To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
CAUTION
The F button in any position does not disconnect the mains line.
Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off).
The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall
remain readily operable.
• When the system is on standby, the STANDBY lamp lights red.
• When the system is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able
to get out.)
• Do not place any naked flame sources, such as lighted candles, on the apparatus.
• When discarding batteries, environmental problems must be considered and local rules or laws
governing the disposal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
CAUTION
• Excessive sound pressure from earphones or headphones can cause hearing loss.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover or cabinet. There are no user serviceable parts inside the unit;
leave all servicing to qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.
G-1
CAUTION — Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage, locate the apparatus as follows:
Top/Front/Back/Sides: No obstructions should be placed in the areas shown by the dimensions below.
Bottom:Place on the level surface. Maintain adequate air path for ventilation by placing on
In addition, maintain the best possible air circulation.
Front view of the main unit and speakers (CA-NXF30 and SP-NXF30F)
Side view of the main unit (CA-NXF30)
a stand with a height of 10 cm or more.
SP-NXF30FSP-NXF30FCA-NXF30
CA-NXF30
CAUTION
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
[European Union only]
G-2
Table of contents
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain
the best possible performance from the unit.
• This manual explains the operations
assuming that you will use the remote
control. Some buttons on the main unit are
the same as those on the remote control.
You can use either button in this case.
• Some diagrams in this manual are simplified
or exaggerated for the purpose of
explanation.
• You can operate some functions differently
from the explanation given in this manual.
• Depending on the disc/file, you may not
obtain the explained result even after
following the operation in this manual.
• The following marks refer to the usable
discs/files for the explained function.
2
Part description
The numbers refer to the pages in which the parts are explained.
Front view
Refer to “Display
Introduction
STANDBY
lamp
Remote control sensor
window” below.
26, 27
19, 20
12, 13, 42
16, 21, 22,
26–28, 49
10, 12, 4115, 19, 20
Touch sensor panels
*
Rear view
6
9
The voltage selector is located on the rear of the main unit sold in countries/areas other than
Insert the batteries into the remote control by
matching the polarity (+ and –) correctly.
R03 (UM-4)/AAA
(24F) type dry-cell
batteries (supplied)
• If the range or effectiveness of the remote
control decreases, replace both batteries.
Operating the system from
the remote control
Point the remote control directly at the
front of the main unit.
• Do not block the remote control sensor on the
main unit.
Remote control sensor
4
Preparation
Do not connect the power cable until all other connections have been made.
Connecting the FM antenna
Preparation
When radio reception with the supplied FM antenna is poor, or when using a communal antenna
Main unit (rear view)
Main unit (rear view)
Antenna cable
(not supplied)
or
Converter (not
supplied:
compatible with
300 C/75 C)
Depending on the radio reception conditions, an
FM feeder antenna (not supplied: compatible with
300 C) can be used. In this case, a converter (not
supplied) is required.
Communal
antenna terminal
Coaxial cable
(not supplied)
FM antenna (supplied)
Stretch out the FM antenna to
the best position for radio
reception.
Outdoor FM
antenna
(not supplied)
• When using an antenna other than those supplied for this system, refer to the operation manuals for the
antenna and converter for details of connection.
• When positioning the antennas, find the best position for reception while listening to an actual radio
program (refer to “Listening to FM radio” on page 16).
• You cannot receive an FM radio broadcast without the antenna connection.
5
Connecting the speakers and subwoofer
Connect the speakers to the main unit by connecting the colored connectors to the same color terminals on
the rear of the main unit.
Red
Main unit (rear view)
White
Speaker cableSpeaker cable
Preparation
Gray
Right speaker
(rear view)
Subwoofer
(rear view)
■ IMPORTANT
• Improper speaker cable connection reduces the
stereo effect and sound quality.
• The supplied left/right speakers are magnetically
shielded, but color irregularity may occur on the
TV. To prevent color irregularity, set up the
speakers following the instructions below.
(The subwoofer is not magnetically shielded.)
1. Turn off the main power of the TV before
setting up the speakers.
2. Place the speakers enough distance from the
TV so that they do not cause color irregularity
on the TV.
3. Wait for approximately 30 minutes before
turning on the main power of the TV again.
Speaker cable
Blue
Purple
CAUTION
• The supplied speakers are manufactured
exclusively for use with the NX-F30 system. Do
not connect the supplied speakers to devices
other than the supplied main unit. Doing so may
damage the speakers.
• Do not connect external speakers together with
the supplied speakers. The change in
impedance may damage the main unit and the
speakers.
Left speaker
(rear view)
CAUTION
• The left and right speakers can be installed on a wall.
• When installing the speakers on a wall, be sure to have the speakers installed by qualified personnel.
• DO NOT install the speakers on the wall by yourself to avoid unexpected damage from them falling off the
wall due to incorrect installation or weakness in wall structure.
• Care must be taken in selecting a location for speaker installation on a wall. Injury to personnel or damage
to devices may result if the installed speakers interfere with daily activities.
6
Preparation (continued)Do not connect the power cable until all other connections have been made.
Speaker layout
Main unit
Subwoofer
Preparation
Left speaker
This system is designed to provide virtual surround
sound by positioning the 3 speakers in front. (The
set of the left and right speakers and the
subwoofer refers to 2.1 channel.) The front
surround function processes input signals to
create a realistic sound field.
Right speaker
Connecting a TV
After connecting a TV, follow the instructions on
page 10.
Connecting a TV with the [VIDEO]
terminal
TV
Main unit
(rear view)
To a video input terminal
Composite video cable (supplied)
Connecting a TV with the
[COMPONENT] terminals
TV
Main unit
(rear view)
To component
input terminals
Component video cable (not supplied)
7
■ IMPORTANT
• Connect the main unit directly to a TV (or a
monitor) without routing through a video
cassette recorder (VCR) or an HDD/DVD
recorder. Otherwise picture distortion may occur
during playback. (Routing the connection
through a VCR or an HDD/DVD recorder,
however, does not affect the audio quality.)
VCR
or HDD/DVD
Main unit
• Connecting the main unit to a VCR-built-in-TV
may also cause picture distortion during
playback.
recorder
Direct connection
TV (or monitor)
Connecting external digital
audio devices
OutputMD player or
satellite receiver
To an optical digital
output terminal
Optical digital cable
(not supplied)
Preparation
Connecting a TV with the [HDMI
MONITOR OUT] terminal
This system can output uncompressed digital
video signals to a TV compatible with HDMI (High
Definition Multimedia Interface).
TV
To an HDMI input terminal
HDMI cable (not supplied)
NOTE
• The HDMI video signal type can be checked with
the “HDMI” indicator in the display window.
(Refer to “Selecting the video signal type” on
page 10.)
• If the picture is distorted while an HDMI TV is
connected, turn off the main unit and turn it on
again.
• A TV compatible with HDCP (High-Bandwidth
Digital Content Protection) can also be
connected to the [HDMI MONITOR OUT]
terminal, so that the uncompressed HD video
signal type can be output as well.
• This system is compatible with some basic
functions of HDMI CEC. (Refer to page 57.)
Main unit
(rear view)
Main unit
(rear view)
InputOutput
Optical digital cable
(not supplied)
To an optical digital
input terminal
Input
NOTE
• You can output the audio signal from the
[DIGITAL OUT] terminal when “DVD”, “USB” or
“DGTL IN” is selected as the source in the
display window.
• When “DGTL IN” is selected as the source in the
display window, digital audio from the
[DIGITAL OUT] terminal is decoded to a linear
PCM signal.
AV amplifier with
a built-in decoder
8
Preparation (continued)Do not connect the power cable until all other connections have been made.
Connecting external analog
audio devices
Preparation
Output
Audio cable
(not supplied)
Input
Main unit
(rear view)
Analog audio
device
Selecting the voltage for
your area (Only for countries/
areas other than Thailand)
Before connecting the power cable to an AC outlet,
you must set the correct voltage for your area.
Slide the voltage selector on the main
unit to the correct voltage for your
area.
• Confirm that the position of the voltage selector
corresponds to the voltage in your area.
Main unit (rear view)
HDMI
CAUTION
• Do not connect the power cable to an AC outlet
before setting the voltage selector on the main
unit and completing all connections.
Connecting the power cable
Main unit
(rear view)
AC outlet
• Connect the power cable after you complete the
other connections.
• The [STANDBY] lamp on the main unit lights up.
9
Remote control
mode selector
2/3
(cursor)/
ENTER
Selecting the video signal
type
To view an image on the TV screen, select the
video signal type correctly according to the TV
after connecting the main unit to the TV.
1Turn on the main unit.
• Refer to “Turning on/off the main unit” on
page 12.
2Press [DVD 3] or [USB 3].
• When a disc is loaded or a USB device is
connected, press
7
to stop playback.
3Press [SCAN MODE].
• The current video signal type appears.
Example: When “PAL.576I (Interlace)” is
selected as the video signal
4Press 2 or 3 (cursor) to select the
video signal type suitable for the
TV.
• When the TV is connected to the [VIDEO]
terminal or the [COMPONENT] terminals,
the video signal type can be selected as
instructed below.
- Select “PAL. 576I” for a TV only compatible
with a PAL interlaced video signal.
- Select “PAL. 576P” for a TV equipped with
component terminals and compatible with
a PAL progressive video signal.
- Select “NT. 480I” for a TV only compatible
with an NTSC interlaced video signal.
- Select “NT. 480P” for a TV equipped with
component terminals and compatible with
an NTSC progressive video signal.
Preparation
■ IMPORTANT
• Slide the remote control mode
selector to [SHIFT].
(Continued on the next page)
10
Preparation (continued)
• When the TV is connected to the [HDMI
MONITOR OUT] terminal, the video signal
type can be selected as instructed below.
- Select “AUTO” for normal usage. (the
Preparation
NOTE
• “480”, “576”, “720” and “1080” refer to the
• “I” refers to the interlaced scanning. “P” refers to
• When an HDMI video signal is output, the
• When an HD video signal is output, the “HD”
• When “PAL. 576P”, “PAL. 720P”, “PAL.1080P”,
initial setting)
- Select “PAL. 576P”, “PAL. 720P”,
“PAL.1080I”, “PAL.1080P”, “NT. 480P”,
“NT. 720P”, “NT.1080I” or “NT.1080P” as
needed. (The selectable settings differ
according to the resolution of the
connected TV.)
• You can also select the video signal type by
repeatedly pressing [SCAN MODE].
number of the scanning lines. Generally, the
larger the number, the better picture that can be
obtained.
the progressive scanning. A better picture can
be obtained in the progressive scanning than in
the interlaced scanning.
“HDMI” indicator lights up in the display window.
indicator lights up in the display window.
“NT. 480P”, “NT. 720P” or “NT.1080P” is
selected, the “PROGRESSIVE” indicator lights
up in the display window.
For the locations of the remote
control buttons, refer to page 10.
5Press [ENTER].
NOTE
• It is recommended that you slide the remote
control mode selector to [AUDIO] after selecting
the video signal type. Most of the other functions
can be used when the remote control mode
selector is at [AUDIO].
• To check the compatibility of your TV, contact
your local JVC customer service center.
• Even if the main unit is turned off, the video
signal type setting is stored.
11
Basic operations
Turning on/off the main unit
Number
buttons
Remote control
mode selector
3
(playback)
Press [AUDIO
F] (or [STANDBY F]
on the main unit).
• The power of the main unit turns on and the
[STANDBY] lamp (button) on the main unit turns
off.
• Press [AUDIO
main unit) again to turn off the power of the main
unit. (The main unit enters the standby mode.)
• With the power off, pressing any of the following
buttons also turns on the main unit.
- [DVD
[DIGITAL IN],
remote control
The function assigned to the pressed button
starts working at the same time. (When
(playback) is pressed, “DVD” is selected as the
source in the display window.)
• An internal cooling fan turns on when the main
unit turns on. This is to prevent overheating of
the main unit. The cooling fan produces noise
during operation. This is not a malfunction.
F] (or [STANDBY F] on the
3
], [USB 3], [TUNER], [AUDIO IN] and
3
(playback) or 0 on the
3
Selecting the source
Basic operations
■ IMPORTANT
• Slide the remote control mode
selector to [AUDIO].
Using the number buttons
Examples:
5: [5]
15: [ 10] →
150: [ 10] → [ 10] → [1] → [5] → [0]
[1] → [5]
Press [DVD3], [USB3], [TUNER],
[AUDIO IN] or [DIGITAL IN] on the
remote control.
• You can also select the source by turning
[SOURCE] on the main unit.
DVD
USBFM
AUDIO INDGTL IN
Adjusting the volume
Press [VOL +] or [VOL –] repeatedly.
• You can also adjust the volume by turning the
[VOLUME] control on the main unit.
12
Basic operations (continued)
Turning off the sound
temporarily
Press [MUTING].
• Press [MUTING] again or [VOL +] or [VOL –], or
Basic operations
turn the [VOLUME] control on the main unit to
restore the sound. The sound is also restored
when the main unit is turned off once and turned
on.
Adjusting the treble/bass
1Press [TREBLE/BASS] repeatedly
to select “TRE” or “BASS” in the
display window.
2Press [LEVEL +] or [LEVEL –]
repeatedly to adjust the sound
quality.
• Adjustable sound quality is from –10 to +10.
Adjusting the volume level
for surround/subwoofer
sound
You can adjust the volume level for the left and
right surround sound and the subwoofer sound
respectively.
1Press [SPK LEVEL] repeatedly to
select “SURR” or “SUBWFR” in
the display window.
• “SURR” refers to the left and right surround
sound.
• “SUBWFR” refers to the subwoofer sound.
2Press [LEVEL +] or [LEVEL –]
repeatedly to adjust the volume
level.
• The adjustable volume range is from –6 to
+6.
Selecting the surround mode
Press [SURROUND].
• Each time you press [SURROUND], the display
changes in the display window as follows.
- “AUTO SUR”
When a multi-channel signal is input, surround
sound is automatically produced.
- “MOVIE”
Surround sound suitable for a movie or multichannel signal is produced.
- “WIDE/2CH”
When a 2ch signal is input, surround sound is
produced. The sound is broader than the one
with “MOVIE”.
- “SUPER W”
Surround sound broader than the one with the
“WIDE/2CH” is produced.
13
NOTE
• Depending on the signal type, surround sound
may not be produced as the surround mode
setting.
• During playback, when you change the surround
mode setting, sound from the [DIGITAL OUT]
terminal may be intermittent. Before recording
sound to an external device, select the desired
surround mode setting.
• This function does not work for a JPEG/ASF/
DivX/MPEG1/MPEG2 file.
For the locations of the remote
control buttons, refer to page 12.
Selecting the headphone
surround mode
You can listen to surround sound via headphones
connected to the [PHONES] terminal.
■ When headphones are connected to the
[PHONES] terminal
Press [SURROUND].
• Each time you press [SURROUND], the setting
toggles between “H.P. SURR” and “H.PHONE”
in the display window.
NOTE
• The [PHONES] terminal is for connecting a pair
of headphones equipped with a stereo mini plug
(not supplied). When headphones are
connected, no sound is output from the
speakers.
• This function does not work for a JPEG/ASF/
DivX/MPEG1/MPEG2 file.
Sharpening the voice sound
This function allows you to easily understand
dialog recorded on the disc/file even with the
volume down low. This function is useful when you
are watching a movie.
Selecting the surround
volume level
You can increase the surround volume level.
This function is effective for the following
conditions:
(1) When the surround mode is set to an item
other than “AUTO SUR”. (Refer to page 13.)
(2) When the surround mode is set to “AUTO
SUR” and a DVD VIDEO of multi-channel
signal is played back.
(3) When the surround mode is set to “AUTO
SUR” and the source is set to “DGTL IN”.
1Press [SETTING] repeatedly to
select “SURR VOL” in the display
window.
2Press [LEVEL +] or [LEVEL –]
repeatedly to select the desired
setting in the display window.
• Each time you press [LEVEL +] or [LEVEL –],
the surround volume level display changes to
one of three levels. The surround volume
level increases in the order of “SURR:
NRML”, “SURR: MID” and “SURR: HIGH”.
• Select the surround volume level while
listening to the actual sound to confirm the
difference.
Basic operations
1Press [SETTING] repeatedly to
select “CLR VOIC” in the display
window.
• “CLR VOIC” refers to a clear voice.
2Press [LEVEL +] or [LEVEL –]
repeatedly to select “CLR: ON” in
the display window.
This indicator lights up when the
clear voice function is activated.
• Each time you press [LEVEL +] or [LEVEL –]
the clear voice function turns on and off.
• When you want to deactivate the clear voice
function, select “CLR: OFF”.
NOTE
• This function does not affect the sound with the
headphone surround mode.
14
Basic operations (continued)
For the locations of the remote
control buttons, refer to page 12.
Using the sleep timer
When the time you specify elapses, the main unit
automatically turns off.
Press [SLEEP].
• Each time you press [SLEEP], the time indicated in
Basic operations
the display window changes. You can set the time
to 10, 20, 30, 60, 90, 120, 150 or 180 minutes.
Example: Display when the sleep timer is
set to 60 minutes
Changing the remaining time
Press [SLEEP] repeatedly to select the
time again.
Confirming the remaining time
Press [SLEEP] once.
Canceling the sleep timer
Press [SLEEP] repeatedly until
“SLEEP --” appears.
Turning off the main unit also cancels the sleep
timer.
Changing the brightness of
the display window
■ When the main unit is turned on
Press [DIMMER] repeatedly.
• Each time you press [DIMMER], the brightness
changes in 3 levels.
Locking disc ejection
You can lock the disc tray to prevent the disc from
being ejected.
Setting the disc ejection lock
■ When the main unit is turned off
Touch 0 while holding 7 on the main
unit for more than 2 seconds.
If you attempt to open the disc tray by pressing
while the main unit is turned on, the disc tray does
not open and “LOCKED” appears in the display
window.
0
15
To cancel the lock, do the same operation above
again while the main unit is turned off.
“UNLOCKED” is displayed in the display window.
Listening to FM radio
Number
buttons
*
Remote control
mode selector
For the number button usage, refer to “Using the
*
number buttons” on page 12.
■ IMPORTANT
• Slide the remote control mode
selector to [AUDIO].
2Press [TUNING] or [TUNING]
repeatedly to select a radio station
(frequency).
• When the main unit has received an FM
radio, the “ST” (stereo) indicator lights up in
the display window.
■ Automatic tuning:
You can also select a radio station using
automatic tuning.
Hold down [TUNING] or [TUNING] until
the frequency starts changing, and then
release the button.
• When the main unit has received a
broadcast, the frequency automatically
stops changing.
• You can select a specific radio station while
searching for a broadcast. Press
[TUNING] or [TUNING] to stop
automatic tuning when the desired
frequency appears in the display window.
NOTE
• You can use 4 and x on the main unit
instead of [TUNING] and [TUNING].
• If an FM radio is difficult to hear because of
noise, you may be able to hear the broadcast
more easily by pressing [FM MODE] to switch
the sound to monaural reception. In this case,
the “MONO” (monaural) indicator lights up in the
display window. To return the sound to stereo
reception, press [FM MODE] again. “AUTO” is
displayed and the “ST” (stereo) indicator lights
up in the display window.
Listening to FM radio
Selecting an FM radio station
1Press [TUNER].
• Turning [SOURCE] on the main unit can
also select an FM radio as the source.
(Refer to page 12.)
Example: When an FM radio is received
Stereo indicator
Preset number
(Refer to page 17.)
Frequency
16
Listening to FM radio (continued)
For the locations of the remote
control buttons, refer to page 16.
Tuning in to a preset FM
radio station
Presetting radio stations in the main unit allows
you to easily tune in to a radio station.
Presetting FM stations
You can store up to 30 FM radio stations.
Listening to FM radio
1Select a radio station you want to
store.
• Refer to “Selecting an FM radio station” on
page 16.
2Press [ENTER].
•“--” flashes in the display window for
approximately 5 seconds.
3While “
--
” is flashing, press the
number buttons to select the
preset number you want to assign.
• You can also select the preset number by
pressing [PRESET] or [PRESET].
4Press [ENTER] while the selected
number is flashing.
• “STORED” appears and the selected radio
station is stored.
Tuning in to a preset radio station
■ When an FM radio is selected as the source
Press the number buttons to select
the preset number of the radio station
to which you want to tune in.
• You can also select the preset number by
pressing [PRESET] or [PRESET].
NOTE
• When you store a radio station to a preset
number to which another radio station has
previously been stored, the newly set radio
station replaces the previously stored radio
station.
17
Playing back sources from external devices
Playing back sources from
external devices
1Press [AUDIO IN] or [DIGITAL IN].
• [AUDIO IN] is for selecting the device
connected to the [AUDIO IN] terminals.
• [DIGITAL IN] is for selecting the device
Remote control
mode selector
connected to the [DIGITAL IN] terminal.
• You can also select the connected device as
the source by turning [SOURCE] on the
main unit.
2Start playback on the connected
device.
3Adjust the volume or the sound
quality for your preference.
• Refer to pages 12 to 14.
NOTE
• Refer also to the operation manual for the
connected device.
• You can also operate your digital broadcast
satellite and video cassette recorder using the
remote control of this system. Refer to pages 54
to 56.
Playing back sources from external devices
■ IMPORTANT
• Slide the remote control mode
selector to [AUDIO].
Selecting the signal gain
You can select the gain of the signal from the
[AUDIO IN] terminals. Use the initial settings for
normal operation. If the sound is too small or too
loud, change the settings.
1Press [AUDIO IN].
2Hold down [ENTER].
• “LEVEL 1” or “LEVEL 2” appears in the
display window.
3Press [ENTER] repeatedly to
select “LEVEL 1” or “LEVEL 2”.
• Each time you press [ENTER], the display
toggles between “LEVEL 1” and “LEVEL 2”.
• The signal gain in “LEVEL 1” is lower than
that in “LEVEL 2”.
• The display returns to “AUDIO IN” in
approximately 5 seconds.
18
Basic operations of disc/file playback
Playing back a disc
This part explains how to play back the types of
Number
buttons
*
Remote control
mode selector
discs shown above.
1Press
0
on the remote control or
on the main unit.
• The disc tray ejects.
2Place a disc on the disc tray.
Basic operations of disc/file playback
For the number button usage, refer to “Using the
*
number buttons” on page 12.
■ IMPORTANT
• Slide the remote control mode
selector to [AUDIO].
5/K/2/3
(cursor)/
ENTER
3
(playback)
Printed surface
Disc tray
• To play back an 8-cm disc, place it on the
inner hollow of the disc tray.
3Press [DVD
• If “DVD” is selected as the source, pressing
3
(playback) can start playback.
NOTE
• When using the main unit, turn [SOURCE] to
select “DVD” as the source, then touch
(playback) to start playback.
• A menu screen may appear on the TV screen
after DVD playback starts. In such a case,
operate the menu screen, using 5, K, 2, 3
(cursor), the number buttons and [ENTER].
(Refer to “Selecting a chapter/track from the
menu screen” on page 28.)
3
].
3
19
Loading...
+ 50 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
