PARTS LIST
CONTENTS
! USING PW BOARD & REMOTE CONTROL UNIT･････････････････････････････････････････････････････ 3-1
! EXPLODED VIEW PARTS LIST ････････････････････････････････････････････････････････････････････ 3-2
! EXPLODED VIEW ････････････････････････････････････････････････････････････････････････････････ 3-3
! PRINTED WIRING BOARD PARTS LIST
[ AV-28KT1BUF/A , AV-28KT1SUF/A ]
" MAIN PW BOARD ASS'Y････････････････････････････････････････････････････････････････････････ 3-4
" CRT SOCKET PW BOARD ASS'Y
" SIDE CONTROL PW BOARD ASS’Y
" LED PW BOARD ASS’Y
" SWITCH PW BOARD ASS’Y
[ AV-28KT1BUF/B , AV-28KT1SUF/B ]
" MAIN PW BOARD ASS'Y････････････････････････････････････････････････････････････････････････ 3-9
(COMMON)
(COMMON)
(COMMON)
･･･････････････････････････････････････････････････････････････ 3-8
(COMMON)
･･････････････････････････････････････････････････････ 3-8
････････････････････････････････････････････････････ 3-8
･･･････････････････････････････････････････････････････････ 3-8
AV-28KT1BUF
AV-28KT1SUF
[ AV-28KT1BUF/C , AV-28KT1SUF/C ]
" MAIN PW BOARD ASS'Y････････････････････････････････････････････････････････････････････････ 3-9
! PACKING / PACKING PARTS LIST ････････････････････････････････････････････････････････････････ 3-10
USING PW BOARD & REMOTE CONTROL UNIT
PWB ASS'Y
MAIN PWB
CRT SOCKET PWB
SIDE CONTROL PWB
LED PWB
SWITCH PWB
REMOTE CONTROL UNIT
Model
AV-28KT1BUF
AV-28KT1SUF
[A-VERSION]
VE-20120604 VE-20127801 VE-20127796
VE-20121506
VE-20120893
VE-20129110
VE-20122229
VE-30017763
(RM-C1100)
/A
/A
AV-28KT1BUF
AV-28KT1SUF
[B-VERSION]
/B
/B
AV-28KT1BUF
AV-28KT1SUF
[C-VERSION]
/C
/C
No. 52137
3-1
AV-28KT1BUF
AV-28KT1SUF
EXPLODED VIEW PARTS LIST
!
Ref.No. Part No. Part Name Description
[ AV-28KT1BUF : BLACK model ]
!
V01 VE-30002751 PICTURE TUBE Inc. DY, PC MAGNET
!
L01 VE-30002138 DEG COIL&EARTH
!
TR600 VE-30021290 FB TRANSF. Within MAIN PWB
!
1 VE-20121492 FRONT CABINET
!
2 VE-20091798 FUNCTION BUTTON
3 VE-40013592 LOGO JVC
!
4 VE-20111864 ON/OFF BUTTON (POWER)
5 VE-35000013 SPRING (ON/OFF SWITCH)
!
6 VE-20094352 PRE-AMP LENS
!
7 VE-20056446 LED LENS
8 VE-30001946 SPEAKER (x2) 8R 15W 57*160
!
10 VE-20093231 CHASSIS FRAME
!
11 VE-30015614 PFC TRANSF.
!
12 VE-20108124 BACK DOOR
!
13 VE-20121494 BACK COVER
!
14 VE-20127842 LABEL [A-VERSION]
!
14 VE-20127843 LABEL [A-VERSION]
!
14 VE-20127874 LABEL [B-VERSION]
!
14 VE-20127871 LABEL [C-VERSION]
!
15 VE-30016513 POWER CORD (2.2MT)
!
16 VE-20110931 BACK COVER HOLDER (x2)
17 VE-40014391 FOOT RUBBER (x2)
!
18 VE-20004520 CABLE HOLDER
19 VE-35000211 SCREW (2.9*9.5) (x4) For BACK DOOR
20 VE-35004572 SCREW (4x20) (x8) For BACK COVER
!
21 VE-20081578 BASE
!
Ref.No. Part No. Part Name Description
[ AV-28KT1SUF : SILVER model ]
!
V01 VE-30002751 PICTURE TUBE Inc. DY, PC MAGNET
!
L01 VE-30002138 DEG COIL&EARTH
!
TR600 VE-30021290 FB TRANSF. Within MAIN PWB
!
1 VE-20119985 FRONT CABINET
!
2 VE-20096498 FUNCTION BUTTON
3 VE-40013593 LOGO JVC
!
4 VE-20120046 ON/OFF BUTTON (POWER)
5 VE-35000013 SPRING (ON/OFF SWITCH)
!
6 VE-20094352 PRE-AMP LENS
!
7 VE-20056446 LED LENS
8 VE-30001946 SPEAKER (x2) 8R 15W 57*160
!
10 VE-20093231 CHASSIS FRAME
!
11 VE-30015614 PFC TRANSF.
!
12 VE-20120043 BACK DOOR
!
13 VE-20111863 BACK COVER
!
14 VE-20127776 LABEL [A-VERSION]
!
14 VE-20127777 LABEL [A-VERSION]
!
14 VE-20127841 LABEL [B-VERSION]
!
14 VE-20127894 LABEL [C-VERSION]
!
15 VE-30016513 POWER CORD (2.2MT)
!
16 VE-20110931 BACK COVER HOLDER (x2)
17 VE-40014391 FOOT RUBBER (x2)
!
18 VE-20004520 CABLE HOLDER
19 VE-35000211 SCREW (2.9*9.5) (x4) For BACK DOOR
20 VE-35004572 SCREW (4x20) (x8) For BACK COVER
!
21 VE-20081578 BASE
3-2
No. 52137
EXPLODED VIEW
AV-28KT1BUF
AV-28KT1SUF
No. 52137
3-3
AV-28KT1BUF
AV-28KT1SUF
PRINTED WIRING BOARD PARTS LIST
[ AV-28KT1BUF/A / AV-28KT1SUF/A ]
!!!!MAIN P.W. BOARD ASS’Y (VE-20120604)
!
Symbol No. Part No. Part Name Description
RESISTOR
C202 VE-30012643 SMD R 1/16W 120R J
L240 VE-30000464 SMD R 1/10W 100R J
L241 VE-30000464 SMD R 1/10W 100R J
L242 VE-30000464 SMD R 1/10W 100R J
L268 VE-30000614 SMD R 1/10W 2.4K J
R100 VE-30000718 CF R 1/4W 4.7K J
R101 VE-30000896 MF R 1/4W 160K G
R105 VE-30000982 MF R 1/4W 4.7K J
R106 VE-30000593 SMD R 1/10W 2.2K J
R108 VE-30000452 CF R 1/4W 10R J
R110 VE-30012657 SMD R 1/16W 1K J
R112 VE-30012657 SMD R 1/16W 1K J
R114 VE-30007784 MO R 5W 33K J(RADIAL)
R116 VE-30001173 MO R 1W 0.47R J
!
R117 VE-30001257 MG R 1/2W 4.7M J
R118 VE-30000580 CF R 1/4W 22R J
R119 VE-30012641 SMD R 1/16W 10K J
R122 VE-30014022 SMD R 1/16W 47R J
R126 VE-30012641 SMD R 1/16W 10K J
R127 VE-30012692 SMD R 1/16W 4.7K J
R129 VE-30012692 SMD R 1/16W 4.7K J
R130 VE-30012641 SMD R 1/16W 10K J
R131 VE-30000466 CF R 1/4W 1K J
R132 VE-30000466 CF R 1/4W 1K J
R133 VE-30000513 CF R 1/4W 130K J
R134 VE-30000575 SMD R 1/10W 2K J
R137 VE-30000481 CF R 1/4W 1M J
R138 VE-30000660 CF R 1/4W 3.3K J
R139 VE-30000593 SMD R 1/10W 2.2K J
R140 VE-30015222 MO R 1W 0.75R J
R141 VE-30012641 SMD R 1/16W 10K J
R142 VE-30012657 SMD R 1/16W 1K J
R143 VE-30020455 SMD R 1/16W 1.5K F
R144 VE-30000480 SMD R 1/10W 100K J
R145 VE-30020457 SMD R 1/16W 910R F
R146 VE-30012697 SMD R 1/16W 5.1K J
R147 VE-30020455 SMD R 1/16W 1.5K F
R148 VE-30020457 SMD R 1/16W 910R F
R149 VE-30012657 SMD R 1/16W 1K J
R150 VE-30000466 CF R 1/4W 1K J
R151 VE-30012641 SMD R 1/16W 10K J
!
R152 VE-30001224 FUSE R 1/2W 0.22R J
R153 VE-30012692 SMD R 1/16W 4.7K J
R154 VE-30012641 SMD R 1/16W 10K J
R155 VE-30012641 SMD R 1/16W 10K J
R156 VE-30012641 SMD R 1/16W 10K J
R157 VE-30012641 SMD R 1/16W 10K J
R158 VE-30012657 SMD R 1/16W 1K J
R161 VE-30012657 SMD R 1/16W 1K J
R162 VE-30000494 SMD R 1/10W 120R J
R164 VE-30000593 SMD R 1/10W 2.2K J
R165 VE-30001159 MO R 1W 0.33R J
R166 VE-30012641 SMD R 1/16W 10K J
R200 VE-30012713 SMD R 1/16W 75R J
R201 VE-30012713 SMD R 1/16W 75R J
R202 VE-30012713 SMD R 1/16W 75R J
R203 VE-30012713 SMD R 1/16W 75R J
R204 VE-30012713 SMD R 1/16W 75R J
R205 VE-30012713 SMD R 1/16W 75R J
R206 VE-30000459 CF R 1/4W 100R J
R207 VE-30000459 CF R 1/4W 100R J
R208 VE-30012510 SMD R 1/16W 100R J
R209 VE-30012510 SMD R 1/16W 100R J
R210 VE-30012662 SMD R 1/16W 2.7K J
R211 VE-30012657 SMD R 1/16W 1K J
R215 VE-30012713 SMD R 1/16W 75R J
R219 VE-30000792 CF R 1/4W 75R J
R220 VE-30012641 SMD R 1/16W 10K J
R221 VE-30000792 CF R 1/4W 75R J
R222 VE-30012641 SMD R 1/16W 10K J
R230 VE-30012641 SMD R 1/16W 10K J
R231 VE-30000792 CF R 1/4W 75R J
R232 VE-30012713 SMD R 1/16W 75R J
R233 VE-30012657 SMD R 1/16W 1K J
R234 VE-30012702 SMD R 1/16W 560R J
R235 VE-30000655 CF R 1/4W 330R J
R236 VE-30012713 SMD R 1/16W 75R J
R237 VE-30012641 SMD R 1/16W 10K J
R238 VE-30012641 SMD R 1/16W 10K J
R239 VE-30012713 SMD R 1/16W 75R J
R241 VE-30012510 SMD R 1/16W 100R J
R242 VE-30012696 SMD R 1/16W 47K J
R247 VE-30000500 CF R 1/4W 12K J
R248 VE-30012641 SMD R 1/16W 10K J
R254 VE-30012657 SMD R 1/16W 1K J
R256 VE-30012655 SMD R 1/16W 180R J
!
Symbol No. Part No. Part Name Description
RESISTOR
R259 VE-30000593 SMD R 1/10W 2.2K J
R260 VE-30012669 SMD R 1/16W 22K J
R261 VE-30012677 SMD R 1/16W 3.3K J
R264 VE-30012705 SMD R 1/16W 6.8K J
R265 VE-30000459 CF R 1/4W 100R J
R266 VE-30000459 CF R 1/4W 100R J
R267 VE-30012657 SMD R 1/16W 1K J
R268 VE-30012641 SMD R 1/16W 10K J
R269 VE-30012641 SMD R 1/16W 10K J
R270 VE-30012641 SMD R 1/16W 10K J
R272 VE-30012713 SMD R 1/16W 75R J
R273 VE-30012713 SMD R 1/16W 75R J
R274 VE-30012702 SMD R 1/16W 560R J
R276 VE-30000593 SMD R 1/10W 2.2K J
R277 VE-30012679 SMD R 1/16W 3.9K J
R278 VE-30012713 SMD R 1/16W 75R J
R279 VE-30012713 SMD R 1/16W 75R J
R280 VE-30012713 SMD R 1/16W 75R J
R281 VE-30012673 SMD R 1/16W 270R J
R282 VE-30012668 SMD R 1/16W 220R J
R283 VE-30012707 SMD R 1/16W 680R J
R284 VE-30012684 SMD R 1/16W 330R J
R285 VE-30012707 SMD R 1/16W 680R J
R286 VE-30012707 SMD R 1/16W 680R J
R288 VE-30000770 CF R 1/4W 680R J
R289 VE-30012707 SMD R 1/16W 680R J
R299 VE-30012510 SMD R 1/16W 100R J
R308 VE-30012641 SMD R 1/16W 10K J
R310 VE-30012713 SMD R 1/16W 75R J
R316 VE-30012641 SMD R 1/16W 10K J
R317 VE-30000792 CF R 1/4W 75R J
R318 VE-30012657 SMD R 1/16W 1K J
R326 VE-30000815 CF R 1/4W 8.2K J
R327 VE-30000480 SMD R 1/10W 100K J
R330 VE-30012657 SMD R 1/16W 1K J
R334 VE-30012713 SMD R 1/16W 75R J
R336 VE-30000466 CF R 1/4W 1K J
R337 VE-30000466 CF R 1/4W 1K J
R338 VE-30000466 CF R 1/4W 1K J
R342 VE-30012657 SMD R 1/16W 1K J
R343 VE-30012692 SMD R 1/16W 4.7K J
R349 VE-30012641 SMD R 1/16W 10K J
R350 VE-30012510 SMD R 1/16W 100R J
R351 VE-30012510 SMD R 1/16W 100R J
R352 VE-30012698 SMD R 1/16W 5.6K J
R353 VE-30012685 SMD R 1/16W 33K J
R354 VE-30012677 SMD R 1/16W 3.3K J
R355 VE-30012643 SMD R 1/16W 120R J
R356 VE-30012707 SMD R 1/16W 680R J
R357 VE-30012644 SMD R 1/16W 12K J
R358 VE-30012655 SMD R 1/16W 180R J
R359 VE-30012669 SMD R 1/16W 22K J
R400 VE-30012669 SMD R 1/16W 22K J
R404 VE-30012692 SMD R 1/16W 4.7K J
R406 VE-30012650 SMD R 1/16W 15K J
R409 VE-30012713 SMD R 1/16W 75R J
R410 VE-30012713 SMD R 1/16W 75R J
R411 VE-30012657 SMD R 1/16W 1K J
R412 VE-30012657 SMD R 1/16W 1K J
R413 VE-30012713 SMD R 1/16W 75R J
R414 VE-30012713 SMD R 1/16W 75R J
R415 VE-30012679 SMD R 1/16W 3.9K J
R416 VE-30012695 SMD R 1/16W 470R J
R417 VE-30012695 SMD R 1/16W 470R J
R418 VE-30012695 SMD R 1/16W 470R J
R419 VE-30012695 SMD R 1/16W 470R J
R420 VE-30012695 SMD R 1/16W 470R J
R421 VE-30012695 SMD R 1/16W 470R J
R422 VE-30012695 SMD R 1/16W 470R J
R423 VE-30012695 SMD R 1/16W 470R J
R424 VE-30012695 SMD R 1/16W 470R J
R425 VE-30012695 SMD R 1/16W 470R J
R426 VE-30012695 SMD R 1/16W 470R J
R503 VE-30012510 SMD R 1/16W 100R J
R504 VE-30012510 SMD R 1/16W 100R J
R505 VE-30000471 CF R 1/4W 10K J
R506 VE-30000471 CF R 1/4W 10K J
R507 VE-30012696 SMD R 1/16W 47K J
R508 VE-30012696 SMD R 1/16W 47K J
R509 VE-30012696 SMD R 1/16W 47K J
R510 VE-30012696 SMD R 1/16W 47K J
R512 VE-30012668 SMD R 1/16W 220R J
R513 VE-30012662 SMD R 1/16W 2.7K J
R516 VE-30012692 SMD R 1/16W 4.7K J
R518 VE-30012662 SMD R 1/16W 2.7K J
R519 VE-30000466 CF R 1/4W 1K J
3-4
No. 52137
[ AV-28KT1BUF/A / AV-28KT1SUF/A ]
!
Symbol No. Part No. Part Name Description
RESISTOR
R520 VE-30012650 SMD R 1/16W 15K J
R521 VE-30012679 SMD R 1/16W 3.9K J
R522 VE-30012692 SMD R 1/16W 4.7K J
R523 VE-30012712 SMD R 1/16W 8.2K J
R524 VE-30012679 SMD R 1/16W 3.9K J
R526 VE-30012679 SMD R 1/16W 3.9K J
R527 VE-30012679 SMD R 1/16W 3.9K J
R528 VE-30012650 SMD R 1/16W 15K J
R533 VE-30012685 SMD R 1/16W 33K J
R535 VE-30012641 SMD R 1/16W 10K J
R537 VE-30000466 CF R 1/4W 1K J
R538 VE-30012508 SMD R 1/16W 1.8K J
R539 VE-30012508 SMD R 1/16W 1.8K J
R540 VE-30012508 SMD R 1/16W 1.8K J
R541 VE-30012662 SMD R 1/16W 2.7K J
R545 VE-30012696 SMD R 1/16W 47K J
R546 VE-30000471 CF R 1/4W 10K J
R547 VE-30012510 SMD R 1/16W 100R J
R548 VE-30012641 SMD R 1/16W 10K J
R549 VE-30012657 SMD R 1/16W 1K J
R550 VE-30012679 SMD R 1/16W 3.9K J
R553 VE-30012695 SMD R 1/16W 470R J
R554 VE-30012692 SMD R 1/16W 4.7K J
R555 VE-30012506 SMD R 1/16W 1.5K J
R560 VE-30012641 SMD R 1/16W 10K J
R561 VE-30012510 SMD R 1/16W 100R J
R564 VE-30012692 SMD R 1/16W 4.7K J
R565 VE-30012510 SMD R 1/16W 100R J
R566 VE-30012641 SMD R 1/16W 10K J
R567 VE-30000459 CF R 1/4W 100R J
R568 VE-30000459 CF R 1/4W 100R J
R571 VE-30012657 SMD R 1/16W 1K J
R582 VE-30012641 SMD R 1/16W 10K J
R584 VE-30012696 SMD R 1/16W 47K J
R585 VE-30012641 SMD R 1/16W 10K J
R586 VE-30012641 SMD R 1/16W 10K J
R587 VE-30012641 SMD R 1/16W 10K J
R588 VE-30012641 SMD R 1/16W 10K J
R589 VE-30012641 SMD R 1/16W 10K J
R590 VE-30012679 SMD R 1/16W 3.9K J
R600 VE-30012510 SMD R 1/16W 100R J
R601 VE-30000470 CF R 1/2W 10K J
!
R603 VE-30001244 FUSE R 1/2W 0.47R J
!
R604 VE-30001244 FUSE R 1/2W 0.47R J
R605 VE-30000665 CF R 1/4W 33K J
R607 VE-30012695 SMD R 1/16W 470R J
R608 VE-30001100 MO R 1W 150R J
!
R611 VE-30001244 FUSE R 1/2W 0.47R J
R612 VE-30000471 CF R 1/4W 10K J
!
R613 VE-30001232 FUSE R 1/4W 2.7R J
!
R614 VE-30001244 FUSE R 1/2W 0.47R J
R616 VE-30018904 MO R 5W 4.7k J
R621 VE-30012696 SMD R 1/16W 47K J
R622 VE-30012641 SMD R 1/16W 10K J
R623 VE-30012641 SMD R 1/16W 10K J
R624 VE-30012692 SMD R 1/16W 4.7K J
R625 VE-30000480 SMD R 1/10W 100K J
R626 VE-30012692 SMD R 1/16W 4.7K J
R627 VE-30000480 SMD R 1/10W 100K J
R628 VE-30012657 SMD R 1/16W 1K J
R629 VE-30012674 SMD R 1/16W 27K J
R630 VE-30000504 CF R 1/4W 120K J
R631 VE-30000504 CF R 1/4W 120K J
R632 VE-30012662 SMD R 1/16W 2.7K J
R636 VE-30012641 SMD R 1/16W 10K J
R637 VE-30012657 SMD R 1/16W 1K J
R638 VE-30012674 SMD R 1/16W 27K J
R639 VE-30001162 MO R 1W 390R J
R640 VE-30001134 MO R 2W 2.2R J
R644 VE-30000649 CF R 1/2W 33R J
R645 VE-30000580 CF R 1/4W 22R J
R646 VE-30012654 SMD R 1/16W 180K J
R647 VE-30012650 SMD R 1/16W 15K J
R648 VE-30012658 SMD R 1/16W 1M J
!
R649 VE-30001228 FUSE R 1/2W 2.2R J
R650 VE-30001082 MO R 1/2W 1K J
R652 VE-30000848 MF R 1/4W 1K F
R653 VE-30012686 SMD R 1/16W 36K J
R654 VE-30012674 SMD R 1/16W 27K J
R655 VE-30012641 SMD R 1/16W 10K J
R656 VE-30012641 SMD R 1/16W 10K J
R657 VE-30000466 CF R 1/4W 1K J
R658 VE-30000466 CF R 1/4W 1K J
R700 VE-30012695 SMD R 1/16W 470R J
R701 VE-30012695 SMD R 1/16W 470R J
R702 VE-30012657 SMD R 1/16W 1K J
R703 VE-30012510 SMD R 1/16W 100R J
R704 VE-30012510 SMD R 1/16W 100R J
R705 VE-30012510 SMD R 1/16W 100R J
R710 VE-30012657 SMD R 1/16W 1K J
R713 VE-30012510 SMD R 1/16W 100R J
R714 VE-30012510 SMD R 1/16W 100R J
R715 VE-30012657 SMD R 1/16W 1K J
R718 VE-30012657 SMD R 1/16W 1K J
AV-28KT1BUF
AV-28KT1SUF
!
Symbol No. Part No. Part Name Description
RESISTOR
R719 VE-30012657 SMD R 1/16W 1K J
R723 VE-30000459 CF R 1/4W 100R J
R724 VE-30012510 SMD R 1/16W 100R J
R725 VE-30012657 SMD R 1/16W 1K J
R726 VE-30012657 SMD R 1/16W 1K J
R753 VE-30014076 SMD R 1/16W 4.7R J
R755 VE-30014076 SMD R 1/16W 4.7R J
R759 VE-30012641 SMD R 1/16W 10K J
R760 VE-30012702 SMD R 1/16W 560R J
R762 VE-30012641 SMD R 1/16W 10K J
R763 VE-30012702 SMD R 1/16W 560R J
R765 VE-30012669 SMD R 1/16W 22K J
R766 VE-30012669 SMD R 1/16W 22K J
R793 VE-30012695 SMD R 1/16W 470R J
R794 VE-30012695 SMD R 1/16W 470R J
R798 VE-30000466 CF R 1/4W 1K J
R799 VE-30012657 SMD R 1/16W 1K J
R811 VE-30012641 SMD R 1/16W 10K J
R815 VE-30012644 SMD R 1/16W 12K J
R816 VE-30012649 SMD R 1/16W 150R J
R817 VE-30012641 SMD R 1/16W 10K J
R818 VE-30000723 CF R 1/4W 47K J
R819 VE-30000593 SMD R 1/10W 2.2K J
R820 VE-30012696 SMD R 1/16W 47K J
R821 VE-30012641 SMD R 1/16W 10K J
VR100 VE-30001064 ADJ.R 1/10W 470R VER (MAN)
CAPACITOR
!
C102 VE-30000084 MKT CAP. 150NF AC275V M
!
C103 VE-30000094 MKT CAP. 220NF AC275V M
C105 VE-30012603 SMD CAP. 100NF 25V K R
C106 VE-30000400 EL CAP. 47UF 50V M
C107 VE-30000421 EL CAP. 220UF 400V M
C108 VE-30000161 MKP CAP. 47NF 630V J
C111 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C113 VE-30006940 CER CAP. 2.7NF 1KV K B
C114 VE-30009208 CER CAP. 470PF 1KV K (PULSE)
!
C115 VE-30000440 CER CAP. 2.2NF 4KV M
C118 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C119 VE-30000090 MKT CAP. 22NF 100V J
C120 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C121 VE-30012560 SMD CAP. 100PF 50V J
C122 VE-30007308 CER CAP. 220PF 1KV K (PULSE)
C124 VE-30000375 EL CAP. 220UF 16V M
C125 VE-30000406 EL CAP. 47UF 250V M (HR)
C126 VE-30012603 SMD CAP. 100NF 25V K R
C127 VE-30012603 SMD CAP. 100NF 25V K R
C129 VE-30016654 SMD CAP. 100NF 16V K R
C130 VE-30000436 CER CAP. 10NF 1KV ZE
C133 VE-30000383 EL CAP. 2200UF 25V M
C134 VE-30000383 EL CAP. 2200UF 25V M
C135 VE-30000411 EL CAP. 4700UF 16V M
C137 VE-30000367 EL CAP. 1UF 250V M
C138 VE-30016654 SMD CAP. 100NF 16V K R
C140 VE-30000393 EL CAP. 3.3UF 50V M
C141 VE-30000359 EL CAP. 1000UF 16V M
C142 VE-30000387 EL CAP. 33UF 50V M
C145 VE-30000375 EL CAP. 220UF 16V M
C146 VE-30012603 SMD CAP. 100NF 25V K R
C147 VE-30016654 SMD CAP. 100NF 16V K R
C148 VE-30000360 EL CAP. 1000UF 25V M
C149 VE-30012581 SMD CAP. 1NF 50V K R
C150 VE-30016654 SMD CAP. 100NF 16V K R
C152 VE-30000375 EL CAP. 220UF 16V M
C154 VE-30000375 EL CAP. 220UF 16V M
C155 VE-30000375 EL CAP. 220UF 16V M
C156 VE-30016654 SMD CAP. 100NF 16V K R
C157 VE-30016654 SMD CAP. 100NF 16V K R
!
C160 VE-30000076 MKT CAP. 100NF AC275V M
!
C161 VE-30000440 CER CAP. 2.2NF 4KV M
C162 VE-30007708 CER CAP. 1NF 1KV K (PULSE)
C164 VE-30000345 EL CAP. 10UF 50V M
C165 VE-30000362 EL CAP. 1UF 50V M
C166 VE-30000225 CER CAP. 220PF 50V J SL
C167 VE-30018085 VAR CAP. 510V K
C168 VE-30000161 MKP CAP. 47NF 630V J
C170 VE-30012566 SMD CAP. 22PF 50V J
C171 VE-30012590 SMD CAP. 47NF 50V K
C172 VE-30000313 CER CAP. 22NF 50V Z F
C173 VE-30018085 VAR CAP. 510V K
C201 VE-30000445 CER CAP. 4.7NF 1KV M E
C208 VE-30016126 SMD CAP. 220NF 16V K R
C209 VE-30016126 SMD CAP. 220NF 16V K R
C210 VE-30016126 SMD CAP. 220NF 16V K R
C212 VE-30000352 EL CAP. 100UF 16V M
C213 VE-30012609 SMD CAP. 68NF 50V K
C214 VE-30016126 SMD CAP. 220NF 16V K R
C215 VE-30016126 SMD CAP. 220NF 16V K R
C217 VE-30016126 SMD CAP. 220NF 16V K R
C218 VE-30012610 SMD CAP. 10NF 50V J
No. 52137
3-5
AV-28KT1BUF
AV-28KT1SUF
[ AV-28KT1BUF/A / AV-28KT1SUF/A ]
!
Symbol No. Part No. Part Name Description
CAPACITOR
C222 VE-30016126 SMD CAP. 220NF 16V K R
C225 VE-30000109 MKT CAP. 470NF 63V J
C226 VE-30000352 EL CAP. 100UF 16V M
C227 VE-30016654 SMD CAP. 100NF 16V K R
C229 VE-30000345 EL CAP. 10UF 50V M
C231 VE-30016654 SMD CAP. 100NF 16V K R
C233 VE-30016654 SMD CAP. 100NF 16V K R
C234 VE-30016126 SMD CAP. 220NF 16V K R
C235 VE-30012610 SMD CAP. 10NF 50V J
C237 VE-30012583 SMD CAP. 1.5NF 50V K
C238 VE-30012610 SMD CAP. 10NF 50V J
C240 VE-30012559 SMD CAP. 10PF 50V D COG
C242 VE-30012560 SMD CAP. 100PF 50V J
C246 VE-30012586 SMD CAP. 22NF 50V K
C248 VE-30012586 SMD CAP. 22NF 50V K
C249 VE-30012610 SMD CAP. 10NF 50V J
C252 VE-30000387 EL CAP. 33UF 50V M
C253 VE-30000345 EL CAP. 10UF 50V M
C255 VE-30016126 SMD CAP. 220NF 16V K R
C258 VE-30012581 SMD CAP. 1NF 50V K R
C259 VE-30000345 EL CAP. 10UF 50V M
C260 VE-30012585 SMD CAP. 2.2NF 50V K R
C261 VE-30012588 SMD CAP. 33NF 50V K
C262 VE-30012610 SMD CAP. 10NF 50V J
C263 VE-30012588 SMD CAP. 33NF 50V K
C264 VE-30012603 SMD CAP. 100NF 25V K R
C265 VE-30000109 MKT CAP. 470NF 63V J
C266 VE-30000109 MKT CAP. 470NF 63V J
C267 VE-30012581 SMD CAP. 1NF 50V K R
C268 VE-30012590 SMD CAP. 47NF 50V K
C269 VE-30016654 SMD CAP. 100NF 16V K R
C270 VE-30016654 SMD CAP. 100NF 16V K R
C271 VE-30016654 SMD CAP. 100NF 16V K R
C273 VE-30012590 SMD CAP. 47NF 50V K
C274 VE-30016654 SMD CAP. 100NF 16V K R
C275 VE-30016654 SMD CAP. 100NF 16V K R
C276 VE-30016654 SMD CAP. 100NF 16V K R
C277 VE-30000345 EL CAP. 10UF 50V M
C278 VE-30012559 SMD CAP. 10PF 50V D COG
C279 VE-30012559 SMD CAP. 10PF 50V D COG
C280 VE-30000345 EL CAP. 10UF 50V M
C282 VE-30012585 SMD CAP. 2.2NF 50V K R
C283 VE-30000345 EL CAP. 10UF 50V M
C284 VE-30012585 SMD CAP. 2.2NF 50V K R
C286 VE-30000345 EL CAP. 10UF 50V M
C287 VE-30012607 SMD CAP. 150PF 50V J
C288 VE-30012589 SMD CAP. 4.7NF 50V K
C289 VE-30012589 SMD CAP. 4.7NF 50V K
C290 VE-30012581 SMD CAP. 1NF 50V K R
C292 VE-30012589 SMD CAP. 4.7NF 50V K
C293 VE-30012607 SMD CAP. 150PF 50V J
C296 VE-30012589 SMD CAP. 4.7NF 50V K
C300 VE-30012589 SMD CAP. 4.7NF 50V K
C301 VE-30012607 SMD CAP. 150PF 50V J
C302 VE-30012581 SMD CAP. 1NF 50V K R
C304 VE-30012607 SMD CAP. 150PF 50V J
C308 VE-30012589 SMD CAP. 4.7NF 50V K
C327 VE-30000109 MKT CAP. 470NF 63V J
C331 VE-30012572 SMD CAP. 390PF 50V J
C333 VE-30012579 SMD CAP. 82PF 50V J
C336 VE-30012581 SMD CAP. 1NF 50V K R
C348 VE-30000109 MKT CAP. 470NF 63V J
C349 VE-30012581 SMD CAP. 1NF 50V K R
C350 VE-30016654 SMD CAP. 100NF 16V K R
C351 VE-30000345 EL CAP. 10UF 50V M
C352 VE-30016654 SMD CAP. 100NF 16V K R
C353 VE-30012581 SMD CAP. 1NF 50V K R
C355 VE-30012603 SMD CAP. 100NF 25V K R
C356 VE-30000109 MKT CAP. 470NF 63V J
C357 VE-30000345 EL CAP. 10UF 50V M
C358 VE-30000345 EL CAP. 10UF 50V M
C359 VE-30012581 SMD CAP. 1NF 50V K R
C360 VE-30012581 SMD CAP. 1NF 50V K R
C361 VE-30012603 SMD CAP. 100NF 25V K R
C362 VE-30012603 SMD CAP. 100NF 25V K R
C506 VE-30000345 EL CAP. 10UF 50V M
C507 VE-30000393 EL CAP. 3.3UF 50V M
C508 VE-30000345 EL CAP. 10UF 50V M
C509 VE-30016654 SMD CAP. 100NF 16V K R
C510 VE-30016654 SMD CAP. 100NF 16V K R
C511 VE-30016654 SMD CAP. 100NF 16V K R
C514 VE-30016654 SMD CAP. 100NF 16V K R
C515 VE-30016654 SMD CAP. 100NF 16V K R
C516 VE-30016654 SMD CAP. 100NF 16V K R
C517 VE-30016654 SMD CAP. 100NF 16V K R
C518 VE-30016654 SMD CAP. 100NF 16V K R
C519 VE-30016654 SMD CAP. 100NF 16V K R
C520 VE-30012573 SMD CAP. 47PF 50V J
C521 VE-30012573 SMD CAP. 47PF 50V J
C522 VE-30000345 EL CAP. 10UF 50V M
C523 VE-30000345 EL CAP. 10UF 50V M
C524 VE-30000345 EL CAP. 10UF 50V M
C525 VE-30000345 EL CAP. 10UF 50V M
C527 VE-30016654 SMD CAP. 100NF 16V K R
!
Symbol No. Part No. Part Name Description
CAPACITOR
C530 VE-30000375 EL CAP. 220UF 16V M
C537 VE-30016654 SMD CAP. 100NF 16V K R
C601 VE-30000350 EL CAP. 10UF 250V M
C603 VE-30000402 EL CAP. 47UF 100V M
C604 VE-30000075 MKT CAP. 100NF 250V K (DC)
C605 VE-30000406 EL CAP. 47UF 250V M (HR)
C607 VE-30012610 SMD CAP. 10NF 50V J
C608 VE-30000409 EL CAP. 470UF 25V M
C609 VE-30000082 MKT CAP. 15NF 63V J
C612 VE-30000348 EL CAP. 10UF 160V M
C613 VE-30000360 EL CAP. 1000UF 25V M
C614 VE-30000360 EL CAP. 1000UF 25V M
C618 VE-30000444 CER CAP. 470PF 1KV KB
C619 VE-30000367 EL CAP. 1UF 250V M
C628 VE-30016126 SMD CAP. 220NF 16V K R
C630 VE-30012603 SMD CAP. 100NF 25V K R
C632 VE-30000074 MKT CAP. 100NF 63V J
C633 VE-30012603 SMD CAP. 100NF 25V K R
C635 VE-30012584 SMD CAP. 1.8NF 50V K R
C636 VE-30009208 CER CAP. 470PF 1KV K (PULSE)
C637 VE-30012589 SMD CAP. 4.7NF 50V K
C638 VE-30000092 MKT CAP. 220NF 63V J
C643 VE-30000092 MKT CAP. 220NF 63V J
C644 VE-30012591 SMD CAP. 5.6NF 50V K
C645 VE-30012591 SMD CAP. 5.6NF 50V K
C646 VE-30000296 CER CAP. 100NF 100V Z F
C648 VE-30000090 MKT CAP. 22NF 100V J
C700 VE-30000352 EL CAP. 100UF 16V M
C701 VE-30000345 EL CAP. 10UF 50V M
C702 VE-30012583 SMD CAP. 1.5NF 50V K
C707 VE-30016654 SMD CAP. 100NF 16V K R
C708 VE-30000407 EL CAP. 470UF 16V M
C712 VE-30012581 SMD CAP. 1NF 50V K R
C713 VE-30012581 SMD CAP. 1NF 50V K R
C716 VE-30016654 SMD CAP. 100NF 16V K R
C717 VE-30000092 MKT CAP. 220NF 63V J
C718 VE-30000092 MKT CAP. 220NF 63V J
C719 VE-30016126 SMD CAP. 220NF 16V K R
C720 VE-30000345 EL CAP. 10UF 50V M
C721 VE-30012576 SMD CAP. 56PF 50V J CH
C722 VE-30012576 SMD CAP. 56PF 50V J CH
C724 VE-30000345 EL CAP. 10UF 50V M
C725 VE-30016654 SMD CAP. 100NF 16V K R
C728 VE-30012581 SMD CAP. 1NF 50V K R
C729 VE-30016126 SMD CAP. 220NF 16V K R
C730 VE-30016126 SMD CAP. 220NF 16V K R
C731 VE-30012583 SMD CAP. 1.5NF 50V K
C732 VE-30012581 SMD CAP. 1NF 50V K R
C733 VE-30016126 SMD CAP. 220NF 16V K R
C734 VE-30016654 SMD CAP. 100NF 16V K R
C735 VE-30000393 EL CAP. 3.3UF 50V M
C736 VE-30000345 EL CAP. 10UF 50V M
C737 VE-30000345 EL CAP. 10UF 50V M
C738 VE-30012576 SMD CAP. 56PF 50V J CH
C739 VE-30000345 EL CAP. 10UF 50V M
C740 VE-30012581 SMD CAP. 1NF 50V K R
C741 VE-30012581 SMD CAP. 1NF 50V K R
C742 VE-30012565 SMD CAP. 1.8PF 50V J CH
C743 VE-30012565 SMD CAP. 1.8PF 50V J CH
C744 VE-30000345 EL CAP. 10UF 50V M
C745 VE-30012581 SMD CAP. 1NF 50V K R
C746 VE-30012581 SMD CAP. 1NF 50V K R
C747 VE-30012581 SMD CAP. 1NF 50V K R
C748 VE-30012583 SMD CAP. 1.5NF 50V K
C749 VE-30012581 SMD CAP. 1NF 50V K R
C750 VE-30012581 SMD CAP. 1NF 50V K R
C751 VE-30012581 SMD CAP. 1NF 50V K R
C754 VE-30000352 EL CAP. 100UF 16V M
C764 VE-30012567 SMD CAP. 220PF 50V J
C771 VE-30000345 EL CAP. 10UF 50V M
C772 VE-30000345 EL CAP. 10UF 50V M
C774 VE-30012567 SMD CAP. 220PF 50V J
C781 VE-30012590 SMD CAP. 47NF 50V K
C783 VE-30012590 SMD CAP. 47NF 50V K
C789 VE-30000362 EL CAP. 1UF 50V M
C791 VE-30000362 EL CAP. 1UF 50V M
C793 VE-30012581 SMD CAP. 1NF 50V K R
C794 VE-30012581 SMD CAP. 1NF 50V K R
C799 VE-30016126 SMD CAP. 220NF 16V K R
C800 VE-30012610 SMD CAP. 10NF 50V J
C801 VE-30012610 SMD CAP. 10NF 50V J
C806 VE-30012603 SMD CAP. 100NF 25V K R
C807 VE-30012590 SMD CAP. 47NF 50V K
C808 VE-30000345 EL CAP. 10UF 50V M
C809 VE-30000345 EL CAP. 10UF 50V M
S237 VE-30012610 SMD CAP. 10NF 50V J
TRANSF
!
TR100 VE-30019432 SMPS TRANSF.
!
TR600 VE-30021290 FB TRANSF.
TR601 VE-30002090 LINE DRIVER
3-6
No. 52137
[ AV-28KT1BUF/A / AV-28KT1SUF/A ]
!
Symbol No. Part No. Part Name Description
COIL
J344 VE-30001996 FIXED COIL 22UH
L103 VE-30001992 FIXED COIL 10UH
L105 VE-30011450 FIXED COIL 22UH
L203 VE-30001996 FIXED COIL 22UH
L206 VE-30001979 FIXED COIL 1UH
L207 VE-30001979 FIXED COIL 1UH
L263 VE-30001979 FIXED COIL 1UH
L264 VE-30001979 FIXED COIL 1UH
L265 VE-30001979 FIXED COIL 1UH
L266 VE-30001987 FIXED COIL 4.7UH
L500 VE-30001992 FIXED COIL 10UH
L501 VE-30001992 FIXED COIL 10UH
L502 VE-30001992 FIXED COIL 10UH
L503 VE-30001992 FIXED COIL 10UH
L504 VE-30001992 FIXED COIL 10UH
L505 VE-30001992 FIXED COIL 10UH
L506 VE-30006770 FIXED COIL 0.22UH
L601 VE-30002031 INJECTION FIXED COIL 15MH
L700 VE-30001996 FIXED COIL 22UH
L701 VE-30001996 FIXED COIL 22UH
L702 VE-30001996 FIXED COIL 22UH
L703 VE-30001996 FIXED COIL 22UH
L711 VE-30001996 FIXED COIL 22UH
L717 VE-30001979 FIXED COIL 1UH
DIODE
D100 VE-30001329 DIODE 1A/1000V 30A
!
D101 VE-20108354 BRIDGE DIODE 4A/1000V 150A(FORMLU)
D103 VE-30001318 DIODE 1A/800V 20A
D104 VE-30001318 DIODE 1A/800V 20A
D105 VE-30001318 DIODE 1A/800V 20A
D106 VE-30001344 ZENER DIODE 6.2V 1/2W
D108 VE-30001315 DIODE 1A/200V 20A
D110 VE-30001288 DIODE 2A/200V 50A
D111 VE-30001318 DIODE 1A/800V 20A
D112 VE-30001285 SMD DIODE
D113 VE-30003720 SMD ZENER DIODE 3.3V
D114 VE-30001285 SMD DIODE
D118 VE-30009366 DIODE 3A/200V 150A
D119 VE-30009366 DIODE 3A/200V 150A
D125 VE-30001285 SMD DIODE
D127 VE-30001315 DIODE 1A/200V 20A
D129 VE-30001285 SMD DIODE
D130 VE-30001329 DIODE 1A/1000V 30A
D131 VE-30001318 DIODE 1A/800V 20A
D132 VE-30001285 SMD DIODE
D133 VE-30003722 ZENER DIODE
D134 VE-30001285 SMD DIODE
D200 VE-30001285 SMD DIODE
D204 VE-30001285 SMD DIODE
D212 VE-30001285 SMD DIODE
D213 VE-30012411 SMD DIODE
D214 VE-30007763 SMD ZENER DIODE
D215 VE-30007763 SMD ZENER DIODE
D216 VE-30007763 SMD ZENER DIODE
D506 VE-30012412 SMD ZENER DIODE 2.4V
D601 VE-30001377 UZT ZENER DIODE 33V
D602 VE-30001318 DIODE 1A/800V 20A
D603 VE-30001299 DIODE 3A/400V 150A
D604 VE-30001299 DIODE 3A/400V 150A
D609 VE-30001318 DIODE 1A/800V 20A
D610 VE-30001318 DIODE 1A/800V 20A
D611 VE-30007681 DIODE 3A/800V 150A
D612 VE-30001285 SMD DIODE
D613 VE-30001291 DIODE 1A/800V 30A
D614 VE-30007763 SMD ZENER DIODE
D615 VE-30001318 DIODE 1A/800V 20A
D617 VE-30001285 SMD DIODE
D622 VE-30001285 SMD DIODE
D623 VE-30001285 SMD DIODE
D624 VE-30001285 SMD DIODE
D625 VE-30001320 DIODE
D627 VE-30001284 DIODE 0.15A/100V 0.5A
D701 VE-30007761 SMD ZENER DIODE
D702 VE-30001285 SMD DIODE
D706 VE-30001285 SMD DIODE
D707 VE-30001285 SMD DIODE
TRANSISTOR
Q102 VE-30001386 TRANSISTOR
Q103 VE-30001454 TRANSISTOR
Q106 VE-30001454 TRANSISTOR
Q107 VE-30001428 TRANSISTOR
Q108 VE-30001457 SMD TRANSISTOR
Q109 VE-30001457 SMD TRANSISTOR
Q110 VE-30001384 TRANSISTOR
Q112 VE-30001458 SMD TRANSISTOR
Q113 VE-30001457 SMD TRANSISTOR
AV-28KT1BUF
AV-28KT1SUF
!
Symbol No. Part No. Part Name Description
TRANSISTOR
Q114 VE-30001457 SMD TRANSISTOR
Q200 VE-30001457 SMD TRANSISTOR
Q201 VE-30001457 SMD TRANSISTOR
Q202 VE-30001457 SMD TRANSISTOR
Q203 VE-30001457 SMD TRANSISTOR
Q208 VE-30001457 SMD TRANSISTOR
Q216 VE-30001457 SMD TRANSISTOR
Q218 VE-30001458 SMD TRANSISTOR
Q220 VE-30001457 SMD TRANSISTOR
Q221 VE-30001457 SMD TRANSISTOR
Q222 VE-30001457 SMD TRANSISTOR
Q500 VE-30001457 SMD TRANSISTOR
Q501 VE-30001457 SMD TRANSISTOR
Q502 VE-30001457 SMD TRANSISTOR
Q503 VE-30001457 SMD TRANSISTOR
Q504 VE-30001457 SMD TRANSISTOR
Q505 VE-30001458 SMD TRANSISTOR
Q508 VE-30001457 SMD TRANSISTOR
Q510 VE-30001457 SMD TRANSISTOR
Q511 VE-30001457 SMD TRANSISTOR
Q512 VE-30001457 SMD TRANSISTOR
Q513 VE-30001458 SMD TRANSISTOR
Q600 VE-30001429 TRANSISTOR
Q601 VE-30001435 TRANSISTOR
!
Q602 VE-30001441 TRANSISTOR H.OUT
Q603 VE-30001458 SMD TRANSISTOR
Q605 VE-30001458 SMD TRANSISTOR
Q606 VE-30001458 SMD TRANSISTOR
Q700 VE-30001458 SMD TRANSISTOR
Q703 VE-30001458 SMD TRANSISTOR
Q704 VE-30001457 SMD TRANSISTOR
IC
!
IC100 VE-30015087 I.C.
IC101 VE-30001622 I.C.
IC102 VE-30001668 I.C.
IC103 VE-30001668 I.C.
IC104 VE-30001500 I.C.
IC106 VE-30011968 I.C.
IC116 VE-30001506 I.C.
IC200 VE-30019492 I.C.
IC201 VE-30001619 I.C.
IC206 VE-30021083 I.C.
IC301 VE-30016113 I.C.
IC500 VE-20139901 I.C.(MICOM) [A-VERSION]
IC502 VE-20120610 I.C.(MEMORY) [A-VERSION]
IC600 VE-30007793 I.C.
IC601 VE-30001506 I.C.
IC700 VE-30013658 I.C.
OTHERS
!
L101 VE-30018866 LINE FILTER
L102 VE-30001971 FERRITE BEAT
L212 VE-30001971 FERRITE BEAT
L213 VE-30001971 FERRITE BEAT
L214 VE-30001971 FERRITE BEAT
L215 VE-30001971 FERRITE BEAT
L216 VE-30001971 FERRITE BEAT
L217 VE-30001971 FERRITE BEAT
L218 VE-30001971 FERRITE BEAT
L220 VE-30001971 FERRITE BEAT
L227 VE-30001971 FERRITE BEAT
L232 VE-30001971 FERRITE BEAT
L236 VE-30001971 FERRITE BEAT
L239 VE-30001971 FERRITE BEAT
L247 VE-30001971 FERRITE BEAT
L251 VE-30001971 FERRITE BEAT
L252 VE-30001971 FERRITE BEAT
L719 VE-30001968 FERRITE BEAD
!
TH100 VE-30001270 PTC 9 OHM
!
TU200 VE-30009637 TUNER
X200 VE-30002851 XTAL 4MHZ
X201 VE-30008778 XTAL 20.25MHZ
X500 VE-30006662 XTAL 6MHZ
X700 VE-30001756 XTAL 18.432MHZ
Z200 VE-30014261 SAW FILTER
Z201 VE-30012545 SAW FILTER
PR.IC.45-SDA55XX FLASH JVC JA100
IC 24C16 V008D4313A01040100122
No. 52137
3-7
AV-28KT1BUF
AV-28KT1SUF
[ AV-28KT1BUF/A / AV-28KT1SUF/A ]
!!!!CRT SOCKET PW BOARD ASSY (VE-20121506)
!
Symbol No. Part No. Part Name Description
RESISTOR
C911 VE-30012707 SMD R 1/16W 680R J
C912 VE-30012707 SMD R 1/16W 680R J
R900 VE-30000788 CF R 1/4W 6.8M J
R901 VE-30000459 CF R 1/4W 100R J
R902 VE-30000459 CF R 1/4W 100R J
R903 VE-30000459 CF R 1/4W 100R J
R904 VE-30000535 CF R 1/2W 150K J
R905 VE-30000477 CF R 1/4W 100K J
R906 VE-30000477 CF R 1/4W 100K J
R907 VE-30023197 CC R 1W 1.5K K
R908 VE-30023197 CC R 1W 1.5K K
R909 VE-30000477 CF R 1/4W 100K J
R910 VE-30023197 CC R 1W 1.5K K
R911 VE-30000466 CF R 1/4W 1K J
R912 VE-30000459 CF R 1/4W 100R J
R913 VE-30021483 CC R 1W 2.2K K
R914 VE-30000459 CF R 1/4W 100R J
R915 VE-30012649 SMD R 1/16W 150R J
R916 VE-30014128 SMD R 1/16W 33R J
R917 VE-30000583 CF R 1/4W 220R J
R919 VE-30012712 SMD R 1/16W 8.2K J
R920 VE-30012661 SMD R 1/16W 2.4K J
R921 VE-30012649 SMD R 1/16W 150R J
R922 VE-30014128 SMD R 1/16W 33R J
R923 VE-30000583 CF R 1/4W 220R J
R925 VE-30012649 SMD R 1/16W 150R J
R926 VE-30014128 SMD R 1/16W 33R J
R927 VE-30000583 CF R 1/4W 220R J
R928 VE-30012510 SMD R 1/16W 100R J
CAPACITOR
C900 VE-30000075 MKT CAP. 100NF 250V K (DC)
C902 VE-30000415 EL CAP. 4.7UF 250V M
C903 VE-30000438 CER CAP. 2.2NF 2KV
C904 VE-30000287 CER CAP. 10NF 50V K B
C905 VE-30000350 EL CAP. 10UF 250V M
C906 VE-30000075 MKT CAP. 100NF 250V K (DC)
C909 VE-30000407 EL CAP. 470UF 16V M
C910 VE-30000294 SMD CAP. 100NF 50V K
C913 VE-30000294 SMD CAP. 100NF 50V K
C914 VE-30012577 SMD CAP. 560PF 50V J
C915 VE-30000407 EL CAP. 470UF 16V M
C916 VE-30000352 EL CAP. 100UF 16V M
C918 VE-30012577 SMD CAP. 560PF 50V J
C919 VE-30012577 SMD CAP. 560PF 50V J
C920 VE-30012577 SMD CAP. 560PF 50V J
C921 VE-30000294 SMD CAP. 100NF 50V K
C931 VE-30000075 MKT CAP. 100NF 250V K (DC)
S4 VE-30016654 SMD CAP. 100NF 16V K R
COIL
L901 VE-30001994 FIXED COIL 22UH J AXIAL
DIODE
D902 VE-30001318 DIODE 1A/800V 20A
D903 VE-30001284 DIODE 0.15A/100V 0.5A
D904 VE-30001318 DIODE 1A/800V 20A
D905 VE-30001318 DIODE 1A/800V 20A
D907 VE-30001318 DIODE 1A/800V 20A
D908 VE-30014353 DIODE
D909 VE-30001285 SMD DIODE
TRANSISTOR
Q900 VE-30001427 TRANSISTOR
Q901 VE-30001458 SMD TRANSISTOR
Q902 VE-30001458 SMD TRANSISTOR
Q903 VE-30001458 SMD TRANSISTOR
Q904 VE-30001458 SMD TRANSISTOR
IC
IC900 VE-30015857 I.C.
IC901 VE-30014346 I.C.
OTHERS
!
PL901 VE-30001855 CRT SOCKET
SG901 VE-30000428 SPARK GAP 300V
SG902 VE-30000428 SPARK GAP 300V
SG903 VE-30000428 SPARK GAP 300V
SG904 VE-30000428 SPARK GAP 300V
SG905 VE-30021532 SPARK GAP 1500V
!!!!SIDE CONTROL PW BOARD ASSY(VE-20120893)
!
Symbol No. Part No. Part Name Description
RESISTOR
R102 VE-30000594 CF R 1/4W 22K J
R103 VE-30000712 CF R 1/4W 470R J
R104 VE-30000594 CF R 1/4W 22K J
R106 VE-30000712 CF R 1/4W 470R J
R122 VE-30000770 CF R 1/4W 680R J
R123 VE-30000712 CF R 1/4W 470R J
!
R124 VE-30000623 CF R 1/4W 270R G
R125 VE-30000526 CF R 1/4W 1.5K J
R126 VE-30000689 CF R 1/4W 3.9K J
R127 VE-30000655 CF R 1/4W 330R J
R128 VE-30000655 CF R 1/4W 330R J
CAPACITOR
C101 VE-30000190 CER CAP. 100PF 50V J CH
!
C103 VE-30000190 CER CAP. 100PF 50V J CH
C104 VE-30000190 CER CAP. 100PF 50V J CH
C105 VE-30000307 CER CAP. 2.2NF 50V K B
COIL
L101 VE-30001979 FIXED COIL 1UH
L103 VE-30001996 FIXED COIL 22UH
L104 VE-30001996 FIXED COIL 22UH
OTHERS
JK101 VE-30001884 RCA JACK
JK102 VE-30001882 RCA JACK
JK103 VE-30001883 RCA JACK
JK109 VE-30020016 HEADPHONE JACK
SW101 VE-30002181 TACT SWITCH
SW102 VE-30002181 TACT SWITCH
SW103 VE-30002181 TACT SWITCH
SW104 VE-30002181 TACT SWITCH
SW105 VE-30002181 TACT SWITCH
!!!!LED PW BOARD ASSY (VE-20119110)
!
Symbol No. Part No. Part Name Description
DIODE
D100 VE-30001279 LED(RED/GREEN)
D100 VE-20119034 LED HOLDER
OTHERS
MD101 VE-30001670 PREAMPLIFIER
!!!!SWITCH PW BOARD ASSY (VE-20122229)
!
Symbol No. Part No. Part Name Description
OTHERS
!
F801 VE-30001731 FUSE 2.5A
!
SW800 VE-30022450 SWITCH(ON/OFF)
3-8
No. 52137
[ AV-28KT1BUF/B / AV-28KT1SUF/B ]
!!!!MAIN P.W. BOARD ASS’Y (VE-20127801)
Regarding the parts list for the main PW board ass’y
described, For further details regarding the other parts, refer to the parts list for the
Part No.
!
Symbol No.
IC500 VE-20139901 VE-20137151 I.C. (MICOM) [B-VERSION]
IC502 VE-20120610 VE-20134092 I.C. (MEMORY) [B-VERSION]
VE-20120604
[A-VERSION]
VE-20127801
VE-20127801
[B-VERSION]
!!!!CRT SOCKET PW BOARD ASSY (VE-20121506)
Refer to PARTS LIST in page 8 for this P. W. board.
!!!!SIDE CONTROL PW BOARD ASSY(VE-20120893)
Refer to PARTS LIST in page 8 for this P. W. board.
!!!!LED PW BOARD ASSY (VE-20119110)
Refer to PARTS LIST in page 8 for this P. W. board.
, only the different parts from those of the
VE-20120604
Part Name Description
described on page 4 through page 7.
AV-28KT1BUF
AV-28KT1SUF
VE-20120604
are
!!!!SWITCH PW BOARD ASSY (VE-20122229)
Refer to PARTS LIST in page 8 for this P. W. board.
[ AV-28KT1BUF/C / AV-28KT1SUF/C ]
!!!!MAIN P.W. BOARD ASS’Y (VE-20127796)
Regarding the parts list for the main PW board ass’y
described, For further details regarding the other parts, refer to the parts list for the
Part No.
!
Symbol No.
IC500 VE-20139901 VE-20139902 I.C. (MICOM) [C-VERSION]
IC502 VE-20120610 VE-20126318 I.C. (MEMORY) [C-VERSION]
VE-20120604
[A-VERSION]
VE-20127796
VE-20127796
[C-VERSION]
!!!!CRT SOCKET PW BOARD ASSY (VE-20121506)
Refer to PARTS LIST in page 8 for this P. W. board.
!!!!SIDE CONTROL PW BOARD ASSY(VE-20120893)
Refer to PARTS LIST in page 8 for this P. W. board.
, only the different parts from those of the
VE-20120604
Part Name Description
described on page 4 through page 7.
VE-20120604
are
!!!!LED PW BOARD ASSY (VE-20119110)
Refer to PARTS LIST in page 8 for this P. W. board.
!!!!SWITCH PW BOARD ASSY (VE-20122229)
Refer to PARTS LIST in page 8 for this P. W. board.
No. 52137
3-9
AV-28KT1BUF
AV-28KT1SUF
PACKING
1
2
4
3
5 8!9
!
6!7
!
10
2
PACKING PARTS LI ST
!
Ref.No. Part No. Part Name Description
[ AV-28KT1BUF : BLACK model ]
1 VE-50038917 CARTON BOX [A-VERSION]
1 VE-50038933 CARTON BOX [B-VERSION]
1 VE-50038949 CARTON BOX [C-VERSION]
2 VE-20116671 SNOW BOX ASSY 4 pcs in 1set
3 VE-50026637 POLY BAG (1250*1000)
4 VE-70000587 POLY BAG
5 VE-30017763 REMOTE CONTROL UNIT (RM-C1100)
!
6 VE-50038905 INST BOOK [A-VERSION]
!
7 VE-50038931 INST BOOK [B-VERSION]
!
8 VE-50038935 INST BOOK [C-VERSION]
9 BT-54013-2TK WARRANTY CARD
!
10 VE-20127842 LABEL [A-VERSION]
!
10 VE-20127843 LABEL [A-VERSION]
!
10 VE-20127874 LABEL [B-VERSION]
!
10 VE-20127871 LABEL [C-VERSION]
[ AV-28KT1SUF : SILVER model ]
1 VE-50038907 CARTON BOX [A-VERSION]
1 VE-50038932 CARTON BOX [B-VERSION]
1 VE-50038950 CARTON BOX [C-VERSION]
2 VE-20116671 SNOW BOX ASSY 4 pcs in 1set
3 VE-50026637 POLY BAG (1250*1000)
4 VE-70000587 POLY BAG
5 VE-30017763 REMOTE CONTROL UNIT (RM-C1100)
!
6 VE-50038905 INST BOOK [A-VERSION]
!
7 VE-50038931 INST BOOK [B-VERSION]
!
8 VE-50038935 INST BOOK [C-VERSION]
9 BT-54013-2TK WARRANTY CARD
!
10 VE-20127776 LABEL [A-VERSION]
!
10 VE-20127777 LABEL [A-VERSION]
!
10 VE-20127841 LABEL [B-VERSION]
!
10 VE-20127894 LABEL [C-VERSION]
3-10
No. 52137
Loading...
