AV-29L31
PARTS LIST
CAUTION
q The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the
safety .
q The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied .
q P. W. Board Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied .
ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES
RESISTORS CAPACITORS
C R Carbon Resistor
F R Fusible Resistor
P R Plate Resistor
V R Variable Resistor
HV R High Voltage Resistor
MF R Metal Film Resistor
MG R Metal Glazed Resistor
MP R Metal Plate Resistor
OM R Metal Oxide Film Resistor
CMF R Coating Metal Film Resistor
UNF R Non-Flammable Resistor
CH V R Chip Variable Resistor
CH MG R Chip Metal Glazed Resistor
COMP. R Composition Resistor
LPTC R Linear Positive Temperature Coefficient Resistor
C CAP. Ceramic Capacitor
E CAP. Electrolytic Capacitor
M CAP. Mylar Capacitor
HV CAP. High Voltage Capacitor
MF CAP. Metalized Film Capacitor
MM CAP. Metalized Mylar Capacitor
MP CAP. Metalized Polystyrol Capacitor
PP CAP. Polypropylene Capacitor
PS CAP. Polystyrol Capacitor
TF CAP. Thin Film Capacitor
MPP CAP. Metalized Polypropylene Capacitor
TAN. CAP. Tantalum Capacitor
CH C CAP. Chip Ceramic Capacitor
BP E CAP. Bi-Polar Electrolytic Capacitor
CH AL E CAP. Chip Aluminum Electrolytic Capacitor
CH AL BP CAP. Chip Aluminum Bi-Polar Capacitor
CH TAN. E CAP. Chip Tantalum Electrolytic Capacitor
CH AL BP E CAP. Chip Tantalum Bi-Polar Electrolytic Capacitor
RESISTORS
FGJ KMNRHZP
±1% ±2% ±5% ±10% ±20% ±30%
No. 51970 33
+30% +50% +80% +100%
-10% -10% -20% 0%
AV-29L31
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT .......................................................................................... 35
EXPLODED VIEW PARTS LIST-1 ......................................................................................................................... 35
EXPLODED VIEW-1 ................................................................................................................................................35
EXPLODED VIEW PARTS LIST-2 ........................................................................................................................ 36
EXPLODED VIEW-2 ...............................................................................................................................................37
PRINTED WIRING BOARD PARTS LIST
MAIN PW BOARD ASS'Y .....................................................................................................................................38
CRT SOCKET PW BOARD ASS’Y .......................................................................................................................42
FRONT CONTROL PW BOARD ASS’Y ............................................................................................................... 43
REMOTE CONTROL UNIT PARTS LIST (RM-C248-2C) ......................................................................... 44
PACKING/PACKING PARTS LIST .......................................................................................................................45
34 No. 51970
USING P.W. BOARD & REMOTE CONTROL UNIT
ASS’Y No.P.W.B ASS’Y
MAIN PWB SCH-1039A-H2
CRT SOCKET PWB SCH-3001A-H2
FRONT CONTROL PWB SCH-8001A-H2
REMOTE CONTROL UNIT RM-C248-2C
EXPLODED VIEW PARTS LIST-1
!
Ref.No. Part No. Part Name Description Local
22 LC20778-001A-H OPERATION SHEET
23 LC31474-001A-H CONTROL WINDOW
24 LC31476-001B-H LED LENS
25 LC41037-001A JVC MARK
100 LC11193-007A-H FRONT CABINET ASS’Y Inc. No. 101-105
101 LC20776-007A-H DOOR
102 CM48229-00A-C DOOR LATCH
103 LC20777-001D-H CENTRE PLATE
AV-29L31
104 LC31475-001B-H POWER KNOB
105 CM35235-003-H SPRING
EXPLODED VIEW-1
100
22
102
101
25
24
103
23
104
No. 51970 35
105
AV-29L31
EXPLODED VIEW PARTS LIST-
!
Ref.No. Part No. Part Name Description Local
! V01 A68QCU259X PICTURE TUBE
! L01 QQW0113-001 DEG COIL
DY01 QQD0057-001 DEF YOKE
! T1551 QQH0096-001 FBT
1 LC11061-001A-H CHASSIS BASE
2 LC11062-001D-H CONTROL BASE
3 LC11064-002A-H AV TERMINAL BOARD
4 QYSBSF3012M TAPPING SCREW (X4)
5 CHFD125-18BD FFC WIRE
! 6 QMP40D0-200J5 POWER CORD
! 7 CM23167-A01-H POWER CORD CLAMP
8 LC30103-001B-H CHASSIS ADAPTER (X2)
9 LC11063-001C-H SP HOLDER (X2)
10 LC40226-003A-H SPACER (X4)
11 LC40317-002A-H TAPPING SCREW (X4)
12 QAS0083-001 SPEAKER (X2)
13 QYSBSBG4016Z TAPPING SCREW (X8)
14 WJY0018-001A BRAIDED ASS’Y
15 CHGB0017-0C BRAIDED ASS’Y (SUB) (X2)
16 A48457-3-H SPRING
17 CE42568-00A PC MAGNET
18 CE40764-00A WEDGE ASS’Y (X4)
! 19 LC10763-008A-H REAR COVER
20 QYSBSFG4016Z TAPPING SCREW (X16)
! 21 LC20377-001B-H RATING LABEL
2
36 No. 51970
EXPLODED VIEW-2
FRONT CABINET
V01
L01
10
11
9
12
13
DY01
8
18
17
14
15
FRONT CONTROL
PWB (1/2)
AV-29L31
16
10
11
9
15
10
CRT
SOCKET PWB
8
5
12
13
11
FRONT CONTROL PWB (2/2)
MAIN PWB
T1551
10
11
19
2
1
7
20
21
6
3
4
No. 51970 37
AV-29L31
PRINTED WIRING BOARD PARTS LIST
MAIN PW BOARD ASS’Y(SCH-1039A-H2)
! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
RESISTOR
R1001-02 NRSA63J-221X MG R 220Ø 1/16W J
R1003 NRSA63J-392X MG R 3.9kØ 1/16W J
R1004 NRSA63J-221X MG R 220Ø 1/16W J
R1006 NRSA63J-273X MG R 27kØ 1/16W J
R1101 NRSA63J-100X MG R 10Ø 1/16W J
R1102 NRSA63J-682X MG R 6.8kØ 1/16W J
R1103 NRSA63J-272X MG R 2.7kØ 1/16W J
R1104 NRSA63J-181X MG R 180Ø 1/16W J
R1105 NRSA63J-220X MG R 22Ø 1/16W J
R1106 NRSA63J-101X MG R 100Ø 1/16W J
R1107 NRSA63J-472X MG R 4.7kØ 1/16W J
R1108-10 NRSA63J-222X MG R 2.2kØ 1/16W J
R1117 NRSA63J-102X MG R 1kØ 1/16W J
R1119 NRSA63J-102X MG R 1kØ 1/16W J
R1120 NRSA63J-471X MG R 470Ø 1/16W J
R1150 NRSA63J-331X MG R 330Ø 1/16W J
R1151 NRSA63J-222X MG R 2.2kØ 1/16W J
R1152 NRSA63J-121X MG R 120Ø 1/16W J
R1153 NRSA63J-122X MG R 1.2kØ 1/16W J
R1154 NRSA63J-181X MG R 180Ø 1/16W J
R1301-02 NRSA63J-222X MG R 2.2kØ 1/16W J
R1303 NRSA63J-562X MG R 5.6kØ 1/16W J
R1304-05 NRSA63J-222X MG R 2.2kØ 1/16W J
R1306 NRSA63J-562X MG R 5.6kØ 1/16W J
R1308 NRSA63J-101X MG R 100Ø 1/16W J
R1309 NRSA63J-104X MG R 100kØ 1/16W J
R1310 NRSA63J-473X MG R 47kØ 1/16W J
R1311 NRSA63J-123X MG R 12kØ 1/16W J
R1401 NRSA63J-224X MG R 220kØ 1/16W J
R1403 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R1405 NRSA63J-682X MG R 6.8kØ 1/16W J
R1406 NRSA63J-472X MG R 4.7kØ 1/16W J
R1408 NRSA63J-682X MG R 6.8kØ 1/16W J
R1410 NRSA63J-472X MG R 4.7kØ 1/16W J
R1411 QRG01GJ-221 OM R 220Ø 1W J
R1412 QRE121J-1R0Y C R 1.0Ø 1/2W J
R1413 QRX01GJ-1R2 MF R 1.2Ø 1W J
R1414 QRE121J-2R7Y C R 2.7Ø 1/2W J
R1425 NRSA63J-683X MG R 68kØ 1/16W J
R1478-79 NRSA63J-101X MG R 100Ø 1/16W J
R1480 QRE121J-681Y C R 680Ø 1/2W J
R1481 NRSA63J-223X MG R 22kØ 1/16W J
R1482 NRSA63J-562X MG R 5.6kØ 1/16W J
R1483 NRSA63J-823X MG R 82kØ 1/16W J
R1484 NRSA63J-562X MG R 5.6kØ 1/16W J
R1485 NRSA63J-123X MG R 12kØ 1/16W J
R1486 NRSA63J-272X MG R 2.7kØ 1/16W J
R1487 NRSA63J-333X MG R 33kØ 1/16W J
R1489 NRSA63J-122X MG R 1.2kØ 1/16W J
R1490 NRSA63J-102X MG R 1kØ 1/16W J
R1491 NRSA63J-562X MG R 5.6kØ 1/16W J
R1492 NRSA63J-822X MG R 8.2kØ 1/16W J
R1493 QRE121J-223Y C R 22kØ 1/2W J
R1494 QRL039J-330 OM R 33Ø 3W J
R1521 NRSA63J-101X MG R 100Ø 1/16W J
R1522 NRSA63J-102X MG R 1kØ 1/16W J
R1523-24 QRL039J-151 OM R 150Ø 3W J
R1526 QRL029J-271 OM R 270Ø 2W J
R1527 QRL039J-103 OM R 10kØ 3W J
R1528-29 QRX029J-3R3 MF R 3.3Ø 2W J
R1531 NRSA63J-182X MG R 1.8kØ 1/16W J
!
R1532 QRZ9017-4R7 F R 4.7Ø 1/4W J
R1541-42 QRE121J-124Y C R 120kØ 1/2W J
R1543 QRE121J-471Y C R 470Ø 1/2W J
R1545 QRE121J-220Y C R 22Ø 1/2W J
R1546 QRE121J-822Y C R 8.2kØ 1/2W J
R1547 QRG01GJ-121 OM R 120Ø 1W J
R1561 QRL029J-220 OM R 22Ø 2W J
R1562 QRE121J-123Y C R 12kØ 1/2W J
R1563 QRZ0056-103Z COMP.R 10kØ 1/2W J
R1591 QRA14CF-1202Y MF R 12kØ 1/4W F
R1592 QRZ0221-2R2 UNF R 2.2Ø
RESISTOR
R1593 NRSA02F-332X MG R 3.3kØ 1/10W F
R1594 QRE121J-183Y C R 18kØ 1/2W J
R1595 NRSA63J-222X MG R 2.2kØ 1/16W J
R1602 NRSA63J-271X MG R 270Ø 1/16W J
R1603-04 NRSA63J-101X MG R 100Ø 1/16W J
R1634-35 NRSA63J-222X MG R 2.2kØ 1/16W J
R1640 NRSA63J-102X MG R 1kØ 1/16W J
R1650 NRSA63J-223X MG R 22kØ 1/16W J
R1651-52 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R1653 NRSA63J-104X MG R 100kØ 1/16W J
R1654 NRSA63J-223X MG R 22kØ 1/16W J
R1655-56 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R1657 NRSA63J-104X MG R 100kØ 1/16W J
R1658-59 QRE121J-2R2Y C R 2.2Ø 1/2W J
R1660 NRSA63J-103X MG R 10kØ 1/16W J
R1661 NRSA63J-683X MG R 68kØ 1/16W J
R1662 NRSA63J-333X MG R 33kØ 1/16W J
R1663 NRSA63J-103X MG R 10kØ 1/16W J
R1664 NRSA63J-222X MG R 2.2kØ 1/16W J
R1665-66 NRSA63J-392X MG R 3.9kØ 1/16W J
R1667 NRSA63J-103X MG R 10kØ 1/16W J
R1668 NRSA63J-683X MG R 68kØ 1/16W J
R1669 NRSA63J-563X MG R 56kØ 1/16W J
R1670 NRSA63J-153X MG R 15kØ 1/16W J
R1671 NRSA63J-272X MG R 2.7kØ 1/16W J
R1672 NRSA63J-563X MG R 56kØ 1/16W J
R1673-74 NRSA63J-683X MG R 68kØ 1/16W J
R1675 NRSA63J-103X MG R 10kØ 1/16W J
R1676-77 NRSA63J-472X MG R 4.7kØ 1/16W J
R1678 NRSA63J-153X MG R 15kØ 1/16W J
R1679 NRSA63J-272X MG R 2.7kØ 1/16W J
R1680 NRSA63J-683X MG R 68kØ 1/16W J
R1688 NRSA63J-273X MG R 27kØ 1/16W J
R1690 NRSA63J-104X MG R 100kØ 1/16W J
R1691 NRSA63J-682X MG R 6.8kØ 1/16W J
R1692 NRSA63J-104X MG R 100kØ 1/16W J
R1693 NRSA63J-103X MG R 10kØ 1/16W J
R1696 NRSA63J-222X MG R 2.2kØ 1/16W J
R1701 NRSA63J-103X MG R 10kØ 1/16W J
R1702-03 NRSA63J-101X MG R 100Ø 1/16W J
R1705-06 NRSA63J-102X MG R 1kØ 1/16W J
R1707-10 NRSA63J-472X MG R 4.7kØ 1/16W J
R1711-14 NRSA63J-101X MG R 100Ø 1/16W J
R1715-17 NRSA63J-103X MG R 10kØ 1/16W J
R1718-19 NRSA63J-221X MG R 220Ø 1/16W J
R1720 NRSA63J-102X MG R 1kØ 1/16W J
R1721-24 NRSA63J-221X MG R 220Ø 1/16W J
R1725 NRSA63J-103X MG R 10kØ 1/16W J
R1726 NRSA63J-472X MG R 4.7kØ 1/16W J
R1727 NRSA63J-104X MG R 100kØ 1/16W J
R1728 NRSA63J-103X MG R 10kØ 1/16W J
R1730 NRSA63J-223X MG R 22kØ 1/16W J
R1731 NRSA63J-101X MG R 100Ø 1/16W J
R1732 NRSA02F-393X MF R 39kØ 2W F
R1733 NRSA63J-273X MG R 27kØ 1/16W J
R1734 NRSA63J-391X MG R 390Ø 1/16W J
R1735 NRSA63J-104X MG R 100kØ 1/16W J
R1736 NRSA63J-333X MG R 33kØ 1/16W J
R1737 NRSA63J-272X MG R 2.7kØ 1/16W J
R1738 NRSA63J-103X MG R 10kØ 1/16W J
R1739-41 NRSA63J-101X MG R 100Ø 1/16W J
R1742 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R1744 NRSA63J-561X MG R 560Ø 1/16W J
R1745 NRSA63J-105X MG R 1MØ 1/16W J
R1746 NRSA63J-333X MG R 33kØ 1/16W J
R1747 NRSA63J-103X MG R 10kØ 1/16W J
R1748 NRSA02J-225X MG R 2.2MØ 1/10W J
R1749 NRSA02J-185X MG R 1.8MØ 1/10W J
R1750 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R1755-56 NRSA63J-101X MG R 100Ø 1/16W J
R1757-58 NRSA63J-222X MG R 2.2kØ 1/16W J
R1790 NRSA63J-0R0X MG R 0.0Ø 1/16W J
38 No. 51970
AV-29L31
! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
RESISTOR
R1803 NRSA63J-333X MG R 33kØ 1/16W J
R1804-07 NRSA63J-750X MG R 75Ø 1/16W J
R1808 NRSA63J-823X MG R 82kØ 1/16W J
R1809 NRSA63J-391X MG R 390Ø 1/16W J
R1810 NRSA63J-823X MG R 82kØ 1/16W J
R1811 NRSA63J-391X MG R 390Ø 1/16W J
R1812 NRSA63J-104X MG R 100kØ 1/16W J
R1813 NRSA63J-222X MG R 2.2kØ 1/16W J
R1815 NRSA63J-101X MG R 100Ø 1/16W J
R1818 NRSA63J-222X MG R 2.2kØ 1/16W J
R1820 NRSA63J-101X MG R 100Ø 1/16W J
R1821 NRSA63J-222X MG R 2.2kØ 1/16W J
R1823 NRSA63J-101X MG R 100Ø 1/16W J
R1824 NRSA63J-222X MG R 2.2kØ 1/16W J
R1826 NRSA63J-101X MG R 100Ø 1/16W J
R1829 NRSA63J-750X MG R 75Ø 1/16W J
R1830-31 NRSA63J-222X MG R 2.2kØ 1/16W J
R1832 NRSA63J-391X MG R 390Ø 1/16W J
R1833 NRSA63J-331X MG R 330Ø 1/16W J
R1834-35 NRSA63J-562X MG R 5.6kØ 1/16W J
R1836 NRSA63J-750X MG R 75Ø 1/16W J
R1837 NRSA63J-101X MG R 100Ø 1/16W J
R1838 QRK126J-121X C R 120Ø 1/2W J
R1839-40 QRE121J-221Y C R 220Ø 1/2W J
R1841-42 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R1843 NRSA63J-821X MG R 820Ø 1/16W J
R1844 NRSA63J-222X MG R 2.2kØ 1/16W J
R1845 NRSA63J-102X MG R 1kØ 1/16W J
R1846 NRSA63J-222X MG R 2.2kØ 1/16W J
R1847 NRSA63J-103X MG R 10kØ 1/16W J
R1848 NRSA63J-221X MG R 220Ø 1/16W J
R1849 NRSA63J-471X MG R 470Ø 1/16W J
R1880 NRSA63J-202X MG R 2kØ 1/16W J
R1881 NRSA63J-103X MG R 10kØ 1/16W J
R1882 NRSA63J-181X MG R 180Ø 1/16W J
R1883 NRSA63J-471X MG R 470Ø 1/16W J
R1902 QRF154K-2R2 UNF R 2.2Ø 15W K
R1903 QRL039J-473 OM R 47kØ 3W J
R1904 QRE121J-681Y C R 680Ø 1/2W J
R1905 QRM034J-R10 MP R 0.1Ø 3W J
R1908 NRSA63J-103X MG R 10kØ 1/16W J
R1909 QRE121J-274Y C R 270kØ 1/2W J
R1911 QRE121J-472Y C R 4.7kØ 1/2W J
R1912 QRE121J-222Y C R 2.2kØ 1/2W J
!
R1913 QRZ9017-4R7 F R 4.7Ø 1/4W
R1914 QRL039J-473 OM R 47kØ 3W J
R1915 QRE121J-394Y C R 390kØ 1/2W J
R1916 QRE121J-332Y C R 3.3kØ 1/2W J
R1917 NRSA63J-101X MG R 100Ø 1/16W J
R1918 NRSA63J-224X MG R 220kØ 1/16W J
R1919 NRSA63J-104X MG R 100kØ 1/16W J
R1920 NRSA63J-473X MG R 47kØ 1/16W J
R1921 QRE121J-563Y C R 56kØ 1/2W J
R1950 QRE141J-0R0Y C R 0.0Ø 1/4W J
R1951 QRE121J-223Y C R 22kØ 1/2W J
R1952 NRSA63J-222X MG R 2.2kØ 1/16W J
R1953 QRE121J-152Y C R 1.5kØ 1/2W J
R1955 QRG01GJ-470 OM R 47Ø 1W J
R1957 QRE121J-5R6Y C R 5.6Ø 1/2W J
R1958 QRL039J-820 OM R 82Ø 3W J
R1959 QRE121J-820Y C R 82Ø 1/2W J
R1960 NRSA63J-391X MG R 390Ø 1/16W J
R1961 QRL029J-223 OM R 22kØ 2W J
R1962 NRSA63J-681X MG R 680Ø 1/16W J
R1963 QRE121J-332Y C R 3.3kØ 1/2W J
R1964 NRSA63J-103X MG R 10kØ 1/16W J
R1965 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R1966 NRSA63J-682X MG R 6.8kØ 1/16W J
R1967 NRSA63J-473X MG R 47kØ 1/16W J
R1968 NRSA63J-331X MG R 330Ø 1/16W J
R1969 QRT029J-2R7 MF R 2.7Ø 2W J
R1970 NRSA63J-153X MG R 15kØ 1/16W J
RESISTOR
R1971 NRSA63J-183X MG R 18kØ 1/16W J
!
R1991 QRZ0057-825 C R 8.2MØ 1W J
CAPACITOR
C1001 NCB31HK-103X C CAP. 0.01µF 50V K
C1002 QETN1HM-106Z E CAP. 10µF 50V M
C1003 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1004 QETN1CM-477Z E CAP. 470µF 16V M
C1005 NCB31HK-222X C CAP. 2200pF 50V K
C1006 QETN1CM-336Z E CAP. 33µF 16V M
C1007 NCB31HK-103X C CAP. 0.01µF 50V K
C1101-04 NCB31HK-472X C CAP. 4700pF 50V K
C1106-07 NCB31HK-103X C CAP. 0.01µF 50V K
C1109 QETN1HM-106Z E CAP. 10µF 50V M
C1150-51 NCB31HK-472X C CAP. 4700pF 50V K
C1301-02 NCB31CK-104X C CAP. 0.1µF 16V K
C1304-05 NCB31HK-103X C CAP. 0.01µF 50V K
C1306 NCB31CK-104X C CAP. 0.1µF 16V K
C1307 NDC31HJ-330X C CAP. 33pF 50V J
C1308 NCB31HK-103X C CAP. 0.01µF 50V K
C1401 QETN1HM-105Z E CAP. 1µF 50V M
C1402 QCB31HK-682Z C CAP. 6800pF 50V K
C1403 QEHR1VM-107Z E CAP. 100µF 35V M
C1406 QCS32HJ-560Z CH C CAP. 56pF 500V J
C1407 QCS32HJ-180Z CH C CAP. 18pF 500V J
C1411-12 NCF21HZ-334X C CAP. 0.33µF 50V Z
C1413 QFLC2AJ-563Z M CAP. 0.056µF 100V J
C1422 QEHR1VM-108Z E CAP. 1000µF 35V M
C1471 QETN1HM-106Z E CAP. 10µF 50V M
C1480 QETN1HM-106Z E CAP. 10µF 50V M
C1483 QEZ0195-475Z E CAP. 4.7µF 50V M
C1485 QETN1HM-226Z E CAP. 22µF 50V M
C1521 QETN1VM-476Z E CAP. 47µF 35V M
C1522 QFLC1HJ-332Z M CAP. 3300pF 50V J
C1523 QFLC1HJ-223Z M CAP. 0.022µF 50V J
C1524 QFZ0196-382 MPP CAP. 3800pF 1.5kVH ±3%
C1525 QFZ0200-143 MPP CAP. 0.014µF 1.5kVH ±3%
C1526 QFP32JJ-223 PP CAP. 0.022µF 630V J
C1527-28 QFZ0199-224 MPP CAP. 0.22µF 250V J
C1529 QENC2AM-225Z E CAP. 2.2µF 100V M
C1530 QCB32HK-561Z C CAP. 560pF 500V K
C1531 QEHR1EM-108Z E CAP. 1000µF 25V M
C1532 QCB32HK-561Z C CAP. 560pF 500V K
C1533 QEHR1EM-108Z E CAP. 1000µF 25V M
C1534 QCB32HK-561Z C CAP. 560pF 500V K
C1536 QFLC1HJ-103Z M CAP. 0.01µF 50V J
C1540 QFV71HJ-104Z MF CAP. 0.1µF 50V J
C1541 QETN2EM-106Z E CAP. 10µF 250V M
C1550 NCB31CK-104X C CAP. 0.1µF 16V K
C1561 QFV11HJ-683Z TF CAP. 0.068µF 50V J
C1566 QFZ0200-113 MPP CAP. 0.011µF 1.5kVH ±3%
C1591 QETN1CM-107Z E CAP. 100µF 16V M
C1592 QETM2CM-227 E CAP. 220µF 160V M
C1593 QETN1EM-476Z E CAP. 47µF 25V M
C1602 NCB31HK-103X C CAP. 0.01µF 50V K
C1603 QETN1CM-107Z E CAP. 100µF 16V M
C1604 NCB31CK-104X C CAP. 0.1µF 16V K
C1606-07 NDC31HJ-2R0X C CAP. 2.0pF 50V J
C1608-09 NCB31HK-103X C CAP. 0.01µF 50V K
C1610 QETN1HM-106Z E CAP. 10µF 50V M
C1611 NCB31CK-104X C CAP. 0.1µF 16V K
C1612 QETN1HM-106Z E CAP. 10µF 50V M
C1613 NCB31CK-104X C CAP. 0.1µF 16V K
C1615 QETN1HM-106Z E CAP. 10µF 50V M
C1616 NCB31CK-104X C CAP. 0.1µF 16V K
C1617 QETN1HM-106Z E CAP. 10µF 50V M
C1619 NCB31CK-104X C CAP. 0.1µF 16V K
C1620 QETN1HM-106Z E CAP. 10µF 50V M
C1621-22 NCB31HK-102X C CAP. 1000pF 50V K
C1623-24 NCF31AZ-105X C CAP. 1µF 10V Z
C1650 QEHR1HM-106Z E CAP. 10µF 50V M
No. 51970 39
AV-29L31
! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
CAPACITOR
C1651 QEHQ1HM-107 E CAP. 100µF 50V M
C1652 QETN1HM-106Z E CAP. 10µF 50V M
C1659-61 NCF21HZ-224X C CAP. 0.22µF 50V Z
C1662 QETN1HM-106Z E CAP. 10µF 50V M
C1663 NCF21HZ-224X C CAP. 0.22µF 50V Z
C1665 NCB31CK-104X C CAP. 0.1µF 16V K
C1666-67 NCB31HK-222X C CAP. 2200pF 50V K
C1668-69 NCB31CK-104X C CAP. 0.1µF 16V K
C1670 NCB31HK-223X C CAP. 0.022µF 50V K
C1671 QETN1EM-476Z E CAP. 47µF 25V M
C1672 NCB31HK-473X C CAP. 0.047µF 50V K
C1673 QETN1CM-336Z E CAP. 33µF 16V M
C1674 NCB31CK-104X C CAP. 0.1µF 16V K
C1675 NCB31HK-473X C CAP. 0.047µF 50V K
C1676 NCB31HK-223X C CAP. 0.022µF 50V K
C1681-82 QETN1CM-227Z E CAP. 220µF 16V M
C1683 QETN1CM-336Z E CAP. 33µF 16V M
C1685-86 NCF31AZ-105X C CAP. 1µF 10V Z
C1702 QETN1HM-106Z E CAP. 10µF 50V M
C1703-04 NDC31HJ-220X C CAP. 22pF 50V J
C1706 NCB21EK-224X C CAP. 0.22µF 25V K
C1707 QETN1CM-107Z E CAP. 100µF 16V M
C1709 QETN1CM-477Z E CAP. 470µF 16V M
C1710 NCB21EK-224X C CAP. 0.22µF 25V K
C1711 NCB31CK-104X C CAP. 0.1µF 16V K
C1712 QETN1CM-476Z E CAP. 47µF 16V M
C1713 NCB31CK-104X C CAP. 0.1µF 16V K
C1720 QETN1EM-476Z E CAP. 47µF 25V M
C1725 NCB31HK-681X C CAP. 680pF 50V K
C1729 QETN1CM-476Z E CAP. 47µF 16V M
C1730-31 NCB21EK-224X C CAP. 0.22µF 25V K
C1732 QETN1CM-107Z E CAP. 100µF 16V M
C1733 NCB31CK-104X C CAP. 0.1µF 16V K
C1734-35 NCB31HK-222X C CAP. 2200pF 50V K
C1736-37 QETN1HM-105Z E CAP. 1µF 50V M
C1738 NCB31CK-104X C CAP. 0.1µF 16V K
C1739 NFV41CJ-104X MPP CAP. 0.1µF 16V J
C1740 QETN1HM-225Z E CAP. 2.2µF 50V M
C1741-42 NCB31CK-104X C CAP. 0.1µF 16V K
C1743 QETN1CM-107Z E CAP. 100µF 16V M
C1744 NCB31HK-222X C CAP. 2200pF 50V K
C1745-47 NCB31HK-473X C CAP. 0.047µF 50V K
C1749 QETN1HM-106Z E CAP. 10µF 50V M
C1751-53 NCB21HK-104X C CAP. 0.1µF 50V K
C1801-04 QETN1HM-106Z E CAP. 10µF 50V M
C1805 NCB31CK-104X C CAP. 0.1µF 16V K
C1807-08 NCF31AZ-105X C CAP. 1µF 10V Z
C1810 NCF31AZ-105X C CAP. 1µF 10V Z
C1811 NCB31CK-104X C CAP. 0.1µF 16V K
C1812 NCF31AZ-105X C CAP. 1µF 10V Z
C1813 NCB31HK-103X C CAP. 0.01µF 50V K
C1814 NCB31CK-104X C CAP. 0.1µF 16V K
C1815 NCF31AZ-105X C CAP. 1µF 10V Z
C1817 NCF31AZ-105X C CAP. 1µF 10V Z
C1819 NCB31CK-104X C CAP. 0.1µF 16V K
C1820-21 NCF31AZ-105X C CAP. 1µF 10V Z
C1822 QETN1CM-477Z E CAP. 470µF 16V M
C1823-24 QETN1CM-107Z E CAP. 100µF 16V M
C1825 NCB31HK-103X C CAP. 0.01µF 50V K
C1826 NCB31CK-104X C CAP. 0.1µF 16V K
C1827 NCB31HK-103X C CAP. 0.01µF 50V K
C1829-31 NCB31HK-103X C CAP. 0.01µF 50V K
C1833 QETN1HM-226Z E CAP. 22µF 50V M
C1834 NDC31HJ-181X C CAP. 180pF 50V J
!
C1902 QFZ9073-104 MF CAP. 0.1µF
C1903-05 QCZ9015-102Z C CAP. 1000pF 250V Z
C1907 QEZ0371-337 E CAP. 330µF 400V M
C1909 QCZ0325-821 C CAP. 820pF 2000V K
C1910 NDC31HJ-471X C CAP. 50V J
C1911 QETN1VM-476Z E CAP. 47µF 35V M
C1915 QCS31HJ-151Z CH C CAP. 150pF 50V J
C1916 QETN1EM-476Z E CAP. 47µF 25V M
CAPACITOR
C1918 QCB32HK-103 C CAP. 0.01µF 500V K
C1919 QCZ0325-391 C CAP. 390pF 2000V K
C1921 QCS31HJ-820Z CH C CAP. 82pF 50V J
C1952 QCB32HK-471Z C CAP. 470pF 500V K
C1953 QEHQ1VM-228 E CAP. 2200µF 35V M
C1955 QCB32HK-471Z C CAP. 470pF 500V K
C1956 QETN1VM-107Z E CAP. 100µF 35V M
C1957 QCB31HK-471Z C CAP. 470pF 50V K
C1958 QEHR1CM-108Z E CAP. 1000µF 16V M
C1959 QCZ0364-561 C CAP. 560pF
C1960 QEZ0203-227 E CAP. 220µF 160V M
C1961 QETN1CM-476Z E CAP. 47µF 16V M
C1962 QETN1HM-106Z E CAP. 10µF 50V M
C1963 QETN1CM-477Z E CAP. 470µF 16V M
C1964 QETN1EM-476Z E CAP. 47µF 25V M
C1965 QETN1VM-476Z E CAP. 47µF 35V M
C1966 QETN1CM-107Z E CAP. 100µF 16V M
C1968 NCB31CK-104X C CAP. 0.1µF 16V K
C1970 QETN1CM-107Z E CAP. 100µF 16V M
C1972 QETN1EM-476Z E CAP. 47µF 25V M
C1974 NCB31CK-104X C CAP. 0.1µF 16V K
C1975 QETN1CM-227Z E CAP. 220µF 16V M
C1977 QETN1EM-476Z E CAP. 47µF 25V M
C1978 NCB21HK-104X C CAP. 0.1µF 50V K
C1980 QETN1CM-107Z E CAP. 100µF 16V M
C1981 NCB31HK-102X C CAP. 1000pF 50V K
C1982 QETN1CM-476Z E CAP. 47µF 16V M
C1983 QETN1CM-107Z E CAP. 100µF 16V M
!
C1991 QCZ9079-102 C CAP. 1000pF AC250V M
!
C1992-93 QCZ9079-471 C CAP. 470pF AC250V K
TRANSFORMER
T1521 QQR1229-001 DRIVE TRANSF.
!
T1551 QQH0096-001 FLYBACK TRANSF.
T1561 QQR1153-001 DEF.TRANSF.
!
T1901 QQS0110-001 SWICH.TRANSF.
COIL
L1001-02 QQL244K-8R2Z COIL 8.2µH K
L1101 QQL244J-5R6Z COIL 5.6µH J
L1104 QQL244K-180Z COIL 18µH K
L1301 QQL244K-221Z COIL 220µH K
L1401 QQL26AK-220Z COIL 22µH K
L1480 QQR1138-001 CHOKE COIL
L1523 QQR1243-001 LINEARITY COIL
L1541 QQL244K-220Z COIL 22µH K
L1561 QQLZ028-272 CHOKE COIL 2.7mH
L1601 QQL244K-4R7Z COIL 4.7µH K
L1701-02 QQL244K-100Z COIL 10µH K
L1731 QQL244J-101Z COIL 100µH J
L1951 QQLZ034-460 CHOKE COIL 46µH
L1953 QQL244J-5R6Z COIL 5.6µH J
L1954 QQL26AK-820Z COIL 82µH K
DIODE
D1101 DAN235K-X SI.DIODE
D1401 RGP10J-5025-T3 SI.DIODE
D1402 MTZJ75-T2 ZENER DIODE
D1405 1N4003-T2 SI.DIODE
D1408 MA111-X SI.DIODE
D1480 MTZJ4.3A-T2 ZENER DIODE
D1521 RH3G-F1 SI.DIODE
D1522 31DF6N-FC5 DIODE
D1523 RGP10J-5025-T3 SI.DIODE
D1541 RGP10J-5025-T3 SI.DIODE
40 No. 51970
AV-29L31
! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
DIODE
D1550 MA111-X SI.DIODE
D1551 EU2-T3 SI.DIODE
D1553 RGP10J-5025-T3 SI.DIODE
D1554 RGP10J-5025-T3 SI.DIODE
D1592 MA3075/H/-X ZENER DIODE
D1652-53 MA3330/L/-X ZENER DIODE
D1682 MA111-X SI.DIODE
D1701 NRSA63J-0R0X MG R 0.0Ø 1/16W J
D1702 MA3020-X ZENER DIODE
D1730-33 MA111-X SI.DIODE
D1801-02 MA3120/M/-X ZENER DIODE
D1901 GSIB460 DIODE
D1902 MTZJ33B-T2 ZENER DIODE
D1903 1SS133-T2 SI.DIODE
D1906 MTZJ27B-T2 ZENER DIODE
D1907 MTZJ33B-T2 ZENER DIODE
D1908 MA3200/M/-X ZENER DIODE
D1909 MA111-X SI.DIODE
D1910 MA3075/H/-X ZENER DIODE
D1911-12 RGP10J-5025-T3 SI.DIODE
D1913 RGP10M-5010-T3 SI.DIODE
D1914 1SS133-T2 SI.DIODE
D1915 MA3068/M/-X ZENER DIODE
D1916 MTZJ15B-T2 ZENER DIODE
D1950 RGP10J-5025-T3 SI.DIODE
D1952 ERC30-02L38 SI.DIODE
D1953 RGP10J-5025-T3 SI.DIODE
D1954 RU30A-F1 SI.DIODE
D1955 1SR35-400A-T2 SI.DIODE
D1956 31DF6N-FC5 DIODE
D1958 MTZJ5.1A-T2 ZENER DIODE
D1960 MA111-X SI.DIODE
D1964 MA3330/L/-X ZENER DIODE
D1966 MA3039/H/-X ZENER DIODE
D1968-69 MA111-X SI.DIODE
D1970 MTZJ9.1B-T2 ZENER DIODE
D1971 MA111-X SI.DIODE
TRANSISTOR
Q1101 2SC5083/L-P/-T SI.TRANSISTOR
Q1109 2SA1037AK/QR/-X SI.TRANSISTOR
Q1111 2SC2412K/QR/-X SI.TRANSISTOR
Q1150 2SC2412K/QR/-X SI.TRANSISTOR
Q1301-02 2SA1037AK/QR/-X SI.TRANSISTOR
Q1304 2SC2412K/QR/-X SI.TRANSISTOR
Q1480 2SD1408/OY/-LB SI.TRANSISTOR
Q1521 2SC2655/Y/-T SI.TRANSISTOR
Q1522 2SD2634-YD SI.TRANSISTOR
Q1591 2SA1208/ST/Z1-T SI.TRANSISTOR
Q1592 DTC124EKA-X DIGI.TRANSISTOR
Q1660-61 2SC2412K/QR/-X SI.TRANSISTOR
Q1683-84 2SA1037AK/QR/-X SI.TRANSISTOR
Q1685-86 DTC323TK-X DIGI.TRANSISTOR
Q1687 2SC2412K/QR/-X SI.TRANSISTOR
Q1701-02 2SA1037AK/QR/-X SI.TRANSISTOR
Q1703 2SC2412K/QR/-X SI.TRANSISTOR
Q1720 2SA1037AK/QR/-X SI.TRANSISTOR
Q1801-02 DTC323TK-X DIGI.TRANSISTOR
Q1803 2SA1037AK/QR/-X SI.TRANSISTOR
Q1804 2SC1740S/QR/-T SI.TRANSISTOR
Q1860 2SC2412K/QR/-X SI.TRANSISTOR
Q1861-62 2SA1037AK/QR/-X SI.TRANSISTOR
Q1901 2SC3852A SI.TRANSISTOR
Q1902-03 2SA1037AK/QR/-X SI.TRANSISTOR
Q1951 2SA1013/RO/-T SI.TRANSISTOR
Q1952-55 2SC2412K/QR/-X SI.TRANSISTOR
IC
IC1301 TDA9181T/N1-X I.C(MONO-ANA)
IC1401 LA78041 I.C(MONO-ANA)
IC1461 JLC1562BF-X I.C(DIGI-MOS)
IC1480 UPC358G2-XE I.C(MONO-ANA)
IC1601 MSP3445G-QG-B8 I.C
IC1650 AN5277 I.C(MONO-ANA)
IC1665 BA4558F-X I.C(MONO-ANA)
IC1701 TDA9365N13S0503 I.C(MICRO-COMP)
IC1702 AT24C08-29LS I.C(MEMORY-OTH) (SERVICE)
IC1801 MM1492AF I.C(MONO-ANA)
IC1901 STR-F6456S/F7 I.C(HYBRID)
IC1951 SE135N I.C(HYBRID)
IC1972 L88M33T-X I.C(MONO-ANA)
IC1973 BA17812T I.C(MONO-ANA)
IC1974 BA51W12ST-V5 I.C(MONO-ANA)
OTHERS
CF1106 QAX0639-001Z CERAMIC FILTER
!
CP1650 ICP-N50-Y I.C.PROTECT
!
CP1951 ICP-N75-Y I.C.PROTECT
!
CP1953 ICP-N38-Y I.C.PROTECT
J1801 QNN0349-001 PIN JACK
J1802 QNN0349-002 PIN JACK
J1803 QNN0348-001 PIN JACK
J1804 QNN0349-001 PIN JACK
K1301 CE41433-001Z BEADS CORE
K1705 QQR1214-001Y FERRITE BEADS
K1903 QQR1214-001Y FERRITE BEADS
K1904 CE42050-001Z CORE
K1951 QQR1214-001Y FERRITE BEADS
K1953-55 QQR1214-001Y FERRITE BEADS
LC1601 CE42482-103Y EMI FILTER
!
LF1901 QQR1035-002 LINE FILTER
!
PC1901 PC123F2 I.C(PH.COUPLER)
!
RY1901 QSK0061-001 RELAY
SF1101 QAX0663-001 SAW FILTER
SF1102 QAX0594-001 SAW FILTER
TH1901 QAD0134-4R5 P.THERMISTOR
TU1001 QAU0251-001 TUNER
W1010 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1067 QQR1214-001Y FERRITE BEADS
W1239 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1257 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1306-07 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1309 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1321 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1325-26 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1330 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1333 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1379 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1383 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1386 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1393 QQR1214-001Y FERRITE BEADS
W1395 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1397 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1405 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1418 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1423 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W1428 NRSA63J-0R0X MG R 0.0Ø 1/16W J
X1601 CE42546-001Z CRYSTAL
X1701 QAX0688-001 CRYSTAL
Y1004 NRSA63J-0R0X MG R 0.0Ø 1/16W J
Y1602-03 NRSA63J-0R0X MG R 0.0Ø 1/16W J
No. 51970 41
AV-29L31
CRT SOCKET PW BOARD ASS’Y(SCH-3001A-H2)
! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
RESISTOR
R3101 NRSA63J-682X MG R 6.8kØ 1/16W J
R3102 NRSA63J-102X MG R 1kØ 1/16W J
R3103 NRSA63J-153X MG R 15kØ 1/16W J
R3104 NRSA63J-682X MG R 6.8kØ 1/16W J
R3105 NRSA63J-102X MG R 1kØ 1/16W J
R3106 NRSA63J-272X MG R 2.7kØ 1/16W J
R3107 NRSA63J-682X MG R 6.8kØ 1/16W J
R3108 NRSA63J-102X MG R 1kØ 1/16W J
R3109 NRSA63J-562X MG R 5.6kØ 1/16W J
R3110-12 NRSA63J-101X MG R 100Ø 1/16W J
R3113 NRSA63J-563X MG R 56kØ 1/16W J
R3121-23 QRC121K-561Z COMP.R 560Ø 1/2W K
R3125 NRSA63J-222X MG R 2.2kØ 1/16W J
R3126 QRE121J-393Y C R 39kØ 1/2W J
R3128 NRSA63J-473X MG R 47kØ 1/16W J
R3129 NRSA63J-223X MG R 22kØ 1/16W J
R3142 NRSA63J-101X MG R 100Ø 1/16W J
R3150 QRZ0107-152Z C R 1.5kØ 1/2W K
R3152 NRSA63J-101X MG R 100Ø 1/16W J
R3160 NRSA63J-101X MG R 100Ø 1/16W J
R3166 QRZ0107-152Z C R 1.5kØ 1/2W K
R3170 QRZ0107-474Z C R 470kØ 1/2W K
R3171 QRZ0107-152Z C R 1.5kØ 1/2W K
R3172 NRSA63J-101X MG R 100Ø 1/16W J
!
R3175 QRZ9021-1R5 F R 1.5Ø 1W J
R3176 QRE121J-123Y C R 12kØ 1/2W J
R3211 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R3212 NRSA63J-153X MG R 15kØ 1/16W J
R3213 NRSA63J-222X MG R 2.2kØ 1/16W J
R3214 NRSA63J-152X MG R 1.5kØ 1/16W J
R3215 NRSA63J-680X MG R 68Ø 1/16W J
R3216 NRSA63J-221X MG R 220Ø 1/16W J
!
R3217 QRJ146J-100X C R 10Ø 1/4W J
R3221-22 NRSA63J-470X MG R 47Ø 1/16W J
R3224 NRSA63J-122X MG R 1.2kØ 1/16W J
R3225-26 QRE121J-563Y C R 56kØ 1/2W J
R3227 NRSA63J-122X MG R 1.2kØ 1/16W J
R3228 NRSA63J-390X MG R 39Ø 1/16W J
R3229-30 QRE121J-2R7Y C R 2.7Ø 1/2W J
R3231 NRSA63J-390X MG R 39Ø 1/16W J
R3232 QRE121J-121Y C R 120Ø 1/2W J
R3233 QRL029J-391 OM R 390Ø 2W J
R3251 NRSA63J-822X MG R 8.2kØ 1/16W J
R3252 NRSA63J-222X MG R 2.2kØ 1/16W J
R3253 NRSA63J-101X MG R 100Ø 1/16W J
R3254 NRSA63J-563X MG R 56kØ 1/16W J
R3255 NRSA63J-223X MG R 22kØ 1/16W J
R3256 NRSA63J-681X MG R 680Ø 1/16W J
R3257 NRSA63J-102X MG R 1kØ 1/16W J
R3258 NRSA63J-182X MG R 1.8kØ 1/16W J
R3259 NRSA63J-102X MG R 1kØ 1/16W J
R3260 NRSA63J-271X MG R 270Ø 1/16W J
R3261-63 NRSA63J-101X MG R 100Ø 1/16W J
R3264 NRSA63J-222X MG R 2.2kØ 1/16W J
R3265 NRSA63J-102X MG R 1kØ 1/16W J
R3266 NRSA63J-103X MG R 10kØ 1/16W J
R3267 NRSA63J-102X MG R 1kØ 1/16W J
R3268 NRSA63J-222X MG R 2.2kØ 1/16W J
R3269 NRSA63J-102X MG R 1kØ 1/16W J
R3270 NRSA63J-103X MG R 10kØ 1/16W J
R3271 NRSA63J-102X MG R 1kØ 1/16W J
R3272 NRSA63J-222X MG R 2.2kØ 1/16W J
R3273 NRSA63J-102X MG R 1kØ 1/16W J
R3274 NRSA63J-103X MG R 10kØ 1/16W J
R3275 NRSA63J-102X MG R 1kØ 1/16W J
CAPACITOR
C3110 QCZ0131-222 C CAP. 2200pF 2000V K
C3114 QCS31HJ-151Z CH C CAP. 150pF 50V J
C3121 QETN1HM-225Z E CAP. 2.2µF 50V M
C3123 QETN2EM-475Z E CAP. 4.7µF 250V M
C3204 NDC31HJ-561X C CAP. 560pF 50V J
C3205 QETN1HM-335Z E CAP. 3.3µF 50V M
C3206 QETN1HM-106Z E CAP. 10µF 50V M
C3209 QETN1CM-107Z E CAP. 100µF 16V M
C3211 NDC31HJ-391X C CAP. 390pF 50V J
C3212 QCB32HK-472Z C CAP. 4700pF 500V K
C3213 NDC31HJ-561X C CAP. 560pF 50V J
C3214 QETN2CM-106Z E CAP. 10µF 160V M
C3215 QCB32HK-472Z C CAP. 4700pF 500V K
C3216 QETN2CM-106Z E CAP. 10µF 160V M
C3217-18 QETN1AM-107Z E CAP. 100µF 10V M
C3219 QETN1AM-337Z E CAP. 330µF 10V M
C3251 QENC1HM-105Z E CAP. 1µF 50V M
C3252 NDC31HJ-151X C CAP. 150pF 50V J
C3253 NDC31HJ-560X C CAP. 56pF 50V J
C3255 NCB31HK-103X C CAP. 0.01µF 50V K
C3264-66 QETN1AM-107Z E CAP. 100µF 10V M
C3267 QETN1CM-227Z E CAP. 220µF 16V M
COIL
L3121 QQL244J-5R6Z COIL 5.6µH J
L3251 QQL244K-150Z COIL 15µH K
DIODE
D3107 MA111-X SI.DIODE
D3108 MA3075/H/-X ZENER DIODE
D3109 MA3051/H/-X ZENER DIODE
D3110 MA111-X SI.DIODE
D3111 MA3051/H/-X ZENER DIODE
D3112 MA111-X SI.DIODE
D3113 MA3051/H/-X ZENER DIODE
D3114 MA111-X SI.DIODE
D3115-17 EU01N-T2 SI.DIODE
D3121-23 1N4003-T2 SI.DIODE
D3124 MA111-X SI.DIODE
D3125 MTZJ75-T2 ZENER DIODE
D3201-02 NRSA63J-0R0X MG R 0.0Ø 1/16W J
D3203-04 RGP10J-5025-T3 SI.DIODE
TRANSISTOR
Q3101-06 2SC2412K/QR/-X SI.TRANSISTOR
Q3121 2SC4212/Z1/ SI.TRANSISTOR
Q3122 2SA1037AK/QR/-X SI.TRANSISTOR
Q3204-05 2SC1740S/QR/-T SI.TRANSISTOR
Q3206 2SA933AS/QR/-T SI.TRANSISTOR
Q3209 2SA1964/DE/ SI.TRANSISTOR
Q3210 2SC5248/DE/ SI.TRANSISTOR
Q3251 2SA1037AK/QR/-X SI.TRANSISTOR
Q3252 2SC2412K/QR/-X SI.TRANSISTOR
Q3253 2SA1037AK/QR/-X SI.TRANSISTOR
Q3261-63 2SA1037AK/QR/-X SI.TRANSISTOR
Q3264-66 2SC2412K/QR/-X SI.TRANSISTOR
IC
IC3101 TDA6107Q/N2 I.C(MONO-ANA)
CAPACITOR
C3101 QETN1CM-477Z E CAP. 470µF 16V M
C3102 QFK62EK-104Z MM CAP. 0.1µF 250V K
C3107 QETM2EM-336 E CAP. 33µF 250V M
C3109 QCZ0131-472 C CAP. 4700pF 2000V K
42 No. 51970
OTHERS
CL3001 QZW0028-002 WIRE CLAMP
DL3261-63 CE41925-001 DELAY LINE
!
FR3201 QRZ9021-561
AV-29L31
FRONT CONTROL PW BOARD ASS’Y(SCH-8001A-H2)
! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
OTHERS
K3201-04 CE41492-001Z CHOKE COIL
SG3101-03 QAF0006-501 ARRESTER
SG3104 QAF0041-272 ARRESTER
!
SK3001 CE42670-001 C.R.T.SOCKET
W3019 NRSA63J-0R0X MG R 0.0Ø 1/16W J
W3034 NRSA63J-0R0X MG R 0.0Ø 1/16W J
RESISTOR
R8482 NRSA63J-124X MG R 120kØ 1/16W J
R8483 NRSA63J-683X MG R 68kØ 1/16W J
R8484-85 NRSA63J-562X MG R 5.6kØ 1/16W J
R8486 NRSA63J-333X MG R 33kØ 1/16W J
R8487 NRSA63J-332X MG R 3.3kØ 1/16W J
R8488 NRSA63J-154X MG R 150kØ 1/16W J
R8489 NRSA63J-104X MG R 100kØ 1/16W J
R8491-92 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R8495 NRSA63J-152X MG R 1.5kØ 1/16W J
R8497 NRSA63J-562X MG R 5.6kØ 1/16W J
R8499 QRE121J-561Y C R 560Ø 1/2W J
R8801 NRSA63J-332X MG R 3.3kØ 1/16W J
R8802 NRSA63J-392X MG R 3.9kØ 1/16W J
R8803 NRSA63J-682X MG R 6.8kØ 1/16W J
R8805 NRSA63J-682X MG R 6.8kØ 1/16W J
R8807 NRSA63J-181X MG R 180Ø 1/16W J
R8808 NRSA63J-221X MG R 220Ø 1/16W J
R8809 NRSA63J-331X MG R 330Ø 1/16W J
R8810 NRSA63J-471X MG R 470Ø 1/16W J
R8811 NRSA63J-821X MG R 820Ø 1/16W J
R8812 NRSA63J-122X MG R 1.2kØ 1/16W J
R8813 NRSA63J-471X MG R 470Ø 1/16W J
R8815-16 QRE121J-271Y C R 270Ø 1/2W J
R8817-18 NRSA63J-102X MG R 1kØ 1/16W J
R8819 NRSA63J-272X MG R 2.7kØ 1/16W J
R8826 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R8830-31 NRSA63J-222X MG R 2.2kØ 1/16W J
!
R8901 QRZ0111-474 C R 470kØ 1/2W K
CAPACITOR
C8481-84 NCB21EK-224X C CAP. 0.22µF 25V K
C8485 QETN1EM-476Z E CAP. 47µF 25V M
C8487 QFLC1HJ-103Z M CAP. 0.01µF 50V J
C8660-61 QETM1VM-108 E CAP. 1000µF 35V M
C8801 QETN1HM-106Z E CAP. 10µF 50V M
C8802 QETN1CM-107Z E CAP. 100µF 16V M
C8803 NCB31CK-104X C CAP. 0.1µF 16V K
C8815 QETN1CM-107Z E CAP. 100µF 16V M
!
C8901 QFZ9073-224 MF CAP. 0.22µF
COIL
L8401 QQL244K-820Z COIL 82µH K
DIODE
D8601-02 MA3330/L/-X ZENER DIODE
D8801 MA111-X SI.DIODE
D8802 P1241-04 C.D.S.
D8803 SLR-342VR-T16 L.E.D.
TRANSISTOR
Q8481 2SC2412K/QR/-X SI.TRANSISTOR
Q8801 2SA1037AK/QR/-X SI.TRANSISTOR
IC
IC8481 LA6515 I.C(MONO-ANA)
IC8801 GP1U281Q IFR DETECT UNIT
OTHERS
CM35921-005-H CDS HOLDER
!
F8901 QMF51E2-4R0J4 FUSE
FC8901 CEMG002-001Z FUSE CLIP
CM36626-B01-H L.E.D.HOLDER
No. 51970 43
AV-29L31
! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
OTHERS
J8302 QNN0279-003 PIN JACK
J8303 QNN0279-002 PIN JACK
J8304 QNN0279-001 PIN JACK
J8801 QNS0155-001 JACK
!
LF8901 QQR1035-002 LINE FILTER
S8801 QSW0619-003Z PUSH SWITCH CH+
S8802 QSW0619-003Z PUSH SWITCH CHS8803 QSW0619-003Z PUSH SWITCH MENU
S8804 QSW0619-003Z PUSH SWITCH TV/VIDEO
S8805 QSW0619-003Z PUSH SWITCH VOL+
S8806 QSW0619-003Z PUSH SWITCH VOL-
!
S8901 QSW0750-001 PUSH SWITCH POWER
!
VA8901 QAF0052-621 VARISTOR
Y8401 NRSA63J-0R0X MG R 0.0Ø 1/16W J
REMOTE CONTROL UNIT PARTS LIST(RM-C248-2C)
!
Ref.No. Part No. Part Name Description Local
31392340128 BATTERY COVER
44 No. 51970
PACKING
AV-29L31
3
11
12
4
!!
6 7
5
3
12
1
9
8
3
10
3
2
PACKING PARTS LIST
!
Ref.No. Part No. Part Name Description Local
1 CP30967-004-H POLY BAG
2 GG10044-022B-H P CASE
3 LC11066-022B-H CUSHION ASSY
4 RM-C248-2C RC HAND UNIT
5 CP30966-001-H POLY BAG
!
6 LCT0991-001B-H INST
!
7 QAM0054-001 CONVERSION PLUG
8 LC30946-001A-H CRT PROTECTOR
9 LC30947-002A-H CAUTION SHEET
10 GG20012-001A-H CORNER LABEL (X2)
11 GG20011-003A-H SUPPORT PAD(FRONT)
12 GG20011-004A-H SUPPORT PAD(SIDE) (X2)
BOOK
10
No. 51970 45
AV-29L31
SERVICE NOTE :
46 No. 51970
Loading...
