Knowing your TV’s features

Main features

PIP (Picture in Picture) You can view two different sources (e.g. TV programme and VCR sources) at the same

TELETEXT You can view teletext programmes which are broadcasted by some TV channels. Teletext

A2/NICAM You can listen to the stereo sound or bilingual sound from TV programme broadcasting by A2 (STEREO / I■II) or NICAM Sound-multiplex system.

FAVORITE CH (Channel) You can register up to four favorite channels for quick recall with one press.

AI ECO TV detects the brightness of your room and automatically adjust the picture brightness to a

AI VOLUME TV adjusts the volume automatically to the same level for all TV channels to avoid sudden

Confirm your TV’s functions

Some functions written in this instruction manual may not be available for your TV.

2 3

Please see the chart below and check the functions that are equipped for your TV’s model number. The model number is indicated at the rear of your TV. When you press a button concerned to a function that is not available for your TV, it does not work and the logo “Ø” appears on the screen. For a function that is not available for your TV, it is not displayed in the menu.

Model No.

No.

Function

1 (STEREO/I■II) –– – – – – –__ _ _ _ – – ––– 2 *PICTURE BOOSTER –– – – – – ––––– – – – ––_ 3 *ECO – _ – ____– _ –– ___–––

PIP control buttons

4,6

(Green label)

TELETEXT control

5,6

buttons (Black label)

– PICTURE TILT __ ––_ – ___–– – _ – –––

– COMPRESS (16:9) __ _ _ _ _ ____– ___– _ –

time.

programme is an information in text form.

suitable level for a better eye care.

change of the volume when selecting different TV channel.

AV-29LX14

AV-29WX14

AV-25LX14

AV-21LX14

AV-21VX14

AV-21WX14

AV-29VX54

AV-25VX54

AV-21VX54

AV-29WX24

AV-29LS24

AV-29VS24

AV-25LS24

AV-21CS24

AV-25VS24

AV-21WS24

AV-21VS24

AV-29VX74

AV-25VX74

AV-21VX74

AV-21CX14

AV-21DX14

AV-21YX14

–– – – __ ––––– – __ –––

–– – – – – _____ _ _ _ –––

Remote control buttons and basic functions

No. Press To

1 POWER Turn on or off the TV from standby mode. 2 MENU/OK Display menu and confirm selected function. 3 5 / ∞ / 2 / 3 Select and adjust menu function. 4 CHANNEL -/+ Select the desired channel number. 5 VOLUME -/+ Adjust the volume level. 6 TV/VIDEO Select TV or video terminal input. 7 MUTING Turn off the volume.

8 DISPLAY Display the programme number or video terminal number, stereo/bilingual broadcast system

9 0~9, -/-- Select the programme number. For two digits programme number, press -/--, then press the

! RETURN

Press this button again to resume the volume.

and PR list (channel list) on the screen. You can select the channel using the PR list.

1 Press the DISPLAY button once to display the PR list. 2 Press 5 / ∞ / 2 / 3 buttons to choose a channel, then press the MENU/OK button.

You can confirm the favorite channels in the PR list. The channels set to favorite channels are indicated with coloured mark.

number button.

a) Return to the frequently view channel with one touch.

1 Choose the channel you want to register. 2 Press and hold RETURN+ button until “RETURN PLUS PROGRAMMED!” appears.

To cancel, press and hold RETURN+ button until “RETURN PLUS CANCELED!” appears.

b) Return to the previously viewed channel, if you have not set or have cancelled the Return

channel as above.

! 4

Remote control buttons and basic functions (continued)

How to operate menus and menus locations

Display the MENU

Display the top menu

Display the 2nd menu

Display the 3rd menu

Return to the previous menu

Choose the setting of a function

Adjust the effect level of a function

Display the sub menu of a function.

Press the MENU/OK button 2.

Press 5/∞ buttons 3 to choose a menu title. Then press MENU/OK button 2.

Press the DISPLAY button 8.

Press 5/∞ buttons 3 to choose a function. Then press the 2/3 buttons 3 to change the setting.

Press 5/∞ buttons 3 to choose a function. Then press the 2/3 buttons 3 to adjust the effect level.

Press the 5/∞ buttons 3 to choose a function. Then press MENU/OK button 2 to display the sub menu.

The following chart shows locations of functions in menus. In this manual, location of a function is described as follows:

MENU Top menu

MENU 2nd menu

Top menu

Note: Some functions have the 4th menus as the sub-menus.

Operation

2nd menu

Note

To exit the MENU, press the DISPLAY button 8 or choose EXIT menu.

Press ∞ button 3 to display the next page for more functions.

–

Press the MENU/OK button 2 to exit from the menu.

–

3rd menu

Top menu 2nd menu Location 3rd menu Location

MENU INPUT EXT. INPUT P.18 – –

PICTURE PICTURE MODE P.9 – – *If you want to

adjust PICTURE SETTING menu, you must set PICTURE MODE menu to USER.

SOUND STEREO/ *If you want to

adjust EQUALIZER menu, you must set SOUND MODE menu to USER.

FEATURES OFF TIMER P.17 – –

INSTALL AUTO PROGRAM P.19 – –

EXIT – – – –

DISPLAY P.18 – –

PICTURE SETTING P.10 – – WHITE BALANCE P.10 – – PICTURE – VNR P.17

FEATURES

I■II

AI VOLUME P.15 – – SOUND MODE P.14 – – EQUALIZER P.15 – – BALANCE P.14 – – SOUND TURBO P.14 – – CINEMA SURROUND

CHILD LOCK P.17 – – AI ECO SENSOR P.11 – – PIP – PIP,SUB INPUT,SWAP P.12

EDIT/MANUAL P.19 DELETE, MOVE, P.19-

LANGUAGE P.17 LANGUAGE P.17 BLUE BACK P.11 – – AUTO SHUTOFF P.18 – – VIDEO-2 SETTING P.18 – – AI ECO DISPLAY P.11 – – TEXT LANGUAGE P.13 TEXT LANGUAGE P.13

FAVORITE CH SETTING VIDEO SETTING P.16 COLOUR SYSTEM P.9 PICTURE BOOSTER P.10 COMPRESS (16:9) P.11 PICTURE TILT P.11

P.15 – –

MANUAL, INSERT P.20

P.16

TV buttons and functions

The illustrations shown below is for AV-29VS24 and AV-21CS24 only, which are used for explanation purpose. Your TV may not look exactly the same as illustrated.

Front of the TV

AV-29VS24

!9 8765 234 1

L/MONO

IN (VIDEO-3)

CHANNEL

VOLUME

TV/VIDEO

EXIT

POWER

AV-21CS24

!9 876 4

VOLUME

L / MO

IN (VIDEO-2)

POWER

Rear of the TV

AV-29VS24

COMPONENT

VIDEO-1

(VIDEO-2)

INPUT

OVER

/ V

MONO

OUTPUT

LRRL

# "

AV-21CS24

VIDEO-1

INPUT

MONO

OUTPUT

No. Button/terminal Description Page

1 L (main power) Press to turn on or turn off the TV’s main power. – 2 POWER lamp Indicate the TV is being turned on or off. –

No colour : TV’s main power is being turned off. Red : TV’s main power is being turned on. Note: When you turn off the power switch while TV is in standby mode, the light of power lamp will be off in 10 -15 seconds.

3 ECO sensor – 4 Remote control sensor – 5 TV/VIDEO Press to select TV or video mode. – 6 VOLUME -/+ Press to adjust the volume level. – 7 CHANNEL -/+ Press to select the desired channel. – 8 MENU Press to display the menu. – 9 IN (VIDEO-3) Video and audio input jacks for VIDEO-3 mode. 22

IN (VIDEO-2) Video and audio input jacks for VIDEO-2 mode. 22

! Headphone jack. 22 " Aerial socket. 7 # OUTPUT Video and audio output jacks. (The component video 22

signal cannot be output.)

$ COMPONENT Video or component video, and audio input jacks for 22

(VIDEO-2) INPUT VIDEO-2 mode. You can select the input signal by setting

the “VIDEO-2 SETTING” function (see page 18).

% VIDEO-1 INPUT Video or S-VIDEO, and audio input jacks for VIDEO-1 7

mode

How to operate the menus with the TV button

TV button

Work as same as the button on the remote control unit

MENU MENU/OK button To display main menu and exit

CHANNEL -/+ ∞/5 button To select menu function. VOLUME -/+ 2/3 button To adjust the desired function.

Note

menu after finish setting.

Setting up your TV

CAUTION

• Turn off the equipment including the TV before connecting.

1 Connecting the aerial cable.

VHF/UHF outdoor aerial

75-ohm coaxial cable (not supplied)

If you connect a VCR, connect the aerial output jack of your VCR and the aerial jack on the TV with aerial cable. Then connect the output jacks of your VCR and the VIDEO-1 input jacks of the TV with the video cable (or S-VIDEO cable if available) and audio cables. For details, see the manual of your VCR.

Rear of TV

AV-29VS24

To video output

To S-video output

VCR

To audio output

To aerial input

To RF output

The illustration shown is just a sample. It may not be same as your TV.

VHF/UHF outdoor aerial

COMPONENT

VIDEO-1

(VIDEO-2)

OUTPUT

INPUT

OVER

LRRL

MONO

2 Connecting the compatible main plug to the AC outlet.

3 Inserting batteries into the remote control.

Insert two batteries by following the + and polarities and inserting the - end first.

CAUTION:

Follow the cautions printed on the batteries. Notes:

• Use AA/R6/UM-3 dry cell batteries.

• If the remote control does not work properly, fit

new batteries. The supplied batteries are for testing, not regular use.

4 Turn on the TV by pressing the main power button.

JVC logo appears on the screen.

Setting up your TV (continued)

5 Making the initial settings

Set up your TV by pressing any button except POWER button, then operate the TV menu by following the steps as below:

LANGUAGE

ENGLISH

кмллдав

FRANÇAIS

BACK ■

• Press 5/∞ button to select your desired language*, then press MENU/OK button.

TEXT LANGUAGE

GROUP–1

GROUP–2

GROUP–3

GROUP–4

BACK ■

• Press 5/∞ button to select your desired Teletext language group*. For details, see page 13. (For CS24/LS24/ VS24/VX74/WS24/ WX24 series only)

22%

CH 12

• TV will start searching for the channels.

To stop AUTO PROGRAM, press MENU/OK button.

AUTO PROGRAMAUTO PROGRAM

SETUP TOUR RESTART?

RESTART

■

• Press the red button to cancel the SETUP TOUR RESTART function. If you want to make initial settings again when the next time you turn on the TV, press the MENU/OK button to activate the SETUP TOUR RESTART function.

If the JVC logo does not appear, use LANGUAGE, TEXT LANGUAGE, and AUTO PROGRAM functions to make the initial settings. Those functions are located in the INSTALL menu.

If the JVC logo appears, although you had made the initial settings, press the TV/VIDEO button to exit from initial settings. * If the TEXT function is available for your TV and the LANGUAGE shown follow as ENGLISH/РУССКИЙ/

you can select the TEXT LANGUAGE group from GROUP-1 to GROUP-4. If the TEXT function is available for your TV and the LANGUAGE shown follow as ENGLISH/РУССКИЙ/

you can select the TEXT LANGUAGE group from GROUP-1 to GROUP-3.

EDIT

PR CH/CC 7 CH 09 8 CH 11 9 ■ CH 13 10 11 12 13

BACK ■

■

MOVE ■DELETE

INSERT

MANUAL

• To complete the initial setting, press the MENU/OK button. To edit the channel list, see page 19.

/ /FRANÇAIS,

/MELAYU/INDONESIA,

Basic setting for picture

COLOUR SYSTEM

You can select the appropriate colour system when the picture is not clear or no colour appears. Press the COLOUR SYSTEM button to select a setting.

AUTO PAL SECAM NTSC3.58

NTSC4.43

To operate this function with a menu:

❇

COLOUR SYSTEM

For the colour system in each country or region, see the table below:

Area Country or Region System

Asia, Middle China, Vietnam, etc. PAL

East Hong Kong, etc. PAL

Europe

Oceania Australia, New Zealand, etc. PAL

Africa Nigeria, etc. PAL

PICTURE menu

Bahrain, Kuwait, Oman, Qatar, United Arab Emirates, Yemen, etc. PAL Indonesia, Malaysia, Singapore, Thailand, India, etc.

Islamic Republic of Iran, Lebanon, Saudi Arabia, etc. SECAM Philippines, Taiwan, Myanmar, etc. NTSC Russia, etc. SECAM Czech Republic, Poland, etc. PAL Germany, Holland, Belgium, etc. PAL UK, etc. PAL

Republic of South Africa, etc. PAL

Egypt, Morocco, etc. SECAM

PICTURE FEATURES menu

PICTURE MODE

You can choose the desired picture setting with one-touch. Press the PICTURE MODE button to select a setting.

SOFT Softens contrast and sharpness. BRIGHT Heightens contrast and sharpness. STANDARD Standard picture setting. USER You can change this picture setting as you like.

*TINT can only be adjusted in NTSC system.

To operate this function with a menu:

❇

To return the USER setting to the default, press the blue button when the PICTURE SETTING menu appears.

❇ About the basic operations of the menu, please see the “How

to operate menus and menus locations” on page 5.

Select USER and adjust following items in the PICTURE SETTING menu. (CONTRAST, BRIGHT, SHARP, COLOUR, TINT*)

PICTURE menu

PICTURE MODE

Basic setting for picture (continued)

Adjusting the picture – USER

You can adjust the desired picture setting when selecting USER in PICTURE MODE.

1 Select the USER in PICTURE MODE under PICTURE menu.

❇

USER

PICTURE menu

PICTURE MODE

2 Select the PICTURE SETTING in PICTURE menu, then adjust

the setting.

❇

CONTRAST 2 : Lower contrast 3 : Higher contrast BRIGHT 2 : Darker 3 : Brighter SHARP 2 : Softer 3 : Higher COLOUR 2 : Lighter 3 : Deeper TINT* 2 : Reddish 3 : Greenish

*TINT can only be adjusted in NTSC system.

PICTURE BOOSTER

You can improve picture clarity when the picture is unclear due to the low signal reception. Press the PICTURE BOOSTER button to select the desired mode.

HIGH Perform at maximum level. LOW Perform at minimum level. OFF Cancel the function

To operate this function with a menu:

❇

PICTURE BOOSTER

PICTURE menu

PICTURE SETTING

PICTURE FEATURES menu

WHITE BALANCE

You can change the white balance of the picture to better match the type of video being viewed. Select the WHITE BALANCE in the PICTURE menu, then choose the desired setting.

❇

NORMAL Normal white balance. COOL Bluish white. WARM Reddish white.

❇ About the basic operations of the menu, please see the “How

to operate menus and menus locations” on page 5.

PICTURE menu

WHITE BALANCE

Advanced setting for picture

AI ECO SENSOR (ECO)

You can adjust TV screen contrast according to the brightness of your room. Press the ECO button to select the desired mode.

1 Mild contrast (recommended). 2 Even contrast. OFF Cancel the function.

To operate this function with a menu:

❇

FEATURES menu

AI ECO SENSOR

You can display the graphic of AI ECO SENSOR on the screen. Select the AI ECO DISPLAY in the INSTALL menu, then choose ON or OFF.

❇

INSTALL menu

AI ECO DISPLAY

Correcting the Slanting Picture (PICTURE TILT)

You can correct the picture tilt caused by the earth’s magnetic force.

1 Select the PICTURE TILT in the PICTURE FEATURES menu

under PICTURE menu, then press MENU/OK button.

❇

PICTURE TILT

The following display appears.

PICTURE menu

PICTURE TILT

PICTURE FEATURES menu

2 Press the 5/∞ buttons until the picture become level. Then

press the MENU/OK button.

COMPRESS (16:9)

You can convert a normal picture (4:3 aspect ratio) into a wide picture (16:9 aspect ratio). Select the COMPRESS (16:9) in the PICTURE FEATURES menu under PICTURE menu, then choose ON or OFF.

❇

COMPRESS (16:9)

BLUE BACK

You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or absent, or when there is no input from an antenna.

Select the BLUE BACK in the INSTALL menu, then choose ON or OFF.

❇

If you wish to continue viewing the poor picture, cancel the BLUE BACK function.

❇ About the basic operations of the menu, please see the “How

to operate menus and menus locations” on page 5.

PICTURE menu

INSTALL menu

PICTURE FEATURES menu

BLUE BACK

BACK ■

Original features for picture

PIP

You can display a sub picture on the screen. Press the PIP operation buttons to display and change the sub picture setting.

PIP Display the sub picture.

SUB-P -/+ Select the desired channel for sub picture.

(Input) Select the input source for the sub picture. (Swap) Swap between the main picture and sub picture.

(Position) Change the sub picture position.

(Freeze) Freeze the sub picture to be still.

To cancel, press the PIP button again.

Notes:

• You can hear the sound from the main picture only.

• Main picture and sub picture will use different input

sources, which are TV and VIDEO mode. When the same input source are selected, the sub picture input source will change as follows: Main picture Sub picture TV VIDEO-1 = VIDEO-2 = VIDEO-3 VIDEO-1 TV = VIDEO-2 = VIDEO-3 VIDEO-2 TV = VIDEO-1 = VIDEO-3 VIDEO-3 TV = VIDEO-1 = VIDEO-2

Each time you press on (Position) button, the sub picture position will change as follows:

lower right lower left upper left

upper right

To operate this function with a menu:

❇

FEATURES menu

PIP

When VIDEO-2 is set to component, you can’t select VIDEO-2 for sub picture.

When VIDEO-2 is set to component, if the input source of main picture is set to VIDEO-2 with component, PIP button is disabled and sub picture can’t be displayed.

TELETEXT

You can watch the Teletext broadcast channel with TEXT function.

1 Press the TEXT button to select the desired mode as follows:

TV mode TEXT mode MIX mode

2 Press the CHANNEL -/+ buttons, number buttons or colour

buttons to select other Teletext pages.

3 Press TEXT or TV/VIDEO button to return to TV mode.

You can also operate the teletext using the following buttons:

(Hold) Hold a teletext page.

The (Hold) are displayed at the top left of the screen. To cancel, press (Hold) button again.

(Reveal) Display the hidden text (e.g. answers to a quiz).

To cancel, press (Reveal) button again. (Size) Enlarge the teletext display. (Index) Return to the index page instantly. (Cancel) Watch TV programme while waiting for a teletext page.

When the teletext page is found, a page number

appears at the upper left of the screen.

Press (Cancel) to view the teletext page. (Sub-page) Operate the (Sub-page) function.

Sub-page numbers are displayed at the left of the

screen.

To cancel sub-page function, press (Sub-page)

button again.

❇ About the basic operations of the menu, please see the “How

to operate menus and menus locations” on page 5.

Original features for picture (continued)

Using the List mode

You can store and recall the favorite teletext pages in memory using the colour buttons.

1 In TEXT mode, press the MODE button to enter the List mode. 2 Press a colour button, then press the number buttons to enter

the page number.

3 Press and hold down the (Store) button.

The page number is blinking white to indicate that they are stored in memory.

4 To store other favorite teletext pages, repeat Step 2 to 3.

To recall the favorite teletext page, press the MODE button, then press the colour button. To exit the List mode, press the MODE button again. When viewing teletext programme, menu operations are not available. If characters on a teletext programme do not appear properly, change the TEXT LANGUAGE setting.

TEXT LANGUAGE

You can set the Teletext language group that corresponds to the programmes. Select TEXT LANGUAGE in the INSTALL menu, then choose the desired language group.

❇

GROUP-1 English, German, Swedish / Finnish / Danish /

GROUP-2 Polish, German, Estonian, Slovenian, Czech /

GROUP-3 Polish, German, Estonian, Lettish, Russian, Ukrainian GROUP-4 English, French, Turkish, Arabic, Iranian

Depending on the broadcast, the language set may not display properly. For details, see in page 8.

❇ About the basic operations of the menu, please see the “How

to operate menus and menus locations” on page 5.

INSTALL menu

Hungarian, Italian, French, Spanish / Portuguese, Turkish

Slovakian, Rumanian

TEXT LANGUAGE

Basic setting for sound

SOUND SYSTEM

You can select an appropriate sound system when abnormal sound occurs even when the picture appears normally. Press the SOUND SYSTEM button to select a setting.

B/G I D/K M

This function is not available in video mode. For the sound system in each country or region, see the table below:

Area Country or Region System

Asia, Middle China, Vietnam, etc. D/K East Hong Kong, etc. I

Europe

Oceania Australia, New Zealand, etc. B/G

Africa Nigeria, etc. B/G

Bahrain, Kuwait, Oman, Qatar, United Arab Emirates, Yemen, etc. B/G Indonesia, Malaysia, Singapore, Thailand, India, etc.

Islamic Republic of Iran, Lebanon, Saudi Arabia, etc. B/G Philippines, Taiwan, Myanmar, etc. M Russia, etc. D/K Czech Republic, Poland, etc. D/K Germany, Holland, Belgium, etc. B/G UK, etc. I

Republic of South Africa, etc. I

Egypt, Morocco, etc. B/G

SOUND MODE

You can choose the desired sound setting. Select the SOUND MODE in SOUND menu, then choose the setting.

❇

MENU SOUND menu

USER You can change this sound setting as you like.

Select USER and adjust the frequencies in EQUALIZER (100, 300, 1K, 3K, 8K Hz).

For details, see “EQUALIZER” on page 15. DYNAMIC Emphasize on both vocal sound and music. MUSIC Emphasize on music effect. NEWS Emphasize on vocal sound.

SOUND MODE

BALANCE

You can adjust the volume balance between the left and right speakers. Select the BALANCE in SOUND menu, then adjust the setting.

❇

MENU SOUND menu

BALANCE

SOUND TURBO

You can set the sound frequency to emphasize the low and high frequency levels.

Press the SOUND TURBO to select ON or OFF. To operate this function with a menu:

❇

MENU SOUND menu

SOUND TURBO

❇ About the basic operations of the menu, please see the “How

to operate menus and menus locations” on page 5.

Advanced setting for sound

CINEMA SURROUND

You can enjoy an enhanced sound for wider audience. Press the CINEMA SURROUND button to select a setting.

OFF Cancel the function. LOW Listen to sound with less wider audience effect. HIGH Listen to sound with more wider audience effect. MONO Listen to mono sound with stereo effect.

To operate this function with a menu:

❇

SOUND menu

CINEMA SURROUND

If slight volume distortion occurs when you select HIGH mode, change the setting to LOW mode. The CINEMA SURROUND effect will be less noticeable. If you use CINEMA SURROUND and SOUND TURBO together, volume distortion might occurs.

STEREO / I■II ( )

You can enjoy the stereo and bilingual broadcasted programmes. Press the button to select the desired mode.

Select stereo sound. Select monaural sound.

I Select bilingual I (sub I). II Select bilingual II (sub II).

MONO Cancels the Multi Sound function, and the sound

This function is not available in video mode. To operate this function with a menu:

❇

becomes monaural.

SOUND menu

STEREO / I■II

EQUALIZER

You can adjust the sound frequencies when selecting USER mode in SOUND MODE.

1 Select the USER in SOUND MODE under SOUND menu.

❇

SOUND menu

SOUND MODE USER

2 Select the EQUALIZER in SOUND menu.

❇

The following display appears.

SOUND menu

EQUALIZER

IIIIIIIIIIII

100 300 1K 3K 8K Hz

BACK ■

IIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIIIIIII

IIIIIIIIIIIIIIIIIIIIIII

EQUALIZER

IIIIIIIIIIII

3 Select and adjust the desired frequencies. 4 Press the MENU/OK button to exit the menu.

Adjust high frequency will affect higher pitch sound and vice versa.

AI VOLUME

You can adjust the volume of all the channels and video inputs to the same level automatically. Select the AI VOLUME in SOUND menu, then choose ON or OFF.

❇

❇ About the basic operations of the menu, please see the “How

to operate menus and menus locations” on page 5.

SOUND menu

AI VOLUME

+ 33 hidden pages
