Page 2”)

Notes

• The display language of the menus is set to “English” when
the projector is bought. The display language can be se­lected from among 8 languages. (☞ page 39)
However, certain phrases and nouns, etc., are displayed
only in English.

• The menu screen for HDCP compatible signal input is
the same as when PC input is selected.

33

Adjustments and Settings Using Menus

ENTER

ENTER

ENTER

When no image signal is inputted

SubmenuMain menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Position

Deinterlace
HDTV
Aspect ratio
Decoder
Phase

ENTER

Auto OFF

1080i 1035i sF

ENTER

ENTER

12

3 Main: “Set up” menu

(When video input is selected)

Image adj.

Set up

R

Logo

GB

Options

A

Language

Information

Position

Tracking
Phase
Resize
Clamp

Sync level

ENTER

123

12

ENTER

ST BP

Low Std High

3 Main: “Set up” menu

(When PC input is selected)

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Color profile

Menu display
Line display
Flip H
Flip V
Page 2

ENTER

15sec

5sec OFF

OFF ON

OFF ON

ENTER

ON

q Main: “Options” menu (“Page 1”)

Position

Menu pos.

Horiz.disp.pos.

Vert.disp.pos.

Horiz.DIST pos.

12

12

1

R

GB

A

Image adj.

Set up

Logo

Options

Language

Information

4 “Position” menu

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Sleep time[min]

Menu color

PC2(BNC)
DIST

SCART
RS-232C[bps]
SXGA
PC3

6015 30 OFF

OFF ON

RGB YPbPr

OFF ON

OFF ON

9600

19200

1280

1400

PC

HDCP

e Main: “Options” menu (“Page 2”)

R

GB

A

Image adj.

Set up

Logo

Options

Language

Information

English

Deutsch

Español
Italiano

Français

Português

r Main: “Language” menu

R

GB

A

Image adj.

Set up

Logo

Options

Language

Information

Input

Switcher

Lamp time

PC1

CH.0

1234 h

t Main: “Information” menu

Notes

• The display language of the menus is set to “English” when
the projector is bought. The display language can be se­lected from among 8 languages. (☞ page 39)
However, certain phrases and nouns, etc., are displayed
only in English.

• The menu screen for HDCP compatible signal input is
the same as when PC input is selected.

34

Adjustments and Settings Using Menus

EXIT

The Menu Operation Buttons

The menus are accessed and operated using the following buttons on
the projector/remote control:

LAMP

PC

V-KEYSTONE

MENU

PRESET

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

STAND BY

TEMP

OPERATE

VIDEO

H-KEYSTONE VOL.

EXIT

ENTER

HIDE

OPERATE

W

DIGITAL

SCREEN

ZOOM

S

FREEZE

FOCUS

QUICK ALIGN.

Menu
operation
button

Button

Main unit Remote control unit

MENU

ENTER

EXIT

MENU

ENTER

ENTER

Main unit

ENTER

Function

Displays the main menu on the
screen.

•When the main menu is displayed,
press to exit the menu mode.

Confirm the selected item on main
menu.
Press to shift to the “Set up” screen
of the selected item against which
[ENTER] is displayed.

Press to return to the previous menu.

• While the main menu is displayed,
press to exit the menu mode.

 /  : Select menu items and ad-

justment items.

 /  :Perform setting of the se-

lected adjustment item.
(Some items are not possi­ble for setting)
The adjusted value will be
reflected to the image im­mediately.

MENU EXIT

ENTER

PRESET HIDE

Menu operation
button

Remote control unit

35

Adjustments and Settings Using Menus

ENTER

ENTER

ENTER

The Procedure for Menu Operation

1.

Press the [MENU] button

The main menu is displayed on the screen.

LAMP

TEMP

PC

VIDEO

V-KEYSTONE

H-KEYSTONE VOL.

MENU

ENTER

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

FOCUS

MENU EXIT

ENTER

PRESET HIDE

W

SCREEN

S

STAND BY

OPERATE

MENU

EXIT

OPERATE

DIGITAL

ZOOM

FREEZE

QUICK ALIGN.

1

6
3, 5

5
2, 4

1
6

3, 5
5
2, 4

Image adj.

Set up

Logo

Options

Language

A

Information

Contrast
Brightness
Color
Tint
Sharpness
Color temp.
Reset

12
12
12
12

1

ENTER

ENTER

The icon of the selected menu
item will be highlighted.

The menu item currently
selected is displayed.

E.g. Main menu when video input

is selected: “Image adj.”

2.

Press the cursor buttons (/) to select a main menu
item

• The content of the selected item is displayed on the right side of
the screen.

• When “Information” is chosen, the image input or PC input infor­mation (whichever is currently selected) is displayed on the right
of the menu.

• When “Language” is selected, you can set the language. ➔ Pro-
ceed to Procedure 6.

3.

Press [ENTER] or cursor (  ) to confirm the menu item

• The menu indicated differs according to whether Video input or
PC input is selected, or when there is no image signal inputted.
For details, please see ‘The Menu Configuration’ on the next page.

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Position

Deinterlace
HDTV
Aspect ratio
Decoder
Phase

E.g. “Set up” menu when video

input is selected

4.

Press the cursor buttons (/) to select an adjustment

ENTER

Auto OFF

1080i 1035i sF

ENTER

ENTER

12

Image adj.

Set up

R

Logo

GB

Options

A

Language

Information

Position

Tracking
Phase
Resize
Clamp

Sync level

Low Std High

E.g. “Set up” menu when PC

input is selected

item

• Adjustment item names displayed in pale cannot be selected.

5.

Press the cursor buttons ( / ) to change the setting
value

ENTER

123

12

ENTER

ST BP

36

Alternatively, press [ENTER].

• When the item in the image adjustment menu against which

[ENTER] is indicated is selected, either it will shift to the set
up screen or the item command will be executed.

6.

To exit after the adjustment, press the [EXIT] button

• Each time you press the button, the menu returns to the previous
one.

7.

Repeat procedures 2 to 6 to set other items

After all adjustments are done,

Press the [MENU] button.
The menu will disappear from the screen.

Adjustment and Setting Using Menus

The Menu Configuration

Item values shown in { } are initial values set at manufacture.

• Press [ENTER], [EXIT] or the right cursor button (
ate a menu while it is displayed.

• The menu items corresponding to an item currently selected
is displayed on the right-hand side of the main menu.

• Menu items shown differ according to whether Video input or
PC input is selected or when there is no image signal input­ted.

• When “Information” is selected, information relating to the
present selected image input appears on the right side of the
menu.
There is no submenu for this “Information” menu. (For details,
please see ‘The Menu Structure’ on page 32.)



) to oper-

1 “Image adj.” menu

Image adjustment.
You can adjust the following items on the “Image adj.” menu.

• There is no display when no image signal is inputted.

When Video input is selected When PC input is selected

Adjustment item (press/) Adjustment content (press/ )

“Contrast” Adjusts the contrast of the picture image.

“Brightness” Adjusts the brightness of the picture im-

“Color” Adjusts the color density of the picture

“Tint” Adjusts the tint of the picture image.

“Sharpness”* Adjusts the outline of the picture image.

“Color temp.” Adjust the Color temperature of the

“Reset” Resets all items in the “Image adj.”

* In the “Set up” menu 3, if the “Resize” function in the PC submenu is

set to “1:1”, the image quality will not change even if the value is
changed. (No adjustment)

Range of values: –30 - 30 {0}

age. Range of values: –30 - 30 {0}

image. Range of values: –30 - 30 {0}

Range of values: –30 - 30 {0}

Range of values: –3 - 3 {0}

screen.
[ Press the [ENTER] button to enter the

Color temperature setting menu 2.

submenu to the pre-set values (i.e. val­ues set upon purchase).
[ Press the [ENTER] button to reset.

2 “Color temp.” menu

To adjust the “Color temp.” of the projected image, press the (/)
cursor buttons and choose the setting. Next press the (/) cursor
buttons to set the “Color temp.”. If “D65” is set, the image will turn out
reddish.

Set value : “D65”, “HIGH”, “User” {“D65”}
“RED” : –255 - 0 {0}
“GREEN” : –255 - 0 {0}
“BLUE” : –255 - 0 {0}

3 “Set up” menu

Use this menu to set the basic Tracking and Positioning settings of a
picture image. Items that can be adjusted via the “Set up” menu are
shown below.

• Displaying items differ depending on whether Video input or PC input
is selected.

When Video input is selected

Adjustment item (press/) Adjustment content (press/ )

“Position” Adjusts the position of the image and

menu display.
[ Press the [ENTER] button to enter the

“Position” menu 4.

“Deinterlace” This is set when viewing movies.

Set value : “Auto”, “OFF” {“Auto”}
“Auto” : Normally, the projector

is set to “Auto”.

“OFF” : This is set when not

viewing movies.

“HDTV” In order to display “HDTV” signals in the

exact aspect ratio of 16:9, the correct nu­merical value has to be set.
Set value : “1080i”, “1035i”, “sF”

{1080i}
“1080i” : Normally, set to “1080i”.
“1035i” : Set when high vision

signals are used.

“sF” : Used for segment

frame signals.

“Aspect ratio” Select the vertical-to-horizontal ratio of

the image projected.
[ Press the [ENTER] button to enter the

“Aspect ratio” menu 5.

“Decoder” Sets the “Decoder”.

[ Press the [ENTER] button to enter the

“Decoder” menu 6.

“Phase” Adjusts flickering or dim images.

(setting is normally not required.)
Range of values: 0 - 31

{Varies with signals}

When PC input is selected

Adjustment item (press/) Adjustment content (press/ )

“Position” Adjusts the position of the image and

menu display.
[ Press the [ENTER] button to enter the

“Position” menu 4.

“Tracking” Adjusts lateral size and display area of

image. (Setting is normally not required.)

{Varies with signals}

“Phase” Adjusts flickering or dim image.

(adjustment is normally not required.)
Range of values: 0 - 40

{Varies with signals}

“Resize” To set the way to display in the panel in-

put signals that have fewer pixels (lower
resolution) than D-ILA elements.
[ Press the [ENTER] button to enter the

“Resize” menu 7.

“Clamp” This can be used if the screen of the PC/

workstation is unstable in that it dims and
brightens.
Set the position of the clamp pulse to
Back porch (“BP”) or Sync tip (“ST”).
Normally, “BP” is used.
Values : “ST”, “BP” {“BP”}

37

Adjustments and Settings Using Menus

When there is no image signal inputted

Adjustment item (press/) Adjustment content (press/ )

“Position” Adjusts the position of the image and

“Sync level” Although the inputted image signal is
(When PC input is
selected)

menu display.
[ Press the [ENTER] button to enter the

“Position” menu 4.

adjusted so that synchronization occurs
automatically, this changes by changing
this setup.
Setting can be made by selecting “Low”
(weaker), “Std” (factory set) or “High”
(stronger).
Values : “Low”, “Std”, “High” {“Std”}

4 “Position” menu

You can adjust the menu display position. Press the (/) cursors to
set the horizontal/vertical position of the menu display.

Set Value :
“Menu pos.” :

“Horiz. disp. pos.” : Varies with signals.
“Vert. disp. pos.” : Varies with signals.
“Horiz. DIST pos.” : –8 - +7 {0}

¥¥¥¥¥¥¥¥

{ }

5 “Aspect ratio” menu

Press the cursor ( / ) to set the aspect ratio of image.
(☞ page 41, 42)

Setting value : “4:3”, “16:9”, “Zoom” * {varies with signals}
* When creating a 16:9 image with black bars above and below the

screen from the signal with original aspect ratio of 4:3, the image will
be enlarged to full screen on the panel if “Aspect ratio” is set to “Zoom”.

6 “Decoder” menu

Press the (/) cursor buttons to choose the “Decoder” of the image
signals. Normally, “AUTO” is selected. When “AUTO” does not function
or when there is error, select the appropriate color system according to
the software player.

8 “Logo” menu

Adjustment item (press/) Adjustment content (press/ )

“Logo disp.” Sets whether to indicate the user set logo

“Logo pos.” Sets the position of the user set logo (cap-

Set value :
“Logo pos.” :

“Back color” Selects the background color of the user

“Logo delete” Deletes the user set logo (captured

“Capture menu” You can project a picture from the video

(captured image: “Logo disp.”) when the
projector starts up.

{“ON”}

tured image: “Logo disp.”) when the pro­jector starts-up. Re-setting can be per­formed only when the logo has been
eliminated.

¥¥¥¥¥¥¥¥

{ }

set picture (captured image: “Logo disp.”).

{“Black”}
Re- setting can be performed only when
the logo has been eliminated.

image: “Logo disp.”). Deletion takes a few
seconds.
[ Press the [ENTER] button to delete.

player or PC and capture it to use as your
logo.
The captured picture can be displayed as
a logo display when the projector starts
up.
[ Press the [ENTER] button to enter the

“Capture menu” 9.

9 “Capture menu”

Adjustment item (press/) Adjustment content (press/ )

“Menu pos.” Adjusts the display position of the cap-

Set value :
“Menu pos.” :

ture menu.

¥¥¥¥¥¥¥¥

{ }

Values : “AUTO”, “NTSC”, “NTSC4.43”, “PAL”, “SECAM”

{“AUTO”}

7 “Resize” menu

Press the cursor ( / ) to resize.
(☞ page 43, 44)

Setting value : “1:1”, “Panel”, “Aspect”, “Zoom”

{varies with signals}
“1:1” : The image is displayed at the inputted resolution.
“Panel” : The picture image projected is virtually enlarged

to the full screen size if the inputted resolution is
smaller than (1400 pixels x 788 pixels).

“Aspect” : While maintaining the original aspect ratio, the

video image projected is virtually enlarged until ei­ther the horizontal or vertical side reaches the full
size (1400 pixels x 788 pixels).

“Zoom” : The picture image projected is virtually enlarged

to the full screen size if the 16:9 image is created
with black bars above and below the screen from
the signal with original aspect ratio of 4:3.

38

“Horiz. move” The position of the picture that you want

to capture can be moved left or right with
the cursor buttons ( / ).

“Vert. move” The position of the picture that you want

to capture can be moved up or down with
the cursor buttons ( / ).

“Horiz. size” The width of the picture that you want to

capture can be set by the cursor buttons
( / ).

“Vert. size” The height of the picture that you want to

capture can be set by the cursor buttons
( / ).

“Capture start” After setting all the items of the capture

menu, image capture starts.
❈ Note that images already inputted will

be deleted.

[ Press the [ENTER] button to start.

Adjustments and Settings Using Menus

p “Capture start”

The status of capture is displayed in bold.

“Capt. in prog. (approx. 2min)”

“Signal can not be captured”

“Reduce capt. size”

The image is being read into the projec­tor. During this time interval, the projec­tor will not respond to any command sig­nal inputted by the user.

Clear the message with the [EXIT] but­ton and input appropriate signals.

Clear the message with the [EXIT] but­ton and decrease the signal size.

• Depending on the image content,
there will be cases where certain sig­nals cannot be captured while others
of the same size can be.

q “Options” menu (“Page 1”)

The items of the “Options” menu shown below can be adjusted.

• The “Options” menu consists of two pages (“Page 1” and “Page 2”).

“Page 1”

Adjustment item (press/) Adjustment content (press/ )

“Color profile” Sets the color table.

“Menu display” Sets whether the menu display automati-

“Line display” Sets whether the line display is shown for

“Flip H” Reverses image left to right.

“Flip V” Inverses image upside down.

“Page 2” Displays “Page 2” of the “Options” menu.

[ Press the [ENTER] button to enter the

“Color profile” menu w.

cally clears after 15 seconds.
Values : “15sec”, “ON” {“15sec”}

about 5 seconds.
Values : “5sec”, “OFF” {“5sec”}

Values : “ON”, “OFF” {“OFF”}

Values : “ON”, “OFF” {“OFF”}

[ Press the [ENTER] button to enter the

“Options” menu (“Page 2”) e.

w “Color profile” menu

To choose the color table of the image signals, press the (/) CUR­SOR buttons. When using “Color profile”, set the “Color temp.” to “D65”.

• No display in the absence of image signal input.
Values : “------”, “HDTV”, “MacRGB”, “NTSC”, “PAL”

{Varies with signals}

e “Options” menu (“Page 2”)

Adjustment item (press/) Adjustment content (press/ )

“Sleep time[min]” Sets the length of sleep time which, when

lapsed, automatically puts the projector
into stand-by state if no signal is input­ted.
Setting value: “15”, “30”, “60”, “OFF”

{“OFF”}

“Menu color” When “ON”, menu becomes transparent

and the background can be seen through
it.
Setting value: “OFF”, “ON” {“OFF”}

“PC2(BNC)” Sets whether to use the BNC connector

on the back of the projector as an “RGB”
signal input terminal or as a “YPBPR”
(color-difference) signal input terminal.
Please reset it based on the connected
apparatus.

• The input will be “RGB” irrespective
of the PC signal setting.

Setting value: “RGB”, “YPbPr” {“YPbPr”}

“DIST” Image of high resolution can be achieved.

Set as required.
This is turned “ON” when the [OPERATE]
button is pressed.
Setting value: “OFF”, “ON”

{Varies with signals}

“SCART” Connects to a Europe-adapted SCART

plug and turns it “ON” during component
input.
Connect the Image Signal cable to the
[RGB] terminal of the [PC2] input termi­nal and the Sync Signal cable to the
[VIDEO IN] terminal.
Setting value: “OFF”, “ON” {“OFF”}

“RS-232C [bps]” Sets the communication speed (signal

transmission speed) when communicat­ing with a computer by using the [RS­232C] terminal. Please set the baud rate
for transmission.
Setting value: “9600”, “19200” {19200}

“SXGA” Select “1400” to project SXGA+ signal.

Setting value: “1280”, “1400” {1280}

“PC 3” Set whether to use PC input or HDCP

compatible video signal when using [PC3]
terminal as input. Set according to the
connecting equipment.
Setting value : “PC”, “HDCP” {“HDCP”}

r “Language” menu

Select the language in this language menu with the CURSOR buttons
(/).

Setting value : [ ] (Japanese), [English], [Deutsch] (German),

[Español] (Spanish), [Italiano] (Italian), [Français]
(French), [Português] (Portuguese) and [ ]
(Korean).

{[English]}

• Some words in the menu and proper nouns such as “VIDEO”, “NTSC”,
“QUICK ALIGN...” are shown only in English.

39

Adjustments and Settings Using Menus

t “Information” menu

Displays the information such as image input currently selected, other
information and lamp usage time.

When video input is selected

“Input” Displays the image input [VIDEO], [Y/C],

“Switcher” Displays the selected switcher matching

“Source” Displays the type of video signal of the

“Lamp time” Displays the number of accumulated used

[PC2]) when projecting.

the specification of this projector.
“0” : not being used.
“1-10” : switcher number.
For details, please check with your au-

thorized dealer.

image projected.

hours of the light-source lamp.

When PC input is selected

“Input” Displays the computer input ([PC1],

“Switcher” Displays the selected switcher number

“Resolution” Displays the resolution of the inputted sig-

“Frequency H” Displays the horizontal frequency of the

“Frequency V” Displays the vertical frequency of the in-

“Lamp time” Displays the number of accumulated used

[PC2], [PC3]) when projecting.

matching the specification of this projec­tor.
“0” : not being used.
“1-10” : switcher number.
For details, please check with your au-

thorized dealer.

nal. (Horizontal x vertical)

• Some inputted signals cannot be dis­played correctly.

inputted signal.

putted signal.

hours of the current light-source lamp.

When no image signal is inputted

“Input” Displays the current selected image in-

“Switcher” Displays the selected switcher number

“Lamp time” Displays the number of accumulated used

put ([VIDEO], [Y/C], [PC1], [PC2], [PC3])
when projecting.

matching the specification of this projec­tor.
“0” : not being used
“1-10” : switcher number.
For details, please check with your au-

thorized dealer.

hours of the light-source lamp.

40

Setting “Aspect ratio” and “Resize”

ENTER

ENTER

ENTER

ENTER

ENTER

ENTER

By setting the “Aspect ratio” and “Resize” of the projected input image, optimum image can be projected onto the screen.

Setting the “Aspect ratio”

Set the “Aspect ratio” when image is input from the [VIDEO], [Y/C] or
[PC2] terminals.

1.

Project the image onto the screen

LAMP

TEMP

PC

VIDEO

V-KEYSTONE

H-KEYSTONE VOL.

MENU

ENTER

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

FOCUS

MENU EXIT

ENTER

PRESET HIDE

W

SCREEN

S

STAND BY

OPERATE

MENU

EXIT

OPERATE

DIGITAL

ZOOM

FREEZE

QUICK ALIGN.

2

3, 4

3, 4

2

3, 4

3, 4

4:3 image recorded in letterbox
(black bars above and below the
screen) such as in DVD software.

2.

Press the [MENU] button

• The main menu appears on the screen.

Contrast
Brightness
Color
Tint
Sharpness
Color temp.
Reset

Press the cursor buttons ( / ) to select “Set up” and

A

3.

Image adj.

Set up

Logo

Options

Language

Information

12
12
12
12

1

ENTER

ENTER

press [ENTER] or cursor (  )

• The “Set up” menu appears on the right side of the screen.

Position

Deinterlace
HDTV
Aspect ratio
Decoder
Phase

Select “Aspect ratio” with the cursor buttons ( / ) and

4.

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

ENTER

Auto OFF

1080i 1035i sF

ENTER

ENTER

12

press [ENTER]

• The “Aspect ratio” menu appears on the screen.

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Position
Deinterlace
HDTV

Aspect ratio

Decoder
Phase

ENTER

Auto OFF

1080i 1035i sF

ENTER

ENTER

12

R

GB

A

Image adj.

Set up

Logo

Options

Language

Information

Aspect ratio

4:3 16:9 Zoom

41

Setting “Aspect ratio” and “Resize”

PRESET HIDE

ENTER

MENU EXIT

STAND BY

TEMP

LAMP

PC

V-KEYSTONE

OPERATE

MENU

VIDEO

H-KEYSTONE VOL.

6

5.

Select “Zoom” with the cursor buttons

( / )

• Set “Aspect ratio” to “Zoom” for optimum projected image.

Aspect ratio

4:3 16:9 Zoom

Press the [MENU] button to end when adjustment is com-

A

6.

Image adj.

Set up

R

Logo

GB

Options

Language

Information

pleted

• The menu disappears from the screen.

ENTER

EXIT

5

MENU

6

5

 The relation between the input image and the projected image according to the setting of “Aspect ratio”

menu

The setting of “Aspect ratio” menu when input terminal is

Input image

“4:3”

[VIDEO], [Y/C] or [PC2]

“16:9” “Zoom”

SDTV(4:3)

HDTV(16:9)

SDTV(4:3)

Images recorded in

letterbox (black bars

above and below the

screen) such as in DVD

software.

42

Image loss : No
Aspect ratio : Same

Optimum image

Image loss : No
Aspect ratio : Portrait

Image is stretched

vertically

Image loss : No
Aspect ratio : Same

Image cannot be largely

projected

Image loss : No
Aspect ratio : Landscape

Image is stretched

horizontally

Image loss : No
Aspect ratio : Same

Optimum image

Image loss : No
Aspect ratio : Landscape

Image is stretched

horizontally

Image loss : Yes
Aspect ratio : Same

Image is chopped off at

the upper and lower

portion

Image loss : Yes
Aspect ratio : Portrait

Image is stretched

vertically and chopped

off at the upper and

lower portion

Image loss : No
Aspect ratio : Same

Optimum image

LAMP

ENTER

ENTER

PC

V-KEYSTONE

MENU

STAND BY

TEMP

OPERATE

MENU

VIDEO

H-KEYSTONE VOL.

ENTER

EXIT

2

3, 4

3, 4

Setting “Aspect ratio” and “Resize”

Setting the “Resize”

Set the “Resize” when HDCP image is input from [PC3] terminal.

1.

Project the image onto the screen

4:3 image recorded in letterbox
(black bars above and below the
screen) such as in DVD software.

2.

Press the [MENU] button

• The main menu appears on the screen.

Image adj.

Set up

Logo

Options

Language

A

Information

3.

Press the cursor buttons ( / ) to select “Set up” and

Contrast
Brightness
Color
Tint
Sharpness
Color temp.
Reset

press [ENTER] or cursor (  )

• The “Set up” menu appears on the right side of the screen.

12
12
12
12

1

ENTER

ENTER

FOCUS

ENTER

W

SCREEN

S

OPERATE

DIGITAL

FREEZE

QUICK ALIGN.

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

MENU EXIT

PRESET HIDE

Image adj.

Set up

R

Logo

GB

Options

A

Language

Information

ZOOM

4.

Select “Resize” with the cursor buttons ( / ) and press

Position

Tracking
Phase
Resize
Clamp

Sync level

ENTER

123

12

ENTER

ST BP

Low Std High

[ENTER]

• The “Resize” menu appears on the screen.

2

3, 4

R

GB

A

Image adj.

Set up

Logo

Options

Language

Information

Position
Tracking
Phase

Resize

Clamp
Sync level

ENTER

123

12

ENTER

ST BP

Low Std High

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Resize

1:1 Panel ZoomAspect

3, 4

43

Setting “Aspect ratio” and “Resize”

PRESET HIDE

ENTER

MENU EXIT

5.

Select “Zoom” with the cursor buttons

• Set “Resize” to “Zoom” for optimum projected image.

( / )

LAMP

PC

V-KEYSTONE

MENU

STAND BY

TEMP

OPERATE

MENU

VIDEO

H-KEYSTONE VOL.

EXIT

ENTER

6

5

6

5

Resize

1:1 Panel ZoomAspect

Press the [MENU] button to end when adjustment is com-

6.

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

pleted

• The menu disappears from the screen.

 The relation between the input image and the projected image according to the setting of “Resize” menu

Input image

SDTV(4:3)

HDTV(16:9)

SDTV(4:3)

Images recorded in

letterbox (black bars

above and below the

screen) such as in DVD

software.

The setting of “Resize” menu when input terminal is [PC3] and with HDCP signal input.

“1:1” “Panel” “Aspect” “Zoom”

Image loss : No
Aspect ratio : Same

Image cannot be largely

projected

Image loss : Yes
Aspect ratio : Same

There may be cases

where only the upper left

portion of the image is

projected

Image loss : No
Aspect ratio : Same

Image cannot be largely

projected

Image loss : No
Aspect ratio : Landscape

Image is stretched

horizontally

Image loss : No
Aspect ratio : Same

Aspect ratio may

change

Image loss : No
Aspect ratio : Landscape

Image is stretched

horizontally

Image loss : No
Aspect ratio : Same

Optimum image

Image loss : No
Aspect ratio : Same

Optimum image

Image loss : No
Aspect ratio : Same

Image cannot be largely

projected

Image loss : No
Aspect ratio : Same

Image is chopped off at

the upper and lower

portion

Image loss : Yes
Aspect ratio : Portrait

Image is stretched

vertically and chopped

off at the upper and

lower portion

Image loss : No
Aspect ratio : Same

Optimum image

44

Editing and Projecting Logo

ENTER

ENTER

ENTER

ENTER

ENTER

ENTER

ENTER

ENTER

You can project your logo if you like when you start up the projector.
This may come in useful during presentations, etc.

1.

Project the images to be included in your logo

MOTOR SHOW

2

4

2
4

V-KEYSTONE H-KEYSTONE VOL.

FOCUS

ENTER

ENTER

W

SCREEN

S

EXIT

OPERATE

DIGITAL

FREEZE

QUICK ALIGN.

MENU

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

MENU EXIT

PRESET HIDE

Screen display

2.

Press the [MENU] button

• The main menu appears on the screen.

3,5

3.

ZOOM

4.

Image adj.

Set up

Logo

Options

Language

A

Information

Select “Logo” with the cursor buttons ( / )

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Press the [ENTER] or the right cursor button ( )

Contrast
Brightness
Color
Tint
Sharpness
Color temp.
Reset

Logo disp.

Logo pos.
Back color

Logo delete

Capture menu

12
12
12
12

1

ENTER

ENTER

OFF ON

Blue Black

ENTER

ENTER

• The “Logo” menu appears on the screen.

ON

3,5

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

Logo disp.

Logo pos.
Back color

Logo delete

Capture menu

OFF

Blue Black

ENTER

ENTER

Notes

• Setting the logo display item in the “Logo”
menu to “ON” and switching on the power dis­plays the D-ILA logo and then the user-set
logo. (Factory setting is “ON”)

• When the D-ILA or user-set logo is displayed
after the projector is turned on, pressing the
[EXIT] button will delete the logo.

• During video signal input, pressing the [EXIT]
button on the remote control unit when the
menu is not displayed causes the logo to ap­pear.
Press any other button to delete the logo from
the screen.

• The capture frame may disappear from the
screen when “Aspect ratio” is set to “Zoom”
during video signal input or when “Resize” is
set to “Zoom” during PC signal input. When
this happens, display the capture frame as
described below.

· Set setting to other than “Zoom”

· Move the frame upwards and downwards

· Change the vertical size of the frame

5.

Select “Capture menu” with the

cursor

buttons ( / )

and press [ENTER]

OFF

Image adj.

Set up

R

Logo

GB

Options

Language

A

Information

6.

The captured picture appears on the screen

Logo disp.

Logo pos.
Back color

Logo delete
Capture menu

• The captured picture (i.e. your logo) with a frame appears on the
screen.

Screen display

ON

Blue Black

ENTER

ENTER

45

Editing and projecting logo

ENTER

ENTER

ENTER

Image adj.

Set up

Logo

Options

Language

Information

A

ENTER

(-) (+)

12

GB

R

Capture menu

Menu pos.

Horiz.move

Vert.move

Horiz.size

Vert.size

Capture start

(-) (+)

12

ENTER

Image adj.

Set up

Logo

Options

Language

Information

A

(-) (+)

12

(-) (+)

12

GB

R

Capture menu

Menu pos.

Horiz.move

Vert.move

Horiz.size

Vert.size

Capture start

ENTER

V-KEYSTONE H-KEYSTONE VOL.

ENTER

EXIT

7-12

MENU

12

FOCUS

W

SCREEN

S

OPERATE

DIGITAL

ZOOM

FREEZE

QUICK ALIGN.

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

7.

Set the menu position as required

• Select “Menu pos.” with the cursor buttons ( / )

•Move the menu display position with the cursor buttons (
while viewing the projected image.

Capture menu

Image adj.

Menu pos.

Set up

Horiz.move

Logo

Options

Language

Information

Vert.move

Horiz.size

Vert.size

Capture start

(-) (+)

12

(-) (+)

12

ENTER

Select “Horiz. move” with the

cursor

buttons ( / )

8.

R

GB

A

•Move the logo left or right with the cursor buttons ( / ) while
viewing it on the screen.

Capture menu

Image adj.

Menu pos.

Set up

Horiz.move

Logo

Options

Language

Information

Vert.move

Horiz.size

Vert.size

Capture start

(-) (+)

12

(-) (+)

12

ENTER

Select “Vert. move” with the cursor buttons ( / )

9.

R

GB

A

•Move the logo up or down with the cursor buttons ( / ) while
viewing it on the screen.

Capture menu

Image adj.

Menu pos.

Set up

Logo

Options

Language

Information

Horiz.move

Vert.move

Horiz.size

Vert.size

Capture start

(-) (+)

12

(-) (+)

12

ENTER

R

GB

A



/ )

MENU EXIT

ENTER

PRESET HIDE

7-12
12

“Capt. in prog. (approx. 2min)”

The image is being read into the projector. During this time
interval, the projector will not respond to any command
signal inputted by the user.

Capt.in prog.(approx. 2min)

Signal can not be captured

Reduce capt.size

“Signal can not be captured”

Clear the message with the [EXIT] button and input ap­propriate signals.

“Reduce capt. size”

Clear the message with the [EXIT] button and decrease
the signal size.

• Depending on the image content, there will be cases
where certain signals cannot be captured while others
of the same size can be.

46

10.

Select “Horiz. size” with the cursor buttons ( / )

• Set the width with the cursor buttons ( / ) while viewing the
projected image.

11.

Select “Vert. size” with the cursor buttons ( / )

• Set the height with the cursor buttons ( / ) while viewing the
projected image.

Capture menu

Image adj.

Menu pos.

Set up

R

GB

A

12.

Horiz.move

Logo

Vert.move

(-) (+)

Options

Language

Information

Horiz.size

Vert.size

Capture start

12

(-) (+)

12

ENTER

Select “Capture start” with the cursor buttons ( / )
and press [ENTER]

• Begin to capture the framed image set in the procedures 8 to 11
from the projected image.

• The captured picture will be taken into memory as a logo in the
projector and will be shown during start-up.

Replacing the Lamp

The light source lamp and its lamp time

The light-source lamp has a service life. The life of lamps currently used for this projector is about 2000 hours.
[Average lamp life: 2000 hours]
When the light-source lamp approaches the end of its service life, deterioration progresses rapidly. Please install a new lamp when
the accumulated lamp time exceeds 1900 hours or at least get a replacement lamp ready. Depending on the operating conditions,
the lamp may have to be changed earlier. If the image remains dark or the tone, unusual, even after adjustment, please replace the
lamp as soon as possible. You can check the accumulated used hours of the lamp via the “Lamp time” item in the “Information”
menu. (☞ page 40)

Please purchase the new lamp unit from the authorized dealer where you purchased the projector.

Exchange lamp Part No.: BHL5006-S

 When lamp time exceeds 1000 hours:

When the accumulated lamp time reaches 1000, a mes­sage indicating “1000h” will appear on the projected screen.

• Press [EXIT] button to delete the message.

 When lamp time exceeds 1900 hours:

● When the accumulated lamp time reaches 1900 hours:

The [LAMP] indicator on the projector lights up.

● When the accumulated lamp time exceeds 1900 hours:

“Lamp replacement” appears on the screen.
* Press [EXIT] button to delete the message.

● When the lamp time exceeds 2000 hours:

The lamp indicator on the projector blinks.
“Warning” and “Lamp replacement” appear on the screen;
the word “Warning” blinks.

•To cancel the message, press the [EXIT] button.
However, the same message will appear again every one
hour.

❈ Once the lamp time exceeds 2000 hours, and the projec-

tor is either put into the standby state or turned off, pro­jection will not be possible again until the lamp is replaced
and the lamp time is reset. (☞ page 49)

● When the lamp time exceeds 2010 hours:

The projector quits and shuts down.
❈ The projector does not turn on unless the lamp (lamp unit)

is replaced and the lamp time is reset. (☞ page 49)

About lamp replacement

● If the projector is set in a constricted place, attempting to replace the lamp in that place could cause injury. Move the projector

to a place large enough to work in.

● To avoid malfunctions, be sure to use only genuine replacement parts. Also, never attempt to re-use an old lamp as this could

cause marked performance deterioration or lamp blow-out leading to projector malfunction. In the worse case, broken pieces
of glass from the lamp may cause injuries.

● Do not replace the lamp immediately after the projector has been used. The temperature of the lamp unit is still high and

could cause a burn. Allow a cooling period of one hour or more before replacement.

● Before starting to replace the lamp, disconnect the power cord from the wall outlet while the [STAND BY] indicator is on.

Replacing a lamp while the power cord is connected to wall outlet could cause injury or electric shocks.

The procedure for lamp replacement

1.

Loosen the screws and detach the light-source lamp cover

• Loosen the two screws with a ª screwdriver.

2.

Loosen the screws and lift up the handle

• Loosen the two screws with a ª screwdriver.

Handle

47

Replacing the Lamp

3.

Remove the lamp unit.

4.

Insert the new lamp unit until it is fully in.

Caution

• Neither touches the glass surface of the lamp di­rectly with your hand nor stains it. If you touch it with
a bare hand, oil or other substances on your hand
may adhere to the lamp, possibly preventing it from
performing as specified and therefore lead to a short­ened lamp life, a darkened screen, etc.

Lamp unit

5.

Close the handle, and tighten the screw.

• Tighten the two screws with a ª screwdriver.

6.

Attach the light-source lamp cover and tighten

the screw.

• Tighten the two screws with a ª screwdriver.

Note

• When closing the lamp cover, please insert the left
side (with the two claws) in first and then ensure that
the protruding part found on the reverse side of the
cover fits snugly into the hole of the main unit. As
this protrusion acts as a switch, misfitting leads to
power not being able to flow in.

48

Replacing the Lamp

EXIT

PRESET

HIDE

VOL( )

Resetting the lamp time

After installing a new lamp, reset the lamp time counter inside the projector when this is done. A new count will start.
If the display of the accumulated lamp time has reached 2000 hours, the projector will not work (lamp does not light up) unless the
lamp time is reset.

1.

Insert the power cord into the wall outlet

• The [STAND BY] indicator lights up when the main power is input­ted.

2.

Press the [EXIT], [HIDE], [PRESET] buttons on the remote
control sequentially, then press VOL ª for 2 seconds or
more

• The [STAND BY] and [OPERATE] indicators alternately blink about
every approx. 3 seconds. After blinking stops, lamp time resets
and the projector returns to the stand-by state ([STAND BY] indi­cator lights up).

Press as per normal

Press for
2 seconds

PC VIDEO

V-KEYSTONE H-KEYSTONE

VOLUME

FOCUS

W

SCREEN

S

OPERATE

DIGITAL

ZOOM

FREEZE

QUICK ALIGN.

MENU EXIT

EXIT

ENTER

PRESET HIDE

PRESET HIDE

Press for 2 seconds or more

To ensure the lamp time has been reset

The lamp time can be checked via the “Lamp time” item in the “Infor­mation” menu. (☞ page 32, 33, 34, 40)

Caution for reset work

Reset the lamp time only when you have replaced the lamp.
Never reset it while the lamp is still in use, otherwise the approximate
standard for gauging replacement time may be inaccurate, lamp per­formance may suffer and lamp blow-out may also occur.

49

Cleaning and Replacing the Filter

Clean the filter regularly or it may not work satisfactorily, causing damage. If the filter is extremely dirty and cannot be cleaned, or
if it is damaged, replace the filter with a new one (Lower filter: LC32087-002A/ Inner filter: LC32058-001C). Otherwise, dirt may get
inside the unit and appear on the screen, preventing you from enjoying the video fully. If dirt has gotten in or if you need information
about the filter, please consult the authorized dealer where you purchased the projector.

❈ The air inlet filter on the right side cannot be removed. Please clean this filter regularly using, for example, a vacuum

cleaner.

1.

Pull out the power cord from the wall outlet

• After the projector goes into the stand-by state with the
[STAND BY] indicator on, pull out the power cord from
the wall outlet.

2.

Remove the filter

• When removing the lower filter:

Withdraw the lower filter backwards along the rail in the
direction of the arrow.

• When removing the inner filter:

Push the claw at the base of the inner filter in the up­ward direction and draw the filter out.

3.

Clean the filter

• Clean the filter with water and dry it, avoiding direct sun­light. In extremely soiled cases, use of a neutral deter­gent is recommended.

claw

lower filter

inner filter

4.

Reinstalling the filter

• When reinstalling the lower filter:

Reinstall the lower filter by inserting it into the projector.

• When reinstalling the inner filter:

Install the filter after engaging the two claws of the inner
filter to the projector.

● Put on rubber gloves when using a neutral detergent.

● After you wash a filter in water, make sure that the filter is

completely dry before reinstalling, otherwise electric
shocks or malfunctions may occur.

● Do not clean removable filters with a vacuum cleaner.
Since these filters are soft, they can be sucked into the
vacuum cleaner or otherwise damaged.

lower filter

50

inner filter

claw

Troubleshooting

Before consulting your authorized dealer, please check the following points.

Symptom

Power is not sup­plied.

Light is not emitted,
or light is dim.

With power on, the
projector works but
stops abruptly in a
few minutes.

Probable cause Corrective action Page

Is the power cord disconnected?

Is the light-source lamp cover closed correctly?

Is the filter inserted correctly?

Has the lamp life expired? (Has the lamp time
reached 2000 hours?)

Is the lens cap removed?

Is the lamp near exhaustion?

Is the air inlet or exhaust vent area blocked?

• Insert the power cord (plug) firmly.

• After the projector goes into the stand-by
state with the [STAND BY] indicator on, un­plug from the main power outlet, close the
light- source lamp cover correctly and plug in
again.

• After the projector goes into the stand-by
state with the [STAND BY] indicator on, un­plug from the main power outlet, insert the
filter properly and plug in again.

• After the projector goes into the stand-by state
with the [STAND BY] indicator on, un-plug
from the main power outlet, replace light­source lamp and plug in again.
Reset the lamp time after replacing the lamp.

• Remove the lens cap.

• Check the “Lamp time” on the menu, and if
the lamp is near exhaustion, prepare a new
lamp and install as soon as possible.

• After the projector goes into the stand-by state
with the [STAND BY] indicator on, un-plug
from the main power outlet, remove any block­ing object and plug in again.

24

25, 27, 48

25, 27, 50

25, 27, 47, 48, 49

24

47, 48, 49

7, 8, 15, 25, 27

Video image does
not appear, or audio
sound does not oc­cur.

Is the filter dirty?

Is the correct input terminal selected?

Are devices connected correctly?

Are signals being supplied from the connected
devices?

Are input signals (scanning frequency, etc.)
appropriate?

Is “Brightness” adjusted correctly?

Is volume level set at minimum?

Are video and audio temporarily turned off by
the [HIDE] button being pressed?

• Clean filter.

• Select the correct input with the [VIDEO] and
[PC] buttons.

• Connect devices correctly.

• Set connected devices correctly.

• Check if the signal is appropriate (scanning
frequency, etc.) and input the appropriate sig­nal.

• Adjust “Brightness” using the menu.

• Adjust volume with the [VOLUME] buttons.

• Press the [HIDE] button to turn video and au­dio on.

50

25, 26

21, 22

—————

19, 20

37

27

29

51

Troubleshooting

Symptom Probable cause Corrective action Page

Video image is fuzzy.

Video image is ab­normally dark or
bright.

Color is poor or un­stable.

Is the focus adjusted correctly?

Is the projector placed too near or too far from
the screen?

Are “Tracking” and “Phase” adjusted correctly?

Is the “Brightness” adjusted correctly?

Is the picture quality (color density, etc.) ad­justed correctly?

Is the correct “Decoder” selected?

Are signals (scanning frequency, etc.) from the
connected device appropriate?

Is the [PC2] input terminal being used?

• Adjust focus with the focus ring of the lens.

• Set the projector at the correct distance.

• Adjust “Tracking” and “Phase” using the menu.

• Adjust “Brightness” using the menu.

• Adjust picture quality using the menu.

• Set the “Decoder” to “AUTO” or the correct
dedicated decoder.

• If the problem is not rectified after setting to
“AUTO”, set to forced dedicated mode.

• Check if the signal is appropriate (scanning
frequency, etc.), and input the appropriate sig­nal.

• When the [PC2] input terminal is being used,
“PC2(BNC)” must be selected from the
“Options” menu. Set it correctly according to
the input signal.

26

17

37

37

37

38

19, 20

39

The upper part of the
video image bows or
distorts.

Remote control unit
does not work.

If the input signal comes from a computer sys­tem, is this a sync signal of composite sync (Cs)
or G on sync type?

Are signals with much jitter or skew distortion
being input from a video deck?

Are batteries installed correctly?

Are batteries exhausted?

Is there an obstructive object between the re­mote control unit and the remote sensor?

Is the remote control held too far from the sen­sor?

• Input separate sync signals for vertical sync
(V) and horizontal sync (H) signals.

• Input signals with little jitter or skew distor­tion.

• Use a TBC or a device with a built-in TBC.

• Match the polarities of batteries correctly, as
shown on the battery cartridge.

• Replace with new batteries.

• Remove any shielding objects.

• Use the remote control unit at a nearer point.

19, 20

—————

14

14

18

18

• This projector uses a micro computer. External noise may cause it to malfunction. If this happens, unplug from the main power
outlet and then plug on again. (☞ page 25, 27)

52

What to do when these messages are displayed

Message Cause (Contents)

No device is connected to the input terminal.
The terminal is connected but no signal is output from the connected device.

• The selected input mode (input terminal) name is shown above the mes-

PC 1

No Input

PC 1

Frequency of input signal is out of range.

sage.

[ Check the input image signal source.

The frequency of the input video signal is out of range.
[ Please ensure the frequency level of the input video signals is within the

projector’s specifications.

53

What to do when these messages are displayed

Message Cause (Contents)

When the “Lamp time” reaches 1000 hours
[ A message indicating “1000h” appears on the projected screen.

1000h

EXIT

Lamp replacement

EXIT

• Press [EXIT] button to delete the message.

At the moment when the accumulated lamp time reaches 1900 hours, a
“Lamp replacement” message will be displayed.
In addition, when the accumulated lamp time reaches between 1900 hours
to 2000 hours, the “Lamp replacement” message will be displayed each
time the projector is turned on.

● The message can be cleared by pressing the [EXIT] button or dis-

playing the menu.

[ Get ready a new lamp (lamp unit) in advance or replace as soon as

possible.

Lamp replacement

Warning

EXIT

The word “Warning” appears and blinks when the accumulated lamp time
reaches 2000 hours.
The message can be cleared by pressing the [EXIT] button. However, the
same message will re-appear every hour.
Once the projector is turned off, it cannot be turned on again if the accumu­lated lamp time has exceeded 2000 hours.
When the accumulated lamp time reaches 2010 hours, the projector shuts
down and cannot be turned on again.
[ Replace the light-source lamp and reset the lamp time.

(☞ page 47, 48, 49)

Note

• The message display language corresponds to the menu language
setting. This is set to [English] when the projector is bought. The dis­play language can be selected from among 8 languages. (☞ page 39)
However, the input mode ([PC1], [PC2], [PC3], [Y/C], [VIDEO]) and
button indications ([FREEZE], [D.ZOOM], [EXIT]) are only displayed in
English irrespective of the display language setting.

54

Warning Indication

 About warning indicators

If something abnormal has occurred in the projector, the warning mode will be set in and the type of abnormality will be indicated
by a combination of indicators displayed on the control panel as shown in the following table.
The projector will then automatically stops projection and run the cooling fan for about 90 seconds.

No.

[LAMP]

1

Blink

2

Blink

3

Blink

4

Blink

5

6

7

Blink

• For details on individually blinking indicators, please see page 47.

[TEMP] [OPERATE][STAND BY]

Indicator

Blink

Blink simultaneously

Blink

Blink alternately

Blink

Blink

Blink

Blink

Blink

Blink

Blink

Blink

Warning

The light-source lamp does not light up and projection cannot be done.

Lamp turned off during projection.

Circuits operation is abnormal.

Lamp cover is not installed.

The internal temperature is abnormally high.

The temperature at the air inlets has risen abnormally high.

The cooling fan has stopped (Fan Locked)

 Action to be taken upon warning indications

Please follow the procedures below.

For No.1-3

No.1 : Unplug from the main power outlet and restart according to the basic operation procedures.
No.2 : After checking if a shock (such as from knocking) has not occurred during operation, unplug from the main power outlet

and restart according to the basic operation procedures.

No.3 : Unplug from the main power outlet and restart according to the basic operation procedures.

For No.4-7

Pull out the power cord when [STAND BY] indicator lights up. After that, check No.4 - No.7.
No.4 : Ensure that the lamp is correctly set in place. Restart according to the basic operation procedures.
No.5 : Check that nothing is blocking the air inlets, and wait until the inside cools down. Restart according to the basic operation

procedures.

No.6 : Check the ambient temperature. If it is normal, leave the projector until it cools down. Restart according to the basic

operation procedures.

No.7 : Leave the projector until it cools down. Restart according to the basic operation procedures.

If the warning indication is observed again, wait for the cooling fan to stop. Plug out the power cord with [STAND BY] indicator lights
up and call your dealer for repair.

55

Specifications

 Model name/ Article name DLA-HX2U/ DLA-HX2E D-ILA projector

 Emission method D-ILA®*1 (Reflective Active Matrix Principle)

 Display panel/ size D-ILA*2 / 0.64 (1400 pixels x 788 pixels) x 3 (Total number of pixels: Approx. 3,309,600)

 Projecting lens x 1.3 zoom lens (2:1 - 2.6:1) (Manual zooming and focusing)

 Light-source lamp 250 W Ultra High Pressure Mercury lamp

[Part No.: BHL5006-S/ Rating: 250 W]

 Screen size Approx. type 37 - type 275 (with aspect ratio: 16:9)

 Projection distance Approx. 1.6 m - 12 m

 Color system NTSC, NTSC4.43, PAL, SECAM (Automatic switching/manual switching)

 Resolution 1400 dots x 788 dots (during RGB input)

1000 TV lines (Horizontal resolution, aspect ratio 4:3, during video input)

 Scanning frequency Horizontal frequency : 15 kHz - 120 kHz

Vertical frequency : 24 Hz, 25 Hz, 30 Hz, 50 Hz - 120 Hz

Please be sure to refer to the frequency correspondence table on page 20.

 Audio Power output : 1 W (monaural), 4 cm round type micro-speaker x 1

 Input terminals VIDEO IN Y/C 1-line, mini DIN 4 pin x 1

Y: 1.0 Vp-p, 75 ohm C: 0.286 Vp-p, 75 ohm (NTSC), 0.3 Vp-p, 75 ohm (PAL)

VIDEO 1-line, RCA pin x 1 1.0 V (p-p), 75 ohm, synchronised

PC1 1-line, D-sub 3-rows 15 pin x 1

PC2 1-line, BNC x 5

Y, C

B, CR : Component (Y, B-Y, R-Y) signal (Color Difference signal)

B, PR : DTV-format (Y, PB, PR) signal

Y, P

R, G, B : Analog RGB signal

H/Cs, V : Horizontal (H) sync/ composite (Cs) sync, Vertical (V) sync signal

PC3 1-line, DVI-D (single-24pin) terminal, HDCP compatible*

AUDIO 1-line, RCApin X 1 (Y/C, VIDEO, PC1, PC2, PC3) 0.5 V (rms), high impedance

CONTROL RS-232C : 2-lines, D-sub 9pin x1 (External controller) ❈ (IN: 1 system OUT: 1 system)

REMOTE : 1-line, stereo mini-jack x1 (remote control)

 Output terminals SCREEN TRIGGER terminal : DC Power Jack (Tip = DC +12 V / max. 100 mA, Sleeve = Gnd)

 Power requirements AC 100 V - 240 VAC, 50 Hz/ 60 Hz

 Power consumption 3.4 A (100 V AC) - 1.42 A (240 V AC)

 Operation environment Temperature : 41 °F - 95 °F (+5 °C - +35 °C)

Humidity : 20 % - 80 % (no condensation)

Preservation temperature 14 °F - 140 °F (–10 °C - +60 °C)



Dimensions (Width x Height x Length)

 Mass Approx. 13.2 lbs (Approx. 6.0 Kg)

 Accessories (☞ page 6)

Approx. 117/10"x approx. 53/10"x approx. 141/5" (Approx. 298 mm x 134 mm x 360 mm)

(Excluding handle, lens and protrusion portion)

3

*1D-ILA® is the abbreviation for Direct drive Image Light Amplifier.

2

D-ILA® devices are manufactured using extremely high-precision technology. Pixel effectiveness is 99.99 %. Only 0.01 % or less

*

of the pixels would either not lit up or remain permanently lit up.

3

The image of [DVI-D] input terminal might not be displayed due to HDCP specification change.

*

• Design and Specifications are subject to change without notice.

• Please note that some pictures and illustrations may have been be abridged, enlarged or contextualized in order to aid compre­hension. Images may differ from the actual product.

• All brand names and products (IBM, Macintosh) herein are the trademarks or registered trademarks of their respective compa­nies.

• This product conforms to the ‘Household electric appliances and general-purpose articles harmonics control measure guideline’.

56

Dimensions (unit: mm)

Specifications

360

8.2

 Front

92.5

89

 Bottom Top

181 20

300

29838.2

M6 (Depth 10 mm)

298 27

Attachment screw should be more than 6 mm

67.5

Center of lens

but less than 10 mm in length.

 Side

115.9

65.4

267

15

109

25 - 56

29236.2

57

Specifications

Pin arrangement

 Y/C terminal

4

2

3

1

 RS-232C IN/OUT terminal

9

8 7 6

54321

 PC 1 terminal

11 12 13

1514

6712 1094538

Pin number

1

2

3

4

Pin number

1

2

3

4

5

Pin number

1

2

3

4

5

6

7

8

Signal name

GND (Y)

GND (C)

Y

C

Signal name

N/C

RD

TD

N/C

GND

Signal name

Red

Green

Blue

N/C

N/C

GND (Red)

GND (Green)

GND (Blue)

Pin number

6

7

8

9

Pin number

9

10

11

12

13

14

15

Signal name

N/C

N/C

N/C

N/C

N/C

Signal name

N/C

GND (SYNC)

GND

N/C

H.SYNC

V. SYNC

N/C

 PC 3 terminal

8

7

6

3

2

5

4

16

15

14

11

10

13

12

24

23

22

19

18

21

20

58

1

9

17

Pin number

1

2

3

4

5

6

7

8

9

10

11

12

TMDS = Transition Minimized Differential Signaling
DDC = Display Data Channel

Signal name

TMDS data 2 -

TMDS data 2 +

TMDS data 2/4 shield

N/C

N/C

DDC clock

DDC data

N/C

TMDS data 1 -

TMDS data 1 +

TMDS data 1/3 shield

N/C

Pin number

13

14

15

16

17

18

19

20

21

22

23

24

Signal name

N/C

TMDS +5 V power supply

Earth (+5 V)

Hot plug detection

TMDS data 0 -

TMDS data 0 +

TMDS data 0/5 shield

N/C

N/C

TMDS clock shield

TMDS clock +

TMDS clock -

Specifications

 RS-232C external control

By connecting a computer to the projector with a RS-232C cross cable (D-sub 9 pins), you can control the projector with the
computer. The commands to control the projector and the response data format against the received commands are explained
here.
For details, please consult the authorized dealer where you purchased your projector.

1. Communication Specifications

The communication specifications are as follows.

Baud rate

Data length

Parity

Stop bit

Flow control

9600 bps/19200 bps

8 bits

None

1 bit

None

2. Command Format

2-1 Command data format

When sending a control command to the projector, use the following data format.

Header SPID Parameter CRSPCommand

Header : Designates the head of data and the data type.

: ! (21h): Assigns command to the projector.

: ? (3Fh): Query to the projector. (Asking command)
ID : 1: The identification number of the projector. (Manufacturer set value 1)
SP : Designates the delimiter for ID, Command, and Parameter. (20h)
CR : Designates the terminal of the data. (0Dh)

*[ ] is not necessary for Asking command.

2-2 Response data format

Upon executing a control command it has received, the projector sends back the following response data to the computer:

[

[

Header SPID Parameter CRSPNormal Termination Status

Header : Designates the head of data.

:@ (40h): Fetches data from the projector.
ID : 1: The identification number of the projector. (Manufacturer set value 1)
SP : Designates the delimiter for ID, Command, and Parameter. (20h)
Normal Termination Status : 0 (30h)
CR : Designates the terminal of the data. (0Dh)

2-3 Parameters used for the data format

The following three kinds of parameters are used for control commands and response data.

1) Numeric value

2) ON/OFF

3) Special parameters

Each parameter is as follows:

1) Numeric value
A 2-byte hexadecimal value (sign included) is represented by a set of 4 digit (4 bytes) characters.
Designated range: 8000 to 7FFF.

2) ON/OFF
Shows the status (ON/OFF) of the projector, such as POWER and HIDE.

Character

0

1

Hex.

30

31

Meaning

OFF

ON

[

[

59

Specifications

3) Special parameters
Input switching parameters

Character

0

1

3

4

5

Operation mode parameters

Character

0000

0001

0002

0004

Hex.

30

31

33

34

35

30h 30h 30h 30h

30h 30h 30h 31h

30h 30h 30h 32h

30h 30h 30h 34h

3. External control command table

Function Command Asking

OPERATE

HIDE

Right Left reversal

Top Bottom inversion

Input switch

Operation mode

Hex.

Meaning

Y/C

VIDEO

PC1

PC2

PC3

U0F

U00

U17

U18

U1A

Z03

Meaning

Stand-by mode

Power-on mode

Cool-down mode

Emergency mode

Data type

Power on ELSE Numeric Value ON/OFF Special Data

X











X

X

X

X

X



X

X

X

X

X

X









X

X

X

X

X

X

Y/C ...

Stand-by…

Operation mode: Only Asking command is possible.

60

Memo

61

DLA-HX2U/DLA-HX2E

®

PROJECTOR

© 2004 Victor Company of Japan, Limited

®

Printed in Japan
1004-SW-VP
