JVC AV-28R4SK, AV-28T4BK, AV-28T4BR, AV-28T4SK, AV-28T4SP Schematics

...
SCHEMATIC DIAGRAMS
COLOUR TELEVISION
YA06020042
AV-28R4SK, AV-28T4BK, AV-28T4SK,
AV-28T4SP, AV-28T4BR, AV-28T4SR,
AV-28T77SK, AV-32R4SK, AV-32T4SK,
1
4
7
P
TV OK
P
/L
.T
F
TV
CD-ROM No.SML200403
BASIC CHASSIS
JW
2
3
5
6
8
9
0
AV
MENU
AV-28R4SK, AV-28T4BK, AV-28T4SK, AV-28T4SP, AV-28T4BR, AV-28T4SR, AV-32R4SK, AV-32T4SK, AV-32T4SP, AV-32T4SR
AV-28T77SK AV-32T77SK
COPYRIGHT © 2004 VICTOR COMPANY OF JAPAN, LIMITED
No.YA060
2004/2
AV-28R4SK, AV-28T4BK, AV-28T4SK, AV-28T4SP, AV-28T4BR, AV-28T4SR AV-28T77SK, AV-32R4SK, AV-32T4SK, AV-32T4SP, AV-32T4SR, AV-32T77SK
STANDARD CIRCUIT DIAGRAM
NOTE ON USING CIRCUIT DIAGRAMS
1.SAFETY
The components identified by the symbol and shading are critical for safety. For continued safety replace safety ciritical components only with manufactures recommended parts.
2.SPECIFIED VOLTAGE AND WAVEFORM VALUES
The voltage and waveform values have been measured under the following conditions.
(1)Input signal : Colour bar signal (2)Setting positions of
each knob/button and variable resistor
(3)Internal resistance of tester (4)Oscilloscope sweeping time
(5)Voltage values
Since the voltage values of signal circuit vary to some extent according to adjustments, use them as reference values.
: Original setting position when shipped
: DC 20k : H : V
: Othters
: All DC voltage values
/V
20µs / div 5ms / div
Sweeping time is specified
3.INDICATION OF PARTS SYMBOL [EXAMPLE]
In the PW board
: R1209
R209
Type
No indication
MM PP MPP MF TF BP
TAN
(3)Coils
No unit Others
(4)Power Supply
Respective voltage values are indicated
(5)Test point
: Test point
(6)Connecting method
: Ceramic capacitor : Metalized mylar capacitor
: Polypropylene capacitor : Metalized polypropylene capacitor : Metalized film capacitor : Thin film capacitor : Bipolar electrolytic capacitor : Tantalum capacitor
: [µH] : As specified
: B1
: 9V
: Connector
: Receptacle
: B2 (12V
: 5V
: Only test point display
: Wrapping or soldering
)
4.INDICATIONS ON THE CIRCUIT DIAGRAM
(1)Resistors
Resistance value
No unit :[
K M
Rated allowable power No indication : 1/16 [W] Others : As specified
Type
No indication
OMR
MFR
MPR
UNFR
FR
Composition resistor 1/2 [W] is specified as 1/2S or Comp.
(2)Capacitors
Capacitance value 1 or higher : [pF]
less than 1
Withstand voltage
No indication : DC50[V]
Others : DC withstand voltage [V]
AC indicated Electrolytic Capacitors
47/50[Example]: Capacitance value [µF]/withstand voltage[V]
]
: [k
]
]
: [M
: Carbon resistor : Oxide metal film resistor : Metal film resistor : Metal plate resistor : Uninflammable resistor : Fusible resistor
: [µF]
: AC withstand voltage [V]
(7)Ground symbol
: LIVE side ground : ISOLATED(NEUTRAL) side ground : EARTH ground : DIGITAL ground
5.NOTE FOR REPAIRING SERVICE
This model's power circuit is partly different in the GND. The difference of the GND is shown by the LIVE : ( ) side GND and the ISOLATED(NEUTRAL) : ( ) side GND. Therefore, care must be taken for the following points.
(1)Do not touch the LIVE side GND or the LIVE side GND and the ISOLATED(NEUTRAL) side GND simultaneously. if the above caution is not respected, an electric shock may be caused. Therefore, make sure that the power cord is surely removed from the receptacle when, for example, the chassis is pulled out.
(2)Do not short between the LIVE side GND and ISOLATED(NEUTRAL side GND or never measure with a measuring apparatus measure with a measuring apparatus ( oscilloscope, etc.) the LIVE side GND and ISOLATED(NEUTRAL) side GND at the same time. If the above precaution is not respected, a fuse or any parts will be broken.
Since the circuit diagram is a standard one, the circuit and circuit constants may be subject to change for improvement without any notice.
NOTE Due improvement in performance, some part numbers show in the circuit diagram may not agree with those indicated in the part list. When ordering parts, please use the numbers that appear in the Parts List.
No.YA060 2-1
)
CONTENTS
SEMICONDUCTOR SHAPES ...................................................................... 2-2
BLOCK DIAGRAM ........................................................................................ 2-3
CIRCUIT DIAGRAMS .................................................................................... 2-7
MAIN PWB CIRCUIT DIAGRAM ................................................................................................................ 2-7
CRT SOCKET PWB CIRCUIT DIAGRAM ................................................................................................. 2-13
AV JACK PWB CIRCUIT DIAGRAM ......................................................................................................... 2-15
POWER & DEF PWB CIRCUIT DIAGRAM ............................................................................................... 2-17
FRONT CONTROL PWB CIRCUIT DIAGRAM .......................................................................................... 2-19
SIDE CONTROL PWB CIRCUIT DIAGRAM ............................................................................................. 2-21
DOLBY PWB CIRCUIT DIAGRAM ............................................................................................................ 2-23
PATTERN DIAGRAMS .............................................................................. 2-25
MAIN PWB PATTERN .............................................................................................................................. 2-25
POWER & DEF PWB PATTERN ............................................................................................................... 2-27
AV JACK PWB PATTERN ........................................................................................................................ 2-29
CRT SOCKET PWB PATTERN ................................................................................................................. 2-29
FRONT CONTROL PWB PATTERN ......................................................................................................... 2-30
SIDE CONTROL PWB PATTERN ............................................................................................................. 2-30
DOLBY PWB PATTERN ........................................................................................................................... 2-31
USING P.W. BOARD
PWB ASS'Y name AV -28R4SK A V-28T4BK A V-28T4SK AV -28T4SP A V-28T4BR A V-28T4SR AV-28T77SK A V-32R4SK A V-32T4SK AV -32T4SP A V-32T4SR AV-32T77SK
MAIN P.W. BOARD SJW-1902A-U2 SJW-1906A -U2
CRT SOCKET P.W. BOARD SJW-3002A-U2
AV JACK P.W. BOARD SJW0J001A-U2
POWER & DEF P.W. BOARD SJW-2004A-U2 SJW-2002A -U2
FRONT CONTROL P.W. BOARD SJW-8001A-U2
SIDE CONTROL P.W. BOARD SJW-8101A- U2
DOLBY P.W. BOARD SJW0D001A-U2 - - - - - - SJW0D001A-U2 - - - -
←←←←←← ←←←←←←←←←←←
←←←←←←←←←←← ←←←←←←←←←←←
SJW-1002A-U2
←←←←←
←←
SJW-1904A-U2 SJW-1901A -U2 SJW-1905A- U2 SJW-1001A -U2
SJW-3001A-U2
SJW-2003A-U2 SJW-2001A -U2
SJW-1903A-U2
←←←←
←←←

SEMICONDUCTOR SHAPES

TRANSISTOR
BOTTOM VIEW FRONT VIEW TOP VIEW
CHIP TR
E C B
ECB
IC
BOTTOM VIEW FRONT VIEW TOP VIEW
OUT E IN
IN OUTE
CHIP IC
N
N
B
(G)E(S)C(D)
TOP VIEW
1 N
1
ECB
ECB
1
1 N
C
BE
N
2-2
N
1
N
N
No.YA060
BLOCK DIAGRAM
[AV-28T4BK, AV-28T4SK, AV-28T4SP, AV-28T4BR, AV-28T4SR, AV-28T77SK, AV-32T4SK, AV-32T4SP, AV-32T4SR, AV-32T77SK]
EXT-1
EXT-2
TU101
TUNER
LTV/RTV
TV OUT
L2/R2 OUT
V2 OUT
R1/G1/B1
V1
L1/R1
R2/G2/B2
V2
Y2/C2
L2/R2
V3
SF101
SAW FILTER
SF102
SAW FILTER
IC201
R1/G1/B1
R2/G2/B2
AV SW
MAIN CPU/TELETEXT DECODE/IF PROCESS/MULTISOUND PROCESS/
IC701
VIF
SIF
LTV/RTV
TV OUT
Y/C
V1
L/R
VIDEO PROCESS/RGB PROCESS/SYNC. SEP./DEF. PROCESS
VIDEO IF/AGC/AFT
VIDEO AMP
QSS SOUND IF/
AGC/
AM DEMODULATOR/
STEREO DECODER
V
VIDEO SW/
VIDEO FILTER
KEY
REMOCON
RGB INSERT
C
Y
CPU/ TELETEXT DECODER/ DSP
AUDIO SELECT
ADC/DAC
DECODER/
DELAY
SERIAL
L/R
RGB MATRIX/
RGB CONTROL
VELOCITY SCAN MODULATION
H/V SYNC SEP./
H OSC. & DRIVE
V DRIVE
IC606
D-A CONVERTER
R/G/B
VM
V OUT
H OUT
L/R
MAIN PWB
IC802
AUDIO OUT
L/R
SIDE CONTROL
CRT SOCKET
PWB
IC3101
RGB OUT
Q3304 Q3305 Q3306 Q3309 Q3310
VM AMP
HEAD
PHONE
CRT
VM COIL
SPEAKER L
SPEAKER R
PWB
V2
EXT-3
EXT-4
AC IN
Y3/C3
L3/R3
AV JACK PWB
V4
L4
R4
KEY
SIDE
CONTROL
PWB
IC8851
REMO-CON
RECEIVER
REMOCON
Y/C
FRONT
CONTROL
PWB
L1/R1
L2/R2
D901
POWER & DEF PWB
T901
DY01
IC401
V.OUT
V
Q521
H.OUT
H
T551
HVT
B1
SCREEN
EHT
FOCUS2
FOCUS1
DEF YOKE
POWER SW
FUSE
LF8901
No.YA060 No.YA060
2-42-3
BLOCK DIAGRAM
[AV-28R4SK, AV-32R4SK]
EXT-1
EXT-2
EXT-3
EXT-4
TU101
TUNER
LTV/RTV
TV OUT
R1/G1/B1
V1
L1/R1
R2/G2/B2
V2
Y2/C2
L2/R2
L2/R2 OUT
V2 OUT
V3
Y3/C3
L3/R3
AV JACK PWB
V4
L4
R4
SF101
SAW FILTER
SF102
SAW FILTER
IC201
Y/C
R1/G1/B1
R2/G2/B2
AV SW
L1/R1
L2/R2
MAIN CPU/TELETEXT DECODE/IF PROCESS/MULTISOUND PROCESS/
IC701
VIF
SIF
LTV/RTV
TV OUT
Y/C
V1
VIDEO PROCESS/RGB PROCESS/SYNC. SEP./DEF. PROCESS
VIDEO IF/AGC/AFT
VIDEO AMP
QSS SOUND IF/
AGC/ AM DEMODULATOR/ STEREO DECODER
V
VIDEO SW/
VIDEO FILTER
KEY
REMOCON
RGB INSERT
C
Y
CPU/ TELETEXT DECODER/ DSP
AUDIO SELECT
ADC/DAC
DECODER/
DELAY
RGB MATRIX/
RGB CONTROL
VELOCITY SCAN MODULATION
H/V SYNC SEP./
H OSC. & DRIVE
V DRIVE
R/G/B
VM
V OUT
H OUT
MAIN PWB
C
SL/SR
SW
FRONT(MAIN)/WOOFER AUDIO OUT
L/R
IC801
REAR/CENTER AUDIO OUT
IC802
CENTER SPEAKER
WOOFER
L/R
SIDE CONTROL
CRT SOCKET
PWB
IC3101
RGB OUT
Q3304 Q3305 Q3306 Q3309 Q3310
VM AMP
SPEAKER L
SPEAKER
HEAD
PHONE
R
CRT
VM COIL
PWB
V2
IC201-IC203
L/R
IC101
DIGITAL AUDIO CODEC
DOLBY SURROUND DECODER
AMP
IC102
L/R
C
SW
SL/SR
IC303
TONE/VOL CONTROL
SW
SL/SR
IC501
AMP
L/R
IC304
C
L.R/CENTER SW
DOLBY PWB
L
AUDIO OUT
R
REAR
L
SPEAKER
R
OUT
AC IN
KEY
SIDE
CONTROL
PWB
IC8851
REMO-CON
RECEIVER
POWER SW
REMOCON
FUSE
IC401
V.OUT
T551
FRONT
POWER & DEF PWB
HVT
CONTROL
PWB
B1
LF8901
No.YA060 No.YA060
D901
2-5 2-6
T901
SCREEN
EHT
FOCUS2
FOCUS1
DY01
V
Q521
H.OUT
H
DEF YOKE

CIRCUIT DIAGRAMS

MAIN PWB CIRCUIT DIAGRAM (1/3)
MODE PIN NO.
IC 701 1 0 2 0 3 2 4 3.3 5 3.2 6 0 7 3.2 8 0 9 3.2 10 4.1 11 4.2 12 0 13 0 14 2.6 15 4.8 16 1.9 17 2.2 18 0 19 2.3 20 2.3 21 3.7 22 0.9 23 1 24 1.9 25 1.9 26 2.4 27 1.9 28 0 29 1.9 30 1.9 31 3 32 3.4 33 0 34 2.2 35 2.2 36 3.6 37 3.6 38 2.2 39 2 40 0 41 2.2 42 1.6 43 2.7 44 2.8 45 8.1 46 2 47 4.8 48 1.9 49 2.2 50 2.2 51 1.8 52 1.5 53 2.2 54 2.2 55 1.4 56 2.2 57 2.2 58 1.4 59 0 60 3.6 61 3.6 62 3.6 63 3.5 64 2 65 2 66 0.3 67 1.3 68 0 69 4.8 70 1.2 71 1.2 72 1.2 73 2 74 1.8 75 0 76 0 77 0 78 1.2 79 1.2 80 1.2 81 0 82 4.8 83 3.5 84 3.3 85 1.7 86 1.7 87 1.7 88 3.2 89 0 90 3.3 91 1.6 92 0 93 1.9 94 3.3
DC (V
MODE
)
PIN NO.
95 0 96 1.9 97 3.2 98 0 99 0 100 2 101 0.1 102 1.6 103 3.3 104 0 105 0 106 3.3 107 0.1 108 5.2 109 5.2 110 3.3 111 3.2 112 0 113 3.2 114 3.3 115 0.1 116 3.3 117 2 118 2 119 3.3 120 1.5 121 0 122 0 123 3.3 124 2 125 0 126 3.3 127 0 128 3.3 IC 702 1 0 2 0 3 0 4 0 5 3.2 6 3.2 7 0 8 3.3 Q 101 E 1.8 C 9 B 2.5 Q 102 E 0 C 5.8 B 0 Q 301 E 4.7 C -2.5 B 4.8 Q 302 E 1.3 C 4.5 B 2 Q 702 E 0 C 0 B 0 Q 703 E 0 C 4.5 B 0 Q 704 E 4.1 C 4.8 B 4.8 Q 707 E 2 C 2.8 B 2.5 Q 708 E 2 C 2.7 B 2.5 Q 709 E 3.5 C 2 B 2.8 Q 710 E 3.5 C 2 B 2.8 Q 711 E 0 C 3.3 B 0 Q 712 E 4.6 C 0 B 4.8
DC (V
)
R771
4.7k
TU101
*
TUNER
SDA
SCL
ADRS
AGC
TP-IF
IF
R107 75
NC
BT
NC
C101 .01
BP
MB
NC
R101 10k
C103 .1
C106 OPEN
R769 R767 47k 3.9
Q707
*1
C105 OPEN
22.0022
C102 10
C104 1000
C108C107
/10CH/16
/50
IC701
R775
0
R770 47k
1/2W 1/2W
Q708 *1
Q709 2SA562TM/Y/-T
L101
10
QQL244K-100Z
/50
L102
27
QQL244K-270Z
R102
100
R103
100
R104
100
R105 82k
CN0C1
QGA2501F1-06
SJW-1906A SJW-1905A SJW-1904A SJW-1903A SJW-1002A SJW-1902A
SJW-1901A
SJW-1001A
AT24C16-
AT24C16­28R4SK
28T4SP
IC702 *
A0
VCC
A1
WP
A2
SCL
VSS
SDA
R773
D706
*3
2.2k
C779
.1
Q712
/16
*2
RESET
R774 100k
R768
3.9
C777
.22
Q710
2SA562TM/Y/-T
1.8V2
1.8V1
QQL244K-4R7Z
R108
4.7k
C118
.0047
R119
2.2k
MAIN PWB ASSY(1/3) SJW-1902A-U2: AV-28R4SK SJW-1906A-U2: AV-28T4BK, AV-28T4SK SJW-1002A-U2: AV-28T4SP, AV-28T4BR, AV-28T4SR SJW-1904A-U2: AV-28T77SK SJW-1901A-U2: AV-32R4SK SJW-1905A-U2: AV-32T4SK SJW-1001A-U2: AV-32T4SP, AV-32T4SR SJW-1903A-U2: AV-32T77SK
R750
/16
L103
4.7
C109 OPEN
100
C778 OPEN
D712
1SR35-400A-T2
D711
EC30HA03L-X
Y101 OPEN
C110 .0047
R111 33
C772 .1
R749
100
1.5
L104
QQL244K-1R5Z
/16
Q711 *1
RESET
R106
15
CF101
*
R112 330
Q101
2SC5083/L-P/-T
AMP R110
68
C111
.0047
220
220
R765
R766
SDA1
SCL1
SF101
QAX0531-001
C112 OPEN
C113 .0047
R115
2.2k
220
R764
SCL0
32V
R114
4.7k
220
R763
SDA0
9V
R113
VGUARD
*
D101
*
Q102
*
SW
8V
GND
GND
8V
UDZS2.0B-X
UDZS2.0B-X
D714
D713
C114
*
C115
.0047
STB3.3V
SF102
Y102
MAIN PWB(2/3) MAIN PWB(3/3)
I2SWS
10k
D/A_RST
R723R724R726
P01/I2SDo1
Audio3InL
/10
.47
C719
*100220
L/R_CENT
R722 100
P02/I2SDo2
Audio3InR
CHCH
C721C720 47p47p
I2SCLK
M_CV/Y
M_CV/Y
/16
C746
.22
R707R706
**
VssC2
P04/I2SWs
P03/I2SClk
Y3/CvbsC3AudOutLsL
/16
.01
.01
C723
MAIN_L
MAIN_R
C722
DIG1
L710
*6
V1.8C2
AudOutLsR
R705R704 OPENOPEN
R721 R720
100 15k
P11/TO
P10/Int1
AudOutHpR
AudOutHpL
REMOCON
IntO
V1.8ADC
VssADC
V3.3A2
V1.8A
V3.3RefAdP
RefAdN
V3.3A1
INSSW3
Vout/Swo1
Uout/INSSW2
Yin/G2/Y
Uin/B2/Pb
Vin/R2/Pr
V5Comb
VssComb
CVBSO/PIP
GndA
RefAd
Rout
BLKIN
V5P3
B3/Pb
G3/Y
R3/Pr
Ysync
Hout
FbiSo
Bout
Gout
Gnd3
Yout
R751
220
R753
10k
R308
Q301
*2
FLASH
D302 D303
*3 *3
CH
R752
10k
0
C306
220
C301C302 10p10p
R754 27k
D705
*3
Q703
*1
D704 MA8068/M/-X
/10
CHCH
SJW-1002A SJW-1902A
SJW-1001A
QAU0345
TU101
-001 -001
QAX0619
CF101
-001
QAX0621
SF102
-001
UN2212-X
Q102
1SS356-X
D101 R113 R740
.0047
C114 Y102
SJW-1906A SJW-1905A
SJW-1904A SJW-1903A SJW-1002A SJW-1902A
SJW-1001A
R706 R707 R723 R781 R782 R783 R784
1/6.3
C701
1/6.3
C702 C782 C783
Q704
*1
R758 10k
R309 OPEN
C303
220 /16
SJW-1905A SJW-1906A SJW-1904A SJW-1903A
SJW-1901A
QAU0344
OPEN
QAX0795
-001
OPEN OPEN
2.2k
OPEN
100 OPEN
OPEN
OPEN
SJW-1901A
100
OPEN
100
OPEN
OPEN
100
3.3k
OPEN
10k
47p
3.3k OPEN 10k
47p OPEN OPEN
1/10
R760
1k
R757 10k
C304
.01
CN008
QGA2501C5-07Z
12V GND Ik B G R VM
CRT SOCKET PWB
0
0 01/10
C773 1/10 80%
AV_LINK
Q702
*1
R755
R756
47k
1k
LINK_OUT LINK_IN
L709
*6
C745
/16
.22
C744
12V
/16
100
C743
/16
.1
C740
.1
/16
C738
.22
BCL
C784 10
C724
/16
.1
L708
*6
C742
.22
/16
L707
*6
C739 100
/16
L706
C741 .22
*6
/16
L705 *6
C737
/16
100
/16
/50
R717
CH
R719
100
100
R304
100
R303
100
R302
1k
R301
C736 560p
C735
.1
C734 .1
C732
C731
C730
100
C729
C728
C727
C726
ABL
R713
MA111-X
2.7k
/16
L704
C733
*6
10
/50
/16
/16
.1
SC_B2
/16
.1
SC_G2
SC_R2
/16
.1
SC_YS2
SC_YS1VD-
/16
.1
SC_G1
/16
.1
SC_B1
/16
.1
SC_R1
/16
.1
C725
L703
10
/50
*6
HD
100
R712
10k
R711
HFLB
12k
R710
1k
R709
R305
0
NRSA02J-0R0X
R314
470 470
D304
R306
*3
1k
R307
10
D301
*3
C305 10p
R313
47
Q302
*1
R315
SC_R1
5V
L
R
32V
12V
12V
9V
*
*
LTV
9V
32V
SIF1
SIF2
RTV
LRLTV
RTV
VD+
POW_DET
C753
/16
.22
L714
*6
L715
*6
R786
L716
22
*6
R745 100
L717
*6
C759 D707
2.2
/6.3
C762
L718
.1
/16
*6
C763
100
/16
C764
2.2
/50
EW
VD+
GND
VD+
VD-
VD-
KEY
C754
/16
.22
/16
C756
100
C757
7p
C758
7p
QAX0799-001Z
C761
6800p
C765
.22
C766
10
/50
C767
.022
R772 C768 R776 C769 R777
C770
.047
C771 QFVF1HJ-104Z
R778
R715
ROTATION
PROTECT
P_ON/OFF
HP_DET
REMOCON
AV_LINK
M_C
ROTATION
P_ON/OFF
HP_DET
REMOCON
M_C
AV_LINK
R743R744
3.3k3.3k
P15/TX
VssP2
VssC4
V1.8C4
V3.3A3
VrefP_Sdac
VrefN_Sdac
VrefP_Sdac
VrefN_Sdac
VrefP_Sdac
XtalIn
XtalOut
X701
VssA1
Vguard/Swo
DecDig
V5P1 C760 .01
Phi2
Phi1
12k
Gnd1
SecPll
Dec8G
Ewd/Avl
Vdb
Vda
Vif1
Vif2
Vsc
Iref
39k
GndIF
Sif1
Sif2
Agc
EHT SVM
Ssif/RefIn/Avl/RefOut
R740
*
R782
*
R714
1M
R781
*
C701 C702
**
D708
*3
ABL
LRLTV
CH
CH
/16
/50
MY
C116
R116
C776 .001
KEY
C755
/16
.01
680
PROTECT
/16 .1
R746
100
.001
100
.001
100
R747
22k
10k
SC_G1
HD
HD
4.7k
R742
P14/RX
R741
100
C781
.1 /16
P12/Int2
SC_R1
VssC3
*6
L713
SC_G1
SC_B1
C752
.22 /16
V1.8C3
SC_B1
SC_YS1
SC_R2
SC_YS1
SC_R2
SC_G2
Q713 OPEN RESET
R785 OPEN
R780 47k
P25/PWM4
P24/PWM3
IC701
TDA12026-28R4SK
SC_G2
MAIN CPU/ TELETEXT DECODE/ IF PROCESS/ MULTISOUND PROCESS/ VIDEO PROCESS/ RGB PROCESS/ SYNC. SEP./ DEF. PROCESS
AudioIn5R
AudOutSR
DecsDem
AudOutSL
R784
*
R783
*
RTV
C703
/16 .1
QssO/AmO/AudeEm
C705
3300p
C704 10
/50
AudioIn5L
C783 C782
**
SC_B2EWSC_YS2
SC_B2
D703 OPEN
VssC1+P1
Gnd2
R701
390
/16
C706
.1
SC_YS2
P33/Adc3
PllIf
HFLB
KEY
P32/Adc2
SifAgc
/50
2.2
C707
C786 OPEN
HFLB
1.2k
R737
C751
VGUARD
VGUARD
EW
*6
/50
L712
2.2
/16
C750
.1
0
Y703
DecV1V8
IfVo/FmRo/DvbO
R787
0
C708
8V
V_TV
LED
V_TV
/16
C749 V_TV
.22
V1.8C1
FmRo/DvbO
/16
/50
C709
.1
10
*6
L701
ABL
PROTECT
10k
R779
/10
C748
220
100
R735
P31/Adc1
P30/Adc0
V8AudioSwitches
AgcSsif
/50
2.2
C712
AMP_MUTE
A_MUTE
/16
C780
.1
R733R734R736R738R739
P23/Pwm2
P22/Pwm1
V5P2
SVO/IfVo/Cvbsl
L702
*6
1001001001k39k
C711C710 .110
C747
/16/50
S_COR
/16 .1
R731
4.7k
P21/Pwm0
Audio4InL
CH
C713
47p
ROTATION
L711
*6
/16
C775
R728 R727
.22
3.3k
V3.3P
P20/TPwm
Audio4InR
Y4/Cvbs4C4Audio2InL
/16 .1
C715
CH
C714
47p
C774
M_CV/Y
SDA1
SDA1
OPEN
M_C
SCL1
1SS357-X
D702
R729R730 100100
SCL1
/16
.01
C716
CH
C717 47p
C785
OPEN
*3
D701
MAIN_L
MAIN_L
P_ON/OFF
3.3k
P13/T1
Audio2InR
C718
47p
MAIN_R
MAIN_R
HP_DET
R725
P00/I2SDI1
Cvbs2/Y
ABL
IC701-10
(0.2µs) (0.2µs)
2.8 Vp-p
IC701-11
2.2 Vp-p
IC701-13
4.7 Vp-p
IC701-21
1 Vp-p
No.YA060 No.YA060
IC701-22
1 Vp-p
IC701-23
1.4 Vp-p
IC701-43
2.8 Vp-p
IC701-51
1 Vp-p
IC701-66
5 Vp-p
2-82-7
IC701-67
3 Vp-p
IC701-74
1.3 Vp-p
IC701-85
1.7 Vp-p
IC701-86
1.3 Vp-p
IC701-87
1.5 Vp-p
Loading...
+ 15 hidden pages
