PARTS LIST
CAUTION
J The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the
safety.
J The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied.
J P.W. BOARD Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.
ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES
RESISTORS CAPACITORS
CR Carbon Resistor C CAP. Ceramic Capacitor
FR Fusible Resistor E CAP. Electrolytic Capacitor
PR Plate Resistor M CAP. Mylar Capacitor
VR Variable Resistor CH CAP. Chip Capacitor
HV R High Voltage Resistor HV CAP. High Voltage Capacitor
MF R Metal Film Resistor MF CAP. Metalized Film Capacitor
MG R Metal Glazed Resistor MM CAP. Metalized Mylar Capacitor
MP R Metal Plate Resistor MP CAP. Metalized Polystyrol Capacitor
OM R Metal Oxide Film Resistor PP CAP. Polypropylene Capacitor
CMF R Coating Metal Film Resistor PS CAP. Polystyrol Capacitor
UNF R Non-Flammable Resistor TF CAP. Thin Film Capacitor
CH V R Chip Variable Resistor MPP CAP. Metalized Polypropylene Capacitor
CH MG R Chip Metal Glazed Resistor TAN. CAP. Tantalum Capacitor
COMP. R Composition Resistor CH C CAP. Chip Ceramic Capacitor
LPTC R Linear Positive Temperature Coefficient Resistor BP E CAP. Bi-Polar Electrolytic Capacitor
CH AL E CAP. Chip Aluminum Electrolytic Capacitor
CH AL BP CAP. Chip Aluminum Bi-Polar Capacitor
CH TAN. E CAP. Chip Tantalum Electrolytic Capacitor
CH AL BP E CAP. Chip Tantalum Bi-Polar Electrolytic Capacitor
RESISTORS
FGJ KMNRHZP
±1% ±2% ±5% ±10% ±20% ±30%
+30%
-10%
+50%
-10%
+80%
-20%
+100%
-0%
(No.YA052)3-1
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................................... 3-2
EXPLODED VIEW PARTS LIST -1 ............................................................................................................................. 3-3
EXPLODED VIEW -1 ................................................................................................................................................... 3-3
EXPLODED VIEW PARTS LIST -2 ............................................................................................................................. 3-4
EXPLODED VIEW -2 ................................................................................................................................................... 3-5
PRINTED WIRING BOARD PARTS LIST [AV-20F475/S]
MAIN P.W. BOARD ASS'Y (SFJ-1011A-M2) ..................................................................................................... 3-6
PRINTED WIRING BOARD PARTS LIST [AV-N21F45/S]
MAIN P.W. BOARD ASS'Y (SFJ-1012A-M2) ................................................................................................... 3-10
REMOTE CONTROL UNIT PARTS LIST (RM-C1258G-1H) .................................................................................... 3-14
PACKING ................................................................................................................................................................... 3-14
PACKING PARTS LIST ............................................................................................................................................. 3-14
USING P.W. BOARD & REMOTE CONTROL UNIT
P.W.B ASS'Y AV-20F475/S AV-N21F45/S
MAIN P.W.B SFJ-1011A-M2 SFJ-1012A-M2
REMOTE CONTROL UNIT RM-C1258G-1H ←
3-2(No.YA052)
EXPLODED VIEW PARTS LIST -1
Ref.No. Part No. Part Name Description Local
1 LC32242-001A-A RC LENS
2 CM48006-010-C JVC MARK
3 GQ30025-002A-A CONTROL KNOB
100 GQ10063-003B-A FRONT CABINET ASSY Inc.No.101-104 AV-20F475/S
100 GQ10063-004A-A FRONT CABINET ASSY Inc.No.101-104 AV-N21F45/S
101 GQ20006-001B-A DOOR
102 CM48229-00A-C DOOR LATCH
103 LC32240-001A-A POWER KNOB
104 CM36481-002A-A SPRING
EXPLODED VIEW -1
100
102
101
2
1
3
103
104
(No.YA052)3-3
EXPLODED VIEW PARTS LIST -2
Ref.No. Part No. Part Name Description Local
V01 A51QDX993X001 ITC Inc.DEF YOKE/PC MAGNET/WEDGE
L01 QQW0118-001 DEG COIL
T521 QQH0128-001 FB TRANSF
5 A48457-4-S SPRING
6 CHGB0016-0H BRAIDED ASSY
7 QAS0131-001 SPEAKER SP01/SP02(x2)
8 LC40226-003A-H SPACER (x4)
9 LC41029-001B-A TAPPING SCREW (x4)
10 LC21261-001B-A SP HOLDER (x2)
11 CM48144-001-A PB STOPPER
12 GQ10061-001A-A REAR COVER
13 GQ40041-001A-A WARNING LABEL
14 QMPD390-200-JS POWER CORD(US/CA) 2m BLACK
15 LC20106-001D-A POWER CORD CLAMP
16 QYSBSFG4016Z TAP SCREW 4.0mm x 16mm(x7)
17 QYSBSB3010Z TAP SCREW 3.0mm x 10mm(x4)
18 GQ30032-001A-A RATING LABEL AV-20F475/S
18 GQ20001-001A-A RATING LABEL AV-N21F45/S
19 GQ30034-001B-A WARNING LABEL
30 SFJ-1011A-M2 MAIN PWB Inc. CRT SOCKET PWB AV-20F475/S
30 SFJ-1012A-M2 MAIN PWB Inc. CRT SOCKET PWB AV-N21F45/S
3-4(No.YA052)
EXPLODED VIEW -2
L01
13
V01
7
8
9
10
CRT SOCKET PWB
(Within MAIN PWB)
T521
5
6
30
15
11
12
18
19
17
14
16
(No.YA052)3-5
PRINTED WIRING BOARD PARTS LIST [AV-20F475/S]
MAIN P.W. BOARD ASS'Y (SFJ-1011A-M2)
Ref No. Part No. Part Name Description Local
IC101 M52342FP-X IC
IC201 TM8812CSDNG5DB9 IC(MCU)
IC251 TC90A49AP IC
IC421 AN5522 IC
IC602 TFA9842J/N1 IC
IC641 CXA2205Q-X IC
IC702 AT24C08-20F475 IC (SERVICE)
IC703 S-80840CNY-T IC
IC704 AN78L05-T IC
IC751 GP1UM281QK IR DETECT UNIT 38kHz
IC851 TA1218AN IC
IC901 STR-G5624A/F8 IC
IC921 L7809CP IC
IC922 L7805CP IC
Q001 UN2212-X TRANSISTOR
Q101 2SC5083/L-P/-T TRANSISTOR
Q131 2SA1530A/QR/-X TRANSISTOR
Q161 2SC3928A/QR/-X TRANSISTOR
Q211 2SC3928A/QR/-X TRANSISTOR
Q232 2SC3928A/QR/-X TRANSISTOR
Q233 2SC3928A/QR/-X TRANSISTOR
Q251 2SC3928A/QR/-X TRANSISTOR
Q252 2SC3928A/QR/-X TRANSISTOR
Q281 2SA1530A/QR/-X TRANSISTOR
Q282 2SC3928A/QR/-X TRANSISTOR
Q283 2SA1530A/QR/-X TRANSISTOR
Q291 2SA1530A/QR/-X TRANSISTOR
Q292 2SC3928A/QR/-X TRANSISTOR
Q293 2SA1530A/QR/-X TRANSISTOR
Q301 2SC4075/DE/YA11 POW TRANSISTOR
Q311 2SC4075/DE/YA11 POW TRANSISTOR
Q321 2SC4075/DE/YA11 POW TRANSISTOR
Q331 2SA1530A/QR/-X TRANSISTOR
Q352 2SD601A/QR/-X TRANSISTOR
Q501 2SC4212/Z1/ TRANSISTOR
Q521 2SD2634-YD TRANSISTOR H.OUT
Q623 2SA1530A/QR/-X TRANSISTOR
Q625 2SC3928A/QR/-X TRANSISTOR
Q681 2SC3928A/QR/-X TRANSISTOR
Q682 2SC3928A/QR/-X TRANSISTOR
Q683 2SC3928A/QR/-X TRANSISTOR
Q684 2SC3928A/QR/-X TRANSISTOR
Q701 2SA1530A/QR/-X TRANSISTOR
Q751 UN2112-X TRANSISTOR
Q851 2SA1530A/QR/-X TRANSISTOR
Q921 2SD1383K/AB/-X SI TRANSISTOR
Q922 2SC2785/JH/-T SI TRANSISTOR
Q923 2SA1530A/QR/-X TRANSISTOR
Q924 2SA1208/ST/Z1-T TRANSISTOR
D331 1SS133-T2 DIODE
D332 1SS133-T2 DIODE
D333 1SS133-T2 DIODE
D334 1SS133-T2 DIODE
D352 MTZJ9.1C-T2 Z DIODE
D353 1SS133-T2 DIODE
D365 1SS133-T2 DIODE
D366 1SS133-T2 DIODE
D367 1SS133-T2 DIODE
D368 MTZJ5.1B-T2 Z DIODE
D369 MTZJ5.1B-T2 Z DIODE
D370 MTZJ5.1B-T2 Z DIODE
D401 1SR35-400A-T2 SI DIODE
D402 MTZJ75-T2 Z DIODE
D501 MTZJ3.3A-T2 Z DIODE
D521 1SR35-400A-T2 SI DIODE
D522 RH1S-T3 SI DIODE
D523 1SR35-400A-T2 SI DIODE
D524 RGP10J-04TS-T3 SI DIODE
D525 MTZJ5.6A-T2 Z DIODE
D526 MA4068N/Z1/-T2 Z DIODE
D621 1SS133-T2 DIODE
D622 1SS133-T2 DIODE
D623 1SS133-T2 DIODE
D681 MTZJ9.1C-T2 Z DIODE
D682 MTZJ9.1C-T2 Z DIODE
D683 MTZJ9.1C-T2 Z DIODE
D684 MTZJ9.1C-T2 Z DIODE
D685 MTZJ9.1C-T2 Z DIODE
D686 MTZJ9.1C-T2 Z DIODE
D687 MTZJ9.1C-T2 Z DIODE
Ref No. Part No. Part Name Description Local
D688 MTZJ9.1C-T2 Z DIODE
D705 1SS133-T2 DIODE
D751 LG22440 LED POWER/ON TIMER
D801 MTZJ9.1C-T2 Z DIODE
D802 MTZJ9.1C-T2 Z DIODE
D803 MTZJ9.1C-T2 Z DIODE
D804 MTZJ9.1C-T2 Z DIODE
D807 MTZJ9.1C-T2 Z DIODE
D831 MTZJ9.1C-T2 Z DIODE
D832 MTZJ9.1C-T2 Z DIODE
D833 MTZJ9.1C-T2 Z DIODE
D834 MTZJ9.1C-T2 Z DIODE
D901 GSIB460-S1 DIODE BRIDGE
D902 RGP10J-04TS-T3 SI DIODE
D903 RGP10J-04TS-T3 SI DIODE
D904 RGP10J-04TS-T3 SI DIODE
D905 SARS01-T2 SI DIODE
D907 MA700A-T2 SB DIODE
D908 MTZJ15C-T2 Z DIODE
D921 RGP10J-04TS-T3 SI DIODE
D922 RGP10J-04TS-T3 SI DIODE
D923 RGP10J-04TS-T3 SI DIODE
D924 RGP10J-04TS-T3 SI DIODE
D925 1SS133-T2 DIODE
D926 RU3AM-LFC4 SI DIODE
D927 21DQ10N-T3 SB DIODE
D928 RU3YX-LFC4 SI DIODE
D929 MTZJ7.5A-T2 Z DIODE
D930 1SS133-T2 DIODE
D931 1SS133-T2 DIODE
D932 MTZJ33B-T2 Z DIODE
D933 1N4002G-T2 FR DIODE
C001 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C002 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C003 QETN1VM-476Z E CAPACITOR 47uF 35V M
C004 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C005 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C104 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C105 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C106 QETN1EM-476Z E CAPACITOR 47uF 25V M
C107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C113 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C114 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C116 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C119 NDC31HJ-681X C CAPACITOR 680pF 50V J
C120 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C124 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C161 QETN1HM-106Z E CAPACITOR 10uF 50V M
C162 QETN1HM-106Z E CAPACITOR 10uF 50V M
C163 NDC31HJ-470X C CAPACITOR 47pF 50V J
C164 NDC31HJ-470X C CAPACITOR 47pF 50V J
C165 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C166 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C167 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C202 QETN1HM-105Z E CAPACITOR 1uF 50V M
C203 NCB31HK-152X C CAPACITOR 1500pF 50V K
C211 QETN1EM-476Z E CAPACITOR 47uF 25V M
C221 QETN1HM-106Z E CAPACITOR 10uF 50V M
C222 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C223 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C233 NDC31HJ-680X C CAPACITOR 68pF 50V J
C237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C241 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C243 QETN1EM-476Z E CAPACITOR 47uF 25V M
C244 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C247 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C252 NDC31HJ-101X C CAPACITOR 100pF 50V J
C253 NDC31HJ-470X C CAPACITOR 47pF 50V J
C254 NDC31HJ-181X C CAPACITOR 180pF 50V J
C261 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C262 QETN1EM-476Z E CAPACITOR 47uF 25V M
C263 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C264 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C265 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C266 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C267 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C268 QETN1EM-476Z E CAPACITOR 47uF 25V M
C269 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C270 QETN1EM-476Z E CAPACITOR 47uF 25V M
C272 NCB31HK-103X C CAPACITOR 0.01uF 50V K
3-6(No.YA052)
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
C273 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C274 NDC31HJ-181X C CAPACITOR 180pF 50V J
C275 QETN1EM-476Z E CAPACITOR 47uF 25V M
C276 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C277 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C278 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C283 NDC31HJ-330X C CAPACITOR 33pF 50V J
C293 NDC31HJ-470X C CAPACITOR 47pF 50V J
C302 NDC31HJ-331X C CAPACITOR 330pF 50V J
C312 NDC31HJ-271X C CAPACITOR 270pF 50V J
C322 NDC31HJ-271X C CAPACITOR 270pF 50V J
C331 QETN1AM-227Z E CAPACITOR 220uF 10V M
C341 QETN1CM-107Z E CAPACITOR 100uF 16V M
C343 QCZ0121-102 C CAPACITOR 1000pF 3KV
C352 QETN1EM-476Z E CAPACITOR 47uF 25V M
C354 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C361 QETN1EM-476Z E CAPACITOR 47uF 25V M
C362 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C401 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C402 NCB31HK-102X C CAPACITOR 1000pF 50V K
C403 QENC1CM-336Z BP E CAPACITOR 33uF 16V M
C404 NCB31HK-102X C CAPACITOR 1000pF 50V K
C405 QETN1HM-106Z E CAPACITOR 10uF 50V M
C406 NCB31HK-102X C CAPACITOR 1000pF 50V K
C407 QETN1VM-107Z E CAPACITOR 100uF 35V M
C409 QFLC2AK-104Z M CAPACITOR 0.1uF 100V K
C410 QFLC2AK-104Z M CAPACITOR 0.1uF 100V K
C411 QETM1VM-228 E CAPACITOR 2200uF 35V M
C412 QETN1HM-105Z E CAPACITOR 1uF 50V M
C501 QETN1EM-476Z E CAPACITOR 47uF 25V M
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C503 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C504 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C505 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C506 QETN1EM-476Z E CAPACITOR 47uF 25V M
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C508 QCB32HK-151Z C CAPACITOR 150pF 500V K
C509 QCB32HK-331Z C CAPACITOR 330pF 500V K
C510 QETN2EM-225Z E CAPACITOR 2.2uF 250V M
C521 QCZ0325-821 C CAPACITOR 820pF 2kV K
C522 QFZ0198-562 MPP CAPACITOR 5600pF 1.5KV
C523 QFZ0197-404 MPP CAPACITOR 0.4uF 250V J
C524 QCB32HK-561Z C CAPACITOR 560pF 500V K
C525 QEZ0203-107 E CAPACITOR 100uF 160V M
C526 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C527 QETN2EM-106Z E CAPACITOR 10uF 250V M
C528 QETN1VM-108Z E CAPACITOR 1000uF 35V M
C529 QETN1VM-476Z E CAPACITOR 47uF 35V M
C530 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C621 QETN1HM-106Z E CAPACITOR 10uF 50V M
C622 QETN1HM-106Z E CAPACITOR 10uF 50V M
C627 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C628 QETN1HM-226Z E CAPACITOR 22uF 50V M
C629 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C630 QETN1EM-227Z E CAPACITOR 220uF 25V M
C632 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C633 QETN1EM-227Z E CAPACITOR 220uF 25V M
C634 QETN1HM-106Z E CAPACITOR 10uF 50V M
C636 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C637 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C638 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C641 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C642 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C643 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C644 NCB31HK-562X C CAPACITOR 5600pF 50V K
C645 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C646 QETN1HM-105Z E CAPACITOR 1uF 50V M
C647 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C648 QETN1HM-106Z E CAPACITOR 10uF 50V M
C649 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C650 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C651 QETN1CM-107Z E CAPACITOR 100uF 16V M
C652 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C653 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C654 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C655 NCB31HK-272X C CAPACITOR 2700pF 50V K
C656 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C657 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C658 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C659 QETN1HM-106Z E CAPACITOR 10uF 50V M
C660 QETN1HM-105Z E CAPACITOR 1uF 50V M
C661 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C662 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C663 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C664 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C665 QETN1CM-227Z E CAPACITOR 220uF 16V M
C666 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C667 NCB31HK-472X C CAPACITOR 4700pF 50V K
C668 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C669 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C670 NCB31HK-472X C CAPACITOR 4700pF 50V K
C671 NDC31HJ-101X C CAPACITOR 100pF 50V J
C672 NDC31HJ-101X C CAPACITOR 100pF 50V J
C681 QETN1HM-106Z E CAPACITOR 10uF 50V M
C682 QETN1HM-106Z E CAPACITOR 10uF 50V M
C683 QETN1HM-106Z E CAPACITOR 10uF 50V M
C684 QETN1HM-106Z E CAPACITOR 10uF 50V M
C685 QETN1HM-106Z E CAPACITOR 10uF 50V M
C686 QETN1HM-106Z E CAPACITOR 10uF 50V M
C687 QETN1HM-106Z E CAPACITOR 10uF 50V M
C688 QETN1HM-106Z E CAPACITOR 10uF 50V M
C689 QETN1HM-106Z E CAPACITOR 10uF 50V M
C701 NCB31HK-102X C CAPACITOR 1000pF 50V K
C702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C703 QETN1HM-106Z E CAPACITOR 10uF 50V M
C704 QETN1EM-476Z E CAPACITOR 47uF 25V M
C705 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C708 NDC31HJ-220X C CAPACITOR 22pF 50V J
C709 NDC31HJ-220X C CAPACITOR 22pF 50V J
C711 QETN1EM-476Z E CAPACITOR 47uF 25V M
C712 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C713 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C751 QETN1EM-476Z E CAPACITOR 47uF 25V M
C801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C802 QETN1HM-106Z E CAPACITOR 10uF 50V M
C803 QETN1HM-105Z E CAPACITOR 1uF 50V M
C804 QETN1HM-106Z E CAPACITOR 10uF 50V M
C807 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C815 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C831 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C832 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C833 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C834 QETN1HM-106Z E CAPACITOR 10uF 50V M
C851 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C852 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C853 QETN1HM-106Z E CAPACITOR 10uF 50V M
C854 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C855 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C856 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C857 QETN1HM-106Z E CAPACITOR 10uF 50V M
C858 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C859 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C860 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C861 QETN1EM-476Z E CAPACITOR 47uF 25V M
C862 QETN1HM-106Z E CAPACITOR 10uF 50V M
C901 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
C902 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
C903 QEZ0376-477 E CAPACITOR 470uF 200V M
C904 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C905 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C907 QETN1HM-476Z E CAPACITOR 47uF 50V M
C908 QCZ0340-222 C CAPACITOR 2200pF 2kV K
C909 NCB31HK-122X C CAPACITOR 1200pF 50V K
C910 NDC31HJ-471X C CAPACITOR 470pF 50V J
C911 QFP32GJ-103Z PP CAPACITOR 0.01uF 400V J
C921 QETN1EM-477Z E CAPACITOR 470uF 25V M
C923 QEZ0203-107 E CAPACITOR 100uF 160V M
C924 QETN2CM-476Z E CAPACITOR 47uF 160V M
C925 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C926 QETN1CM-107Z E CAPACITOR 100uF 16V M
C927 QETN1EM-477Z E CAPACITOR 470uF 25V M
C929 QCZ0340-102 C CAPACITOR 1000pF 2kV K
C930 QCB32HK-102Z C CAPACITOR 1000pF 500V K
C931 QCB32HK-102Z C CAPACITOR 1000pF 500V K
C932 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C933 QETN1VM-476Z E CAPACITOR 47uF 35V M
C935 QETN1CM-476Z E CAPACITOR 47uF 16V M
C940 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C941 QETN1CM-107Z E CAPACITOR 100uF 16V M
C942 QETN1CM-107Z E CAPACITOR 100uF 16V M
C943 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C944 QETN1CM-107Z E CAPACITOR 100uF 16V M
C945 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C991 QCZ9074-103 C CAPACITOR 0.01uF AC250V M
C992 QCZ9074-103 C CAPACITOR 0.01uF AC250V M
R003 NRSA63J-221X MG RESISTOR 220
R004 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R005 NRSA63J-0R0X MG RESISTOR 0
R006 NRSA63J-223X MG RESISTOR 22k
R008 NRSA63J-820X MG RESISTOR 82Ω 1/16W J
R101 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R102 NRSA63J-182X MG RESISTOR 1.8k
R103 QRE121J-101Y C RESISTOR 100
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W J
(No.YA052)3-7
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
R104 NRSA63J-180X MG RESISTOR 18Ω 1/16W J
R105 NRSA63J-270X MG RESISTOR 27Ω 1/16W J
R111 NRSA63J-394X MG RESISTOR 390kΩ 1/16W J
R112 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J
R113 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R115 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R116 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R117 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R121 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R122 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R131 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R132 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R133 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R134 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R135 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R161 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R163 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R164 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R165 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R166 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R167 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R168 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R169 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R171 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R201 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R212 NRSA63J-272X MG RESISTOR 2.7k
R215 NRSA63J-562X MG RESISTOR 5.6k
R216 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R217 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R227 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R231 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R232 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R233 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R234 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R235 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R251 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R252 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R253 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R254 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R255 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R256 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R257 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R261 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R262 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R263 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R264 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R282 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R283 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R285 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R286 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R287 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R288 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R292 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R293 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R295 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R296 NRSA63J-102X MG RESISTOR 1k
R297 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R298 NRSA63J-0R0X MG RESISTOR 0
R301 NRSA63J-151X MG RESISTOR 150
R302 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R303 QRZ0111-152 C RESISTOR 1.5kΩ 1/2W K
R304 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R305 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R306 NRSA63J-101X MG RESISTOR 100
R311 NRSA63J-151X MG RESISTOR 150
R312 QRL029J-123 OMF RESISTOR 12k
R313 QRZ0111-152 C RESISTOR 1.5k
R314 NRSA63J-332X MG RESISTOR 3.3k
R315 NRSA63J-271X MG RESISTOR 270
R316 NRSA63J-101X MG RESISTOR 100
R321 NRSA63J-151X MG RESISTOR 150
R322 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R323 QRZ0111-152 C RESISTOR 1.5k
R324 NRSA63J-332X MG RESISTOR 3.3k
R325 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R326 NRSA63J-101X MG RESISTOR 100
R331 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R334 NRSA63J-392X MG RESISTOR 3.9k
R335 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R354 NRSA63J-331X MG RESISTOR 330
R356 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R359 NRSA63J-103X MG RESISTOR 10k
R360 NRSA63J-0R0X MG RESISTOR 0
R364 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R365 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R366 NRSA63J-101X MG RESISTOR 100
R401 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
2W J
Ω
1/2W K
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W K
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R402 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R403 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R405 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R406 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R407 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R408 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R409 QRX01GJ-1R0 MF RESISTOR 1Ω 1W J
R411 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R412 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R414 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R416 QRE121J-102Y C RESISTOR 1kΩ 1/2W J
R501 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R502 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R504 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R505 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R506 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R507 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R508 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R509 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R510 QRE121J-103Y C RESISTOR 10kΩ 1/2W J
R511 QRL039J-272 OMF RESISTOR 2.7kΩ 3W J
R512 QRL039J-332 OMF RESISTOR 3.3kΩ 3W J
R521 QRE121J-220Y C RESISTOR 22Ω 1/2W J
R522 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R523 QRL039J-152 OMF RESISTOR 1.5kΩ 3W J
R524 QRE121J-334Y C RESISTOR 330k
R525 QRE121J-184Y C RESISTOR 180k
R526 QRK129J-150 UNF C RESISTOR 15Ω 1/2W J
R528 QRE121J-472Y C RESISTOR 4.7kΩ 1/2W J
R529 QRK126J-4R7X UNF C RESISTOR 4.7Ω 1/2W J
R530 QRX029J-1R5 MF RESISTOR 1.5Ω 2W J
R531 NRZ0032-7151X CHIP MF RESISTOR 7.15k
R533 NRZ0032-3241X CHIP MF RESISTOR 3.24k
R541 QRE121J-683Y C RESISTOR 68kΩ 1/2W J
R621 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R622 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R624 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R625 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R627 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R628 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R630 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R631 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R632 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R638 QRT039J-1R2 MF RESISTOR 1.2Ω 3W J
R639 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R640 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R641 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R642 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R643 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R644 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R645 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R646 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R647 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R648 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R649 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R650 NRSA63J-332X MG RESISTOR 3.3k
R651 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R652 NRSA63J-332X MG RESISTOR 3.3k
R653 NRSA63J-392X MG RESISTOR 3.9k
R654 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R655 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R656 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R657 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R658 NRSA63J-101X MG RESISTOR 100
R659 NRSA63J-101X MG RESISTOR 100
R660 NRSA63J-105X MG RESISTOR 1M
R681 NRSA63J-221X MG RESISTOR 220
R682 NRSA63J-221X MG RESISTOR 220
R683 NRSA63J-223X MG RESISTOR 22k
R684 NRSA63J-223X MG RESISTOR 22k
R685 NRSA63J-223X MG RESISTOR 22k
R686 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R687 NRSA63J-221X MG RESISTOR 220
R688 NRSA63J-221X MG RESISTOR 220
R691 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R692 NRSA63J-823X MG RESISTOR 82k
R701 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R702 NRSA63J-102X MG RESISTOR 1k
R703 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R704 NRSA63J-472X MG RESISTOR 4.7k
R705 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R706 NRSA63J-472X MG RESISTOR 4.7k
R707 NRSA63J-103X MG RESISTOR 10k
R708 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R709 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R714 NRSA63J-823X MG RESISTOR 82k
R715 NRSA63J-101X MG RESISTOR 100
Ω
1/2W J
Ω
1/2W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
3-8(No.YA052)
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
R718 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R720 QRJ149J-1R0 UNF C RESISTOR 1Ω 1/4W J
R721 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R729 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R731 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R732 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R733 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R734 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R739 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R740 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R751 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R752 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R753 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R754 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R755 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R756 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R757 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R758 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R764 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R765 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R766 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R767 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R768 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R769 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R770 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R771 NRSA63J-153X MG RESISTOR 15k
R772 NRSA63J-103X MG RESISTOR 10k
R773 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R774 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R775 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R776 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R777 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R778 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R801 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R802 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R803 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R804 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R805 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R821 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R831 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R832 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R833 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R834 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R835 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R836 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R839 NRSA63J-225X MG RESISTOR 2.2MΩ 1/16W J
R851 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R852 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R853 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R854 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R855 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R856 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R857 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R858 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R859 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R860 NRSA63J-101X MG RESISTOR 100
R861 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R862 NRSA63J-104X MG RESISTOR 100k
R863 NRSA63J-473X MG RESISTOR 47k
R901 QRF074K-R47 UNF WW RESISTOR 0.47Ω 7W K
R902 QRE121J-473Y C RESISTOR 47kΩ 1/2W J
R903 QRE121J-473Y C RESISTOR 47kΩ 1/2W J
R904 QRT029J-R22 MF RESISTOR 0.22Ω 2W J
R905 QRT029J-R22 MF RESISTOR 0.22
R906 QRE121J-2R2Y C RESISTOR 2.2
R907 QRE121J-472Y C RESISTOR 4.7k
R908 QRK126J-681X UNF C RESISTOR 680
R910 QRE121J-684Y C RESISTOR 680k
R911 QRG01GJ-470 OMF RESISTOR 47
R922 NRSA63J-102X MG RESISTOR 1k
R923 NRSA63J-473X MG RESISTOR 47k
R924 QRX01GJ-1R0 MF RESISTOR 1Ω 1W J
R925 QRX01GJ-1R0 MF RESISTOR 1
R926 QRT029J-1R2 MF RESISTOR 1.2
R927 QRT029J-1R2 MF RESISTOR 1.2Ω 2W J
R928 QRE121J-272Y C RESISTOR 2.7k
R929 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R930 QRE121J-473Y C RESISTOR 47k
R932 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R933 NRSA63J-123X MG RESISTOR 12k
R934 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R935 NRSA63J-333X MG RESISTOR 33k
R936 QRE121J-472Y C RESISTOR 4.7k
R938 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R939 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R941 QRG029J-180 OMF RESISTOR 18
R942 QRE121J-5R6Y C RESISTOR 5.6
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1W J
Ω
1/16W J
Ω
1/16W J
Ω
1W J
Ω
2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W J
Ω
2W J
Ω
1/2W J
R943 QRE121J-820Y C RESISTOR 82Ω 1/2W J
R991 QRZ9041-275 C RESISTOR 2.7MΩ 1/2W K
L101 QQLZ014-R39 COIL 0.39uH 100mA L
L131 QQL29BJ-220Z P COIL 0.65Ω 22uH J
L161 QQL29BJ-220Z P COIL 0.65Ω 22uH J
L232 QQL29BJ-560Z PEAKING COIL 56uH J
L251 QQL29BJ-4R7Z PEAKING COIL 4.7uH J
L281 QQL29BJ-150Z PEAKING COIL 15uH J
L291 QQL29BJ-150Z PEAKING COIL 15uH J
L341 QQL29BJ-390Z PEAKING COIL 39uH J
L521 QQR1005-004 LIN COIL
L522 QQLZ026-410 COIL 41uH ±7%
L921 QQL26AK-470Z CHOKE COIL 47uH K
L922 QQL26AK-470Z CHOKE COIL 47uH K
T111 QQR0907-001 I F T
T501 QQR1414-001 DRIVE TRANSF
T901 QQT0355-001 POWER TRANSF
T921 QQS0204-001 SW TRANSF
CF001 QAX0349-001 C TRAP 47.25MHz
CF131 QAX0639-001Z C TRAP 4.500MHz
CF161 QAX0642-001Z C FILTER 4.500MHz
CN00C QGA2501F1-06 CONNECTOR W-B (1-6)
CN00S QGA2501C5-04Z CONNECTOR W-B (1-4)
CN00T CHGC05-440 CONNECTOR ASSY
CN00U CHGC04-400 CONNECTOR ASSY
CN0E1 CHGT0015-0B CONNECTOR ASSY
CN0HV QGZ5004C1-06 CONNECTOR (1-6)
CNDEG QGZ5004C1-02 CONNECTOR (1-2)
F901 QMF51N1-5R0-J5 FUSE 5A AC125V
H002 LC30381-001A HEAT SINK
HS004 LC31696-001A HEAT SINK
HS009 LC31678-001A HEAT SINK/AL-F/
HS602 LC31696-002A HEAT SINK
J001 QNZ0454-001 AV JACK S/V/L/R IN
J002 QNN0348-001 PIN JACK L/R OUT
J003 QNN0349-002 PIN JACK V/L/R IN
J004 QNN0348-001 PIN JACK L/R IN
J005 CEMN065-001 PIN JACK V IN
J006 CEMN065-002 PIN JACK L IN
J007 CEMN072-003 PIN JACK R IN
J008 QNS0155-001 3.5 JACK HEADPHONE
K001 QQR0582-001Z FERRITE BEADS
K101 QQR0582-001Z FERRITE BEADS
K251 QQR0582-001Z FERRITE BEADS
K252 QQR0582-001Z FERRITE BEADS
K253 QQR0582-001Z FERRITE BEADS
K254 QQR0582-001Z FERRITE BEADS
K255 QQR0621-002Z FERRITE BEADS
K401 QQR0582-001Z FERRITE BEADS
K701 QQR0582-001Z FERRITE BEADS
K702 QQR0582-001Z FERRITE BEADS
K901 QQR0582-001Z FERRITE BEADS
K902 QQR0582-001Z FERRITE BEADS
K903 QQR0582-001Z FERRITE BEADS
K904 QQR0582-001Z FERRITE BEADS
K921 QQR0582-001Z FERRITE BEADS
K922 QQR0582-001Z FERRITE BEADS
K923 QQR0582-001Z FERRITE BEADS
LC687 QQR1459-001 EMI F. COIL
LC688 QQR1459-001 EMI F. COIL
LC801 QQR1459-001 EMI F. COIL
LF901 QQR0527-003 LINE FILTER
RY901 QSK0085-001 RELAY
S401 QSL4A13-C02 LEVER SWITCH V.CENTER
S751 QSW0847-001 TACT SWITCH POWER
S752 QSW0619-003Z TACT SWITCH VOL+
S753 QSW0619-003Z TACT SWITCH VOLS754 QSW0619-003Z TACT SWITCH CH+
S755 QSW0619-003Z TACT SWITCH CHS756 QSW0619-003Z TACT SWITCH MENU
SF101 QAX0723-001 SAW FILTER
SK351 QNZ0536-001 CRT SOCKET
TH901 QAD0129-3R0 POSISTOR 3
TU001 QAU0353-001 TUNER
VA901 ERZV10V621CS ZNR
X701 QAX0767-001Z CRYSTAL 8MHz
Ω
(No.YA052)3-9
PRINTED WIRING BOARD PARTS LIST [AV-N21F45/S]
MAIN P.W. BOARD ASS'Y (SFJ-1012A-M2)
Ref No. Part No. Part Name Description Local
IC101 M52342FP-X IC
IC201 TM8812CSDNG5DB9 IC(MCU)
IC251 TC90A49AP IC
IC421 AN5522 IC
IC602 TFA9842J/N1 IC
IC641 CXA2205Q-X IC
IC702 AT24C08-20F475 IC (SERVICE)
IC703 S-80840CNY-T IC
IC704 AN78L05-T IC
IC751 GP1UM281QK IR DETECT UNIT 38kHz
IC851 TA1218AN IC
IC901 STR-G5624A/F8 IC
IC921 L7809CP IC
IC922 L7805CP IC
Q001 UN2212-X TRANSISTOR
Q101 2SC5083/L-P/-T TRANSISTOR
Q131 2SA1530A/QR/-X TRANSISTOR
Q161 2SC3928A/QR/-X TRANSISTOR
Q211 2SC3928A/QR/-X TRANSISTOR
Q232 2SC3928A/QR/-X TRANSISTOR
Q233 2SC3928A/QR/-X TRANSISTOR
Q251 2SC3928A/QR/-X TRANSISTOR
Q252 2SC3928A/QR/-X TRANSISTOR
Q281 2SA1530A/QR/-X TRANSISTOR
Q282 2SC3928A/QR/-X TRANSISTOR
Q283 2SA1530A/QR/-X TRANSISTOR
Q291 2SA1530A/QR/-X TRANSISTOR
Q292 2SC3928A/QR/-X TRANSISTOR
Q293 2SA1530A/QR/-X TRANSISTOR
Q301 2SC4075/DE/YA11 POW TRANSISTOR
Q311 2SC4075/DE/YA11 POW TRANSISTOR
Q321 2SC4075/DE/YA11 POW TRANSISTOR
Q331 2SA1530A/QR/-X TRANSISTOR
Q352 2SD601A/QR/-X TRANSISTOR
Q501 2SC4212/Z1/ TRANSISTOR
Q521 2SD2634-YD TRANSISTOR H.OUT
Q623 2SA1530A/QR/-X TRANSISTOR
Q625 2SC3928A/QR/-X TRANSISTOR
Q681 2SC3928A/QR/-X TRANSISTOR
Q682 2SC3928A/QR/-X TRANSISTOR
Q683 2SC3928A/QR/-X TRANSISTOR
Q684 2SC3928A/QR/-X TRANSISTOR
Q701 2SA1530A/QR/-X TRANSISTOR
Q751 UN2112-X TRANSISTOR
Q851 2SA1530A/QR/-X TRANSISTOR
Q921 2SD1383K/AB/-X SI TRANSISTOR
Q922 2SC2785/JH/-T SI TRANSISTOR
Q923 2SA1530A/QR/-X TRANSISTOR
Q924 2SA1208/ST/Z1-T TRANSISTOR
D331 1SS133-T2 DIODE
D332 1SS133-T2 DIODE
D333 1SS133-T2 DIODE
D334 1SS133-T2 DIODE
D352 MTZJ9.1C-T2 Z DIODE
D353 1SS133-T2 DIODE
D365 1SS133-T2 DIODE
D366 1SS133-T2 DIODE
D367 1SS133-T2 DIODE
D368 MTZJ5.1B-T2 Z DIODE
D369 MTZJ5.1B-T2 Z DIODE
D370 MTZJ5.1B-T2 Z DIODE
D401 1SR35-400A-T2 SI DIODE
D402 MTZJ75-T2 Z DIODE
D501 MTZJ3.3A-T2 Z DIODE
D521 1SR35-400A-T2 SI DIODE
D522 RH1S-T3 SI DIODE
D523 1SR35-400A-T2 SI DIODE
D524 RGP10J-04TS-T3 SI DIODE
D525 MTZJ5.6A-T2 Z DIODE
D526 MA4068N/Z1/-T2 Z DIODE
D621 1SS133-T2 DIODE
D622 1SS133-T2 DIODE
D623 1SS133-T2 DIODE
D681 MTZJ9.1C-T2 Z DIODE
D682 MTZJ9.1C-T2 Z DIODE
D683 MTZJ9.1C-T2 Z DIODE
D684 MTZJ9.1C-T2 Z DIODE
D685 MTZJ9.1C-T2 Z DIODE
D686 MTZJ9.1C-T2 Z DIODE
Ref No. Part No. Part Name Description Local
D687 MTZJ9.1C-T2 Z DIODE
D688 MTZJ9.1C-T2 Z DIODE
D705 1SS133-T2 DIODE
D751 LG22440 LED POWER/ON TIMER
D801 MTZJ9.1C-T2 Z DIODE
D802 MTZJ9.1C-T2 Z DIODE
D803 MTZJ9.1C-T2 Z DIODE
D804 MTZJ9.1C-T2 Z DIODE
D807 MTZJ9.1C-T2 Z DIODE
D831 MTZJ9.1C-T2 Z DIODE
D832 MTZJ9.1C-T2 Z DIODE
D833 MTZJ9.1C-T2 Z DIODE
D834 MTZJ9.1C-T2 Z DIODE
D901 GSIB460-S1 DIODE BRIDGE
D902 RGP10J-04TS-T3 SI DIODE
D903 RGP10J-04TS-T3 SI DIODE
D904 RGP10J-04TS-T3 SI DIODE
D905 SARS01-T2 SI DIODE
D907 MA700A-T2 SB DIODE
D908 MTZJ15C-T2 Z DIODE
D921 RGP10J-04TS-T3 SI DIODE
D922 RGP10J-04TS-T3 SI DIODE
D923 RGP10J-04TS-T3 SI DIODE
D924 RGP10J-04TS-T3 SI DIODE
D925 1SS133-T2 DIODE
D926 RU3AM-LFC4 SI DIODE
D927 21DQ10N-T3 SB DIODE
D928 RU3YX-LFC4 SI DIODE
D929 MTZJ7.5A-T2 Z DIODE
D930 1SS133-T2 DIODE
D931 1SS133-T2 DIODE
D932 MTZJ33B-T2 Z DIODE
D933 1N4002G-T2 FR DIODE
C001 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C002 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C003 QETN1VM-476Z E CAPACITOR 47uF 35V M
C004 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C005 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C104 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C105 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C106 QETN1EM-476Z E CAPACITOR 47uF 25V M
C107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C113 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C114 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C116 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C119 NDC31HJ-681X C CAPACITOR 680pF 50V J
C120 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C124 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C161 QETN1HM-106Z E CAPACITOR 10uF 50V M
C162 QETN1HM-106Z E CAPACITOR 10uF 50V M
C163 NDC31HJ-470X C CAPACITOR 47pF 50V J
C164 NDC31HJ-470X C CAPACITOR 47pF 50V J
C165 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C166 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C167 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C202 QETN1HM-105Z E CAPACITOR 1uF 50V M
C203 NCB31HK-152X C CAPACITOR 1500pF 50V K
C211 QETN1EM-476Z E CAPACITOR 47uF 25V M
C221 QETN1HM-106Z E CAPACITOR 10uF 50V M
C222 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C223 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C233 NDC31HJ-680X C CAPACITOR 68pF 50V J
C237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C241 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C243 QETN1EM-476Z E CAPACITOR 47uF 25V M
C244 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C247 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C252 NDC31HJ-101X C CAPACITOR 100pF 50V J
C253 NDC31HJ-470X C CAPACITOR 47pF 50V J
C254 NDC31HJ-181X C CAPACITOR 180pF 50V J
C261 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C262 QETN1EM-476Z E CAPACITOR 47uF 25V M
C263 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C264 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C265 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C266 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C267 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C268 QETN1EM-476Z E CAPACITOR 47uF 25V M
C269 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C270 QETN1EM-476Z E CAPACITOR 47uF 25V M
3-10(No.YA052)
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
C272 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C273 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C274 NDC31HJ-181X C CAPACITOR 180pF 50V J
C275 QETN1EM-476Z E CAPACITOR 47uF 25V M
C276 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C277 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C278 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C283 NDC31HJ-330X C CAPACITOR 33pF 50V J
C293 NDC31HJ-470X C CAPACITOR 47pF 50V J
C302 NDC31HJ-331X C CAPACITOR 330pF 50V J
C312 NDC31HJ-271X C CAPACITOR 270pF 50V J
C322 NDC31HJ-271X C CAPACITOR 270pF 50V J
C331 QETN1AM-227Z E CAPACITOR 220uF 10V M
C341 QETN1CM-107Z E CAPACITOR 100uF 16V M
C343 QCZ0121-102 C CAPACITOR 1000pF 3KV
C352 QETN1EM-476Z E CAPACITOR 47uF 25V M
C354 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C361 QETN1EM-476Z E CAPACITOR 47uF 25V M
C362 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C401 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C402 NCB31HK-102X C CAPACITOR 1000pF 50V K
C403 QENC1CM-336Z BP E CAPACITOR 33uF 16V M
C404 NCB31HK-102X C CAPACITOR 1000pF 50V K
C405 QETN1HM-106Z E CAPACITOR 10uF 50V M
C406 NCB31HK-102X C CAPACITOR 1000pF 50V K
C407 QETN1VM-107Z E CAPACITOR 100uF 35V M
C409 QFLC2AK-104Z M CAPACITOR 0.1uF 100V K
C410 QFLC2AK-104Z M CAPACITOR 0.1uF 100V K
C411 QETM1VM-228 E CAPACITOR 2200uF 35V M
C412 QETN1HM-105Z E CAPACITOR 1uF 50V M
C501 QETN1EM-476Z E CAPACITOR 47uF 25V M
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C503 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C504 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C505 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C506 QETN1EM-476Z E CAPACITOR 47uF 25V M
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C508 QCB32HK-151Z C CAPACITOR 150pF 500V K
C509 QCB32HK-331Z C CAPACITOR 330pF 500V K
C510 QETN2EM-225Z E CAPACITOR 2.2uF 250V M
C521 QCZ0325-821 C CAPACITOR 820pF 2kV K
C522 QFZ0198-562 MPP CAPACITOR 5600pF 1.5KV
C523 QFZ0197-404 MPP CAPACITOR 0.4uF 250V J
C524 QCB32HK-561Z C CAPACITOR 560pF 500V K
C525 QEZ0203-107 E CAPACITOR 100uF 160V M
C526 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C527 QETN2EM-106Z E CAPACITOR 10uF 250V M
C528 QETN1VM-108Z E CAPACITOR 1000uF 35V M
C529 QETN1VM-476Z E CAPACITOR 47uF 35V M
C530 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C621 QETN1HM-106Z E CAPACITOR 10uF 50V M
C622 QETN1HM-106Z E CAPACITOR 10uF 50V M
C627 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C628 QETN1HM-226Z E CAPACITOR 22uF 50V M
C629 NCF21CZ-105X C CAPACITOR 1uF 16V Z
C630 QETN1EM-227Z E CAPACITOR 220uF 25V M
C632 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C633 QETN1EM-227Z E CAPACITOR 220uF 25V M
C634 QETN1HM-106Z E CAPACITOR 10uF 50V M
C636 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C637 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C638 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C641 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C642 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C643 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C644 NCB31HK-562X C CAPACITOR 5600pF 50V K
C645 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C646 QETN1HM-105Z E CAPACITOR 1uF 50V M
C647 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C648 QETN1HM-106Z E CAPACITOR 10uF 50V M
C649 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C650 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C651 QETN1CM-107Z E CAPACITOR 100uF 16V M
C652 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C653 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C654 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C655 NCB31HK-272X C CAPACITOR 2700pF 50V K
C656 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C657 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C658 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C659 QETN1HM-106Z E CAPACITOR 10uF 50V M
C660 QETN1HM-105Z E CAPACITOR 1uF 50V M
C661 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C662 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C663 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C664 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C665 QETN1CM-227Z E CAPACITOR 220uF 16V M
C666 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C667 NCB31HK-472X C CAPACITOR 4700pF 50V K
C668 QENC1HM-475Z BP E CAPACITOR 4.7uF 50V M
C669 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C670 NCB31HK-472X C CAPACITOR 4700pF 50V K
C671 NDC31HJ-101X C CAPACITOR 100pF 50V J
C672 NDC31HJ-101X C CAPACITOR 100pF 50V J
C681 QETN1HM-106Z E CAPACITOR 10uF 50V M
C682 QETN1HM-106Z E CAPACITOR 10uF 50V M
C683 QETN1HM-106Z E CAPACITOR 10uF 50V M
C684 QETN1HM-106Z E CAPACITOR 10uF 50V M
C685 QETN1HM-106Z E CAPACITOR 10uF 50V M
C686 QETN1HM-106Z E CAPACITOR 10uF 50V M
C687 QETN1HM-106Z E CAPACITOR 10uF 50V M
C688 QETN1HM-106Z E CAPACITOR 10uF 50V M
C689 QETN1HM-106Z E CAPACITOR 10uF 50V M
C701 NCB31HK-102X C CAPACITOR 1000pF 50V K
C702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C703 QETN1HM-106Z E CAPACITOR 10uF 50V M
C704 QETN1EM-476Z E CAPACITOR 47uF 25V M
C705 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C708 NDC31HJ-220X C CAPACITOR 22pF 50V J
C709 NDC31HJ-220X C CAPACITOR 22pF 50V J
C711 QETN1EM-476Z E CAPACITOR 47uF 25V M
C712 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C713 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C751 QETN1EM-476Z E CAPACITOR 47uF 25V M
C801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C802 QETN1HM-106Z E CAPACITOR 10uF 50V M
C803 QETN1HM-105Z E CAPACITOR 1uF 50V M
C804 QETN1HM-106Z E CAPACITOR 10uF 50V M
C807 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C815 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C831 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C832 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C833 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C834 QETN1HM-106Z E CAPACITOR 10uF 50V M
C851 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C852 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C853 QETN1HM-106Z E CAPACITOR 10uF 50V M
C854 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C855 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C856 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C857 QETN1HM-106Z E CAPACITOR 10uF 50V M
C858 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C859 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C860 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C861 QETN1EM-476Z E CAPACITOR 47uF 25V M
C862 QETN1HM-106Z E CAPACITOR 10uF 50V M
C901 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
C902 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
C903 QEZ0376-477 E CAPACITOR 470uF 200V M
C904 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C905 QCZ9054-102 C CAPACITOR 1000pF AC250V Z
C907 QETN1HM-476Z E CAPACITOR 47uF 50V M
C908 QCZ0340-222 C CAPACITOR 2200pF 2kV K
C909 NCB31HK-122X C CAPACITOR 1200pF 50V K
C910 NDC31HJ-471X C CAPACITOR 470pF 50V J
C911 QFP32GJ-103Z PP CAPACITOR 0.01uF 400V J
C921 QETN1EM-477Z E CAPACITOR 470uF 25V M
C923 QEZ0203-107 E CAPACITOR 100uF 160V M
C924 QETN2CM-476Z E CAPACITOR 47uF 160V M
C925 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C926 QETN1CM-107Z E CAPACITOR 100uF 16V M
C927 QETN1EM-477Z E CAPACITOR 470uF 25V M
C929 QCZ0340-102 C CAPACITOR 1000pF 2kV K
C930 QCB32HK-102Z C CAPACITOR 1000pF 500V K
C931 QCB32HK-102Z C CAPACITOR 1000pF 500V K
C932 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C933 QETN1VM-476Z E CAPACITOR 47uF 35V M
C935 QETN1CM-476Z E CAPACITOR 47uF 16V M
C940 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C941 QETN1CM-107Z E CAPACITOR 100uF 16V M
C942 QETN1CM-107Z E CAPACITOR 100uF 16V M
C943 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C944 QETN1CM-107Z E CAPACITOR 100uF 16V M
C945 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C991 QCZ9073-332 C CAPACITOR 3300pF
R003 NRSA63J-221X MG RESISTOR 220
R004 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R005 NRSA63J-0R0X MG RESISTOR 0
R006 NRSA63J-223X MG RESISTOR 22k
R008 NRSA63J-820X MG RESISTOR 82Ω 1/16W J
R101 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R102 NRSA63J-182X MG RESISTOR 1.8k
R103 QRE121J-101Y C RESISTOR 100
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W J
(No.YA052)3-11
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
R104 NRSA63J-180X MG RESISTOR 18Ω 1/16W J
R105 NRSA63J-270X MG RESISTOR 27Ω 1/16W J
R111 NRSA63J-394X MG RESISTOR 390kΩ 1/16W J
R112 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J
R113 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R115 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R116 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R117 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R121 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R122 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R131 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R132 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R133 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R134 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R135 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R161 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R163 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R164 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R165 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R166 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R167 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R168 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R169 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R171 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R201 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R212 NRSA63J-272X MG RESISTOR 2.7k
R215 NRSA63J-562X MG RESISTOR 5.6k
R216 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R217 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R227 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R231 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R232 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R233 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R234 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R235 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R251 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R252 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R253 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R254 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R255 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R256 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R257 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R261 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R262 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R263 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R264 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R282 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R283 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R285 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R286 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R287 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R288 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R292 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R293 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R295 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R296 NRSA63J-102X MG RESISTOR 1k
R297 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R298 NRSA63J-0R0X MG RESISTOR 0
R301 NRSA63J-151X MG RESISTOR 150
R302 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R303 QRZ0111-152 C RESISTOR 1.5kΩ 1/2W K
R304 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R305 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R306 NRSA63J-101X MG RESISTOR 100
R311 NRSA63J-151X MG RESISTOR 150
R312 QRL029J-123 OMF RESISTOR 12k
R313 QRZ0111-152 C RESISTOR 1.5k
R314 NRSA63J-332X MG RESISTOR 3.3k
R315 NRSA63J-271X MG RESISTOR 270
R316 NRSA63J-101X MG RESISTOR 100
R321 NRSA63J-151X MG RESISTOR 150
R322 QRL029J-123 OMF RESISTOR 12kΩ 2W J
R323 QRZ0111-152 C RESISTOR 1.5k
R324 NRSA63J-332X MG RESISTOR 3.3k
R325 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R326 NRSA63J-101X MG RESISTOR 100
R331 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R334 NRSA63J-392X MG RESISTOR 3.9k
R335 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R354 NRSA63J-331X MG RESISTOR 330
R356 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R359 NRSA63J-103X MG RESISTOR 10k
R360 NRSA63J-0R0X MG RESISTOR 0
R364 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R365 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R366 NRSA63J-101X MG RESISTOR 100
R401 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
2W J
Ω
1/2W K
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W K
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R402 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R403 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R405 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R406 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R407 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R408 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R409 QRX01GJ-1R0 MF RESISTOR 1Ω 1W J
R411 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R412 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R414 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R416 QRE121J-102Y C RESISTOR 1kΩ 1/2W J
R501 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R502 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R504 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R505 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R506 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R507 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R508 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R509 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R510 QRE121J-103Y C RESISTOR 10kΩ 1/2W J
R511 QRL039J-272 OMF RESISTOR 2.7kΩ 3W J
R512 QRL039J-332 OMF RESISTOR 3.3kΩ 3W J
R521 QRE121J-220Y C RESISTOR 22Ω 1/2W J
R522 QRE121J-681Y C RESISTOR 680Ω 1/2W J
R523 QRL039J-152 OMF RESISTOR 1.5kΩ 3W J
R524 QRE121J-334Y C RESISTOR 330k
R525 QRE121J-184Y C RESISTOR 180k
R526 QRK129J-150 UNF C RESISTOR 15Ω 1/2W J
R528 QRE121J-472Y C RESISTOR 4.7kΩ 1/2W J
R529 QRK126J-4R7X UNF C RESISTOR 4.7Ω 1/2W J
R530 QRX029J-1R5 MF RESISTOR 1.5Ω 2W J
R531 NRZ0032-7151X CHIP MF RESISTOR 7.15k
R533 NRZ0032-3241X CHIP MF RESISTOR 3.24k
R541 QRE121J-683Y C RESISTOR 68kΩ 1/2W J
R621 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R622 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R624 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R625 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R627 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R628 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R630 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R631 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R632 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R638 QRT039J-1R2 MF RESISTOR 1.2Ω 3W J
R639 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R640 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R641 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R642 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R643 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R644 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R645 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R646 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R647 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R648 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R649 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R650 NRSA63J-332X MG RESISTOR 3.3k
R651 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R652 NRSA63J-332X MG RESISTOR 3.3k
R653 NRSA63J-392X MG RESISTOR 3.9k
R654 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R655 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R656 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R657 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R658 NRSA63J-101X MG RESISTOR 100
R659 NRSA63J-101X MG RESISTOR 100
R660 NRSA63J-105X MG RESISTOR 1M
R681 NRSA63J-221X MG RESISTOR 220
R682 NRSA63J-221X MG RESISTOR 220
R683 NRSA63J-223X MG RESISTOR 22k
R684 NRSA63J-223X MG RESISTOR 22k
R685 NRSA63J-223X MG RESISTOR 22k
R686 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R687 NRSA63J-221X MG RESISTOR 220
R688 NRSA63J-221X MG RESISTOR 220
R691 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R692 NRSA63J-823X MG RESISTOR 82k
R701 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R702 NRSA63J-102X MG RESISTOR 1k
R703 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R704 NRSA63J-472X MG RESISTOR 4.7k
R705 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R706 NRSA63J-472X MG RESISTOR 4.7k
R707 NRSA63J-103X MG RESISTOR 10k
R708 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R709 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R714 NRSA63J-823X MG RESISTOR 82k
R715 NRSA63J-101X MG RESISTOR 100
Ω
1/2W J
Ω
1/2W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
3-12(No.YA052)
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
R718 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R720 QRJ149J-1R0 UNF C RESISTOR 1Ω 1/4W J
R721 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R729 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R731 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R732 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R733 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R734 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R739 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R740 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R751 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R752 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R753 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R754 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R755 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R756 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R757 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R758 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R764 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R765 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R766 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R767 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R768 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R769 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R770 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R771 NRSA63J-153X MG RESISTOR 15k
R772 NRSA63J-103X MG RESISTOR 10k
R773 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R774 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R775 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R776 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R777 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R778 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R801 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R802 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R803 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R804 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R805 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R821 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R831 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R832 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R833 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R834 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R835 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R836 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R839 NRSA63J-225X MG RESISTOR 2.2MΩ 1/16W J
R851 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R852 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R853 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R854 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R855 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R856 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R857 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R858 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R859 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R860 NRSA63J-101X MG RESISTOR 100
R861 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R862 NRSA63J-104X MG RESISTOR 100k
R863 NRSA63J-473X MG RESISTOR 47k
R901 QRF074K-R47 UNF WW RESISTOR 0.47Ω 7W K
R902 QRE121J-473Y C RESISTOR 47kΩ 1/2W J
R903 QRE121J-473Y C RESISTOR 47kΩ 1/2W J
R904 QRT029J-R22 MF RESISTOR 0.22Ω 2W J
R905 QRT029J-R22 MF RESISTOR 0.22
R906 QRE121J-2R2Y C RESISTOR 2.2
R907 QRE121J-472Y C RESISTOR 4.7k
R908 QRK126J-681X UNF C RESISTOR 680
R910 QRE121J-684Y C RESISTOR 680k
R911 QRG01GJ-470 OMF RESISTOR 47
R922 NRSA63J-102X MG RESISTOR 1k
R923 NRSA63J-473X MG RESISTOR 47k
R924 QRX01GJ-1R0 MF RESISTOR 1Ω 1W J
R925 QRX01GJ-1R0 MF RESISTOR 1
R926 QRT029J-1R2 MF RESISTOR 1.2
R927 QRT029J-1R2 MF RESISTOR 1.2Ω 2W J
R928 QRE121J-272Y C RESISTOR 2.7k
R929 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R930 QRE121J-473Y C RESISTOR 47k
R932 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R933 NRSA63J-123X MG RESISTOR 12k
R934 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R935 NRSA63J-333X MG RESISTOR 33k
R936 QRE121J-472Y C RESISTOR 4.7k
R938 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R939 QRE121J-223Y C RESISTOR 22kΩ 1/2W J
R941 QRG029J-180 OMF RESISTOR 18
R942 QRE121J-5R6Y C RESISTOR 5.6
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/2W J
Ω
1W J
Ω
1/16W J
Ω
1/16W J
Ω
1W J
Ω
2W J
Ω
1/2W J
Ω
1/2W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W J
Ω
2W J
Ω
1/2W J
R943 QRE121J-820Y C RESISTOR 82Ω 1/2W J
R991 QRZ9041-275 C RESISTOR 2.7MΩ 1/2W K
L101 QQLZ014-R39 COIL 0.39uH 100mA L
L131 QQL29BJ-220Z P COIL 0.65Ω 22uH J
L161 QQL29BJ-220Z P COIL 0.65Ω 22uH J
L232 QQL29BJ-560Z PEAKING COIL 56uH J
L251 QQL29BJ-4R7Z PEAKING COIL 4.7uH J
L281 QQL29BJ-150Z PEAKING COIL 15uH J
L291 QQL29BJ-150Z PEAKING COIL 15uH J
L341 QQL29BJ-390Z PEAKING COIL 39uH J
L521 QQR1005-004 LIN COIL
L522 QQLZ026-410 COIL 41uH ±7%
L921 QQL26AK-470Z CHOKE COIL 47uH K
L922 QQL26AK-470Z CHOKE COIL 47uH K
T111 QQR0907-001 I F T
T501 QQR1414-001 DRIVE TRANSF
T901 QQT0355-001 POWER TRANSF
T921 QQS0204-001 SW TRANSF
CF001 QAX0349-001 C TRAP 47.25MHz
CF131 QAX0639-001Z C TRAP 4.500MHz
CF161 QAX0642-001Z C FILTER 4.500MHz
CN00C QGA2501F1-06 CONNECTOR W-B (1-6)
CN00S QGA2501C5-04Z CONNECTOR W-B (1-4)
CN00T CHGC05-440 CONNECTOR ASSY
CN00U CHGC04-400 CONNECTOR ASSY
CN0E1 CHGT0015-0B CONNECTOR ASSY
CN0HV QGZ5004C1-06 CONNECTOR (1-6)
CNDEG QGZ5004C1-02 CONNECTOR (1-2)
F901 QMF51N1-5R0-J5 FUSE 5A AC125V
H002 LC30381-001A HEAT SINK
HS004 LC31696-001A HEAT SINK
HS009 LC31678-001A HEAT SINK/AL-F/
HS602 LC31696-002A HEAT SINK
J001 QNZ0454-001 AV JACK S/V/L/R IN
J002 QNN0348-001 PIN JACK L/R OUT
J003 QNN0349-002 PIN JACK V/L/R IN
J004 QNN0348-001 PIN JACK L/R IN
J005 CEMN065-001 PIN JACK V IN
J006 CEMN065-002 PIN JACK L IN
J007 CEMN072-003 PIN JACK R IN
J008 QNS0155-001 3.5 JACK HEADPHONE
K001 QQR0582-001Z FERRITE BEADS
K101 QQR0582-001Z FERRITE BEADS
K251 QQR0582-001Z FERRITE BEADS
K252 QQR0582-001Z FERRITE BEADS
K253 QQR0582-001Z FERRITE BEADS
K254 QQR0582-001Z FERRITE BEADS
K255 QQR0621-002Z FERRITE BEADS
K401 QQR0582-001Z FERRITE BEADS
K701 QQR0582-001Z FERRITE BEADS
K702 QQR0582-001Z FERRITE BEADS
K901 QQR0582-001Z FERRITE BEADS
K902 QQR0582-001Z FERRITE BEADS
K903 QQR0582-001Z FERRITE BEADS
K904 QQR0582-001Z FERRITE BEADS
K921 QQR0582-001Z FERRITE BEADS
K922 QQR0582-001Z FERRITE BEADS
K923 QQR0582-001Z FERRITE BEADS
LC687 QQR1459-001 EMI F. COIL
LC688 QQR1459-001 EMI F. COIL
LC801 QQR1459-001 EMI F. COIL
LF901 QQR0527-003 LINE FILTER
RY901 QSK0085-001 RELAY
S401 QSL4A13-C02 LEVER SWITCH V.CENTER
S751 QSW0847-001 TACT SWITCH POWER
S752 QSW0619-003Z TACT SWITCH VOL+
S753 QSW0619-003Z TACT SWITCH VOLS754 QSW0619-003Z TACT SWITCH CH+
S755 QSW0619-003Z TACT SWITCH CHS756 QSW0619-003Z TACT SWITCH MENU
SF101 QAX0723-001 SAW FILTER
SK351 QNZ0536-001 CRT SOCKET
TH901 QAD0129-3R0 POSISTOR 3
TU001 QAU0353-001 TUNER
VA901 ERZV10V621CS ZNR
X701 QAX0767-001Z CRYSTAL 8MHz
Ω
(No.YA052)3-13
REMOTE CONTROL UNIT PARTS LIST (RM-C1258G-1H)
Ref.No. Part No. Part Name Description Local
UR77EC0603B BATTERY COVER
PACKING
3
6
7 108 12119
5
1
13
13
4
2
13
3
PACKING PARTS LIST
Ref.No. Part No. Part Name Description Local
1 GQ10009-030A-A PACKING CASE
2 CM36616-001-A CORNER LABEL 2pcs in 1set
3 GQ10062-001A-A CUSHION ASSY 4pcs in 1set
4 CP30056-008-A POLY BAG
5 CP30055-001-A TOP COVER
6 QPA02503505 POLY BAG 25cm x 35cm
7 RM-C1258G-1H REMOCON
8 ------------ BATTERY R6P/AA(x2)
9 BT-52006-2Q WARRANTY CARD AV-20F475/S
10 LCT1532-001A-A INST BOOK English/French AV-20F475/S
10 LCT1608-001A-A INST BOOK Spanish AV-N21F45/S
11 BT-51034-1Q REGIST. CARD AV-20F475/S
12 CM36042-00A-H ROD ANTENNA AV-N21F45/S
13 GQ40044-004B-A INCH SIZE LABEL (x4) AV-N21F45/S
2
13
3-14(No.YA052)
Loading...
