JVC AV-28Z25EUY, AV-32Z25EUY Parts List

A

V-32Z25EU

Y

A

Y

V-28Z25EU

PARTS LIST

CAUTION

! The parts identified by the ! symbol are important for the safety. W henever replacing these parts, be sure to use specified ones to secure

the safety .

! The parts not indicated in this Parts List and those which are filled with lines 　　
! P. W. Board Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.

ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES

RESISTORS CAPACITORS

C R Carbon Resistor C CAP. Ceramic Capacitor

F R Fusible Resistor E CAP. Electrolytic Capacitor

P R Plate Resistor M CAP. Mylar Capacitor

in the Parts No. columns will not be supplied.

V R

HV R High Voltage Resistor MF CAP. Metalized Film Capacitor

MF R Metal Film Resistor MM CAP. Metalized Mylar Capacitor

MG R Metal Glazed Resistor MP CAP. Metalized Polystyrol C apacitor

MP R Metal Plate R esistor PP CAP. Polypropylene Capacitor

OM R Metal Oxide Film Resistor

CMF R Coating Metal Film Resistor TF CAP. Thin Film Capacitor

UNF R Non-Flammable R esistor MPP CAP. Metalized Polypropylene Capacitor

CH V R Chip Variable Resistor TAN. CAP. Tantalum Capacitor

CH MG R Chip Metal Glazed Resistor CH C CAP. Chip Ceramic Capacitor

COMP. R Composition Resistor BP E CAP. Bi-Polar Electr olytic C apacitor

LPTC R

Variable Resisto

Linear Positive Temperature Coefficient
Resistor

r

HV CAP. High Voltage Capacitor

.

PS CAP

CH AL E CAP. Chip Aluminum Electrolytic Capacitor

CH AL BP CAP.

CH TAN. E CAP.

Polystyrol Capacitor

Chip Aluminum Bi-Polar Capacitor

Chip Tantalum Electrolytic Capacitor

CH AL BP E CAP.

Chip Tantalum Bi-Polar Electrolytic Capacitor

TOLERANCES

FGJ KMNRHZP

±1% ±2% ±5% ±10% ±20% ±30%

+30%

-10%

No.52067

+50%

-10%

+80%

-20%

+100%

-0%

31

A

V-32Z25EU

Y

A

Y

[

]

V-28Z25EU

CONTENTS

!!!! USING PW BOARD & REMOTE CONTROL UNIT････････････････････････････････････････････････ 33
!!!! REMOTE CONTROL UNIT PARTS LIST ････････････････････････････････････････････････････････ 33

AV-32Z25EUY

[ AV-32Z25EUY ]

!!!! EXPLODED VIEW PARTS LIST････････････････････････････････････････････････････････････････ 34
!!!! EXPLODED VIEW･････････････････････････････････････････････････････････････････････････ 34,35

[ AV-28Z25EUY ]

!!!! EXPLODED VIEW PARTS LIST････････････････････････････････････････････････････････････････ 36
!!!! EXPLODED VIEW･････････････････････････････････････････････････････････････････････････ 36,37

[ AV-32Z25EUY ]

!!!! PRINTED WIRING BOARD PARTS LIST

MAIN PW BOARD ASS’Y

"

POWER & DEF. PW BOARD ASS’Y

"

CRT SOCKET PW BOARD ASS’Y

"
" FRONT CONTROL PW BOARD ASS’Y

" SIDE CONTROL PW BOARD ASS’Y

DOLBY PW BOARD ASS’Y

"
" MICOM PW BOARD ASS’Y

AV SW PW BOARD ASS’Y

"
" 100Hz PW BOARD ASS’Y

･････････････････････････････････････････････････････････････････････････････････････

････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････････････

･･･････････････････････････････････････････････････････････････････････････

････････････････････････････････････････････････････････････････････････････････････

････････････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････････

38

40

42

43

43

44

47

48

50

[ AV-28Z25EUY ]

!!!! PRINTED WIRING BOARD PARTS LIST

" MAIN PW BOARD ASS’Y

" POWER & DEF. PW BOARD ASS’Y
" CRT SOCKET PW BOARD ASS’Y
" FRONT CONTROL PW BOARD ASS’Y

" SIDE CONTROL PW BOARD ASS’Y

DOLBY PW BOARD ASS’Y

"

MICOM PW BOARD ASS’Y

"

AV SW PW BOARD ASS’Y

"

100Hz PW BOARD ASS’Y

"

･･････････････････････････････････････････････････････････････････････････････････････

････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････････････

･･･････････････････････････････････････････････････････････････････････････

････････････････････････････････････････････････････････････････････････････････････

････････････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････････････････････

･････････････････････････････････････････････････････････････････････････

52

55

57

58

58

58

58

58

58

[ AV-32Z25EUY ] [ AV-28Z25EUY ]

!!!! PACKING ･･･････････････････････････････････････････････････････････････････････････････････ 59
!!!! PACKING PARTS LIST ･･･････････････････････････････････････････････････････････････････････ 59

32

No.52067

A

Y

A

Y

USING PW BOARD & REMOTE CONTROL UNIT

V-32Z25EU
V-28Z25EU

Model

PWB AS S’Y

MAIN PWB SMF-1406A

POWER & DEF. PWB SMF-2406A

CRT SOCKET PWB SMF-3406A

FRONT CONTROL PWB SMF-8405A

SIDE CONTROL PWB SMF-8106A

DOLBY PWB SMF-0D401A

MICOM PWB SMF-0M403A

AV SW PWB SMF-0S402A

100Hz PWB SMF-0Z404A

REMOTE CONTROL UNIT RM-C58H-1C

AV-32Z25EUY AV-28Z25EUY

REMOTE CONTROL UNIT PARTS LIST

SMF-1405A

SMF-2405A

SMF-3407A

SMF-8105A

[ AV-32Z25EUY ] [ AV-28Z25EUY ]

! Ref.No. Part No. Part Name Description

1 2AA027770 BATTERY COVER
2 2AA027760 SLIDE COVER

2

1

(RM-C58H-1C)

No.52067

33

A

V-32Z25EU

Y

EXPLODED VIEW PARTS LIST

[ AV-32Z25EUY ]

!

Ref.No. Part No. Part Name Description

1 LC41 250-001C-C JVC MARK
2 LC31851-001B-C WINDOW

! 100 LC11360-005B-U FRONT CABI ASSY Inc.No.101～103
! 101 LC31201-004A-U POWER KNOB (SERVICE)

102 AEM3149-001-E SPRING
103 LC21031-001C-U SPEAKER PANEL

3 QAS0118-001 SPEAKER SP04

! 4LC11308-001B-U SP BOX T
! 5LC11309-001B-U SP BOX B

6 AEM2250-002A-U BASS INT.DUCT L (x2)
7 AEM2250-001A-U BASS INT.DUCT R (x2)
8 QYSBSAG4016N TAP SCREW (x23)
9 LC31935-001A-C PORT SPACER (x2)

! V01 W76ERF042X044 ITC TUBE(C) Inc.DY,PC MAGNET,WEDGE
! L01 QQW0066-001 DEGAUSSING COIL
! L03 QQW01 30-001 ROT-COIL
! T2551 QQH0127-001 F.B.TRANSF.

10 WJY0001-010A BRAIDED ASSY
11 WJY0013-002A BRAIDED SUB ASSY
12 CHFD1 25-14BD-N FFC WIRE CN-1

! 13LC10716-002G-U CHASSIS BASE

! 14LC11336-002B-U AV BOARD

15 QYSBSB3012M TAPPING SCREW (x6)

! 16LC11311-002A-U CONTROL BASE

17 LC31 205-001B CONTROL SHEET
18LC10856-001C-U SIDE CONTROL BASE
19 QYSBSAG4016N TAPPING SCREW

20 QAS0109-001 SPEAKER SP01-02(x2)
21 QAS0110-001 SPEAKER SP03

22 LC1131 0-001A-U SPEAKER ADAPTER (x2)
23 LC40226-003A-H SPACER (x4)
24 LC40506-001A TAPPING SCREW (x4)

! 25 QMPK160-185-JC POWER CORD CN-PW
! 26 CM46618-A01-E POWER CORD CLAMP
! 27 LC1131 6-001B-U REAR COVER

28 QYSBSAG4016N TAPPING SCREW (x13)

! 29 LC11548-001A-U RATING LABEL

! 30 LC30789-002B-U WARNING LABEL
! 31 QQR0491-001 CORE FILTER

EXPLODED VIEW

!

4

2

1

6

7

9

103

!

101

102

34

!

100

No.52067

8

8

(×13)

(×3)

7

3

8

6

(×3)

8

(×4)

!

5

A

Y

EXPLODED VIEW

V-32Z25EU

L01

!

L03

SIDE
CONTROL
PWB

!

V01

!

!

16

MAIN PWB

10

11

CRT SOCKET
PWB

FRONT
CONTROL
PWB

22

23

12

AV SW PWB

23

MICOM PWB

100Hz PWB

POWER & DEF. PWB

24

31

!

20

!

T2551

!

13

!

14

15

(×6)

18

27

!

17

19

21

DOLBY PWB

SUB WOOFER UNIT

!

30

!

25

!

26

!

29

28

(×13)

No.52067

35

A

V-28Z25EU

Y

EXPLODED VIEW PARTS LIST

[ AV-28Z25EUY ]

!

Ref.No. Part No. Part Name Description

1 LC41 250-001C-C JVC MARK
2 LC31851-001B-C WINDOW

! 100 LC11313-006A-U FRONT CABI ASSY Inc.No.101～103
! 101 LC31201-004A-U POWER KNOB (SERVICE)

102 AEM3149-001-E SPRING
103 LC21031-001C-U SPEAKER PANEL

3 QAS0118-001 SPEAKER SP04

! 4LC11308-001B-U SP BOX T
! 5LC11309-001B-U SP BOX B

6 AEM2250-002A-U BASS INT.DUCT L (x2)
7 AEM2250-001A-U BASS INT.DUCT R (x2)
8 QYSBSAG4016N TAP SCREW (x23)
9 LC31935-001A-C PORT SPACER (x2)

! V01 W66QDE993X925 ITC TUBE(C) Inc.DY,PC MAGNET,WEDGE
! L01 QQW0100-001 DEGAUSSING COIL
! T2551 QQH0126-001 F.B.TRANSF.

10 WJY0001-011A BRAIDED ASSY
11 WJY0013-002A BRAIDED SUB ASSY
12 CHFD1 25-11BD-N FFC WIRE CN-1

! 13LC10716-002G-U CHASSIS BASE
! 14LC11336-002B-U AV BOARD

15 QYSBSB3012M TAPPING SCREW (x6)

! 16LC11311-001A-U CONTROL BASE

17 LC31 205-001B CONTROL SHEET
18LC10856-001C-U SIDE CONTROL BASE
19 QYSBSAG4016N TAPPING SCREW

20 QAS0109-001 SPEAKER SP01-02(x2)
21 QAS0110-001 SPEAKER SP03
22 LC1131 0-001A-U SPEAKER ADAPTER (x2)

23 LC40226-003A-H SPACER (x4)
24 LC40506-001A TAPPING SCREW (x4)

! 25 QMPK160-185-JC POWER CORD CN-PW
! 26 CM46618-A01-E POWER CORD CLAMP
! 27 LC11282-001C-U REAR COVER

28 QYSBSAG4016N TAPPING SCREW (x13)

! 29 LC11548-002A-U RATING LABEL
! 30 LC30789-002B-U WARNING LABEL

! 31 QQR0491-001 CORE FILTER

EXPLODED VIEW

!

4

2

1

6

7

(×3)

8

8

(×13)

9

!

103

36

101

102

!

100

No.52067

7

3

6

8

(×3)

8

(×4)

!

5

A

Y

EXPLODED VIEW

!

L01

V01

V-28Z25EU

23

!

24

10

22

SIDE
CONTROL
PWB

17

18

27

!

19

21

!

16

MAIN PWB

11

FRONT
CONTROL
PWB

23

CRT SOCKET
PWB

12

AV SW PWB

DOLBY PWB

SUB WOOFER UNIT

MICOM PWB

20

100Hz PWB

POWER & DEF. PWB

!

T2551

13

!

31

!

26

!

!

14

15

(×6)

!

25

!

29

28

(×13)

No.52067

!

30

37

A

V-32Z25EU

Y

[ AV-32Z25EUY ]

PRINTED WIRING BOARD PARTS LIST

■ MAIN P.W. BOARD ASS’Y (SMF-1406A)

! Symbol No. Part No. Part Name Description

RESISTOR

R1004 NRSA63J-101X MG R 100Ω 1/16W J
R1005 NRSA63J-101X MG R 100Ω 1/16W J
R1006 NRSA63J-101X MG R 100
R1008 NRSA63J-101X MG R 100Ω 1/16W J
R1009 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1102 NRSA63J-0R0X MG R 0.0
R1103 NRSA63J-222X MG R 2.2kΩ 1/16W J
R1104 NRSA63J-102X MG R 1k
R1105 NRSA63J-561X MG R 560
R1106 NRSA63J-331X MG R 330Ω 1/16W J
R1108 NRSA63J-102X MG R 1kΩ 1/16W J
R1109 NRSA63J-101X MG R 100
R1110 NRSA63J-101X MG R 100
R1111 NRSA63J-101X MG R 100
R1151 NRSA63J-101X MG R 100
R1153 NRSA63J-101X MG R 100Ω 1/16W J
R1301 NRSA63J-101X MG R 100Ω 1/16W J
R1302 NRSA63J-101X MG R 100
R1303 NRSA63J-273X MG R 27kΩ 1/16W J
R1304 NRSA63J-102X MG R 1kΩ 1/16W J
R1311 NRSA63J-331X MG R 330
R1312 NRSA63J-273X MG R 27kΩ 1/16W J
R1313 NRSA63J-183X MG R 18kΩ 1/16W J
R1314 NRSA63J-221X MG R 220
R1315 NRSA63J-101X MG R 100Ω 1/16W J
R1316 NRSA63J-101X MG R 100Ω 1/16W J
R1317 NRSA63J-101X MG R 100
R1318 NRSA63J-562X MG R 5.6kΩ 1/16W J
R1319 NRSA63J-183X MG R 18kΩ 1/16W J
R1321 NRSA63J-0R0X MG R 0.0
R1322 NRSA63J-0R0X MG R 0.0
R1325 NRSA63J-101X MG R 100Ω 1/16W J
R1326 NRSA63J-682X MG R 6.8k
R1401 NRSA63J-102X MG R 1kΩ 1/16W J
R1402 NRSA63J-102X MG R 1kΩ 1/16W J
R1403 NRSA63J-331X MG R 330
R1404 NRSA63J-331X MG R 330Ω 1/16W J
R1405 NRSA63J-102X MG R 1kΩ 1/16W J
R1406 NRSA63J-102X MG R 1k
R1451 NRSA63J-821X MG R 820Ω 1/16W J
R1454 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1455 NRSA63J-123X MG R 12k
R1456 NRSA63J-123X MG R 12kΩ 1/16W J
R1457 NRSA63J-392X MG R 3.9kΩ 1/16W J
R1458 NRSA63J-123X MG R 12k
R1459 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1461 NRSA63J-123X MG R 12kΩ 1/16W J
R1462 NRSA63J-153X MG R 15k
R1463 NRSA63J-124X MG R 120kΩ 1/16W J
R1464 NRSA63J-563X MG R 56kΩ 1/16W J
R1465 NRSA63J-224X MG R 220k
R1466 NRSA63J-224X MG R 220kΩ 1/16W J
R1467 NRSA63J-563X MG R 56kΩ 1/16W J
R1468 NRSA63J-224X MG R 220k
R1469 NRSA63J-683X MG R 68kΩ 1/16W J
R1470 NRSA63J-223X MG R 22kΩ 1/16W J
R1471 NRSA63J-273X MG R 27k
R1472 NRSA63J-682X MG R 6.8kΩ 1/16W J
R1473 NRSA63J-123X MG R 12kΩ 1/16W J
R1474 NRSA63J-563X MG R 56k
R1475 NRSA63J-153X MG R 15kΩ 1/16W J
R1476 NRSA63J-123X MG R 12kΩ 1/16W J
R1477 NRSA63J-123X MG R 12k
R1478 NRSA63J-123X MG R 12kΩ 1/16W J
R1479 NRSA63J-154X MG R 150kΩ 1/16W J
R1480 NRSA63J-823X MG R 82k
R1481 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1482 NRSA63J-272X MG R 2.7kΩ 1/16W J
R1483 NRSA63J-472X MG R 4.7k
R1484 NRSA63J-473X MG R 47kΩ 1/16W J
R1485 NRSA63J-123X MG R 12kΩ 1/16W J
R1486 NRSA63J-472X MG R 4.7k
R1487 NRSA63J-333X MG R 33kΩ 1/16W J
R1489 NRSA63J-333X MG R 33kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

! Symbol No. Part No. Part Name Description

RESISTOR

R1491 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1492 NRSA63J-562X MG R 5.6k
R1493 NRSA63J-183X MG R 18k
R1501 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1504 NRSA63J-102X MG R 1k
R1511 NRSA63J-152X MG R 1.5kΩ 1/16W J
R1512 NRSA63J-332X MG R 3.3kΩ 1/16W J
R1521 NRSA63J-223X MG R 22k
R1522 NRSA63J-562X MG R 5.6kΩ 1/16W J
R1551 NRSA63J-100X MG R 10
R1552 NRSA63J-124X MG R 120k
R1553 NRSA63J-683X MG R 68kΩ 1/16W J
R1554 NRSA63J-562X MG R 5.6kΩ 1/16W J
R1555 NRSA63J-333X MG R 33k
R1556 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1557 NRSA63J-562X MG R 5.6kΩ 1/16W J
R1558 NRSA63J-104X MG R 100k
R1559 NRSA63J-154X MG R 150kΩ 1/16W J
R1560 NRSA63J-100X MG R 10Ω 1/16W J
R1561 QRN143J-0R0X C R 0.0
R1562 NRSA63J-683X MG R 68kΩ 1/16W J
R1563 NRSA63J-103X MG R 10kΩ 1/16W J
R1564 NRSA63J-223X MG R 22k
R1565 NRSA63J-562X MG R 5.6kΩ 1/16W J
R1591 NRSA63J-561X MG R 560Ω 1/16W J
R1592 NRSA63J-332X MG R 3.3k
R1595 NRSA63J-222X MG R 2.2kΩ 1/16W J
R1596 NRSA63J-104X MG R 100kΩ 1/16W J
R1601 NRSA63J-472X MG R 4.7k
R1603 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1604 NRSA63J-104X MG R 100k
R1605 NRSA63J-472X MG R 4.7k
R1607 NRSA63J-103X MG R 10kΩ 1/16W J
R1608 NRSA63J-103X MG R 10kΩ 1/16W J
R1609 NRSA63J-103X MG R 10k
R1613 NRSA63J-223X MG R 22kΩ 1/16W J
R1614 NRSA63J-104X MG R 100kΩ 1/16W J
R1616 NRSA63J-822X MG R 8.2k
R1617 NRSA63J-103X MG R 10kΩ 1/16W J
R1618 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1619 NRSA63J-473X MG R 47k
R1622 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1623 NRSA63J-103X MG R 10kΩ 1/16W J
R1624 NRSA63J-473X MG R 47k
R1625 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1626 NRSA63J-104X MG R 100kΩ 1/16W J
R1627 NRSA63J-472X MG R 4.7k
R1628 NRSA63J-104X MG R 100kΩ 1/16W J
R1629 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1630 NRSA63J-104X MG R 100k
R1631 NRSA63J-103X MG R 10kΩ 1/16W J
R1632 NRSA63J-103X MG R 10kΩ 1/16W J
R1633 NRSA63J-103X MG R 10k
R1637 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1638 NRSA63J-103X MG R 10kΩ 1/16W J
R1639 NRSA63J-473X MG R 47k
R1640 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1641 NRSA63J-103X MG R 10kΩ 1/16W J
R1642 NRSA63J-473X MG R 47k
R1643 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1646 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1649 NRSA63J-223X MG R 22k
R1650 NRSA63J-223X MG R 22kΩ 1/16W J
R1651 NRSA63J-223X MG R 22kΩ 1/16W J
R1652 NRSA63J-473X MG R 47k
R1653 NRSA63J-273X MG R 27kΩ 1/16W J
R1655 NRSA63J-104X MG R 100kΩ 1/16W J
R1656 NRSA63J-822X MG R 8.2k
R1657 NRSA63J-104X MG R 100kΩ 1/16W J
R1701 NRSA63J-103X MG R 10kΩ 1/16W J
R1702 NRSA63J-103X MG R 10k
R1703 NRSA63J-102X MG R 1kΩ 1/16W J
R1704 NRSA63J-102X MG R 1kΩ 1/16W J
R1706 NRSA63J-103X MG R 10k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

38

No. 52067

A

V-32Z25EU

Y

! Symbol No. Part No. Part Name Description

RESISTOR

R1707 NRSA63J-103X MG R 10kΩ 1/16W J
R1708 NRSA63J-103X MG R 10k
R1709 QRE121J-151Y C R 150
R1711 NRSA63J-101X MG R 100
R1712 NRSA63J-101X MG R 100
R1714 NRSA63J-102X MG R 1kΩ 1/16W J
R1715 NRSA63J-102X MG R 1k
R1720 NRSA63J-102X MG R 1k
R1721 NRSA63J-102X MG R 1kΩ 1/16W J
R1722 NRSA63J-102X MG R 1kΩ 1/16W J
R1772 NRSA63J-221X MG R 220
R1773 NRSA63J-221X MG R 220
R1774 NRSA63J-221X MG R 220
R1775 NRSA63J-221X MG R 220
R1776 NRSA63J-221X MG R 220Ω 1/16W J
R1951 QRK126J-220X C R 22Ω 1/2W J

CAPACITOR

C1001 NCB31HK-222X C CAP. 2200pF 50V K
C1002 QETN1HM-106Z E CAP. 10
C1004 NCB31CK-104X C CAP. 0.1µF 16V K
C1005 QETN1CM-108Z E CAP. 1000
C1006 NCB31HK-103X C CAP. 0.01
C1007 QETN1HM-106Z E CAP. 10µF 50V M
C1009 NCB31CK-104X C CAP. 0.1µF 16V K
C1010 QETN1HM-106Z E CAP. 10
C1101 NCB31CK-104X C CAP. 0.1µF 16V K
C1102 QETN1HM-106Z E CAP. 10µF 50V M
C1103 NCB31CK-104X C CAP. 0.1
C1104 QETN1CM-107Z E CAP. 100µF 16V M
C1105 QETN1HM-106Z E CAP. 10µF 50V M
C1106 NCB31CK-104X C CAP. 0.1
C1107 NCB31CK-104X C CAP. 0.1µF 16V K
C1111 NCB31HK-103X C CAP. 0.01µF 50V K
C1116 NCB31HK-472X C CAP. 4700pF 50V K
C1117 NCB31HK-103X C CAP. 0.01
C1118 NCB31HK-103X C CAP. 0.01µF 50V K
C1119 NDC31HJ-2R0X C CAP. 2.0pF 50V J
C1120 NDC31HJ-2R0X C CAP. 2.0pF 50V J
C1121 NCB31HK-103X C CAP. 0.01
C1122 NDC31HJ-102X C CAP. 1000pF 50V J
C1123 NDC31HJ-102X C CAP. 1000pF 50V J
C1124 QETN1HM-106Z E CAP. 10
C1125 QETN1HM-106Z E CAP. 10µF 50V M
C1126 NCB31CK-104X C CAP. 0.1µF 16V K
C1127 QETN1HM-106Z E CAP. 10
C1128 NCB31CK-104X C CAP. 0.1µF 16V K
C1129 NCF31AZ-105X C CAP. 1µF 10V Z
C1130 QETN1HM-106Z E CAP. 10
C1151 NCF31AZ-105X C CAP. 1µF 10V Z
C1152 NCF31AZ-105X C CAP. 1µF 10V Z
C1301 QETN1CM-107Z E CAP. 100
C1302 NCB31CK-104X C CAP. 0.1µF 16V K
C1303 NCB31CK-104X C CAP. 0.1µF 16V K
C1305 NCB31CK-104X C CAP. 0.1
C1306 NCB31CK-104X C CAP. 0.1µF 16V K
C1307 NCB31CK-104X C CAP. 0.1µF 16V K
C1308 NCB31CK-104X C CAP. 0.1
C1309 NCB31CK-104X C CAP. 0.1µF 16V K
C1310 QETN1AM-228Z E CAP. 2200µF 10V M
C1311 NCB31CK-683X C CAP. 0.068
C1312 NDC31HJ-221X C CAP. 220pF 50V J
C1313 NCB31HK-223X C CAP. 0.022
C1314 NCB31HK-223X C CAP. 0.022µF 50V K
C1315 NCB31HK-223X C CAP. 0.022
C1316 NCB31HK-103X C CAP. 0.01µF 50V K
C1317 NCB31HK-103X C CAP. 0.01µF 50V K
C1318 NCB31HK-103X C CAP. 0.01
C1320 QETN0JM-228Z E CAP. 2200µF 6.3V M
C1321 NCB31HK-223X C CAP. 0.022µF 50V K
C1322 NCB31HK-223X C CAP. 0.022
C1323 NCB31HK-223X C CAP. 0.022µF 50V K
C1324 NDC31HJ-820X C CAP. 82pF 50V J
C1351 QENC1EM-106Z BP E CAP. 10
C1401 NCB31CK-104X C CAP. 0.1
C1402 QETN1CM-107Z E CAP. 100µF 16V M
C1403 NCB31CK-104X C CAP. 0.1µF 16V K
C1404 NCB31CK-104X C CAP. 0.1
C1453 NCB31HK-103X C CAP. 0.01µF 50V K

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

µ

F 50V M

µ

F 16V M

µ

F 50V K

µ

F 50V M

µ

F 16V K

µ

F 16V K

µ

F 50V K

µ

F 50V K

µ

F 50V M

µ

F 50V M

µ

F 50V M

µ

F 16V M

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 25V M

µ

F 16V K

µ

F 16V K

! Symbol No. Part No. Part Name Description

CAPACITOR

C1454 NCB31EK-333X C CAP. 0.033µF 25V K
C1455 NCB31CK-104X C CAP. 0.1
C1456 NCB31CK-104X C CAP. 0.1
C1457 NCB31EK-333X C CAP. 0.033
C1458 NCB31CK-104X C CAP. 0.1
C1491 NCB31EK-473X C CAP. 0.047µF 25V K
C1471 NCB31CK-104X C CAP. 0.1
C1472 NCB31HK-103X C CAP. 0.01
C1473 NCB31CK-104X C CAP. 0.1µF 16V K
C1474 NCB31EK-333X C CAP. 0.033µF 25V K
C1475 NCB31CK-104X C CAP. 0.1
C1501 NDC31HJ-150X C CAP. 15pF 50V J
C1502 NDC31HJ-150X C CAP. 15pF 50V J
C1551 NCF31CZ-224X C CAP. 0.22
C1552 NCF31CZ-224X C CAP. 0.22µF 16V Z
C1553 QETN1EM-476Z E CAP. 47
C1554 NCF31CZ-224X C CAP. 0.22
C1555 NCF31CZ-224X C CAP. 0.22µF 16V Z
C1560 QETN1CM-107Z E CAP. 100
C1561 NDC31HJ-561X C CAP. 560pF 50V J
C1562 QETN1HM-105Z E CAP. 1
C1564 NCB31CK-104X C CAP. 0.1µF 16V K
C1591 NDC31HJ-471X C CAP. 470pF 50V J
C1596 NCB31CK-104X C CAP. 0.1
C1601 QETN1HM-106Z E CAP. 10µF 50V M
C1602 QETN1HM-106Z E CAP. 10µF 50V M
C1603 QETN1HM-106Z E CAP. 10
C1604 QETN1HM-107Z E CAP. 100µF 50V M
C1611 QETN1EM-108Z E CAP. 1000µF 25V M
C1612 QETN1EM-108Z E CAP. 1000
C1613 QETN1EM-108Z E CAP. 1000µF 25V M
C1614 QETN1HM-106Z E CAP. 10µF 50V M
C1616 QETN1HM-106Z E CAP. 10
C1617 QETN1HM-106Z E CAP. 10µF 50V M
C1618 QETN1HM-106Z E CAP. 10µF 50V M
C1619 QETN1HM-106Z E CAP. 10
C1620 QETN1HM-107Z E CAP. 100µF 50V M
C1621 QETM1VM-228 E CAP. 2200µF 35V M
C1628 QETN1EM-108Z E CAP. 1000
C1629 QETM1EM-338 E CAP. 3300µF 25V M
C1630 QETN1EM-108Z E CAP. 1000µF 25V M
C1631 QETN1HM-106Z E CAP. 10
C1633 QETN1HM-106Z E CAP. 10µF 50V M
C1634 QETN1CM-108Z E CAP. 1000µF 16V M
C1635 QETM1VM-228 E CAP. 2200
C1636 QETN1HM-107Z E CAP. 100µF 50V M
C1637 QETN1HM-107Z E CAP. 100µF 50V M
C1638 NCB31HK-104X C CAP. 0.1
C1639 QETN1CM-108Z E CAP. 1000µF 16V M
C1640 QETN1CM-107Z E CAP. 100µF 16V M
C1641 QETN1CM-107Z E CAP. 100
C1642 NCB31HK-104X C CAP. 0.1µF 50V K
C1701 QETN1HM-106Z E CAP. 10µF 50V M
C1702 NCB31CK-563X C CAP. 0.056
C1703 QETN1CM-107Z E CAP. 100µF 16V M
C1951 QETN1CM-477Z E CAP. 470µF 16V M
C1952 NCB31CK-104X C CAP. 0.1
C1953 NCB31CK-104X C CAP. 0.1µF 16V K
C1954 QETN1AM-477Z E CAP. 470µF 10V M
C1955 QETN1AM-227Z E CAP. 220
C1956 QETN1AM-107Z E CAP. 100µF 10V M

COIL

L1001 QQL244K-270Z COIL 27µH K
L1002 QQL244K-100Z COIL 10
L1003 QQL244K-100Z COIL 10µH K
L1101 QRN143J-0R0X C R 0.0Ω 1/4W J
L1102 QQL244K-4R7Z COIL 4.7
L1301 NQL092K-1R5X COIL 1.5µH
L1302 NQL092K-1R5X COIL 1.5µH
L1951 QQL26AM-5R6Z COIL 5.6

DIODE

D1317 MA111-X SI.DIODE
D1318 MA111-X SI.DIODE
D1319 MA3036-X ZENER DIODE
D1320 MA3056/M/-X ZENER DIODE
D1321 MA3056/M/-X ZENER DIODE

µ

F 16V K

µ

F 16V K

µ

F 25V K

µ

F 16V K

µ

F 16V K

µ

F 50V K

µ

F 16V K

µ

F 16V Z

µ

F 25V M

µ

F 16V Z

µ

F 16V M

µ

F 50V M

µ

F 16V K

µ

F 50V M

µ

F 25V M

µ

F 50V M

µ

F 50V M

µ

F 25V M

µ

F 50V M

µ

F 35V M

µ

F 50V K

µ

F 16V M

µ

F 16V K

µ

F 16V K

µ

F 10V M

µ

H K

µ

H K

µ

H M

No. 52067

39

A

V-32Z25EU

Y

! Symbol No. Part No. Part Name Description

DIODE

D1471 MA111-X SI.DIODE
D1472 MA111-X SI.DIODE
D1473 MA111-X SI.DIODE
D1474 MA111-X SI.DIODE
D1475 MA3240/M/-X ZENER DIODE
D1521 MA111-X SI.DIODE
D1591 MA111-X SI.DIODE
D1592 MA3051/M/-X ZENER DIODE
D1593 MA111-X SI.DIODE
D1601 MA3330/L/-X ZENER DIODE
D1602 MA3330/L/-X ZENER DIODE
D1603 MA3330/L/-X ZENER DIODE
D1604 MA111-X SI.DIODE
D1606 MA111-X SI.DIODE
D1607 MA111-X SI.DIODE
D1608 MA111-X SI.DIODE
D1610 MA111-X SI.DIODE
D1611 MA3330/L/-X ZENER DIODE
D1612 MA3330/L/-X ZENER DIODE
D1613 MA3330/L/-X ZENER DIODE
D1614 MA111-X SI.DIODE
D1615 MA111-X SI.DIODE
D1616 MA111-X SI.DIODE
D1617 MA111-X SI.DIODE
D1618 MA111-X SI.DIODE
D1619 MA111-X SI.DIODE
D1620 MA111-X SI.DIODE
D1621 MA111-X SI.DIODE
D1622 MA111-X SI.DIODE
D1623 MA111-X SI.DIODE
D1624 MA111-X SI.DIODE
D1771 MA3056/M/-X ZENER DIODE
D1772 MA3056/M/-X ZENER DIODE
D1773 MA3056/M/-X ZENER DIODE
D1774 MA3056/M/-X ZENER DIODE
D1775 MA3033-X ZENER DIODE
D1951 1SR35-400A-T2 SI.DIODE
D1981 MA111-X SI.DIODE
D1982 MA111-X SI.DIODE

TRANSISTOR

Q1101 2SC2412K/QR/-X SI.TRANSISTOR
Q1102 2SC2412K/QR/-X SI.TRANSISTOR
Q1301 2SA1037AK/QR/-X SI.TRANSISTOR
Q1471 2SC2412K/QR/-X SI.TRANSISTOR
Q1472 2SC2412K/QR/-X SI.TRANSISTOR
Q1561 2SC2412K/QR/-X SI.TRANSISTOR
Q1562 2SA1037AK/QR/-X SI.TRANSISTOR
Q1591 2SA1037AK/QR/-X SI.TRANSISTOR
Q1592 2SC2412K/QR/-X SI.TRANSISTOR
Q1601 2SA1037AK/QR/-X SI.TRANSISTOR
Q1603 DTC144EKA-X DIGI.TRANSISTOR
Q1605 DTC144EKA-X DIGI.TRANSISTOR
Q1606 2SC2412K/QR/-X SI.TRANSISTOR
Q1608 DTC144EKA-X DIGI.TRANSISTOR
Q1609 2SC2412K/QR/-X SI.TRANSISTOR
Q1611 2SA1037AK/QR/-X SI.TRANSISTOR
Q1612 DTC144EKA-X DIGI.TRANSISTOR
Q1613 DTC144EKA-X DIGI.TRANSISTOR
Q1614 DTC144EKA-X DIGI.TRANSISTOR
Q1615 DTC144EKA-X DIGI.TRANSISTOR
Q1616 2SC2412K/QR/-X SI.TRANSISTOR
Q1617 DTC144EKA-X DIGI.TRANSISTOR
Q1618 2SC2412K/QR/-X SI.TRANSISTOR
Q1620 2SA1037AK/QR/-X SI.TRANSISTOR

IC

IC1101 MSP3415DQGB3GHX IC
IC1301 SDA9380 IC
IC1402 BA10324AF-XE IC
IC1471 BA10358F-XE IC
IC1551 LA6515 I C
IC1601 AN7585 IC
IC1602 AN7585 IC
IC1603 AN78L24-T IC
IC1604 AN78L05-T IC
IC1701 JLC1562BF-X I C
IC1951 BA09T IC
IC1952 BA08T IC

OTHERS

CN1002 QGF1220C2-25 FFC/FPC CONNE
K1001 NQR0389-003X FERRITE BEADS

! Symbol No. Part No. Part Name Description

OTHERS

K1101 NQR0389-003X FERRITE BEADS
K1102 NQR0389-003X FERRITE BEADS
K1301 NQR0413-003X FERRITE BEADS
LC1102 NQR0431-001X EMI FILTER
LC1301 NQR0431-001X EMI FILTER
LC1302 NQR0431-001X EMI FILTER
LC1303 NQR0431-001X EMI FILTER
TU1001 QAU0276-001 TUNER
X1101 CE42546-001Z CRYSTAL
X1501 QAX0549-001Z CRYSTAL

■■■■POWER & DEF. P.W. BOARD ASS’Y (SMF-2406A)

! Symbol No. Part No. Part Name Description

RESISTOR

R2401 QRE141J-562Y C R 5.6kΩ 1/4W J
R2402 QRE141J-562Y C R 5.6kΩ 1/4W J
R2403 QRE141J-222Y C R 2.2k
R2404 QRX01GJ-1R0 MF R 1.0Ω 1W J
R2405 QRL029J-151 OM R 150Ω 2W J
R2406 QRE141J-222Y C R 2.2k
R2407 QRX01GJ-2R2 MF R 2.2Ω 1W J
R2408 QRX01GJ-1R5 MF R 1.5Ω 1W J
R2409 QRE141J-823Y C R 82k
R2410 QRE141J-103Y C R 10kΩ 1/4W J
R2421 QRE141J-103Y C R 10kΩ 1/4W J
R2422 QRE141J-274Y C R 270k
R2461 QRG029J-820 OM R 82Ω 2W J
R2462 QRE141J-473Y C R 47kΩ 1/4W J
R2463 QRE141J-682Y C R 6.8k
R2464 QRX01GJ-3R3 MF R 3.3Ω 1W J
R2468 QRE141J-102Y C R 1kΩ 1/4W J
R2469 QRE141J-272Y C R 2.7k
R2471 QRE141J-391Y C R 390Ω 1/4W J
R2472 QRA14CF-1002Y MF R 10kΩ 1/4W F
R2473 QRE141J-473Y C R 47k
R2474 QRE141J-103Y C R 10kΩ 1/4W J
R2475 QRE141J-102Y C R 1kΩ 1/4W J
R2476 QRE141J-102Y C R 1k
R2477 QRE141J-563Y C R 56kΩ 1/4W J
R2478 QRE141J-333Y C R 33kΩ 1/4W J
R2501 QRE141J-471Y C R 470
R2502 QRE141J-123Y C R 12kΩ 1/4W J
R2503 QRE121J-152Y C R 1.5kΩ 1/2W J
R2504 QRL039J-272 OM R 2.7k
R2505 QRL039J-272 OM R 2.7kΩ 3W J
R2506 QRE121J-5R6Y C R 5.6Ω 1/2W J
R2521 QRE121J-471Y C R 470
R2522 QRE141J-223Y C R 22kΩ 1/4W J
R2523 QRE141J-103Y C R 10kΩ 1/4W J
R2524 QRC121K-152Z COMP.R 1.5k
R2525 QRL039J-103 OM R 10kΩ 3W J
R2541 QRE141J-182Y C R 1.8kΩ 1/4W J
R2542 QRE141J-222Y C R 2.2k
R2543 QRE121J-272Y C R 2.7kΩ 1/2W J

! R2551 QRZ9022-R47 F R 0.47 Ω 1W K
! R2552 QRZ9022-R47 F R 0.47
! R2555 QRZ9022-R33 F R 0.33 Ω 1W K

R2561 QRG01GJ-220 OM R 22Ω 1W J
R2562 QRE121J-123Y C R 12k
R2563 QRZ0056-103Z COMP R 10kΩ 1/2W K
R2581 QRF154K-4R7 UNF R 4.7Ω 15W K
R2582 QRE141J-681Y C R 680
R2583 QRE121J-682Y C R 6.8kΩ 1/2W J
R2584 QRE141J-183Y C R 18kΩ 1/4W J
R2585 QRE141J-222Y C R 2.2k
R2586 QRA14CF-6201Y MF R 6.2kΩ 1/4W F
R2587 QRA14CF-2801Y MF R 2.8kΩ 1/4W F
R2588 QRE141J-103Y C R 10k

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

3W J

Ω

1/2W J

Ω

1/2W K

Ω

1/4W J

Ω

1W K

Ω

1/2W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

40

No. 52067

A

V-32Z25EU

Y

! Symbol No. Part No. Part Name Description

RESISTOR

Ω

! R2591 QRZ9017-4R7 F R 4.7

R2901 QRE121J-331Y C R 330Ω 1/2W J

! R2902 QRF054K-3R3 UNF R 3.3
! R2903 QRF104K-3R9 UNF R 3.9

R2904 QRL039J-683 OM R 68kΩ 3W J
R2905 QRE121J-474Y C R 470k
R2906 QRE121J-474Y C R 470k
R2908 QRL039J-823 OM R 82k
R2909 QRL039J-823 OM R 82k

! R2910 QRE121J-150Y C R 15Ω 1/2W J

R2911 QRE121J-152Y C R 1.5k
R2914 QRM059J-R10 MP R 0.10
R2915 QRE121J-681Y C R 680
R2916 QRE121J-332Y C R 3.3kΩ 1/2W J
R2931 QRE141J-1R0Y C R 1.0
R2932 QRE141J-1R5Y C R 1.5Ω 1/4W J
R2933 QRE141J-1R8Y C R 1.8Ω 1/4W J
R2944 QRE141J-103Y C R 10k
R2945 QRE141J-563Y C R 56kΩ 1/4W J
R2946 QRE141J-103Y C R 10k
R2951 QRE121J-102Y C R 1k
R2952 QRL039J-223 OM R 22kΩ 3W J
R2954 QRE141J-103Y C R 10kΩ 1/4W J
R2959 QRT039J-R68 MF R 0.68
R2961 QRE141J-332Y C R 3.3kΩ 1/4W J
R2963 QRL039J-561 OM R 560Ω 3W J
R2964 QRT039J-1R5 MF R 1.5
R2981 QRE141J-153Y C R 15kΩ 1/4W J
R2982 QRE141J-102Y C R 1kΩ 1/4W J

! R2991 QRZ9046-825Z C R 8.2M

CAPACITOR

C2404 QCZ0120-104Z C CAP. 0.1µF 25V Z
C2405 QDC31HJ-820Z C CAP. 82pF 50V J
C2406 QETM1VM-108 E CAP. 1000
C2408 QETN1VM-337Z E CAP. 330
C2409 QFV71HJ-474Z MF CAP. 0.47µF 50V J
C2410 QFV71HJ-474Z MF CAP. 0.47µF 50V J
C2411 QFLC2AJ-104Z M CAP. 0.1
C2414 QCB31HK-682Z C CAP. 6800pF 50V K
C2421 QETN1HM-105Z E CAP. 1
C2461 QEZ0414-226 E CAP. 22µF 50V M
C2462 QFM72DJ-152Z M CAP. 1500pF 200V J
C2463 QFM72DJ-122Z M CAP. 1200pF 200V J
C2464 QCZ0120-104Z C CAP. 0.1
C2465 QETN1HM-106Z E CAP. 10µF 50V M
C2466 QFP31HJ-272Z PP CAP. 2700pF 50V J
C2467 QFLC1HJ-102Z M CAP. 1000pF 50V J
C2468 QETN1EM-476Z E CAP. 47
C2470 QCS31HJ-470Z C CAP. 47pF 50V J
C2471 QFLC1HJ-103Z M CAP. 0.01
C2501 QCB32HK-331Z C CAP. 330pF 500V K
C2502 QFM72DK-103 M CAP. 0.01
C2503 QFV71HJ-224Z MF CAP. 0.22µF 50V J

! C2521 QFZ0122-112 MPP CAP. 1100pF1.8kVH±3%
! C2522 QFZ0200-123 MPP CAP. 0.012

C2523 QFM72DK-393 M CAP. 0.039

! C2524 QFP32JJ-183 PP CAP. 0.018

C2526 QFZ0197-184 MPP CAP. 0.18µF 250V J
C2527 QFZ0194-104 MPP CAP. 0.1µF 250V J
C2529 QFZ0194-154 MPP CAP. 0.15
C2530 QCB32HK-561Z C CAP. 560pF 500V K
C2531 QFZ0194-534 MPP CAP. 0.53
C2532 QETM2CM-227 E CAP. 220µF 160V M
C2533 QETN2EM-475Z E CAP. 4.7
C2541 QENC1HM-105Z E CAP. 1µF 50V M
C2551 QCB32HK-152Z C CAP. 1500pF 500V K
C2552 QETN1CM-108Z E CAP. 1000
C2553 QCB32HK-152Z C CAP. 1500pF 500V K
C2554 QETN1CM-108Z E CAP. 1000
C2555 QCB32HK-102Z C CAP. 1000pF 500V K
C2556 QETN2EM-106Z E CAP. 10
C2558 QETN1CM-477Z E CAP. 470µF 16V M
C2559 QEHR1CM-227Z E CAP. 220
C2561 QFLC2AJ-223Z M CAP. 0.022µF 100V J
C2581 QETN1CM-107Z E CAP. 100µF 16V M
C2582 QETN1EM-476Z E CAP. 47
C2583 QETN2AM-106Z E CAP. 10µF 100V M
C2584 QETN1AM-227Z E CAP. 220µF 10V M

1/4W J

Ω

5W K

Ω

10W K

Ω

1/2W J

Ω

1/2W J

Ω

3W J

Ω

3W J

Ω

1/2W J

Ω

5W J

Ω

1/2W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/2W J

Ω

3W J

Ω

3W J

Ω

1/2W K

µ

F 35V M

µ

F 35V M

µ

F 100V J

µ

F 50V M

µ

F 25V Z

µ

F 25V M

µ

F 50V J

µ

F 200V K

µ

F1.5kVH±3%

µ

F 200V K

µ

F 630V J

µ

F 250V J

µ

F 250V J

µ

F 250V M

µ

F 16V M

µ

F 16V M

µ

F 250V M

µ

F 16V M

µ

F 25V M

! Symbol No. Part No. Part Name Description

CAPACITOR

µ

! C2901 QFZ9072-473 MF CAP. 0.047
! OR QFZ9075-473 MPP CAP. 0.047
! C2902 QFZ9072-104 MF CAP. 0.1
! OR QFZ9075-104 MPP CAP. 0.1
! C2903 QFZ9072-473 MF CAP. 0.047
! OR QFZ9075-473 MPP CAP. 0.047µFAC275V M
! C2904 QCZ9054-472 C CAP. 4700pFAC250V Z
! C2905 QCZ9054-472 C CAP. 4700pFAC250V Z
! C2906 QCZ9054-472 C CAP. 4700pFAC250V Z

C2907 QEZ0199-227 E CAP. 220
C2908 QCB32HK-103 C CAP. 0.01
C2909 QCZ0340-391 C CAP. 390pF 2kV K
C2910 QETN1HM-476Z E CAP. 47
C2911 QCB31HK-102Z C CAP. 1000pF 50V K
C2912 QCZ0340-561 C CAP. 560pF 2kV K
C2914 QCB31HK-471Z C CAP. 470pF 50V K
C2915 QFLC1HJ-104Z M CAP. 0.1
C2916 QCB32HK-152Z C CAP. 1500pF 500V K

! C2931 QCZ9054-472 C CAP. 4700pFAC250V Z
! C2932 QCZ9054-472 C CAP. 4700pFAC250V Z
! C2933 QCZ9054-472 C CAP. 4700pFAC250V Z

C2934 QETM2GM-226 E CAP. 22
C2941 QTMN1CM-477Z E CAP. 470µF 16V M
C2942 QETN1AM-337Z E CAP. 330µF 10V M
C2951 QEZ0203-227 E CAP. 220
C2952 QETN1CM-108Z E CAP. 1000µF 16V M
C2954 QETM1VM-338 E CAP. 3300µF 35V M
C2955 QETM1VM-228 E CAP. 2200
C2956 QETN1AM-108Z E CAP. 1000µF 10V M
C2957 QETN1AM-228Z E CAP. 2200µF 10V M
C2959 QFV71HJ-684Z MF CAP. 0.68
C2960 QCZ0325-821 C CAP. 820pF 2kV K
C2972 QETN1AM-477Z E CAP. 470
C2973 QETN1AM-477Z E CAP. 470µF 10V M
C2974 QETN0JM-228Z E CAP. 2200
C2975 QETN1AM-228Z E CAP. 2200µF 10V M

! C2991 QCZ9079-222 C CAP. 2200pFAC250V M
! C2993 QCZ9079-471 C CAP. 470pFAC250V K

TRANSFORMER

T2501 QQR0882-001 DRIVE TRANSF.

! T2551 QQH0127-001 F.B.TRANSF.

T2561 QQR1096-001 DEF TRANSF

! T2901 QQS0176-001 SW TRANSF

COIL

L2461 QQR1195-001 CHOKE COIL
L2462 QQLZ028-272 INDUCTOR
L2521 QQLZ031-180 INDUCTOR
L2522 QQR1191-002 LINEARITY COIL
L2552 QQL26AK-220Z COIL 22
L2561 QQLZ028-272 INDUCTOR
L2901 QQL401K-100Z COIL 10
L2902 QQL401K-100Z COIL 10µH K
L2903 QQR1200-001 CHOKE COIL
L2951 QQLZ026-460 INDUCTOR
L2959 QQL26AK-220Z COIL 22
L2960 QQL26AK-220Z COIL 22
L2961 QQL26AM-4R7Z INDUCTOR

DIODE

D2402 1SR35-400A-T2 SI.DIODE
D2421 1SS133-T2 SI.DIODE
D2461 RGP10J-5025-T3 SI.DIODE
D2462 1SS133-T2 SI.DIODE
D2463 1SS133-T2 SI.DIODE
D2501 1SS81-T5 SI.DIODE
D2521 V11CA-C1 SI.DIODE
D2522 FMV-3FU-F1 SI.DIODE
D2523 MTZJ22B-T2 ZENER DIODE
D2524 1SR35-400A-T2 SI.DIODE
D2525 RGP10J-5025-T3 SI.DIODE
D2541 RGP10J-5025-T3 SI.DIODE
D2542 MTZJ3.9B-T2 ZENER DIODE
D2551 RGP10J-5025-T3 SI.DIODE
D2552 RGP10J-5025-T3 SI.DIODE
D2553 RH1S-T3 SI.DIODE
D2582 MTZJ7.5B-T2 ZENER DIODE
D2583 MTZJ7.5S-T2 ZENER DIODE

! D2584 RGP10J-5025-T3 SI.DIODE

FAC275V K

µ

FAC275V M

µ

FAC275V K

µ

FAC275V M

µ

FAC275V K

µ

F 400V M

µ

F 500V K

µ

F 50V M

µ

F 50V J

µ

F 400V M

µ

F 160V M

µ

F 35V M

µ

F 50V J

µ

F 10V M

µ

F 6.3V M

µ

H K

µ

H K

µ

H K

µ

H K

No. 52067

41

A

V-32Z25EU

Y

■■■■CRT SOCKET P.W. BOARD ASS’Y (SMF-3406A)

! Symbol No. Part No. Part Name Description

DIODE

! D2901 D3SB60 BRIDGE DIODE

D2902 RG1C-LFA1 SI.DIODE
D2904 EU2A-T2 SI.DIODE
D2905 1SS133-T2 SI.DIODE
D2906 MTZJ27B-T2 ZENER DIODE
D2907 1SS133-T2 SI.DIODE
D2908 1SS133-T2 SI.DIODE
D2910 MTZJ15B-T2 ZENER DIODE
D2911 1SS133-T2 SI.DIODE

! D2931 S1WB/A/60-4101 BRIDGE DIODE

D2945 1SS133-T2 SI.DIODE
D2951 RU4AM-LFT2 SI.DIODE
D2952 RU3YX-LFC4 SI.DIODE
D2953 RU4AM-LFT2 SI.DIODE
D2954 FMX-G12S SI.DIODE
D2955 RU3YX-LFC4 SI.DIODE
D2956 RU3YX-LFC4 SI.DIODE
D2958 MTZJ33B-T2 ZENER DIODE
D2959 RU3YX-LFC4 SI.DIODE
D2960 1SR124-400A-T2 SI.DIODE
D2961 1SS133-T2 SI.DIODE
D2981 1SS133-T2 SI.DIODE
D2984 1SS133-T2 SI.DIODE
D2985 1SS133-T2 SI.DIODE

TRANSISTOR

Q2421 DTC124ESA-T DIGI.TRANSISTOR
Q2422 2SC1740S/QR/-T SI.TRANSISTOR
Q2461 2SK2459N-F54 POWER MOS FET
Q2462 2SC1740S/QR/-T SI.TRANSISTOR
Q2463 2SC1740S/QR/-T SI.TRANSISTOR
Q2464 2SA933AS/QR/-T SI.TRANSISTOR
Q2501 BSN304-T MOS FET

! Q2521 2SC5905-RL POWER TRANSISTOR H.OUT

Q2581 2SA1208/ST/Z1-T SI.TRANSISTOR
Q2582 DTC144ESA-T DIGI.TRANSISTOR
Q2583 2SC1740S/QR/-T SI.TRANSISTOR
Q2941 2SC1740S/QR/-T SI.TRANSISTOR
Q2942 2SC1740S/QR/-T SI.TRANSISTOR

IC

IC2401 AN5523 IC
IC2461 BA10393 IC
IC2551 BA12T IC
IC2901 STR-F6667B/F7 IC

! IC2902 QAL0425-001 POWER MODULE

IC2951 SE140N IC
IC2954 BA05T IC
IC2955 NJM2396F33 IC

OTHERS

! CP2951 ICP-N75-Y I.C.PROTECT
! CP2952 ICP-N75-Y I.C.PROTECT
! CP2953 ICP-N75-Y I.C.PROTECT
! CP2954 QMFZ049-4R0Z-E FUSE 4.0A
! CP2955 ICP-N75-Y I.C.PROTECT

K2401 QQR0621-002Z FERRITE BEADS
K2522 CE41832-001 LEAD CORE
K2523 CE41832-001 LEAD CORE
K2524 CE41832-001 LEAD CORE
K2901 QQR0679-001 FERRITE BEADS

! LF2901 QQR1095-001 LINE FILTER
! PC2901 PC123FY2 IC(PHOTO COUPLE
! RY2931 QSK0099-001 RELAY
! TH2901 QAD0133-9R0 THERMISTOR

! Symbol No. Part No. Part Name Description

RESISTOR

R3101 NRSA63J-223X MG R 22kΩ 1/16W J
R3102 NRSA63J-681X MG R 680Ω 1/16W J
R3103 NRSA63J-101X MG R 100Ω 1/16W J
R3104 NRSA63J-822X MG R 8.2kΩ 1/16W J
R3105 NRSA63J-102X MG R 1k
R3106 NRSA63J-221X MG R 220
R3107 NRSA63J-561X MG R 560Ω 1/16W J
R3109 NRSA63J-153X MG R 15k
R3110 NRSA63J-222X MG R 2.2k
R3111 NRSA63J-182X MG R 1.8kΩ 1/16W J
R3112 NRSA63J-272X MG R 2.7k
R3113 NRSA63J-331X MG R 330Ω 1/16W J
R3114 NRSA63J-152X MG R 1.5k
R3115 NRSA63J-820X MG R 82
R3116 QRG01GJ-101 OM R 100Ω 1W J
R3117 NRSA63J-221X MG R 220Ω 1/16W J
R3122 NRSA63J-122X MG R 1.2k
R3123 QRE121J-563Y C R 56kΩ 1/2W J
R3124 NRSA63J-470X MG R 47Ω 1/16W J
R3125 QRE121J-563Y C R 56k
R3126 NRSA63J-470X MG R 47
R3127 NRSA63J-122X MG R 1.2k
R3128 NRSA63J-390X MG R 39
R3129 QRE121J-2R7Y C R 2.7Ω 1/2W J
R3130 QRE121J-2R7Y C R 2.7Ω 1/2W J
R3131 NRSA63J-390X MG R 39
R3132 NRSA63J-121X MG R 120Ω 1/16W J
R3133 QRL029J-391 OM R 390Ω 2W J

! R3134 QRZ9021-561 F R 560

R3204 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3205 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3206 NRSA63J-272X MG R 2.7k
R3211 NRSA63J-154X MG R 150kΩ 1/16W J
R3223 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3224 NRSA63J-272X MG R 2.7k
R3225 NRSA63J-272X MG R 2.7k
R3227 NRSA63J-103X MG R 10kΩ 1/16W J
R3228 NRSA63J-272X MG R 2.7k
R3229 QRL029J-104-F OM R 100kΩ 2W J
R3230 QRL029J-104-F OM R 100kΩ 2W J
R3231 QRL029J-104-F OM R 100k
R3232 NRSA63J-332X MG R 3.3kΩ 1/16W J
R3233 NRSA63J-332X MG R 3.3kΩ 1/16W J
R3234 NRSA63J-332X MG R 3.3k
R3235 QRC121K-152Z COMP.R 1.5kΩ 1/2W K
R3236 QRC121K-152Z COMP.R 1.5kΩ 1/2W K
R3237 QRC121K-152Z COMP.R 1.5k
R3239 QRZ0107-474Z C R 470kΩ 1/2W K
R3240 QRC121K-102Z COMP.R 1kΩ 1/2W K
R3241 QRZ0107-105Z C R 1.0M
R3242 NRSA63J-103X MG R 10kΩ 1/16W J
R3244 NRSA63J-102X MG R 1kΩ 1/16W J
R3245 NRSA63J-562X MG R 5.6k
R3246 NRSA63J-562X MG R 5.6kΩ 1/16W J
R3247 NRSA63J-562X MG R 5.6kΩ 1/16W J
R3301 QRE121J-474Y C R 470k
R3302 QRE121J-474Y C R 470kΩ 1/2W J
R3303 NRSA63J-223X MG R 22kΩ 1/16W J
R3304 NRSA63J-223X MG R 22k
R3305 NRSA63J-562X MG R 5.6kΩ 1/16W J
R3306 NRSA63J-392X MG R 3.9kΩ 1/16W J
R3310 NRSA63J-0R0X MG R 0.0

CAPACITOR

C3102 NDC31HJ-8R0X C CAP. 8.0pF 50V J
C3103 NDC31HJ-151X C CAP. 150pF 50V J
C3104 QCB31HK-103Z C CAP. 0.01
C3106 QETN1HM-335Z E CAP. 3.3µF 50V M
C3107 QETN1CM-107Z E CAP. 100
C3110 QETN2CM-106Z E CAP. 10µF 160V M
C3111 QCB32HK-472Z C CAP. 4700pF 500V K
C3113 QETN2CM-106Z E CAP. 10
C3114 QCB32HK-472Z C CAP. 4700pF 500V K
C3116 QETN1AM-107Z E CAP. 100
C3117 QETN1AM-107Z E CAP. 100µF 10V M
C3118 QETN1AM-337Z E CAP. 330µF 10V M
C3120 NDC31HJ-221X C CAP. 220pF 50V J
C3121 NDC31HJ-221X C CAP. 220pF 50V J
C3201 NDC31HJ-8R0X C CAP. 8.0pF 50V J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

2W J

Ω

1/16W J

Ω

1/2W K

Ω

1/2W K

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

µ

F 50V K

µ

F 16V M

µ

F 160V M

µ

F 10V M

42

No. 52067

A

Y

! Symbol No. Part No. Part Name Description

CAPACITOR

C3202 NDC31HJ-8R0X C CAP. 8.0pF 50V J
C3203 NDC31HJ-8R0X C CAP. 8.0pF 50V J
C3204 NCF31CZ-104X C CAP. 0.1
C3205 NCF31CZ-104X C CAP. 0.1
C3206 NCF31CZ-104X C CAP. 0.1µF 16V Z
C3207 QETN1EM-476Z E CAP. 47
C3208 QETN1EM-476Z E CAP. 47µF 25V M
C3209 QETN1EM-476Z E CAP. 47µF 25V M
C3210 QFK62EK-104Z MM CAP. 0.1µF 250V K
C3211 QFK62EK-104Z MM CAP. 0.1
C3212 QFK62EK-104Z MM CAP. 0.1
C3213 NDC31HJ-181X C CAP. 180pF 50V J
C3214 NDC31HJ-181X C CAP. 180pF 50V J
C3215 NDC31HJ-181X C CAP. 180pF 50V J
C3216 QETN1CM-107Z E CAP. 100
C3218 QETM2EM-336 E CAP. 33
C3219 QFZ0097-223 MM CAP. 0.022
C3221 QETN2EM-106Z E CAP. 10
C3302 QETN1HM-106Z E CAP. 10

COIL

L3101 QQL244K-5R6Z COIL 5.6µH K
L3201 IM-BW BUS WIRE
L3202 IM-BW BUS WIRE
L3203 IM-BW BUS WIRE
L3204 QQL26AJ-102Z COIL 1mH J

DIODE

D3101 MA111-X SI.DIODE
D3102 MA111-X SI.DIODE
D3103 RH1S-T3 SI.DIODE
D3104 RH1S-T3 SI.DIODE
D3204 EU01N-T2 SI.DIODE
D3205 EU01N-T2 SI.DIODE
D3206 EU01N-T2 SI.DIODE
D3207 RM2C-LFA1 SI.DIODE
D3208 1SR124-400A-T2 SI.DIODE
D3209 1SR124-400A-T2 SI.DIODE
D3210 1SR124-400A-T2 SI.DIODE
D3211 MA3062/M/-X ZENER DIODE
D3212 MA3130/H/-X ZENER DIODE
D3213 MA3130/H/-X ZENER DIODE
D3301 MA111-X SI.DIODE
D3303 MA111-X SI.DIODE

TRANSISTOR

Q3101 2SC2412K/QR/-X SI.TRANSISTOR
Q3102 2SA1037AK/QR/-X SI.TRANSISTOR
Q3103 2SC1906-T SI.TRANSISTOR
Q3104 2SC2412K/QR/-X SI.TRANSISTOR
Q3105 2SC1627A/OY/-T SI.TRANSISTOR
Q3108 2SA1837 POWER TRANSISTO
Q3109 2SC4793 POWER TRANSISTO
Q3301 2SA1037AK/QR/-X SI.TRANSISTOR

IC

IC3201 TDA6111Q I C
IC3202 TDA6111Q I C
IC3203 TDA6111Q I C

OTHERS

CN3013 CHGY0146-0A-G CONNECTOR ASSY
CN3014 QJK002-063631 SIN CR C-B WIRE
K3101 CE41492-001Z CHOKE COIL
K3103 CE41492-001Z CHOKE COIL
K3104 CE41492-001Z CHOKE COIL
K3105 QQR0621-002Z FERRITE BEADS
SG3201 QAF0056-501Z SURGE ABSORBER
SG3202 QAF0056-501Z SURGE ABSORBER
SG3203 QAF0056-501Z SURGE ABSORBER

! SK3001 QNZ0380-001 CRT SOCKET

W3003 QQR0679-001 FERRITE BEADS
W3022 QQR0679-001 FERRITE BEADS

µ

F 16V Z

µ

F 16V Z

µ

F 25V M

µ

F 250V K

µ

F 250V K

µ

F 16V M

µ

F 250V M

µ

F 1250V K

µ

F 250V M

µ

F 50V M

V-32Z25EU

■■■■FRONT CONTROL P.W. BOARD ASS’Y

(SMF-8405A)

! Symbol No. Part No. Part Name Description

RESISTOR

R8005 NRSA63J-221X MG R 220Ω 1/16W J
R8008 NRSA63J-102X MG R 1kΩ 1/16W J
R8039 NRSA63J-331X MG R 330Ω 1/16W J

CAPACITOR

C8004 NCB31CK-104X C CAP. 0.1µF 16V K
C8022 QETN1EM-476Z E CAP. 47

! C8901 QFZ9072-474 MM CAP. 0.47
! OR QFZ9075-474 MPP CAP. 0.47

DIODE

D8010 SPR-39MVWF LED
D8011 MA111-X SI.DIODE
D8014 MA3068/M/-X ZENER DIODE

TRANSISTOR

Q8002 DTC124EKA-X DIGI.TRANSISTOR
Q8003 DTA124EKA-X DIGI.TRANSISTOR
Q8004 DTA124EKA-X DIGI.TRANSISTOR

IC

IC8001 GP1U281Q IR DETECT UNIT

OTHERS

LC30349-001A-H LED HOLDER

CN8102 QGF1220C2-25 FFC/FPC CONNE

! F8901 QMF51D2-3R15J1 FUSE 3.15A
! LF8901 QQR1095-001 LINE FILTER
! S8901 QSW0824-001 PUSH SWITCH MAIN POWER

CEMG002-001Z FUSE CLIP x2

µ

F 25V M

µ

FAC275V M

µ

FAC275V M

■ SIDE CONTROL P.W. BOARD ASS’Y

(SMF-8106A)

! Symbol No. Part No. Part Name Description

RESISTOR

R8001 QRE121J-271Y C R 270Ω 1/2W J
R8002 QRE121J-271Y C R 270
R8007 NRSA63J-103X MG R 10kΩ 1/16W J
R8010 NRSA63J-103X MG R 10kΩ 1/16W J
R8012 NRSA63J-103X MG R 10k
R8013 NRSA63J-103X MG R 10kΩ 1/16W J
R8021 NRSA63J-102X MG R 1kΩ 1/16W J
R8022 NRSA63J-102X MG R 1k

CAPACITOR

C8001 NCB31HK-103X C CAP. 0.01µF 50V K
C8002 NCB31HK-103X C CAP. 0.01µF 50V K
C8003 NDC31HJ-680X C CAP. 68pF 50V J
C8010 NCB31HK-472X C CAP. 4700pF 50V K
C8011 NCB31HK-472X C CAP. 4700pF 50V K
C8021 NCB31CK-104X C CAP. 0.1

COIL

L8001 QQR0716-001Z FERRITE BEADS
L8002 QQL244K-5R6Z COIL 5.6µH K
L8003 QQL244K-5R6Z COIL 5.6µH K
L8010 QQL244K-270Z COIL 27
L8011 QQL244K-270Z COIL 27µH K
L8012 QQR0716-001Z FERRITE BEADS

OTHERS

J8001 QMS3001-C01 3.5 JACK
J8003 QNZ0438-001 AV JACK
LC8002 NQR0169-001X EMI FILTER
S8001 QSW0619-003Z TACT SWITCH MENU
S8002 QSW0619-003Z TACT SWITCH CH DOWN
S8003 QSW0619-003Z TACT SWITCH CH UP

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

µ

F 16V K

µ

H K

No. 52067

43

A

V-32Z25EU

Y

■■■■DOLBY P.W. BOARD ASS’Y (SMF-0D401A)

! Symbol No. Part No. Part Name Description

RESISTOR

R0101 NRSA63J-750X MG R 75Ω 1/16W J
R0102 NRSA63J-221X MG R 220Ω 1/16W J
R0105 NRSA63J-101X MG R 100
R0106 NRSA63J-225X MG R 2.2MΩ 1/16W J
R0107 NRSA63J-472X MG R 4.7k
R0108 NRSA63J-103X MG R 10k
R0109 NRSA63J-102X MG R 1kΩ 1/16W J
R0110 NRSA63J-101X MG R 100Ω 1/16W J
R0111 NRSA63J-102X MG R 1k
R0112 NRSA63J-563X MG R 56k
R0113 NRSA63J-103X MG R 10k
R0114 NRSA63J-472X MG R 4.7k
R0115 NRSA63J-103X MG R 10kΩ 1/16W J
R0116 NRSA63J-101X MG R 100Ω 1/16W J
R0117 NRSA63J-101X MG R 100
R0118 NRSA63J-101X MG R 100
R0122 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0123 NRSA63J-682X MG R 6.8k
R0124 NRSA63J-332X MG R 3.3kΩ 1/16W J
R0125 NRSA63J-473X MG R 47kΩ 1/16W J
R0126 NRSA63J-473X MG R 47k
R0127 NRSA63J-221X MG R 220Ω 1/16W J
R0128 NRSA63J-221X MG R 220Ω 1/16W J
R0129 NRSA63J-221X MG R 220
R0130 NRSA63J-221X MG R 220Ω 1/16W J
R0131 NRSA63J-221X MG R 220Ω 1/16W J
R0132 NRSA63J-221X MG R 220
R0133 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0134 NRSA63J-473X MG R 47kΩ 1/16W J
R0135 NRSA63J-473X MG R 47k
R0136 NRSA63J-473X MG R 47kΩ 1/16W J
R0137 NRSA63J-221X MG R 220Ω 1/16W J
R0138 NRSA63J-221X MG R 220
R0139 NRSA63J-221X MG R 220Ω 1/16W J
R0140 NRSA63J-221X MG R 220Ω 1/16W J
R0141 NRSA63J-103X MG R 10k
R0144 NRSA63J-473X MG R 47kΩ 1/16W J
R0145 NRSA63J-103X MG R 10kΩ 1/16W J
R0148 NRSA63J-332X MG R 3.3k
R0149 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0150 NRSA63J-103X MG R 10kΩ 1/16W J
R0155 NRSA63J-101X MG R 100
R0160 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0161 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0162 NRSA63J-183X MG R 18k
R0163 NRSA63J-103X MG R 10kΩ 1/16W J
R0164 NRSA63J-103X MG R 10kΩ 1/16W J
R0165 NRSA63J-103X MG R 10k
R0201 NRSA63J-104X MG R 100kΩ 1/16W J
R0202 NRSA63J-104X MG R 100kΩ 1/16W J
R0203 NRSA63J-273X MG R 27k
R0204 NRSA63J-273X MG R 27kΩ 1/16W J
R0205 NRSA63J-682X MG R 6.8kΩ 1/16W J
R0206 NRSA63J-682X MG R 6.8k
R0207 NRSA63J-102X MG R 1kΩ 1/16W J
R0208 NRSA63J-102X MG R 1kΩ 1/16W J
R0209 NRSA63J-102X MG R 1k
R0210 NRSA63J-102X MG R 1kΩ 1/16W J
R0211 NRSA63J-102X MG R 1kΩ 1/16W J
R0212 NRSA63J-102X MG R 1k
R0213 NRSA63J-102X MG R 1kΩ 1/16W J
R0215 NRSA63J-103X MG R 10kΩ 1/16W J
R0216 NRSA63J-103X MG R 10k
R0217 NRSA63J-103X MG R 10kΩ 1/16W J
R0218 NRSA63J-103X MG R 10kΩ 1/16W J
R0219 NRSA63J-102X MG R 1k
R0220 NRSA63J-102X MG R 1kΩ 1/16W J
R0223 NRSA63J-102X MG R 1kΩ 1/16W J
R0301 NRSA63J-222X MG R 2.2k
R0302 NRSA63J-103X MG R 10kΩ 1/16W J
R0303 NRSA63J-223X MG R 22kΩ 1/16W J
R0304 NRSA63J-222X MG R 2.2k
R0305 NRSA63J-223X MG R 22kΩ 1/16W J
R0306 NRSA63J-103X MG R 10kΩ 1/16W J
R0307 NRSA63J-103X MG R 10k
R0308 NRSA63J-104X MG R 100kΩ 1/16W J
R0309 NRSA63J-104X MG R 100kΩ 1/16W J
R0310 NRSA63J-103X MG R 10k
R0311 NRSA63J-222X MG R 2.2kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

! Symbol No. Part No. Part Name Description

RESISTOR

R0312 NRSA63J-223X MG R 22kΩ 1/16W J
R0313 NRSA63J-103X MG R 10k
R0314 NRSA63J-104X MG R 100k
R0315 NRSA63J-103X MG R 10k
R0316 NRSA63J-104X MG R 100k
R0317 NRSA63J-103X MG R 10kΩ 1/16W J
R0318 NRSA63J-223X MG R 22k
R0319 NRSA63J-222X MG R 2.2k
R0320 NRSA63J-223X MG R 22kΩ 1/16W J
R0321 NRSA63J-103X MG R 10kΩ 1/16W J
R0322 NRSA63J-103X MG R 10k
R0323 NRSA63J-222X MG R 2.2k
R0324 NRSA63J-104X MG R 100k
R0325 NRSA63J-104X MG R 100k
R0326 NRSA63J-123X MG R 12kΩ 1/16W J
R0327 NRSA63J-273X MG R 27kΩ 1/16W J
R0328 NRSA63J-822X MG R 8.2k
R0329 NRSA63J-103X MG R 10k
R0330 NRSA63J-104X MG R 100kΩ 1/16W J
R0401 NRSA63J-0R0X MG R 0.0
R0402 NRSA63J-104X MG R 100kΩ 1/16W J
R0403 NRSA63J-223X MG R 22kΩ 1/16W J
R0405 NRSA63J-103X MG R 10k
R0406 NRSA63J-103X MG R 10kΩ 1/16W J
R0407 NRSA63J-104X MG R 100kΩ 1/16W J
R0408 NRSA63J-223X MG R 22k
R0409 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0410 NRSA63J-103X MG R 10kΩ 1/16W J
R0411 NRSA63J-273X MG R 27k
R0412 NRSA63J-103X MG R 10kΩ 1/16W J
R0413 NRSA63J-104X MG R 100kΩ 1/16W J
R0414 NRSA63J-103X MG R 10k
R0415 NRSA63J-103X MG R 10kΩ 1/16W J
R0416 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0417 NRSA63J-104X MG R 100k
R0418 NRSA63J-0R0X MG R 0.0
R0419 NRSA63J-563X MG R 56kΩ 1/16W J
R0420 NRSA63J-563X MG R 56k
R0421 NRSA63J-563X MG R 56kΩ 1/16W J
R0422 NRSA63J-563X MG R 56kΩ 1/16W J
R0423 NRSA63J-563X MG R 56k
R0424 NRSA63J-563X MG R 56kΩ 1/16W J
R0425 NRSA63J-563X MG R 56kΩ 1/16W J
R0426 NRSA63J-273X MG R 27k
R0427 NRSA63J-273X MG R 27kΩ 1/16W J
R0428 NRSA63J-563X MG R 56kΩ 1/16W J
R0429 NRSA63J-104X MG R 100k
R0430 NRSA63J-104X MG R 100kΩ 1/16W J
R0431 NRSA63J-104X MG R 100kΩ 1/16W J
R0432 NRSA63J-104X MG R 100k
R0433 NRSA63J-104X MG R 100kΩ 1/16W J
R0434 NRSA63J-104X MG R 100kΩ 1/16W J
R0435 NRSA63J-104X MG R 100k
R0436 NRSA63J-104X MG R 100kΩ 1/16W J
R0501 NRSA63J-103X MG R 10kΩ 1/16W J
R0502 NRSA63J-332X MG R 3.3k
R0601 NRSA63J-394X MG R 390kΩ 1/16W J
R0602 NRSA63J-471X MG R 470Ω 1/16W J
R0603 NRSA63J-394X MG R 390k
R0604 NRSA63J-471X MG R 470Ω 1/16W J
R0605 NRSA63J-562X MG R 5.6kΩ 1/16W J
R0606 NRSA63J-562X MG R 5.6k
R0631 NRSA63J-562X MG R 5.6kΩ 1/16W J
R0632 NRSA63J-394X MG R 390kΩ 1/16W J
R0633 NRSA63J-471X MG R 470
R0634 NRSA63J-471X MG R 470Ω 1/16W J
R0651 NRSA63J-394X MG R 390kΩ 1/16W J
R0652 NRSA63J-471X MG R 470
R0653 NRSA63J-394X MG R 390kΩ 1/16W J
R0654 NRSA63J-471X MG R 470Ω 1/16W J
R0655 NRSA63J-562X MG R 5.6k
R0656 NRSA63J-562X MG R 5.6kΩ 1/16W J
R0657 NRSA63J-103X MG R 10kΩ 1/16W J
R0658 NRSA63J-103X MG R 10k
R0701 NRSA63J-103X MG R 10kΩ 1/16W J
R0702 NRSA63J-103X MG R 10kΩ 1/16W J
R0703 NRSA63J-103X MG R 10k
R0704 NRSA63J-153X MG R 15kΩ 1/16W J
R0705 NRSA63J-103X MG R 10kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

44

No. 52067

A

V-32Z25EU

Y

! Symbol No. Part No. Part Name Description

RESISTOR

R0706 NRSA63J-104X MG R 100kΩ 1/16W J
R0707 NRSA63J-153X MG R 15k
R0708 NRSA63J-103X MG R 10k
R0709 NRSA63J-104X MG R 100k
R0710 NRSA63J-681X MG R 680
R0711 NRSA63J-681X MG R 680Ω 1/16W J
R0712 NRSA63J-103X MG R 10k
R0713 NRSA63J-103X MG R 10k
R0714 NRSA63J-681X MG R 680Ω 1/16W J
R0715 NRSA63J-104X MG R 100kΩ 1/16W J
R0716 NRSA63J-153X MG R 15k
R0717 NRSA63J-104X MG R 100k
R0718 NRSA63J-103X MG R 10k
R0719 NRSA63J-103X MG R 10k
R0720 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0721 NRSA63J-104X MG R 100kΩ 1/16W J
R0723 NRSA63J-0R0X MG R 0.0
R0724 NRSA63J-103X MG R 10k
R0726 NRSA63J-104X MG R 100kΩ 1/16W J
R0727 NRSA63J-104X MG R 100k
R0728 NRSA63J-104X MG R 100kΩ 1/16W J
R0729 NRSA63J-104X MG R 100kΩ 1/16W J
R0730 NRSA63J-103X MG R 10k
R0731 NRSA63J-104X MG R 100kΩ 1/16W J
R0732 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0733 NRSA63J-223X MG R 22k
R0734 NRSA63J-223X MG R 22kΩ 1/16W J
R0735 NRSA63J-103X MG R 10kΩ 1/16W J
R0736 NRSA63J-104X MG R 100k
R0737 NRSA63J-223X MG R 22kΩ 1/16W J
R0739 NRSA63J-103X MG R 10kΩ 1/16W J
R0740 NRSA63J-104X MG R 100k
R0741 NRSA63J-104X MG R 100kΩ 1/16W J
R0742 NRSA63J-104X MG R 100kΩ 1/16W J
R0743 NRSA63J-472X MG R 4.7k
R0744 NRSA63J-223X MG R 22k
R0745 NRSA63J-223X MG R 22kΩ 1/16W J
R0746 NRSA63J-223X MG R 22k
R0747 NRSA63J-472X MG R 4.7kΩ 1/16W J

CAPACITOR

C0101 NDC31HJ-101X C CAP. 100pF 50V J
C0102 NEH71HM-105X E CAP. 1µF 50V M
C0103 NCB31HK-103X C CAP. 0.01
C0104 NCB31HK-104X C CAP. 0.1µF 50V K
C0105 NEH71CM-476X E CAP. 47µF 16V M
C0106 NCB31HK-103X C CAP. 0.01
C0107 NEH70JM-107X E CAP. 100µF 6.3V M
C0108 NCB31HK-103X C CAP. 0.01µF 50V K
C0109 NCB31HK-103X C CAP. 0.01
C0110 NCB31HK-104X C CAP. 0.1µF 50V K
C0111 NCB31HK-104X C CAP. 0.1µF 50V K
C0112 NCB31CK-104X C CAP. 0.1
C0113 NDC31HJ-121X C CAP. 120pF 50V J
C0114 NDC31HJ-101X C CAP. 100pF 50V J
C0115 NCB31HK-103X C CAP. 0.01
C0116 NCB31AK-474X C CAP. 0.47µF 10V K
C0117 NCB31HK-103X C CAP. 0.01
C0118 NEH70JM-107X E CAP. 100µF 6.3V M
C0119 NEH71CM-476X E CAP. 47µF 16V M
C0120 NCB31HK-104X C CAP. 0.1
C0121 NEH71CM-476X E CAP. 47µF 16V M
C0122 NCB31HK-104X C CAP. 0.1µF 50V K
C0123 NCB31HK-102X C CAP. 1000pF 50V K
C0124 NCB31HK-102X C CAP. 1000pF 50V K
C0125 NEH71CM-476X E CAP. 47
C0126 NCB31HK-104X C CAP. 0.1µF 50V K
C0129 NCB31HK-103X C CAP. 0.01µF 50V K
C0130 NDC31HJ-101X C CAP. 100pF 50V J
C0131 NCB31HK-103X C CAP. 0.01
C0132 NEH70JM-107X E CAP. 100µF 6.3V M
C0133 NCB31HK-103X C CAP. 0.01µF 50V K
C0134 NEH70JM-107X E CAP. 100
C0137 NEH70JM-107X E CAP. 100µF 6.3V M
C0138 NCB31HK-104X C CAP. 0.1µF 50V K
C0139 NCB31HK-104X C CAP. 0.1
C0140 NDC31HJ-180X C CAP. 18pF 50V J
C0141 NDC31HJ-220X C CAP. 22pF 50V J
C0142 NCB31CK-104X C CAP. 0.1

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 16V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 16V M

µ

F 50V K

µ

F 6.3V M

µ

F 50V K

µ

F 16V K

! Symbol No. Part No. Part Name Description

CAPACITOR

C0143 NCB31CK-104X C CAP. 0.1µF 16V K
C0145 NDC31HJ-101X C CAP. 100pF 50V J
C0146 NCB31CK-104X C CAP. 0.1
C0149 NCB31HK-104X C CAP. 0.1µF 50V K
C0150 NDC31HJ-470X C CAP. 47pF 50V J
C0201 NEH71EM-475X E CAP. 4.7
C0202 NEH71EM-475X E CAP. 4.7µF 25V M
C0203 NDC31HJ-560X C CAP. 56pF 50V J
C0204 NCB31HK-104X C CAP. 0.1
C0207 NDC31HJ-560X C CAP. 56pF 50V J
C0208 NCB31HK-183X C CAP. 0.018
C0209 NCB31HK-183X C CAP. 0.018
C0210 NCB31HK-182X C CAP. 1800pF 50V K
C0211 NCB31HK-104X C CAP. 0.1
C0213 NCB31AK-474X C CAP. 0.47µF 10V K
C0214 NCB31HK-182X C CAP. 1800pF 50V K
C0215 NCB31HK-562X C CAP. 5600pF 50V K
C0216 NCB31HK-562X C CAP. 5600pF 50V K
C0218 NDC31HJ-560X C CAP. 56pF 50V J
C0219 NCB31HK-104X C CAP. 0.1
C0220 NCB31HK-562X C CAP. 5600pF 50V K
C0221 NCB31HK-562X C CAP. 5600pF 50V K
C0223 NDC31HJ-560X C CAP. 56pF 50V J
C0224 NEH71CM-476X E CAP. 47
C0225 NEH71CM-476X E CAP. 47µF 16V M
C0226 NCB31HK-103X C CAP. 0.01
C0301 NCF31AZ-105X C CAP. 1µF 10V Z
C0302 NCB31HK-104X C CAP. 0.1µF 50V K
C0303 NCB31HK-222X C CAP. 2200pF 50V K
C0304 NDC31HJ-560X C CAP. 56pF 50V J
C0305 NCF31AZ-105X C CAP. 1
C0307 NDC31HJ-560X C CAP. 56pF 50V J
C0308 NCB31HK-222X C CAP. 2200pF 50V K
C0309 NDC31HJ-220X C CAP. 22pF 50V J
C0310 NCB31HK-104X C CAP. 0.1
C0311 NCB31HK-222X C CAP. 2200pF 50V K
C0312 NCB31HK-222X C CAP. 2200pF 50V K
C0313 NDC31HJ-220X C CAP. 22pF 50V J
C0314 NCF31AZ-105X C CAP. 1
C0315 NCF31AZ-105X C CAP. 1
C0316 NDC31HJ-220X C CAP. 22pF 50V J
C0317 NCF31AZ-105X C CAP. 1
C0318 NCF31AZ-105X C CAP. 1µF 10V Z
C0319 NDC31HJ-220X C CAP. 22pF 50V J
C0320 NCB31CK-104X C CAP. 0.1
C0321 NCB31HK-222X C CAP. 2200pF 50V K
C0401 NEH71HM-106X E CAP. 10
C0402 NEH71HM-106X E CAP. 10µF 50V M
C0403 NCB31HK-103X C CAP. 0.01
C0405 NCF31AZ-105X C CAP. 1µF 10V Z
C0406 NDC31HJ-560X C CAP. 56pF 50V J
C0407 NDC31HJ-560X C CAP. 56pF 50V J
C0408 NCF31AZ-105X C CAP. 1
C0409 NDC31HJ-560X C CAP. 56pF 50V J
C0410 NCF31AZ-105X C CAP. 1
C0411 NCF31AZ-105X C CAP. 1µF 10V Z
C0412 NDC31HJ-560X C CAP. 56pF 50V J
C0413 NDC31HJ-560X C CAP. 56pF 50V J
C0414 NCF31AZ-105X C CAP. 1
C0415 NCF31AZ-105X C CAP. 1
C0416 NCF31AZ-105X C CAP. 1µF 10V Z
C0417 NEH71CM-476X E CAP. 47µF 16V M
C0440 NCB31HK-104X C CAP. 0.1
C0441 NCB31HK-104X C CAP. 0.1µF 50V K
C0442 NCB31HK-104X C CAP. 0.1µF 50V K
C0443 NCB31HK-104X C CAP. 0.1
C0551 NCB31HK-103X C CAP. 0.01µF 50V K
C0552 NCB31CK-104X C CAP. 0.1µF 16V K
C0553 NEH70JM-107X E CAP. 100
C0558 NEH70JM-107X E CAP. 100µF 6.3V M
C0559 NCB31HK-103X C CAP. 0.01µF 50V K
C0601 NEH71CM-476X E CAP. 47
C0602 NCB31CK-104X C CAP. 0.1µF 16V K
C0603 NCB31CK-104X C CAP. 0.1µF 16V K
C0604 NCB31CK-104X C CAP. 0.1
C0605 NCB31CK-104X C CAP. 0.1µF 16V K
C0606 NCB31HK-222X C CAP. 2200pF 50V K
C0607 NCB31HK-222X C CAP. 2200pF 50V K
C0608 NCF31AZ-105X C CAP. 1
C0612 NEH71EM-226X E CAP. 22
C0613 NCF31AZ-105X C CAP. 1µF 10V Z
C0631 NEH71CM-476X E CAP. 47µF 16V M

µ

F 16V K

µ

F 25V M

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 16V M

µ

F 50V K

µ

F 10V Z

µ

F 50V K

µ

F 10V Z

µ

F 10V Z

µ

F 10V Z

µ

F 16V K

µ

F 50V M

µ

F 50V K

µ

F 10V Z

µ

F 10V Z

µ

F 10V Z

µ

F 10V Z

µ

F 50V K

µ

F 50V K

µ

F 6.3V M

µ

F 16V M

µ

F 16V K

µ

F 10V Z

µ

F 25V M

No. 52067

45

A

V-32Z25EU

Y

! Symbol No. Part No. Part Name Description

CAPACITOR

C0632 NEH71EM-226X E CAP. 22µF 25V M
C0633 NCF31AZ-105X C CAP. 1
C0634 NCF31AZ-105X C CAP. 1
C0635 NCB31CK-104X C CAP. 0.1
C0636 NCB31CK-104X C CAP. 0.1
C0637 NCB31HK-222X C CAP. 2200pF 50V K
C0638 NCB31HK-222X C CAP. 2200pF 50V K
C0651 NEH71CM-476X E CAP. 47
C0652 NEH71EM-226X E CAP. 22µF 25V M
C0653 NCF31AZ-105X C CAP. 1
C0654 NCF31AZ-105X C CAP. 1
C0655 NCB31HK-222X C CAP. 2200pF 50V K
C0656 NCB31HK-222X C CAP. 2200pF 50V K
C0657 NCB31CK-104X C CAP. 0.1
C0658 NCB31CK-104X C CAP. 0.1
C0659 NCB31CK-104X C CAP. 0.1
C0660 NCB31CK-104X C CAP. 0.1µF 16V K
C0701 NCF31AZ-105X C CAP. 1
C0702 NCF31AZ-105X C CAP. 1
C0703 NEH71HM-106X E CAP. 10
C0704 NDC31HJ-100X C CAP. 10pF 50V J
C0705 NDC31HJ-100X C CAP. 10pF 50V J
C0706 NEH71HM-106X E CAP. 10
C0707 NEH71HM-106X E CAP. 10
C0708 NCB31HK-222X C CAP. 2200pF 50V K
C0709 NCB31HK-222X C CAP. 2200pF 50V K
C0710 NEH71HM-106X E CAP. 10
C0711 NCB31HK-222X C CAP. 2200pF 50V K
C0712 NEH71HM-106X E CAP. 10
C0713 NEH71HM-106X E CAP. 10µF 50V M
C0714 NEH71HM-106X E CAP. 10µF 50V M
C0715 NDC31HJ-470X C CAP. 47pF 50V J
C0716 NCF31AZ-105X C CAP. 1
C0717 NCB31HK-103X C CAP. 0.01µF 50V K
C0718 NCF31AZ-105X C CAP. 1µF 10V Z
C0719 NDC31HJ-470X C CAP. 47pF 50V J
C0720 NEH71HM-106X E CAP. 10
C0723 NCB31HK-222X C CAP. 2200pF 50V K
C0724 NCB31HK-222X C CAP. 2200pF 50V K
C0729 NEH71HM-106X E CAP. 10
C0730 NEH71HM-106X E CAP. 10µF 50V M
C0731 NCB31HK-104X C CAP. 0.1
C0732 NCB31HK-104X C CAP. 0.1µF 50V K

COIL

L0101 NQL085J-4R7X COIL 4.7µH
L0551 NQL085J-4R7X COIL 4.7
L0552 NQL034K-4R7X COIL 4.7µH
L0701 NQL085J-100X INDUCTOR
L0702 NQL085J-100X INDUCTOR
L0703 NQL085J-100X INDUCTOR

DIODE

D0101 MA111-X SI.DIODE
D0102 MA111-X SI.DIODE
D0103 MA111-X SI.DIODE
D0104 MA111-X SI.DIODE
D0201 MA3120/M/-X ZENER DIODE
D0301 MA3120/M/-X ZENER DIODE
D0401 MA3120/M/-X ZENER DIODE
D0701 MA3150/M/-X ZENER DIODE
D0702 MA3150/M/-X ZENER DIODE
D0703 MA111-X SI.DIODE
D0704 MA111-X SI.DIODE
D0705 MA111-X SI.DIODE
D0706 MA111-X SI.DIODE

TRANSISTOR

Q0101 DTC124EKA-X DIGI.TRANSISTOR
Q0102 DTC124EKA-X DIGI.TRANSISTOR
Q0103 DTC124EKA-X DIGI.TRANSISTOR
Q0201 2SK433/D/-W JUNCTION FET
Q0301 2SK433/D/-W JUNCTION FET
Q0401 DTC124EKA-X DIGI.TRANSISTOR
Q0402 DTC124EKA-X DIGI.TRANSISTOR
Q0403 2SK433/D/-W JUNCTION FET
Q0501 DTC124EKA-X DIGI.TRANSISTOR
Q0502 DTC124EKA-X DIGI.TRANSISTOR
Q0701 DTC124EKA-X DIGI.TRANSISTOR
Q0702 DTC323TK-X DIGI.TRANSISTOR

µ

F 10V Z

µ

F 10V Z

µ

F 16V K

µ

F 16V K

µ

F 16V M

µ

F 10V Z

µ

F 10V Z

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 10V Z

µ

F 10V Z

µ

F 50V M

µ

F 50V M

µ

F 50V M

µ

F 50V M

µ

F 50V M

µ

F 10V Z

µ

F 50V M

µ

F 50V M

µ

F 50V K

µ

H

! Symbol No. Part No. Part Name Description

TRANSISTOR

Q0703 DTC323TK-X DIGI.TRANSISTOR
Q0704 DTC323TK-X DIGI.TRANSISTOR
Q0705 2SA1037AK/QR/-X SI.TRANSISTOR
Q0706 2SA1037AK/QR/-X SI.TRANSISTOR
Q0707 DTC323TK-X DIGI.TRANSISTOR
Q0708 DTC323TK-X DIGI.TRANSISTOR
Q0709 2SA1037AK/QR/-X SI.TRANSISTOR
Q0710 DTC323TK-X DIGI.TRANSISTOR

IC

IC0101 TC9446F-014 IC
IC0102 TC4066BF/N/-XE IC
IC0105 AK4527BVQ IC
IC0107 TA48M033F-X IC
IC0108 TC7SET32F-X IC(DIGITAL)
IC0109 UPD78F4216AGC I C
IC0110 S-80828CNNB-W IC
IC0111 TA48M033F-X IC
IC0112 IS63LV1024-15T IC
IC0113 TC7WHU04FU-X IC
IC0201 BA4558F-X IC
IC0202 BA4558F-X IC
IC0203 BA4558F-X IC
IC0301 BA4558F-X IC
IC0302 BA4558F-X IC
IC0303 BA4558F-X IC
IC0401 TC4066BF/N/-XE IC
IC0402 BA4558F-X IC
IC0403 BA4558F-X IC
IC0404 BA4558F-X IC
IC0601 BD3869F-X IC
IC0631 BD3869F-X IC
IC0651 BD3869F-X IC
IC0701 TC4066BF/N/-XE IC
IC0702 TC4066BF/N/-XE IC
IC0703 BA4558F-X IC
IC0704 BA4558F-X IC

OTHERS

J0001 QNN0281-004 PIN JACK
J0002 QNZ0523-001 OPT CONNECTOR
J0003 QNN0427-001 PIN JACK
J0004 QNB0006-002 PUSH TERMINAL
LC0101 NQR0313-009X EMI FILTER
LC0102 NQR0313-009X EMI FILTER
LC0103 NQR0313-009X EMI FILTER
LC0105 NQR0313-009X EMI FILTER
LC0106 NQR0313-009X EMI FILTER
LC0107 NQR0313-009X EMI FILTER
LC0108 NQR0313-009X EMI FILTER
LC0109 NQR0313-009X EMI FILTER
LC0111 NQR0313-009X EMI FILTER
X0101 NAX0385-001X CRYSTAL
X0102 NAX0473-001X C RESONATOR

46

No. 52067

A

Y

■■■■MICOM P.W. BOARD ASS’Y (SMF-0M403A)

V-32Z25EU

! Symbol No. Part No. Part Name Description

RESISTOR

R0001 NRSA63J-102X MG R 1kΩ 1/16W J
R0002 NRSA63J-104X MG R 100kΩ 1/16W J
R0003 NRSA63J-102X MG R 1k
R0004 NRSA63J-102X MG R 1kΩ 1/16W J
R0005 NRSA63J-102X MG R 1k
R0006 NRSA63J-152X MG R 1.5k
R0007 NRSA63J-102X MG R 1kΩ 1/16W J
R0008 NRSA63J-102X MG R 1kΩ 1/16W J
R0009 NRSA63J-103X MG R 10k
R0010 NRSA63J-103X MG R 10k
R0011 NRSA63J-103X MG R 10k
R0012 NRSA63J-273X MG R 27k
R0013 NRSA63J-221X MG R 220Ω 1/16W J
R0014 NRSA63J-102X MG R 1kΩ 1/16W J
R0015 NRSA63J-473X MG R 47k
R0016 NRSA63J-103X MG R 10k
R0017 NRSA63J-103X MG R 10kΩ 1/16W J
R0018 NRSA63J-102X MG R 1k
R0022 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0027 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0030 NRSA63J-472X MG R 4.7k
R0032 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0034 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0035 NRSA63J-0R0X MG R 0.0
R0036 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0037 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0038 NRSA63J-0R0X MG R 0.0
R0039 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0040 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0041 NRSA63J-0R0X MG R 0.0
R0042 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0043 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0044 NRSA63J-0R0X MG R 0.0
R0045 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0046 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0047 NRSA63J-0R0X MG R 0.0
R0048 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0049 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0050 NRSA63J-0R0X MG R 0.0
R0051 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0052 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0053 NRSA63J-0R0X MG R 0.0
R0055 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0057 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0058 NRSA63J-0R0X MG R 0.0
R0059 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0060 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0061 NRSA63J-0R0X MG R 0.0
R0062 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0063 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0064 NRSA63J-0R0X MG R 0.0
R0065 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0066 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0067 NRSA63J-0R0X MG R 0.0
R0068 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0069 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0070 NRSA63J-0R0X MG R 0.0
R0071 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0072 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0073 NRSA63J-0R0X MG R 0.0
R0074 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0075 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0076 NRSA63J-0R0X MG R 0.0
R0077 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0081 NCF31CZ-104X C CAP. 0.1µF 16V Z
R0087 NRSA63J-221X MG R 220
R0089 NRSA63J-221X MG R 220Ω 1/16W J
R0090 NRSA63J-221X MG R 220Ω 1/16W J
R0091 NRSA63J-221X MG R 220
R0092 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0093 NRSA63J-221X MG R 220Ω 1/16W J
R0094 NRSA63J-472X MG R 4.7k
R0095 NRSA63J-473X MG R 47kΩ 1/16W J
R0096 NRSA63J-221X MG R 220Ω 1/16W J
R0097 NRSA63J-102X MG R 1k
R0098 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0099 NRSA63J-102X MG R 1kΩ 1/16W J
R0100 NRSA63J-102X MG R 1k
R0101 NRSA63J-102X MG R 1kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

! Symbol No. Part No. Part Name Description

RESISTOR

R0102 NRSA63J-102X MG R 1kΩ 1/16W J
R0103 NRSA63J-103X MG R 10k
R0104 NRSA63J-103X MG R 10k
R0105 NRSA63J-103X MG R 10k
R0106 NRSA63J-103X MG R 10k
R0107 NRSA63J-102X MG R 1kΩ 1/16W J
R0110 NRSA63J-102X MG R 1k
R0111 NRSA63J-103X MG R 10k
R0112 NRSA63J-102X MG R 1kΩ 1/16W J
R0113 NRSA63J-103X MG R 10kΩ 1/16W J
R0114 NRSA63J-103X MG R 10k
R0119 NRSA63J-563X MG R 56k
R0120 NRSA63J-332X MG R 3.3k
R0121 NRSA63J-182X MG R 1.8k
R0122 NRSA63J-682X MG R 6.8kΩ 1/16W J
R0123 NRSA63J-682X MG R 6.8kΩ 1/16W J
R0124 NRSA63J-101X MG R 100
R0125 NRSA63J-472X MG R 4.7k
R0126 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0127 NRSA63J-472X MG R 4.7k
R0128 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0129 NRSA63J-823X MG R 82kΩ 1/16W J
R0130 NRSA63J-104X MG R 100k
R0131 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0133 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0136 NRSA63J-103X MG R 10k
R0137 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0138 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0139 NRSA63J-222X MG R 2.2k
R0144 NRSA63J-103X MG R 10kΩ 1/16W J
R0147 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0151 NRSA63J-183X MG R 18k
R0152 NRSA63J-221X MG R 220Ω 1/16W J
R0153 NRSA63J-221X MG R 220Ω 1/16W J
R0154 NRSA63J-221X MG R 220
R0155 NRSA63J-101X MG R 100
R0156 NRSA63J-101X MG R 100Ω 1/16W J
R0157 NRSA63J-0R0X MG R 0.0
R0158 NRSA63J-221X MG R 220Ω 1/16W J
R0165 NRSA63J-103X MG R 10kΩ 1/16W J
R0166 NRSA63J-223X MG R 22k
R0167 NRSA63J-103X MG R 10kΩ 1/16W J
R0168 NRSA63J-471X MG R 470Ω 1/16W J
R0169 NRSA63J-472X MG R 4.7k

CAPACITOR

C0001 QETN0JM-477Z E CAP. 470µF 6.3V M
C0002 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0003 NCB11CK-225X C CAP. 2.2
C0004 QETN0JM-108Z E CAP. 1000µF 6.3V M
C0005 NCB11CK-225X C CAP. 2.2µF 16V K
C0006 NCB11CK-225X C CAP. 2.2
C0007 NEH71CM-476X E CAP. 47µF 16V M
C0012 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0013 NCF31CZ-104X C CAP. 0.1
C0014 NCB31HK-682X C CAP. 6800pF 50V K
C0017 NDC31HJ-220X C CAP. 22pF 50V J
C0019 NEH71CM-476X E CAP. 47
C0020 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0021 NEH71CM-476X E CAP. 47
C0022 NCF31AZ-105X C CAP. 1µF 10V Z
C0023 NCB31EK-333X C CAP. 0.033µF 25V K
C0024 NCF31CZ-104X C CAP. 0.1
C0027 NEH71CM-476X E CAP. 47µF 16V M
C0028 NEH71CM-476X E CAP. 47µF 16V M
C0029 NDC31HJ-151X C CAP. 150pF 50V J
C0030 NCF31CZ-104X C CAP. 0.1
C0031 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0032 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0034 NCF31CZ-104X C CAP. 0.1
C0035 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0036 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0037 NCF31CZ-104X C CAP. 0.1
C0038 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0039 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0040 NDC31HJ-330X C CAP. 33pF 50V J
C0041 NDC31HJ-270X C CAP. 27pF 50V J
C0042 NCF31CZ-104X C CAP. 0.1
C0043 NCF31CZ-104X C CAP. 0.1µF 16V Z

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

µ

F 16V K

µ

F 16V K

µ

F 16V Z

µ

F 16V M

µ

F 16V M

µ

F 16V Z

µ

F 16V Z

µ

F 16V Z

µ

F 16V Z

µ

F 16V Z

No. 52067

47

A

V-32Z25EU

Y

! Symbol No. Part No. Part Name Description

CAPACITOR

C0045 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0046 NCF31CZ-104X C CAP. 0.1
C0047 NCF31CZ-104X C CAP. 0.1
C0048 NEH71CM-476X E CAP. 47
C0049 NCF31CZ-104X C CAP. 0.1
C0050 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0051 NEH71CM-476X E CAP. 47
C0052 NCF31CZ-104X C CAP. 0.1
C0053 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0054 NCF31CZ-104X C CAP. 0.1µF 16V Z
C0055 NCF31CZ-104X C CAP. 0.1
C0056 NCF31CZ-104X C CAP. 0.1
C0057 NCF31CZ-104X C CAP. 0.1
C0059 NEH71CM-106X E CAP. 10
C0060 NEH71CM-106X E CAP. 10µF 16V M
C0061 NEH71CM-106X E CAP. 10µF 16V M
C0062 NRSA63J-0R0X MG R 0.0
C0063 NDC31HJ-820X C CAP. 82pF 50V J
C0064 NDC31HJ-820X C CAP. 82pF 50V J
C0065 NDC31HJ-820X C CAP. 82pF 50V J

COIL

L0001 NQL092K-4R7X COIL 4.7µH
L0003 NQL092K-4R7X COIL 4.7µH
L0005 NQL092K-4R7X COIL 4.7
L0006 NQL092K-4R7X COIL 4.7µH
L0007 NQL092K-4R7X COIL 4.7µH
L0008 NQL092K-4R7X COIL 4.7
L0009 NQL034K-4R7X COIL 4.7µH
L0010 NQL092K-4R7X COIL 4.7µH
L0011 NQL092K-4R7X COIL 4.7
L0012 NQL092K-4R7X COIL 4.7µH
L0013 NQL092K-4R7X COIL 4.7µH
L0014 NQL092K-4R7X COIL 4.7
L0015 NQL034K-4R7X COIL 4.7
L0016 NQL034K-4R7X COIL 4.7µH
L0017 NQL092K-1R5X COIL 1.5
L0018 NQL092K-1R5X COIL 1.5µH
L0019 NQL092K-1R5X COIL 1.5µH
L0020 NQL092K-1R5X COIL 1.5
L0021 NQL092K-1R5X COIL 1.5µH
L0022 NQL092K-1R5X COIL 1.5µH

DIODE

D0001 MA111-X SI.DIODE
D0002 MA111-X SI.DIODE
D0003 MA3068/M/-X ZENER DIODE
D0004 MA3027-X ZENER DIODE
D0005 MA3056/M/-X ZENER DIODE
D0006 MA3056/M/-X ZENER DIODE
D0007 MA3056/M/-X ZENER DIODE
D0008 MA3056/M/-X ZENER DIODE

TRANSISTOR

Q0001 2SC2712/YG/-X SI.TRANSISTOR
Q0002 2SC2712/YG/-X SI.TRANSISTOR
Q0007 2SA1162/YG/-X SI.TRANSISTOR
Q0008 2SA1162/YG/-X SI.TRANSISTOR
Q0009 2SC2712/YG/-X SI.TRANSISTOR
Q0010 2SC2712/YG/-X SI.TRANSISTOR
Q0011 2SC2712/YG/-X SI.TRANSISTOR
Q0012 2SC2712/YG/-X SI.TRANSISTOR
Q0021 2SC2712/YG/-X SI.TRANSISTOR
Q0022 2SC2712/YG/-X SI.TRANSISTOR

IC

IC0001 SDA6000 IC
IC0002 MR27V1652EE5RAZ IC(MICRO C ROM)
IC0003 K4S161622D-TC80 IC
IC0004 AT24LC-28Z25EU IC (SERVICE)
IC0005 S-80828CNNB-W IC
IC0901 BA33C25FP-X IC

OTHERS

K0001 NRSA63J-390X MG R 39Ω 1/16W J
K0002 NQR0389-003X FERRITE BEADS
K0003 NRSA63J-0R0X MG R 0.0
K0004 NQR0389-003X FERRITE BEADS

µ

F 16V Z

µ

F 16V Z

µ

F 16V M

µ

F 16V Z

µ

F 16V M

µ

F 16V Z

µ

F 16V Z

µ

F 16V Z

µ

F 16V Z

µ

F 16V M

Ω

1/16W J

µ

H

µ

H

µ

H

µ

H

µ

H

µ

H

µ

H

Ω

1/16W J

! Symbol No. Part No. Part Name Description

OTHERS

K0005 NRSA63J-0R0X MG R 0.0Ω 1/16W J
LC0001 NQR0313-007X EMI FILTER
LC0002 NQR0431-001X EMI FILTER
X0001 QAX0669-001Z CRYSTAL

■■■■AV SW P.W. BOARD ASS’Y (SMF-0S402A)

! Symbol No. Part No. Part Name Description

RESISTOR

R0101 NRSA63J-750X MG R 75Ω 1/16W J
R0102 NRSA63J-750X MG R 75
R0103 NRSA63J-750X MG R 75Ω 1/16W J
R0104 NRSA63J-750X MG R 75Ω 1/16W J
R0105 NRSA63J-750X MG R 75
R0106 NRSA63J-750X MG R 75Ω 1/16W J
R0107 NRSA63J-750X MG R 75Ω 1/16W J
R0108 NRSA63J-750X MG R 75
R0109 NRSA63J-750X MG R 75Ω 1/16W J
R0110 NRSA63J-103X MG R 10kΩ 1/16W J
R0111 NRSA63J-103X MG R 10k
R0112 NRSA63J-823X MG R 82kΩ 1/16W J
R0113 NRSA63J-823X MG R 82kΩ 1/16W J
R0114 NRSA63J-333X MG R 33k
R0115 NRSA63J-473X MG R 47kΩ 1/16W J
R0116 NRSA63J-823X MG R 82kΩ 1/16W J
R0117 NRSA63J-223X MG R 22k
R0118 NRSA63J-473X MG R 47kΩ 1/16W J
R0119 NRSA63J-153X MG R 15kΩ 1/16W J
R0120 NRSA63J-273X MG R 27k
R0121 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0122 NRSA63J-473X MG R 47kΩ 1/16W J
R0123 NRSA63J-823X MG R 82k
R0124 NRSA63J-153X MG R 15kΩ 1/16W J
R0125 NRSA63J-223X MG R 22kΩ 1/16W J
R0126 NRSA63J-473X MG R 47k
R0127 NRSA63J-273X MG R 27kΩ 1/16W J
R0128 NRSA63J-823X MG R 82kΩ 1/16W J
R0129 NRSA63J-823X MG R 82k
R0130 NRSA63J-391X MG R 390Ω 1/16W J
R0131 NRSA63J-391X MG R 390Ω 1/16W J
R0132 NRSA63J-222X MG R 2.2k
R0133 NRSA63J-333X MG R 33kΩ 1/16W J
R0134 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0135 NRSA63J-333X MG R 33k
R0136 NRSA63J-103X MG R 10kΩ 1/16W J
R0137 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0138 NRSA63J-333X MG R 33k
R0139 NRSA63J-333X MG R 33kΩ 1/16W J
R0140 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0141 NRSA63J-333X MG R 33k
R0142 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0143 NRSA63J-333X MG R 33kΩ 1/16W J
R0144 NRSA63J-333X MG R 33k
R0145 NRSA63J-103X MG R 10kΩ 1/16W J
R0146 NRSA63J-473X MG R 47kΩ 1/16W J
R0147 NRSA63J-223X MG R 22k
R0148 NRSA63J-391X MG R 390Ω 1/16W J
R0149 NRSA63J-391X MG R 390Ω 1/16W J
R0150 NRSA63J-104X MG R 100k
R0151 NRSA63J-104X MG R 100kΩ 1/16W J
R0152 NRSA63J-101X MG R 100Ω 1/16W J
R0153 NRSA63J-101X MG R 100
R0154 NRSA63J-101X MG R 100Ω 1/16W J
R0155 NRSA63J-101X MG R 100Ω 1/16W J
R0156 NRSA63J-101X MG R 100
R0157 NRSA63J-101X MG R 100Ω 1/16W J
R0158 NRSA63J-101X MG R 100Ω 1/16W J
R0159 NRSA63J-101X MG R 100
R0160 NRSA63J-101X MG R 100Ω 1/16W J
R0161 NRSA63J-101X MG R 100Ω 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

48

No. 52067

A

V-32Z25EU

Y

! Symbol No. Part No. Part Name Description

RESISTOR

R0162 NRSA63J-101X MG R 100Ω 1/16W J
R0163 NRSA63J-101X MG R 100
R0164 NRSA63J-101X MG R 100
R0165 NRSA63J-101X MG R 100
R0166 NRSA63J-101X MG R 100
R0167 NRSA63J-101X MG R 100Ω 1/16W J
R0168 NRSA63J-750X MG R 75
R0169 NRSA63J-222X MG R 2.2k
R0170 NRSA63J-333X MG R 33kΩ 1/16W J
R0171 NRSA63J-750X MG R 75Ω 1/16W J
R0172 NRSA63J-222X MG R 2.2k
R0173 NRSA63J-333X MG R 33k
R0174 NRSA63J-750X MG R 75
R0175 NRSA63J-333X MG R 33k
R0176 NRSA63J-103X MG R 10kΩ 1/16W J
R0177 NRSA63J-823X MG R 82kΩ 1/16W J
R0178 NRSA63J-153X MG R 15k
R0179 NRSA63J-473X MG R 47k
R0180 NRSA63J-273X MG R 27kΩ 1/16W J
R0181 NRSA63J-562X MG R 5.6k
R0182 NRSA63J-562X MG R 5.6kΩ 1/16W J
R0183 NRSA63J-102X MG R 1kΩ 1/16W J
R0184 NRSA63J-102X MG R 1k
R0185 NRSA63J-101X MG R 100Ω 1/16W J
R0186 NRSA63J-101X MG R 100Ω 1/16W J
R0187 NRSA63J-101X MG R 100
R0188 NRSA63J-101X MG R 100Ω 1/16W J
R0189 NRSA63J-101X MG R 100Ω 1/16W J
R0190 NRSA63J-101X MG R 100
R0191 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0192 NRSA63J-101X MG R 100Ω 1/16W J
R0194 NRSA63J-221X MG R 220
R0195 NRSA63J-221X MG R 220Ω 1/16W J
R0196 QRG01GJ-101 OM R 100Ω 1W J
R0197 QRK126J-181X C R 180
R0198 NRSA63J-750X MG R 75
R0199 NRSA63J-101X MG R 100Ω 1/16W J
R0200 NRSA63J-750X MG R 75
R0201 QRK126J-151X C R 150Ω 1/2W J
R0203 NRSA63J-750X MG R 75Ω 1/16W J
R0204 NRSA63J-750X MG R 75
R0205 NRSA63J-750X MG R 75Ω 1/16W J

CAPACITOR

C0101 NCB31HK-472X C CAP. 4700pF 50V K
C0102 NCB31HK-472X C CAP. 4700pF 50V K
C0103 NCB31HK-472X C CAP. 4700pF 50V K
C0104 NCB31HK-472X C CAP. 4700pF 50V K
C0105 NCB31HK-472X C CAP. 4700pF 50V K
C0106 NCB31HK-472X C CAP. 4700pF 50V K
C0107 NCB31HK-472X C CAP. 4700pF 50V K
C0108 NCB31HK-472X C CAP. 4700pF 50V K
C0109 NCB31HK-472X C CAP. 4700pF 50V K
C0110 NCB31HK-472X C CAP. 4700pF 50V K
C0111 QETN1CM-477Z E CAP. 470
C0112 QETN1CM-477Z E CAP. 470
C0113 NCB31HK-102X C CAP. 1000pF 50V K
C0114 NCB31HK-102X C CAP. 1000pF 50V K
C0115 QETN1HM-106Z E CAP. 10
C0116 QETN1HM-106Z E CAP. 10µF 50V M
C0117 QETN1HM-106Z E CAP. 10
C0118 QETN1HM-105Z E CAP. 1µF 50V M
C0119 QETN1HM-105Z E CAP. 1µF 50V M
C0120 NCB31HK-103X C CAP. 0.01
C0121 QETN1HM-105Z E CAP. 1µF 50V M
C0122 QETN1HM-106Z E CAP. 10µF 50V M
C0123 QETN1HM-105Z E CAP. 1
C0124 NCB31HK-103X C CAP. 0.01µF 50V K
C0125 NCB31HK-102X C CAP. 1000pF 50V K
C0126 QETN1HM-106Z E CAP. 10
C0127 QETN1HM-106Z E CAP. 10
C0128 QETN1HM-106Z E CAP. 10µF 50V M
C0129 QETN1HM-105Z E CAP. 1µF 50V M
C0130 NCB31HK-103X C CAP. 0.01
C0131 QETN1HM-105Z E CAP. 1µF 50V M
C0132 NCB31HK-103X C CAP. 0.01µF 50V K
C0133 QETN1HM-106Z E CAP. 10
C0134 QETN1HM-105Z E CAP. 1µF 50V M
C0135 QETN1HM-106Z E CAP. 10µF 50V M

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

µ

F 16V M

µ

F 16V M

µ

F 50V M

µ

F 50V M

µ

F 50V K

µ

F 50V M

µ

F 50V M

µ

F 50V M

µ

F 50V K

µ

F 50V M

! Symbol No. Part No. Part Name Description

CAPACITOR

C0136 QETN1HM-105Z E CAP. 1µF 50V M
C0137 NCB31HK-103X C CAP. 0.01
C0138 QENC1HM-105Z E CAP. 1
C0139 QENC1HM-105Z E CAP. 1
C0140 QENC1EM-106Z BP E CAP. 10
C0141 NCB31HK-103X C CAP. 0.01µF 50V K
C0142 NCB31HK-103X C CAP. 0.01
C0143 NCB31HK-103X C CAP. 0.01
C0144 NCB31HK-103X C CAP. 0.01µF 50V K
C0145 NCB31HK-103X C CAP. 0.01µF 50V K
C0146 NCB31HK-103X C CAP. 0.01
C0147 NCB31HK-103X C CAP. 0.01
C0148 QETN1HM-106Z E CAP. 10
C0149 QENC1EM-106Z BP E CAP. 10
C0150 QETN1CM-107Z E CAP. 100µF 16V M
C0151 QETN1CM-107Z E CAP. 100µF 16V M
C0152 QETN1CM-477Z E CAP. 470
C0153 NCB31HK-103X C CAP. 0.01
C0154 QETN1CM-107Z E CAP. 100µF 16V M
C0155 NDC31HJ-150X C CAP. 15pF 50V J

COIL

L0101 QQR0716-001Z FERRITE BEADS

DIODE

D0101 MA3056/M/-X ZENER DIODE
D0102 MA3056/M/-X ZENER DIODE
D0103 MA3056/M/-X ZENER DIODE
D0104 MA3056/M/-X ZENER DIODE
D0109 MA3120/M/-X ZENER DIODE
D0110 MA3120/M/-X ZENER DIODE
D0111 MA3120/M/-X ZENER DIODE
D0112 MA3120/M/-X ZENER DIODE
D0113 MA3120/M/-X ZENER DIODE
D0114 MA3039/H/-X ZENER DIODE
D0115 MA3056/M/-X ZENER DIODE
D0116 MA3056/M/-X ZENER DIODE
D0117 MA3056/M/-X ZENER DIODE

TRANSISTOR

Q0101 2SC2412K/QR/-X SI.TRANSISTOR
Q0102 2SC2412K/QR/-X SI.TRANSISTOR
Q0103 DTC323TK-X DIGI.TRANSISTOR
Q0104 DTC323TK-X DIGI.TRANSISTOR
Q0105 DTC323TK-X DIGI.TRANSISTOR
Q0106 2SC2412K/QR/-X SI.TRANSISTOR
Q0107 2SC2412K/QR/-X SI.TRANSISTOR
Q0108 2SC2412K/QR/-X SI.TRANSISTOR
Q0109 2SC2412K/QR/-X SI.TRANSISTOR
Q0110 2SA1037AK/QR/-X SI.TRANSISTOR
Q0111 DTC323TK-X DIGI.TRANSISTOR
Q0112 2SA1037AK/QR/-X SI.TRANSISTOR
Q0113 2SC2412K/QR/-X SI.TRANSISTOR
Q0114 2SC2412K/QR/-X SI.TRANSISTOR
Q0115 2SC2412K/QR/-X SI.TRANSISTOR
Q0116 2SA933AS/QR/-T SI.TRANSISTOR
Q0117 2SC1740S/QR/-T SI.TRANSISTOR

IC

IC0101 CXA2069Q IC

OTHERS

J0001 QNZ0465-001 21P CONNECTOR
J0002 QNZ0463-001 21P CONNECTOR
K0101 CE42681-001Y CHIP BEADS CORE
K0102 CE42681-001Y CHIP BEADS CORE
K0103 CE42681-001Y CHIP BEADS CORE
K0104 CE42681-001Y CHIP BEADS CORE

µ

F 50V K

µ

F 50V M

µ

F 50V M

µ

F 25V M

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V M

µ

F 25V M

µ

F 16V M

µ

F 50V K

No. 52067

49

A

V-32Z25EU

Y

■■■■100Hz P.W. BOARD ASS’Y (SMF-0Z404A)

! Symbol No. Part No. Part Name Description

RESISTOR

R0008 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0009 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0010 NRSA63J-101X MG R 100
R0011 NRSA63J-101X MG R 100Ω 1/16W J
R0012 NRSA63J-101X MG R 100
R0101 NRSA63J-332X MG R 3.3k
R0102 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0103 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0104 NRSA63J-332X MG R 3.3k
R0105 NRSA63J-222X MG R 2.2k
R0106 NRSA63J-222X MG R 2.2k
R0107 NRSA63J-750X MG R 75
R0108 NRSA63J-750X MG R 75Ω 1/16W J
R0109 NRSA63J-750X MG R 75Ω 1/16W J
R0110 NRSA63J-750X MG R 75
R0111 NRSA63J-750X MG R 75
R0112 NRSA63J-750X MG R 75Ω 1/16W J
R0113 NRSA63J-750X MG R 75
R0122 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0123 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0124 NRSA63J-101X MG R 100
R0125 NRSA63J-101X MG R 100Ω 1/16W J
R0132 NRSA63J-100X MG R 10Ω 1/16W J
R0133 NRSA63J-100X MG R 10
R0134 NRSA63J-100X MG R 10Ω 1/16W J
R0135 NRSA63J-100X MG R 10Ω 1/16W J
R0136 NRSA63J-100X MG R 10
R0137 NRSA63J-100X MG R 10Ω 1/16W J
R0138 NRSA63J-100X MG R 10Ω 1/16W J
R0139 NRSA63J-100X MG R 10
R0141 NRSA63J-100X MG R 10Ω 1/16W J
R0201 NRSA63J-121X MG R 120Ω 1/16W J
R0202 NRSA63J-101X MG R 100
R0203 NRSA63J-101X MG R 100Ω 1/16W J
R0204 NRSA63J-221X MG R 220Ω 1/16W J
R0205 NRSA63J-0R0X MG R 0.0
R0214 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0217 NRSA63J-103X MG R 10kΩ 1/16W J
R0218 NRSA63J-333X MG R 33k
R0219 NRSA63J-103X MG R 10kΩ 1/16W J
R0220 NRSA63J-822X MG R 8.2kΩ 1/16W J
R0251 NRSA63J-222X MG R 2.2k
R0252 NRSA63J-750X MG R 75Ω 1/16W J
R0254 NRSA63J-391X MG R 390Ω 1/16W J
R0255 NRSA63J-221X MG R 220
R0256 NRSA63J-221X MG R 220Ω 1/16W J
R0257 NRSA63J-271X MG R 270Ω 1/16W J
R0258 NRSA63J-272X MG R 2.7k
R0259 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0261 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0264 NRSA63J-391X MG R 390
R0271 NRSA63J-222X MG R 2.2kΩ 1/16W J
R0274 NRSA63J-391X MG R 390Ω 1/16W J
R0293 NRSA63J-102X MG R 1k
R0301 NRSA63J-104X MG R 100kΩ 1/16W J
R0302 NRSA63J-104X MG R 100kΩ 1/16W J
R0303 NRSA63J-104X MG R 100k
R0304 NRSA63J-101X MG R 100Ω 1/16W J
R0305 NRSA63J-101X MG R 100Ω 1/16W J
R0306 NRSA63J-152X MG R 1.5k
R0307 NRSA63J-152X MG R 1.5kΩ 1/16W J
R0308 NRSA63J-152X MG R 1.5kΩ 1/16W J
R0401 NRSA63J-473X MG R 47k
R0402 NRSA63J-472X MG R 4.7kΩ 1/16W J
R0404 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R0407 NRSA63J-0R0X MG R 0.0
R0409 NRSA63J-0R0X MG R 0.0Ω 1/16W J

CAPACITOR

C0001 NCB31CK-104X C CAP. 0.1µF 16V K
C0002 NEH71CM-476X E CAP. 47
C0003 NCB31CK-104X C CAP. 0.1µF 16V K
C0004 NEH71CM-476X E CAP. 47µF 16V M
C0005 NCB31CK-104X C CAP. 0.1
C0006 NEH71CM-476X E CAP. 47µF 16V M
C0007 NDC31HJ-4R0X C CAP. 4.0pF 50V J
C0008 NDC31HJ-4R0X C CAP. 4.0pF 50V J
C0009 NDC31HJ-4R0X C CAP. 4.0pF 50V J
C0101 NEH71CM-106X E CAP. 10

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

µ

F 16V M

µ

F 16V K

µ

F 16V M

! Symbol No. Part No. Part Name Description

CAPACITOR

C0102 NCB31EK-473X C CAP. 0.047µF 25V K
C0103 NEH71CM-476X E CAP. 47
C0104 NCB31HK-152X C CAP. 1500pF 50V K
C0105 NDC31HJ-102X C CAP. 1000pF 50V J
C0106 NCB31CK-104X C CAP. 0.1
C0107 NCF31CZ-224X C CAP. 0.22
C0108 NCB31HK-152X C CAP. 1500pF 50V K
C0109 NDC31HJ-391X C CAP. 390pF 50V J
C0110 NEH71CM-106X E CAP. 10
C0111 NCB31EK-473X C CAP. 0.047
C0112 NDC31HJ-331X C CAP. 330pF 50V J
C0113 NCF31CZ-224X C CAP. 0.22
C0114 NCF31CZ-224X C CAP. 0.22
C0115 NCF31CZ-224X C CAP. 0.22µF 16V Z
C0116 NCF31CZ-224X C CAP. 0.22µF 16V Z
C0117 NCF31CZ-224X C CAP. 0.22
C0118 NCF31CZ-224X C CAP. 0.22
C0119 NDC31HJ-331X C CAP. 330pF 50V J
C0120 NDC31HJ-331X C CAP. 330pF 50V J
C0121 NDC31HJ-331X C CAP. 330pF 50V J
C0122 NDC31HJ-331X C CAP. 330pF 50V J
C0123 NDC31HJ-331X C CAP. 330pF 50V J
C0124 NDC31HJ-331X C CAP. 330pF 50V J
C0125 NDC31HJ-3R0X C CAP. 3.0pF 50V J
C0126 NDC31HJ-3R0X C CAP. 3.0pF 50V J
C0128 NCB31CK-104X C CAP. 0.1
C0129 NCF31CZ-224X C CAP. 0.22
C0130 NDC31HJ-391X C CAP. 390pF 50V J
C0131 NCB31HK-152X C CAP. 1500pF 50V K
C0132 NCB31EK-473X C CAP. 0.047
C0133 NCB31HK-152X C CAP. 1500pF 50V K
C0134 NCB31CK-683X C CAP. 0.068
C0136 NCB31CK-683X C CAP. 0.068
C0137 NCB31CK-683X C CAP. 0.068µF 16V K
C0138 NCB31HK-152X C CAP. 1500pF 50V K
C0139 NCB31EK-473X C CAP. 0.047
C0140 NEH71CM-476X E CAP. 47
C0141 NDC31HJ-100X C CAP. 10pF 50V J
C0201 NEH71CM-476X E CAP. 47
C0202 NCB31CK-104X C CAP. 0.1µF 16V K
C0203 NCB31CK-104X C CAP. 0.1
C0204 NCB31CK-104X C CAP. 0.1µF 16V K
C0205 NCB31CK-104X C CAP. 0.1µF 16V K
C0206 NEH71CM-476X E CAP. 47
C0207 NCB31CK-104X C CAP. 0.1µF 16V K
C0208 NCB31CK-104X C CAP. 0.1µF 16V K
C0209 NCB31CK-104X C CAP. 0.1
C0210 NCB31CK-104X C CAP. 0.1µF 16V K
C0211 NCB31CK-104X C CAP. 0.1µF 16V K
C0212 NDC31HJ-180X C CAP. 18pF 50V J
C0213 NDC31HJ-180X C CAP. 18pF 50V J
C0214 NCB31CK-104X C CAP. 0.1
C0215 NCB31CK-104X C CAP. 0.1µF 16V K
C0216 NCB31CK-104X C CAP. 0.1µF 16V K
C0217 NCB31CK-104X C CAP. 0.1
C0218 NDC31HJ-561X C CAP. 560pF 50V J
C0219 NEH71CM-476X E CAP. 47
C0220 NCB31CK-104X C CAP. 0.1µF 16V K
C0221 NCB31CK-104X C CAP. 0.1
C0222 NCB31CK-104X C CAP. 0.1µF 16V K
C0223 NCB31CK-104X C CAP. 0.1µF 16V K
C0224 NCB31CK-104X C CAP. 0.1
C0225 NCB31CK-104X C CAP. 0.1µF 16V K
C0226 NCB31CK-104X C CAP. 0.1µF 16V K
C0227 NCB31CK-104X C CAP. 0.1
C0228 NCB31CK-104X C CAP. 0.1µF 16V K
C0229 NCB31CK-104X C CAP. 0.1µF 16V K
C0231 NCB31CK-104X C CAP. 0.1
C0232 NCB31CK-104X C CAP. 0.1µF 16V K
C0233 NCB31CK-104X C CAP. 0.1µF 16V K
C0234 NCB31CK-104X C CAP. 0.1
C0235 NCB31CK-104X C CAP. 0.1µF 16V K
C0237 NEH71CM-106X E CAP. 10µF 16V M
C0238 NEH71CM-106X E CAP. 10
C0239 NCB31CK-104X C CAP. 0.1µF 16V K
C0240 NCB31CK-104X C CAP. 0.1µF 16V K
C0241 NCB31CK-104X C CAP. 0.1
C0242 NCB31CK-104X C CAP. 0.1µF 16V K
C0251 NDC31HJ-4R0X C CAP. 4.0pF 50V J
C0252 NCB31CK-104X C CAP. 0.1
C0253 NCB31CK-104X C CAP. 0.1

µ

F 16V M

µ

F 16V K

µ

F 16V Z

µ

F 16V M

µ

F 25V K

µ

F 16V Z

µ

F 16V Z

µ

F 16V Z

µ

F 16V Z

µ

F 16V K

µ

F 16V Z

µ

F 25V K

µ

F 16V K

µ

F 16V K

µ

F 25V K

µ

F 16V M

µ

F 16V M

µ

F 16V K

µ

F 16V M

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 16V M

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 16V M

µ

F 16V K

µ

F 16V K

µ

F 16V K

50

No. 52067

A

V-32Z25EU

Y

! Symbol No. Part No. Part Name Description

CAPACITOR

C0254 NDC31HJ-120X C CAP. 12pF 50V J
C0255 NDC31HJ-270X C CAP. 27pF 50V J
C0256 NEH71CM-106X E CAP. 10
C0261 NDC31HJ-4R0X C CAP. 4.0pF 50V J
C0262 NCB31CK-104X C CAP. 0.1
C0263 NCB31CK-104X C CAP. 0.1
C0264 NDC31HJ-120X C CAP. 12pF 50V J
C0265 NDC31HJ-270X C CAP. 27pF 50V J
C0271 NDC31HJ-4R0X C CAP. 4.0pF 50V J
C0272 NCB31CK-104X C CAP. 0.1
C0273 NCB31CK-104X C CAP. 0.1
C0274 NDC31HJ-120X C CAP. 12pF 50V J
C0275 NDC31HJ-270X C CAP. 27pF 50V J
C0281 NCF31AZ-105X C CAP. 1
C0282 NEH71CM-476X E CAP. 47
C0283 NCB31CK-104X C CAP. 0.1µF 16V K
C0284 NCB31CK-104X C CAP. 0.1µF 16V K
C0285 NCB31CK-104X C CAP. 0.1
C0286 NEH71CM-106X E CAP. 10
C0301 NEH71CM-476X E CAP. 47µF 16V M
C0302 NCB31CK-104X C CAP. 0.1µF 16V K
C0303 NCB31CK-104X C CAP. 0.1
C0402 NCB31CK-104X C CAP. 0.1µF 16V K
C0403 NCB31CK-104X C CAP. 0.1µF 16V K
C0404 NDC31HJ-330X C CAP. 33pF 50V J

COIL

L0001 NQL092K-1R5X COIL 1.5µH
L0002 NQL092K-1R5X COIL 1.5µH
L0003 NQL092K-1R5X COIL 1.5µH
L0101 NQL034K-150X COIL 15
L0102 NQL092K-3R3X COIL 3.3µH
L0103 NQL092K-3R3X COIL 3.3µH
L0104 NQL092K-3R3X COIL 3.3
L0105 NQL092K-3R3X COIL 3.3µH
L0106 NQL092K-3R3X COIL 3.3
L0107 NQL092K-3R3X COIL 3.3
L0108 NQL092K-3R3X COIL 3.3µH
L0109 NQL034K-6R8X COIL 6.8µH
L0201 NQL034K-100X COIL 10
L0202 NQL034K-100X COIL 10µH
L0203 NQL034K-100X COIL 10µH
L0204 NQL034K-100X COIL 10
L0205 NQL034K-100X COIL 10µH
L0207 NQL034K-100X COIL 10µH
L0208 NQL034K-100X COIL 10
L0209 NQL092K-1R5X COIL 1.5µH
L0210 NQL092K-1R5X COIL 1.5µH
L0211 NQR0413-003X FERRITE BEADS
L0251 NQL092K-5R6X COIL 5.6
L0261 NQL092K-5R6X COIL 5.6µH
L0271 NQL092K-5R6X COIL 5.6µH

DIODE

D0401 MA111-X SI.DIODE

TRANSISTOR

Q0101 2SA1037AK/QR/-X SI.TRANSISTOR
Q0102 2SA1037AK/QR/-X SI.TRANSISTOR
Q0201 2SA1037AK/QR/-X SI.TRANSISTOR
Q0251 2SA1037AK/QR/-X SI.TRANSISTOR
Q0252 2SA1037AK/QR/-X SI.TRANSISTOR
Q0253 2SC2412K/QR/-X SI.TRANSISTOR
Q0261 2SA1037AK/QR/-X SI.TRANSISTOR
Q0271 2SA1037AK/QR/-X SI.TRANSISTOR
Q0301 2SC2412K/QR/-X SI.TRANSISTOR
Q0302 2SC2412K/QR/-X SI.TRANSISTOR
Q0303 2SC2412K/QR/-X SI.TRANSISTOR

IC

IC0101 VPC3230D-QA-B3 IC
IC0201 SAA4979H/V105 IC
IC0202 SAA4994H/V1 IC
IC0203 SAA4955HL/V1 IC
IC0212 R1170H251B-X IC
IC0213 TC7WH32FK-X IC
IC0301 TDA9178T/N1-X IC
IC0401 S-80828CNNB-W IC
IC0402 TC7WH34FU-X IC

µ

F 16V M

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 10V Z

µ

F 16V M

µ

F 16V K

µ

F 16V M

µ

F 16V K

µ

H

µ

H

µ

H

µ

H

µ

H

µ

H

µ

H

µ

H

! Symbol No. Part No. Part Name Description

OTHERS

LC0010 NQR0313-009X EMI FILTER
LC0011 NQR0313-009X EMI FILTER
LC0012 NQR0313-009X EMI FILTER
LC0013 NQR0313-004X EMI FILTER
LC0014 NQR0313-007X EMI FILTER
LC0015 NQR0313-007X EMI FILTER
X0101 QAX0655-001Z CRYSTAL
X0201 QAX0273-001Z CRYSTAL

No. 52067

51

A

V-28Z25EU

Y

[ AV-28Z25EUY ]

PRINTED WIRING BOARD PARTS LIST

■ MAIN P.W. BOARD ASS’Y (SMF-1405A)

! Symbol No. Part No. Part Name Description

RESISTOR

R1004 NRSA63J-101X MG R 100Ω 1/16W J
R1005 NRSA63J-101X MG R 100
R1006 NRSA63J-101X MG R 100Ω 1/16W J
R1008 NRSA63J-101X MG R 100
R1009 NRSA63J-0R0X MG R 0.0
R1102 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1103 NRSA63J-222X MG R 2.2kΩ 1/16W J
R1104 NRSA63J-102X MG R 1k
R1105 NRSA63J-561X MG R 560
R1106 NRSA63J-331X MG R 330
R1108 NRSA63J-102X MG R 1k
R1109 NRSA63J-101X MG R 100Ω 1/16W J
R1110 NRSA63J-101X MG R 100Ω 1/16W J
R1111 NRSA63J-101X MG R 100
R1151 NRSA63J-101X MG R 100Ω 1/16W J
R1153 NRSA63J-101X MG R 100Ω 1/16W J
R1301 NRSA63J-101X MG R 100
R1302 NRSA63J-101X MG R 100Ω 1/16W J
R1303 NRSA63J-273X MG R 27kΩ 1/16W J
R1304 NRSA63J-102X MG R 1k
R1311 NRSA63J-331X MG R 330Ω 1/16W J
R1312 NRSA63J-273X MG R 27kΩ 1/16W J
R1313 NRSA63J-183X MG R 18k
R1314 NRSA63J-221X MG R 220Ω 1/16W J
R1315 NRSA63J-101X MG R 100Ω 1/16W J
R1316 NRSA63J-101X MG R 100
R1317 NRSA63J-101X MG R 100Ω 1/16W J
R1318 NRSA63J-562X MG R 5.6kΩ 1/16W J
R1319 NRSA63J-183X MG R 18k
R1321 NRSA63J-0R0X MG R 0.0
R1322 NRSA63J-0R0X MG R 0.0Ω 1/16W J
R1325 NRSA63J-101X MG R 100
R1326 NRSA63J-682X MG R 6.8kΩ 1/16W J
R1401 NRSA63J-102X MG R 1kΩ 1/16W J
R1402 NRSA63J-102X MG R 1k
R1403 NRSA63J-331X MG R 330Ω 1/16W J
R1404 NRSA63J-331X MG R 330Ω 1/16W J
R1405 NRSA63J-102X MG R 1k
R1406 NRSA63J-102X MG R 1kΩ 1/16W J
R1451 NRSA63J-821X MG R 820Ω 1/16W J
R1454 NRSA63J-472X MG R 4.7k
R1455 NRSA63J-123X MG R 12kΩ 1/16W J
R1456 NRSA63J-123X MG R 12kΩ 1/16W J
R1457 NRSA63J-392X MG R 3.9k
R1458 NRSA63J-123X MG R 12kΩ 1/16W J
R1459 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1461 NRSA63J-123X MG R 12k
R1462 NRSA63J-153X MG R 15kΩ 1/16W J
R1463 NRSA63J-104X MG R 100kΩ 1/16W J
R1465 NRSA63J-224X MG R 220k
R1466 NRSA63J-224X MG R 220kΩ 1/16W J
R1467 NRSA63J-563X MG R 56kΩ 1/16W J
R1468 NRSA63J-224X MG R 220k
R1469 NRSA63J-683X MG R 68kΩ 1/16W J
R1470 NRSA63J-223X MG R 22kΩ 1/16W J
R1471 NRSA63J-273X MG R 27k
R1472 NRSA63J-682X MG R 6.8kΩ 1/16W J
R1473 NRSA63J-123X MG R 12kΩ 1/16W J
R1474 NRSA63J-563X MG R 56k
R1475 NRSA63J-153X MG R 15kΩ 1/16W J
R1476 NRSA63J-123X MG R 12kΩ 1/16W J
R1477 NRSA63J-123X MG R 12k
R1478 NRSA63J-123X MG R 12kΩ 1/16W J
R1479 NRSA63J-154X MG R 150kΩ 1/16W J
R1480 NRSA63J-823X MG R 82k
R1481 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1482 NRSA63J-272X MG R 2.7kΩ 1/16W J
R1483 NRSA63J-472X MG R 4.7k
R1484 NRSA63J-473X MG R 47kΩ 1/16W J
R1485 NRSA63J-123X MG R 12kΩ 1/16W J
R1486 NRSA63J-472X MG R 4.7k
R1487 NRSA63J-183X MG R 18kΩ 1/16W J
R1489 NRSA63J-333X MG R 33kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

! Symbol No. Part No. Part Name Description

RESISTOR

R1491 NRSA63J-332X MG R 3.3kΩ 1/16W J
R1492 NRSA63J-562X MG R 5.6k
R1501 NRSA63J-0R0X MG R 0.0
R1504 NRSA63J-102X MG R 1kΩ 1/16W J
R1511 NRSA63J-152X MG R 1.5k
R1512 NRSA63J-332X MG R 3.3k
R1521 NRSA63J-223X MG R 22k
R1522 NRSA63J-562X MG R 5.6k
R1551 NRSA63J-100X MG R 10Ω 1/16W J
R1552 NRSA63J-124X MG R 120kΩ 1/16W J
R1553 NRSA63J-683X MG R 68k
R1554 NRSA63J-562X MG R 5.6k
R1555 NRSA63J-333X MG R 33kΩ 1/16W J
R1556 NRSA63J-472X MG R 4.7k
R1557 NRSA63J-562X MG R 5.6k
R1558 NRSA63J-104X MG R 100k
R1559 NRSA63J-154X MG R 150k
R1560 NRSA63J-100X MG R 10Ω 1/16W J
R1561 QRN143J-0R0X C R 0.0Ω 1/4W J
R1562 NRSA63J-683X MG R 68k
R1563 NRSA63J-103X MG R 10kΩ 1/16W J
R1564 NRSA63J-223X MG R 22kΩ 1/16W J
R1565 NRSA63J-562X MG R 5.6k
R1591 NRSA63J-561X MG R 560Ω 1/16W J
R1592 NRSA63J-332X MG R 3.3kΩ 1/16W J
R1595 NRSA63J-222X MG R 2.2k
R1596 NRSA63J-104X MG R 100kΩ 1/16W J
R1601 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1603 NRSA63J-472X MG R 4.7k
R1604 NRSA63J-104X MG R 100k
R1605 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1607 NRSA63J-103X MG R 10k
R1608 NRSA63J-103X MG R 10kΩ 1/16W J
R1609 NRSA63J-103X MG R 10kΩ 1/16W J
R1613 NRSA63J-223X MG R 22k
R1614 NRSA63J-104X MG R 100kΩ 1/16W J
R1616 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1617 NRSA63J-103X MG R 10k
R1618 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1619 NRSA63J-473X MG R 47kΩ 1/16W J
R1622 NRSA63J-822X MG R 8.2k
R1623 NRSA63J-103X MG R 10kΩ 1/16W J
R1624 NRSA63J-473X MG R 47kΩ 1/16W J
R1625 NRSA63J-472X MG R 4.7k
R1626 NRSA63J-104X MG R 100kΩ 1/16W J
R1627 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1628 NRSA63J-104X MG R 100k
R1629 NRSA63J-472X MG R 4.7kΩ 1/16W J
R1630 NRSA63J-104X MG R 100kΩ 1/16W J
R1631 NRSA63J-103X MG R 10k
R1632 NRSA63J-103X MG R 10kΩ 1/16W J
R1633 NRSA63J-103X MG R 10kΩ 1/16W J
R1637 NRSA63J-822X MG R 8.2k
R1638 NRSA63J-103X MG R 10kΩ 1/16W J
R1639 NRSA63J-473X MG R 47kΩ 1/16W J
R1640 NRSA63J-822X MG R 8.2k
R1641 NRSA63J-103X MG R 10kΩ 1/16W J
R1642 NRSA63J-473X MG R 47kΩ 1/16W J
R1643 NRSA63J-822X MG R 8.2k
R1646 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1649 NRSA63J-223X MG R 22kΩ 1/16W J
R1650 NRSA63J-223X MG R 22k
R1651 NRSA63J-223X MG R 22kΩ 1/16W J
R1652 NRSA63J-473X MG R 47kΩ 1/16W J
R1653 NRSA63J-273X MG R 27k
R1655 NRSA63J-104X MG R 100kΩ 1/16W J
R1656 NRSA63J-822X MG R 8.2kΩ 1/16W J
R1657 NRSA63J-104X MG R 100k
R1701 NRSA63J-103X MG R 10kΩ 1/16W J
R1702 NRSA63J-103X MG R 10kΩ 1/16W J
R1703 NRSA63J-102X MG R 1k
R1704 NRSA63J-102X MG R 1kΩ 1/16W J
R1706 NRSA63J-103X MG R 10kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

52

No. 52067

A

V-28Z25EU

Y

! Symbol No. Part No. Part Name Description

RESISTOR

R1707 NRSA63J-103X MG R 10kΩ 1/16W J
R1708 NRSA63J-103X MG R 10k
R1709 QRE121J-151Y C R 150
R1711 NRSA63J-101X MG R 100
R1712 NRSA63J-101X MG R 100
R1714 NRSA63J-102X MG R 1kΩ 1/16W J
R1715 NRSA63J-102X MG R 1k
R1720 NRSA63J-102X MG R 1k
R1721 NRSA63J-102X MG R 1kΩ 1/16W J
R1722 NRSA63J-102X MG R 1kΩ 1/16W J
R1772 NRSA63J-221X MG R 220
R1773 NRSA63J-221X MG R 220
R1774 NRSA63J-221X MG R 220
R1775 NRSA63J-221X MG R 220
R1776 NRSA63J-221X MG R 220Ω 1/16W J
R1951 QRK126J-220X C R 22Ω 1/2W J

CAPACITOR

C1001 NCB31HK-222X C CAP. 2200pF 50V K
C1002 QETN1HM-106Z E CAP. 10
C1004 NCB31CK-104X C CAP. 0.1µF 16V K
C1005 QETN1CM-108Z E CAP. 1000
C1006 NCB31HK-103X C CAP. 0.01
C1007 QETN1HM-106Z E CAP. 10µF 50V M
C1009 NCB31CK-104X C CAP. 0.1µF 16V K
C1010 QETN1HM-106Z E CAP. 10
C1101 NCB31CK-104X C CAP. 0.1µF 16V K
C1102 QETN1HM-106Z E CAP. 10µF 50V M
C1103 NCB31CK-104X C CAP. 0.1
C1104 QETN1CM-107Z E CAP. 100µF 16V M
C1105 QETN1HM-106Z E CAP. 10µF 50V M
C1106 NCB31CK-104X C CAP. 0.1
C1107 NCB31CK-104X C CAP. 0.1µF 16V K
C1111 NCB31HK-103X C CAP. 0.01µF 50V K
C1116 NCB31HK-472X C CAP. 4700pF 50V K
C1117 NCB31HK-103X C CAP. 0.01
C1118 NCB31HK-103X C CAP. 0.01µF 50V K
C1119 NDC31HJ-2R0X C CAP. 2.0pF 50V J
C1120 NDC31HJ-2R0X C CAP. 2.0pF 50V J
C1121 NCB31HK-103X C CAP. 0.01
C1122 NDC31HJ-102X C CAP. 1000pF 50V J
C1123 NDC31HJ-102X C CAP. 1000pF 50V J
C1124 QETN1HM-106Z E CAP. 10
C1125 QETN1HM-106Z E CAP. 10µF 50V M
C1126 NCB31CK-104X C CAP. 0.1µF 16V K
C1127 QETN1HM-106Z E CAP. 10
C1128 NCB31CK-104X C CAP. 0.1µF 16V K
C1129 NCF31AZ-105X C CAP. 1µF 10V Z
C1130 QETN1HM-106Z E CAP. 10
C1151 NCF31AZ-105X C CAP. 1µF 10V Z
C1152 NCF31AZ-105X C CAP. 1µF 10V Z
C1301 QETN1CM-107Z E CAP. 100
C1302 NCB31CK-104X C CAP. 0.1µF 16V K
C1303 NCB31CK-104X C CAP. 0.1µF 16V K
C1305 NCB31CK-104X C CAP. 0.1
C1306 NCB31CK-104X C CAP. 0.1µF 16V K
C1307 NCB31CK-104X C CAP. 0.1µF 16V K
C1308 NCB31CK-104X C CAP. 0.1
C1309 NCB31CK-104X C CAP. 0.1µF 16V K
C1310 QETN1AM-228Z E CAP. 2200µF 10V M
C1311 NCB31CK-683X C CAP. 0.068
C1312 NDC31HJ-221X C CAP. 220pF 50V J
C1313 NCB31HK-223X C CAP. 0.022
C1314 NCB31HK-223X C CAP. 0.022µF 50V K
C1315 NCB31HK-223X C CAP. 0.022
C1316 NCB31HK-103X C CAP. 0.01µF 50V K
C1317 NCB31HK-103X C CAP. 0.01µF 50V K
C1318 NCB31HK-103X C CAP. 0.01
C1320 QETN0JM-228Z E CAP. 2200µF 6.3V M
C1321 NCB31HK-223X C CAP. 0.022µF 50V K
C1322 NCB31HK-223X C CAP. 0.022
C1323 NCB31HK-223X C CAP. 0.022µF 50V K
C1324 NDC31HJ-820X C CAP. 82pF 50V J
C1351 QENC1EM-106Z BP E CAP. 10
C1401 NCB31CK-104X C CAP. 0.1
C1402 QETN1CM-107Z E CAP. 100µF 16V M
C1403 NCB31CK-104X C CAP. 0.1µF 16V K
C1404 NCB31CK-104X C CAP. 0.1
C1454 NCB31EK-333X C CAP. 0.033µF 25V K

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

µ

F 50V M

µ

F 16V M

µ

F 50V K

µ

F 50V M

µ

F 16V K

µ

F 16V K

µ

F 50V K

µ

F 50V K

µ

F 50V M

µ

F 50V M

µ

F 50V M

µ

F 16V M

µ

F 16V K

µ

F 16V K

µ

F 16V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 50V K

µ

F 25V M

µ

F 16V K

µ

F 16V K

! Symbol No. Part No. Part Name Description

CAPACITOR

C1455 NCB31CK-104X C CAP. 0.1µF 16V K
C1456 NCB31CK-104X C CAP. 0.1
C1457 NCB31EK-333X C CAP. 0.033
C1491 NCB31EK-473X C CAP. 0.047
C1471 NCB31CK-104X C CAP. 0.1
C1472 NCB31HK-103X C CAP. 0.01µF 50V K
C1473 NCB31CK-104X C CAP. 0.1
C1474 NCB31EK-333X C CAP. 0.033
C1475 NCB31CK-104X C CAP. 0.1µF 16V K
C1501 NDC31HJ-150X C CAP. 15pF 50V J
C1502 NDC31HJ-150X C CAP. 15pF 50V J
C1551 NCF31CZ-224X C CAP. 0.22
C1552 NCF31CZ-224X C CAP. 0.22
C1553 QETN1EM-476Z E CAP. 47µF 25V M
C1554 NCF31CZ-224X C CAP. 0.22µF 16V Z
C1555 NCF31CZ-224X C CAP. 0.22
C1560 QETN1CM-107Z E CAP. 100
C1561 NDC31HJ-561X C CAP. 560pF 50V J
C1562 QETN1HM-105Z E CAP. 1
C1564 NCB31CK-104X C CAP. 0.1
C1591 NDC31HJ-471X C CAP. 470pF 50V J
C1596 NCB31CK-104X C CAP. 0.1
C1601 QETN1HM-106Z E CAP. 10
C1602 QETN1HM-106Z E CAP. 10
C1603 QETN1HM-106Z E CAP. 10µF 50V M
C1604 QETN1HM-107Z E CAP. 100µF 50V M
C1611 QETN1EM-108Z E CAP. 1000
C1612 QETN1EM-108Z E CAP. 1000µF 25V M
C1613 QETN1EM-108Z E CAP. 1000µF 25V M
C1614 QETN1HM-106Z E CAP. 10
C1616 QETN1HM-106Z E CAP. 10µF 50V M
C1617 QETN1HM-106Z E CAP. 10µF 50V M
C1618 QETN1HM-106Z E CAP. 10
C1619 QETN1HM-106Z E CAP. 10µF 50V M
C1620 QETN1HM-107Z E CAP. 100µF 50V M
C1621 QETM1VM-228 E CAP. 2200
C1628 QETN1EM-108Z E CAP. 1000µF 25V M
C1629 QETM1EM-338 E CAP. 3300µF 25V M
C1630 QETN1EM-108Z E CAP. 1000
C1631 QETN1HM-106Z E CAP. 10µF 50V M
C1633 QETN1HM-106Z E CAP. 10µF 50V M
C1634 QETN1CM-108Z E CAP. 1000
C1635 QETM1VM-228 E CAP. 2200µF 35V M
C1636 QETN1HM-107Z E CAP. 100µF 50V M
C1637 QETN1HM-107Z E CAP. 100
C1638 NCB31HK-104X C CAP. 0.1µF 50V K
C1639 QETN1CM-108Z E CAP. 1000µF 16V M
C1640 QETN1CM-107Z E CAP. 100
C1641 QETN1CM-107Z E CAP. 100µF 16V M
C1642 NCB31HK-104X C CAP. 0.1µF 50V K
C1701 QETN1HM-106Z E CAP. 10
C1702 NCB31CK-563X C CAP. 0.056µF 16V K
C1703 QETN1CM-107Z E CAP. 100µF 16V M
C1951 QETN1CM-477Z E CAP. 470
C1952 NCB31CK-104X C CAP. 0.1µF 16V K
C1953 NCB31CK-104X C CAP. 0.1µF 16V K
C1954 QETN1AM-477Z E CAP. 470
C1955 QETN1AM-227Z E CAP. 220µF 10V M
C1956 QETN1AM-107Z E CAP. 100µF 10V M

COIL

L1001 QQL244K-270Z COIL 27µH K
L1002 QQL244K-100Z COIL 10µH K
L1003 QQL244K-100Z COIL 10µH K
L1101 QRN143J-0R0X C R 0.0
L1102 QQL244K-4R7Z COIL 4.7µH K
L1301 NQL092K-1R5X COIL 1.5µH
L1302 NQL092K-1R5X COIL 1.5
L1951 QQL26AM-5R6Z COIL 5.6µH M

DIODE

D1311 MA3051/M/-X ZENER DIODE
D1314 MA111-X SI.DIODE
D1317 MA111-X SI.DIODE
D1318 MA111-X SI.DIODE
D1319 MA3036-X ZENER DIODE
D1320 MA3056/M/-X ZENER DIODE
D1321 MA3056/M/-X ZENER DIODE

µ

F 16V K

µ

F 25V K

µ

F 25V K

µ

F 16V K

µ

F 16V K

µ

F 25V K

µ

F 16V Z

µ

F 16V Z

µ

F 16V Z

µ

F 16V M

µ

F 50V M

µ

F 16V K

µ

F 16V K

µ

F 50V M

µ

F 50V M

µ

F 25V M

µ

F 50V M

µ

F 50V M

µ

F 35V M

µ

F 25V M

µ

F 16V M

µ

F 50V M

µ

F 16V M

µ

F 50V M

µ

F 16V M

µ

F 10V M

Ω

1/4W J

µ

H

No. 52067

53

A

V-28Z25EU

Y

! Symbol No. Part No. Part Name Description

DIODE

D1471 MA111-X SI.DIODE
D1472 MA111-X SI.DIODE
D1473 MA111-X SI.DIODE
D1474 MA111-X SI.DIODE
D1475 MA3240/M/-X ZENER DIODE
D1521 MA111-X SI.DIODE
D1591 MA111-X SI.DIODE
D1592 MA3051/M/-X ZENER DIODE
D1593 MA111-X SI.DIODE
D1601 MA3330/L/-X ZENER DIODE
D1602 MA3330/L/-X ZENER DIODE
D1603 MA3330/L/-X ZENER DIODE
D1604 MA111-X SI.DIODE
D1606 MA111-X SI.DIODE
D1607 MA111-X SI.DIODE
D1608 MA111-X SI.DIODE
D1610 MA111-X SI.DIODE
D1611 MA3330/L/-X ZENER DIODE
D1612 MA3330/L/-X ZENER DIODE
D1613 MA3330/L/-X ZENER DIODE
D1614 MA111-X SI.DIODE
D1615 MA111-X SI.DIODE
D1616 MA111-X SI.DIODE
D1617 MA111-X SI.DIODE
D1618 MA111-X SI.DIODE
D1619 MA111-X SI.DIODE
D1620 MA111-X SI.DIODE
D1621 MA111-X SI.DIODE
D1622 MA111-X SI.DIODE
D1623 MA111-X SI.DIODE
D1624 MA111-X SI.DIODE
D1771 MA3056/M/-X ZENER DIODE
D1772 MA3056/M/-X ZENER DIODE
D1773 MA3056/M/-X ZENER DIODE
D1774 MA3056/M/-X ZENER DIODE
D1775 MA3033-X ZENER DIODE
D1951 1SR35-400A-T2 SI.DIODE
D1981 MA111-X SI.DIODE
D1982 MA111-X SI.DIODE

TRANSISTOR

Q1101 2SC2412K/QR/-X SI.TRANSISTOR
Q1102 2SC2412K/QR/-X SI.TRANSISTOR
Q1301 2SA1037AK/QR/-X SI.TRANSISTOR
Q1471 2SC2412K/QR/-X SI.TRANSISTOR
Q1472 2SC2412K/QR/-X SI.TRANSISTOR
Q1561 2SC2412K/QR/-X SI.TRANSISTOR
Q1562 2SA1037AK/QR/-X SI.TRANSISTOR
Q1591 2SA1037AK/QR/-X SI.TRANSISTOR
Q1592 2SC2412K/QR/-X SI.TRANSISTOR
Q1601 2SA1037AK/QR/-X SI.TRANSISTOR
Q1603 DTC144EKA-X DIGI.TRANSISTOR
Q1605 DTC144EKA-X DIGI.TRANSISTOR
Q1606 2SC2412K/QR/-X SI.TRANSISTOR
Q1608 DTC144EKA-X DIGI.TRANSISTOR
Q1609 2SC2412K/QR/-X SI.TRANSISTOR
Q1611 2SA1037AK/QR/-X SI.TRANSISTOR
Q1612 DTC144EKA-X DIGI.TRANSISTOR
Q1613 DTC144EKA-X DIGI.TRANSISTOR
Q1614 DTC144EKA-X DIGI.TRANSISTOR
Q1615 DTC144EKA-X DIGI.TRANSISTOR
Q1616 2SC2412K/QR/-X SI.TRANSISTOR
Q1617 DTC144EKA-X DIGI.TRANSISTOR
Q1618 2SC2412K/QR/-X SI.TRANSISTOR
Q1620 2SA1037AK/QR/-X SI.TRANSISTOR

IC

IC1101 MSP3415DQGB3GHX IC
IC1301 SDA9380 IC
IC1402 BA10324AF-XE IC
IC1471 BA10358F-XE IC
IC1551 LA6515 I C
IC1601 AN7585 IC
IC1602 AN7585 IC
IC1603 AN78L24-T IC
IC1604 AN78L05-T IC
IC1701 JLC1562BF-X I C
IC1951 BA09T IC
IC1952 BA08T IC

OTHERS

CN1002 QGF1220C2-25 FFC/FPC CONNE
K1001 NQR0389-003X FERRITE BEADS

! Symbol No. Part No. Part Name Description

OTHERS

K1101 NQR0389-003X FERRITE BEADS
K1102 NQR0389-003X FERRITE BEADS
K1301 NQR0413-003X FERRITE BEADS
LC1102 NQR0431-001X EMI FILTER
LC1301 NQR0431-001X EMI FILTER
LC1302 NQR0431-001X EMI FILTER
LC1303 NQR0431-001X EMI FILTER
TU1001 QAU0276-001 TUNER
X1101 CE42546-001Z CRYSTAL
X1501 QAX0549-001Z CRYSTAL

54

No. 52067

A

Y

■■■■POWER & DEF. P.W. BOARD ASS’Y (SMF-2405A)

V-28Z25EU

! Symbol No. Part No. Part Name Description

RESISTOR

R2401 QRE141J-562Y C R 5.6kΩ 1/4W J
R2402 QRE141J-562Y C R 5.6kΩ 1/4W J
R2403 QRE141J-222Y C R 2.2kΩ 1/4W J
R2404 QRX01GJ-1R0 MF R 1.0Ω 1W J
R2405 QRL029J-151 OM R 150
R2406 QRE141J-222Y C R 2.2k
R2407 QRX01GJ-1R5 MF R 1.5Ω 1W J
R2408 QRX01GJ-1R5 MF R 1.5
R2409 QRE141J-823Y C R 82k
R2410 QRE141J-103Y C R 10kΩ 1/4W J
R2421 QRE141J-103Y C R 10k
R2422 QRE141J-274Y C R 270kΩ 1/4W J
R2461 QRG029J-820 OM R 82
R2462 QRE141J-473Y C R 47k
R2463 QRA14CF-9101Y MF R 9.1kΩ 1/4W F
R2464 QRX01GJ-2R7 MF R 2.7Ω 1W J
R2468 QRE141J-102Y C R 1k
R2469 QRE141J-272Y C R 2.7kΩ 1/4W J
R2471 QRE141J-391Y C R 390Ω 1/4W J
R2472 QRA14CF-1002Y MF R 10k
R2473 QRE141J-473Y C R 47k
R2474 QRE141J-103Y C R 10k
R2475 QRE141J-102Y C R 1k
R2476 QRE141J-102Y C R 1kΩ 1/4W J
R2477 QRE141J-563Y C R 56kΩ 1/4W J
R2478 QRE141J-333Y C R 33k
R2501 QRE141J-471Y C R 470Ω 1/4W J
R2502 QRE141J-123Y C R 12kΩ 1/4W J
R2503 QRE121J-152Y C R 1.5k
R2504 QRL039J-272 OM R 2.7kΩ 3W J
R2505 QRL039J-332 OM R 3.3kΩ 3W J
R2506 QRE121J-5R6Y C R 5.6
R2521 QRE121J-471Y C R 470Ω 1/2W J
R2522 QRE141J-223Y C R 22kΩ 1/4W J
R2523 QRE141J-103Y C R 10k
R2524 QRC121K-152Z COMP.R 1.5k
R2525 QRL039J-103 OM R 10kΩ 3W J
R2541 QRE141J-182Y C R 1.8k
R2542 QRE141J-222Y C R 2.2kΩ 1/4W J
R2543 QRE121J-272Y C R 2.7kΩ 1/2W J

! R2551 QRZ9022-R47 F R 0.47
! R2552 QRZ9022-R47 F R 0.47 Ω 1W K

R2581 QRF154K-4R7 UNF R 4.7Ω 15W K
R2582 QRE141J-681Y C R 680
R2583 QRE121J-682Y C R 6.8kΩ 1/2W J
R2584 QRE141J-183Y C R 18kΩ 1/4W J
R2585 QRE141J-222Y C R 2.2k
R2586 QRA14CF-7501Y MF R 7.5kΩ 1/4W F
R2587 QRA14CF-2101Y MF R 2.1kΩ 1/4W F
R2588 QRE141J-103Y C R 10k

! R2591 QRZ9017-4R7 F R 4.7 Ω 1/4W J

R2901 QRE121J-331Y C R 330Ω 1/2W J

! R2902 QRF054K-3R3 UNF R 3.3
! R2903 QRF104K-3R9 UNF R 3.9Ω 10W K

R2904 QRL039J-683 OM R 68kΩ 3W J
R2905 QRE121J-474Y C R 470k
R2906 QRE121J-474Y C R 470kΩ 1/2W J
R2908 QRL039J-823 OM R 82kΩ 3W J
R2909 QRL039J-823 OM R 82k

! R2910 QRE121J-150Y C R 15Ω 1/2W J

R2911 QRE121J-152Y C R 1.5kΩ 1/2W J
R2914 QRM059J-R10 MP R 0.10
R2915 QRE121J-681Y C R 680Ω 1/2W J
R2916 QRE121J-332Y C R 3.3kΩ 1/2W J
R2931 QRE141J-1R0Y C R 1.0
R2932 QRE141J-1R5Y C R 1.5Ω 1/4W J
R2933 QRE141J-1R8Y C R 1.8Ω 1/4W J
R2944 QRE141J-103Y C R 10k
R2945 QRE141J-563Y C R 56kΩ 1/4W J
R2946 QRE141J-103Y C R 10kΩ 1/4W J
R2951 QRE121J-102Y C R 1k
R2952 QRL039J-223 OM R 22kΩ 3W J
R2954 QRE141J-103Y C R 10kΩ 1/4W J
R2959 QRT039J-R68 MF R 0.68
R2961 QRE141J-332Y C R 3.3kΩ 1/4W J
R2963 QRL039J-561 OM R 560Ω 3W J
R2964 QRT039J-1R5 MF R 1.5
R2981 QRE141J-153Y C R 15kΩ 1/4W J
R2982 QRE141J-102Y C R 1kΩ 1/4W J

Ω

2W J

Ω

1/4W J

Ω

1W J

Ω

1/4W J

Ω

1/4W J

Ω

2W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W F

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/2W J

Ω

1/2W J

Ω

1/4W J

Ω

1/2W K

Ω

1/4W J

Ω

1W K

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

5W K

Ω

1/2W J

Ω

3W J

Ω

5W J

Ω

1/4W J

Ω

1/4W J

Ω

1/2W J

Ω

3W J

Ω

3W J

! Symbol No. Part No. Part Name Description

RESISTOR

Ω

! R2991 QRZ9046-825Z C R 8.2M

CAPACITOR

C2404 QCZ0120-104Z C CAP. 0.1µF 25V Z
C2405 QDC31HJ-820Z C CAP. 82pF 50V J
C2406 QETM1VM-108 E CAP. 1000
C2408 QETN1VM-337Z E CAP. 330
C2409 QFV71HJ-474Z MF CAP. 0.47µF 50V J
C2410 QFV71HJ-474Z MF CAP. 0.47
C2411 QFLC2AJ-104Z M CAP. 0.1
C2414 QCB31HK-682Z C CAP. 6800pF 50V K
C2421 QETN1HM-105Z E CAP. 1
C2461 QEZ0414-226 E CAP. 22µF 50V M
C2462 QFM72DJ-152Z M CAP. 1500pF 200V J
C2463 QFM72DJ-152Z M CAP. 1500pF 200V J
C2464 QCZ0120-104Z C CAP. 0.1
C2465 QETN1HM-106Z E CAP. 10
C2466 QFP31HJ-272Z PP CAP. 2700pF 50V J
C2467 QFLC1HJ-102Z M CAP. 1000pF 50V J
C2468 QETN1EM-476Z E CAP. 47
C2470 QCS31HJ-470Z C CAP. 47pF 50V J
C2471 QFLC1HJ-103Z M CAP. 0.01
C2501 QCB32HK-331Z C CAP. 330pF 500V K
C2502 QFM72DK-103 M CAP. 0.01
C2503 QFV71HJ-224Z MF CAP. 0.22µF 50V J

! C2521 QFZ0122-112 MPP CAP. 1100pF1.8kVH±3%
! C2522 QFZ0200-113 MPP CAP. 0.011

C2523 QFM72DK-393 M CAP. 0.039

! C2524 QFP32JJ-223 PP CAP. 0.022µF 630V J

C2526 QFZ0197-184 MPP CAP. 0.18
C2527 QFZ0197-124 MPP CAP. 0.12µF 250V J
C2529 QFZ0197-154 MPP CAP. 0.15µF 250V J
C2530 QCB32HK-561Z C CAP. 560pF 500V K
C2531 QFZ0194-534 MPP CAP. 0.53
C2532 QETM2CM-227 E CAP. 220µF 160V M
C2533 QETN2EM-475Z E CAP. 4.7
C2541 QENC1HM-105Z E CAP. 1
C2551 QCB32HK-152Z C CAP. 1500pF 500V K
C2552 QETN1CM-108Z E CAP. 1000
C2553 QCB32HK-152Z C CAP. 1500pF 500V K
C2554 QETN1CM-108Z E CAP. 1000
C2555 QCB32HK-102Z C CAP. 1000pF 500V K
C2556 QETN2EM-106Z E CAP. 10
C2558 QETN1CM-477Z E CAP. 470µF 16V M
C2559 QEHR1CM-227Z E CAP. 220µF 16V M
C2581 QETN1CM-107Z E CAP. 100
C2582 QETN1EM-476Z E CAP. 47µF 25V M
C2583 QETN2AM-106Z E CAP. 10µF 100V M
C2584 QETN1AM-227Z E CAP. 220

! C2901 QFZ9072-473 MF CAP. 0.047µFAC275V K
! OR QFZ9075-473 MPP CAP. 0.047µFAC275V M
! C2902 QFZ9072-104 MF CAP. 0.1
! OR QFZ9075-104 MPP CAP. 0.1µFAC275V M
! C2903 QFZ9072-473 MF CAP. 0.047µFAC275V K
! OR QFZ9075-473 MPP CAP. 0.047
! C2904 QCZ9054-472 C CAP. 4700pFAC250V Z
! C2905 QCZ9054-472 C CAP. 4700pFAC250V Z
! C2906 QCZ9054-472 C CAP. 4700pFAC250V Z

C2907 QEZ0199-227 E CAP. 220
C2908 QCB32HK-103 C CAP. 0.01µF 500V K
C2909 QCZ0340-391 C CAP. 390pF 2kV K
C2910 QETN1HM-476Z E CAP. 47
C2911 QCB31HK-102Z C CAP. 1000pF 50V K
C2912 QCZ0340-561 C CAP. 560pF 2kV K
C2914 QCB31HK-471Z C CAP. 470pF 50V K
C2915 QFLC1HJ-104Z M CAP. 0.1
C2916 QCB32HK-152Z C CAP. 1500pF 500V K

! C2931 QCZ9054-472 C CAP. 4700pFAC250V Z
! C2932 QCZ9054-472 C CAP. 4700pFAC250V Z
! C2933 QCZ9054-472 C CAP. 4700pFAC250V Z

C2934 QETM2GM-226 E CAP. 22
C2941 QTMN1CM-477Z E CAP. 470
C2942 QETN1AM-337Z E CAP. 330µF 10V M
C2951 QEZ0203-227 E CAP. 220µF 160V M
C2952 QETN1CM-108Z E CAP. 1000
C2954 QETM1VM-338 E CAP. 3300µF 35V M
C2955 QETM1VM-228 E CAP. 2200µF 35V M
C2956 QETN1AM-108Z E CAP. 1000
C2957 QETN1AM-228Z E CAP. 2200µF 10V M
C2959 QFV71HJ-684Z MF CAP. 0.68µF 50V J

1/2W K

µ

F 35V M

µ

F 35V M

µ

F 50V J

µ

F 100V J

µ

F 50V M

µ

F 25V Z

µ

F 50V M

µ

F 25V M

µ

F 50V J

µ

F 200V K

µ

F1.5kVH±3%

µ

F 200V K

µ

F 250V J

µ

F 250V J

µ

F 250V M

µ

F 50V M

µ

F 16V M

µ

F 16V M

µ

F 250V M

µ

F 16V M

µ

F 10V M

µ

FAC275V K

µ

FAC275V M

µ

F 400V M

µ

F 50V M

µ

F 50V J

µ

F 400V M

µ

F 16V M

µ

F 16V M

µ

F 10V M

No. 52067

55

A

V-28Z25EU

Y

! Symbol No. Part No. Part Name Description

CAPACITOR

C2960 QCZ0325-821 C CAP. 820pF 2kV K
C2972 QETN1AM-477Z E CAP. 470
C2973 QETN1AM-477Z E CAP. 470µF 10V M
C2974 QETN0JM-228Z E CAP. 2200µF 6.3V M
C2975 QETN1AM-228Z E CAP. 2200

! C2991 QCZ9079-222 C CAP. 2200pFAC250V M
! C2993 QCZ9079-471 C CAP. 470pFAC250V K

TRANSFORMER

T2501 QQR1111-001 DRIVE TRANSF.

! T2551 QQH0126-001 F.B.TRANSF.
! T2901 QQS0176-001 SW TRANSF

COIL

L2461 QQR1195-001 CHOKE COIL
L2462 QQLZ028-272 INDUCTOR
L2521 QQLZ031-180 INDUCTOR
L2522 QQR1191-002 LINEARITY COIL
L2551 QQLZ026-540 INDUCTOR
L2552 QQL26AK-220Z COIL 22
L2901 QQL401K-100Z COIL 10µH K
L2902 QQL401K-100Z COIL 10
L2903 QQR1200-001 CHOKE COIL
L2951 QQLZ026-460 INDUCTOR
L2959 QQL26AK-220Z COIL 22
L2960 QQL26AK-220Z COIL 22µH K
L2961 QQL26AM-4R7Z INDUCTOR

DIODE

D2402 1SR35-400A-T2 SI.DIODE
D2421 1SS133-T2 SI.DIODE
D2461 RGP10J-5025-T3 SI.DIODE
D2462 1SS133-T2 SI.DIODE
D2463 1SS133-T2 SI.DIODE
D2501 1SS81-T5 SI.DIODE
D2521 V11CA-C1 SI.DIODE
D2522 FMV-3FU-F1 SI.DIODE
D2523 MTZJ22B-T2 ZENER DIODE
D2525 RGP10J-5025-T3 SI.DIODE
D2541 RGP10J-5025-T3 SI.DIODE
D2542 MTZJ3.9B-T2 ZENER DIODE
D2551 RGP10J-5025-T3 SI.DIODE
D2552 RGP10J-5025-T3 SI.DIODE
D2553 RH1S-T3 SI.DIODE
D2582 MTZJ7.5B-T2 ZENER DIODE
D2583 MTZJ7.5S-T2 ZENER DIODE

! D2584 RGP10J-5025-T3 SI.DIODE
! D2901 D3SB60 BRIDGE DIODE

D2902 RG1C-LFA1 SI.DIODE
D2904 EU2A-T2 SI.DIODE
D2905 1SS133-T2 SI.DIODE
D2906 MTZJ27B-T2 ZENER DIODE
D2907 1SS133-T2 SI.DIODE
D2908 1SS133-T2 SI.DIODE
D2910 MTZJ15B-T2 ZENER DIODE
D2911 1SS133-T2 SI.DIODE

! D2931 S1WB/A/60-4101 BRIDGE DIODE

D2945 1SS133-T2 SI.DIODE
D2951 RU4AM-LFT2 SI.DIODE
D2952 RU3YX-LFC4 SI.DIODE
D2953 RU4AM-LFT2 SI.DIODE
D2954 FMX-G12S SI.DIODE
D2955 RU3YX-LFC4 SI.DIODE
D2956 RU3YX-LFC4 SI.DIODE
D2958 MTZJ33B-T2 ZENER DIODE
D2959 RU3YX-LFC4 SI.DIODE
D2960 1SR124-400A-T2 SI.DIODE
D2961 1SS133-T2 SI.DIODE
D2981 1SS133-T2 SI.DIODE
D2984 1SS133-T2 SI.DIODE
D2985 1SS133-T2 SI.DIODE

TRANSISTOR

Q2421 DTC124ESA-T DIGI.TRANSISTOR
Q2422 2SC1740S/QR/-T SI.TRANSISTOR
Q2461 2SK2459N-F54 POWER MOS FET
Q2462 2SC1740S/QR/-T SI.TRANSISTOR
Q2463 2SC1740S/QR/-T SI.TRANSISTOR
Q2464 2SA933AS/QR/-T SI.TRANSISTOR
Q2501 BSN304-T MOS FET

! Q2521 2SC5904-RL POWER TRANSISTOR H.OUT

Q2581 2SA1208/ST/Z1-T SI.TRANSISTOR

µ

F 10V M

µ

F 10V M

µ

H K

µ

H K

µ

H K

! Symbol No. Part No. Part Name Description

TRANSISTOR

Q2582 DTC144ESA-T DIGI.TRANSISTOR
Q2583 2SC1740S/QR/-T SI.TRANSISTOR
Q2941 2SC1740S/QR/-T SI.TRANSISTOR
Q2942 2SC1740S/QR/-T SI.TRANSISTOR

IC

IC2401 AN5523 IC
IC2461 BA10393 IC
IC2551 BA12T IC
IC2901 STR-F6667B/F7 IC

! IC2902 QAL0425-001 POWER MODULE

IC2951 SE140N IC
IC2954 BA05T IC
IC2955 NJM2396F33 IC

OTHERS

! CP2951 ICP-N75-Y I.C.PROTECT
! CP2952 ICP-N75-Y I.C.PROTECT
! CP2953 ICP-N75-Y I.C.PROTECT
! CP2954 QMFZ049-4R0Z-E FUSE 4.0A
! CP2955 ICP-N75-Y I.C.PROTECT

K2401 QQR0621-002Z FERRITE BEADS
K2522 CE41832-001 LEAD CORE
K2523 CE41832-001 LEAD CORE
K2524 CE41832-001 LEAD CORE
K2901 QQR0679-001 FERRITE BEADS

! LF2901 QQR1095-001 LINE FILTER
! PC2901 PC123FY2 IC(PHOTO COUPLE
! RY2931 QSK0099-001 RELAY
! TH2901 QAD0133-9R0 THERMISTOR

56

No. 52067

A

Y

■■■■CRT SOCKET P.W. BOARD ASS’Y (SMF-3407A)

V-28Z25EU

! Symbol No. Part No. Part Name Description

RESISTOR

R3101 NRSA63J-223X MG R 22kΩ 1/16W J
R3102 NRSA63J-681X MG R 680Ω 1/16W J
R3103 NRSA63J-101X MG R 100
R3104 NRSA63J-822X MG R 8.2kΩ 1/16W J
R3105 NRSA63J-102X MG R 1kΩ 1/16W J
R3106 NRSA63J-221X MG R 220
R3107 NRSA63J-561X MG R 560Ω 1/16W J
R3109 NRSA63J-153X MG R 15k
R3110 NRSA63J-222X MG R 2.2k
R3111 NRSA63J-471X MG R 470Ω 1/16W J
R3112 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3113 NRSA63J-152X MG R 1.5k
R3114 NRSA63J-152X MG R 1.5k
R3115 NRSA63J-390X MG R 39
R3116 QRG01GJ-101 OM R 100
R3117 NRSA63J-331X MG R 330Ω 1/16W J
R3122 NRSA63J-122X MG R 1.2kΩ 1/16W J
R3123 QRE121J-563Y C R 56k
R3124 NRSA63J-470X MG R 47
R3125 QRE121J-563Y C R 56kΩ 1/2W J
R3126 NRSA63J-470X MG R 47
R3127 NRSA63J-122X MG R 1.2kΩ 1/16W J
R3128 NRSA63J-390X MG R 39Ω 1/16W J
R3129 QRE121J-2R7Y C R 2.7
R3130 QRE121J-2R7Y C R 2.7Ω 1/2W J
R3131 NRSA63J-390X MG R 39Ω 1/16W J
R3132 NRSA63J-121X MG R 120
R3133 QRL029J-681 OM R 680Ω 2W J

! R3134 QRZ9021-561 F R 560 Ω 1W J

R3204 NRSA63J-272X MG R 2.7k
R3205 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3206 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3211 NRSA63J-154X MG R 150k
R3223 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3224 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3225 NRSA63J-272X MG R 2.7k
R3227 NRSA63J-103X MG R 10kΩ 1/16W J
R3228 NRSA63J-272X MG R 2.7kΩ 1/16W J
R3229 QRL029J-104-F OM R 100k
R3230 QRL029J-104-F OM R 100kΩ 2W J
R3231 QRL029J-104-F OM R 100kΩ 2W J
R3232 NRSA63J-332X MG R 3.3k
R3233 NRSA63J-332X MG R 3.3kΩ 1/16W J
R3234 NRSA63J-332X MG R 3.3kΩ 1/16W J
R3235 QRC121K-152Z COMP.R 1.5k
R3236 QRC121K-152Z COMP.R 1.5kΩ 1/2W K
R3237 QRC121K-152Z COMP.R 1.5kΩ 1/2W K
R3239 QRZ0107-474Z C R 470k
R3240 QRC121K-102Z COMP.R 1kΩ 1/2W K
R3241 QRZ0107-105Z C R 1.0MΩ 1/2W K
R3242 NRSA63J-103X MG R 10k
R3244 NRSA63J-102X MG R 1kΩ 1/16W J
R3245 NRSA63J-562X MG R 5.6kΩ 1/16W J
R3246 NRSA63J-562X MG R 5.6k
R3247 NRSA63J-562X MG R 5.6kΩ 1/16W J
R3301 QRE121J-474Y C R 470kΩ 1/2W J
R3302 QRE121J-474Y C R 470k
R3303 NRSA63J-223X MG R 22kΩ 1/16W J
R3304 NRSA63J-223X MG R 22kΩ 1/16W J
R3305 NRSA63J-562X MG R 5.6k
R3306 NRSA63J-392X MG R 3.9kΩ 1/16W J
R3310 NRSA63J-0R0X MG R 0.0Ω 1/16W J

CAPACITOR

C3102 NDC31HJ-6R0X C CAP. 6.0pF 50V J
C3103 NDC31HJ-390X C CAP. 39pF 50V J
C3104 QCB31HK-103Z C CAP. 0.01
C3106 QETN1HM-335Z E CAP. 3.3µF 50V M
C3107 QETN1CM-107Z E CAP. 100µF 16V M
C3110 QETN2CM-106Z E CAP. 10
C3111 QCB32HK-472Z C CAP. 4700pF 500V K
C3113 QETN2CM-106Z E CAP. 10
C3114 QCB32HK-472Z C CAP. 4700pF 500V K
C3116 QETN1AM-107Z E CAP. 100
C3117 QETN1AM-107Z E CAP. 100
C3118 QETN1AM-337Z E CAP. 330µF 10V M
C3120 NDC31HJ-221X C CAP. 220pF 50V J
C3121 NDC31HJ-221X C CAP. 220pF 50V J
C3201 NDC31HJ-100X C CAP. 10pF 50V J
C3202 NDC31HJ-100X C CAP. 10pF 50V J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

2W J

Ω

1/16W J

Ω

1/2W K

Ω

1/2W K

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

µ

F 50V K

µ

F 160V M

µ

F 160V M

µ

F 10V M

µ

F 10V M

! Symbol No. Part No. Part Name Description

CAPACITOR

C3203 NDC31HJ-100X C CAP. 10pF 50V J
C3204 NCF31CZ-104X C CAP. 0.1
C3205 NCF31CZ-104X C CAP. 0.1µF 16V Z
C3206 NCF31CZ-104X C CAP. 0.1µF 16V Z
C3207 QETN1EM-476Z E CAP. 47
C3208 QETN1EM-476Z E CAP. 47µF 25V M
C3209 QETN1EM-476Z E CAP. 47
C3210 QFK62EK-104Z MM CAP. 0.1µF 250V K
C3211 QFK62EK-104Z MM CAP. 0.1
C3212 QFK62EK-104Z MM CAP. 0.1
C3213 NDC31HJ-181X C CAP. 180pF 50V J
C3214 NDC31HJ-181X C CAP. 180pF 50V J
C3215 NDC31HJ-181X C CAP. 180pF 50V J
C3216 QETN1CM-107Z E CAP. 100
C3218 QETM2EM-336 E CAP. 33
C3219 QFZ0097-223 MM CAP. 0.022
C3221 QETN2EM-106Z E CAP. 10µF 250V M
C3302 QETN1HM-476Z E CAP. 47

COIL

L3101 QQL244K-5R6Z COIL 5.6µH K
L3204 QQL26AJ-102Z COIL 1mH J

DIODE

D3101 MA111-X SI.DIODE
D3102 MA111-X SI.DIODE
D3103 RH1S-T3 SI.DIODE
D3104 RH1S-T3 SI.DIODE
D3204 EU01N-T2 SI.DIODE
D3205 EU01N-T2 SI.DIODE
D3206 EU01N-T2 SI.DIODE
D3207 RM2C-LFA1 SI.DIODE
D3208 1SR124-400A-T2 SI.DIODE
D3209 1SR124-400A-T2 SI.DIODE
D3210 1SR124-400A-T2 SI.DIODE
D3211 MA3062/M/-X ZENER DIODE
D3301 MA111-X SI.DIODE
D3303 MA111-X SI.DIODE

TRANSISTOR

Q3101 2SC2412K/QR/-X SI.TRANSISTOR
Q3102 2SA1037AK/QR/-X SI.TRANSISTOR
Q3103 2SC1906-T SI.TRANSISTOR
Q3104 2SC2412K/QR/-X SI.TRANSISTOR
Q3105 2SC1627A/OY/-T SI.TRANSISTOR
Q3108 2SA1837 POWER TRANSISTO
Q3109 2SC4793 POWER TRANSISTO
Q3301 2SA1037AK/QR/-X SI.TRANSISTOR

IC

IC3201 TDA6111Q I C
IC3202 TDA6111Q I C
IC3203 TDA6111Q I C

OTHERS

K3101 CE41492-001Z CHOKE COIL
K3103 CE41492-001Z CHOKE COIL
K3104 CE41492-001Z CHOKE COIL
K3105 QQR0621-002Z FERRITE BEADS
SG3201 QAF0056-501Z SURGE ABSORBER
SG3202 QAF0056-501Z SURGE ABSORBER
SG3203 QAF0056-501Z SURGE ABSORBER

! SK3001 QNZ0464-001 CRT SOCKET

W3003 QQR0679-001 FERRITE BEADS
W3022 QQR0679-001 FERRITE BEADS

µ

F 16V Z

µ

F 25V M

µ

F 25V M

µ

F 250V K

µ

F 250V K

µ

F 16V M

µ

F 250V M

µ

F 1250V K

µ

F 50V M

No. 52067

57

A

V-28Z25EU

Y

■■■■FRONT CONTROL P.W. BOARD ASS’Y

(SMF-8405A)

Refer to PARTS LIST in page 43 for this P.W . board.

■■■■SIDE CONTROL P.W. BOARD ASS’Y
(SMF-8105A)

! Symbol No. Part No. Part Name Description

RESISTOR

R8001 QRE121J-271Y C R 270Ω 1/2W J
R8002 QRE121J-271Y C R 270
R8007 NRSA63J-103X MG R 10kΩ 1/16W J
R8010 NRSA63J-103X MG R 10k
R8012 NRSA63J-103X MG R 10kΩ 1/16W J
R8013 NRSA63J-103X MG R 10k
R8021 NRSA63J-102X MG R 1k
R8022 NRSA63J-102X MG R 1kΩ 1/16W J

CAPACITOR

C8001 NCB31HK-103X C CAP. 0.01µF 50V K
C8002 NCB31HK-103X C CAP. 0.01
C8003 NDC31HJ-680X C CAP. 68pF 50V J
C8010 NCB31HK-472X C CAP. 4700pF 50V K
C8011 NCB31HK-472X C CAP. 4700pF 50V K
C8021 NCB31CK-104X C CAP. 0.1

COIL

L8001 QQR0716-001Z FERRITE BEADS
L8002 QQL244K-5R6Z COIL 5.6µH K
L8003 QQL244K-5R6Z COIL 5.6
L8010 QQL244K-270Z COIL 27µH K
L8011 QQL244K-270Z COIL 27µH K
L8012 QQR0716-001Z FERRITE BEADS

DIODE

D8010 SPR-39MVWF LED
D8011 MA111-X SI.DIODE
D8014 MA3068/M/-X ZENER DIODE

OTHERS

J8001 QMS3001-C01 3.5 JACK
J8003 QNZ0438-001 AV JACK
LC8002 NQR0169-001X EMI FILTER
S8001 QSW0619-003Z TACT SWITCH MENU
S8002 QSW0619-003Z TACT SWITCH CH DOWN
S8003 QSW0619-003Z TACT SWITCH CH UP

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

µ

F 50V K

µ

F 16V K

µ

H K

■■■■DOLBY P.W. BOARD ASS’Y (SMF-0D401A)

Refer to PARTS LIST in page 44 for this P.W . board.

■■■■MICOM P.W. BOARD ASS’Y (SMF-0M403A)

Refer to PARTS LIST in page 47 for this P.W . board.

■■■■AV SW P.W. BOARD ASS’Y (SMF-0S402A)

Refer to PARTS LIST in page 48 for this P.W . board.

■■■■100Hz P.W. BOARD ASS’Y (SMF-0Z404A)

Refer to PARTS LIST in page 50 for this P.W . board.

58

No. 52067

PAC KING

5

AV-32Z25EUY
AV-28Z25EUY

3

4

6

!

!

!

7

8 9

10

11

1

3

2

PAC KING PARTS LI ST

[ AV-32Z25EUY ]

! Ref.No. Part No. Part Name Description

1 LC10101-017A PACKING CASE
2 AEM1064-030-E EURO LABEL
3 LC11361-001C CUSHION ASSY 4pcs in 1set
4 RM-C58H-1C REMOCON UNIT
5 AEM1047-A02-E POLY BAG
6 AEM3021-003A-E POLY BAG

! 7 LCT1242-001A-U INST BOOK ENG/DEU/FRA/NED/CAS/ITA/POR
! 8 LCT1243-001A-U INST BOOK Northern Europe

! 9 LCT1244-001A-U INST BOOK Eastern Europe

10 BT-54013-4E WARRANTY CARD
11 2832Z25EU-HSAE S.DIAGRAM [ITALY EDITION]

[ AV-28Z25EUY ]

! Ref.No. Part No. Part Name Description

1 LC10101-016A PACKING CASE
2 AEM1064-031-E EURO LABEL
3 LC11318-002C CUSHION ASSY 4pcs in 1set
4 RM-C58H-1C REMOCON UNIT
5 AEM1047-A02-E POLY BAG
6 AEM3021-003A-E POLY BAG

! 7 LCT1242-001A-U INST BOOK ENG/DEU/FRA/NED/CAS/ITA/POR
! 8 LCT1243-001A-U INST BOOK Northern Europe

! 9 LCT1244-001A-U INST BOOK Eastern Europe

10 BT-54013-4E WARRANTY CARD
11 2832Z25EU-HSAE S.DIAGRAM [ITALY EDITION]

No. 52067

59

VICTOR COMP ANY OF J APAN, LIMITED

HOME AV NETWORK BUSINESS UNIT 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama, Kanagawa-prefecture, 221-8528, Japan

4

Printed in Japan
0209 WPC
DP8061
