Instruction Manual
JUWEL TWIN-LITE PL4-15 W
JUWEL TWIN-LITE PL4-18 W
JUWEL TWIN-LITE PL5-20 W
JUWEL TWIN-LITE PL5-40 W
www.juwel-aquarium.com
Page 2
Introduction
Thank you for choosing a JUWEL Aquarium product.
Our products represent over 40 years experience in the manufacturing of aquariums
and their accessories applying the most modern production techniques in bringing
together the JUWEL Aquarium system, which is both easy to use and simple to
maintain.
Important:
Please read this instruction manual carefully and completely to make sure you
have received all components before setting up the aquarium.
Please observe the safety instructions and maintenance guidelines given in this
manual.
This instruction manual has been carefully prepared to provide you with accurate
and complete information. All efforts have been made to ensure that the
information given is correct. However, we cannot accept responsibility for
printing or other errors. Technical details are always approximate and are not
warranted characteristics and may be subject to change without notice.
Always unplug all immersed electrical equipment from mains before placing your
hands into the water.
Safety instructions:
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
Operation with the RC circuit breaker only, max. 30mA.
The power plugs of the electrical devices must not become moist. Connect the
power plugs to the power supply at such a height that the connection cable
forms a loop which would enable the water to drip down.
2
Page 3
Maintenance and care JUWEL Violux
Vio40_Aufstellen
Korallux_60_PL_Detail
SB 60/ 50
Korallux_60_PL_u_SB_60_50
Korallux_60_PL
3
2 1
Korallux_60_Wartung
The JUWEL Aquarium cover light requires very little maintenance and attention.
However, each fluorescent lamp loses luminosity in the course of time. Of course this
affects the growth of the plants in your aquarium. Because of that, we recommend you
to replace the compact fluorescent lamp at regular intervals.
As the JUWEL Twin-Lite PL lamp forms a closed unit with a power plug, the
replacement may be realized without problems.
Replacement of the compact fluorescent lamp JUWEL Twin-Lite PL4 (15 watts):
- Pull the power plug.
- Push the pins connecting the hinges to the cover from the inside to the outside from
the hinges.
- Remove the cover light from the aquarium in order to gain access to the PL lamp.
- Pull the PL lamp to the right at the socket in order to remove it from the holder.
- Now slide the new PL lamp on the holder until it is securely seated.
- Rearrange the cover light on the aquarium and pass the power cord through the
designated rear opening.
- Push the pins from the outside into the hinges until they are securely locked and
flush with the hinge.
- Now the cover light may be connected to the power grid.
Maintenance and care JUWEL Korallux
The JUWEL Aquarium cover light requires very little maintenance and attention.
However, each fluorescent lamp loses luminosity in the course of time. Of course this
affects the growth of the plants in your aquarium. Because of that, we recommend you
to replace the compact fluorescent lamp at regular intervals.
As the JUWEL Twin-Lite PL lamp forms a closed unit with a power plug, the
replacement may be realised without problems.
Replacement of the compact fluorescent lamp JUWEL Twin-Lite PL5 (20 watts):
- Pull the power plug.
- Remove the cover light from the aquarium in order to gain access to the PL lamp.
- Pull the PL lamp to the left at the socket in order to remove it from the holder. (Ref.
figure)
- Start by passing the new PL lamp through the holder in the front section and slide
the PL lamp with the socket on the right holder until it is securely seated.
- Arrange the cover light on the aquarium and reconnect it to the power grid.
Safety instructions:
Do not operate the light under water.
Do not attempt to open the light or repair it in case of a malfunction! This would
endanger the waterproofness.
Install the JUWEL Twin-Lite PL Light unit only in aquarium hoods made by JUWEL
Aquarium from polystyren or ABS to fit the safety requirements using the
specially constructed holders.
Safety instructions:
Pull the power plug for each light replacement.
The connection line may not be repaired. Always replace the entire light in case
of damage.
For Replacement use only original JUWEL Twin-Lite PL Light units!
3
Page 4
Tip:
JUWEL automatic feeder
We offer you the JUWEL automatic feeder matching all JUWEL aquariums.
It is available from specialist retailers as original JUWEL Aquarium accessory (item No.
89000).
Proper disposal (electrical waste)
The labelling on the product or on the accompanying literature declares that it
must not be disposed of, at the end of its service life, together with household
rubbish. Please dispose of this equipment separately from other waste, to protect
the environment or public health from damage by unregulated waste disposal.
Recycle the equipment and support the sustained recycling of material resources.
Private users should contact the dealer who sold them the product or the
responsible authorities, for a demonstration on how to recycle the equipment in
an environmentally friendly way.
Guarantee
We guarantee the performance of the JUWEL-Aquarium product or its accessories to the
purchaser for a period of 24 months from the date of purchase according to the
following conditions:
§ 1 Extent of the guarantee
(1) This guarantee extends to the JUWEL-Aquarium product and its components
excluding items subject to wear and tear such as light tubes and filter media. It is
limited to the product as such and does not cover damage to other property and/or
individuals. In addition, the provisions of the product liability law apply. These
provisions are not limited by the aforementioned arrangement.
(2) It is the prerogative of JUWEL-Aquarium to decide whether the guarantee is
performed by means of repair or replacement. If neither repair nor replacement can
ensure the performance of the JUWEL-Aquarium product the purchaser is entitled to
demand a reduction in price or to return the product against repayment of the
purchase price.
§ 2 Guarantee period and settlement procedure
(1) The guarantee period begins on the day of the purchase of the product from the
retailer. Claims under this guarantee will not be honoured, if
(a) the damage is caused as a result of improper use or maintenance or non-
observance of the instructions given in this manual
(b) the product or its components have been maintained by persons or companies not
authorised by the manufacturer to do so
(c) the product or its components have been damaged by mechanical means of
whatsoever kind, in particular broken glass
(2) All claims under this guarantee have to be notified to the retailer, from whom the
aquarium has been purchased without delay, however, not longer than 2 weeks from
the day of first occurrence of defects. Rights under the consumer protection laws will
remain unaffected.
(3) Guarantee claims will only be accepted if the validity of the claim is supported by
evidence of purchase of the JUWEL-Aquarium product.
This declaration of guarantee is a translation only. In case of doubts the original
German language version prevails.
We reserve the right to make technical alterations.
© JUWEL AQUARIUM
® JUWEL, Trigon, Vision, Rekord, Rio, Lido, Vio, Korall, Monolux, Duolux, Multilux,
Korallux, Violux, High-Lite, Warm-Lite, Colour-Lite, Day-Lite, Juwel Twin-Lite, Juwel
Eccoflow, Bioflow, Cirax, Nitrax.
4
