JURA Z7ALUM, Z7CHROME Operating Instructions
IMPRESSA Z7 Instructions for Use
The Instructions for Use has been awarded the seal of
approval by the independent German T echnical Inspection
Agency, TÜV SÜD, due to its easy-to-understand style, its
thoroughness and coverage of safety aspects.
Table of contents
Your IMPRESSA Z7
IMPORTANT SAFEGUARDS 4
Control elements 8
Important information 10
Proper use .....................................................................................................................................................10
For your safety ..............................................................................................................................................10
1 Preparing and using for the first time 13
JURA on the Internet ....................................................................................................................................13
Setting up the machine ..............................................................................................................................13
Filling the water tank ...................................................................................................................................13
Filling the bean container ...........................................................................................................................13
First-time use ................................................................................................................................................14
Inserting and activating the filter ..............................................................................................................15
Determining and adjusting the water hardness .....................................................................................16
Adjusting the grinder ..................................................................................................................................17
2 Preparation 18
Ristretto, espresso and coffee ....................................................................................................................18
Preparing two speciality coffees at the touch of a button ...................................................................18
Special coffee ................................................................................................................................................18
Latte macchiato, cappuccino .....................................................................................................................19
Hot milk and milk foam .............................................................................................................................20
Preground coffee .........................................................................................................................................20
Permanently setting the amount of water for the cup size .................................................................21
Hot water ......................................................................................................................................................22
3 Daily operation 23
Switching on ................................................................................................................................................23
Daily maintenance ......................................................................................................................................23
Switching off ................................................................................................................................................24
4 Permanent settings in programming mode 25
Products ........................................................................................................................................................26
Energy-saving mode ..................................................................................................................................28
Automatic switch-off ..................................................................................................................................29
Rinses ............................................................................................................................................................30
Rename ..........................................................................................................................................................31
Logo ...............................................................................................................................................................32
Restore factory settings .............................................................................................................................32
Viewing information and maintenance status ......................................................................................33
2
Table of contents
Unit for amount of water ...........................................................................................................................34
Language ......................................................................................................................................................34
5 Maintenance 36
Rinsing the machine ...................................................................................................................................36
Rinsing the cappuccino frother ................................................................................................................37
Cleaning the cappuccino frother ..............................................................................................................37
Dismantling and rinsing the cappuccino frother ..................................................................................38
Changing the filter ......................................................................................................................................38
Cleaning the machine ................................................................................................................................39
Descaling the machine ...............................................................................................................................41
Cleaning the bean container .....................................................................................................................43
Descaling the water tank ...........................................................................................................................43
6 Display messages 44
7 Troubleshooting 46
8 Transport and environmentally friendly disposal 48
Transport / Emptying the system .............................................................................................................48
Disposal .........................................................................................................................................................48
9 Technical data 49
10 Index 50
11 JURA contact details / Legal information 52
Symbol description
Warnings
J CAUTION
CAUTION CAUTION draws your attention to potential damage to the machine.
Symbols used
T Prompt to take action. This symbol means that you are being prompted to
E Information and tips to make it even easier to use your IMPRESSA.
@ References to the JURA website, which provides further information that may be
COFFEE
Always take note of any inf ormation marked with the words CAUTION or W ARNING
and a warning sign. The signal word WARNING draws your attention to potential
serious injury, and the signal word CAUTION to potential minor injury.
perform some action.
of interest to you: www.jura.com
Display message
READY
3
Important Safeguards
IMPORTANT SAFEGUARDS
These safeguards apply for machines with UL safety test (see rating
plate and chapter 9 ‘Technical data’).
Follow the basic safety
precautions
When using electrical appliances, basic safety precautions should
always be followed, to reduce the risk of fire, electric shock, and/or
injury to persons, including the following:
Z Read all instructions.
Z Do not touch hot surfaces. Use handles or knobs.
Z To protect against fire , electric shock and injury to persons, do
not immerse cord, plugs, or body of machine in water or other
liquid.
Z Close supervision is necessary when any appliance is used by
or near children.
Z Unplug from outlet when not in use and before cleaning.
Allow to cool before putting on or taking off parts, and before
cleaning the appliance.
Z Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions, or has been damaged in any
manner. Return appliance to the nearest authorized service
facility for examination, repair or adjustment.
Z The use of an accessory attachment not recommended by the
appliance manufacturer may result in fire, electric shock, or
injury to persons.
Z Do not use outdoors.
Z Do not let the cord hang over the edge of a table or counter,
or touch hot surfaces.
Z Do not place on or near a hot gas or electric burner, or in a
heated oven.
Z Always attach plug to appliance first, then plug cord into the
wall outlet. To disconnect, turn any control to ‘OFF’ then
remove plug from wall outlet.
Z Do not use appliance for other than intended use.
Z Use extreme caution when dispensing hot steam.
Z For household use only.
SAVE THESE INSTRUCTIONS
4
Important Safeguards
Special cord set instructions
a. A short power supply cord is provided to reduce the risk
resulting from becoming entangled in or tripping over a long
cord.
Your IMPRESSA has a 3-pin grounded plug.
b. Longer extension cords are available and may be used if care
is exercised in their use.
c. If an extension cord is used,
1. the marked electrical rating of the extension cord should be
at least as great as the electrical rating of the appliance,
and
2. if the appliance is of the grounded type, the extension cord
should be a grounding type 3-wire cord, and
3. the longer cord shall be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on
by children or tripped over.
Z As a safety feature, this plug will fit in a polarized outlet only
one way.
Z If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician.
Z Do not modify the plug in any way or attempt to defeat this
safety feature.
Warning
Caution
To reduc e the risk of fire or electric shock, do not remove any service
covers. No user serviceable parts inside. Repair should be done by
authorized personnel only.
This appliance is for household use. Any servicing other than cleaning and user maintenance should be performed by an authorized
service representative:
Z Do not immerse base in water or try to disassemble.
Z To reduce the risk of fire or electric shock, do not remove the
base. No user serviceable parts inside. Repair should be done
by authorized service personnel only.
Z Check voltage to be sure that the voltage indicated on the
name plate complies with your voltage.
Z Never use warm or hot water to fill the water container! Use
cold water only.
5
Important Safeguards
Z Keep your hands and the cord away from hot parts of the
appliance during operation.
Z Never clean with scouring powders or hard implements.
NEVER DO
(or you will void your
warranty protection):
Z Never fill instant coffee, chocolat e mix et c. int o the grinder or
ground coffee funnel (grinder by-pass). It will damage the
functioning of the brewing chamber.
Z Never fill sugar coated coffee beans into the bean hopper. In
case of doubt, call your dealer.
Z Never fill anything other than coffee beans into the bean con-
tainer (no chocolate, no rice, no nuts, no spices, nothing other
than roasted coffee beans).
Z Never do anything with the machine which is not described in
the User‘s Manual. In case of doubt, call your dealer.
6
Important Safeguards
7
Control elements
Control elements
1
2
3
4
5
6
7
Figure: IMPRESSA Z7 Aluminium
8
9
10
11
12
13
1 Bean container cover
2 Water tank cover
3 Water tank
4 Power switch and mains cable
(side view)
5 Height-adjustable cappuccino frother
6 Coffee grounds container
7 Drip tray
8
8 Grinder adjustment switch
9 Bean container with aroma preservation
cover
10 Filler funnel for preground coffee
11 Hot-water spout
12 Height- and width-adjustable coffee
spout
13 Cup platform
Control elements
231
4
1 Q On/Off button
2 g Rotary Switch
3 c Maintenance button
98765111210
4 z Milk button
5 q Latte Macchiato button
6 p Cappuccino button
7 e Special Coffee button
8 Display
9 m Hot Water button
10 u Ristretto button
11 i Espresso button
12 o Coffee button
9
Important information
Important information
Proper use
For your safety
J
The machine is designed and intended for private domestic use. It
should only be used for coffee preparation and to heat milk and
water . Use for any other purpose will be deemed improper . JURA Elektroapparate AG cannot accept any responsibility for the consequences of improper use.
Before using the machine read these instructions for use thoroughly
and completely and comply with the instructions contained. Keep
these instructions for use close to the machine and pass them on to
the next user.
Please carefully read and observe the important safety information
set out below.
To avoid danger of potentially fatal electric shock:
Never use a machine which is damaged or has a defective
U
mains cable.
In the event of signs of damage, for example if there is a smell
U
of burning, unplug the machine immediately from the mains
supply and contact JURA service.
If the mains cable of this machine is damaged, it must be
U
repaired either directly by JURA or by an authorised JURA service centre.
Make sure that the IMPRESSA and the mains cable are not
U
located close to hot surfaces.
Be careful to ensure that the mains cable is not trapped and
U
does not rub against sharp edges.
Never open and repair the machine yourself. Do not modify
U
the machine in any way that is not described in these instructions for use. The machine contains live parts. If opened, there
is a danger of potentially fatal injury. Repairs may only be car ried out by authorised JURA service centres, using original
spare parts and accessories.
10
Important information
There is a risk of scalds or burns on the spouts and the cappuccino
frother.
Place the machine out of the reach of children.
U
Do not touch any hot parts. Use the handles provided.
U
Ensure that the cappuccino frother is correctly fitted and
U
clean. If incorrectly fitted or if they become blocked, the cappuccino frother or its parts might come off.
A defective machine is not safe and could cause injury or fire. To
avoid damage and any associated risk of injury or fire:
Never allow the mains cable to loosely hang down. The mains
U
cable could pose a tripping hazard or become damaged.
Protect the IMPRESSA from environmental influences such as
U
rain, frost and direct sunlight.
Do not immerse the IMPRESSA, cables or connections in
U
water.
Do not put the IMPRESSA or any individual parts in the dish-
U
washer.
Switch your IMPRESSA off at the power switch before any
U
cleaning operation. Always wipe the IMPRESSA with a damp
cloth rather than a wet one, and protect it from prolonged
exposure to water splash.
Only connect the machine to the mains voltage in accordance
U
with the information on the rating plate. The rating plate is
located on the underside of your IMPRESSA. Further technical
data is provided in these instructions for use (see Chapter 9
‘Technical data’).
Please only use original JURA maintenance products. Use of
U
products that are not explicitly recommended by JURA could
damage the IMPRESSA.
Do not use any coffee beans treated with additives or caramel-
U
ised coffee beans.
Only fill the water tank with fresh, cold water.
U
Switch the machine off at the power switc h if you are going to
U
be absent for a longer period of time.
11
Important information
People, including children, who
do not have the physical, sensory or mental capabilities to use
U
the machine safely or
are inexperienced or lack knowledge in how to use the machine
U
safely
must be supervised by a responsible person when using it, or must
be instructed in how to use it correctly.
Safety when handling the CLARIS Blue filter cartridge:
Filter cartridges should be kept out of the reach of children.
U
Store filter cartridges in a dry place in the sealed packaging.
U
Protect cartridges from heat and direct sunlight.
U
Do not use damaged cartridges.
U
Do not open filter cartridges.
U
12
1 Preparing and using for the first time
1 Preparing and using for the first time
JURA on the Internet
Setting up the machine
Filling the water tank
CAUTION
Visit us on the internet.
@ You can download short operating instructions for your
machine from the JURA website www.jura.com. You will also
find interesting and up-to-date information on your IMPRESSA
and on every aspect of coffee.
@ You can familiarise yourself with your IMPRESSA in a fun
way on the PC. The Knowledge Builder awaits you at
www.jura.com. The interac tive assistant, LEO, will assist you
and explain the benefits of and how to use your IMPRESSA.
When setting up your IMPRESSA, please note the following:
Place the IMPRESSA on a horizontal surface that is not sensi-
U
tive to water.
Choose a spot for your IMPRESSA which prot ects the machine
U
against overheating. Ensure that the ventilation slots are not
covered.
To enjoy the perfect cup of coffee we recommend changing the
water every day.
Milk, mineral water or other liquids can damage the water tank or
the machine.
T Only fill the water tank with fresh, cold water.
Filling the bean container
CAUTION
T Open the water tank cover.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Close the water tank cover.
The bean container has an aroma preservation cover . This will ensure
that your coffee beans retain their aroma for longer.
Coffee beans which have been treated with additives (e.g. sugar),
preground coffee or freeze-dried coffee will damage the grinder.
T Only use untreated coffee beans to refill the bean container.
13
1 Preparing and using for the first time
First-time use
J
WARNING
T Open the bean container cover and remove the aroma pres-
ervation cover.
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans, then close the
aroma preservation cover and the bean container cover.
If the machine is operated with a defective mains cable, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged or has a defective
mains cable.
Precondition: The water tank and bean container are full.
T Insert the mains plug into a power socket.
3 T Switch on the IMPRESSA using the power switch on the left-
hand side of the machine.
Q T Press the On/Off button to switch the IMPRESSA on.
The Rotary Switch lights up.
appears on the display.
g T Turn the Rotary Switch until the required language is dis-
played, for example
k T Press the Rotary Switch to confirm the language.
LANGUAGE ENGLISH.
SPRACHE DEUTSCH
CONFIRMED appears briefly on the display to confirm the
setting.
PRESS RINSE, the Maintenance button c lights up.
c T Press the Maintenance button.
SYSTEM FILLS, the system fills up with water . The oper -
ation stops automatically and
appears on the display.
WELCOME TO JURA
UNIT IS HEATING
PRESS RINSE, the Maintenance button c lights up.
T Place a receptacle under the coffee spout.
c T Press the Maintenance button.
RINSING, the machine rinses. The operation stops auto-
matically.
COFFEE READY appears on the display. Your IMPRESSA
is ready for use.
14
1 Preparing and using for the first time
Inserting and activating
the filter
Your IMPRESSA no longer has to be descaled if you are using the
CLARIS Blue filter cartridge.
E Perform the ‘inserting the filter’ operation without any inter-
ruptions. This will ensure that your IMPRESSA alwa ys produces
its best.
Precondition:
k T Press and hold the Rotary Switch until
g T Turn the Rotary Switch until
k T Press the Rotary Switch to enter the programme item.
COFFEE READY is displayed.
MAINTENANCE
appears on the display.
FILTER is displayed.
FILTER NO
g T Turn the Rotary Switch until FILTER YES is displayed.
k T Press the Rotary Switch to confirm the setting.
CONFIRMED appears briefly on the display.
INSERT FILTER / PRESS BUTTON, the Mainte-
nance button c lights up.
T Remove the filter cartridge extension from the Welcome
Pack.
T Fit the filter extension on top of a CLARIS Blue filter car-
tridge.
T Remove and empty the water tank.
T Open the filter holder and insert the filter cartridge into the
water tank, exerting slight pressure.
T Close the filter holder. It will click into place audibly.
E After two months, the filter will cease to work. You can check
the elapsed time by referring to the date plate on the filter
holder in the water tank.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Place a receptacle (at least 500 ml) under the cappuccino
frother.
c T Press the Maintenance button.
FILTER RINS.. Water flows out of the cappuccino
frother.
15
1 Preparing and using for the first time
E You can interrupt rinsing of the filter at any time by pressing
any button. Press the Maintenance button c to continue rins-
ing of the filter.
E The water may be slightly discoloured. This is not harmful to
health and does not affect the taste.
Rinsing of the filter stops automatically after approximately
500 ml.
COFFEE READY appears on the display. The filter
is activated.
Determining and
adjusting the water
hardness
Determining the water
hardness
Adjusting the water
hardness
E If you are using the CLARIS Blue filter cartridge and have acti-
vated it in programming mode, you will not be able to adjust
the water hardness.
The harder the water is, the more frequently the IMPRESSA needs to
be descaled. It is therefore important to adjust the water hardness.
The water hardness can be adjusted on a continuous scale between
1° dH and 30° dH. It can also be deactivated, which means that the
IMPRESSA will not let you know when it has to be descaled.
You can find out what the w at er hardness is by using the Aquadur®
test strip supplied as standard.
T Hold the test strip briefly (for one second) under flowing
water. Shake off the water.
T Wait for about one minute.
T You will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
You can now adjust the water hardness.
Example: Proceed as follows to change the water hardness from
16°dH to 25°dH.
Precondition:
k T Press and hold the Rotary Switch until
g T Turn the Rotary Switch until
k T Press the Rotary Switch to enter the programme item.
COFFEE READY is displayed.
MAINTENANCE
appears on the display.
HARDNESS is displayed.
HARDNESS 16°dH
16
Loading...
