DIGITAL VIDEO CAMERA
LINEUP CATALOGUE
Plug into the future with JVC. From digital video cameras and double-deck
MiniDV/S-VHS recorders to powerful software and convenient accessories,
JVC is your complete source for multimedia products.
JVC Europe Homepage — http://www.jvc-europe.com/
JVC MiniDV Digital Video Cameras — Your Gateway To The World Of Multimedia
From the compact mobile-type to professional shooting model, JVC offers a complete line of MiniDV cameras. Each model is equipped
with a variety of multimedia interfaces and features that let you make the most of your recorded images and sound. All models feature a
DV (i.Link) terminal for fast, lossless digital transfer, while DSC-equipped models also feature a USB terminal for convenient, high-speed
data transfer. Removable media such as SD Memory Cards and MultiMediaCards make it really easy to transfer data to a computer. JVC
effectively links audio-visual sources and your PC, creating a smooth and cohesive multimedia environment for you to enjoy.
rom the first take to the final cut, JVC has got the tools you need to transform
F
your personal vision into a multimedia masterpiece. Simple enough for
beginners, yet advanced enough for the most demanding professionals, JVC
offers a comprehensive selection of multimedia products to make it easy for
everyone to explore new creative vistas.
High-Value Software —
A Complete Production Package
With JVC, all the software you
need to produce a high-quality
finished multimedia production is
available. You’ll be able to file
images, create catalogues, photo
albums and customised portfolios.
JVC Accessories —
Expanding Your Options
As you become familiar with the enormous
potential of JVC multimedia, you’ll want to
take advantage of the wide variety of
accessories available from JVC. These
include a power option, various lenses,
camera cases, cables, multimedia items,
and more. We’ve also got high-resolution
colour printers to output your multimedia
productions
The Ultimate Editing VCR —
DV/S-VHS Dual Deck
Bridging the gap between MiniDV and
VHS, the HR-DVS dual deck series offer
an easy solution for editing and making
S-VHS or VHS dubs of DV masters.
With enhanced PC connectivity, batch
editing capabilities, or built-in transition
effects, these decks provide a solid
foundation for your own professional-
level editing suite.
Introduction P2—3
GR-DVP3/DVP1 P4—5
GR-DV2000/1800 P6—7
GR-DVX88/77/44 P8—9
GR-DVL557/555/450/357/355/157/150 P10—11
Software and Accessories P12—13
HR-DVS2/DVS1 P14—15
microPocket DV
microPocket DV —
the new style in digital video
ew style DV for a new style of life. Ultra-compact and ultra-stylish, the
N
GR-DVP3/1 is the first digital video camera that’s designed for your
lifestyle. With its full-flat body, the GR-DVP3/1 is small enough to slip into
your pocket, yet it also offers incredible picture performance and multimedia
capabilities. microPocket DV brings a whole new style to digital video.
MPEG4 Video Clips For Email
At the touch of a button, the MPEG4 Video Clips For Email function allows you to instantly
create multi-platform compatible video clips that can be viewed on most computer
systems using pre-installed or easily available viewer software*. Based on today’s most
advanced video compression standard, MPEG4’s small file size
makes it ideal for attaching to email or posting on the Web.
* For Windows®computer, Windows MediaTMPlayer ver. 6 or later is required.
For Macintosh
Up to 20-sec. movies with sound can be converted into
MPEG4 and stored on the SD Memory Card/MultiMediaCard
®
computer, Windows MediaTMPlayer for Macintosh is required.
MPEG4
Simulated picture
Super High-Band Processor For 520 Lines Of
Horizontal Resolution
The Super High-Band Processor intelligently calculates
and restores the high-band components of the
luminance signal that would be lost in conventional
processing. This ensures extremely high horizontal
resolution of 520 lines.
Luminance signal
High-band
processor
Conventional
process
Signal interference area 6.75MHz
Frequency characteristics of CCD output
Colour
signal
004
FEATURE LISTS
GR-DVP3
High-Band Digital Video Camera
❐
520 lines of horizontal resolution with Super High-Band Processor
❐
Built-in HG digital still camera (XGA/VGA)
❐
MPEG4 Video Clips for Email
❐
Digital Sound Effects (MP3)
❐
SD Memory Card slot with MultiMediaCard compatibility
❐
USB high-speed interface
❐
DV input/output
❐
10x optical/100x digital zoom with spline interpolation
❐
Digital NightScope for extreme low-light shooting
❐
2" high-resolution colour LCD monitor
❐
Dimensions (W x H x D): 43 x 115 x 80mm
❐
Weight: 340g without battery and tape; 410g with battery
and tape
GR-DVP1
High-Band Digital Video Camera
The GR-DVP1 comes with a sophisticated silver finish and
has all the features provided on the GR-DVP3 except for DV
(i.LINK) input capability.
Dark grey and silver finish
GR-DVP3
HIGH-BAND DIGITAL VIDEO CAMERA
Digital Sound Effects (MP3)
Available on the provided SD Memory Card/MultiMediaCard, these sound effects
(MP3 format) can be inserted into a recording at any time — either during
shooting or afterwards during editing. Among the effects provided are:
Applause, Cheering, Laughter, Explosion, Buzzer, Siren, and Fanfare. You can
also visit JVC’s website and choose from an even wider range of sound effects
and background music available for download.
More sound effects downloadable at
http://www.jvc-victor.co.jp/english/download/d-sound/index.html
:
Info-Shoe For Various Accessories
Dress up your camera for any occasion with a variety of
optional attachments. The exclusive hot-shoe supplies power
to the attached accessory and acts as conduit for control
signals. Just attach these accessories to the Info-Shoe, and
you’re ready for any shooting opportunity.
MP3
Silver finish
GR-DVP1
HIGH-BAND DIGITAL VIDEO CAMERA
① Auto Light
Automatically brightens the scene if existing light
is insufficient while you’re shooting video.*
* Manual on/off operation also possible
② Video Flash
For brilliant digital stills and video snapshots with
adjustable brightness level.
③ Stereo Zoom Microphone
Accurately picks up sound relative to subject
distance as you zoom in or zoom out.
①②③
All screen images are simulated
005
Ultra-high resolution video
and megapixel digital stills —
uncompromised performance for video enthusiasts
f you’re looking for a camera that does it all and does
I
it better, look no further. With an advanced camera
section featuring an AIS lens and a Progressive Scan
CCD, these versatile cameras produce the best possible
quality images whether you’re shooting high-resolution
digital video or UXGA digital stills. If serious performance
is what you want, choose the GR-DV2000/1800.
Progressive Scan CCD with Progressive Colour Filter —
520 lines of horizontal by 576 lines of vertical
JVC has employed an advanced array of picture-improvement technologies to ensure superb image quality. The backbone of these
technologies is a progressive scan CCD which provides extremely high resolution – recording images ideal for playback, printing,
or capturing to a computer. JVC’s progressive colour filter works in
tandem with the progressive scan CCD to provide increased sensitivity
and picture quality by raising vertical resolution to 576
lines (in Progressive mode).
Conventional CCD
Interlace scanning
Neighbouring lines are combined and
processed.
1/50 sec. 1st scan
1/50 sec. 2nd scan
Progressive Scan CCD
Progressive scanning
Each line is processed individually,
resulting in higher vertical resolution.
1/50 sec. scan
Dual Shooting Mode
Lets you shoot motion video and still pictures simultaneously. Just push the Snapshot button in the Dual mode and a VGA still
picture is recorded on the SD Memory Card or MultiMediaCard while you continue taping video. You can take a snapshot any time
without stopping video recording so you’ll never miss any action even while shooting a still.
UXGA (1600 x 1200) 1.92 Megapixel Digital Stills with Pixel Shift Technology
A combination of JVC’s AIS (Accurate Image Shift) Lens and 800K-pixel Progressive Scan CCD makes this possible. In this mode,
for each shot, the image is first sampled with all the pixels in their usual locations, and within a split second, the image is
double-exposed while shifting diagonally 1/2-pixel’s worth. This pixel shift technology, along with JVC’s unique interpolation method,
is able to generate a UXGA-size picture with 1600 x 1200-pixel resolution — the same 1.92 megapixel image size you’d get with the
high-grade digital still cameras.
Note: Only optical zoom (2x max.) is possible in UXGA mode. In cases where there is
excessive camera-shake or with certain low-contrast images, a single exposure will be
processed to generate a UXGA picture.
First Exposure Second Exposure Resized Output
006
Megapixel Digital Still
FEATURE LISTS
GR-DV2000
High-Band Digital Video Camera
❐
576 lines of vertical resolution with Progressive Scan CCD
(in Progressive mode)
❐
520 lines of horizontal resolution with Super High-Band Processor
❐
UXGA 1.92 megapixel digital stills with Pixel Shift Technology
❐
Dual Shooting mode
❐
SLR-type operation with real-touch manual focus ring
❐
SD Memory Card slot with MultiMediaCard compatibility
❐
USB high-speed interface
Optional Lenses
Wide Conversion Lens
GL-V0752
❐
DV input/output
❐
10x optical/300x super digital zoom with spline interpolation
❐
3.5" high-resolution colour LCD monitor
❐
Dimensions (W x H x D): 74 x 90 x 178mm
❐
Weight: 660g without battery and tape; 740g with battery and tape
GR-DV1800
High-Band Digital Video Camera
The GR-DV1800 has all the features provided on the GR-DV2000
except for DV (i.LINK) input and analogue input capabilities.
Tele Conversion Lens
GL-V1452
Exclusive high-speed printing — GV-SP2
Digital System Printer
The GR-DV2000/1800 has a special
connector for rapid image transfer to the
optionally available GV-SP2 Digital
System Printer. In addition to borderless
print capability, the GV-SP2’s high-resolution
310-dpi head enables to produce natural,
breathtaking full-colour printouts.
GR-DV2000/1800
HIGH-BAND DIGITAL VIDEO CAMERA
Info-Shoe for optional attachments
Auto Light
Major features
❐
Borderless photo-size
(100mm x 150mm) print
❐
310-dpi high-resolution image
❐
Full-colour dye-sublimation system
❐
Pre-selected automatic
printing with DPOF compatibility
❐
USB terminal for computer
connectivity
❐
Dimensions (W x H x D):
262 x 79 x 254mm
❐
Weight: 2.2kg
Video Flash Stereo Zoom Microphone
Borderless
Calendar
A variety of print styles
Black & White/
Sepia
Multiscreen
Templates
All screen images are simulated
007
Best balance of mobility,
quality and creativity —
compact digital imaging companion
ith extended PC connectivity and instant multimedia
production capability, these slim, flat-design cameras offer
W
a unique balance of quality, mobility and creativity. Superior
picture quality, sophisticated shooting features, and more make
it ideal for mobile video enjoyment today and the future.
008
USB Terminal
For easier and even more convenient data transfer capability, the USB
terminal is provided for fast, plug-and-play data downloading from the SD
Memory Card/MultiMediaCard to a compatible PC. Since
the USB Mass Storage Class support is provided, just
hook up the camera via cable and it will appear on your
computer screen as a drive unit.
HG Digital Stills (XGA/VGA)
The built-in HG digital still camera can capture crystal-clear still
images for output in either XGA mode or VGA mode. Based on a
combination of 800K-pixel CCD and mechanical shutter system,
the HG Digital Still function is able to capture full frame stills
offering 1.5 times the vertical resolution of conventional field stills.
By emulating the operation of a progressive-scan CCD, HG Digital
Still enables moving subjects to be captured for non-jittery high
quality stills.
Conventional field stills
Whereas conventional field stills capture only half the scanning lines
and artificially double them, HG Digital Stills capture a full frame with
all 625 scanning lines, resulting in 420 lines of vertical resolution.
HG Digital Still captures
full frame
FEATURE LISTS
TM
GR-DVX88
High-Band Digital Video Camera
❐
520 lines of horizontal resolution with Super High-Band Processor
❐
Built-in HG digital still camera (XGA/VGA)
❐
MPEG4 Video Clips for Email
❐
Digital Sound Effects (MP3)
❐
SD Memory Card slot with MultiMediaCard compatibility
❐
USB high-speed interface
❐
DV input/output terminal
❐
10x optical/200x digital zoom with spline interpolation
❐
Digital NightScope for extreme low-light shooting
❐
2.5" high-resolution colour LCD monitor
❐
Auto Flash
❐
Dimensions (W x H x D): 51 x 120 x 97mm
❐
Weight: 500g without battery and tape; 575g with battery and tape
GR-DVX44
HIGH-BAND DIGITAL VIDEO CAMERA
GR-DVX77
High-Band Digital Video Camera
The GR-DVX77 comes with all the features the GR-DVX88
has except for DV (i.LINK) input capability.
GR-DVX44
High-Band Digital Video Camera
❐
520 lines of horizontal resolution with Super High-Band
Processor
❐
Direct PC connection with DV (i.LINK) output and PC
(serial port) terminal
❐
10x optical/200x digital zoom with spline interpolation
❐
Digital NightScope for extreme low-light shooting
❐
2.5" high-resolution colour LCD monitor
❐
Dimensions (W x H x D): 51 x 120 x 97mm
❐
Weight: 470g without battery and tape; 545g with battery
and tape
SD Memory Card/MultiMediaCard
Compatibility
The removable MultiMediaCard lets you easily transfer image
and sound data to and from a PC. Just remove the card and
load it into the optional adapter or card reader — the stored
data can be dragged and dropped on your PC just like any
other file. And since the card slot is SD-ready, future
compatibility with forthcoming storage formats is assured.
SD Memory Card
MultiMediaCard
CU-VPSD60
PC Card Adapter
CU-VFSD50
Floppy Disk Adapter
CU-VUSD70
USB Reader/Writer
GR-DVX88/DVX77
HIGH-BAND DIGITAL VIDEO CAMERA
All screen images are simulated
009
Aversatile lineup
to meet any requirement —
experience MiniDV performance and versatility
dvanced performance is fundamental to all of our MiniDV digital video
A
cameras. No matter which model you choose, you’ll always get all the
advantages and quality of the MiniDV format, including multimedia
versatility, in an extremely easy-to-use package. Point-and-shoot
controls, built-in digital still camera with USB interface,* and
Digital NightScope for night scene shooting make JVC
MiniDV the ideal way to begin your exploration of digital
video.
*Availability differs by model.
Built-in Digital Still Camera Facility
In addition to high-quality motion video, some models also feature a built-in digital still
camera to capture digital still pictures. It takes VGA (640 x 480 pixels) size digital stills
and stores them on the provided MultiMediaCard. You can choose image quality
between Fine and Standard depending on your needs.
Digital NightScope For Extreme Low-Light Shooting
With enhanced low-light sensitivity, JVC’s exclusive Digital NightScope function allows you to
capture clear, bright images at night without loss of colour associated with other nightshooting systems. Without relying on infrared rays as do similar systems, Digital NightScope
uses the camera’s normal optical system. As a result, the image you shoot is always in
colour, and there’s no limit on shooting range.
DV terminal For Digital-To-Digital Transfer
All models of DVL series are provided with a DV terminal* (i.LINK:
IEEE 1394 compliant) for fast, lossless digital transfer to a computer,
as well as for dubbing to another DV unit in native DV format.
*Input and output for GR-DV557/357/157, output only for GR-DVL555/450/355/150
PC (Serial) Terminal For Easy Still Image Capture
For models not equipped with digital still camera facility, there’s a serial
terminal for direct connection to PCs with serial ports (RS-232C), enabling
you to take advantage of computer-controlled still image capture using the
provided JLIP software without installing an additional board.
Digital NightScope
off
Digital NightScope
on
Simulated pictures
010
FEATURE LISTS
All models are equipped with the following features:
❐
520 lines of horizontal resolution with Super
High-Band Processor
❐
DV terminal
❐
10x optical/300x digital zoom with spline interpolation
❐
Digital NightScope for extreme low-light shooting
❐
Snapshot mode
❐
EasyEdit with multi-brand remote control
❐
Built-in auto light
GR-DVL557/555
High-Band Digital Video Camera
❐
Built-in digital still camera for high-quality digital stills
❐
SD Memory Card slot with MultiMediaCard compatibility
❐
USB high-speed interface
❐
DV input/output (GR-DVL557), DV output (GR-DVL555)
❐
Analogue input (GR-DVL557)
❐
Software package for image processing and editing
❐
3.5" high-resolution colour LCD monitor
❐
Dimensions (W x H x D): 83 x 97 x 188mm
❐
Weight: 610g without battery and tape, 690g
battery and tape
with
GR-DVL357/355
High-Band Digital Video Camera
❐
Built-in digital still camera for high-quality digital stills
❐
SD Memory Card slot with MultiMediaCard compatibility
❐
USB high-speed interface
❐
DV input/output (GR-DVL357), DV output (GR-DVL355)
❐
Software package for image processing and editing
❐
2.5" high-resolution colour LCD monitor
❐
Dimensions (W x H x D): 83 x 97 x 188mm
❐
Weight: 590g without battery and tape, 670g with
battery and tape
GR-DVL450
High-Band Digital Video Camera
❐
DV output
❐
Digital Still Out (serial port) terminal
❐
Software package for image processing and editing
❐
3.5" high-resolution colour LCD monitor
❐
Dimensions (W x H x D): 83 x 97 x 188smm
❐
Weight: 610g without battery and tape, 690g with battery
and tape
GR-DVL157/150
High-Band Digital Video Camera
❐
DV input/output (GR-DVL157), DV output (GR-DVL150)
❐
Digital Still Out (serial port) terminal
❐
Software package for image processing and editing
(GR-DVL157)
❐
2.5" high-resolution colour LCD monitor
❐
Dimensions (W x H x D): 83 x 97 x 188mm
❐
Weight: 590g without battery and tape, 670g with battery
and tape
HS-V16KIT JLIP Capture Pack —
Make the most of your MiniDV camcorder
For models that don’t come with the software, an optional
connection kit is available. It includes the essential
accessories for image capturing and video-to-video
editing with your computer. Included items: PC connection
cable, JLIP Video Capture, JLIP Video Producer and
Presto! Series software.
GV-DT3 Digital Printer —
Direct connection for high-quality printouts
❐
High-quality picture (306 dpi) with 16.77 million colours
❐
Dye Sublimation Printing system for superior quality images
❐
DV input terminal (i.LINK) for digital-to-digital printing
❐
Infrared data transfer (IrTran-P) for wireless printing with a compatible
equipment
❐
Video/S-video input for printing directly from camcorders and VCRs
❐
Serial port for direct printout from PC/capture of image to
PC
❐
Bundled software and cables for image filing,
graphics processing and printing
❐
Dimensions (W x H x D): 213 x 107 x 213mm
❐
Weight: 2.3kg (with paper tray)
All screen images are simulated
011
The software you need to produce
the multimedia you want
From simple photo albums to sophisticated digital video productions
complete with special effects and titles, these versatile applications
give you all the tools you need to create multimedia products you’ll
be proud of.
JLIP Software: For still image capture
and pro-style video editing
JVC’s JLIP software bundled with some digital video
cameras enables computer-controlled still image capture
and linear video editing.
JLIP Video Producer
Lets you use your PC as a controller for linear video editing of up to 99 segments at a time. Drop in an array
of digital special effects and generate as many first-generation high-quality tapes as needed.
JLIP Video Capture
Enables digital-to-digital capture of still
images from DV recordings to a PC as
BMP or JPEG data. Interval Capture (with
timecode management) allows unattended
automatic capture of images.
Choose
the order of scenes and
special effects
Computer-controlled
JLIP connection
JLIP terminal
S-video out
Edit terminal
Video Echo Shutter Wipe Sepia Corner Wipe
Automatic
computer-controlled editing
begins with the touch of a button
JLIP Interface
JLIP (Joint Level Interface Protocol) is a communications protocol developed by JVC to allow
multimedia products with J-terminals to communicate. JLIP enables centralised bi-directional control
of compatible AV equipment from any PC with a standard serial por t and running Windows®, for
streamlined video editing and image capture with JLIP software
Presto! Series: All the software you need for quality image editing
The Presto! software bundled with most models is all you need for storing, polishing and editing your best shots.
Presto! Mr.Photo
Lets you create customised
catalogues of still images as
well as letting you drag-anddrop images for printing,
emailing or creating HTML
slideshows.
Presto!
ImageFolio
Ideal for pro-style retouching
with multi-layer mask
support, as well as special
effects such as shadowing
and embossing.
Program
up to 99 segments
Presto!
PhotoAlbum
Simplifies the creation of
digital photo albums with
several album and templates.
You can easily convert these
albums into HTML for
uploading to the web.
USB Driver
For models equipped with a USB terminal, a USB driver is also provided for easy plug-and-play
data downloading to your computer.
Software Availability For Each Model
Item
Model
JLIP Video Capture
JLIP Video Producer
Presto! Mr. Photo
Presto! PhotoAlbum
Presto! ImageFolio
USB Driver
012
GR-DVP3
GR-DVP1
GR-DV2000
GR-DV1800
GR-DVX88
GR-DVX77
GR-DVX44
GR-DVL557
GR-DVL555
GR-DVL450
GR-DVL357
GR-DVL355
Note: For system requirements information, please refer to the back cover.
GR-DVL157 HS-V16KITGR-DVL150
All screen images are simulated
Accessorise your camera
with these versatile options
Your camera comes equipped with everything you need to get started
in the world of multimedia. But when you’re ready to start exploring
more options, JVC offers a variety of accessories that will help you
make the most of your camera’s potential.
Power Supply
❐
BN-V107 (Dark grey/Silver)
Battery Pack
❐
BN-V114
Battery Pack
❐
BN-V416/V428
Battery Packs
❐
BN-V507 (Silver)/
V507B (Grey)
Battery Pack
Lenses Multimedia
❐
Wide Conversion Lens
❐
GL-V1452
Tele Conversion Lens
GL-V0637
❐
GL-V0752
Wide Conversion Lens
❐
LN-KIT1D
Lens Kit
❐
BT-V408K1
Battery Kit
*
❐
VU-V840KIT/V840KBC*
High-Capacity Battery Kits
❐
BN-V514
Battery Pack
Bags & Cases
❐
CB-V230/V240
Snow & Rain Jackets
❐
CB-V920
Snow & Rain Jacket
❐
WR-DV75/DVP3
Marine Cases
❐
CB-V77
Carrying Bag
❐
BT-V507K1 (Silver)/
BT-V507BK1 (Grey)
Battery Kits
❐
VU-V856KIT/V856KBC*
High-Capacity Battery Kits
❐
❐
CU-SD016
SD Memory
Card
* Connection cable (VC-VBN856) is included in VU-V840KBC/V856KBC only.
CU-MMC08/MMC16
MultiMediaCards
❐
CU-VFSD50
Floppy Disk Adapter
❐
CU-VPSD60
PC Card Adapter
❐
AA-V100
AC Power Adapter/
Battery Charger
*
❐
AA-V40
AC Power Adapter/
Battery Charger
❐
Miscellaneous
❐
VU-V995KIT/V996KIT/V997KIT/
V999KIT/V888KIT
Starter Kits
❐
AC Power Adapter/
BH-V1
Car Battery Inverter
AA-V50
Battery Charger
❐
VU-VCKIT1D
Cleaning Kit
❐
GL-V027FK
Filter Kit
❐
❐
GL-V37MC
Lens Protector
V2000/1800
VP3/1
-D
R
R-D
G
G
G
-D
R
VX88/77
BN-V107/V114
BN-V416/V428
BN-V507/V507B/V514
BT-V408K1
BT-V507K1/V507BK1
VU-V840KIT/V840KBC*
VU-V856KIT/V856KBC*
*
*
AA-V40
AA-V50
Power Supply
AA-V100
BH-V1
GL-V0637
GL-V0752
GL-V1452
LN-KIT1D
Lenses
GL-V027FK
GL-V37MC
* Connection cable (VC-VBN856) is included in VU-V840KBC/V856KBC only.
Note: Certain accessories may not be available in certain areas.
❐
CB-V753
Leather Pouch
CB-V747
Soft Camera Case
VX44
-D
-D
R
G
R
G
*
*
*
*
VL450/157/150
VL557/555/357/355
-D
R
G
*
*
Bags & Cases
Multimedia
Miscellaneous
CB-V230
CB-V240
CB-V920
WR-DV75
WR-DVP3
CB-V77
CB-V753
CB-V747
CU-MMC08/MMC16
CU-SD016
CU-VFSD50
CU-VPSD60
CU-VUSD70
VC-VDV204/VDV206
VU-V995KIT
VU-V996KIT
VU-V997KIT
VU-V999KIT
VU-V888KIT
MZ-V3/VL-F3/VL-V3
VU-VCKIT1D
❐
VC-VDV204/VDV206
DV Cables
R-D
G
❐
CU-VUSD70
USB Reader/Writer
V2000/1800
VP3/1
R-D
G
G
R-D
VX88/77
G
R-D
VX44
G
VL450/157/150
VL557/555/357/355
-D
R-D
R
G
Accessory compatibility chart
013
The ideal editing solution, JVC’s
dual-decks combine MiniDV and
VHS in a single unit
A valuable addition to any home or professional editing suite,
JVC’s dual decks integrate a high-quality MiniDV deck and Super
VHS deck in a single unit, bridging the gap between DV and
VHS to offer unprecedented video editing, dubbing and playback
flexibility. As well as allowing you to record and enjoy television
programming in digital or analogue formats, these decks provide
the simplest way for you to dub DV masters to VHS or S-VHS, or
to edit directly from DV to VHS.
Streamlined MiniDV playback
The integrated MiniDV deck extends the flexibility of your
multimedia capabilities. Playing back your MiniDV recordings is
as simple as inserting a MiniDV cassette into the MiniDV slot, for
instant viewing on TV without connecting your MiniDV camera.
Innovative JVC technologies deliver
outstanding picture quality
MiniDV Quality & Performance
❏
The MiniDV format shrinks the superior quality and versatility of
digital video into a matchbox-size cassette. Broadcast-level quality
is achieved with MiniDV’s inherent high horizontal resolution (500
lines) and a colour bandwidth 3 times that of analogue video.
S-VHS Quality & Performance
❏
These models incorporate JVC’s DigiPure Technology to deliver
top-of-the-line S-VHS quality characterised by sharp image
contours and vivid colours. DigiPure Technology is, in fact, a group
of advanced digital image processing technologies perfected by
JVC. They include Digital Wide TBC (Time Base Corrector) which
removes "jitter" from fluctuating video signals, to deliver stable
pictures even with old tapes, for improved playback quality. The
3-Dimensional Digital Circuit incorporating 2MB of Frame Memory
is an underlying component for the following Digipure technologies.
Precision 3-D Colour Circuit ensures clear colour separation
without bleeding, to sharpen the edges of images, especially with
red colours. Digital 3-D YNR/CNR removes fine dust-like noise
(YNR) and uneven colour noise (CNR), improving the S/N ratio by
approximately 3 dB. In addition, Digital 3R Picture System applies
edge correction to the luminance signal to enhance detail and
improve the
chrominance
signal’s transient
characteristics.
Video with fluctuating signals
With Digital Wide TBC
Simulated pictures
Dubbing Possibilities
One-touch Dubbing
❏
By virtue of the 2-in-1 design, one-touch dubbing is enabled in
either direction — from DV-to-S-VHS or S-VHS-to-DV. Push the
one-touch dubbing button on the front panel for two seconds and
it synchronises the two decks, rewinds both
tapes to the start, and begins recording.
Versatile Dubbing Options
❏
Video insert and audio dubbing is possible on either deck for
increased post-recording options. For superior sound, high-quality
32KHz audio dubbing is available with the MiniDV deck. The
S-VHS deck’s Flying Erase Head enables insert editing of new
pictures without affecting the original audio track, and with no
noticeable distortion at the transition points.
Advanced Connectivity
❏
Both units are equipped with a DV in/out
terminal that enables direct loss-less
recording to/from the MiniDV format, as
014
FEATURE LISTS
MiniDV/Super VHS Hi-Fi Stereo Video Cassette Recorders
Both models are equipped with the following features:
❐
MiniDV format with PCM digital audio
❐
High-resolution Super VHS and Hi-Fi VHS Stereo provide
exceptional image and sound quality
❐
DigiPure Technology
• Digital Wide TBC • Precision 3-D Colour Circuit
• Digital 3-D YNR/CNR • Digital 3R Picture System
❐
One-touch dubbing (DV S-VHS/VHS)
❐
64-Programme "EasyEdit" (DV S-VHS/VHS)
❐
DV in/out terminal (i.Link, IEEE 1394 compliant) for direct
with 2MB frame memory
digital transfer
HR-DVS1
❐
DV insert editing and audio dubbing (32kHz mode)
❐
S-VHS/VHS insert editing and audio dubbing
HR-DVS2
❐
Super VHS ET
❐
Extensive compatibility with popular NLE systems*
❐
Jog/shuttle on deck
*Please consult an authorised JVC dealer for further information on compatible NLE
(Non-Linear Editing) systems.
HR-DVS1
❐
Digital special effects, wipes and fades during "EasyEdit"
Specifications
Formats: MiniDV standard with PCM digital audio
Power requirement: AC 220~240V, 50/60 Hz
Max. recording time: MiniDV deck (M-DV80ME cassette)
Channel coverage: (VHF) 47~89/104~300/302~470 MHz
Dimensions (W x H x D): HR-DVS2: 435 x 124 x 391mm
Weight: HR-DVS2: 6.9kg
S-VHS/VHS PAL standard with Hi-Fi audio
80 min. (SP)/120 min. (LP)
S-VHS deck (E-240 cassette)
240 min. (SP)/480 min. (LP)
(UHF) 470~862 MHz
HR-DVS1: 437 x 127 x 380mm
HR-DVS1: 7.6kg
HR-DVS2
well as direct output to JVC’s digital printers such as the GV-DT3.
The front panel AV input terminals accept input from most
analogue video sources. For more advanced editing and
connectivity, the i.Link connection enables direct connection to
compatible PCs for image capture.
NLE Integration For The Editing Enthusiast
Those who expand their creativity into the realm of NLE (nonlinear editing) will appreciate the extensive i.LINK (IEEE 1394)
connectivity and compatibility the HR-DVS2 offers with popular
NLE systems*. Since systems by various third-party manufacturers
are supported, you’ll be able to transfer from video to PC, or vice
versa, regardless of whether the original or target video format is
S-VHS/VHS or MiniDV.
MiniDV content
S-VHS/VHS content
Dub to MiniDV
Dub to S-VHS/VHS
*Please consult an authorised JVC dealer for further information on compatible systems.
i.LINK
i.LINK
PC
(NLE system)
PC
(Edited result)
64-Programme "EasyEdit"
Dubbing from the MiniDV deck to the S-VHS deck opens up
editing capabilities, without requiring a computer. Advanced
Random Assemble Edit enables the "EasyEdit" of 8 programmes,
each with up to 8 sets of in/out points (for a maximum 64 recorded
scenes), to be combined in a final edit. Since edit programmes
are saved to memory,* you can create multiple first-generation
P1 IN OUT MODE
1 - - 0:18:03 0:18:27
2 - - 0:04:58 0:05:33
3 - - 0:00:11 0:03:48
4 - - 0:42:18 0:44:21
5 - - 0:21:39 0:22:26
6 - - 0:08:43 0:11:03
7 - - 0:11:26 0:15:52
8 - - 0:32:33 0:37:15
TO 0:20:54
TOTAL 0:20:54
8 Segments X 8 Programmes
DV VHS
P1 22:45 / 24. 12 / 1999
P2 06:30 / 25. 12 / 1999
P3 13:45 / 18. 11 / 1999
P4 18:31 / 03. 08 / 1999
P5 20:27 / 30. 12 / 1999
P6 09:38 / 27. 10 / 1999
P7 10:19 / 08. 03 / 1999
P8 17:03 / 22. 11 / 1999
[ ] OK
[ R. A. EDIT ] : EXIT
=
64
Total!
tapes on the S-VHS deck.
*Switching off the power to the deck
for longer than 30 minutes erases the
memory
Digital Special Effects during
"EasyEdit"
The HR-DVS1 offers an array of professional-quality digital
special effects and transitions that can be programmed
on-screen using the provided remote control, to be applied
during "EasyEdit". Great if you’re looking for an all-in-one editing
solution that doesn’t require any external equipment.
Video Echo
(HR-DVS1)
Sepia
Door WipeConer Wipe
Other High Value Features for Recording
and Playback Enjoyment
The multi-brand TV/satellite-compatible remote provides control
❏
over most major brand TVs and satellite decoder units. The
remote is also used for Advanced Random Assemble Editing and
controlling the 10x Pinpoint Digital Zoom (HR-DVS1) when taking
a closer look at your MiniDV recordings.
T-V Link compatibility offers users convenient features that
❏
include Preset Download to import preset information from the TV
to the video deck, NexTView Link for timer-based recording based on the
TV’s electronic programme guide. Direct Rec recording of TV programmes
while you’re watching them is yet another user-friendly feature.
All screen images are simulated
015
Feature Comparison Chart
Super High-Band Processor
with 520 Lines of Horizontal Resolution
Progressive Scan CCD
with Progressive Colour Filter
1.92 Megapixel Digital Stills
With Pixel Shift Technology
Built-in Digital Still Camera
SD Memory Card/MultiMediaCard
Compatibility
Provided Memory Card
(XGA/VGA)
VP3
R-D
G
HG
HG
(XGA/VGA)
SD SD MMC MMC MMC MMC MMC MMC MMC MMC
Dual Shooting Mode
MPEG4 Video Clips For Email
Digital Sound Effects (MP3)
In/Out
DV Ter minal
Out In/Out Out In/Out Out Out In/Out Out Out In/Out Out In/Out Out
Analogue Input
USB Ter minal
Digital Still Output (Serial)
Zoom Ratio (Optical/Digital)
Colour LCD Monitor
Colour Viewfinder
Digital NightScope
Built-in Auto Flash
Built-in Auto Light
Info-Shoe
Snapshot Mode
Digital Effects & Scene Transitions
EasyEdit with Multi-Brand Remote
Provided Software*
* For available software items, refer to "Software Availability Chart" on page 12.
R-D
G
XGA/VGA)
(UXGA/
VP1
R-D
G
XGA/VGA)
(UXGA/
V2000
R-D
G
HG
(XGA/VGA)HG(XGA/VGA)
V1800
VL555
G
R
-D
VL450
G
R-D
R-D
G
G
G
10x/300x10x/300x10x/300x10x/300x10x/300x10x/300x10x/300x10x/200x10x/200x10x/200x10x/300x10x/300x10x/100x10x/100x
2.5”2.5”2.5”2.5”3.5”3.5”3.5”2.5”2.5”2.5”3.5”3.5”2”2”
-D
R
R-D
VX88
-D
R
G
R-D
R-D
G
G
-D
R-D
R
G
G
(VGA) (VGA) (VGA) (VGA)
VL557
VX44
VX77
VL150
VL157
VL355
VL357
Software System Requirements
[For Windows®]
JLIP Video Capture/JLIP Video Producer
• Personal computer with Microsoft®Windows®95/98/Me/2000 Professional
• One free serial port, compatible with 9600bps transmission rate, connectable to
RS-232C terminal with 9-pin serial connector (Recommended compatible with
UART 16550A)
Note: An optional 9-pin serial conversion adapter is required for Windows® computers using
serial communication port other than standard 9-pin.
Presto! Mr.Photo/PhotoAlbum/ImageFolio
• Personal computer with Microsoft®Windows®95/98/NT4.0/2000 Professional*
*Also compatible with Windows® Me for GR-DVP3/DVP1
USB Driver
• Microsoft®, Windows®98 Full Version (Not Upgrade)
• Microsoft
®
, windows®98 Second Edition Full Version (Not Upgrade)
• Available USB port
If you are using Windows® 2000 Professional/Windows®Me, the information file (.inf) that is needed
in order to install the standard driver that is provided with the OS is provided in this packet.
E. & O.E. Design & specifications are subject to change without notice. It should be noted that it may be unlawful to re-record pre-recorded tapes, records, or discs without the consent of the
owner of copyright in the sound or video recording, broadcast or cable programme and in any literary, dramatic, musical, or artistic work embodied therein. SD Logo is a trademark. All brand
names are trademarks, registered trademarks, or trade names of their respective holders. ShowView is a registered trademark of Gemstar Development Corporation. The ShowView system is
manufactured under license from Gemstar Development Corporation. Video Plus+ and PlusCode are trademarks of Gemstar Development Corporation. Video Plus+ system is manufactured under
license from Gemstar Development Corporation. Certain accessories may not be available in certain areas. All screen images and print samples in this catalogue are simulated. Copyright © 2001,
Victor Company of Japan, Limited (JVC). All Rights Reserved.
Presto! Mr.Photo/PhotoAlbum
• Mac OS7.5 or later on Power Macintosh
USB Driver
• iMacTM,. iBookTM, Power Macintosh G3/Power MacTM G4, or
PowerBook
TM
G3
• Mac OS 8.5.1/Mac OS 8.6/Mac OS 9.0*/Mac OS 9.1*
• Available USB port
* For Mac OS 9.0/9.1, please use the USB drive that is provided with the OS software.
Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries. Apple, Apple log, Macintosh®and Mac are registered trademarks of
Apple Computer, Inc. in United States and/or other countries. Other trademarks are the property of their
respective owners.
[For Macintosh
®
]
JVC Europe Homepage — http://www.jvc-europe.com/
AVAILABLE AT
JVC is an Official Partner of the 2002 FIFA World Cup
Loading...
