JVC AV-14FTT2, AV-21DTT2, AV-21LTT1 User Manual

15 cm

10 cm 15 cm

10 cm

Specifications

TV RF systems B, G, I, D, K, K1

Colour systems PAL, SECAM, NTSC 3.58 / 4.43 MHz (in VIDEO mode only)

Channel and frequencies VHF low channel (VL) = 46.25 to 168.25 MHz

Teletext system Fastext (United Kingdom system), WST (Standard system)

Language displayed by English, Turkish, French, Arabic, Farsi (AV-14FTT2/AV-21DTT2 teletext only)

External input / output VIDEO input (RCA)

Design and specifications subject to change without notice.

Broadcasting Systems

Area

Bahrain, Kuwait, Oman, Qatar,

United Arab Emirates, Yemen, etc.

Asia,

Middle

East

Europe

Oceania

Africa

 2001 VICTOR COMPANY OF JAPAN, LIMITED

Indonesia, Malaysia, Singapore,

Thailand, India, etc.

China, Vietnam, etc.

Hong Kong, etc.

Islamic Republic of Iran, Lebanon,

Saudi Arabia, etc.

Russia, etc.

Czech Republic, Poland, etc.

Germany, Holland, Belgium, etc.

UK, etc.

Australia, New Zealand, etc.

Republic of South Africa, etc.

Nigeria, etc.

Egypt, Morocco, etc.

VHF high channel (VH) = 175.25 to 463.25 MHz UHF channel (U) = 471.25 to 863.25 MHz

■ Receives cable channels in mid band (X to Z, S1 to S10), super band (S11 to S20) and hyper band (S21 to S41) .

AUDIO input (RCA)

VIDEO output (RCA) AUDIO output (RCA)

Headphone jack: mini jack (dia. 3.5 mm)

Country or Region

Colour

PA L

SECAM

PA L

SECAM

System

LCT0990-001B-H 0701-Ki-NV-JMT

Sound

B/G

D/K

B/G

D/K

B/G

COLOUR TELEVISION

AV-14FTT2 AV-21DTT2 AV-21LTT1

INSTRUCTIONS

Thank you for purchasing this JVC colour television. To ensure your complete understanding, please read this manual thoroughly before operation.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

Locations ................................

Preparation .............................

Basic operation ......................

Remote control buttons

and functions........................

Using the TV’s menus ..........

Using the button

on the TV ...............................

Viewing a teletext

programme ...........................

Troubleshooting ...................

Specifications .........

Contents

Back cover

CAUTION:

• TO ENSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES REGARDING THE USE OF THIS TV.

• Operate only from the power source specified on the TV.

• Avoid damaging the power plug and power cord.

• Avoid improper installation and never position this TV where good ventilation is unattainable. When installing this TV distance recommendations must be maintained between the floor and wall, as well as installment in a tightly enclosed area or piece of furniture. Adhere to the minimum distance guidelines shown for safe operation.

• Do not allow objects or liquid into the cabinet openings.

• In the event of a fault, unplug this TV and call a service technician. Do not attempt to repair it by yourself or remove the rear cover.

• When you don’t use this TV for a long period of time, be sure to disconnect the power plug from the AC outlet.

10 13

Locations

ECO

1 2 3 4

8 9 0

SENSOR

SYSTEM

COLOUR SOUND

DISPLAY

TV/VIDEO

123

OFF

TIMER

456


MODE

789

CHANNEL

RETURN+

SCAN

CHANNEL

TEXT

HOLD

REVEAL

SUBPAGE CANCEL

RM-C90

POWER

MUTING

TV/TEXT

0-/

VOLUME

INDEX SIZE

1 ECO SENSOR button p.10 2 COLOUR SYSTEM button p.10

= ~ !

3 SOUND SYSTEM button p.10 4 DISPLAY button p.11 5 MENU buttons

• MENU / buttons

6 TV/VIDEO button p.9 7 OFF TIMER button p.11

8 PICTURE MODE button p.11 9 CHANNEL SCAN button p.12

0 RETURN + button p.12

- CHANNEL –/+ buttons p.9 = POWER button p.5,9 ~ MUTING button p.10

!% Teletext buttons p.17,18 @ Number buttons p.9 # -/-- button p.9 $ VOLUME –/+ buttons p.9

Preparation

1. Connecting the aerial and external devices

Notes: .........................................................................................................................

• For further details, refer to the manuals provided with the devices you are connecting.

• Connecting cables are not supplied.

• The front and rear AUDIO/VIDEO input jacks are directly connected so that input to either

jack is output through both. You cannot provide input to both the front and rear jacks at the same time. Disconnect one input, or use one of the jacks as an output jack only (for monitoring or recording).

• The rod aerial is supplied with the AV-14FTT2.

....................................................................................................................................

■ Connecting the aerial and VCR

Connecting the aerial

To install rod aerial:

Install into the top-rear aerial holder. Once installed, it cannot be removed.

VHF/UHF outdoor aerial

VIDEO

AUDIO

OUT

Indoor aerial

Rod aerial

• Illustration of AV-14FTT2.

Connecting the aerial and VCR

VHF/UHF outdoor aerial

To RF output

To video output

To aerial input

VIDEO

AUDIO

OUT

To audio output

VCR

• Illustration of AV-14FTT2.

Preparation

■ Connecting other external devices

VIDEO

AUDIO

• Illustration of AV-21DTT2.

OUT

To audio output

VCR (for playing)

VCR (for recording)

To audio input

To video output

To audio output

To video output

To video input

Camcorder

TV game

VIDEO AUDIO

Headphones

• Illustration of AV-21DTT2.

Note: ..................................................................................................................

• Use the headphones with a stereo mini jack (3.5 mm in diameter). When you connect the headphones, the TV speakers go off.

...........................................................................................................................

Preparation

2. Connecting the power cord

Insert the Power plug into an AC outlet.

3. Inserting batteries into the remote control

Correctly insert two batteries, observing the and polarities and inserting the

end first.

CAUTION:...........................................

• Follow the cautions printed on the batteries.

............................................................

Notes: .................................................

• Use AA/R6/UM-3 dry cell batteries.

• If the remote control does not work

properly, fit new batteries. The supplied batteries are for testing, not regular use.

............................................................

4. Turning your TV on

Press the Main power button on the TV to turn the TV’s main power on.

The POWER lamp lights.

If image does not appear:

Your TV is in the standby mode. Press the POWER button on the remote control to turn your TV on.

• You can also turn on your TV by pressing the CHANNEL –/+ button on your TV.

To turn your TV off:

Press the POWER button on the remote control. Your TV enters the standby mode.

To turn the TV’s main power off:

Press the Main power button on the TV.

MENU 3 AUTO CH PRESET MANUAL CH PRESET LANGUAGE ENGLISH

SELECT BY EXIT BY OPERATE BY -+

DISPLAY

Preparation

5. Selecting the on-screen language

You can select the language for the on-screen display.

Press MENU then select

Press MENU

The on-screen displays indications are in the selected

to display the

LANGUAGE

to select language.

MENU 3

menu,

MENU 3 AUTO CH PRESET MANUAL CH PRESET LANGUAGE ENGLISH

SELECT BY EXIT BY OPERATE BY -+

DISPLAY

language.

Viewing a Farsi teletext programme (AV-14FTT2/AV-21DTT2 only):

This TV supports Farsi teletext programmes.

1. Using Step 2 above, select Arabic.

The arabic menu is displayed.

2. Press the MENU

3. Press the MENU

Select

to view an arabic teletext programme.

button to select .

WLzU

uMIK w« j³{«

Ëb¹ j³{uMIK Í«

hM«

qOGA²K

ÃËdK—UO²šö

DISPLAY

dŽwÐWGK«

—UwÝ

6. Presetting TV stations

To view a TV programme, you must first preset TV channels to channels on the TV. This TV has 100 channels (channel 1 to 99 and channel AV).

■ Auto Channel Preset

You can automatically preset all TV channels that can be received by your TV to channels.

• The Auto Channel Preset function does not preset a TV channel to the AV channel (channel number 0).

• If the TV cannot preset the TV channel you want to view, preset it manually. For details see “Manual Channel Preset” on page 7.

Press MENU then select

Press MENU Preset function.

ON SEARCH

When you have finished presetting all TV channels that can be received on your TV, the display will go out and the Auto Channel Preset function will end.

• To stop the Auto Channel Preset, press the MENU / button.

to display the

AUTO CH PRESET

to start the Auto Channel

is displayed on the screen.

MENU 3

menu,
