JVC AV28H20EUB, AV28H20EUS, AV32H20EUS Parts List

V32H20EUS

V28H20EUS V28H20EUB

PARTS LIST

CAUTION

! The pa rts identified b y the ! symbol ar e import ant for t he s afe ty. W hene ver r epl acing these par ts, be s ure to us e s pec if ied o nes to se cure

the safet y .

T he parts n ot i nd ic ate d i n this P arts L i s t a nd tho se which ar e fil l ed wi th li nes 　　 in the Parts No. columns will not be supplied.

! P. W. Board Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. colu mns will be s upplied.

ABBREVIATIONS OF RESISTOR S, CAP ACITORS AND TOLERANCE S

RESISTORS CAPACITORS

C R Carbon Resistor C CAP. Ceramic Capacitor

F R Fusible Resistor E CAP. Electrolytic Capacitor

P R Plat e Res istor M CAP. Mylar Capacitor

V R

HV R High Voltage Resistor MF CAP. Metalized Film Capacitor

MF R Metal Film Resistor MM CAP. Metalized Mylar Capacitor

MG R Metal Glazed Resistor MP CAP. Metalized Polystyrol Capacitor

MP R M etal Pl ate R esi sto r PP CA P. Po ly p ropyl en e Ca pa cit or

OM R Metal Oxide Fil m Resi s tor

CMF R Coating Metal Film Resistor TF CAP. Thin F ilm Capacitor

UNF R Non-Flammable R es i sto r MPP C AP . Metal i ze d P olypr op y l ene Cap acito r

CH V R Chip Variable Resistor TAN. CAP. Tantalum Capacitor

CH MG R Chip Metal Glazed Resistor CH C CAP. Chip Ceramic Capacitor

COMP . R Composi t ion Re sist or BP E CAP . Bi- Pol a r E lectr ol y ti c C a pac i t or

LP T C R

Variable Resistor

Lin ear P ositive T emper at ure C o eff ici e nt Resistor

HV CAP. High Voltage Capacitor

PS CAP.

CH AL E CAP. Chip Aluminum Electrolytic Capacitor

CH AL BP CA P.

CH TAN. E CAP.

Polystyrol Capacitor

Chip A l um i num Bi-Po lar Cap ac i tor

Chip T antalum El ec trolytic C ap acitor

CH AL BP E CAP.

Chip T antalum Bi - Po lar El ec tr o lyt ic C a pacit or

TOLERANCES

FGJ K MNRHZP

10 %

20 %

30 %

+30%

-10%

No.51945

+50%

-10%

+80%

-20%

+100 %

-0%

V32H20EUS

V28H20EUS V28H20EUB

CONTENTS

!!!! USIN G PW B OAR D & REM OTE CON TR OL UN IT

AV32H20EUS

!!!!

EXPLODED VIEW PARTS LIST

!!!!

EXPLODED VIEW

････････････････････････････････････････････････････････････････････････････････････････････ 33, 35

･･･････････････････････････････････････････････････････････････････････････････ 33, 34

!!!! PRINTED WIRING BOARD PARTS LIST

MAIN PW BOARD ASS’Y

POWER & DEF. PW BOARD ASS’Y

CRT SOCKET PW BOARD ASS’Y

FRONT CONTROL PW BO ARD ASS’Y

MICOM PW BOARD ASS’Y

AV SW PW BOARD ASS’Y

100Hz PW BOARD ASS’Y

･･････････････････････････････････････････････････････････････････････････････････････ 36

････････････････････････････････････････････････････････････････････････････ 38

･････････････････････････････････････････････････････････････････････････････ 40

･････････････････････････････････････････････････････････････････････････ 41

････････････････････････････････････････････････････････････････････････････････････ 42

･････････････････････････････････････････････････････････････････････････････････････ 43

･････････････････････････････････････････････････････････････････････････････････････ 44

AV28H20EUS / AV28H20EUB

!!!!

EXPLODED VIEW PARTS LIST

!!!!

EXPLODED VIEW

!!!!

PRINTED WIRING BOARD PARTS LIST

MAIN PW BOARD ASS’Y

POWER & DEF. PW BOARD ASS’Y

CRT SOCKET PW BOARD ASS’Y

FRONT CONTROL PW BOARD ASS’Y

MICOM PW BOARD ASS’Y

AV SW PW BOARD ASS’Y

100Hz PW BOARD ASS’Y

････････････････････････････････････････････････････････････････････････････････････････････ 45, 47

･･･････････････････････････････････････････････････････････････････････････････ 45, 46

･･････････････････････････････････････････････････････････････････････････････････････ 48

････････････････････････････････････････････････････････････････････････････ 50

･････････････････････････････････････････････････････････････････････････････ 52

･････････････････････････････････････････････････････････････････････････ 53

････････････････････････････････････････････････････････････････････････････････････ 53

･････････････････････････････････････････････････････････････････････････････････････ 53

･････････････････････････････････････････････････････････････････ 32

!!!!

REMOTE CONTROL UNIT PARTS LIST

PA CK IN G ･･･････････････････････････････････････････････････････････････････････････････････････････････････････ 55

PA CKING PARTS LIST

･･･････････････････････････････････････････････････････････････････････････････････････････

･･････････････････････････････････････････････････････････････････････････ 54

USING PW BOARD & REMOTE CONTROL UNIT

Model

PW B AS S’ Y

MAIN PWB

POW E R & DEF. PWB SMF-2401A-U2 SMF-2402A-U2

CRT SOCKET PWB SMF-3401A-U2 SMF-3402A-U2

FRON T CON TRO L PWB

MICOM PWB

AV SW PWB SMF0S401A-U2

100Hz PWB SMF0Z4 05A-U2

REM OTE CO NTRO L UNI T RM -C5 4H-1C RM-C5 0-1 C

AV32H20EUS AV28H20EUS AV28H20EUB

SMF-1401A-U2 SMF-1402A-U2

SMF-8401A-U2 SMF-8402A-U2

SMF0M401A-U2

No.51945

EXPLODED VIEW PARTS LIST

AV32H20EUS

Ref.No. Part No. Part Name Description

1 LC 403 54- 003A -C JV C M ARK 2 LC 305 80- 001C-C LED LENS

3 LC 305 79- 001B -C RE MOC ON WIND OW 4AEM41 22- 001A -E CA B S PAC ER (x 2) 5 AE M40 69- A01- E SP ACE R (x 2)

! 100 LC10376- 020A -U FR ONT CA BINE T A SSY In c.N o.1 01～105 ! 101 LC 202 65- 017A -U DO OR (S ERV ICE )

10 2 CM 482 29- 00A- C DOOR LAT CH

! 103 LC 305 78- 007B -U PO WER KN OB (S ERV ICE )

10 4 AE M31 49- 001- E SPRIN G 10 5 LC 311 09- 006A -U CO NTR OL SHEE T

EXPLODED VIEW

V32H20EUS

102

101

105

103

104

100

No.51945

V32H20EUS

AV32H20EUS

Ref.No. Part No. Part Name Description

! V01 W7 6QD D25 7XV4 IT C T UBE (C) Inc.D Y,P C MA GNE T,WE DGE ! L01 QQ W01 05- 001 DE GAU SSI NG C OIL

! T2551 QQ H01 27- 001 H. V.T RAN SF.

6 WJ Y00 01-010A BR AID ED ASS Y 7 WJ Y00 13- 002A BR AID ED SU B AS SY

8CHFD1 25- 18BD FF C WI RE CN -1

! 9LC107 16- 002F -U CH ASS IS BASE ! 10LC107 17- 005D -U TE RMI NAL BOA RD

11 QYSBS B30 12M TAPPI NG SCRE W (x 3)

! 12LC103 80- 001C -U CO NTR OL BASE L ! 13LC103 80- 002B -U CO NTR OL BASE R

14 QAS00 88- 001 SPEAK ER SP 01- 02(x 2)

! 15LC107 20- 001D -U AD APT ER (x 2)

16 LC402 26- 003A -H SP ACE R (x 4) 17 LC405 06- 001A TA PPI NG SCRE W (x4)

! 18QMPK160- 185- JC PO WER CO RD CN -PW

! 19 CM 466 18- A01- E PO WER CO RD C LAM P ! 20 LC 103 78- 004B -U RE AR COV ER

21 QY SBSA G40 16N TA PPI NG SCRE W (x 13)

! 22 LC 203 79- 027A -U RA TIN G L ABEL ! 23 LC 307 89- 002B -U WA RNI NG LABE L ! 24 QQ R04 91-001 FILTE R

No.51945

EXPLODED VIEW

L0 1

V01

V32H20EUS

MAIN PWB

FRONT C ONT RO L PWB

MICOM PWB

CRT SOCKET PWB

10 0H z PW B

POWER & DEF. PWB

T2551

(×3)

AV SW PWB

(×13 )

No.51945

V32H20EUS

AV32H20EUS

PRINTED WIRING BOARD PARTS LIST

■ MAIN P.W. BOARD ASS’Y (SMF-1401A-U2)

Symbol No. Part No. Part Name Description

RESISTOR

R1004-06 NRSA63J-101X MG R 100Ω 1/16W J R1008-09 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R1102 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1103 NRSA63J-222X MG R 2.2kΩ 1/16W J R1104 NRSA63J-102X MG R 1kΩ 1/16W J R1105 NRSA63J-561X MG R 560Ω 1/16W J R1106 NRSA63J-331X MG R 330Ω 1/16W J

R1108 NRSA63J-102X MG R 1kΩ 1/16W J

R1109-11 NRSA63J-101X MG R 100Ω 1/16W J R1151 NRSA63J-101X MG R 100Ω 1/16W J R1153 NRSA63J-101X MG R 100Ω 1/16W J R1156 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1158-59 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1161 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R1301-02 NRSA63J-101X MG R 100Ω 1/16W J R1303 NRSA63J-273X MG R 27kΩ 1/16W J

R1304 NRSA63J-102X MG R 1kΩ 1/16W J R1311 NRSA63J-331X MG R 330Ω 1/16W J R1312 NRSA63J-273X MG R 27kΩ 1/16W J R1313 NRSA63J-183X MG R 18kΩ 1/16W J

R1314 NRSA63J-221X MG R 220Ω 1/16W J R1315-17 NRSA63J-101X MG R 100Ω 1/16W J R1318 NRSA63J-562X MG R 5.6kΩ 1/16W J R1319 NRSA63J-183X MG R 18kΩ 1/16W J

R1321-22 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1325 NRSA63J-101X MG R 100Ω 1/16W J R1326 NRSA63J-682X MG R 6.8kΩ 1/16W J R1401-02 NRSA63J-102X MG R 1kΩ 1/16W J

R1403-04 NRSA63J-331X MG R 330Ω 1/16W J R1405-06 NRSA63J-102X MG R 1kΩ 1/16W J R1451 NRSA63J-821X MG R 820Ω 1/16W J R1454 NRSA63J-472X MG R 4.7kΩ 1/16W J

R1455-56 NRSA63J-123X MG R 12kΩ 1/16W J R1457 NRSA63J-392X MG R 3.9kΩ 1/16W J R1458 NRSA63J-123X MG R 12kΩ 1/16W J

R1459 NRSA63J-472X MG R 4.7kΩ 1/16W J R1461 NRSA63J-123X MG R 12kΩ 1/16W J R1462 NRSA63J-153X MG R 15kΩ 1/16W J R1463 NRSA63J-124X MG R 120kΩ 1/16W J R1464 NRSA63J-563X MG R 56kΩ 1/16W J

R1465-66 NRSA63J-224X MG R 220kΩ 1/16W J R1467 NRSA63J-563X MG R 56kΩ 1/16W J

R1468 NRSA63J-224X MG R 220kΩ 1/16W J R1469 NRSA63J-683X MG R 68kΩ 1/16W J R1470 NRSA63J-223X MG R 22kΩ 1/16W J R1471 NRSA63J-273X MG R 27kΩ 1/16W J R1472 NRSA63J-682X MG R 6.8kΩ 1/16W J R1473 NRSA63J-123X MG R 12kΩ 1/16W J

R1474 NRSA63J-563X MG R 56kΩ 1/16W J R1475 NRSA63J-153X MG R 15kΩ 1/16W J

R1476-78 NRSA63J-123X MG R 12kΩ 1/16W J R1479 NRSA63J-154X MG R 150kΩ 1/16W J R1480 NRSA63J-823X MG R 82kΩ 1/16W J R1481 NRSA63J-472X MG R 4.7kΩ 1/16W J R1482 NRSA63J-272X MG R 2.7kΩ 1/16W J R1483 NRSA63J-472X MG R 4.7kΩ 1/16W J

R1484 NRSA63J-473X MG R 47kΩ 1/16W J R1485 NRSA63J-123X MG R 12kΩ 1/16W J R1486 NRSA63J-472X MG R 4.7kΩ 1/16W J R1487 NRSA63J-333X MG R 33kΩ 1/16W J R1489 NRSA63J-333X MG R 33kΩ 1/16W J R1491 NRSA63J-472X MG R 4.7kΩ 1/16W J

R1492 NRSA63J-562X MG R 5.6kΩ 1/16W J R1493 NRSA63J-183X MG R 18kΩ 1/16W J

Symbol No. Part No. Part Name Description

RESISTOR

R1501 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1504 NRSA63J-102X MG R 1kΩ 1/16W J R1511 NRSA63J-152X MG R 1.5kΩ 1/16W J R1512 NRSA63J-332X MG R 3.3kΩ 1/16W J

R1521 NRSA63J-223X MG R 22kΩ 1/16W J R1522 NRSA63J-562X MG R 5.6kΩ 1/16W J R1551 NRSA63J-100X MG R 10Ω 1/16W J R1552 NRSA63J-124X MG R 120kΩ 1/16W J

R1553 NRSA63J-683X MG R 68kΩ 1/16W J R1554 NRSA63J-562X MG R 5.6kΩ 1/16W J

R1555 NRSA63J-333X MG R 33kΩ 1/16W J R1556 NRSA63J-472X MG R 4.7kΩ 1/16W J R1557 NRSA63J-562X MG R 5.6kΩ 1/16W J R1558 NRSA63J-104X MG R 100kΩ 1/16W J R1559 NRSA63J-154X MG R 150kΩ 1/16W J R1560 NRSA63J-100X MG R 10Ω 1/16W J

R1561 QRN143J-0R0X C R 0.0Ω 1/4W J R1562 NRSA63J-683X MG R 68kΩ 1/16W J

R1563 NRSA63J-103X MG R 10kΩ 1/16W J R1564 NRSA63J-223X MG R 22kΩ 1/16W J R1565 NRSA63J-562X MG R 5.6kΩ 1/16W J R1591 NRSA63J-561X MG R 560Ω 1/16W J R1592 NRSA63J-332X MG R 3.3kΩ 1/16W J

R1595 NRSA63J-222X MG R 2.2kΩ 1/16W J

R1596 NRSA63J-104X MG R 100kΩ 1/16W J R1601 NRSA63J-273X MG R 27kΩ 1/16W J

R1602 NRSA63J-103X MG R 10kΩ 1/16W J R1603 NRSA63J-273X MG R 27kΩ 1/16W J R1604 NRSA63J-103X MG R 10kΩ 1/16W J R1605 NRSA63J-473X MG R 47kΩ 1/16W J R1606 NRSA63J-273X MG R 27kΩ 1/16W J

R1609 NRSA63J-104X MG R 100kΩ 1/16W J

R1610 NRSA63J-682X MG R 6.8kΩ 1/16W J R1618 NRSA63J-333X MG R 33kΩ 1/16W J R1619 NRSA63J-104X MG R 100kΩ 1/16W J R1620 NRSA63J-562X MG R 5.6kΩ 1/16W J R1637 QRK126J-2R2X C R 2.2Ω 1/2W J

R1639 NRSA63J-561X MG R 560Ω 1/16W J R1642-43 NRSA63J-681X MG R 680Ω 1/16W J R1644 NRSA63J-104X MG R 100kΩ 1/16W J

R1645-46 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1649 QRK126J-2R2X C R 2.2Ω 1/2W J R1650-51 NRSA63J-103X MG R 10kΩ 1/16W J R1654-55 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1664-65 NRSA63J-103X MG R 10kΩ 1/16W J

R1666 NRSA63J-473X MG R 47kΩ 1/16W J R1667 NRSA63J-183X MG R 18kΩ 1/16W J R1668 NRSA63J-473X MG R 47kΩ 1/16W J

R1669 NRSA63J-183X MG R 18kΩ 1/16W J R1670-71 NRSA63J-104X MG R 100kΩ 1/16W J R1672 NRSA63J-223X MG R 22kΩ 1/16W J R1673 NRSA63J-273X MG R 27kΩ 1/16W J

R1675 NRSA63J-103X MG R 10kΩ 1/16W J R1677-78 NRSA63J-103X MG R 10kΩ 1/16W J R1679 NRSA63J-223X MG R 22kΩ 1/16W J R1680 NRSA63J-273X MG R 27kΩ 1/16W J

R1684 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1687 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R1701-02 NRSA63J-103X MG R 10kΩ 1/16W J R1703-04 NRSA63J-102X MG R 1kΩ 1/16W J R1705-08 NRSA63J-103X MG R 10kΩ 1/16W J R1711-12 NRSA63J-101X MG R 100Ω 1/16W J R1714-15 NRSA63J-102X MG R 1kΩ 1/16W J R1720-22 NRSA63J-102X MG R 1kΩ 1/16W J

No. 51945

V32H20EUS

Symbol No. Part No. Part Name Description

RESISTOR

R1772-76 NRSA63J-221X MG R 220Ω 1/16W J R1951 QRK126J-220X C R 22Ω 1/2W J

CAPACITOR

C1001 NCB31HK-222X C CAP. 2200pF 50V K C1002 QETN1HM-106Z E CAP. 10µF 50V M C1004 NCB31CK-104X C CAP. 0.1µF 16V K

C1005 QETN1CM-108Z E CAP. 1000µF 16V M C1006 NCB31HK-103X C CAP. 0.01µF 50V K C1007 QETN1HM-106Z E CAP. 10µF 50V M C1009 NCB31CK-104X C CAP. 0.1µF 16V K C1010 QETN1HM-106Z E CAP. 10µF 50V M

C1101 NCB31CK-104X C CAP. 0.1µF 16V K C1102 QETN1HM-106Z E CAP. 10µF 50V M C1103 NCB31CK-104X C CAP. 0.1µF 16V K

C1104 QETN1CM-107Z E CAP. 100µF 16V M C1105 QETN1HM-106Z E CAP. 10µF 50V M C1106-07 NCB31CK-104X C CAP. 0.1µF 16V K

C1108 NDC31HJ-680X C CAP. 68pF 50V J C1111 NCB31HK-103X C CAP. 0.01µF 50V K

C1116 NCB31HK-472X C CAP. 4700pF 50V K C1117-18 NCB31HK-103X C CAP. 0.01µF 50V K C1119-20 NDC31HJ-2R0X C CAP. 2.0pF 50V J

C1121 NCB31HK-103X C CAP. 0.01µF 50V K C1122-23 NDC31HJ-102X C CAP. 1000pF 50V J

C1124-25 QETN1HM-106Z E CAP. 10µF 50V M C1126 NCB31CK-104X C CAP. 0.1µF 16V K C1127 QETN1HM-106Z E CAP. 10µF 50V M

C1128 NCB31CK-104X C CAP. 0.1µF 16V K C1129 NCF31AZ-105X C CAP. 1µF 10V Z C1130 QETN1HM-106Z E CAP. 10µF 50V M C1151-54 NCF31AZ-105X C CAP. 1µF 10V Z

C1155-56 NDC31HJ-102X C CAP. 1000pF 50V J C1301 QETN1CM-107Z E CAP. 100µF 16V M

C1302-03 NCB31CK-104X C CAP. 0.1µF 16V K C1305-09 NCB31CK-104X C CAP. 0.1µF 16V K

C1310 QETN1AM-228Z E CAP. 2200µF 10V M C1311 NCB31CK-683X CHIP CAP. 0.068 µF 16V K

C1312 NDC31HJ-221X C CAP. 220pF 50V J C1313-15 NCB31HK-223X C CAP. 0.022 µF 50V K C1316-18 NCB31HK-103X C CAP. 0.01µF 50V K C1320 QETN0JM-228Z E CAP. 2200µF 6.3V M C1321-23 NCB31HK-223X C CAP. 0.022 µF 50V K

C1324 NDC31HJ-820X C CAP. 82pF 50V J

C1351 QENC1EM-106Z BP E CAP. 10µF 25V M C1401 NCB31CK-104X C CAP. 0.1µF 16V K C1402 QETN1CM-107Z E CAP. 100µF 16V M

C1403-04 NCB31CK-104X C CAP. 0.1µF 16V K C1453 NCB31HK-103X C CAP. 0.01µF 50V K C1454 NCB31EK-333X C CAP. 0.033 µF 25V K C1455-56 NCB31CK-104X C CAP. 0.1µF 16V K C1457 NCB31EK-333X C CAP. 0.033 µF 25V K

C1458 NCB31CK-104X C CAP. 0.1µF 16V K C1471 NCB31CK-104X C CAP. 0.1µF 16V K

C1472 NCB31HK-103X C CAP. 0.01µF 50V K C1473 NCB31CK-104X C CAP. 0.1µF 16V K C1474 NCB31EK-333X C CAP. 0.033 µF 25V K C1475 NCB31CK-104X C CAP. 0.1µF 16V K C1491 NCB31EK-473X C CAP. 0.047 µF 25V K

C1501-02 NDC31HJ-150X C CAP. 15pF 50V J

C1551-52 NCF31CZ-224X C CAP. 0.22µF 16V Z C1553 QETN1EM-476Z E CAP. 47µF 25V M C1554-55 NCF31CZ-224X C CAP. 0.22µF 16V Z

C1560 QETN1CM-107Z E CAP. 100µF 16V M

Symbol No. Part No. Part Name Description

CAPACITOR

C1561 NDC31HJ-561X C CAP. 560pF 50V J C1562 QETN1HM-105Z E CAP. 1µF 50V M

C1564 NCB31CK-104X C CAP. 0.1µF 16V K C1591 NDC31HJ-471X C CAP. 470pF 50V J

C1596 NCB31CK-104X C CAP. 0.1µF 16V K C1600 QETN1HM-226Z E CAP. 22µF 50V M C1606-07 QETN1CM-227Z E CAP. 220µF 16V M C1616 QETN1HM-105Z E CAP. 1µF 50V M

C1618 QETN1HM-105Z E CAP. 1µF 50V M C1628 QETN1HM-107Z E CAP. 100µF 50V M C1629 QETN1HM-106Z E CAP. 10µF 50V M C1630 NCF21HZ-224X C CAP. 0.22µF 50V Z

C1632 NCF21HZ-224X C CAP. 0.22µF 50V Z C1634 QETM1HM-228 E CAP. 2200 µF 50V M C1641-42 NCF21HZ-224X C CAP. 0.22µF 50V Z C1646-47 NCB31HK-103X C CAP. 0.01µF 50V K

C1648-49 QETM1VM-108 E CAP. 1000 µF 35V M C1673-74 NCF31 AZ-105X C CAP. 1µF 10V Z

C1675 QETN1EM-476Z E CAP. 47µF 25V M C1676-77 NDC31HJ-151X C CAP. 150pF 50V J

C1678-79 NDC31HJ-150X C CAP. 15pF 50V J C1680 NCF31AZ-105X C CAP. 1µF 10V Z

C1681 NCB31HK-332X C CAP. 3300pF 50V K C1682 NCB31EK-333X C CAP. 0.033 µF 25V K

C1683 QETN1EM-476Z E CAP. 47µF 25V M C1684 NCB31HK-332X C CAP. 3300pF 50V K

C1685 NCB31EK-333X C CAP. 0.033 µF 25V K C1686 NCF31AZ-105X C CAP. 1µF 10V Z

C1687 QETN1HM-106Z E CAP. 10µF 50V M C1688 QETN1EM-476Z E CAP. 47µF 25V M C1689 NCB31CK-104X C CAP. 0.1µF 16V K C1695 NRSA63J-0R0X MG R 0.0Ω 1/16W J

C1698 NRSA63J-0R0X MG R 0.0Ω 1/16W J C1699 NCB31HK-103X C CAP. 0.01µF 50V K C1701 QETN1HM-106Z E CAP. 10µF 50V M

C1702 NCB31CK-563X CHIP CAP. 0.056µF 16V K C1951 QETN1CM-477Z E CAP. 470µF 16V M C1952-53 NCB31CK-104X C CAP. 0.1µF 16V K C1954 QETN1AM-477Z E CAP. 470µF 10V M C1955 QETN1AM-227Z E CAP. 220µF 10V M

C1956 QETN1AM-107Z E CAP. 100µF 10V M

COIL

L1001 QQL244K-270Z PEAKING COIL L1002-03 QQL244K-100Z COIL 10µH K

L1101 QRN143J-0R0X C R 0.0Ω 1/4W J L1102 QQL244K-4R7Z COIL 4.7µH K

L1301-02 NQL092K-1R5X INDUCTOR L1951 QQL26AM-5R6Z CHOKE COIL

DIODE

D1317-18 MA111-X SI.DIODE D1319 MA3036-X ZENER DIODE

D1320-21 MA3056/M/-X ZENER DIODE D1471-74 MA111-X SI.DIODE D1475 MA3240/M/-X CHIP ZENER DIODE D1521 MA111-X SI.DIODE D1591 MA111-X SI.DIODE D1592 MA3051/M/-X ZENER DIODE

D1593 MA111-X SI.DIODE D1602 MA111-X SI.DIODE D1610-11 MA111-X SI.DIODE D1614-15 MA111-X SI.DIODE

D1617 MA111-X SI.DIODE D1619-20 MA3330/L/-X ZENER DIODE

No. 51945

V32H20EUS

Symbol No. Part No. Part Name Description

DIODE

D1771-74 MA3056/M/-X ZENER DIODE D1951 1SR35-400A-T2 SI.DIODE D1981-82 MA111-X SI.DIODE

TRANSISTOR

Q1101-02 2SC2412K/QR/-X SI.TRANSISTOR Q1301 2SA1037AK/QR/-X SI.TRANSISTOR Q1471-72 2SC2412K/QR/-X SI.TRANSISTOR

Q1561 2SC2412K/QR/-X SI.TRANSISTOR Q1562 2SA1037AK/QR/-X SI.TRANSISTOR Q1591 2SA1037AK/QR/-X SI.TRANSISTOR Q1592 2SC2412K/QR/-X SI.TRANSISTOR Q1601-02 2SA1037AK/QR/-X SI.TRANSISTOR

Q1604-05 DTC124EKA-X DIGI.TRANSISTOR Q1606 2SC2412K/QR/-X SI.TRANSISTOR Q1607 DTA124EKA-X DIGI.TRANSISTOR Q1615 2SA1037AK/QR/-X SI.TRANSISTOR Q1616-17 DTC323TK-X DIGI.TRANSISTOR

IC1101 MSP3415DQGB3GHX I.C(MONO-ANA) IC1301 SDA9380 I.C(M)

IC1402 BA10324AF-XE I.C(MONO-ANA) IC1471 BA10358F-XE I.C(M) IC1551 LA6515 I.C(MONO-ANA) IC1601 TA8246AH I.C(HYBRID) IC1662 BA4558F-X I.C(MONO-ANA)

IC1663 NJM2150AM-X I.C(MONO-ANA)

IC1701 JLC1562BF-X I.C(DIGI-MOS) IC1951 BA09T I.C(MONO-ANA) IC1952 BA08T I.C(MONO-ANA)

OTHERS

CN1013 QGA2501C1-10 W TO B CONNE LC1102 NQR0431-001X EMI FILTER LC1301-03 NQR0431-001X EMI FILTER

J1001 QNN0296-001 PIN JACK K1001 NQR0389-003X FERRITE BEADS K1101-02 NQR0389-003X FERRITE BEADS K1301 NQR0413-003X BEADS CORE K1601-02 CE42681-001Y BEADS CORE

TU1001 QAU0276-001 TUNER X1101 CE42546-001Z CRYSTAL X1501 QAX0549-001Z CRYSTAL

Y1612-13 NCF21CZ-105X C CAP. 1µF 16V Z

■■■■POWER & DE F. P.W. BOARD ASS’Y

(SMF -2401A-U2)

Symbol No. Part No. Part Name Description

RESISTOR

R2401-02 QRE141J-562Y C R 5.6kΩ 1/4W J R2403 QRE141J-222Y C R 2.2kΩ 1/4W J R2404 QRX01GJ-1R0 MF R 1.0Ω 1W J R2405 QRL029J-151 OM R 150Ω 2W J R2406 QRE141J-222Y C R 2.2kΩ 1/4W J R2407 QRX01GJ-2R2 MF R 2.2Ω 1W J R2408 QRX01GJ-1R5 MF R 1.5Ω 1W J

R2409 QRE141J-823Y C R 82kΩ 1/4W J

R2410 QRE141J-103Y C R 10kΩ 1/4W J R2421 QRE141J-103Y C R 10kΩ 1/4W J R2422 QRE141J-274Y C R 270kΩ 1/4W J R2461 QRG029J-820 OM R 82 Ω 2W J R2462 QRE141J-473Y C R 47kΩ 1/4W J R2463 QRE141J-682Y C R 6.8kΩ 1/4W J

R2464 QRX01GJ-3R3 MF R 3.3Ω 1W J R2468 QRE141J-102Y C R 1kΩ 1/4W J

R2469 QRE141J-272Y C R 2.7kΩ 1/4W J R2471 QRE141J-391Y C R 390Ω 1/4W J R2472 QRA14CF-1002Y MF R 10kΩ 1/4W F R2473 QRE141J-473Y C R 47kΩ 1/4W J R2474 QRE141J-103Y C R 10kΩ 1/4W J R2475 QRE141J-102Y C R 1kΩ 1/4W J

R2476 QRE141J-102Y C R 1kΩ 1/4W J R2477 QRE141J-563Y C R 56kΩ 1/4W J

R2478 QRE141J-333Y C R 33kΩ 1/4W J R2501 QRE141J-471Y C R 470Ω 1/4W J R2502 QRE141J-123Y C R 12kΩ 1/4W J R2503 QRE121J-152Y C R 1.5kΩ 1/2W J

R2504-05 QRL039J-222 OM R 2.2kΩ 3W J R2506 QRE121J-5R6Y C R 5.6Ω 1/2W J R2521 QRE121J-471Y C R 470Ω 1/2W J R2522 QRE141J-223Y C R 22kΩ 1/4W J

R2523 QRE141J-103Y C R 10kΩ 1/4W J R2524 QRC121K-152Z COMP.R 1.5kΩ 1/2W K R2525 QRL039J-103 OM R 10kΩ 3W J R2541 QRE141J-182Y C R 1.8kΩ 1/4W J

R2542 QRE141J-222Y C R 2.2kΩ 1/4W J R2543 QRE121J-272Y C R 2.7kΩ 1/2W J

R2551 QRZ9022-R47 F R 0.47 Ω 1W K

R2552 QRZ9022-R47 F R 0.47 Ω 1W K

R2555 QRZ9022-R33 F R 0.33 Ω 1W K R2561 QRG01GJ-220 OM R 22Ω 1W J R2562 QRE121J-123Y C R 12kΩ 1/2W J

R2563 QRZ0056-103Z COMP R 10kΩ 1/2W K R2581 QRF154K-4R7 UNF R 4.7Ω 15W K R2582 QRE141J-681Y C R 680Ω 1/4W J R2583 QRE121J-682Y C R 6.8kΩ 1/2W J R2584 QRE141J-183Y C R 18kΩ 1/4W J

R2585 QRE141J-222Y C R 2.2kΩ 1/4W J R2586 QRA14CF-6201Y MF R 6.2kΩ 1/4W F

R2587 QRA14CF-2801Y MF R 2.8kΩ 1/4W F R2588 QRE141J-103Y C R 10kΩ 1/4W J

R2591 QRZ9017-4R7 F R 4.7 Ω 1/4W J R2901 QRE121J-331Y C R 330Ω 1/2W J R2902 QRF054K-3R3 UNF R 3.3Ω 5W K

R2903 QRF104K-3R9 UNF R 3.9Ω 10W K

R2904 QRL039J-683 OM R 68kΩ 3W J R2905-06 QRE121J-474Y C R 470kΩ 1/2W J

R2908-09 QRL039J-823 OM R 82kΩ 3W J R2910 QRZ9017-100 F R 10 Ω 1/4W K

R2911 QRE121J-152Y C R 1.5kΩ 1/2W J R2914 QRM059J-R10 MP R 0.10Ω 5W J R2915 QRE121J-681Y C R 680Ω 1/2W J

R2916 QRE121J-332Y C R 3.3kΩ 1/2W J

No. 51945

V32H20EUS

Symbol No. Part No. Part Name Description

RESISTOR

R2931 QRE141J-1R0Y C R 1.0Ω 1/4W J R2932 QRE141J-1R5Y C R 1.5Ω 1/4W J R2933 QRE141J-1R8Y C R 1.8Ω 1/4W J R2944 QRE141J-103Y C R 10kΩ 1/4W J R2945 QRE141J-563Y C R 56kΩ 1/4W J R2946 QRE141J-103Y C R 10kΩ 1/4W J R2951 QRE121J-102Y C R 1kΩ 1/2W J

R2952 QRL039J-223 OM R 22kΩ 3W J

R2953 QRE141J-474Y C R 470kΩ 1/4W J R2954 QRE141J-103Y C R 10kΩ 1/4W J R2981 QRE141J-153Y C R 15kΩ 1/4W J R2982 QRE141J-102Y C R 1kΩ 1/4W J

R2991 QRZ9046-825Z C R 8.2MΩ 1/2W K

CAPACITOR

C2404 QCZ0120-104Z C CAP. 0.1µF 25V Z C2405 QDC31HJ-820Z C CAP. 82pF 50V J

C2406 QETM1VM-108 E CAP. 1000 µF 35V M C2408 QETN1VM-337Z E CAP. 330µF 35V M C2409-10 QFV71HJ-474Z MF CAP. 0.47µF 50V J C2411 QFLC2AJ-104Z M CAP. 0.1µF 100V J

C2414 QCB31HK-682Z C CAP. 6800pF 50V K C2421 QETN1HM-105Z E CAP. 1µF 50V M

C2461 QEZ0414-226 E CAP. 22µF 50V M C2462 QFM72DJ-152Z M CAP. 1500pF 200V J

C2463 QFM72DJ-122Z M CAP. 1200pF 200V J C2464 QCZ0120-104Z C CAP. 0.1µF 25V Z C2465 QETN1HM-106Z E CAP. 10µF 50V M

C2466 QFP31HJ-272Z PP CAP. 2700pF 50V J C2467 QFLC1HJ-102Z M CAP. 1000pF 50V J

C2468 QETN1EM-476Z E CAP. 47µF 25V M

C2470 QCS31HJ-470Z C CAP. 47pF 50V J C2471 QFLC1HJ-103Z M CAP. 0.01µF 50V J

C2501 QCB32HK-331Z C CAP. 330pF 500V K C2502 QFM72DK-103 M CAP. 0.01µF 200V K C2503 QFV71HJ-224Z MF CAP. 0.22µF 50V J

C2521 QFZ0122-112 MPP CAP. 1100pF1.8kVH±3% C2522 QFZ0200-123 MPP CAP. 0.012 µF1.5kVH±3%

C2523 QFM72DK-393 M CAP. 0.039µF 200V K

C2524 QFP32JJ-183 PP CAP. 0.018µF 630V J

C2526 QFZ0197-204 MPP CAP. 0.2µF 250V J C2527 QFZ0194-154 MPP CAP. 0.15µF 250V J C2529 QFZ0194-154 MPP CAP. 0.15µF 250V J

C2530 QCB32HK-561Z C CAP. 560pF 500V K C2531 QFZ0194-534 MPP CAP. 0.53µF 250V J C2532 QETM2CM-227 E CAP. 220µF 160V M C2533 QETN2EM-475Z E CAP. 4.7µF 250V M

C2541 QENC1HM-105Z E CAP. 1µF 50V M C2551 QCB32HK-152Z C CAP. 1500pF 500V K

C2552 QETN1CM-108Z E CAP. 1000µF 16V M C2553 QCB32HK-152Z C CAP. 1500pF 500V K

C2554 QETN1CM-108Z E CAP. 1000µF 16V M C2555 QCB32HK-102Z C CAP. 1000pF 500V K

C2556 QETN2EM-106Z E CAP. 10µF 250V M C2558 QETN1CM-477Z E CAP. 470µF 16V M

C2559 QEHR1CM-227Z E CAP. 220µF 16V M C2561 QFLC2AJ-223Z M CAP. 0.022µF 100V J

C2581 QETN1CM-107Z E CAP. 100µF 16V M C2582 QETN1EM-476Z E CAP. 47µF 25V M C2583 QETN2AM-106Z E CAP. 10µF 100V M C2584 QETN1AM-227Z E CAP. 220µF 10V M

C2901 QFZ9072-473 MM CAP. 0.47µFAC275V K C2902 QFZ9072-104 MF CAP. 0.1µFAC275V K

C2903 QFZ9072-473 MM CAP. 0.47µFAC275V K

Symbol No. Part No. Part Name Description

CAPACITOR

C2904 QCZ9054-472 C CAP. 4700pFAC250V Z C2905 QCZ9054-472 C CAP. 4700pFAC250V Z C2906 QCZ9054-472 C CAP. 4700pFAC250V Z

C2907 QEZ0199-227 E CAP. 220µF 400V M C2908 QCB32HK-103 C CAP. 0.01µF 500V K

C2909 QCZ0340-391 C CAP. 390pF 2kV K C2910 QETN1HM-476Z E CAP. 47µF 50V M

C2911 QCB31HK-102Z C CAP. 1000pF 50V K

C2912 QCZ0340-561 C CAP. 560pF 2kV K C2914 QCB31HK-471Z C CAP. 470pF 50V K

C2915 QFLC1HJ-104Z M CAP. 0.1µF 50V J C2916 QCB32HK-152Z C CAP. 1500pF 500V K

C2931 QCZ9054-472 C CAP. 4700pFAC250V Z

C2932 QCZ9054-472 C CAP. 4700pFAC250V Z C2933 QCZ9054-472 C CAP. 4700pFAC250V Z

C2934 QETM2GM-226 E CAP. 22µF 400V M

C2941 QTMN1CM-477Z E CAP. 470µF 16V M C2942 QETN1AM-337Z E CAP. 330µF 10V M C2951 QEZ0203-227 E CAP. 220µF 160V M C2952 QETN1CM-108Z E CAP. 1000µ F 16V M

C2955 QETM1VM-228 E CAP. 2200µF 35V M C2956 QETN1AM-108Z E CAP. 1000µ F 10V M C2957 QETN1AM-228Z E CAP. 2200µ F 10V M C2959 QFV71HJ-684Z MF CAP. 0.68µF 50V J

C2960 QCZ0325-821 C CAP. 820pF 2kV K C2972-73 QETN1AM-477Z E CAP. 470µF 10V M C2974 QETN0JM-228Z E CAP. 2200µF 6.3V M C2975 QETN1AM-228Z E CAP. 2200µ F 10V M

C2991 QCZ9079-222 C CAP. 2200pFAC250V M

C2993 QCZ9079-471 C CAP. 470pFAC250V K

TRANSFORMER

T2501 QQR0882-001 HOR.DEF.TRANSF.

T2551 QQH0127-001 H.V.TRANSF. T2561 QQR1096-001 DEF.TR ANSF T2901 QQS0156-001 SWITCH.TRANSF.

COIL

L2461 QQR1195-001 CHOKE COIL L2462 QQLZ028-272 CHOKE COIL

L2521 QQLZ031-180 CHOKE COIL L2522 QQR1191-001 LINEARITY COIL

L2552 QQL26AK-220Z COIL 22µH K L2561 QQLZ028-272 CHOKE COIL L2901-02 QQL401K-100Z CHOKE COIL L2903 QQR1200-001 CHOKE COIL

L2951 QQLZ026-460 HEATER CHOKE L2959-60 QQL26AK-220Z COIL 22µH K

L2961 QQL26AM-4R7Z CHOKE COIL

DIODE

D2402 1SR35-400A-T2 SI.DIODE D2421 1SS133-T2 SI.DIODE

D2461 RGP10J-5025-T3 SI.DIODE D2462 1SS133-T2 SI.DIODE D2463 1SS133-T2 SI.DIODE D2501 1SS81-T5 SI.DIODE

D2521 V11CA-C1 SI.DIODE D2522 FMV-3FU-F1 SI.DIODE

D2523 MTZJ22B-T2 ZENER DIODE D2524 1SR35-400A-T2 SI.DIODE

D2525 RGP10J-5025-T3 SI.DIODE D2541 RGP10J-5025-T3 SI.DIODE D2542 MTZJ3.9B-T2 ZENER DIODE D2551 RGP10J-5025-T3 SI.DIODE D2552 RGP10J-5025-T3 SI.DIODE

D2553 RH1S-T3 SI.DIODE

No. 51945

V32H20EUS

Symbol No. Part No. Part Name Description

DIODE

D2582 MTZJ7.5B-T2 ZENER DIODE D2583 MTZJ7.5S-T2 ZENER DIODE D2584 RGP10J-5025-T3 SI.DIODE

D2901 D3SB60 BRIDGE DIODE D2902 RG1C-LFA1 SI.DIODE

D2904 EU2A-T2 SI.DIODE D2905 1SS133-T2 SI.DIODE D2906 MTZJ27B-T2 ZENER DIODE

D2907 1SS133-T2 SI.DIODE D2908 1SS133-T2 SI.DIODE D2910 MTZJ15B-T2 ZENER DIODE D2911 1SS133-T2 SI.DIODE D2931 S1WB/A/60-4101 SI.DIODE

D2945 1SS133-T2 SI.DIODE D2951 RU4AM-LFT2 SI.DIODE

D2952 RGP10J-5025-T3 SI.DIODE

D2953 RU4AM-LFT2 SI.DIODE D2955 RU3YX-LFC4 SI.DIODE

D2956 RGP10J-5025-T3 SI.DIODE D2958 MTZJ33B-T2 ZENER DIODE D2959 RU3YX-LFC4 SI.DIODE D2960 1SR124-400A-T2 SI.DIODE D2961 1SS133-T2 SI.DIODE

D2981 1SS133-T2 SI.DIODE

D2984 1SS133-T2 SI.DIODE D2985 1SS133-T2 SI.DIODE

TRANSISTOR

Q2421 DTC124ESA-T DIGI.TRANSISTOR Q2422 2SC1740S/QR/-T SI.TRANSISTOR Q2461 2SK2459N-F54 F.E.T.

Q2462-63 2SC1740S/QR/-T SI.TRANSISTOR Q2464 2SA933AS/QR/-T SI.TRANSISTOR Q2501 BSN304-T F.E.T. Q2521 2SC5552-RL SI.TRANSISTOR H.OUT

Q2581 2SA1208/ST/Z1-T SI.TRANSISTOR

Q2582 DTC144ESA-T DIGI.TRANSISTOR Q2583 2SC1740S/QR/-T SI.TRANSISTOR Q2941-42 2SC1740S/QR/-T SI.TRANSISTOR

IC2401 AN5523 I.C(M) IC2461 BA10393 I.C(MONO-ANA) IC2551 BA12T I.C(MONO-ANA) IC2901 STR-F6667B/F7 I.C(HYBRID)

IC2902 QAL0425-001 P.W.B.MODULE IC2951 SE140N I.C(HYBRID) IC2954 BA05T I.C(MONO-ANA) IC2955 PQ3RD13 I.C(MONO-ANA)

OTHERS

CN2004-06 QGB1506M1-16 CONNECTOR CN2010 QGA2501C5-04Z W TO B CONNE CN2014 QGA2501C5-06Z EH POST HEADER

CP2951 ICP-N75-Y I.C.PROTECT

CP2952 ICP-N75-Y I.C.PROTECT

CP2953 ICP-N75-Y I.C.PROTECT CP2955 ICP-N75-Y I.C.PROTECT

K2401 QQR0621-002Z BEADS CORE

K2522-24 CE41832-001 LEAD CORE K2901 QQR0679-001 FERRITE BEADS LF2901 QQR1095-001 LINE FILTER

PC2901 PC123FY2 I.C(PH.COUPLER)

RY2931 QSK0099-001 RELAY

! !

TH2901 QAD0133-9R0 P.THEMISTOR

■■■■CRT SOCKET P.W. BOARD ASS’Y

(SMF -3401A-U2)

Symbol No. Part No. Part Name Description

RESISTOR

R3101 NRSA63J-223X MG R 22kΩ 1/16W J R3102 NRSA63J-681X MG R 680Ω 1/16W J R3103 NRSA63J-101X MG R 100Ω 1/16W J R3104 NRSA63J-822X MG R 8.2kΩ 1/16W J R3105 NRSA63J-102X MG R 1kΩ 1/16W J R3106 NRSA63J-221X MG R 220Ω 1/16W J R3107 NRSA63J-561X MG R 560Ω 1/16W J

R3109 NRSA63J-153X MG R 15kΩ 1/16W J

R3110 NRSA63J-222X MG R 2.2kΩ 1/16W J R3111 NRSA63J-182X MG R 1.8kΩ 1/16W J R3112 NRSA63J-272X MG R 2.7kΩ 1/16W J R3113 NRSA63J-331X MG R 330Ω 1/16W J R3114 NRSA63J-152X MG R 1.5kΩ 1/16W J R3115 NRSA63J-820X MG R 82Ω 1/16W J

R3116 QRG01GJ-101 OM R 100Ω 1W J R3117 NRSA63J-221X MG R 220Ω 1/16W J

R3122 NRSA63J-122X MG R 1.2kΩ 1/16W J R3123 QRE121J-563Y C R 56kΩ 1/2W J R3124 NRSA63J-470X MG R 47Ω 1/16W J R3125 QRE121J-563Y C R 56kΩ 1/2W J R3126 NRSA63J-470X MG R 47Ω 1/16W J R3127 NRSA63J-122X MG R 1.2kΩ 1/16W J

R3128 NRSA63J-390X MG R 39Ω 1/16W J R3129-30 QRE121J-2R7Y C R 2.7Ω 1/2W J

R3131 NRSA63J-390X MG R 39Ω 1/16W J R3132 NRSA63J-121X MG R 120Ω 1/16W J R3133 QRL029J-391 OM R 390Ω 2W J

R3134 QRZ9021-561 F R 560Ω 1W J R3204-06 NRSA63J-272X MG R 2.7kΩ 1/16W J

R3211 NRSA63J-154X MG R 150kΩ 1/16W J R3223-25 NRSA63J-272X MG R 2.7kΩ 1/16W J R3227 NRSA63J-103X MG R 10kΩ 1/16W J

R3228 NRSA63J-272X MG R 2.7kΩ 1/16W J R3229-31 QRL029J-104-F OM R 100kΩ 2W J R3232-34 NRSA63J-332X MG R 3.3kΩ 1/16W J R3235-37 QRC121K-152Z COMP.R 1.5kΩ 1/2W K

R3239 QRZ0107-474Z C R 470kΩ 1/2W K R3240 QRC121K-102Z MF R 1kΩ 1/2W K R3241 QRZ0107-105Z C R 1.0MΩ 1/2W K R3242 NRSA63J-103X MG R 10kΩ 1/16W J

R3244 NRSA63J-102X MG R 1kΩ 1/16W J R3245-47 NRSA63J-562X MG R 5.6kΩ 1/16W J R3301-02 QRE121J-474Y C R 470kΩ 1/2W J

R3303-04 NRSA63J-223X MG R 22kΩ 1/16W J R3305 NRSA63J-562X MG R 5.6kΩ 1/16W J R3306 NRSA63J-392X MG R 3.9kΩ 1/16W J R3310 NRSA63J-0R0X MG R 0.0Ω 1/16W J

CAPACITOR

C3102 NDC31HJ-8R0X C CAP. 8.0pF 50V J C3103 NDC31HJ-151X C CAP. 150pF 50V J

C3104 QCB31HK-103Z C CAP. 0.01µ F 50V K C3106 QETN1HM-335Z E CAP. 3.3µF 50V M

C3107 QETN1CM-107Z E CAP. 100µF 16V M C3110 QETN2CM-106Z E CAP. 10µ F 160V M

C3111 QCB32HK-472Z C CAP. 4700pF 500V K C3113 QETN2CM-106Z E CAP. 10µF 160V M

C3114 QCB32HK-472Z C CAP. 4700pF 500V K C3116-17 QETN1AM-107Z E CAP. 100µF 10V M

C3118 QETN1AM-337Z E CAP. 330µF 10V M C3120-21 NDC31HJ-221X C CAP. 220pF 50V J

C3201-03 NDC31HJ-8R0X C CAP. 8.0pF 50V J C3204-06 NCF31CZ-104X C CAP. 0.1µF 16V Z

C3207 -09 QETN1EM-476Z E CAP. 47µF 25V M C3210-12 QFK62EK-104Z MM CAP. 0.1µF 250V K

No. 51945

Symbol No. Part No. Part Name Description

CAPACITOR

C3213-15 NDC31HJ-181X C CAP. 180pF 50V J C3216 QETN1CM-107Z E CAP. 100µF 16V M

C3218 QETM2EM-336 E CAP. 33µF 250V M C3219 QFZ0097-223 MM CAP. 0.022µF 1250V K C3221 QETN2EM-106Z E CAP. 10µF 250V M C3302 QETN1AM-107Z E CAP. 100µF 10V M

COIL

L3101 QQL244K-5R6Z COIL 5.6µ H K L3204 QQL26AJ-102Z COIL 1mH J

DIODE

D3101-02 MA111-X SI.DIODE D3103 RH1S-T3 SI.DIODE

D3104 RH1S-T3 SI.DIODE D3204-06 EU01N-T2 SI.DIODE D3207 RM2C-LFA1 SI.DIODE D3208-10 1SR124-400A-T2 SI.DIODE D3211 MA3062/M/-X ZENER DIODE D3212-13 MA3130/H/-X ZENER DIODE

D3301 MA111-X SI.DIODE D3303 MA111-X SI.DIODE

TRANSISTOR

Q3101 2SC2412K/QR/-X SI.TRANSISTOR Q3102 2SA1037AK/QR/-X SI.TRANSISTOR Q3103 2SC1906-T SI.TRANSISTOR Q3104 2SC2412K/QR/-X SI.TRANSISTOR

Q3105 2SC1627A/OY/-T SI.TRANSISTOR Q3108 2SA1837 SI.TRANSISTOR Q3109 2SC4793 SI.TRANSISTOR Q3301 2SA1037AK/QR/-X SI.TRANSISTOR

IC3201-03 TDA6111Q I.C(MONO-ANA)

OTHERS

K3101 CE41492-001Z CHOKE COIL K3103-04 CE41492-001Z CHOKE COIL K3105 QQR0621-002Z BEADS CORE SG3201-03 QAF0056-501Z VARISTOR SK3001 QNZ0380-001 C.R.T.SOCKET

W3003 QQR0679-001 FERRITE BEADS W3022 QQR0679-001 FERRITE BEADS

V32H20EUS

■■■■FRONT CONTROL P.W. BOARD ASS’Y

(SMF -8401A-U2)

Symbol No. Part No. Part Name Description

RESISTOR

R8001-02 QRE121J-271Y C R 270Ω 1/2W J R8005 NRSA63J-221X MG R 220Ω 1/16W J R8008 NRSA63J-102X MG R 1kΩ 1/16W J R8010 NRSA63J-103X MG R 10kΩ 1/16W J R8012-13 NRSA63J-103X MG R 10kΩ 1/16W J R8021-22 NRSA63J-102X MG R 1kΩ 1/16W J R8035 QRE121J-151Y C R 150Ω 1/2W J

R8039 NRSA63J-331X MG R 330Ω 1/16W J

CAPACITOR

C8001-02 NCB31HK-103X C CAP. 0.01µF 50V K C8004 NCB31CK-104X C CAP. 0.1µF 16V K

C8005 NDC31HJ-680X C CAP. 68pF 50V J C8010-11 NCB31HK-472X C CAP. 4700pF 50V K

C8019 QETN1CM-107Z E CAP. 100µF 16V M C8021 NCB31CK-104X C CAP. 0.1µF 16V K C8022 QETN1EM-476Z E CAP. 47µF 25V M

C8901 QFZ9072-474 MF CAP. 0.47µFAC275V K

COIL

L8001 QQR0716-001Z LEAD CORE L8002-03 QQL244K-5R6Z COIL 5.6µH K

L8010-11 QQL244K-270Z PEAKING COIL L8012 QQR0716-001Z LEAD CORE

DIODE

D8010 SPR-39MVWF L.E.D. D8011 MA111-X SI.DIODE

D8014 MA3068/M/-X ZENER DIODE D8018 MA3033-X ZENER DIODE

TRANSISTOR

Q8002 DTC124EKA-X DIGI.TRANSISTOR Q8003-04 DTA124EKA-X DIGI.TRANSISTOR

IC8001 GP1U281Q IFR DETECT UNIT

OTHERS

CEMG002-001Z FUSE CLIP

F8901 QMF51D2-3R15J1 FUSE 3.15A LC8002 NQR0169-001X EMI FILTER

LF8901 QQR1095-001 LINE FILTER J8001 QMS3004-C01 HEADPHONE JACK J8003 QNZ0453-001 JACK

S8001 QSW0619-003Z PUSH SWITCH MENU

S8002 QSW0619-003Z PUSH SWITCH CH DOWN S8003 QSW0619-003Z PUSH SWITCH CH UP S8901 QSW0824-001 PUSH SWITCH MAIN POWER

LC30596-001B-C L.E.D.HOLDER

No. 51945

V32H20EUS

■■■■MICO M P.W. BOAR D AS S ’Y (SMF0M4 01A-U2 )

Symbol No. Part No. Part Name Description

RESISTOR

R0001 NRSA63J-102X MG R 1kΩ 1/16W J R0002 NRSA63J-104X MG R 100kΩ 1/16W J R0003-05 NRSA63J-102X MG R 1kΩ 1/16W J

R0006 NRSA63J-152X MG R 1.5kΩ 1/16W J R0007-08 NRSA63J-102X MG R 1kΩ 1/16W J R0009-11 NRSA63J-103X MG R 10kΩ 1/16W J R0012 NRSA63J-273X MG R 27kΩ 1/16W J R0013 NRSA63J-221X MG R 220Ω 1/16W J

R0014 NRSA63J-102X MG R 1kΩ 1/16W J R0015 NRSA63J-473X MG R 47kΩ 1/16W J R0016-17 NRSA63J-103X MG R 10kΩ 1/16W J

R0018 NRSA63J-102X MG R 1kΩ 1/16W J R0022 NRSA63J-472X MG R 4.7kΩ 1/16W J R0027 NRSA63J-472X MG R 4.7kΩ 1/16W J R0030 NRSA63J-472X MG R 4.7kΩ 1/16W J R0032 NRSA63J-472X MG R 4.7kΩ 1/16W J

R0034-53 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0055 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R0057-77 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0081 NCF31CZ-104X C CAP. 0.1µF 16V Z R0087 NRSA63J-221X MG R 220Ω 1/16W J R0089-91 NRSA63J-221X MG R 220Ω 1/16W J R0092 NRSA63J-472X MG R 4.7kΩ 1/16W J

R0093 NRSA63J-221X MG R 220Ω 1/16W J

R0094 NRSA63J-472X MG R 4.7kΩ 1/16W J R0095 NRSA63J-473X MG R 47kΩ 1/16W J

R0096 NRSA63J-221X MG R 220Ω 1/16W J R0097 NRSA63J-102X MG R 1kΩ 1/16W J R0098 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0099 NRSA63J-102X MG R 1kΩ 1/16W J R0100-02 NRSA63J-102X MG R 1kΩ 1/16W J

R0103-06 NRSA63J-103X MG R 10kΩ 1/16W J

R0107 NRSA63J-102X MG R 1kΩ 1/16W J R0110 NRSA63J-102X MG R 1kΩ 1/16W J R0111 NRSA63J-103X MG R 10kΩ 1/16W J R0112 NRSA63J-102X MG R 1kΩ 1/16W J R0113-14 NRSA63J-103X MG R 10kΩ 1/16W J R0119 NRSA63J-563X MG R 56kΩ 1/16W J

R0120 NRSA63J-332X MG R 3.3kΩ 1/16W J R0121 NRSA63J-182X MG R 1.8kΩ 1/16W J

R0122 NRSA63J-103X MG R 10kΩ 1/16W J R0123 NRSA63J-682X MG R 6.8kΩ 1/16W J R0124 NRSA63J-101X MG R 100Ω 1/16W J R0125-28 NRSA63J-472X MG R 4.7kΩ 1/16W J

R0129 NRSA63J-823X MG R 82kΩ 1/16W J R0130 NRSA63J-104X MG R 100kΩ 1/16W J R0131 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0133 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R0136 NRSA63J-103X MG R 10kΩ 1/16W J R0137-39 NRSA63J-222X MG R 2.2kΩ 1/16W J R0144 NRSA63J-103X MG R 10kΩ 1/16W J R0147 NRSA63J-472X MG R 4.7kΩ 1/16W J

R0151 NRSA63J-183X MG R 18kΩ 1/16W J R0152-54 NRSA63J-221X MG R 220Ω 1/16W J R0155-56 NRSA63J-101X MG R 100Ω 1/16W J R0157 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R0158 NRSA63J-221X MG R 220Ω 1/16W J R0165 NRSA63J-103X MG R 10kΩ 1/16W J R0166 NRSA63J-223X MG R 22kΩ 1/16W J

R0167 NRSA63J-103X MG R 10kΩ 1/16W J R0168 NRSA63J-471X MG R 470Ω 1/16W J R0169 NRSA63J-472X MG R 4.7kΩ 1/16W J

CAPACITOR

C0001 QETN0JM-477Z E CAP. 470µF 6.3V M

Symbol No. Part No. Part Name Description

CAPACITOR

C0002 NCF31CZ-104X C CAP. 0.1µF 16V Z C0003 NCB11CK-225X C CAP. 2.2µF 16V K C0004 QETN0JM-108Z E CAP. 1000µF 6.3V M C0005-06 NCB11CK-225X C CAP. 2.2µF 16V K C0007 NEH71CM-476X E CAP. 47µF 16V M C0012-13 NCF31CZ-104X C CAP. 0.1µF 16V Z

C0014 NCB31HK-682X C CAP. 6800pF 50V K C0017 NDC31HJ-150X C CAP. 15pF 50V J

C0019 NEH71CM-476X E CAP. 47µF 16V M C0020 NCF31CZ-104X C CAP. 0.1µF 16V Z C0021 NEH71CM-476X E CAP. 47µF 16V M C0022 NCF31AZ-105X C CAP. 1µ F 10V Z

C0023 NCB31EK-333X C CAP. 0.033µF 25V K C0024 NCF31CZ-104X C CAP. 0.1µF 16V Z C0027-28 NEH71CM-476X E CAP. 47µF 16V M

C0029 NDC31HJ-151X C CAP. 150pF 50V J

C0030-32 NCF31CZ-104X C CAP. 0.1µF 16V Z C0034-39 NCF31CZ-104X C CAP. 0.1µF 16V Z

C0040 NDC31HJ-330X C CAP. 33pF 50V J C0041 NDC31HJ-270X C CAP. 27pF 50V J

C0042-43 NCF31CZ-104X C CAP. 0.1µF 16V Z C0045-47 NCF31CZ-104X C CAP. 0.1µF 16V Z C0048 NEH71CM-476X E CAP. 47µF 16V M C0049-50 NCF31CZ-104X C CAP. 0.1µF 16V Z

C0051 NEH71CM-476X E CAP. 47µF 16V M C0052-57 NCF31CZ-104X C CAP. 0.1µF 16V Z C0059-61 NEH71CM-106X E CAP. 10µF 16V M

C0062 NRSA63J-0R0X MG R 0.0Ω 1/16W J C0063-65 NDC31HJ-820X C CAP. 82pF 50V J

COIL

L0001 NQL092K-4R7X INDUCTOR L0003 NQL092K-4R7X INDUCTOR

L0005-08 NQL092K-4R7X INDUCTOR L0009 NQL034K-4R7X INDUCTOR L0010-14 NQL092K-4R7X INDUCTOR L0015-16 NQL034K-4R7X INDUCTOR L0017-22 NQL092K-1R5X INDUCTOR

DIODE

D0001-02 MA111-X SI.DIODE D0003 MA3068/M/-X ZENER DIODE D0004 MA3027-X ZENER DIODE

D0005-08 MA3056/M/-X ZENER DIODE

TRANSISTOR

Q0001-02 2SC2712/YG/-X SI.TRANSISTOR Q0007-08 2SA1162/YG/-X SI.TRANSISTOR

Q0009-12 2SC2712/YG/-X SI.TRANSISTOR Q0021-22 2SC2712/YG/-X SI.TRANSISTOR

IC0001 SDA6000 I.C(M) IC0002 MR27V1652EB6RAZ I.C(M) IC0003 K4S161622D-TC80 I.C(D-RAM) IC0004 AT24LC-28H28EU I.C (SERVICE)

IC0005 S-80828CNNB-W I.C(M) IC0901 BA33C25FP-X I.C(M)

OTHERS

CN0001 QGB1505K1-50 CONNECTOR K0001 NRSA63J-390X MG R 39Ω 1/16W J K0002 NQR0389-003X FERRITE BEADS

K0003 NRSA63J-0R0X MG R 0.0Ω 1/16W J K0004 NQR0389-003X FERRITE BEADS

K0005 NRSA63J-0R0X MG R 0.0Ω 1/16W J LC0001 NQR0313-007X EMI FILTER

LC0002 NQR0431-001X EMI FILTER

X0001 QAX0669-001Z CRYSTAL

No. 51945

■■■■AV SW P.W. BOARD ASS’Y (SMF0S401A-U2)

V32H20EUS

Symbol No. Part No. Part Name Description

RESISTOR

R0101-09 NRSA63J-750X MG R 75Ω 1/16W J R0110-11 NRSA63J-103X MG R 10kΩ 1/16W J R0112-13 NRSA63J-823X MG R 82kΩ 1/16W J

R0114 NRSA63J-333X MG R 33kΩ 1/16W J R0115 NRSA63J-473X MG R 47kΩ 1/16W J R0116 NRSA63J-823X MG R 82kΩ 1/16W J R0117 NRSA63J-223X MG R 22kΩ 1/16W J R0118 NRSA63J-473X MG R 47kΩ 1/16W J

R0119 NRSA63J-153X MG R 15kΩ 1/16W J R0120 NRSA63J-273X MG R 27kΩ 1/16W J R0121 NRSA63J-222X MG R 2.2kΩ 1/16W J

R0122 NRSA63J-473X MG R 47kΩ 1/16W J R0123 NRSA63J-823X MG R 82kΩ 1/16W J R0124 NRSA63J-153X MG R 15kΩ 1/16W J R0125 NRSA63J-223X MG R 22kΩ 1/16W J R0126 NRSA63J-473X MG R 47kΩ 1/16W J

R0127 NRSA63J-273X MG R 27kΩ 1/16W J R0128-29 NRSA63J-823X MG R 82kΩ 1/16W J

R0130-31 NRSA63J-391X MG R 390Ω 1/16W J R0132 NRSA63J-222X MG R 2.2kΩ 1/16W J R0133 NRSA63J-333X MG R 33kΩ 1/16W J R0134 NRSA63J-222X MG R 2.2kΩ 1/16W J R0135 NRSA63J-333X MG R 33kΩ 1/16W J

R0136 NRSA63J-103X MG R 10kΩ 1/16W J

R0137 NRSA63J-222X MG R 2.2kΩ 1/16W J R0138-39 NRSA63J-333X MG R 33kΩ 1/16W J

R0140 NRSA63J-222X MG R 2.2kΩ 1/16W J R0141 NRSA63J-333X MG R 33kΩ 1/16W J R0142 NRSA63J-222X MG R 2.2kΩ 1/16W J R0143-44 NRSA63J-333X MG R 33kΩ 1/16W J R0145 NRSA63J-103X MG R 10kΩ 1/16W J

R0146 NRSA63J-473X MG R 47kΩ 1/16W J

R0147 NRSA63J-223X MG R 22kΩ 1/16W J R0148-49 NRSA63J-391X MG R 390Ω 1/16W J R0150-51 NRSA63J-104X MG R 100kΩ 1/16W J R0152-67 NRSA63J-101X MG R 100Ω 1/16W J R0168 NRSA63J-750X MG R 75Ω 1/16W J R0169 NRSA63J-222X MG R 2.2kΩ 1/16W J

R0170 NRSA63J-333X MG R 33kΩ 1/16W J R0171 NRSA63J-750X MG R 75Ω 1/16W J

R0172 NRSA63J-222X MG R 2.2kΩ 1/16W J R0173 NRSA63J-333X MG R 33kΩ 1/16W J R0174 NRSA63J-750X MG R 75Ω 1/16W J R0175 NRSA63J-333X MG R 33kΩ 1/16W J

R0176 NRSA63J-103X MG R 10kΩ 1/16W J R0177 NRSA63J-823X MG R 82kΩ 1/16W J R0178 NRSA63J-153X MG R 15kΩ 1/16W J R0179 NRSA63J-473X MG R 47kΩ 1/16W J

R0180 NRSA63J-273X MG R 27kΩ 1/16W J R0181-82 NRSA63J-562X MG R 5.6kΩ 1/16W J R0183-84 NRSA63J-102X MG R 1kΩ 1/16W J R0185-90 NRSA63J-101X MG R 100Ω 1/16W J

R0191 NRSA63J-222X MG R 2.2kΩ 1/16W J R0192 NRSA63J-101X MG R 100Ω 1/16W J R0194-95 NRSA63J-221X MG R 220Ω 1/16W J R0196 QRG01GJ-101 OM R 100Ω 1W J

R0197 QRK126J-181X C R 180Ω 1/2W J R0198 NRSA63J-750X MG R 75Ω 1/16W J R0199 NRSA63J-101X MG R 100Ω 1/16W J

R0200 NRSA63J-750X MG R 75Ω 1/16W J R0201 QRK126J-151X C R 150Ω 1/2W J R0203-05 NRSA63J-750X MG R 75Ω 1/16W J

CAPACITOR

C0101-10 NCB31HK-472X C CAP. 4700pF 50V K

Symbol No. Part No. Part Name Description

CAPACITOR

C0111-12 QETN1CM-477Z E CAP. 470µF 16V M C0113-14 NCB31HK-102X C CAP. 1000pF 50V K

C0115-17 QETN1HM-106Z E CAP. 10µF 50V M C0118-19 QETN1HM-105Z E CAP. 1µF 50V M C0120 NCB31HK-103X C CAP. 0.01µ F 50V K C0121 QETN1HM-105Z E CAP. 1µ F 50V M C0122 QETN1HM-106Z E CAP. 10µF 50V M C0123 QETN1HM-105Z E CAP. 1µ F 50V M

C0124 NCB31HK-103X C CAP. 0.01µ F 50V K C0125 NCB31HK-102X C CAP. 1000pF 50V K

C0126-28 QETN1HM-106Z E CAP. 10µF 50V M C0129 QETN1HM-105Z E CAP. 1µ F 50V M

C0130 NCB31HK-103X C CAP. 0.01µF 50V K C0131 QETN1HM-105Z E CAP. 1µ F 50V M C0132 NCB31HK-103X C CAP. 0.01µ F 50V K C0133 QETN1HM-106Z E CAP. 10µF 50V M

C0134 QETN1HM-105Z E CAP. 1µ F 50V M C0135 QETN1HM-106Z E CAP. 10µF 50V M

C0136 QETN1HM-105Z E CAP. 1µF 50V M C0137 NCB31HK-103X C CAP. 0.01µF 50V K C0138-39 QENC1HM-105Z E CAP. 1µF 50V M C0140 QENC1EM-106Z BP E CAP. 10µF 25V M C0141-47 NCB31HK-103X C CAP. 0.01µF 50V K C0148 QETN1HM-106Z E CAP. 10µF 50V M

C0149 QENC1EM-106Z BP E CAP. 10µF 25V M C0150-51 QETN1CM-107Z E CAP. 100µF 16V M

C0152 QETN1CM-477Z E CAP. 470µF 16V M C0153 NCB31HK-103X C CAP. 0.01µ F 50V K C0154 QETN1CM-107Z E CAP. 100µF 16V M

C0155 NDC31HJ-150X C CAP. 15pF 50V J

COIL

L0101 QQR0716-001Z LEAD CORE

DIODE

D0101-04 MA3056/M/-X ZENER DIODE D0109-13 MA3120/M/-X ZENER DIODE D0114 MA3039/H/-X ZENER DIODE D0115-17 MA3056/M/-X ZENER DIODE

TRANSISTOR

Q0101-02 2SC2412K/QR/-X SI.TRANSISTOR Q0103-05 DTC323TK-X DIGI.TRANSISTOR Q0106-09 2SC2412K/QR/-X SI.TRANSISTOR

Q0110 2SA1037AK/QR/-X SI.TRANSISTOR Q0111 DTC323TK-X DIGI.TRANSISTOR Q0112 2SA1037AK/QR/-X SI.TRANSISTOR Q0113-15 2SC2412K/QR/-X SI.TRANSISTOR Q0116 2SA933AS/QR/-T SI.TRANSISTOR

Q0117 2SC1740S/QR/-T SI.TRANSISTOR

IC0101 CXA2069Q I.C(MONO-ANA)

OTHERS

CN0001 QGB1505K1-50 CONNECTOR J0001 QNZ0465-001 PIN CONNECTOR

J0002 QNZ0463-001 PIN CONNECTOR K0101-04 CE42681-001Y BEADS CORE

No. 51945

V32H20EUS

■■■■100Hz P.W. BOARD ASS’Y (SMF0Z405A-U2)

Symbol No. Part No. Part Name Description

RESISTOR

R0008-09 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0010-12 NRSA63J-101X MG R 100Ω 1/16W J R0101 NRSA63J-332X MG R 3.3kΩ 1/16W J

R0102-03 NRSA63J-222X MG R 2.2kΩ 1/16W J R0104 NRSA63J-332X MG R 3.3kΩ 1/16W J R0105-06 NRSA63J-222X MG R 2.2kΩ 1/16W J R0107-13 NRSA63J-750X MG R 75Ω 1/16W J R0122-23 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R0124-25 NRSA63J-101X MG R 100Ω 1/16W J R0132-39 NRSA63J-100X MG R 10Ω 1/16W J R0141 NRSA63J-100X MG R 10Ω 1/16W J

R0201 NRSA63J-121X MG R 120Ω 1/16W J R0202-03 NRSA63J-101X MG R 100Ω 1/16W J R0204-05 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0214 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0217 NRSA63J-103X MG R 10kΩ 1/16W J

R0218 NRSA63J-333X MG R 33kΩ 1/16W J R0219 NRSA63J-103X MG R 10kΩ 1/16W J

R0220 NRSA63J-822X MG R 8.2kΩ 1/16W J R0226-42 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0243-44 NRSA63J-103X MG R 10kΩ 1/16W J R0251 NRSA63J-222X MG R 2.2kΩ 1/16W J R0252 NRSA63J-750X MG R 75Ω 1/16W J

R0254 NRSA63J-391X MG R 390Ω 1/16W J

R0255-56 NRSA63J-221X MG R 220Ω 1/16W J R0257 NRSA63J-271X MG R 270Ω 1/16W J

R0258 NRSA63J-272X MG R 2.7kΩ 1/16W J R0259 NRSA63J-472X MG R 4.7kΩ 1/16W J R0261 NRSA63J-222X MG R 2.2kΩ 1/16W J R0264 NRSA63J-391X MG R 390Ω 1/16W J R0271 NRSA63J-222X MG R 2.2kΩ 1/16W J

R0274 NRSA63J-391X MG R 390Ω 1/16W J

R0401 NRSA63J-473X MG R 47kΩ 1/16W J R0402 NRSA63J-472X MG R 4.7kΩ 1/16W J R0404 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0407 NRSA63J-0R0X MG R 0.0Ω 1/16W J R0409 NRSA63J-0R0X MG R 0.0Ω 1/16W J

CAPACITOR

C0001 NCB31CK-104X C CAP. 0.1µF 16V K C0002 NEH71CM-476X E CAP. 47µF 16V M C0003 NCB31CK-104X C CAP. 0.1µF 16V K C0004 NEH71CM-476X E CAP. 47µF 16V M

C0005 NCB31CK-104X C CAP. 0.1µF 16V K C0006 NEH71CM-476X E CAP. 47µF 16V M

C0007-09 NDC31HJ-4R0X C CAP. 4.0pF 50V J C0101 NEH71CM-106X E CAP. 10µF 16V M

C0102 NCB31EK-473X C CAP. 0.047µF 25V K C0103 NEH71CM-476X E CAP. 47µF 16V M

C0104 NCB31HK-152X C CAP. 1500pF 50V K C0105 NDC31HJ-102X C CAP. 1000pF 50V J

C0106 NCB31CK-104X C CAP. 0.1µF 16V K C0107 NCF31CZ-224X C CAP. 0.22µF 16V Z

C0108 NCB31HK-152X C CAP. 1500pF 50V K C0109 NDC31HJ-391X C CAP. 390pF 50V J

C0110 NEH71CM-106X E CAP. 10µF 16V M C0111 NCB31EK-473X C CAP. 0.047 µF 25V K

C0112 NDC31HJ-331X C CAP. 330pF 50V J C0113-18 NCF31CZ-224X C CAP. 0.22µF 16V Z

C0119-24 NDC31HJ-331X C CAP. 330pF 50V J C0125-26 NDC31HJ-3R0X C CAP. 3.0pF 50V J

C0128 NCB31CK-104X C CAP. 0.1µF 16V K C0129 NCF31CZ-224X C CAP. 0.22µF 16V Z

C0130 NDC31HJ-391X C CAP. 390pF 50V J

Symbol No. Part No. Part Name Description

CAPACITOR

C0131 NCB31HK-152X C CAP. 1500pF 50V K C0132 NCB31EK-473X C CAP. 0.047µF 25V K

C0133 NCB31HK-152X C CAP. 1500pF 50V K C0134 NCB31CK-683X CHIP CAP. 0.068 µF 16V K

C0136-37 NCB31CK-683X CHIP CAP. 0.068µF 16V K C0138 NCB31HK-152X C CAP. 1500pF 50V K

C0139 NCB31EK-473X C CAP. 0.047µF 25V K C0140 NEH71CM-476X E CAP. 47µF 16V M

C0141 NDC31HJ-100X C CAP. 10pF 50V J C0201 NEH71CM-476X E CAP. 47µF 16V M

C0202-05 NCB31CK-104X C CAP. 0.1µF 16V K C0206 NEH71CM-476X E CAP. 47µF 16V M C0207-11 NCB31CK-104X C CAP. 0.1µF 16V K

C0212-13 NDC31HJ-180X C CAP. 18pF 50V J C0214-17 NCB31CK-104X C CAP. 0.1µF 16V K

C0218 NDC31HJ-561X C CAP. 560pF 50V J

C0237-38 NEH71CM-106X E CAP. 10µF 16V M C0251 NDC31HJ-4R0X C CAP. 4.0pF 50V J

C0252 NCB31CK-104X C CAP. 0.1µF 16V K C0254 NDC31HJ-120X C CAP. 12pF 50V J

C0255 NDC31HJ-270X C CAP. 27pF 50V J C0256 NEH71CM-106X E CAP. 10µF 16V M

C0261 NDC31HJ-4R0X C CAP. 4.0pF 50V J C0262 NCB31CK-104X C CAP. 0.1µF 16V K

C0264 NDC31HJ-120X C CAP. 12pF 50V J C0265 NDC31HJ-270X C CAP. 27pF 50V J C0271 NDC31HJ-4R0X C CAP. 4.0pF 50V J

C0272 NCB31CK-104X C CAP. 0.1µF 16V K C0274 NDC31HJ-120X C CAP. 12pF 50V J

C0275 NDC31HJ-270X C CAP. 27pF 50V J C0402-03 NCB31CK-104X C CAP. 0.1µF 16V K

C0404 NDC31HJ-330X C CAP. 33pF 50V J

COIL

L0001-03 NQL092K-1R5X INDUCTOR L0101 NQL034K-150X INDUCTOR

L0102-08 NQL092K-3R3X INDUCTOR L0109 NQL034K-6R8X INDUCTOR L0201-03 NQL034K-100X INDUCTOR L0209-10 NQL092K-1R5X INDUCTOR

L0251 NQL092K-5R6X INDUCTOR L0261 NQL092K-5R6X INDUCTOR

L0271 NQL092K-5R6X INDUCTOR

DIODE

D0401 MA111-X SI.DIODE

TRANSISTOR

Q0101-02 2SA1037AK/QR/-X SI.TRANSISTOR Q0201 2SA1037AK/QR/-X SI.TRANSISTOR Q0251-52 2SA1037AK/QR/-X SI.TRANSISTOR Q0253 2SC2412K/QR/-X SI.TRANSISTOR Q0261 2SA1037AK/QR/-X SI.TRANSISTOR

Q0271 2SA1037AK/QR/-X SI.TRANSISTOR

IC0101 VPC3230D-QA-B3 I.C(M) IC0201 SAA4979H/V105 I.C(M)

IC0401 S-80828CNNB-W I.C(M) IC0402 TC7WH34FU-X I.C(DIGI-MOS)

OTHERS

CN0003 QGB1505K1-50 CONNECTOR LC0010-12 NQR0313-009X EMI FILTER LC0013 NQR0313-004X EMI FILTER LC0014-15 NQR0313-007X EMI FILTER X0101 QAX0655-001Z CRYSTAL

X0201 QAX0273-001Z CRYSTAL

No. 51945

EXPLODED VIEW PARTS LIST

AV28H20EUS

Ref.No. Part No. Part Name Description

1 LC 403 54- 003A -C JV C M ARK 2 LC 305 80- 001C-C LED LENS

3 LC 305 79- 001B -C RE MOC ON WIND OW

! 100 LC106 62- 023A -U FR ONT CA BINE T A SSY In c.N o.1 01～105 ! 101 LC 202 65- 017A -U DO OR (S ERV ICE )

10 2 CM 482 29- 00A- C DOOR LAT CH

! 103 LC 305 78- 007B -U PO WER KN OB (S ERV ICE )

10 4 AE M31 49- 001- E SPRIN G

10 5 LC 311 09- 006A -U CO NTR OL SHEE T

AV28H20EUB

Ref.No. Part No. Part Name Description

1 LC 403 54- 001C-C JVC MARK 2 LC 305 80- 001C-C LED LENS

3 LC 305 79- 001B -C RE MOC ON WIND OW

! 100 LC106 62- 024A -U FR ONT CA BINE T A SSY In c.N o.1 01～105 ! 101 LC 202 65- 024A- U DO OR (S ERV ICE )

10 2 CM 482 29- 00A- C DOOR LAT CH

! 103 LC 305 78- 004A -U PO WER KN OB (S ERV ICE )

10 4 AE M31 49- 001- E SPRIN G

10 5 LC 311 09- 004 B-U CO NTR OL SHEE T

V28H20EUS V28H20EUB

EXPLODED VIEW

101

105

102

100

103

104

No.51945

V28H20EUS

V28H20EUB

AV28H20EUS

Ref.No. Part No. Part Name Description

! V01 W6 6QD E99 3X92 5 ITC T UBE (C) Inc.D Y,P C MA GNE T,WE DGE ! L01 QQ W01 00- 001 DE GAU SSI NG C OIL

! T2551 QQ H01 26- 001 H. V.T RAN SF.

4 WJ Y00 01-011A BR AID ED ASSY 5 WJ Y00 13- 002A BR AID ED SU B AS SY

6CHFD1 25- 11BD FF C WI RE CN -1

! 7LC107 16- 002F -U CH ASS IS BASE ! 8LC107 17- 005D -U TE RMI NAL BOA RD

9 QY SBS B30 12M TAPPI NG SCRE W (x3)

! 10LC103 80- 003B -U CO NTR OL BASE L ! 11 LC 103 80- 004 B-U CO NTR OL BASE R

12 QA S00 88- 001 SPEAK ER SP 01- 02(x 2)

! 13LC107 20- 001D -U AD APT ER (x 2)

14 LC 402 26- 003A -H SP ACE R (x4) 15 LC 405 06- 001A TA PPI NG SCRE W (x 4)

! 16LC106 64- 003B -U RE AR COV ER

17 QY SBS AG4 016N TA PPI NG SCRE W (x 12)

! 18QMPK160- 185- JC PO WER CO RD CN -PW ! 19 CM 466 18- A01- E PO WER CO RD C LAM P

! 20 LC 203 79- 026A -U RA TIN G L ABEL ! 21 LC 307 89- 002B -U WA RNI NG LABE L ! 22 QQ R04 91-001 FILTE R

AV28H20EUB

Ref.No. Part No. Part Name Description

! V01 W6 6QD E99 3X92 5 ITC T UBE (C) Inc.D Y,P C MA GNE T,WE DGE ! L01 QQ W01 00- 001 DE GAU SSI NG C OIL

! T2551 QQ H01 26- 001 H. V.T RAN SF.

4 WJ Y00 01-011A BR AID ED ASSY 5 WJ Y00 13- 002A BR AID ED SU B AS SY

6CHFD1 25- 11BD FF C WI RE CN -1

! 7LC107 16- 002F -U CH ASS IS BASE ! 8LC107 17- 003E -U TE RMI NAL BOA RD

9 QY SBS B30 12M TAPPI NG SCRE W (x3)

! 10LC103 80- 003B -U CO NTR OL BASE L ! 11 LC 103 80- 004B -U CO NTR OL BASE R

12 QA S00 88- 001 SPEAK ER SP 01- 02(x 2)

! 13LC107 20- 001D -U AD APT ER (x 2)

14 LC 402 26- 003A -H SP ACE R (x4) 15 LC 405 06- 001A TA PPI NG SCRE W (x 4)

! 16LC1 066 4-0 01E- U RE AR COV ER

17 QY SBS AG4 016N TA PPI NG SCRE W (x 12)

! 18QMPK160- 185- JC PO WER CO RD CN -PW ! 19 CM 466 18- A01- E PO WER CO RD C LAM P

! 20 LC 203 79- 025A -U RA TIN G L ABEL ! 21 LC 307 89- 002B -U WA RNI NG LABE L ! 22 QQ R04 91-001 FILTE R

No.51945

EXPLODED VIEW

V28H20EUS V28H20EUB

L0 1

FRONT C ONT RO L PWB

V01

CRT SOCKE T PWB

10 0H z PW B

POWER & DEF. PWB

T2551

MAIN PWB

MICOM PWB

AV SE L . P WB

(×3)

(×12 )

No.51945

V28H20EUS

V28H20EUB

AV28H20EUS / AV28H20EUB

PRINTED WIRING BOARD PARTS LIST

■ MAIN P.W. BOARD ASS’Y (SMF-1402A-U2)

Symbol No. Part No. Part Name Description

RESISTOR

R1004-06 NRSA63J-101X MG R 100Ω 1/16W J R1008-09 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R1102 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1103 NRSA63J-222X MG R 2.2kΩ 1/16W J R1104 NRSA63J-102X MG R 1kΩ 1/16W J R1105 NRSA63J-561X MG R 560Ω 1/16W J R1106 NRSA63J-331X MG R 330Ω 1/16W J

R1108 NRSA63J-102X MG R 1kΩ 1/16W J

R1301-02 NRSA63J-101X MG R 100Ω 1/16W J R1303 NRSA63J-273X MG R 27kΩ 1/16W J

R1304 NRSA63J-102X MG R 1kΩ 1/16W J R1311 NRSA63J-331X MG R 330Ω 1/16W J R1312 NRSA63J-273X MG R 27kΩ 1/16W J R1313 NRSA63J-183X MG R 18kΩ 1/16W J

R1314 NRSA63J-221X MG R 220Ω 1/16W J R1315-17 NRSA63J-101X MG R 100Ω 1/16W J R1318 NRSA63J-562X MG R 5.6kΩ 1/16W J R1319 NRSA63J-183X MG R 18kΩ 1/16W J

R1321-22 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1325 NRSA63J-101X MG R 100Ω 1/16W J R1326 NRSA63J-682X MG R 6.8kΩ 1/16W J R1401-02 NRSA63J-102X MG R 1kΩ 1/16W J

R1403-04 NRSA63J-331X MG R 330Ω 1/16W J R1405-06 NRSA63J-102X MG R 1kΩ 1/16W J R1451 NRSA63J-821X MG R 820Ω 1/16W J R1454 NRSA63J-472X MG R 4.7kΩ 1/16W J

R1455-56 NRSA63J-123X MG R 12kΩ 1/16W J R1457 NRSA63J-392X MG R 3.9kΩ 1/16W J R1458 NRSA63J-123X MG R 12kΩ 1/16W J

R1459 NRSA63J-472X MG R 4.7kΩ 1/16W J R1461 NRSA63J-123X MG R 12kΩ 1/16W J R1462 NRSA63J-153X MG R 15kΩ 1/16W J R1463 NRSA63J-104X MG R 100kΩ 1/16W J R1465-66 NRSA63J-224X MG R 220kΩ 1/16W J

R1467 NRSA63J-563X MG R 56kΩ 1/16W J R1468 NRSA63J-224X MG R 220kΩ 1/16W J

R1469 NRSA63J-683X MG R 68kΩ 1/16W J R1470 NRSA63J-223X MG R 22kΩ 1/16W J R1471 NRSA63J-273X MG R 27kΩ 1/16W J R1472 NRSA63J-682X MG R 6.8kΩ 1/16W J R1473 NRSA63J-123X MG R 12kΩ 1/16W J R1474 NRSA63J-563X MG R 56kΩ 1/16W J

R1475 NRSA63J-153X MG R 15kΩ 1/16W J R1476-78 NRSA63J-123X MG R 12kΩ 1/16W J

R1479 NRSA63J-154X MG R 150kΩ 1/16W J R1480 NRSA63J-823X MG R 82kΩ 1/16W J R1481 NRSA63J-472X MG R 4.7kΩ 1/16W J R1482 NRSA63J-272X MG R 2.7kΩ 1/16W J R1483 NRSA63J-472X MG R 4.7kΩ 1/16W J R1484 NRSA63J-473X MG R 47kΩ 1/16W J

R1485 NRSA63J-123X MG R 12kΩ 1/16W J R1486 NRSA63J-472X MG R 4.7kΩ 1/16W J R1487 NRSA63J-183X MG R 18kΩ 1/16W J R1489 NRSA63J-333X MG R 33kΩ 1/16W J R1491 NRSA63J-332X MG R 3.3kΩ 1/16W J R1492 NRSA63J-562X MG R 5.6kΩ 1/16W J

R1501 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1504 NRSA63J-102X MG R 1kΩ 1/16W J

Symbol No. Part No. Part Name Description

RESISTOR

R1511 NRSA63J-152X MG R 1.5kΩ 1/16W J R1512 NRSA63J-332X MG R 3.3kΩ 1/16W J R1521 NRSA63J-223X MG R 22kΩ 1/16W J R1522 NRSA63J-562X MG R 5.6kΩ 1/16W J

R1551 NRSA63J-100X MG R 10Ω 1/16W J R1552 NRSA63J-124X MG R 120kΩ 1/16W J R1553 NRSA63J-683X MG R 68kΩ 1/16W J R1554 NRSA63J-562X MG R 5.6kΩ 1/16W J

R1555 NRSA63J-333X MG R 33kΩ 1/16W J R1556 NRSA63J-472X MG R 4.7kΩ 1/16W J

R1557 NRSA63J-562X MG R 5.6kΩ 1/16W J R1558 NRSA63J-104X MG R 100kΩ 1/16W J R1559 NRSA63J-154X MG R 150kΩ 1/16W J R1560 NRSA63J-100X MG R 10Ω 1/16W J R1561 QRN143J-0R0X C R 0.0Ω 1/4W J R1562 NRSA63J-683X MG R 68kΩ 1/16W J

R1563 NRSA63J-103X MG R 10kΩ 1/16W J R1564 NRSA63J-223X MG R 22kΩ 1/16W J

R1565 NRSA63J-562X MG R 5.6kΩ 1/16W J R1591 NRSA63J-561X MG R 560Ω 1/16W J R1592 NRSA63J-332X MG R 3.3kΩ 1/16W J R1595 NRSA63J-222X MG R 2.2kΩ 1/16W J R1596 NRSA63J-104X MG R 100kΩ 1/16W J

R1601 NRSA63J-273X MG R 27kΩ 1/16W J

R1602 NRSA63J-103X MG R 10kΩ 1/16W J R1603 NRSA63J-273X MG R 27kΩ 1/16W J

R1604 NRSA63J-103X MG R 10kΩ 1/16W J R1605 NRSA63J-473X MG R 47kΩ 1/16W J R1606 NRSA63J-273X MG R 27kΩ 1/16W J R1609 NRSA63J-104X MG R 100kΩ 1/16W J R1610 NRSA63J-682X MG R 6.8kΩ 1/16W J

R1618 NRSA63J-333X MG R 33kΩ 1/16W J

R1619 NRSA63J-104X MG R 100kΩ 1/16W J R1620 NRSA63J-562X MG R 5.6kΩ 1/16W J R1637 QRK126J-2R2X C R 2.2Ω 1/2W J R1639 NRSA63J-561X MG R 560Ω 1/16W J R1642-43 NRSA63J-681X MG R 680Ω 1/16W J

R1644 NRSA63J-104X MG R 100kΩ 1/16W J R1645-46 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1649 QRK126J-2R2X C R 2.2Ω 1/2W J

R1650-51 NRSA63J-103X MG R 10kΩ 1/16W J R1654-55 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1664-65 NRSA63J-103X MG R 10kΩ 1/16W J R1666 NRSA63J-473X MG R 47kΩ 1/16W J R1667 NRSA63J-183X MG R 18kΩ 1/16W J

R1668 NRSA63J-473X MG R 47kΩ 1/16W J R1669 NRSA63J-183X MG R 18kΩ 1/16W J R1670-71 NRSA63J-104X MG R 100kΩ 1/16W J

R1672 NRSA63J-223X MG R 22kΩ 1/16W J R1673 NRSA63J-273X MG R 27kΩ 1/16W J R1675 NRSA63J-103X MG R 10kΩ 1/16W J R1677-78 NRSA63J-103X MG R 10kΩ 1/16W J

R1679 NRSA63J-223X MG R 22kΩ 1/16W J R1680 NRSA63J-273X MG R 27kΩ 1/16W J R1684 NRSA63J-0R0X MG R 0.0Ω 1/16W J R1687 NRSA63J-0R0X MG R 0.0Ω 1/16W J

R1701-02 NRSA63J-103X MG R 10kΩ 1/16W J R1703-04 NRSA63J-102X MG R 1kΩ 1/16W J

R1705-08 NRSA63J-103X MG R 10kΩ 1/16W J R1711-12 NRSA63J-101X MG R 100Ω 1/16W J R1714-15 NRSA63J-102X MG R 1kΩ 1/16W J R1720-22 NRSA63J-102X MG R 1kΩ 1/16W J R1772-76 NRSA63J-221X MG R 220Ω 1/16W J R1951 QRK126J-220X C R 22Ω 1/2W J

No. 51945

V28H20EUS

V28H20EUB

Symbol No. Part No. Part Name Description

CAPACITOR

C1001 NCB31HK-222X C CAP. 2200pF 50V K C1002 QETN1HM-106Z E CAP. 10µF 50V M

C1004 NCB31CK-104X C CAP. 0.1µF 16V K C1005 QETN1CM-108Z E CAP. 1000µF 16V M C1006 NCB31HK-103X C CAP. 0.01µF 50V K C1007 QETN1HM-106Z E CAP. 10µF 50V M C1009 NCB31CK-104X C CAP. 0.1µF 16V K C1010 QETN1HM-106Z E CAP. 10µF 50V M

C1101 NCB31CK-104X C CAP. 0.1µF 16V K C1102 QETN1HM-106Z E CAP. 10µF 50V M

C1103 NCB31CK-104X C CAP. 0.1µF 16V K C1104 QETN1CM-107Z E CAP. 100µF 16V M C1105 QETN1HM-106Z E CAP. 10µF 50V M C1106-07 NCB31CK-104X C CAP. 0.1µF 16V K

C1108 NDC31HJ-680X C CAP. 68pF 50V J C1111 NCB31HK-103X C CAP. 0.01µF 50V K

C1116 NCB31HK-472X C CAP. 4700pF 50V K C1117-18 NCB31HK-103X C CAP. 0.01µF 50V K

C1119-20 NDC31HJ-2R0X C CAP. 2.0pF 50V J C1121 NCB31HK-103X C CAP. 0.01µF 50V K

C1122-23 NDC31HJ-102X C CAP. 1000pF 50V J C1124-25 QETN1HM-106Z E CAP. 10µF 50V M C1126 NCB31CK-104X C CAP. 0.1µF 16V K C1127 QETN1HM-106Z E CAP. 10µF 50V M

C1128 NCB31CK-104X C CAP. 0.1µF 16V K C1129 NCF31AZ-105X C CAP. 1µF 10V Z C1130 QETN1HM-106Z E CAP. 10µF 50V M

C1151-54 NCF31AZ-105X C CAP. 1µF 10V Z C1155-56 NDC31HJ-102X C CAP. 1000pF 50V J

C1301 QETN1CM-107Z E CAP. 100µF 16V M C1302-03 NCB31CK-104X C CAP. 0.1µF 16V K C1305-09 NCB31CK-104X C CAP. 0.1µF 16V K

C1310 QETN1AM-228Z E CAP. 2200µF 10V M C1311 NCB31CK-683X CHIP CAP. 0.068 µF 16V K

C1312 NDC31HJ-221X C CAP. 220pF 50V J C1313-15 NCB31HK-223X C CAP. 0.022 µF 50V K C1316-18 NCB31HK-103X C CAP. 0.01µF 50V K C1320 QETN0JM-228Z E CAP. 2200µF 6.3V M

C1321-23 NCB31HK-223X C CAP. 0.022µF 50V K C1324 NDC31HJ-820X C CAP. 82pF 50V J

C1351 QENC1EM-106Z BP E CAP. 10µF 25V M C1401 NCB31CK-104X C CAP. 0.1µF 16V K

C1402 QETN1CM-107Z E CAP. 100µF 16V M C1403-04 NCB31CK-104X C CAP. 0.1µF 16V K C1453 NCB31HK-103X C CAP. 0.01µF 50V K C1454 NCB31EK-333X C CAP. 0.033 µF 25V K C1455-56 NCB31CK-104X C CAP. 0.1µF 16V K

C1457 NCB31EK-333X C CAP. 0.033µF 25V K

C1471 NCB31CK-104X C CAP. 0.1µF 16V K C1472 NCB31HK-103X C CAP. 0.01µF 50V K C1473 NCB31CK-104X C CAP. 0.1µF 16V K C1474 NCB31EK-333X C CAP. 0.033 µF 25V K C1475 NCB31CK-104X C CAP. 0.1µF 16V K C1491 NCB31EK-473X C CAP. 0.047 µF 25V K

C1501-02 NDC31HJ-150X C CAP. 15pF 50V J C1551-52 NCF31CZ-224X C CAP. 0.22µF 16V Z

C1553 QETN1EM-476Z E CAP. 47µF 25V M C1554-55 NCF31CZ-224X C CAP. 0.22µF 16V Z

C1560 QETN1CM-107Z E CAP. 100µF 16V M C1561 NDC31HJ-561X C CAP. 560pF 50V J

C1562 QETN1HM-105Z E CAP. 1µF 50V M C1564 NCB31CK-104X C CAP. 0.1µF 16V K

C1591 NDC31HJ-471X C CAP. 470pF 50V J

Symbol No. Part No. Part Name Description

CAPACITOR

C1596 NCB31CK-104X C CAP. 0.1µF 16V K C1600 QETN1HM-226Z E CAP. 22µF 50V M C1606-07 QETN1CM-227Z E CAP. 220µF 16V M C1616 QETN1HM-105Z E CAP. 1µ F 50V M C1618 QETN1HM-105Z E CAP. 1µ F 50V M C1628 QETN1HM-107Z E CAP. 100µF 50V M C1629 QETN1HM-106Z E CAP. 10µF 50V M

C1630 NCF21HZ-224X C CAP. 0.22µ F 50V Z

C1632 NCF21HZ-224X C CAP. 0.22µF 50V Z C1634 QETM1HM-228 E CAP. 2200 µF 50V M C1641-42 NCF21HZ-224X C CAP. 0.22µF 50V Z C1646-47 NCB31HK-103X C CAP. 0.01µF 50V K C1648-49 QETM1VM-108 E CAP. 1000 µF 35V M

C1673-74 NCF31AZ-105X C CAP. 1µF 10V Z C1675 QETN1EM-476Z E CAP. 47µF 25V M

C1676-77 NDC31HJ-151X C CAP. 150pF 50V J

C1678-79 NDC31HJ-150X C CAP. 15pF 50V J C1680 NCF31AZ-105X C CAP. 1µ F 10V Z

C1681 NCB31HK-332X C CAP. 3300pF 50V K C1682 NCB31EK-333X C CAP. 0.033 µF 25V K C1683 QETN1EM-476Z E CAP. 47µF 25V M

C1684 NCB31HK-332X C CAP. 3300pF 50V K C1685 NCB31EK-333X C CAP. 0.033 µF 25V K

C1686 NCF31AZ-105X C CAP. 1µF 10V Z

C1687 QETN1HM-106Z E CAP. 10µF 50V M C1688 QETN1EM-476Z E CAP. 47µF 25V M C1689 NCB31CK-104X C CAP. 0.1µF 16V K C1695 NRSA63J-0R0X MG R 0.0Ω 1/16W J C1698 NRSA63J-0R0X MG R 0.0Ω 1/16W J

C1699 NCB31HK-103X C CAP. 0.01µF 50V K C1701 QETN1HM-106Z E CAP. 10µF 50V M C1702 NCB31CK-563X CHIP CAP. 0.056µF 16V K

C1951 QETN1CM-477Z E CAP. 470µF 16V M C1952-53 NCB31CK-104X C CAP. 0.1µF 16V K C1954 QETN1AM-477Z E CAP. 470µF 10V M C1955 QETN1AM-227Z E CAP. 220µF 10V M C1956 QETN1AM-107Z E CAP. 100µF 10V M

COIL

L1001 QQL244K-270Z PEAKING COIL L1002-03 QQL244K-100Z COIL 10µH K L1101 QRN143J-0R0X C R 0.0Ω 1/4W J L1102 QQL244K-4R7Z COIL 4.7µH K

L1301-02 NQL092K-1R5X INDUCTOR L1951 QQL26AM-5R6Z CHOKE COIL

DIODE

D1317-18 MA111-X SI.DIODE D1319 MA3036-X ZENER DIODE D1320-21 MA3056/M/-X ZENER DIODE

D1471-74 MA111-X SI.DIODE D1475 MA3240/M/-X CHIP ZENER DIODE D1521 MA111-X SI.DIODE D1591 MA111-X SI.DIODE D1592 MA3051/M/-X ZENER DIODE

D1593 MA111-X SI.DIODE D1602 MA111-X SI.DIODE D1610-11 MA111-X SI.DIODE D1614-15 MA111-X SI.DIODE D1617 MA111-X SI.DIODE

D1619-20 MA3330/L/-X ZENER DIODE D1771-74 MA3056/M/-X ZENER DIODE D1951 1SR35-400A-T2 SI.DIODE

D1981-82 MA111-X SI.DIODE

No. 51945

V28H20EUS

V28H20EUB

Symbol No. Part No. Part Name Description

TRANSISTOR

Q1101-02 2SC2412K/QR/-X SI.TRANSISTOR Q1301 2SA1037AK/QR/-X SI.TRANSISTOR Q1471-72 2SC2412K/QR/-X SI.TRANSISTOR Q1561 2SC2412K/QR/-X SI.TRANSISTOR

Q1562 2SA1037AK/QR/-X SI.TRANSISTOR Q1591 2SA1037AK/QR/-X SI.TRANSISTOR Q1592 2SC2412K/QR/-X SI.TRANSISTOR Q1601-02 2SA1037AK/QR/-X SI.TRANSISTOR

Q1604-05 DTC124EKA-X DIGI.TRANSISTOR Q1606 2SC2412K/QR/-X SI.TRANSISTOR Q1607 DTA124EKA-X DIGI.TRANSISTOR Q1615 2SA1037AK/QR/-X SI.TRANSISTOR Q1616-17 DTC323TK-X DIGI.TRANSISTOR

IC IC1101 MSP3415DQGB3GHX I.C(MONO-ANA) IC1301 SDA9380 I.C(M) IC1402 BA10324AF-XE I.C(MONO-ANA) IC1471 BA10358F-XE I.C(M)

IC1551 LA6515 I.C(MONO-ANA) IC1601 TA8246AH I.C(HYBRID) IC1662 BA4558F-X I.C(MONO-ANA) IC1663 NJM2150AM-X I.C(MONO-ANA)

IC1701 JLC1562BF-X I.C(DIGI-MOS) IC1951 BA09T I.C(MONO-ANA) IC1952 BA08T I.C(MONO-ANA)

OTHERS

CN1013 QGA2501C1-10 W TO B CONNE J1001 QNN0296-001 PIN JACK K1001 NQR0389-003X FERRITE BEADS K1101-02 NQR0389-003X FERRITE BEADS

K1301 NQR0413-003X BEADS CORE K1601-02 CE42681-001Y BEADS CORE LC1102 NQR0431-001X EMI FILTER LC1301-03 NQR0431-001X EMI FILTER

TU1001 QAU0276-001 TUNER X1101 CE42546-001Z CRYSTAL

X1501 QAX0549-001Z CRYSTAL Y1612-13 NCF21CZ-105X C CAP. 1µF 16V Z

■■■■POWER & DE F. P.W. BOARD ASS’Y

Symbol No. Part No. Part Name Description

RESISTOR

R2401-02 QRE141J-562Y C R 5.6kΩ 1/4W J R2403 QRE141J-222Y C R 2.2kΩ 1/4W J

R2404 QRX01GJ-1R0 MF R 1.0Ω 1W J R2405 QRL029J-151 OM R 150Ω 2W J R2406 QRE141J-222Y C R 2.2kΩ 1/4W J R2407-08 QRX01GJ-1R5 MF R 1.5Ω 1W J R2409 QRE141J-823Y C R 82kΩ 1/4W J

R2410 QRE141J-103Y C R 10kΩ 1/4W J

R2421 QRE141J-103Y C R 10kΩ 1/4W J R2422 QRE141J-274Y C R 270kΩ 1/4W J R2461 QRG029J-820 OM R 82 Ω 2W J R2462 QRE141J-473Y C R 47kΩ 1/4W J R2463 QRA14CF-9101Y MF R 9.1kΩ 1/4W F R2464 QRX01GJ-2R7 MF R 2.7Ω 1W J

R2468 QRE141J-102Y C R 1kΩ 1/4W J R2469 QRE141J-272Y C R 2.7kΩ 1/4W J

R2471 QRE141J-391Y C R 390Ω 1/4W J R2472 QRA14CF-1002Y MF R 10kΩ 1/4W F R2473 QRE141J-473Y C R 47kΩ 1/4W J R2474 QRE141J-103Y C R 10kΩ 1/4W J R2475 QRE141J-102Y C R 1kΩ 1/4W J

R2476 QRE141J-102Y C R 1kΩ 1/4W J R2477 QRE141J-563Y C R 56kΩ 1/4W J R2478 QRE141J-333Y C R 33kΩ 1/4W J

R2501 QRE141J-471Y C R 470Ω 1/4W J R2502 QRE141J-123Y C R 12kΩ 1/4W J R2503 QRE121J-152Y C R 1.5kΩ 1/2W J R2504 QRL039J-272 OM R 2.7kΩ 3W J R2505 QRL039J-332 OM R 3.3kΩ 3W J

R2506 QRE121J-5R6Y C R 5.6Ω 1/2W J R2521 QRE121J-471Y C R 470Ω 1/2W J R2522 QRE141J-223Y C R 22kΩ 1/4W J

R2523 QRE141J-103Y C R 10kΩ 1/4W J R2524 QRC121K-152Z COMP.R 1.5kΩ 1/2W K R2525 QRL039J-103 OM R 10kΩ 3W J

R2541 QRE141J-182Y C R 1.8kΩ 1/4W J R2542 QRE141J-222Y C R 2.2kΩ 1/4W J R2543 QRE121J-272Y C R 2.7kΩ 1/2W J

R2551 QRZ9022-R47 F R 0.47 Ω 1W K

R2552 QRZ9022-R47 F R 0.47 Ω 1W K

R2581 QRF154K-4R7 UNF R 4.7Ω 15W K R2582 QRE141J-681Y C R 680Ω 1/4W J

R2583 QRE121J-682Y C R 6.8kΩ 1/2W J R2584 QRE141J-183Y C R 18kΩ 1/4W J R2585 QRE141J-222Y C R 2.2kΩ 1/4W J R2586 QRA14CF-7501Y MF R 7.5kΩ 1/4W F R2587 QRA14CF-2101Y MF R 2.1kΩ 1/4W F R2588 QRE141J-103Y C R 10kΩ 1/4W J

R2591 QRZ9017-4R7 F R 4.7 Ω 1/4W J R2901 QRE121J-331Y C R 330Ω 1/2W J

R2902 QRF054K-3R3 UNF R 3.3Ω 5W K R2903 QRF104K-3R9 UNF R 3.9Ω 10W K R2904 QRL039J-683 OM R 68kΩ 3W J R2905-06 QRE121J-474Y C R 470kΩ 1/2W J R2908-09 QRL039J-823 OM R 82kΩ 3W J

R2910 QRZ9017-100 F R 10 Ω 1/4W K

R2911 QRE121J-152Y C R 1.5kΩ 1/2W J R2914 QRM059J-R10 MP R 0.10Ω 5W J R2915 QRE121J-681Y C R 680Ω 1/2W J R2916 QRE121J-332Y C R 3.3kΩ 1/2W J R2931 QRE141J-1R0Y C R 1.0Ω 1/4W J R2932 QRE141J-1R5Y C R 1.5Ω 1/4W J

R2933 QRE141J-1R8Y C R 1.8Ω 1/4W J R2944 QRE141J-103Y C R 10kΩ 1/4W J

(SMF -2402A-U2)

No. 51945

V28H20EUS

V28H20EUB

Symbol No. Part No. Part Name Description

RESISTOR

R2945 QRE141J-563Y C R 56kΩ 1/4W J R2946 QRE141J-103Y C R 10kΩ 1/4W J R2951 QRE121J-102Y C R 1kΩ 1/2W J R2952 QRL039J-223 OM R 22kΩ 3W J R2953 QRE141J-474Y C R 470kΩ 1/4W J R2954 QRE141J-103Y C R 10kΩ 1/4W J R2981 QRE141J-153Y C R 15kΩ 1/4W J

R2982 QRE141J-102Y C R 1kΩ 1/4W J

R2991 QRZ9046-825Z C R 8.2MΩ 1/2W K

CAPACITOR

C2404 QCZ0120-104Z C CAP. 0.1µF 25V Z C2405 QDC31HJ-820Z C CAP. 82pF 50V J

C2406 QETM1VM-108 E CAP. 1000 µF 35V M C2408 QETN1VM-337Z E CAP. 330µF 35V M

C2409-10 QFV71HJ-474Z MF CAP. 0.47µF 50V J C2411 QFLC2AJ-104Z M CAP. 0.1µF 100V J

C2414 QCB31HK-682Z C CAP. 6800pF 50V K C2421 QETN1HM-105Z E CAP. 1µF 50V M

C2461 QEZ0414-226 E CAP. 22µF 50V M C2462-63 QFM72DJ-152Z M CAP. 1500pF 200V J

C2464 QCZ0120-104Z C CAP. 0.1µF 25V Z C2465 QETN1HM-106Z E CAP. 10µF 50V M

C2466 QFP31HJ-272Z PP CAP. 2700pF 50V J C2467 QFLC1HJ-102Z M CAP. 1000pF 50V J

C2468 QETN1EM-476Z E CAP. 47µF 25V M C2470 QCS31HJ-470Z C CAP. 47pF 50V J

C2471 QFLC1HJ-103Z M CAP. 0.01µF 50V J C2501 QCB32HK-331Z C CAP. 330pF 500V K C2502 QFM72DK-103 M CAP. 0.01µF 200V K

C2503 QFV71HJ-224Z MF CAP. 0.22µF 50V J C2521 QFZ0122-112 MPP CAP. 1100pF1.8kVH±3%

! !

C2522 QFZ0200-113 MPP CAP. 0.011µF1.5kVH±3% C2523 QFM72DK-393 M CAP. 0.039µ F 200V K

C2524 QFP32JJ-223 PP CAP. 0.022µF 630V J

C2526 QFZ0197-184 MPP CAP. 0.18µF 250V J C2527 QFZ0197-124 MPP CAP. 0.12µF 250V J

C2529 QFZ0197-154 MPP CAP. 0.15µF 250V J C2530 QCB32HK-561Z C CAP. 560pF 500V K

C2531 QFZ0194-534 MPP CAP. 0.53µF 250V J C2532 QETM2CM-227 E CAP. 220µF 160V M C2533 QETN2EM-475Z E CAP. 4.7µF 250V M C2541 QENC1HM-105Z E CAP. 1µF 50V M

C2551 QCB32HK-152Z C CAP. 1500pF 500V K C2552 QETN1CM-108Z E CAP. 1000µF 16V M

C2553 QCB32HK-152Z C CAP. 1500pF 500V K C2554 QETN1CM-108Z E CAP. 1000µF 16V M

C2555 QCB32HK-102Z C CAP. 1000pF 500V K C2556 QETN2EM-106Z E CAP. 10µF 250V M C2558 QETN1CM-477Z E CAP. 470µF 16V M C2559 QEHR1CM-227Z E CAP. 220µF 16V M

C2581 QETN1CM-107Z E CAP. 100µF 16V M C2582 QETN1EM-476Z E CAP. 47µF 25V M

C2583 QETN2AM-106Z E CAP. 10µF 100V M C2584 QETN1AM-227Z E CAP. 220µF 10V M C2901 QFZ9072-473 MM CAP. 0.047µFAC275V K

! !

C2902 QFZ9072-104 MF CAP. 0.1µFAC275V K

C2903 QFZ9072-473 MM CAP. 0.047µFAC275V K C2904 QCZ9054-472 C CAP. 4700pFAC250V Z

C2905 QCZ9054-472 C CAP. 4700pFAC250V Z C2906 QCZ9054-472 C CAP. 4700pFAC250V Z

C2907 QEZ0199-227 E CAP. 220µF 400V M C2908 QCB32HK-103 C CAP. 0.01µF 500V K

Symbol No. Part No. Part Name Description

CAPACITOR

C2909 QCZ0340-391 C CAP. 390pF 2kV K C2910 QETN1HM-476Z E CAP. 47µF 50V M

C2911 QCB31HK-102Z C CAP. 1000pF 50V K C2912 QCZ0340-561 C CAP. 560pF 2kV K C2914 QCB31HK-471Z C CAP. 470pF 50V K

C2915 QFLC1HJ-104Z M CAP. 0.1µF 50V J C2916 QCB32HK-152Z C CAP. 1500pF 500V K C2931 QCZ90 54-472 C CAP. 4700pFAC250V Z

C2932 QCZ9054-472 C CAP. 4700pFAC250V Z

C2933 QCZ9054-472 C CAP. 4700pFAC250V Z C2934 QETM2GM-226 E CAP. 22µF 400V M

C2941 QTMN1CM-477Z E CAP. 470µF 16V M C2942 QETN1AM-337Z E CAP. 330µF 10V M C2951 QEZ0203-227 E CAP. 220µF 160V M C2952 QETN1CM-108Z E CAP. 1000µ F 16V M C2955 QETM1VM-228 E CAP. 2200µF 35V M

C2956 QETN1AM-108Z E CAP. 1000µ F 10V M C2957 QETN1AM-228Z E CAP. 2200µ F 10V M C2959 QFV71HJ-684Z MF CAP. 0.68µF 50V J

C2960 QCZ0325-821 C CAP. 820pF 2kV K C2972-73 QETN1AM-477Z E CAP. 470µF 10V M C2974 QETN0JM-228Z E CAP. 2200µF 6.3V M

C2975 QETN1AM-228Z E CAP. 2200µF 10V M C2991 QCZ9079-222 C CAP. 2200pFAC250V M

C2993 QCZ9079-471 C CAP. 470pFAC250V K

TRANSFORMER

T2501 QQR1111-001 DRIVE TRANSF

T2551 QQH0126-001 H.V.TRANSF.

T2901 QQS0156-001 SWITCH.TRANSF.

COIL

L2461 QQR1195-001 CHOKE COIL L2462 QQLZ028-272 CHOKE COIL L2521 QQLZ031-180 CHOKE COIL L2522 QQR1191-002 LINEARITY COIL

L2551 QQLZ026-540 HEATER CHOKE L2552 QQL26AK-220Z COIL 22µH K

L2901-02 QQL401K-100Z CHOKE COIL L2903 QQR1200-001 CHOKE COIL

L2951 QQLZ026-460 HEATER CHOKE L2959-60 QQL26 AK-220Z COIL 22µH K

L2961 QQL26AM-4R7Z CHOKE COIL

DIODE

D2402 1SR35-400A-T2 SI.DIODE D2421 1SS133-T2 SI.DIODE D2461 RGP10J-5025-T3 SI.DIODE D2462 1SS133-T2 SI.DIODE

D2463 1SS133-T2 SI.DIODE D2501 1SS81-T5 SI.DIODE D2521 V11CA-C1 SI.DIODE D2522 FMV-3FU-F1 SI.DIODE

D2523 MTZJ22B-T2 ZENER DIODE D2525 RGP10J-5025-T3 SI.DIODE D2541 RGP10J-5025-T3 SI.DIODE D2542 MTZJ3.9B-T2 ZENER DIODE D2551 RGP10J-5025-T3 SI.DIODE

D2552 RGP10J-5025-T3 SI.DIODE D2553 RH1S-T3 SI.DIODE D2582 MTZJ7.5B-T2 ZENER DIODE

D2583 MTZJ7.5S-T2 ZENER DIODE

D2584 RGP10J-5025-T3 SI.DIODE D2901 D3SB60 BRIDGE DIODE D2902 RG1C-LFA1 SI.DIODE

No. 51945

V28H20EUS

V28H20EUB

Symbol No. Part No. Part Name Description

DIODE

D2904 EU2A-T2 SI.DIODE D2905 1SS133-T2 SI.DIODE D2906 MTZJ27B-T2 ZENER DIODE D2907 1SS133-T2 SI.DIODE

D2908 1SS133-T2 SI.DIODE D2910 MTZJ15B-T2 ZENER DIODE D2911 1SS133-T2 SI.DIODE D2931 S1WB/A/60-4101 SI.DIODE

D2945 1SS133-T2 SI.DIODE D2951 RU4AM-LFT2 SI.DIODE D2952 RGP10J-5025-T3 SI.DIODE D2953 RU4AM-LFT2 SI.DIODE

D2955 RU3YX-LFC4 SI.DIODE D2956 RGP10J-5025-T3 SI.DIODE

D2958 MTZJ33B-T2 ZENER DIODE D2959 RU3YX-LFC4 SI.DIODE D2960 1SR124-400A-T2 SI.DIODE D2961 1SS133-T2 SI.DIODE

D2981 1SS133-T2 SI.DIODE D2984 1SS133-T2 SI.DIODE

D2985 1SS133-T2 SI.DIODE

TRANSISTOR

Q2421 DTC124ESA-T DIGI.TRANSISTOR Q2422 2SC1740S/QR/-T SI.TRANSISTOR Q2461 2SK2459N-F54 F.E.T.

Q2462-63 2SC1740S/QR/-T SI.TRANSISTOR Q2464 2SA933AS/QR/-T SI.TRANSISTOR Q2501 BSN304-T F.E.T. Q2521 2SC5552-RL SI.TRANSISTOR H.OUT

Q2581 2SA1208/ST/Z1-T SI.TRANSISTOR

Q2582 DTC144ESA-T DIGI.TRANSISTOR Q2583 2SC1740S/QR/-T SI.TRANSISTOR Q2941-42 2SC1740S/QR/-T SI.TRANSISTOR

IC2401 AN5523 I.C(M) IC2461 BA10393 I.C(MONO-ANA) IC2551 BA12T I.C(MONO-ANA) IC2901 STR-F6667B/F7 I.C(HYBRID)

IC2902 QAL0425-001 P.W.B.MODULE IC2951 SE140N I.C(HYBRID) IC2954 BA05T I.C(MONO-ANA) IC2955 PQ3RD13 I.C(MONO-ANA)

OTHERS

CN2004-06 QGB1506M1-16 CONNECTOR CN2014 QGA2501C5-06Z EH POST HEADER CP2951 ICP-N75-Y I.C.PROTECT

! !

CP2952 ICP-N75-Y I.C.PROTECT

CP2953 ICP-N75-Y I.C.PROTECT

CP2955 ICP-N75-Y I.C.PROTECT K2401 QQR0621-002Z BEADS CORE K2522-24 CE41832-001 LEAD CORE

K2901 QQR0679-001 FERRITE BEADS

LF2901 QQR1095-001 LINE FILTER PC2901 PC123FY2 I.C(PH.COUPLER)

RY2931 QSK0099-001 RELAY

TH2901 QAD0133-9R0 P.THEMISTOR

■■■■CRT SOCKET P.W. BOARD ASS’Y

(SMF -3402A-U2)

Symbol No. Part No. Part Name Description

RESISTOR

R3101 NRSA63J-223X MG R 22kΩ 1/16W J R3102 NRSA63J-681X MG R 680Ω 1/16W J

R3103 NRSA63J-101X MG R 100Ω 1/16W J R3104 NRSA63J-822X MG R 8.2kΩ 1/16W J R3105 NRSA63J-102X MG R 1kΩ 1/16W J R3106 NRSA63J-221X MG R 220Ω 1/16W J R3107 NRSA63J-561X MG R 560Ω 1/16W J

R3109 NRSA63J-153X MG R 15kΩ 1/16W J

R3110 NRSA63J-222X MG R 2.2kΩ 1/16W J R3111 NRSA63J-471X MG R 470Ω 1/16W J R3112 NRSA63J-272X MG R 2.7kΩ 1/16W J R3113-14 NRSA63J-152X MG R 1.5kΩ 1/16W J R3115 NRSA63J-390X MG R 39Ω 1/16W J R3116 QRG01GJ-101 OM R 100Ω 1W J

R3117 NRSA63J-331X MG R 330Ω 1/16W J R3122 NRSA63J-122X MG R 1.2kΩ 1/16W J

R3123 QRE121J-563Y C R 56kΩ 1/2W J R3124 NRSA63J-470X MG R 47Ω 1/16W J R3125 QRE121J-563Y C R 56kΩ 1/2W J R3126 NRSA63J-470X MG R 47Ω 1/16W J R3127 NRSA63J-122X MG R 1.2kΩ 1/16W J

R3128 NRSA63J-390X MG R 39Ω 1/16W J R3129-30 QRE121J-2R7Y C R 2.7Ω 1/2W J R3131 NRSA63J-390X MG R 39Ω 1/16W J

R3132 NRSA63J-121X MG R 120Ω 1/16W J R3133 QRL029J-681 OM R 680Ω 2W J

R3134 QRZ9021-561 F R 560Ω 1W J R3204-06 NRSA63J-272X MG R 2.7kΩ 1/16W J R3211 NRSA63J-154X MG R 150kΩ 1/16W J

R3223-25 NRSA63J-272X MG R 2.7kΩ 1/16W J R3227 NRSA63J-103X MG R 10kΩ 1/16W J R3228 NRSA63J-272X MG R 2.7kΩ 1/16W J

R3229-31 QRL029J-104-F OM R 100kΩ 2W J R3232-34 NRSA63J-332X MG R 3.3kΩ 1/16W J R3235-37 QRC121K-152Z COMP.R 1.5kΩ 1/2W K

R3239 QRZ0107-474Z C R 470kΩ 1/2W K R3240 QRC121K-102Z MF R 1kΩ 1/2W K R3241 QRZ0107-105Z C R 1.0MΩ 1/2W K R3242 NRSA63J-103X MG R 10kΩ 1/16W J R3244 NRSA63J-102X MG R 1kΩ 1/16W J

R3245-47 NRSA63J-562X MG R 5.6kΩ 1/16W J R3301-02 QRE121J-474Y C R 470kΩ 1/2W J

R3303-04 NRSA63J-223X MG R 22kΩ 1/16W J R3305 NRSA63J-562X MG R 5.6kΩ 1/16W J R3306 NRSA63J-392X MG R 3.9kΩ 1/16W J R3310 NRSA63J-0R0X MG R 0.0Ω 1/16W J

CAPACITOR

C3102 NDC31HJ-6R0X C CAP. 6pF 50V J C3103 NDC31HJ-390X C CAP. 39pF 50V J

C3104 QCB31HK-103Z C CAP. 0.01µ F 50V K C3106 QETN1HM-335Z E CAP. 3.3µF 50V M

C3107 QETN1CM-107Z E CAP. 100µF 16V M C3110 QETN2CM-106Z E CAP. 10µF 160V M C3111 QCB32HK-472Z C CAP. 4700pF 500V K

C3113 QETN2CM-106Z E CAP. 10µ F 160V M

C3114 QCB32HK-472Z C CAP. 4700pF 500V K C3116-17 QETN1AM-107Z E CAP. 100µF 10V M

C3118 QETN1AM-337Z E CAP. 330µF 10V M C3120-21 NDC31HJ-221X C CAP. 220pF 50V J

C3201-03 NDC31HJ-100X C CAP. 10pF 50V J C3204-06 NCF31CZ-104X C CAP. 0.1µF 16V Z

C3207-09 QETN1EM-476Z E CAP. 47µF 25V M C3210-12 QFK62EK-104Z MM CAP. 0.1µF 250V K

C3213-15 NDC31HJ-181X C CAP. 180pF 50V J

No. 51945

Symbol No. Part No. Part Name Description

CAPACITOR

C3216 QETN1CM-107Z E CAP. 100µF 16V M C3218 QETM2EM-336 E CAP. 33µF 250V M C3219 QFZ0097-223 MM CAP. 0.022µF 1250V K C3221 QETN2EM-106Z E CAP. 10µF 250V M C3302 QETN1HM-476Z E CAP. 47µF 50V M

COIL

L3101 QQL244K-5R6Z COIL 5.6µ H K L3204 QQL26AJ-102Z COIL 1mH J

DIODE

D3101-02 MA111-X SI.DIODE D3103 RH1S-T3 SI.DIODE D3104 RH1S-T3 SI.DIODE D3204-06 EU01N-T2 SI.DIODE

D3207 RM2C-LFA1 SI.DIODE D3208-10 1SR124-400A-T2 SI.DIODE D3211 MA3062/M/-X ZENER DIODE D3301 MA111-X SI.DIODE

D3303 MA111-X SI.DIODE

TRANSISTOR

Q3101 2SC2412K/QR/-X SI.TRANSISTOR Q3102 2SA1037AK/QR/-X SI.TRANSISTOR

Q3103 2SC1906-T SI.TRANSISTOR Q3104 2SC2412K/QR/-X SI.TRANSISTOR Q3105 2SC1627A/OY/-T SI.TRANSISTOR Q3108 2SA1837 SI.TRANSISTOR Q3109 2SC4793 SI.TRANSISTOR

Q3301 2SA1037AK/QR/-X SI.TRANSISTOR

IC3201-03 TDA6111Q I.C(MONO-ANA)

OTHERS

K3101 CE41492-001Z CHOKE COIL K3103-04 CE41492-001Z CHOKE COIL

K3105 QQR0621-002Z BEADS CORE SG3201-03 QAF0056-501Z VARISTOR

SK3001 QNZ0464-001 C.R.T.SOCKET W3003 QQR0679-001 FERRITE BEADS W3022 QQR0679-001 FERRITE BEADS

V28H20EUS V28H20EUB

■■■■FRONT CONTROL P.W. BOARD ASS’Y

Symbol No. Part No. Part Name Description

RESISTOR

R8039 NRSA63J-331X MG R 330Ω 1/16W J

CAPACITOR

C8001-02 NCB31HK-103X C CAP. 0.01µF 50V K C8004 NCB31CK-104X C CAP. 0.1µF 16V K

C8005 NDC31HJ-680X C CAP. 68pF 50V J C8010-11 NCB31HK-472X C CAP. 4700pF 50V K

C8019 QETN1CM-107Z E CAP. 100µF 16V M C8021 NCB31CK-104X C CAP. 0.1µF 16V K C8022 QETN1EM-476Z E CAP. 47µF 25V M

C8901 QFZ9072-474 MF CAP. 0.47µFAC275V K

COIL

L8001 QQR0716-001Z LEAD CORE L8002-03 QQL244K-5R6Z COIL 5.6µH K

L8010-11 QQL244K-270Z PEAKING COIL L8012 QQR0716-001Z LEAD CORE

DIODE

D8010 SPR-39MVWF L.E.D. D8011 MA111-X SI.DIODE

D8014 MA3068/M/-X ZENER DIODE D8018 MA3033-X ZENER DIODE

TRANSISTOR

Q8002 DTC124EKA-X DIGI.TRANSISTOR Q8003-04 DTA124EKA-X DIGI.TRANSISTOR

IC8001 GP1U281Q IFR DETECT UNIT

OTHERS

CEMG002-001Z FUSE CLIP LC30596-001B-C L.E.D.HOLDER

F8901 QMF51D2-3R15J1 FUSE 3.15A J8001 QMS3004-C01 HEADPHONE JACK J8003 QNZ0453-001 JACK LC8002 NQR0169-001X EMI FILTER

LF8901 QQR1095-001 LINE FILTER

S8001 QSW0619-003Z PUSH SWITCH MENU S8002 QSW0619-003Z PUSH SWITCH CH DOWN S8003 QSW0619-003Z PUSH SWITCH CH UP

S8901 QSW0824-001 PUSH SWITCH MAIN POWER

CM35921-005-H CDS HOLDER

(SMF -8402A-U2)

■■■■

MICO M P.W. BOAR D ASS’Y (SMF0M4 01A-U2 )

Refe r to PARTS LIST in p age 42 f or this P.W . board.

■■■■AV SW P.W. BOARD ASS’Y (SMF0S401A-U2)

Refe r to PARTS LIST in p age 43 f or this P.W . board.

■■■■100 Hz P.W. BOARD ASS’Y (SMF0Z405A-U2)

Refe r to PARTS LIST in p age 44 f or this P.W . board.

No. 51945

V32H20EUS

)

V28H20EUS V28H20EUB

REMOTE CONTROL UNIT PARTS LIST

AV32H20EUS / AV28H20EUS (RM-C54H-1C

Ref.No. Part No. Part Name Description

1 2AA030733 BATTERY COVER 2 2AA030732 SLIDE COVER

AV28H20EUB (RM-C50-1C

Ref.No. Part No. Part Name Description

1 2AA027770 BATTERY COVER 2 2AA027761 SLIDE COVER

No. 51945

PACKING

V32H20EUS V28H20EUS V28H20EUB

9 10

11 12

768

PACKING PARTS LIST

AV32H20EUS

Ref.No. Part No. Part Name Description

1 AEM1002-E70-E PACKING CASE 2 AEM1052-063-E EURO LABEL

3 LC10384-002C-U CUSHION ASSY 4pcs in 1set 4 AEM1047-A02-E POLY BAG 5 RM-C54H-1C REMOCON UNIT 6 AEM3021-003A-E POLY BAGS (x2) 7 LCT1142-001A-U INST.BOOK

! !

8 LCT1143-001A-U INST.BOOK

9 LCT1144-001A-U INST.BOOK

10 BT-54013-1E WARRANTY CARD 11 AEM1075-001A-U X-RAY CARD

12 2832H20EU-HSAE S.DIAGRAM [ITALY EDITION]

AV28H20EUS / AV 28H20EUB

Ref.No. Part No. Part Name Description

1 AEM1002-B68-E PACKING CASE 2 AEM1052-064-E EURO LABEL [AV28H20EUS]

2 AEM1052-096-E EURO LABEL [AV28H20EUB] 3 LC10722-002A-U CUSHION ASSY 4pcs in 1set 4 AEM1047-A02-E POLY BAG 5 RM-C54H-1C REMOCON UNIT [AV28H20EUS]

5 RM-C50-1C REMOCON UNIT [AV28H20EUB] 6 AEM3021-003A-E POLY BAGS (x2)

7 LCT1142-001A-U INST.BOOK

8 LCT1143-001A-U INST.BOOK

! !

9 LCT1144-001A-U INST.BOOK 10 BT-54013-1E WARRANTY CARD 11 AEM1073-001A-U X-RAY CARD 12 2832H20EU-HSAE S.DIAGRAM [ITALY EDITION]

No. 51945

VICTOR COMPANY OF J APAN, LIMIT ED

HOME AV NETWORK BU SINESS UNIT 12, 3-chome, Moriya-cho, Kanagawa- ku, Yokohama, Kanagawa-prefecture, 221-8528, Japan

AV32H20EU S- U #3 AV28H20EU S- U #3 AV28H20EU B- U #3

VP 0205 DP8061
