JVC AV 20F476, AV-27F476, AV-32F476 User Manual

Color Television Users Guide

For Models:

AV-20F476
AV-27F476
AV-32F476

Illustration of AV-32F476 and RM-C1258G

Important Note:

In the spaces below, enter the model and serial number of your television (located at the
rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this
guide. Keep this user's guide in a convenient place for future reference. Keep the carton and
original packaging for future use.

Model Number:

Serial Number:

LCT1785-001A-A

1204JGI-II-IM

Important Safety Precautions

CAUTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock. Do not remove

cover (or back). No user serviceable parts inside. Refer
servicing to qualifi ed service personnel.

The lightning fl ash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of suffi cient magnitude
to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS TV SET TO

RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specifi ed on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid Improper installation and never position the unit where good ventilation is

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do not attempt

Changes or modifi cations not approved by JVC could void the warranty.

• When you don’t use this TV set for a long period of time, be sure to disconnect both

• To prevent electric shock do not use this polarized plug with an extension cord,

unattainable.

to repair it yourself or remove the rear cover.

the power plug from the AC outlet and antenna for your safety.

receptacle or other outlet unless the blades can be fully inserted to prevent blade
exposure.

IMPORTANT RECYCLING INFORMATION

This product utilizes both a Cathode Ray Tube (CRT) and other components
that contain lead. Disposal of these materials may be regulated in your
community due to environmental considerations. For disposal or recycling
information, please contact your local authorities, or the Electronic
Industries Alliance: http://www.eiae.org

2

• As an “ENERGY STAR®” partner, JVC has determined
that this product or product model meets the “ENERGY
STAR®” guidelines for energy effi ciency.

Important Safeguards

CAUTION:

Please read and retain for your safety.

Electrical energy can perform many useful functions. This TV set has been engineered and manufactured to
assure your personal safety. But improper use can result in potential electrical shock or fi re hazards.
In order not to defeat the safeguards incorporated in this TV set, observe the following basic rules for its

installation, use and servicing. Also follow all warnings and instructions marked on your TV set.

INSTALLATION

1 Your TV set is equipped with a polarized AC line plug (one blade of the

plug is wider than the other). This safety feature allows the plug to fi t
into the power outlet only one way. Should you be unable to insert the
plug fully into the outlet, try reversing the plug. Should it still fail to fi t,
contact your electrician.

2 Operate the TV set only from a power source as indicated on the TV set or refer to the operating

instructions for this information. If you are not sure of the type of power supply to your home, consult your
TV set dealer or local power company. For battery operation, refer to the operating instructions.

3 Overloaded AC outlets and extension cords are dangerous, and so are frayed power cords and broken

plugs. They may result in a shock or fi re hazard. Call your service technician for replacement.

4 Do not allow anything to rest on or roll over the power cord, and do not place the TV set where power cord

is subject to traffi c or abuse. This may result in a shock or fi re hazard.

5 Do not use this TV set near water – for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a

wet basement, or near swimming pool, etc.

6 If an outside antenna is connected to the TV set, be sure the antenna system is grounded so as to provide

some protection against voltage surges and built-up static charges. Section 810 of the National Electrical
Code provides information with respect to proper grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge
unit, connection requirements for the grounding electrode.

(POLARIZED-TYPE)

3

7 An outside antenna system

should not be located in the
vicinity of overhead power
lines or other electric light
or power circuits, or where it
can fall into such power lines
or circuits. When installing
an outside antenna system,
extreme care should be taken
to keep from touching such
power lines or circuits as
contact with them might be
fatal.

ELECTRICAL
SERVICE
EQUIPMENT

NEC - NATIONAL ELECTRIC CODE

GROUND
CLAMP

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ARTICLE 250, PART H)

ANTENNA
LEAD IN
WIRE

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE

8 TV sets are provided with ventilation openings in the cabinet to allow heat generated during operation to be

released.

Therefore:

— Never block the bottom ventilation slots of a portable TV set by placing it on a bed, sofa, rug, etc.
— Never place a TV set in a “built-in” enclosure unless proper ventilation is provided.
— Never cover the openings with a cloth or other material.
— Never place the TV set near or over a radiator or heat register.

9 To avoid personal injury:

— Do not place a TV set on a sloping shelf unless properly secured.
— Use only a cart or stand recommended by the TV set manufacturer.
— Do not try to roll a cart with small casters across thresholds or deep pile carpets.
— Wall or shelf mounting should follow the manufacturer’s instructions, and should use a mounting kit

approved by the manufacturer.

Use

10 Caution children about dropping or pushing objects into the TV set through cabinet openings. Some

internal parts carry hazardous voltages and contact can result in a fi re or electrical shock.

11 Unplug the TV set from the wall outlet before cleaning. Do not use liquid or an aerosol cleaner.

12 Never add accessories to a TV set that has not been designed for this purpose. Such additions may result

in a hazard.

4

PORTABLE CART WARNING (Symbol provided by RETAC)

13 For added protection of the TV set during a lightning storm or when the TV set is to be left unattended for

an extended period of time, unplug it from the wall outlet and disconnect the antenna. This will prevent
damage to product due to lightning storms or power line surges.

14 A TV set and cart combination should be moved with care. Quick stops, excessive force, and uneven

surfaces may cause the TV set and cart combination to overturn.

Service

15 Unplug this TV set from the wall outlet and refer servicing to qualified service personnel under the

following conditions:
A. When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the TV set.
C. If the TV set has been exposed to rain or water.
D. If the TV set does not operate normally by following the operating instructions. Adjust only those

controls that are covered in the operating instructions as improper adjustment of other controls may
result in damage and will often require extensive work by a qualified technician to restore the TV set to
normal operation.

E. If the TV set has been dropped or damaged in any way.
F. When the TV set exhibits a distinct change in performance — this indicates a need for service.

16 Do not attempt to service this TV set yourself as opening or removing covers may expose you to

dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

17 When replacement parts are required, have the service technician verify in writing that the replacement

parts he uses have the same safety characteristics as the original parts. Use of manufacturer’s specified
replacement parts can prevent fire, shock, or other hazards.

18 Upon completion of any service or repairs to this TV set, please ask the service technician to perform the

safety check described in the manufacturer’s service literature.

19 When a TV set reaches the end of its useful life, improper disposal could result in a picture tube

implosion. Ask a qualified service technician to dispose of the TV set.

20 Note to CATV system installer.

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC
that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.

5

Table of Contents

Quick Setup . . . . . . . . . . . 7

Unpacking your TV . . . . . . . . . . . . 7

TV Models . . . . . . . . . . . . . . . . 8

TV Remote Control . . . . . . . . . . . 9

Getting Started . . . . . . . . . . . . . 10

The Remote Control . . . . . . . . . . 10

Connecting Your Devices . . . . . . . 11

Interactive Plug In Menu . . . . . . . . 15

Remote Programming . . . . . 18

Setting CATV, VCR and DVD Codes . . . 18

CATV or Satellite Codes . . . . . . . . 18

VCR Codes . . . . . . . . . . . . . . 19

DVD Codes . . . . . . . . . . . . . . 20

Search Codes . . . . . . . . . . . . . 21

Onscreen Menus . . . . . . . . 22

Using the Guide . . . . . . . . . . . . . 22

Onscreen Menu System . . . . . . . . . 23

Initial Setup . . . . . . . . . . 24

Auto Tuner Setup . . . . . . . . . . . . 24

Channel Summary . . . . . . . . . . . . 24

V-Chip . . . . . . . . . . . . . . . . . . 25

Set Lock Code . . . . . . . . . . . . . 31

Language . . . . . . . . . . . . . . . . 32

Closed Caption . . . . . . . . . . . . . 32

Front Panel Lock . . . . . . . . . . . . 33

Auto Shut Off . . . . . . . . . . . . . . 33

XDS ID . . . . . . . . . . . . . . . . . 33

Video Input Label . . . . . . . . . . 34

Picture Adjust . . . . . . . . . 35

Picture Settings . . . . . . . . . . . . . 35

Adjust Picture Settings . . . . . . . . . 35

Color Temperature . . . . . . . . . . . . 36

Noise Muting . . . . . . . . . . . . . . 36

VSM . . . . . . . . . . . . . . . . . 36

Clock Timers . . . . . . . . . . 38

Set Clock . . . . . . . . . . . . . . . . 38

On/Off Timer . . . . . . . . . . . . . . . 39

World Clock . . . . . . . . . . . . . . 40

Button Functions . . . . . . . 41

Power . . . . . . . . . . . . . . . . . . 41

Number Buttons . . . . . . . . . . . . . 41

100+ Button . . . . . . . . . . . . . . . 41

Channel +/– . . . . . . . . . . . . . . . 41

Volume +/– . . . . . . . . . . . . . . . 41

Muting . . . . . . . . . . . . . . . . . . 41

Menu . . . . . . . . . . . . . . . . . . 41

Exit . . . . . . . . . . . . . . . . . . . 41

Return + . . . . . . . . . . . . . . . . . 42

Input . . . . . . . . . . . . . . . . . . . 42

Display . . . . . . . . . . . . . . . . . 43

Sleep Timer . . . . . . . . . . . . . . . 43

Sound . . . . . . . . . . . . . . . . . . 44

C.C. . . . . . . . . . . . . . . . . . . . 44

Video Status . . . . . . . . . . . . . . . 45

TheaterPro D6500K . . . . . . . . . . . 45

Aspect . . . . . . . . . . . . . . . . 45

TV/CATV Slide Switch . . . . . . . . . . 46

VCR/DVD Slide Switch . . . . . . . . . 46

VCR Buttons . . . . . . . . . . . . . . . 46

DVD Buttons . . . . . . . . . . . . . . . 46

Appendices . . . . . . . . . . 47

Troubleshooting . . . . . . . . . . . . . 47

Specifications . . . . . . . . . . . . . . 48

Warranty . . . . . . . . . . . . . . . . . 50

Authorized Service Centers . . . . . . . 51

Sound Adjust . . . . . . . . . 37

Sound Settings . . . . . . . . . . . . . 37

Adjust Sound Settings . . . . . . . . . 37

MTS (Multi-channel Sound) . . . . . . . 37

Smart Sound . . . . . . . . . . . . 37

6

Quick Setup Unpacking Your TV

Thank you for your purchase of a JVC Color Television. Before you begin setting up your new
television, please check to make sure you have all of the following items. In addition to this
guide, your television box should include:

1 Television

1 Remote Control

Two AA

Batteries

AA Alkaline

POWER

TV

DVD

CATVVCR

INPUT

DISPLAY

1

3

2

SLEEP TIMER

4

6

5

SOUND

7

9

8

RETURN+

100+

VIDEO STATUS

0

THEATER PRO

ASPECT

MUTING

C.C.

CH +

VOL

VOL

+

–

CH –

EXIT

MENU

VCR/DVD

VCR CHANNEL

TV/VCR

POWER

PREV NEXT

PLAY FFREW

REC

STOP PAUSE

OPEN/CLOSE

ON TIMER

POWER

STILL/PAUSE

RM-C1258G

TV

Note: Your television
and/or remote
control may differ
from the examples
illustrated here.

AA Alkaline

Once you have unpacked your television, the next step is to connect it to your antenna/
cable or satellite system and to connect the audio/video devices you want to use with your
television. To make these connections you will use plugs like the ones illustrated below.

Coaxial Cables

Component Cables

Composite Cables

Audio Cables

Used to connect an
external antenna or
cable TV system to your
TV.

S-Video Cable

Used to connect audio/
video devices like
VCRs, DVD players,
stereo amplifiers, game
consoles, etc.

Used to make video
connections with S-Video
VCRs, Camcorders and
DVD players.

We recommend that before you start using your new television, you read your entire User’s
Guide so you can learn about your new television’s many great features. If you’re anxious to
start using your television right away, a quick setup guide follows on the next few pages.

7

Quick Setup TV Models

NOTE: Before you connect your television to another device, please refer to the proper

diagrams for your specific TV and remote. These will help assist you in understanding
how to connect your television to another device, as well as use the remote to set up
your television.

Rear Panel Diagrams

MODELS:
AV-32F476
AV-27F476

R L MONO

R

AUDIO OUT

AUDIO

L

OVER

S VIDEOVIDEO

INPUT 1

INPUT 2

COMPONENT

VIDEO

Video/Y

PB

PR

75Ω

(VHF / UHF)

MODEL:
AV-20F476

Front Panel Diagrams

VIDEO

MODELS: AV-32F476, AV-27F476

VIDEO L MONO AUDIO R

MODEL: AV-20F476

AUDIO OUT

INPUT 3

L MONO

INPUT 3

INPUT 1

S-VIDEO

OVER

VIDEO

AUDIO

L/MONO

L

R

AUDIO R

RR

MENU CHANNEL VOLUME

OPERATE

L/MONO

MENU

INPUT 2

COMPONENT

VIDEO

VIDEO/Y

B

P

PR

CHANNEL

OPERATE

75Ω

(VHF/UHF)

VOLUME

8

Quick Setup TV Remote Control

TV

CATV VCR

INPUT

DISPLAY

SLEEP TIMER

SOUND

VIDEO STATUS

THEATER PRO

MUTING

VOL

–

MENU

VCR CHANNEL

PREV NEXT

REC

OPEN/CLOSE

DVD

1

4

7

100+

ASPECT

CH +

CH –

VCR/DVD

POWER

PLAY FFREW

STOP PAUSE

RM-C1258G

TV

POWER

2

5

8

RETURN+

0

C.C.

VOL

+

EXIT

TV/VCR

STILL/PAUSE

3

6

9

RM-C1258G

MODELS:
AV-20F476
AV-27F476
AV-32F476

• For information on remote control buttons, see pages 41 - 46.

9

Quick Setup Getting Started

V

Getting Started

These quick setup pages will provide you, in three easy steps, with the basic information you
need to begin using your new television right away.

If you have questions, or for more detailed information on any of these steps, please consult
other sections of this manual.

Step 1 – The Remote Control

Before you can operate your remote control, you first need to install the batteries (included).

Lift and pull the latch on the back of the
remote control to open. Insert two batteries
(included) carefully noting the “+” and “–”
markings, placing the “–” end in the unit first.
Snap the cover back into place.

When you change the batteries, try to
complete the task within three minutes.
If you take longer than three minutes,
the remote control codes for your VCR,
DVD, and/or cable box/satellite receiver
may have to be reset. See pages 18 - 20.

Key Feature Buttons

The four key feature buttons at the center of the remote
can be used for basic operation of the television.
The top and bottom buttons will scan forward and
back through the available channels. To move rapidly
through the channels using JVC’s Hyperscan feature,
press and hold CH+ or CH –. The channels will zip by
at a rate of five channels per second. The right and left
buttons will turn the volume up or down. These buttons
are also marked with four arrows and are used with
JVC’s onscreen menu system. To use the onscreen
menus, press the M

ENU button.

MUTING

VOL

–

MENU

CH +

CH –

C.C.

VOL

+

EXIT

Basic Operation

Turn the television on and off by pressing the POWER button at the top right
corner of the remote. If this is the first time you are turning on the TV, the
interactive plug-in menu appears.

• Make sure the TV/CATV switch is set to TV. Move the switch to CATV only if
you need to operate a cable box.

• Slide the VCR/DVD selector switch to VCR to control a VCR. Slide to
DVD to control a DVD player. Please see pages 18 to 21 for instructions on
programming your remote control to operate a cable box, VCR or DVD player.

10

POWER

TV

CATV

VCR DVD

Quick Setup Connections

Step 2 – Connecting Your Devices

Please follow the flow chart below to determine which connection setup is right for you. Then,
refer to the appropriate diagrams to connect your television to other devices that you may
have. After you are finished connecting your devices, plug the power cord into the nearest
power outlet and turn on the TV.

A VCR is not necessary for operation of the television. If you follow these diagrams and the
television does not work properly, contact your local cable operator.

• To connect a DVD player, see Diagram #3. A DVD player is optional.

• If you have a satellite television system, please refer to the satellite TV manual.

Do you use a Cable TV Box?

Yes

Do you have a VCR? Do you have a VCR?

Yes No Yes No

Diagram #2

Diagram #1 Diagram #3 Diagram #1

No

11

Quick Setup Connections

Diagram #1

Illustration of AV-32F476

TV Rear Panel

R L MONO

R

AUDIO OUT

AUDIO

L

S VIDEOVIDEO

OVER

INPUT 1

INPUT 2

COMPONENT

VIDEO

Video/Y

PB

PR

75Ω

(VHF / UHF)

Coaxial Cable

Note:

• If you do not have a cable box, connect the cable wire from the wall outlet into the back of
the TV.

Diagram #2

Illustration of AV-32F476

TV Rear Panel

R L MONO

R

AUDIO OUT

AUDIO

L

S VIDEOVIDEO

OVER

INPUT 1

INPUT 2

COMPONENT

VIDEO

Video/Y

PB

PR

75Ω

(VHF / UHF)

Cable or Antenna

OR

OUT IN

Cable Box

Cable or Antenna

Output

Output

Coaxial Cable

IN

OUT

R L V

OR

OUT

VCR

IN

OUT IN

Cable Box

Notes:

• If your VCR is a mono sound unit, it will have only one audio out jack. Connect it to the TV’s
LEFT AUDIO INPUT.

• Use the S-Video connection if possible for superior picture quality.

• Your VCR must be turned on to view premium cable channels.

12

Quick Setup Connections

Notes:

• Green, blue and red are the most common colors for DVD cables. Some models may vary
colors. Please consult the user’s manual for your DVD player for more information.

• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete
one set of connections (DVD or audio output) before starting the other to avoid accidentally
switching the cables.

• If you use INPUT 2 (Component-In), for a DVD connection, you must select
"V2-COMPONENT" by pressing the I

• Progressive DVD players (players with an output scan of 31.5 KHz) will not work properly with
this television. Set your DVD player’s output to “interlaced”, or non-progressive mode.

Diagram #3

Illustration of AV-32F476

DVD Player (OPTIONAL)

Green

Blue

Red

Y

B

P

PR

OUT

AUDIO OUT

L R

NPUT button, for proper display of the DVD signal.

Cable or Antenna

VCR

R L V

AUDIO

R L MONO

R

AUDIO OUT

IN

IN

OUT

OUT

OR

S VIDEOVIDEO

OVER

INPUT 1

INPUT 2

COMPONENT

VIDEO

L

Video/Y

75Ω

(VHF / UHF)

PB

PR

Output

Coaxial Cable

Headphone Connection

You can connect a pair of headphones to the television using the headphone jack located under
the front panel door. To access, push on the door to open it.

1) Plug a headphone jack into the headphone jack on the television’s front panel.

Note:

• AV-20F476 ONLY

13

Quick Setup Connections

r

Connecting to a Camcorder

You may connect a camcorder, game console or other equipment to your television by using
the front input jacks (Input 3) located under the front panel door. To access, pull on the door
to open it. You can also connect these using the television’s rear input jacks, using the same
instructions.

Illustration of AV-32F476

INPUT 3

AUDIO R

L MONO

VIDEO

MENU

CHANNEL

OPERATE

1) Connect a yellow composite cable from the camcorder VIDEO OUT, into the VIDEO IN on

the front of the TV.

2) Connect a white composite cable from the camcorder LEFT AUDIO OUT, into the

LEFT AUDIO IN on the front of the TV.

3) Connect a red composite cable from the camcorder RIGHT AUDIO OUT, into the

RIGHT AUDIO IN on the front of the TV.

Note:

• If your camcorder is a mono sound model it will have only one AUDIO OUT. Connect it to the
LEFT AUDIO IN.

VOLUME

Camcorde

Connecting to an External Amplifier

Illustration of AV-32F476

L

SpeakerSpeaker

Amplifier

R

AUDIO OUT

TV Rear Panel

1) Connect a white composite cable from the LEFT AUDIO OUTPUT on the back of the TV to
the LEFT AUDIO INPUT on the amplifier.

2) Connect a red composite cable from the RIGHT AUDIO OUTPUT on the back of the TV to
the RIGHT AUDIO INPUT on the amplifier.

Notes:

• Refer to your amplifier’s manual for more information.

• You can use AUDIO OUTPUT for your home theater system.

14

Quick Setup Plug-In Menu

Step 3 – The Interactive Plug In Menu

When you turn your television on for the first time the interactive plug-in menu will appear. The
plug-in menu helps you to get your TV ready to use by letting you set your preferences for:

• The language in which you want the onscreen menus to appear.

• Setting the TV’s clock to the correct time so your timer functions will work properly. You can
choose “AUTO” or “MANUAL” for setting the clock.

• The auto tuner setup of which channels you wish to receive.

We recommend you complete the interactive plug-in items before you start using your
television.

Language

After the “JVC INTERACTIVE PLUG IN MENU” has been displayed, the TV automatically
switches to the LANGUAGE settings. You can choose to view your onscreen menus in three
languages: English, French (Français) or Spanish (Español).

è

INTERACTIVE PLUG IN MENU

LANGUAGE/LANGUE/IDIOMA

ENGLISH

>

To choose a language:

(English, Français or Español)

†

To NEXT (To set clock)

SELECT
OPERATE BY

BY

NEXT

EXIT BY

EXIT

(To be continued...)

15

Quick Setup Plug-In Menu

Auto Clock Set

Before you use any of your TV’s timer functions, you must first set the clock. You may precisely
set your clock using the XDS time signal broadcast by most public broadcasting stations. If you
do not have this in your area, you will have to set the clock manually. See manual clock set
below. To set the clock using the XDS signal:

è

INTERACTIVE PLUG IN MENU
SET CLOCK

MODE
TIME
TIME ZONE

D.S.T.

NEXT
SELECT
OPERATE BY

BY

>

AUTO

––:–– ––

PACIFIC

OFF

EXIT BY

EXIT

Notes:

• D.S.T. can be used only for US and Canada when it is set to ON in the SET CLOCK menu.

• Only when the MODE set to AUTO, the Daylight Savings Time feature automatically adjusts
your TV’s clock for Daylight Savings. The clock will move forward one hour at 2:00 am on
the first Sunday in April. The clock will move back one hour at 2:00 am on the last Sunday in
October.

• You will have to reset the clock after a power interruption. You must set the clock before
operating any timer functions.

To choose AUTO

†

To TIME ZONE

è

To select your time zone:
(Atlantic, Eastern, Central, Mountain, Pacific,
Alaska or Hawaii)

†

To move to D.S.T. (Daylight Savings Time)

è

To turn D.S.T. ON or OFF

†

To NEXT (To Auto Tuner Setup)

Manual Clock Set

To set your clock manually (without using the XDS signal), choose MANUAL. If you choose
AUTO, see auto clock set above.

è

INTERACTIVE PLUG IN MENU
SET CLOCK

MODE
TIME
TIME ZONE

D.S.T.

SELECT
OPERATE BY

BY

START CLOCK

MANUAL

––:–– ––

PACIFIC

EXIT BY

>

OFF

EXIT

To choose MANUAL

†

è

†

è

†

To TIME

To set the hour

To minute

To set the minute

To START CLOCK

Note:

• You will have to reset the clock after a power interruption. You must set the clock before
operating any timer functions.

(To be continued...)

16
