JMA-5912-6 JMA-5922-7/9

◆◆◆PRECAUTIONS BEFORE OPERATION◆◆◆

■Cautions for high voltage

High voltages from hundreds volts to tens of thousands volts are to be applied to the electronic
equipment such radio and radar devices. You do not face any danger during normal operation,
but sufficient cares are required for maintenance, inspection and adjustment of their internal
components. (Maintenance, check-up and adjustment of the inside of the equipment are prohibited
except by maintenance specialists.)
High voltages of tens of thousands volts are so dangerous as to bring an instantaneous death from
electric shock, but even voltages of hundred volts may sometimes lead to a death from electric
shock. To prevent such an accident, make it a rule to turn off the power switch, discharge
capacitors with a wire surely earthed on an end make sure that internal parts are no longer charged
before you touch any parts inside these devices. At the time, wearing dry cotton gloves ensures
you further to prevent such danger. It is also a necessary caution to put one of your hands in the
pocket and not to use your both hands at the same time.
It is also important to select a stable foothold always to prevent additional injuries once you were
shocked by electricity. If you were injured from electric shock, disinfect the burn sufficiently
and get it taken care of promptly.

■What to do in case of electric shock

When finding a victim of electric shock, turn off the power source and earth the circuit
immediately.
If it is impossible to turn off the circuit, move the victim away promptly using insulators such as
dry wood plate and cloth without touching the victim directly.
In case of electric shock, breathing may stop suddenly if current flows to the respiration center in
the brain. If the shock is not so strong, artificial respiration may recover breathing. When
shocked by electricity, the victim will come to look very bad with weak pulse or without beating,
resulting in unconsciousness and rigidity. In this case, it is necessary to perform an emergency
measure immediately.

◆◆◆FIRST-AID TREATMENTS◆◆◆

☆First-aid treatments

As far as the victim of electric shock is not in dangerous condition, do not move him and practice
artificial respiration on him immediately. Once started, it should be continued rhythmically.

(1) Do not touch the victim confusedly as a result of the accident, but the rescuer may also get an

electric shock.

(2) Turn off the power source calmly and move the victim away quietly from the electric line.

(3) Call a physician or ambulance immediately or ask someone to call a doctor.

(4) Lay the victim on this back and loosen his necktie, clothes, belt, etc.

(5) a. Examine the victim’s pulse.
b. Examine his heartbeat bringing your ear close to his heart.
c. Examine his breathing bringing the back of your hand or your face close to his face.
d. Check the size of the pupils of his eyes.

(6) Open the victim’s mouth and take out artificial teeth, cigarette or chewing gum if any.

Keep his mouth open, stretch his tongue and insert a towel or the like in his mouth to prevent
the tongue from suffocating. (If it is hard to open his mouth due to set teeth, open it with a
screwdriver and insert a towel in this mouth.)

(7) Then, wipe his mouth so that foaming mucus does not accumulate inside.

☆When pulse is beating but breathing has stopped

(Mouth-to-mouth respiration) Fig. 1

(1) Tilt the victim’s head back as far as this face looks back. (A pillow may be inserted his neck.)
(2) Push his jaw upward to open his throat wide (to spread his airway).
(3) Pinch the victim’s nostrils and take a deep breath, block his mouth completely with yours

and blow into his mouth strongly. Take a deep breath again and blow into his mouth.
Continue this 10 to 15 times a minutes (blocking his nostrils).

(4) Carefully watch that he has recovered his natural breathing and atop practicing artificial

respiration.

(5) If it is difficult to open the victim’s mouth, insert a rubber or vinyl tube into one of his

nostrils and blow into it blocking the other nostril and his mouth completely.

(6) When the victim recovers consciousness, he may try to stand up suddenly, but let him lie

calmly and serve him with a cup of hot coffee or tea and keep him warm and quiet. (Never
give him alcoholic drinks.)

Method of mouth-to-mouth respiration by raising head

(1) Raise the victim’s head. Support his

forehead with one of your hand and his
neck with the other hand. →1

When you tilt his head backward, the

victim, in most cases, opens his mouth to
the air. This makes mouth-to mouth
respiration easy.

(2) Cover his mouth as widely as possible with

yours and press your cheek against his nose
→2

or, pinch his nostrils with your fingers to

prevent air from leaking. →3

(3) Blow into his lungs. Continue blowing

into his mouth until his breast swells.
Blow into his mouth as quickly as possible
for the first 10 times.

Fig. 1 Mouth-to mouth respiration

☆When both pulse and breathing have stopped

Perform the (Cardiac massage) Fig. 2 and (Mouth-to-mouth respiration) Fig. 1

When no pulse has come not to be felt, his pupils are open and no heartbeat is heard, cardiac arrest
is supposed to have occurred and artificial respiration must be performed.

(1) Place your both hands, one hand on the other, on the lower one third area of his breastbone

and compress his breast with your elbows applying your weight on his breast so that it is
dented about 2cm (Repeat compressing his breast 50 times or so a minutes). (Cardiac
massage)

(2) In case of one rescuer,
Repeat cardiac massages about 15 times and blow into his mouth 2 times quickly, and repeat

this combination.
In case of two rescuers,
One person repeats cardiac massages 15 times while the other person blow into his mouth

twice, and they shall repeat this combination. (Perform the cardiac massage and

mouth-to-mouth respiration)

(3) Examine his pupils and his pulse sometimes. When the both have returned to normal, stop

the artificial respiration, serve him with a cup of hot coffee or tea and keep him warm and

calm while watching him carefully. Commit the victim to a medical specialist depending

on his condition. (Never give him alcoholic drinks.) To let him recover from the mental

shock, it is necessary for persons concerned to understand his situations and the necessary

treatment.

Fig. 2 Cardiac massage

PREFACE

Thank you very much for purchasing the JRC marine radar equipment, JMA-5900 series.
This equipment is a marine radar equipment designed to obtain safe operation of marine ships.
This equipment consists of a radar signal transmitter-receiver unit, a LCD display unit and a scanner unit as
its main units.

● Before operating the equipment, be sure to read this instruction manual carefully for correct operation.

● Maintain this instruction manual so that operators can refer to it at anytime.

Refer to this manual when any inconvenience or defect occurs.

- i -

●Before Operation●

Pictorial Indication

Various pictorial indications are included in this manual and are shown on these equipment so that you can
operate them safety and correctly and prevent any danger to you and/or to other persons and any damage to
your property during operation. Such indications and their meanings are as follows.
Please understand them before you read this manual:

DANGER

WARNING

CAUTION

This indication is shown where incorrect equipment operation due to
negligence may cause death or serious injuries.

This indication is shown where any person is supposed to be in
danger of being killed or seriously injured if this indication is
neglected and these equipment are not operated correctly.

This indication is shown where any person is supposed to be injured
or any property damage is supposed to occur if this indication is
neglected and these equipment are not operated correctly.

Examples of Pictorial Indication

The U mark represents CAUTION (including DANGER and WARNING).

Electric Shock

Disassembling

Prohibited

Prohibited

Detailed contents of CAUTION (“Electric Shock” in the example on the
left.) is shown in the mark.

The  mark represents prohibition.
Detailed contents of the prohibited action (“Disassembling Prohibited” in the
example on the left.) is shown in the mark.

plug

Instruction

Disconnect

the power

Warning Label

There is a warning label on the top cover of the equipment.
Do not try to remove, break or modify the label.

The  mark represents instruction.
Detailed contents of the instruction (“Disconnect the power plug “ in the
example on the left.) is shown in the mark.

- ii -

●PRECAUTIONS●

DANGER

Never carry out internal inspection or repair work of the
equipment by users.

Inspection or repair work by uncertified personnel may
result in fire hazard or electrocution.

For inspection and repair work of equipment components,
consult with our branch office, branch shop, sales office,
or our distributor in your district.

When conducting maintenance, make sure to turn the main
power off.

Failure to comply may result in electrocution.

Turn off the main power before cleaning the equipment.
Especially when a rectifier is used, make sure to turn it off
since voltage is still outputted from the rectifier even after
the indicator and the radar are turned off. Failure to comply
may result in equipment failure, or death or serious injury
due to electric shock.

When conducting maintenance work on the scanner, make
sure to turn its main power off.

Failure to comply may result in electrocution or injuries.

Make sure to turn off the scanner safety switch. Failure to
comply may result in injuries caused by physical contact
with the rotating scanner.

Do not touch the radiator. Even if the power is turned off,
the radiator may be rotated by the wind.

- iii -

WARNING

Never directly touch the internal components of the
scanner or indicator. Direct contact with these high-voltage
components may cause electrocution. For maintenance,
inspection, or adjustment of equipment components,
consult with our branch office, branch shop, sales office,
or our distributor in your district.

To contact our sales department, branch offices, branch
shops, and sales offices:

Please refer to the "Office List" at the end of the document.

Do not get close to the radiant section of the scanner. It is
a rotating part, and it may cause injuries if it suddenly
starts rotating and consequently hits the body. It is
recommended that the radiant section be installed at a high
place such as on the roof of the wheelhouse, on the flying
bridge, on the trestle, or on the radar mast so that no one
can get close to it. When any work must be done on the
scanner, make sure to turn the safety switch off.

Microwave radiation level:
Keep out from a distance closer than that specified below

for each type of scanner when it is transmitting. Being
within the specified distance from the center of the front
face of the scanner may cause microwave exposure which
could result in injuries (especially of the eyes).

50W/m

NKE-2103 n/a 26cm 123cm

NKE-2254 5cm 81cm 162cm

NKE-1130 11cm 76cm 181cm

Make sure to install the scanner at a place higher than
human height.

Direct exposure to electromagnetic waves at close range
will have adverse effects on the human body.

2

10W/m2 2.5W/m2

- iv -

WARNING

Do not change MBS Level/Area unless absolutely
necessary.

Incorrect adjustment will result in deletion of nearby target
images and thus collisions may occur resulting in death or
serious injuries.

When cleaning the display screen, do not wipe it too
strongly with a dry cloth. Also, do not use gasoline or
thinner to clean the screen. Failure to comply will result in
damage to the screen surface.

Direct exposure to electromagnetic waves at close range
will have adverse effects on the human body. When it is
necessary to get close to the scanner for maintenance or
inspection purposes, make sure to turn the indicator power
switch to "OFF" or "STBY."

Direct exposure to electromagnetic waves at close range
will have adverse effects on the human body.

When conducting maintenance work, make sure to turn off
the power and unplug the power connector J1 of the radar
process unit so that the power supply to the equipment is
completely cut off.

Some equipment components can carry electrical current
even after the power switch is turned off, and conducting
maintenance work without unplugging the power
connector may result in electrocution, equipment failure, or
accidents.

When disposing of used lithium batteries, be sure to
insulate the batteries by attaching a piece of adhesive tape
on the + and - terminals. Failure to comply may cause
heat generation, explosion, or fire when the batteries get
shorted out.

- v -

CAUTION

A malfunction may occur if the power in the ship is
instantaneously interrupted during operation of the radar.
In this case, the power should be turned on again.

Normally, use the automatic tune mode.
Use the manual tune mode only when best tuning is not

possible in the automatic tune mode due to deterioration of
magnetron.

If the gain is too high, unnecessary signals including
receiver noise and false video increase resulting in
reduction of visibility of targets.

On the contrary, if the gain is too low, targets including
ships and dangerous objects may not be clearly indicated.

When using the sea clutter suppression function, never set
the suppression level too high canceling out all image
noises from the sea surface at close range.

Detection of not only echoes from waves but also targets
such as other ships or dangerous objects will become
inhibited.

When using the sea clutter suppression function, make
sure to choose the most appropriate image noise
suppression level.

When using the rain / snow clutter suppression function,
never set the suppression level too high canceling out all
image noises from the rain or snow at the close range.

Detection of not only echoes from the rain or snow but also
targets such as other ships or dangerous objects will
become inhibited.

When using the rain / snow clutter suppression function,
make sure to choose the most appropriate image noise
suppression level.

- vi -

CAUTION

Use the radar only as a navigation aid.
The final navigation decision must always be made by the

operator him/herself.
Making the final navigation decision based only on the

radar display may cause accidents such as collisions or
running aground.

Use target tracking function only as a navigation aid. The
final navigation decision must always be made by the
operator him/herself.

Making the final navigation decision based only on
tracking target information may cause accidents.

Tracking target information such as vector, target
numerical data, and alarms may contain some errors. Also,
targets that are not detected by the radar cannot be
acquired or tracked.

Making the final navigation decision based only on the
radar display may cause accidents such as collisions or
running aground.

In setting an automatic acquisition zone, it is necessary to
adjust the gain, sea clutter suppression and rain clutter
suppression to ensure that target echoes are displayed in
the optimum conditions. No automatic acquisition zone
alarms will be issued for targets undetected by the radar,
and this may cause accidents such as collisions.

Target Tracking Function Test is provided to test if the
target tracking function is operating normally. Thus, do not
use the function except when you test the target tracking
function.

In particular, if the operation test mode is used during
navigation, pseudo targets appear on the radar display and
they are confused with actual targets.

Do not use the mode during navigation.
Otherwise, an accident may result.

- vii -

CAUTION

If a great value is set as a condition for deciding targets as
identical, a tracking target near an AIS target is regarded as
identical to the AIS target and it may not be displayed any
more.

For example, when a pilot boat (which is a small target not
being tracked) equipped with an AIS function approaches a
cargo ship as a tracking target not equipped with an AIS
function, the tracking target symbol of the cargo ship may
not be displayed any more.

Since these alarms may include some errors depending on
the target tracking conditions, the navigation officer
himself should make the final decision for ship operations
such as collision avoidance.

Making the final navigation decision based only on the
alarm may cause accidents such as collisions.

Any adjustments must be made by specialized service
personnel.

Incorrect settings may result in unstable operation.

Do not make any adjustments during navigation. Failure to
comply may result in adverse effects on the radar function
which may lead to accidents or equipment failure.

Optimal values have been set for Video Level and Vector
Constant; therefore, never change their values unless
absolutely necessary. Failure to comply may result in
accidents that would lower target tracking performance.

Do not change the quantization level settings unless
absolutely necessary. If set at an inappropriate value, the
target acquisition or target tracking function deteriorates,
and this may lead to accidents.

- viii -

CAUTION

Any adjustments must be made by specialized service
personnel.

Failure to comply may result in accidents or equipment
failure.

Make sure to shut off the main power before replacing
parts. Failure to comply may result in electrocution or
equipment failure.

When replacing magnetrons, make sure to shut off the
main power and let the equipment stand for more than 5
minutes to discharge the high-voltage circuit. Failure to
comply may result in electrocution.

Make sure to take off your watch when your hand must get
close to the magnetron.

Failure to comply may result in damage to the watch since
the magnetron is a strong magnet.

Make sure that two or more staff member work together
when replacing the LCD. If only one person attempts to
replace the LCD, he/she may drop it and become injured.

Do not directly touch the inverter circuit of the LCD display
with a bare hand since high voltage temporarily remains in
the circuit even after the main power is shut off.

Failure to comply may result in electrocution.

- ix -

The Mounting Point of the Warning Label

Warning Label

NCD-1477 Radar Process Unit

Warning Label

Front face Back face

NWZ-170 Monitor

Unit(Option)

- x -

Warning Label

NKE-2103-6 Scanner Unit

Warning Label

NKE-2254-7/9 Scanner Unit

- xi -

Warning

Label

NQE-3151A Junction Box

Warning

Label

NKE-1130 Scanner Unit

- xii -

Warning Label

NQE-3141-4A/8A Interswitch Unit

Warning Label

NBA-5111 Power Supply

- xiii -

Warning

Label

NQE-3167 Power Control Unit

- xiv -

EQUIPMENT APPEARANCE

Scanner Unit Type NKE-1130 (12 feet)

Scanner Unit Type NKE-2103-6 (6 feet)

Scanner Unit Type NKE-2254-7 (7 feet)

- xv -

Scanner Unit Type NKE-2254-9 (9 feet)

NDC-1477 Radar Process Unit (Desktop Type)

- xvi -

NWZ-170 Monitor Unit (Desktop Type)

NCE-5171 Operation Unit (Desktop Type)

- xvii -

GLOSSARY

This section describes the main terms used for this equipment and general related maritime terms.

A

AZ

Activated target

AIS

Anti-clutter rain

Anti-clutter sea

Associated target

AZI

Acquisition/Activation zone
A zone set up by the operator in which the system should
automatically acquire radar targets and activate reported AIS targets
when entering the zone.

A target representing the automatic or manual activation of a sleeping
target for the display of additional information.

Automatic Identification System
A system which enables ships and shore stations to obtain identifying
and navigation information about other ships at sea, using an
automated transponder.

Rain/snow clutter suppression.

Sea clutter suppression.

A target simultaneously representing a tracked target and a reported
AIS target having similar parameters (position, course, speed) which
comply with an association algorithm.

AZImuth stabilization mode

BCR/BCT

C up

CCRP

Clutter

B

Bow Crossing Range and Bow Crossing Time

C

Course up
Own ship’s course is pointed to the top center of the radar display.

The Consistent Common Reference Point
A location on own ship, to which all horizontal measurements such as
target range, bearing, relative course, relative speed, CPA or TCPA
are referenced, typically the conning position of the bridge.

Unwanted reflections on a radar screen, from sea surface, rain or
snow.

- xviii -

COG

CORREL

CPA/TCPA

CTW

DRIFT

EBL

ETA

Ground
stabilization

HDG

HL

HSC

H up

Course Over Ground
The direction of the ship's movement relative to the earth, measured
on board the ship, expressed in angular units from true north

CORRELation

The distance to the Closest Point of Approach and Time to the
Closest Point of Approach. Limits are set by the operator and are
related to own ship.

Course Through Water
The direction of the ship's movement through the water

D

The current velocity for manual correction or the current speed on the
horizontal axis of the 2-axis log is displayed.

E

Electronic Bearing Line
An electronic bearing line originated from own ship’s position.

Estimated Time of Arrival

G

A display mode in which speed and course information are referred to
the ground, using ground track input data.

H

Heading
The horizontal direction that the bow of a ship is pointing at any
instant, expressed in angular units from a reference direction .

Heading line
A graphic line on a radar presentation drawn from the consistent
common reference point to the bearing scale to indicate the heading
of the ship

Vessels which comply with the definition in SOLAS for high speed
craft

Head up
Own ship’s heading line is always pointed to the top center of the
radar display.

IMO

Interswitch Unit

International Maritime Organization

A device to switch over two or more radar display units and two or
more scanners.

I

- xix -

IR

ISW

Lost AIS target

Lost tracked target

LP

MMSI

MOB

MON

MP

nm

N up

Own track

PI

Past positions

POSN

PRF

PROC

Radar beacon

radar Interference Rejecter

InterSWitch

L

A target symbol representing the last valid position of an AIS target
before the reception of its data was lost, or its last dead-reckoned
position.

One for which target information is no longer available due to poor,
lost or obscured signals.

Long Pulse

M

Maritime Mobile Service Identity

Man OverBoard

Performance monitor

Medium Pulse

N

1nm=1852m

North up
The north is always pointed to the top center of the radar display.

O

Display function of own ship’s track

P

Parallel Index line

Equally time-spaced past position marks of a tracked or AIS target
and own ship.

POSitioN

Pulse Repetition Frequency
The number of radar pulses transmitted each second.

PROCess
Radar signal processing function

R

A navigation aid which responds to the radar transmission by
generating a radar signal to identify its position and identity

- xx -

Radar cross-section

Range Rings

Reference target

Relative course

Relative speed

Relative vector

RM

RM(R)

RM(T)

ROT

Route

RR

SART

Sea stabilization

Sea state

SET

Sleeping AIS target

Radar cross-section of a target determines the power density returned
to the radar for a particular power density incident on the target

A set of concentric circles labeled by distance from CCRP.

A symbol indicating that the associated tracked stationary target is
used as a speed reference for the ground stabilization

The direction of motion of a target relative to own ship motion

The speed of a target relative to own ship’s speed data

A predicted movement of a target relative to own ship’s motion

Relative Motion
A display on which the position of own ship remains fixed, and all
targets move relative to own ship.

Relative Motion. Relative Trails.

Relative Motion. True Trails.

Rate Of Turn
Change of heading per time unit.

A set of waypoints.

Range Rings

S

Search And Rescue Transponder
Radar transponder capable of operating in the 9GHz band

A display mode in which speed and course information are referred to
the sea.

Status of the sea condition due to the weather environment, expressed
as a sea state 0 for flat conditions with minimal wind, to sea state 8
for very rough sea conditions.

The current direction for manual correction or the current speed on
the horizontal axis of the 2-axis log is displayed.

A target indicating the presence and orientation of a vessel equipped
with AIS in a certain location.

- xxi -

SOG

SP

STAB

STW

TCPA

Test target

TM

Trails

Trial maneuver

True course

True speed

True vector

TT

TTG

TXRX

UTC

Speed Over the Ground
The speed of the ship relative to the earth, measured on board of the
ship.

Short Pulse

STABilization

Speed Through Water
The speed of the ship relative to the water surface.

T

Time to Closest Point of Approach to own ship

Radar target of known characteristics used for test requirement

True Motion
A display across which own ship moves with its own true motion.

Tracks displayed by the radar echoes of targets in the form of an
afterglow.

A graphical simulation facility used to assist the operator to perform a
proposed maneuver for navigation and collision avoidance purposes.

The direction of motion relative to ground or to sea, of a target
expressed as an angular displacement from north

The speed of a target relative to ground, or to sea

A vector representing the predicted true motion of a target, showing
course and speed with reference to the ground or sea

Target Tracking.
A computer process of observing the sequential changes in the
position of a radar target in order to establish its motion. Such a
target is a Tracked Target.

Time To Go.
Time to next waypoint.

Transceiver Unit

U

Universal Time Coordinated.
The international standard of time, kept by atomic clocks around the
world.

- xxii -

VRM

Waypoint

V

Variable Range Marker
An adjustable range ring used to measure the distance to a target.

W

A geographical location on a route indicating a event.

- xxiii -

CONTENTS

PREFACE............................................................................................................... i

BEFORE OPERATION.......................................................................................... ii

PRECAUTIONS.................................................................................................... iii

The Mounting Point of the Warning Label ........................................................ ix

EQUIPMENT APPEARANCE............................................................................. xiv

GLOSSARY....................................................................................................... xvii

1. GENERAL AND EQUIPMENT COMPOSITION

1.1 FUNCTIONS.............................................................................................. 1-1

1.1.1 FUNCTION OF THIS SYSTEM ............................................................ 1-1

1.2 FEATURES ............................................................................................... 1-2

1.3 CONFIGURATION .................................................................................... 1-4

1.4 OUTSIDE DRAWINGS.............................................................................. 1-6

1.5 GENERAL SYSTEM DIAGRAMS ........................................................... 1-20

2. NAMES AND FUNCTIONS OF CONTROL PANEL KEYS
AND FUNCTIONS OF SOFTWARE BUTTONS

2.1 NAMES OF DISPLAY................................................................................ 2-1

2.2 NAMES AND FUNCTIONS OF CONTROL PANEL KEYS ...................... 2-10

2.3 FUNCTIONS OF SOFTWARE BUTTONS ............................................... 2-15

3. BASIC OPERATION

3.1 OPERATION FLOW .................................................................................. 3-1

3.1.1 POWER ON AND START THE SYSTEM ............................................. 3-2

3.1.2 OBSERVE AND ADJUST VIDEO......................................................... 3-3

3.1.3 ACQUIRE AND MEASURE DATA........................................................ 3-3

3.1.4 DISPLAY AND MEASURE WITH REFERENCE TO CCRP.................. 3-3

3.1.5 END THE OPERATION AND STOP THE SYSTEM.............................. 3-4

3.2 OBSERVE AND ADJUST VIDEO ............................................................. 3-5

3.2.1 ADJUST

MONITOR BRILLIANCE [BRILL] ......................................... 3-5

3.2.2 CHANGE OBSERVATION RANGE [RANGE + / - ] .............................. 3-5

3.2.3 TUNE ................................................................................................... 3-6

3.2.4 ADJUST GAIN [GAIN / PL].................................................................. 3-7

3.2.5 SUPPRESS SEA CLUTTER [AUTO-SEA] .......................................... 3-7

3.2.6 SUPPRESS RAIN / SNOW CLUTTER [AUTO-RAIN].......................... 3-9

3.2.7 RESET ALARM BUZZER [ALARM ACK].......................................... 3-10

3.3 OPERATION PROCEDURES ..................................................................3-11

3.3.1 MOVE CROSS CURSOR MARK BY TRACKBALL............................3-11

3.3.2 OPERATE SOFTWARE BUTTONS................................................... 3-12

3.3.3 BASIC MENU OPERATION ............................................................... 3-13

3.3.4 OPERATION ON NUMERIC VALUE, LATITUDE / LONGITUDE

AND CHARACTER INPUT MENU.................................................... 3-15

3.3.5 OVERVIEW OF MENU STRUCTURE ................................................ 3-19

3.3.6 OPERATE MULTI-DIAL [MULTI] ....................................................... 3-19

3.4 GENERAL RADAR OPERATION ........................................................... 3-21

3.4.1 INTERFERENCE REJECTION (IR) ................................................... 3-21

3.4.2 SWITCH TRANSMITTER PULSE LENGTH [GAIN / PL] ................... 3-22

3.4.3 TARGET ENHANCE (ENH) ............................................................... 3-23

3.4.4 USE VIDEO PROCESSING (PROC).................................................. 3-24

3.4.5 SWITCH AZIMUTH DISPLAY MODE [AZI MODE] ............................ 3-25

3.4.6 SWITCH TRUE / RELATIVE MOTION DISPLAY MODE [TM / RM].... 3-26

3.4.7 MOVE OWN SHIP’S DISPLAY POSITION [OFF CENT] .................... 3-27

3.4.8 DISPLAY RADAR TRAILS [TRAILS]................................................. 3-28

3.4.9 ERASE PART OF RADAR TRAILS (TRAILS ERASE) ...................... 3-30

3.4.10 OPERATE RADAR TRAILS FILE (FILE OPERATIONS) ................... 3-31

3.4.11 ZOOM (X2) ......................................................................................... 3-33

3.4.12 HIDE / DISPLAY RANGE RINGS (RR / HL) ....................................... 3-33

3.4.13 HIDE GRAPHICS INFORMATION ON RADAR DISPLAY

(DATA OFF) ...................................................................................... 3-34

3.4.14 SWITCH DAY / NIGHT MODE [DAY / NIGHT].................................... 3-34

3.4.15 ADJUST OPERATION PAN E L BRILLIANCE [PANEL]..................... 3-34

3.4.16 SET TRUE BEARING (GYRO SETTING) .......................................... 3-35

3.4.17 SET OWN SHIP SPEED..................................................................... 3-35

3.4.18 MAGNET COMPASS CORRECTION (MAG COMPASS SETTING).. 3-36

3.4.19 SET DRIFT CORRECTION (SET / DRIFT SETTING)......................... 3-37

3.4.20 GPS RECEIVER SETTING (GPS PROCESS SETTING) ................... 3-38

3.4.21 DGPS RECEIVER SETTING (DGPS SETTING) ................................ 3-42

3.4.22 SBAS RECEIVER SETTING (SBAS SETTING)................................. 3-43

3.4.23 DISPLAYING GPS RECEPTION STATUS (GPS STATUS) ................ 3-46

3.4.24 SET RADAR ALARM (RADAR ALARM) ........................................... 3-47

3.5 USE OWN SHIP'S TRACK DATA............................................................ 3-49

3.5.1 DISPLAY OWN SHIP’S TRACK (DISPLAY OWN TRACK)................ 3-49

3.5.2 SAVE OWN SHIP'S TRACK DATA (OWN TRACK MEMORY)........... 3-50

3.5.3 CANCEL SAVING OF OWN SHIP’S TRACK DATA

(OWN TRACK MEMORY)................................................................. 3-50

3.5.4 CLEAR OWN SHIP’S TRACK DATA (CLEAR OWN TRACK) ........... 3-50

3.5.5 OPERATE OWN SHIP'S TRACK FILES (FILE OPERATIONS) ......... 3-51

3.6 DISPLAY USER MAP.............................................................................. 3-54

3.6.1 CREATE USER MAP (MARK / LINE) ................................................. 3-54

3.6.2 SET USER MAP DISPLAY (MARK DISPLAY SETTING)................... 3-57

3.6.3 EDIT USER MAP (EDIT USER MAP)................................................. 3-60

3.6.4 EDIT MARK / LINE LIST (MARK / LINE LIST) ................................... 3-66

3.6.5 CORRECT POSITION ON USER MAP (SHIFT USER MAP) ............. 3-72

3.6.6 OPERATE USER MAP FILE (FILE OPERATIONS) ........................... 3-73

3.6.7 SET AND DISPLAY GEODETIC SYSTEM (GEODETIC) ................... 3-77

3.7 USE ROUTE FUNCTION ........................................................................ 3-78

3.7.1 DISPLAY DESTINATION MARK (NMEA WAYPOINT DISPLAY)....... 3-78

3.8 APPLIED OPERATIONS......................................................................... 3-79

3.8.1 SET RADAR SIGNAL PROCESSING (PROCESS SETTING)........... 3-79

3.8.2 SET RADAR TRAILS (RADAR TRAILS SETTING) ........................... 3-81

3.8.3 SET SCANNER UNIT (TXRX SETTING)............................................ 3-83

3.8.4 SET CURSOR (CURSOR SETTING) ................................................. 3-84

3.8.5 SET RADAR DISPLAY (DISPLAY SETTING) .................................... 3-85

3.8.6 ADJUST SOUND VOLUME (BUZZER VOLUME) ............................. 3-87

3.8.7 SET USER KEYS [USER KEY 1 / 2]................................................... 3-88

3.8.8 SET NAVIGATION DATA DISPLAY (MULTI WINDOW SETTING) ..... 3-90

3.9 USE FUNCTION KEY [FUNC]................................................................. 3-94

3.9.1 OPERATION PROCEDURES [FUNC] ............................................... 3-94

3.9.2 FUNCTION SETTING MENU ITEMS (USER FUNCTION SETTING) . 3-95

3.9.3 OVERVIEW OF FUNCTION OPERATIONS

(USER FUNCTION SETTING).......................................................... 3-96

3.9.4 OVERVIEW OF SAVED FUNCTION SETTING DATA ........................ 3-99

3.10 USE USER SETTING ............................................................................ 3-100

3.10.1 SAVE OPERATING STATE (SAVE USER SETTING) ...................... 3-100

3.10.2 LOAD OPERATING STATE (LOAD USER SETTING) ..................... 3-101

3.10.3 DELETE OPERATING STATE (DELETE USER SETTING) ............. 3-101

3.11 USING CARD........................................................................................ 3-102

3.11.1 OPERATE

FILE ON THE CARD (FILE MANAGER) ........................ 3-102

3.12 DISPLAY SIMPLE CHART.................................................................... 3-108

3.12.1 DISPLAY JRC COASTLINE ROM CARD [MAP] ............................. 3-108

3.12.2 DISPLAY ERC CARD [MAP] ........................................................... 3-108

3.12.3 DISPLAY JRC CHART ON CF CARD (SEL JRC ROM CARD FILE) 3-109

3.12.4 FILL CHARTS (FILL LAND AREA) ...................................................3-110

3.12.5 SET JRC / ERC CHART DISPLAY (JRC / ERC SETTING) ...............3-111

3.12.6 DISPLAY C-MAP CARD [MAP] ........................................................3-115

3.12.7 CORRECTING CHART POSITION (MAP DISPLAY SETTING)........3-118

3.12.8 CHART PLOTTING BEARING MODE (MAP DRAW AZI MODE) .... 3-120

3.13 CAPTURE SCREEN TO CARD ............................................................ 3-121

3.13.1 SAVE SCREEN TO CARD ............................................................... 3-121

3.13.2 AUTOMATICALLY SAVE SCREEN TO CARD ................................ 3-121

3.13.3 ERASEING SAVE SCREEN DATA .................................................. 3-122

3.13.4 SET SAVE ITEMS ............................................................................ 3-123

3.13.5 SET FILE STYLE ............................................................................. 3-123

3.13.6 OPEN THE CAPTURED SCREEN FILE .......................................... 3-124

4. MEASUREMENT OF RANGE AND BEARING

4.1 USE OF NAVIGATION TOOLS ................................................................. 4-1

4.1.1 USING CURSOR (CURSOR)............................................................... 4-2

4.1.2 USING RANGE RINGS [RR / HL] ........................................................ 4-2

4.1.3 USING ELECTRONIC BEARING LINE (EBL1/EBL2) ......................... 4-3

4.1.4 USING VARIABLE RANGE MARKER (VRM1 / VRM2) ....................... 4-6

4.1.5 USING PARALLEL INDEX LINES (PI MENU) ..................................... 4-7

4.1.6 OPERATING EBL MANEUVER FUNCTION

(EBL MANEUVER SETTING)........................................................... 4-12

4.1.7 USING MOB [MOB] ........................................................................... 4-14

4.1.8 OPERATING EBL, VRM, AND PI WITH CURSOR............................. 4-14

4.2 MEASUREMENT OF RANGE AND BEARING ....................................... 4-17

4.2.1 MEASUREMENT WITH CURSOR POSITION (CURSOR) ................ 4-18

4.2.2 MEASUREMENT WITH ELECTRONIC BEARING LINE AND

VARIABLE RANGE MARKER [EBL] [VRM] .................................... 4-19

4.2.3 MEASUREMENT WITH TWO ARBITRARY POINTS ........................ 4-20

5. OPERATION OF TARGET TRACKING AND AIS

USAGE

5.1 PREPARATION......................................................................................... 5-2

5.2 TARGET

5.3 AIS OPERATION..................................................................................... 5-31

5.4 DECISION OF TARGETS AS IDENTICAL (ASSOCIATION)................... 5-42

5.5 ALARM DISPLAY.................................................................................... 5-44

5.6 TRACK FUNCTION................................................................................. 5-48

5.7 TRIAL MANEUVERING (TRIAL MANEUVER) ....................................... 5-58

OF TARGET TRACKING FUNCTION ..................................................... 5-1

5.1.1 COLLISION AVOIDANCE.................................................................... 5-3

5.1.2 DEFINITIONS OF SYMBOLS .............................................................. 5-6

5.1.3 RADAR DISPLAY ................................................................................ 5-9

5.1.4 CURSOR MODES (CURSOR)........................................................... 5-11

5.1.5 SETTING COLLISION DECISION CRITERIA ................................... 5-13

5.1.6 SETTING CPA RING.......................................................................... 5-13

5.1.7 SETTING VECTORS (VECTOR TIME).............................................. 5-14

5.1.8 SETTING THE GPS ANTENNA LOCATION...................................... 5-15

TRACKING OPERATION......................................................... 5-16

5.2.1 ACQUIRING TARGET [ACQ] ............................................................ 5-17

5.2.2 CANCELING UNWANTED TRACKED TARGETS [TGT CNCL]....... 5-20

5.2.3 TRACKED TARGET DATA DISPLAY [TGT DATA] ........................... 5-21

5.2.4 DISPLAYING TARGET ID NO. (TARGET NUMBER DISPLAY)........ 5-22

5.2.5 ADDING TRACKED TARGET ID NAME (NAME) ............................. 5-23

5.2.6 REFERENCE TARGET (REFERENCE) ............................................ 5-24

5.2.7 OPERATION TEST (TT TEST MENU)............................................... 5-26

5.3.1 RESTRICTIONS................................................................................. 5-31

5.3.2 SETTING AIS DISPLAY FUNCTION (AIS FUNCTION)..................... 5-31

5.3.3 ACTIVATE AIS TARGETS (ACTIVATE AIS)...................................... 5-32

5.3.4 DEACTIVATE AIS TARGETS (DEACTIVATE AIS)............................ 5-32

5.3.5 DISPLAYING AIS INFORMATION [TGT DATA]................................ 5-33

5.3.6 DISPLAYING TARGET ID NO. (TARGET NUMBER DISPLAY)........ 5-37

5.3.7 SETTING AIS FILTER (AIS FILTER SETTING)................................. 5-37

5.3.8 CONDITIONS FOR DECIDING AIS TARGET TO BE LOST ............. 5-40

5.3.9 SETTING CONDITIONS FOR AIS ALARM (AIS ALARM SETTING) 5-41

5.6.1 PAST POSITION (PAST POSN) ........................................................ 5-48

5.6.2 TARGET SHIP'S TRACKS (TARGET TRACK) ................................. 5-49

6. TRUE AND FALSE ECHOES ON DISPLAY

6.1 RADAR

WAVE WITH THE HORIZON ....................................................... 6-1

6.2 STRENGTH OF REFLECTION FROM THE TARGET............................... 6-3

6.3 SEA

CLUTTER AND RAIN AND SNOW CLUTTER.................................. 6-5

6.4 FALSE ECHOES....................................................................................... 6-9

6.5 DISPLAY OF RADAR TRANSPONDER (SART) .................................... 6-12

7. SETTINGS FOR SYSTEM OPERATION

7.1 SETTINGS AT INSTALLATION................................................................. 7-1

7.1.1 HOW TO OPEN THE SERVICEMAN MENU ........................................ 7-1

7.1.2 GYRO I/F SETTING ............................................................................. 7-2

7.1.3 TUNING (TUNE ADJUSTMENT) ......................................................... 7-4

7.1.4 BEARING ADJUSTMENT ................................................................... 7-5

7.1.5 RANGE ADJUSTMENT ....................................................................... 7-6

7.1.6 NAVIGATOR SETTING (DEVICE) ....................................................... 7-6

7.1.7 SETTING OF TRUE BEARING VALUE ............................................... 7-7

7.1.8 ANTENNA

7.1.9 SETTING

(CCRP SETTING) ............................................................................... 7-8

7.2 SETTINGS .............................................................................................. 7-10

7.2.1 COMMUNICATION PORT SETTING (COM PORT SETTING)........... 7-10

7.2.2 SECTOR BLANK SETTING (SECTOR BLANK) ............................... 7-14

7.2.3 TNI BLANK SETTING (TNI BLANK).................................................. 7-15

7.2.4 SETTING OF BEARING PULSES FROM ANTENNA

(OUTPUT PULSE)............................................................................ 7-16

7.2.5 SLAVE MODE SETTING (MASTER/SLAVE)..................................... 7-17

7.2.6 LANGUAGE SETTING (LANGUAGE)............................................... 7-18

7.2.7 DATE TIME SETTING ........................................................................ 7-18

7.2.8 INPUT INSTALLATION INFORMATION ............................................ 7-19

7.2.9 SETTING THE ALARM SYSTEM....................................................... 7-20

7.3 ADJUSTMENT........................................................................................ 7-22

7.3.1 NOISE LEVEL ADJUSTMENT (NOISE LEVEL)................................ 7-22

7.3.2 ADJUSTMENT OF TARGET TRACKING FUNCTION (TT) ............... 7-24

7.3.3 MAIN BANG SUPPRESSION ADJUSTMENT (MBS)........................ 7-27

7.3.4 ADJUSTMENT OF PERFORMANCE MONITOR (MON) ................... 7-28

7.4 MAINTENANCE MENU .......................................................................... 7-30

7.4.1 ANTENNA SAFETY SWITCH (SAFETY SWITCH) ............................ 7-30

HEIGHT SETTING (ANTENNA HEIGHT) .......................... 7-7

OF CCRP/ANTENNA/GPS ANTENNA POSITION

7.4.2 INITIALIZATION OF MEMORY AREA (AREA INITIAL) ..................... 7-31

7.4.3 SAVE OF INTERNAL MEMORY DATA (CARD1/2) ............................ 7-32

7.4.4 CLEAR AND SAVE/RESTORATION OF ANTENNA OPERATION

TIME (TXRX TIME) ........................................................................... 7-33

7.4.5 UPDATE OF CHARACTER STRING DATA

(STRING DATA UPDATE)................................................................. 7-35

8. MAINTEMANCE

8.1 ROUTINE MAINTENANCE ....................................................................... 8-1

8.2 MAINTENANCE ON EACH UNIT.............................................................. 8-2

8.2.1 SCANNER UNIT NKE-1130/2103/2254 ............................................... 8-2

8.2.2 DISPLAY UNIT NCD-4590 ................................................................... 8-5

8.3 PERFORMANCE CHECK ......................................................................... 8-6

8.3.1 CHECK PERFORMANCE ON TEST MENU ........................................ 8-7

8.4 REPLACEMENT OF MAJOR PARTS ..................................................... 8-12

8.4.1 PARTS REQUIRED FOR PERIODIC REPLACEMENT ..................... 8-13

8.4.2 REPLACEMENT OF MAGNETRON .................................................. 8-14

8.4.3 REPLACEMENT

8.4.4 REPLACEMENT

OF MOTOR ............................................................ 8-21

OF LCD MONITOR................................................. 8-27

8.4.5 REPLACEMENT OF BACKUP BATTERY ......................................... 8-28

9. TROUBLESHOOTING AND AFTER-SALES SERVICE

9.1 FAULT FINDING........................................................................................ 9-1

9.1.1 LIST OF ALARMS AND OTHER INDICATIONS .................................. 9-1

9.1.2 OPERATION CHECKING .................................................................... 9-5

9.1.3 FUSE CHECKING................................................................................ 9-6

9.2 TROUBLE SHOOTING ............................................................................. 9-7

9.3 AFTER-SALES SERVICE....................................................................... 9-12

9.3.1 KEEPING PERIOD OF MAINTENANCE PARTS ............................... 9-12

9.3.2 WHEN YOU REQUEST FOR REPAIR ............................................... 9-12

9.3.3 RECOMMENDED MAINTENANCE ................................................... 9-12

10. DISPOSAL

10.1 DISPOSAL

OF THE UNIT ....................................................................... 10-1

10.2 DISPOSAL OF USED BATTERIES......................................................... 10-1

10.3 DISPOSAL

OF USED MAGNETRON ..................................................... 10-2

10.4 ABOUT THE CHINA ROHS .................................................................... 10-2

11. SPECIFICATIONS

11.1 JMA-5912-6 TYPE RADAR......................................................................11-1

11.2 JMA-5922-7/9 TYPE RADAR...................................................................11-2

11.3 JMA-5932-12 TYPE RADAR....................................................................11-3

11.4 SCANNER (NKE-2103-6) ........................................................................11-4

11.5 SCANNER (NKE-2254-7/9)......................................................................11-5

11.6 SCANNER (NKE-1130)............................................................................11-6

11.7 DISPLAY UNIT (NCD-4590) .....................................................................11-7

11.8 PROCESSOR UNIT (NDC-1477) .............................................................11-8

11.9 TARGET TRACKING FUNCTION..........................................................11-10

11.10 AIS UNIT (NQA-2103) ..........................................................................11-11

11.11 PLOTTER...............................................................................................11-12

11.12 OPERATION UNIT (NCE-5171) .............................................................11-13

11.13 PERFORMANCE MONITOR (NJU-84) ..................................................11-14

11.14 PERFORMANCE MONITOR (NJU-85) ..................................................11-14

11.15 AVAILABLE INPUT SIGNAL .................................................................11-15

11.16 AVAILABLE OUTPUT SIGNAL..............................................................11-16

11.17 STANDARD CONFIGURATION.............................................................11-16

11.18 EQUIPMENT DISTANCE BETWEEN OTHER INSTRUMENTS.............11-17

11.19 OTHERS (OPTION) ...............................................................................11-17

APPENDIX

INTERSWITCH (OPTION) NQE-3141 INSTRUCTION MANUAL

HOW TO INSERT AND REMOVE A CARD

FIG.1 BLOCK DIAGRAM OF JMA-5912-6, JMA-5922-7/9 RADAR

FIG.2 BLOCK DIAGRAM OF JMA-5932-12 RADAR

FIG.3 TERMINAL BOARD CONNECTION DIAGRAM OF JMA-5912-6 RADAR

FIG.4 TERMINAL BOARD CONNECTION DIAGRAM OF JMA-5922-7/9

RADAR

FIG.5 TERMINAL BOARD CONNECTION DIAGRAM OF JMA5932-12 RADAR

FIG.6 TERMINAL BOARD CONNECTION DIAGRAM OF RADAR AND

INTERSWITCH UNIT (OPTION)

FIG.7 POWER SYSTEM DIAGRAM OF JMA-5912-6, JMA-5922-7/9 RADAR

FIG.8 POWER SYSTEM DIAGRAM OF JMA-5932-12 RADAR

FIG.9 INTERCONNECTION DIAGRAM OF NCD-1477 RADAR PROCESS

UNIT

FIG.10 INTERCONNECTION DIAGRAM OF NQA-2123 INTERFACE UNIT

FIG.11 INTERCONNECTION DIAGRAM OF NCE-5171 OPERATION UNIT

FIG.12 INTERNAL CONNECTION DIAGRAM OF NWZ-170 MONITOR UNIT

FIG.13 INTERCONNECTION DIAGRAM OF NQE-3151A JUNCTION BOX

FIG.14 INTERCONNECTION DIAGRAM OF NKE-2103 SCANNER UNIT

FIG.15 INTERCONNECTION DIAGRAM OF NKE-2254 SCANNER UNIT

FIG.16 INTERCONNECTION DIAGRAM OF NKE-1130 SCANNER UNIT

(100/110/115V)

FIG.17 INTERCONNECTION DIAGRAM OF NKE-1130 SCANNER UNIT

(220/230/240V)

FIG.18 INTERCONNECTION DIAGRAM OF NQE-3141 INTERSWITCH UNIT

(OPTION)

FIG.19 OVER VIEW OF RADAR MENU

1

2

3

4

5

6

GENERAL AND EQUIPMENT COMPOSITION

NAME AND FUNCTION OF CONTROL PANEL KEYS
AND FUNCTION OF SOFTWARE BUTTONS

BASIC OPERATION

MEASUREMENT OF RANGE AND BEARING

OPERATION OF ARPA AND AIS

TRUE AND FALSE ECHOES ON DISPLAY

1

2

3

4

5

6

7

8

9

10

11

APPENDIX

MAINTENANCE

COUNTERMEASURES FOR TROUBLE AND
ADJUSTMENT

AFTER-SALES SERVICE

DISPOSAL

SPECIFICATION

7

8

9

10

11

APPENDIX

SECTION 1

GENERAL AND EQUIPMENT

COMPOSITION

FUNCTIONS.........................................................................................1-1

1.1

1.2 FEATURES...........................................................................................1-2

1.3 CONFIGURATION................................................................................1-4

1.4 OUTSIDE DRAWINGS .........................................................................1-6

1.5 GENERAL SYSTEM DIAGRAMS ......................................................1-20

1.1 FUNCTIONS

This equipment is a high-performance radar equipment consisting of a scanner unit, a transceiver unit and a
high resolution color LCD display unit.

1.1.1 Function of This System

The JMA-5900 series is a color radar system designed to comply with the international standards of
the IMO.
The main functions include:

• gain adjustment

• sea clutter and rain / snow clutter suppression

• interference rejection

• bearing and range measurement using a cursor, fixed/variable range markers, and electronic bearing

line

• own track display

• colored own track display (7 colors) (Option)

• NAV line and marker displays

• TM (True Motion) presentation

• self-diagnostic facilities

• radar performance monitoring (Performance Monitor)

• Target Tracking (TT) functions (manual / automatic target acquisition and automatic tracking,

vector and track displays and alarm displays)

• simple plotter functions:
marker and line display (up to 2000 items.)
marker and line display (up to 20000 items.)(Option)
waypoint / route setting (Option)

• 8-unit switchover (Inter switch) function (Option)

1-1

1.2 Features

y

1.2 FEATURES

Realization of Large, Easy-to-see Screen with High Resolution

The 23.1-inch color LCD with high resolution of 1280 × 1024 pixels can display radar images of 320 mm or
more in diameter. Even short-range targets can also be displayed as high-resolution images.

Target Detection by Latest Signal Processing Technology

The system employs the latest digital signal processing technology to eliminate undesired clutter from the
radar video signals that are obtained from the receiver with a wide dynamic range, thus improving the target
detection.

Advanced Technology Based Target Tracking (TT) Functions

The target acquisition and tracking performance is enhanced by the use of the fastest DSP and tracking
algorithm. So stable operation in target tracking under clutter is ensured.

• Acquisition and tracking of 100 targets.

• Hazardous conditions are represented by shapes and colors of symbols as well as sounds.

• Trial maneuvering functions provided.

• Tracks of up to 20 target ships can be stored with a maximum of 1,500 points for each of them, and

displayed distinguished by using 7 different colors.

Overlay of Radar Images, Coastlines, and Own Ship's Track

As well as operator-created NAV lines, the data of coastlines, objects such as buoys, and own ship's tracks /
target tracks / AIS tracks, which is stored on the memory card can be superimpose-displayed with radar
images and radar trails in all display modes including the head-up mode.
Creation / display of marks and lines (up to 2000 items).
Use of the optional plotter function enables the own track display distinguished by using 7 different colors,
creation of marks and lines (up to 20000 items) and the settings of waypoints / courses.

Easy Operation with GUI

All the radar functions can be easily controlled by simply using the trackball and 2 switches to operate the
buttons shown on the radar display.

Improved Day / Night Mode

Five types of background colors are available in Day / Dusk / Night mode.
Each background color can be reproduced to be suited for the user’s operating environment by simple key
operation. The radar echoes and a variety of graphics can also be represented in different colors, ensuring
easy-to-see displays.

1

1-2

Self-diagnostic Program Incorporated

The Self-diagnostic program always monitors all the functions of the system. If any function deteriorates,
an alarm message will appear on the radar display and an alarm sounds at the same time. Even when the
system is operating, the functionality test can be carried out. (except on some functions)

Performance Monitor

The radar performance (transmitted output power and receiving sensitivity) can appear on the radar display.

Easy Interswitch Operation (Option)

If an interswitch unit (option) is connected, up to four JMA-5900 radars can be switched over by
performing simple operation.
* An interswitch (NQE-3141) is needed separately.

Various Functions

• RADAR Trails

• TM (True Motion) display

• Head-up / North-up / Course-up display

• Own ship’s track display

• Automatic Acquisition / Activation function

1-3

1.3 Configuration

y

1.3 CONFIGURATION

Specified of scanner, and categories of ship/craft for SOLAS V

Radar Model Antenna Type

JMA-5912-6 6 ft slot antenna 10 kW X 27 rpm CAT 1

JMA-5922-7 7 ft slot antenna 25 kW X 24 rpm CAT 1

JMA-5922-9 9 ft slot antenna 25 kW X 24 rpm CAT 1

JMA-5932-12 12 ft slot antenna 30 kW S 24 rpm CAT 1

*The class of emission: P0N (All scanner types)

Radar Configuration and Ship’s Mains

Radar Model Scanner Unit

JMA-5912-6 NKE-2103-6 NJU-85 NCD-4590 24 VDC

JMA-5922-7 NKE-2254-7 NJU-85 NCD-4590 24 VDC

Performance

Output Power

Monitor

Transmitted

Display Unit Ship’s Mains

Band

Rate of

Rotation

1

Category

JMA-5922-9 NKE-2254-9 NJU-85 NCD-4590 24 VDC

NCD-4590

JMA-5932-12 NKE-1130 NJU-84

*NQE-3151A

* The NQE-3151A included in JMA-5932-12 is a connection unit to supply AC power for the motor to

the scanner unit.

Notes:

1. The JMA-5932-12 needs AC power for the radar process unit (rectifier unit NBA-5111), and motor
to drive the scanner unit.

2. The drive motor for the scanner unit is available in AC100-115V or AC220-240V type for
JMA-5932-12. Please specify the motor type when ordering.

3. An optional POWER SUPPLY NBA-5111 is necessary for using Ship's Mains
100/110/115/220/230/240 VAC,1φ,50/60Hz.

4. When using the ship's mains of AC440V as the radar power source, a step-down transformer shall
be used.

5. The scanner unit except NKE-2103 series can be equipped with a deicing heater as an option, and
'-D' shall be suffixed to the type name. (e.g. NKE-1130-D, NKE-2254-6D).

(supplied from NBA-5111)

100/110/115 VAC,1 φ,50/60 Hz

220/230/240 VAC,1 φ,50/60 Hz

24 VDC

1-4

6. The DISPLAY UNIT NCD-4590 has a separate structure consisting of the following:
MONITOR UNIT NWZ-170 (Option)
CONTROL UNIT NCM-878

The control unit NCM-878 is consisting of the following

RADAR PROCESS UNIT NDC-1477
OPERATION UNIT NCE-5171

1-5

1.4 Exterior Drawings

y

1.4 OUTSIDE DRAWINGS

Fig. 1.1 Outside Drawing of NKE-2103-6 SCANNER UNIT

Fig. 1.2 Outside Drawing of NKE-2254-7 SCANNER UNIT

Fig. 1.3 Outside Drawing of NKE-2254-9 SCANNER UNIT

Fig. 1.4 Outside Drawing of NKE-1130 SCANNER UNIT

Fig. 1.5 Outside Drawing of NWZ-170 MONITOR UNIT (Option)

Fig. 1.6 Outside Drawing of NWZ-170 MONITOR UNIT with MPBC40501 Stand (Option)

Fig. 1.7 Outside Drawing of NDC-1477 RADAR PROCESS UNIT

Fig. 1.8 Outside Drawing of NCE-5171 OPERATION UNIT

Fig. 1.9 Outside Drawing of NQE-3151A JUNCTION BOX

Fig. 1.10 Outside Drawing of NQE-3141-4A INTERSWITCH UNIT (Option)

Fig. 1.11 Outside Drawing of NQE-3141-8A INTERSWITCH UNIT (Option)

Fig. 1.12 Outside Drawing of NBA-5111 RECTIFIER UNIT
(JMA-5912-6, JMA-5922-7/9: Option, JMA-5932-12 : Standard)

Fig. 1.13 Outside Drawing of NQE-3167 POWER CONTROL UNIT

1

1-6

Fig. 1.1 Outside Drawing of NKE-2103-6 SCANNER UNIT

1-7

1.4 Exterior Drawings

y

1

Fig. 1.2 Outside Drawing of NKE-2254-7 SCANNER UNIT

1-8

Fig. 1.3 Outside Drawing of NKE-2254-9 SCANNER UNIT

1-9

1.4 Exterior Drawings

y

1

Fig. 1.4 Outside Drawing of NKE-1130 SCANNER UNIT

1-10

Fig. 1.5 Outside Drawing of NWZ-170 MONITOR UNIT (Option)

1-11

1.4 Exterior Drawings

y

1

Fig. 1.6 Outside Drawing of NWZ-170 MONITOR UNIT with MPBC40501A Stand (Option)

1-12

Fig. 1.7 Outside Drawing of NDC-1477 RADAR PROCESS UNIT

1-13

1.4 Exterior Drawings

y

1

Fig. 1.8 Outside Drawing of NCE-5171 OPERATION UNIT

1-14

Fig. 1.9 Outside Drawing of NQE-3151A JUNCTION BOX

1-15

1.4 Exterior Drawings

y

1

Fig. 1.10 Outside Drawing of NQE-3141-4A INTERSWITCH UNIT (Option)

1-16

Fig. 1.11 Outside Drawing of NQE-3141-8A INTERSWITCH UNIT (Option)

1-17

1.4 Exterior Drawings

y

1

Fig. 1.12 Outside Drawing of NBA-5111 RECTIFIER UNIT

(JMA-5912-6, JMA-5922-7/9 : Option, JMA-5932-12 : Standard)

1-18

Fig. 1.13 Outside Drawing of NQE-3167 POWER CONTROL UNIT (Option)

1-19

1.5 General System Diagrams

y

1.5 GENERAL SYSTEM DIAGRAMS

Fig. 1.14 General System Diagram of JMA-5912-6 RADAR

Fig. 1.15 General System Diagram of JMA-5922-7/9 RADAR

Fig. 1.16 General System Diagram of JMA-5932-12 RADAR

1

1-20

NKE-2103-6 SCANNER UNIT

NJU-85 PERFORMANCE MONITOR

19 CORES COMPOSITE CABLE

CFQ-6912
MAX φ14.5 (JRC SUPPLY)

NCM-878 CONTROL UNIT

NCD-4590 DISPLAY UNIT

MONITOR UNIT:
NWZ-170,HATTELAND,
MELFORD or ISIC

NCE-5171 OPERATION UNIT

JRC LAN

INTERSWITCH

LOG(NMEA)

LOG(200P)

AC100/110/115V 50/60Hz 1φ

AC220/230/240V 50/60Hz 1φ

LAN CABLE H-7ZCNA0483

(JRC SUPPLY, OPTION)

H-2695111153 MAX φ18
(JRC SUPPLY, OPTION)

250V-TTYCS-4

AIS

250V-TTYCS-1

250V-MPYCYS-7

GYRO

250V-DPYCYS-1.5

250V-TTYCS-1

GPS

SHIP'S MAIN

0.6/1kV-DPYC-6

NDC-1477 RADAR PROCESS UNIT

NCA-877WA ARPA PROCESS UNIT

NDB-34A PLOTTER CONTROL UNIT
(OPTION)

NQA-2103 AIS PROCESS UNIT

NCT-59A GYRO INTERFACE UNIT

NBA-5111 POWER SUPPLY

(OPTION)

(JRC SUPPLY) 5m

CFQ-5436-5
MAX φ10 (JRC SUPPLY) 5m

DC24V

NOTE: Eliminating the interference on frequencies used for marine communications and navigation due to

operation of the radar.
All cables of the radar are to be run away from the cables of radio equipment.
(Ex. Radiotelephone. Communications receiver and direction finder, etc. )
Especially inter-wiring cables between scanner unit and display unit of the radar should not be run parallel
with the cables of radio equipment.

Fig. 1.14 General System Diagram of JMA-5912-6 RADAR

1-21

OPTION

HEATER CONTROL PART

CIRCUIT BREAKER (5A)

(SHIPYARD SUPPLY)

0.6/1kV-DPYCYS-1.5

0.6/1kV-DPYC-1.5

AC100V 50/60Hz 1φ 100W

NBL-175 STEPDOWN TRANSFORMER

NKE-2254-7/9 SCANNER UNIT

19 CORES COMPOSITE CABLE

CFQ-6912
MAX φ14.5 (JRC SUPPLY)

1.5 General System Diagrams

NJU-85 PERFORMANCE MONITOR

y

1

NCD-4590 DISPLAY UNIT

0.6/1kV-DPYC-1.5

SHIP'S MAIN

AC220/230/240V 50/60Hz 1φ

JRC LAN

INTERSWITCH

LOG(NMEA)

LOG(200P)

AC100/110/115V 50/60Hz 1φ

AC220/230/240V 50/60Hz 1φ

LAN CABLE H-7ZCNA0483

(JRC SUPPLY, OPTION)

H-2695111153 MAX φ18
(JRC SUPPLY, OPTION)

250V-TTYCS-4

AIS

250V-TTYCS-1

250V-MPYCYS-7

GYRO

250V-DPYCYS-1.5

250V-TTYCS-1

GPS

SHIP'S MAIN

0.6/1kV-DPYC-6

NCM-878 CONTROL UNIT

NDC-1477 RADAR PROCESS UNIT

NCA-877WA ARPA PROCESS UNIT

NDB-34A PLOTTER CONTROL UNIT
(OPTION)

NQA-2103 AIS PROCESS UNIT

NCT-59A GYRO INTERFACE UNIT

NBA-5111 POWER SUPPLY

(OPTION)

(JRC SUPPLY) 5m

CFQ-5436-5
MAX φ10 (JRC SUPPLY) 5m

DC24V

MONITOR UNIT:
NWZ-170,HATTELAND,
MELFORD or ISIC

NCE-5171 OPERATION UNIT

NOTE: Eliminating the interference on frequencies used for marine communications and navigation due to

operation of the radar.
All cables of the radar are to be run away from the cables of radio equipment.
(Ex. Radiotelephone. Communications receiver and direction finder, etc. )
Especially inter-wiring cables between scanner unit and display unit of the radar should not be run parallel
with the cables of radio equipment.

Fig. 1.15 General System Diagram of JMA-5922-7/9 RADAR

1-22

OPTION

HEATER CONTROL PART

CIRCUIT BREAKER (5A)

(SHIPYARD SUPPLY)

0.6/1kV-DPYCYS-1.5

0.6/1kV-DPYC-1.5

AC100V 50/60Hz 1φ 200W

NBL-175 STEPDOWN TRANSFORMER

NKE-1130 SCANNER UNIT

NQE-3151A JUNCTION BOX

NJU-84 PERFORMANCE MONITOR

14 CORES COMPOSITE CABLE

H-2695110056
MAX φ23 (JRC SUPPLY)

0.6/1kV-DPYC-1.5

19 CORES COMPOSITE CABLE

CFQ-6912
MAX φ14.5 (JRC SUPPLY)

SHIP'S MAIN

AC100/110/115V 50/60Hz 1φ

AC220/230/240V 50/60Hz 1φ

NCD-4590 DISPLAY UNIT

0.6/1kV-DPYC-1.5

SHIP'S MAIN

AC220/230/240V 50/60Hz 1φ

JRC LAN

INTERSWITCH

LOG(NMEA)

LOG(200P)

AC100/110/115V 50/60Hz 1φ

AC220/230/240V 50/60Hz 1φ

LAN CABLE H-7ZCNA0483

(JRC SUPPLY, OPTION)

H-2695111153 MAX φ18
(JRC SUPPLY, OPTION)

250V-TTYCS-4

AIS

250V-TTYCS-1

250V-MPYCYS-7

GYRO

250V-DPYCYS-1.5

250V-TTYCS-1

GPS

SHIP'S MAIN

0.6/1kV-DPYC-6

NCM-878 CONTROL UNIT

NDC-1477 RADAR PROCESS UNIT

NCA-877WA ARPA PROCESS UNIT

NDB-34A PLOTTER CONTROL UNIT
(OPTION)

NQA-2103 AIS PROCESS UNIT

NCT-59A GYRO INTERFACE UNIT

NBA-5111 POWER SUPPLY

(JRC SUPPLY) 5m

CFQ-5436-5
MAX φ10 (JRC SUPPLY) 5m

DC24V

MONITOR UNIT:
NWZ-170,HATTELAND,
MELFORD or ISIC

NCE-5171 OPERATION UNIT

NOTE: Eliminating the interference on frequencies used for marine communications and navigation due to

operation of the radar.
All cables of the radar are to be run away from the cables of radio equipment.
(Ex. Radiotelephone. Communications receiver and direction finder, etc. )
Especially inter-wiring cables between scanner unit and display unit of the radar should not be run parallel
with the cables of radio equipment.

Fig. 1.16 General System Diagram of JMA-5932-12 RADAR

1-23

SECTION 2

NAMES AND FUNCTIONS OF CONTROL

PANEL KEYS AND FUNCTIONS OF

SOFTWARE BUTTONS

2.1 NAMES OF DISPLAY......................................................................... 2-1

2.2 NAMES AND FUNCTIONS OF CONTROL PANEL KEYS............... 2-10

2.3 FUNCTIONS OF SOFTWARE BUTTONS........................................ 2-15

2.1 NAMES OF DISPLAY

Example of screen display

In this example, the screen is divided into a number of areas and the names in each area are
indicated.

Upper left

of the display

PPI

Upper right

of the display

Own ship's
information

Target

tracking (TT) /

AIS

information

Lower left

of the display

Lower right

of the display

Digital

information

Menu

Display

information /

alarm

2-1

y

2.1 Names of Displa

yy

PPI

2

Upper left of the display

About ground and sea stabilization
Speed sensor source is MAN , LOG , 2AXW
If Set/Drift Setting menu is on : GND (Ground stabilization)
If Set/Drift Setting menu is off : Sea (Sea stabilization)
Speed sensor source is 2AXG , GPS : GND (Ground stabilization)

2-2

Lower left of the display

Upper right of the display

2-3

y

Lower right of the display

2.1 Names of Displa

yy

2

Own ship's information

About time display mode
UTC : Universal Time Coordinate
UTC(S) : UTC (System Time)
LMT : Local Mean Time
LMT(S) : LMT (System Time)

2-4

Target tracking (TT) / AIS information

Digital information: AIS target information

AIS target number

Simple display item

Ship's name

Call sign

Course

Speed

Bearing

Range

Unread message

MMSI

CPA

TCPA

Ship's heading bearing

Rate of turn

Latitude

Latitude / longitude error

Longitude

DestinationNavigation status

2-5

y

Digital information: Tracked target information

Tracked target number

2.1 Names of Displa

yy

Bearing

RangeTrue course

True speed

CPA

BCR

TCPA

BCT

No information is displayed

if digital information value is

not displayed

Digital information: Enhancement of cursor position numeric value

indication

2

Digital information: Enhancement of EBL / VRM numeric value display

2-6

Digital information: Navigation information

Digital information: Depth indication

Digital information: Water temperature indication

2-7

y

Digital information: Wind direction / speed

2.1 Names of Displa

yy

2

Digital information: Course bar

Digital information: Marker

Marker bearing

Marker range

Marker latitude

Marker longitude

Arrival time

2-8

Menu

Brilliance

Display information

Alarm

Alarm indication

(The system alarm indicated in red.

Other information indicated in blue or yellow.)

2-9

2.2 Names and Functions of Control Panel Keys

2.2 NAMES AND FUNCTIONS OF

CONTROL PANEL KEYS

Clear /

38

dial

Gain / pulse length

1

37 38

Variable range marker dial

3

/ Variable range marker 1 / 2

35 36

3

35 36

37

Enter

Vector mode / 3

information

yy

2

Track ball

1

Automatic

acquisition /

Mark / 6

activation zone / 9

Target tracking

(TT) menu

32

Automatic - Sea

clutter dial

6 7

Automatic - Rain /

snow clutter dial

5

/ Range scale + / -

33 34

4 5 6 7

33

21 22 23

1615

34

Map / 2

Off-center / 5

22 23

25 262728 29

Range rings /

3031 32

24 25 26

27 28 29

2019

True / relative

Azimuth display

21

motion / 4

mode / 1

24

ship’s heading line

Day / night / 7

cancellation / 8

Radar trails / 0

30

Main menu

31

Multi dial

4

Transmission /

9

transmission repetition

frequency

11

8 9

10

18 17

Tracked target

1615

14

13

12

Manual

2

indication

cancellation

Target data

17

acquisition

Function

call

18

2019

/ User registration 1 / 2

11

Standby

8

Electronic bearing line dial

2

10

/ Electronic bearing line 1 / 2

The name of each button is described from the following page. See below.

2-10

Control panel

Alarm

acknowledgment

13

12

Marker

14

brilliance

Track ball

1

Use the track ball to move the cursor mark to any position.
For example, use it for setting in each mode and specifying a floating EBL center position and
off-center position.

2

[EBL] (Electronic Bearing Line) dial

Turn the dial to rotate the bearing of the EBL.
By pressing the dial, the selected EBL can be switched.

(Center fixing) ⇒ C (Floating) ⇒ D (latitude / longitude fixing) ⇒

* D is enabled only when the navigator is connected.

[VRM] (Variable Range Marker) dial

3

Turn the dial to change the VRM range.
Press the dial to set the display of parallel index line (PI) to On / Off and open the PI Menu.

[MULTI] dial

4

Press the dial to switch the function that is registered in the multi-dial.

Vec t or ⇒ Trails ⇒ TGT No. ⇒ Course ⇒ Track ⇒ Mark
⇒ Tune ⇒ Vector

The function that is switched is displayed in multi-dial mode (lower left of the display on page 2-3)
If the dial is pressed for 2 seconds, the Multi Dial Setting menu is opened. If the dial is pressed again
for 2 seconds, the setting menu is closed.

[AUTO-RAIN] (Automatic - Rain / Snow clutter suppression) dial

5

Turn the dial to suppress images by rain / snow clutter.
Turn the dial clockwise to increase the effect of suppression.
Press the dial to switch the mode to manual / automatic.

[AUTO-SEA] (Automatic - Sea clutter suppression) dial

6

Turn the dial to suppress images by sea clutter.
Turn the dial clockwise to increase the effect of suppression.
Press the dial to switch the mode to manual / automatic.

[GAIN / PL] (Gain / Pulse Length) dial

7

Turn the dial to adjust the reception gain of the radar.
Turn the dial clockwise to increase the gain.
Press the dial to switch the transmitting pulse length.

[STBY] (Standby) key

8

Use this key to turn on the power of the equipment.
Use this key also to switch the equipment from a transmitting state to a standby state.
The power can be turned off by pressing the [STBY] key and [TX / PRF] key concurrently while the
power is On.

[TX / PRF] (Transmission / transmission repetition frequency) key

9

At expiration of the pre-heat time after the power is turned on, Preheat of the transmission /
standby indication (Upper left of the display on page 2-2) changes to Standby .
If this key is pressed subsequently, transmission starts.
If this key is pressed during transmission, fine adjustments of the transmission repetition frequency are
enabled.
By using the fine adjustments of the transmission repetition frequency and the interference removal
function, the interference suppression effect can be improved.

2-11

/

10

[EBL1] / [EBL2] (Electronic Bearing Line 1 / 2) key

11

Use these keys to switch EBL1 / EBL2 to On / Off.
If the key is pressed for 2 seconds, the EBL / Cursor Setting menu is opened.

2.2 Names and Functions of Control Panel Keys

yy

[ALARM ACK] (Alarm acknowledgment) key

12

Use this key to acknowledge the alarm such as a failure alarm and a collision alarm.
To stop the alarm, press this key while the alarm sound is emitted.
If multiple alarms occur, press this key same time as the alarms.

2

[PANEL] (Control panel brilliance) key

13

Use this key to adjust the brilliance of various keys and dials on the control panel.

[MOB] (Marker) key

14

A marker is set on the own ship's position latitude / longitude at that time. Use this key to store the
own ship's position at the time in such a case that someone falls overboard from the ship.
The marker can be cleared by pressing the key for 2 seconds.

[ACQ] (Manual acquisition) key

15

Use this key to acquire a target of the cursor position manually.

[TGT CNCL] (Tracked target cancellation) key

16

Use this key to cancel the tracked target symbol / vector at the cursor position and stop tracking.
When this key is pressed for 2 seconds, all the tracked target symbols / vectors are cancelled and
tracking is stopped.

[TGT DATA] (Target data indication) key

17

Use this key to check the digital information of the AIS target or the tracked target.

[FUNC] (Function call) key

18

Use this key to switch the original signal processing settings.

FUNC Off ⇒ Coast ⇒ Deep Sea ⇒ Fishnet ⇒ Storm ⇒ FUNC Off
If the key is pressed for 2 seconds, the User Function Setting menu is displayed.

/

19

[USER KEY 1 / 2] (User registration 1 / 2) key

20

Use this key to perform pre-registered operations.
If this key is pressed for 2 seconds while no operation is registered, the User Key Setting menu is
opened.

[AZI MODE / 1] (Azimuth display mode / 1) key

21

Switch the azimuth display.

H Up (Head Up) ⇒ N Up (North Up) ⇒ C Up (Course Up) ⇒ N Up
During the menu operation, the key functions as a numeric key [1].

If this key is pressed for 2 seconds, GYRO setting menu is opened.

[MAP / 2] key

22

Use this key to switch the map display to On / Off such as marine chart, coastline, and depth contour.
During the menu operation, the key functions as a numeric key [2].
If this key is pressed for 2 seconds, the Map Setting menu is opened.

2-12

[VECT R / T / 3] (Vector mode / 3)

23

Use this key to switch vector indication T (true vector) / R (relative vector).
During the menu operation, the key functions as a numeric key [3].

[TM / RM / 4] (True Motion / Relative Motion / 4) key

24

Use this key to switch the motion mode between TM (true motion) and RM (relative motion).
If the key is pressed for 2 seconds in TM , the own ship's position is reset.
During the menu operation, the key functions as a numeric key [4].

[OFF CENT / 5] (Off-center / 5) key

25

By pressing this key, moving the cursor, and pressing the [ENT] key, the ship's position can be moved
to the cursor position. The moving range is about 66% of the radius.
If the key is pressed for 2 seconds, the off-center is set to Off and the ship's position is returned to the
center of the screen.
During the menu operation, the key functions as a numeric key [5].

[MARK / 6] (Mark / 6) key

26

Use this key to display a mark in any screen position. This key can also be used for clearing the mark
that is currently displayed.
If the key is pressed for 2 seconds, the Mark Setting menu is opened.
During the menu operation, the key functions as a numeric key [6].

[DAY / NIGHT / 7] (Day / night mode / 7) key

27

Use this key to switch the color and brightness of the screen that have been set in advance.
If the key is pressed for 2 seconds, the Display Color Setting menu is opened.
During the menu operation, the key functions as a numeric key [7].

[RR / HL / 8] (Range Rings / ship's heading line off / 8) key

28

Use this key to set the range rings marker to On / Off.
If the key is pressed for 2 seconds, the ship's heading line is cleared while the key is pressed.
During the menu operation, the key functions as a numeric key [8].

[AZ / 9] (Automatic Acquisition / Activation Zone / 9) key

29

Use this key to set automatic acquisition / activation zone.
If the key is pressed for 2 seconds, the AZ Menu (automatic acquisition / activation zone menu) is
opened.
During the menu operation, the key functions as a numeric key [9].

[TRAILS / 0] (Radar trails / 0) key

30

Use this key to switch the length of the radar trail period.
If the key is pressed for 2 seconds, the RADAR Trails setting menu is opened.
If this key is pressed for 5 seconds, the radar trail is cleared.
During the menu operation, the key functions as a numeric key [0].

[RADAR Menu] (Main menu) key

31

Use this key to open the Main Menu.

[TT Menu] key

32

Use this key to open the TT Menu (target tracking menu).

/

33

[RANGE + / - ] key

34

Press the [+] key to increase the observation range and the [-] key to reduce the observation range.

2-13

/

35

[VRM 1 / 2 ] (Variable Range Marker 1 / 2) key

36

Use this key to set the display of VRM1 / VRM2 to On / Off and acquire the operation right.

2.2 Names and Functions of Control Panel Keys

yy

[ENT] (Enter) key

37

Use this key to confirm menu selection and input of numeric values.
This key is equivalent to the clicking of the left button of the track ball.

[CLR / INFO] (Clear / information) key

38

Use this key to cancel menu selection or numeric value input.
This key is equivalent to the clicking of the right button of the track ball.

2

2-14

2.3 FUNCTIONS OF SOFTWARE BUTTONS

In this radar, the frequently used functions can be directly set from the screen without opening the
menu by using the software buttons on the screen for quick handling. The screen is divided into a
number of areas and each area is named.

Upper left

of the display

PPI

Upper right

of the display

Own ship's
information

Target

tracking (TT) /

AIS

information

Lower left

of the display

Digital

information

Menu

Display

information /

alarm

Lower right

of the display

The name of each button is described from the next page. The function can be used by pressing
(clicking) the [ENT] key while setting the arrow cursor on the button position.

2-15

Upper left of the display

2.3 Functions of Software Buttons

yy

2

①：Range scale switching

To increase the observation range scale (maximum 96 NM), click + and to reduce the range
(minimum 0.125 NM), click - .

②：Range rings display On / Off

The display of range rings are set to On / Off whenever this button is clicked.
When the display is set to On, the interval of the fixed range marker is displayed.

③：Motion mode true / relative switching

The screen motion mode is switched whenever the button is clicked.

TM (true motion) ⇒ RM (relative motion) ⇒ TM

RM(R) indicates that the radar trails is a relative trail.

RM(T) indicates that the radar trails is a true trail.

④：Off center switching

If this button is clicked, the cursor is moved, and the [ENT] key is pressed, the ship's position can be
moved to the cursor position. The moving range is within 66 % of the radius.
If the button is clicked for 2 seconds, the off-center is set to Off and the ship's position is returned to
the center of the screen.

⑤：Transmission / standby switching

At expiration of the pre-heat time after the power is turned on, Preheat changes to Standby .

Standby : Indicates a standby state. If this button is clicked in this state, the equipment is set to a

transmission state.

Transmit : Indicates a transmission state. If this button is clicked in this state, the equipment is set

to a standby state.

2-16

⑥：Interswitch connection change

This button is displayed when the interswitch is connected. This button indicates the connection
status of the scanner unit that is connected to the indicator.
If the button is clicked in the transmission standby state, the menu for changing the connection state
between the scanner unit and the indicator is displayed. The connection state of the scanner unit and
indicator cannot be changed unless the master indicator is in a standby state.

→ Refer to the Interswitch (Optional) Instruction Manual that is attached for the setting method.

This button is not displayed if the interswitch is not connected.

⑦：Transmission pulse length switching

The transmission pulse length is switched whenever this button is clicked. Three types of pulses are
available, short pulse (SP), middle pulse (MP), and long pulse (LP). The pulse length and repetition
frequency vary even for the same short pulse, according to the range that is used and it is displayed as
SP1 , SP2 .

⑧：Azimuth display mode switching

The azimuth display is switched whenever this button is clicked.
H Up (Head Up) ⇒ N Up (North Up) ⇒ C Up (Course Up) ⇒ H Up
If the button is clicked for 2 seconds, the GYTO Setting menu is displayed.

2-17

Lower left of the display

2.3 Functions of Software Buttons

yy

2

①：Double zoom switching

Use this function to enlarge to double the size the display screen of the position specified by the cursor.
If this button is clicked, the zoom mode is set. When the cursor is moved to the radar screen and the
[ENT] key is pressed, the screen is enlarged to double the size so that the middle of the cursor and the
own ship's position is set to the center of the screen. This function cannot be used when the range is

0.125NM.

②：Interference rejection (IR) mode switching

The interference rejection mode is switched whenever this button is clicked.

IR Off ⇒ IR Low ⇒ IR Medium ⇒ IR High ⇒ IR Off

③：Target enhance (ENH) mode switching

The target enhance mode is switched whenever this button is clicked.

ENH Off ⇒ ENH Level1 ⇒ ENH Level2 ⇒ ENH Level3 ⇒ ENH Off

④：Radar video processing (PROC) mode switching

The radar video processing mode is switched whenever this button is clicked.

PROC Off ⇒ 3Scan CORREL ⇒ 4Scan CORREL ⇒ 5Scan CORREL ⇒

⇒ Remain ⇒ Peak Hold ⇒ PROC Off

⑤：Function (FUNC) mode switching

The function mode is switched whenever this button is clicked.

FUNC Off ⇒ Coast ⇒ Deep Sea ⇒ Fishnet ⇒ Storm ⇒ FUNC Off

If the button is clicked for 2 seconds, the function registration menu (User Function Setting) is opened.

2-18

⑥, ⑦, ⑧,and ⑨：Gain, Sea clutter suppression (Sea), Rain / snow clutter

suppression (Rain), Tune adjustment

Adjust the gain, sea clutter suppression, rain and snow clutter suppression and tune using the track ball.
If the button is clicked on, the adjustment value is shown at the upper-right of the cursor. Make
adjustments by moving the track ball to the left and right. Determine the adjustment by pressing the
[ENT] key.

⑩, ⑪,and ⑫：Sea clutter suppression (Sea) mode, Rain / snow clutter

suppression (Rain) mode, and Tune mode switching

Use these functions to switch to the manual or automatic mode of sea clutter suppression, rain / snow
clutter suppression and tune. The bar on the left side indicates the position of the dial.

The mode is switched to MAN (manual) / AUTO (automatic) whenever the button is clicked.
If rain / snow clutter suppression is switched to an automatic mode, sea clutter suppression is switched
to an automatic mode also.

⑬：Multi-dial mode switching

The function that is registered in the multi-dial is switched whenever the button is clicked.

Vector ⇒ Trails ⇒ TGT No. ⇒ Course ⇒ Track ⇒ Mark ⇒

⇒ Tune ⇒ Vector
The switched function is displayed in ( ).
If the button is clicked for 2 seconds, the Multi Dial Setting menu is opened. If this button is clicked
again for 2 seconds, this setting menu is closed.

Upper right of the display

⑨ EBL1 numeric value indication

true / relative switching

② Mark font / line pattern

switching

① Cursor mode switching

④ Cursor bearing

numeric value display

true / relative switching

⑤ EBL1 adjustment

⑥ VRM1 adjustment

⑦ EBL2 adjustment

⑧ VRM2 adjustment

⑩ EBL2 numeric value indication

true / relative switching

③ Mark color / line color

⑪ EBL1 starting point

⑫ EBL2 starting point

⑬ Parallel index line

⑭ Parallel index line

starting point mode

switching

①：Cursor mode switching

The mode of the function that uses the cursor is switched whenever this button is pressed.

AUTO ⇒ ACQ TT ⇒ ACT AIS ⇒ TGT DATA ⇒ CNCL TT ⇒

⇒ DEACT AIS ⇒ CNCL Data ⇒ □ (Mark) ⇒ -------- (Line) ⇒

⇒ Property ⇒ AUTO

switching

mode switching

mode switching

setting

2-19

2.3 Functions of Software Buttons

②：Mark font / line pattern switching

This function switches a mark font / line pattern. If this button is clicked while the cursor mode is

□ (mark) or -------- (line), the mark font / line pattern is changed.

③：Mark color / line color switching

This function switches a mark color / line color. If this button is clicked while the cursor mode is

□ (mark) or -------- (line), the mark color / line color is changed.

④：Cursor bearing numeric value display true / relative switching

The bearing numeric value display T (true bearing) / R (relative bearing) of the cursor is
switched whenever this button is clicked.

⑤, ⑥, ⑦,and ⑧：EBL1 / 2 and VRM1 / 2 adjustment

These functions set the EBL1 , VRM1 , EBL2 , and VRM2 displays to On / Off and acquire
the operation right.
If the button is clicked on, the operation right is acquired. Make adjustments by moving the track ball
to the left and right Determine the adjustment by pressing the [ENT] key.

⑨ and ⑩：EBL1, EBL2 numeric value true / relative switching

The EBL1 / 2 bearing numeric value display T (true bearing) / R (relative bearing) is switched
whenever the button is clicked.
If the button is clicked for 2 seconds, the EBL / Cursor Setting menu is displayed.

⑪ and ⑫：EBL1 / EBL2 starting point mode switching

The EBL starting point is set to CCRP or any position on the radar screen whenever this button is
clicked.

⇒ C ⇒ D ⇒

: Center :The starting point is fixed to the CCRP position.

C : Screen Fix :The starting point is set to the cursor position. If the [ENT] key is pressed

subsequently, the starting position is fixed to the cursor position.

D : L/L Fix :The starting point is set to the cursor position. If [ENT] key is pressed

subsequently, the starting position is fixed to the latitude / longitude of the

cursor.
(Connection of a navigator is necessary.)
If the starting point is moved outside of the screen, the operation is reset

automatically and the starting point returns to the CCRP position.

* D is enabled only when a navigator is connected.

⑬：Parallel index line setting

This function sets the parallel index line display to On / Off and acquires the operation right.
If this button is clicked, the operation right is acquired and the menu is opened. After setting,
determine the setting by pressing the [ENT] key.

⑭：Parallel index line starting point mode switching

The parallel index line starting point is set to CCRP or any position on the radar screen whenever this
button is clicked.
In the same way as for the EBL starting point, three options are available, : Center, C :
Screen Fix, and D : L/L Fix.

yy

2

2-20

Lower right of the display

①：Mark color switching

The color of the mark is switched whenever this button is clicked.
If the button is clicked for 2 seconds, the Mark Setting menu is opened.

②：Own ship's track interval switching

The own ship's track interval is switched whenever this button is clicked.

③：Own ship's track interval unit switching

The unit of the own ship's track interval is switched whenever this button is clicked.

sec ⇒ min ⇒ NM ⇒ sec

④：Map display On / Off

The map display is set to On / Off whenever this button is clicked.
Map information must be inserted in the card slot of the radar process unit in advance.
If the button is clicked for 2 seconds, the Map Setting menu is opened.

⑤：Graphic display Off

While the button is clicked, the graphic display other than VRM, EBL, HL, a cursor, and range rings
on the radar screen is cleared temporarily.

⑥：Ship's heading line Off

The ship's heading line (HL) display is set to Off while this button is clicked.
Since the ship's heading line is cleared while the button is clicked, the target in the ship's heading
bearing can be clearly seen.

⑦：CPA ring display On / Off

The CPA ring display is switched to On / Off whenever the button is clicked.
When the target vector display mode is T (true vector), the CPA ring cannot be set to On.

2-21

Own ship's information

2.3 Functions of Software Buttons

yy

2

①：Heading device switching

The heading device is switched whenever this button is clicked.

GYRO ⇒ CMPS (Electronic compass) ⇒ GCOM (GPS compass) ⇒ GYRO
When the selected heading device is not connected to the equipment, an alarm is issued.

②：Speed sensor switching

The speed sensor is switched whenever the button is clicked.
MAN (Manual) ⇒ LOG (Single-axis water log) ⇒ 2AXW (Dual-axis water log)

⇒ 2AXG (Dual-axis ground log) ⇒ GPS ⇒ MAN

When the selected speed device is not connected to the equipment, an alarm is issued.

③：Time display mode switching

The time display mode UTC (universal time clock) / LMT (local mean time) is switched
whenever this button is clicked.

④：Manual own ship's speed setting

When selection of the speed sensor is set to MAN , enter the own ship's speed manually.
If this button is clicked, the numeric value input screen is opened. After setting a value, determine the
entry by clicking ENT .

2-22

Target tracking (TT) / AIS information

①：Target vector display true / relative switching

The tracked target / AIS target vector display is switched to T (true vector) / R (relative vector)
whenever this button is clicked.
This setting is switched together with the past position display true / relative switching.

②：Target vector length setting

Set a vector length of the tracked target / AIS target.
If this button is clicked, the numeric value input screen is opened. After setting the length, determine
the setting by clicking ENT .

③：CPA limit setting

Set a CPA limit.
If this button is clicked, the numeric value input screen is opened. After setting the limit, determine
the setting by clicking ENT .

④：TCPA limit setting

Set a TCPA limit.
If this button is clicked, the numeric value input screen is opened. After setting the limit, determine
the setting by clicking ENT .

⑤：Past position display true / relative switching

The tracked target / AIS target past position display is switched to T (true past position) /
R (relative past position) whenever the button is clicked.
This setting is switched together with the target vector display true / relative switching.

⑥：Past position display interval switching

The past position display interval is switched whenever the button is clicked.

⑦：Past position display interval unit switching

The past position display interval unit is switched whenever the button is clicked.

min ⇒ NM ⇒ min

2-23

⑧：AIS On / Off

The AIS display is switched to On / Off whenever the button is clicked.

⑨：Tracked target symbol display On / Off

The tracked target symbol display is switched to On / Off whenever the button is clicked. Use this
function to avoid confusion with the AIS symbol.

⑩：AIS target symbol display On / Off

The AIS target symbol display is switched to On / Off whenever the button is clicked. Use this
function to avoid confusion with the tracked target symbol.

⑪：Association On / Off

The tracked target / AIS target association is switched to On / Off whenever the button is clicked.

⑫：AIS filter mode switching

The AIS filter is switched whenever the button is clicked.

Range ⇒ Sector ⇒ Zone ⇒ Range

⑬：Radar trails display true / relative switching

Radar trails are switched to T (true motion trail) / R (relative motion trail) whenever this button
is clicked.
This setting is restricted by the radar display motion mode.
In relative motion display mode (RM), switching to T / R is possible.
In true motion display mode (TM), only T can be set.

⑭：Radar trails display time switching

The radar trails display time is switched whenever the button is clicked.
If the time does not reach the radar trails time that was set, the remaining time is displayed on the
right-hand side.
If the button is clicked for 2 seconds, the RADAR Trails Setting menu is opened.

2.3 Functions of Software Buttons

yy

2

2-24

Digital information: AIS target information

Simple display item

① Detail / simple display

switching

② Unread message display

①：Detail / simple display switching

This function switches the display mode to detail / simple display when AIS target information is
displayed.

②：Unread message display

When there is an unread message from the AIS target that is displayed, the message is displayed. If
this button is clicked, the message is displayed.

2-25

Digital information: Tracked target information

2.3 Functions of Software Buttons

yy

2

①：Tracked target numeric value indication scroll

This function scrolls the target numbers that are indicated in the tracked target information.

Digital information: Navigation information

①：Wind direction / speed numeric value indication true / relative switching

The wind direction / speed numeric value indication is switched to T (true) / R (relative)
whenever this button is clicked.

2-26

Digital information: Wind direction / speed

①：Wind direction / speed numeric value indication true / relative switching

The wind direction / speed numeric value indication is switched to T (true) / R (relative)
whenever this button is clicked.

Menu

①：Digital information display

If this button is clicked while the menu screen is open, the menu is closed and control returns to the
digital information display.
This function switches between the tracked target / AIS target display and navigation information or
the course bar, and so on.

②：Target ship's track menu

If this button is clicked, the Target Track Setting menu is opened.

③：Map menu

If the button is clicked, the Map Setting menu is opened.

④：Main menu

If this button is clicked, the Main Menu is opened.

⑤：Automatic acquisition / activation zone (AZ) menu

If this button is clicked, the AZ Menu is opened.

2-27

⑥：Plotter menu

If this button is clicked, the Plot Menu is opened.

⑦：Radar trails menu

If this button is clicked, the RADAR Trails Setting menu is opened.

⑧：Own ship's track menu

If this button is clicked, the Own Track Menu is opened.

⑨：Tool menu

If this button is clicked, the Tool Menu is opened.

Brilliance

2.3 Functions of Software Buttons

yy

2

Display information

①：Display item switching

The brilliance adjustment screen and display information setting screen interchange whenever this
button is clicked.

2-28

②：Panel lighting brilliance switching

This function enables the setting of the brilliance of the lighting of the control panel.
The brilliance changes whenever this button is clicked. Five levels of settings are available.

③：Radar video brilliance switching

Adjust the brightness of the radar video (echo).
The brilliance changes whenever this button is clicked. Four levels of settings are available.

④：Tracked target / AIS target symbol brilliance switching

Use this function to adjust the brilliance of the tracked target / AIS target symbol.
The brilliance changes whenever this button is clicked. Five levels of settings are available.

⑤：Day / night mode switching

The day / night mode is switched whenever this button is clicked.

Day1 ⇒ Day2 ⇒ Day3 ⇒ Dusk ⇒ Night ⇒ Day1

⑥：User map load

If this button is clicked, the user created map read menu is opened.

⑦：User setting load

If this button is clicked, the user setting read menu is opened.

Alarm

①：Alarm acknowledgment

If this button is clicked, the buzzer sound of the alarm that is currently issued is stopped and the alarm
lamp stops blinking. If multiple alarms are issued, the next alarm to be acknowledged is displayed.
If the button is clicked, the alarm displayed on the top is acknowledged.
The alarms that are currently issued are displayed at the bottom one by one.

②：Alarm log display

If this button is clicked, the alarm log is displayed.

2-29

SECTION 3

BASIC OPERATION

3.1

OPERATION FLOW .......................................................................... 3-1

3.2 OBSERVE AND ADJUST VIDEO ..................................................... 3-5

3.3 OPERATION PROCEDURES ..........................................................3-11

3.4 GENERAL RADAR OPERATION ................................................... 3-21

3.5 USE OWN SHIP'S TRACK DATA ................................................... 3-49

3.6 DISPLAY USER MAP...................................................................... 3-54

3.7 USE ROUTE FUNCTION ................................................................ 3-78

3.8 APPLIED OPERATIONS ................................................................. 3-79

3.9 USE FUNCTION KEY [FUNC] ........................................................ 3-94

3.10 USE USER SETTING.................................................................... 3-100

3.11 USING CARD ................................................................................ 3-102

3.12 DISPLAY SIMPLE CHART ........................................................... 3-108

3.13 CAPTURE SCREEN TO CARD.................................................... 3-121

3.1 OPERATION FLOW

z Do not put anything on the operation panel.

z Do not give any impact to the operation panel,

Each operation is described in detail below.

Attention

If you put anything hot on it, it may be deformed.

trackball, or controls.

Otherwise, any failure or damage may result.

POWER ON AND

START THE SYSTEM

OBSERVE AND

ADJUST VIDEO

ACQUIRE AND

MEASURE DATA

END THE OPERATION AND

STOP THE SYSTEM

3-1

3.1.1 Power ON and Start the System

CAUTION

A malfunction may occur if the power in the ship is
instantaneously interrupted during operation of the radar.
In this case, the power should be turned on again.

z Wait for about 2 seconds before turning on the

z Immediately after the radar is installed, at start of the

z If the preheating time is short, the magnetron

Attention

power again.

system after it has not been used for a long time, or

after the magnetron is replaced, preheat the

equipment in the standby state for 20 to 30 minutes

before setting it into the transmit state.

causes sparks, resulting in its unstable oscillation.

Start transmission on a short-pulse range and

change the range to the longer pulse ranges in turn.

If the transmission is unstable in the meantime,

immediately place the system back into the standby

state and maintain it in the standby state for 5 to 10

minutes before restarting the operation.

Repeat these steps until the operation is stabilized.

3.1 Operation Flow

y y

y

3

3-2

Procedures 1 Check that the ship’s mains are turned on.

2 Press the [STBY] key.

The system is turned on, and the preheating time is displayed.
Preheat is indicated upper left of the display.

3 Wait until the preheating time is over.

When the preheating time is over, the preheating time screen disappears, and Preheat
upper left of the display changes to Standby .

4 Press the [TX / PRF] key.

The radar will start transmission and the antenna will start rotating.
Standby upper left of the display changes to Transmit .

Note: The radar does not start transmission if you Press the [TX / PRF] key while Preheat is

indicated.

3.1.2 Observe and Adjust Video

Procedures 1 Press the [RANGE+] key or [RANGE-] key to set the range to the scale

required for target observation.

2 Turn the dials [GAIN / PL], [AUTO-SEA], and [AUTO-RAIN] to obtain

the clearest targets.

Refer to

[GAIN/PL]→3-7P
[AUTO-SEA]→3-7P
[AUTO-RAIN]→3-9P

for how to use each dial.

For how to adjust video, see Chapter 3.2.

3.1.3 Acquire and Measure Data

For details on how to acquire data and measure, see Section 4 "Measurement of range and bearing."

3.1.4 Display and Measure with Reference to CCRP

The radar video, range, bearing, Target Tracking and AIS data display etc... are displayed with
reference to CCRP (Consistent Common Reference Point).
If scanner is switched, these data are measured from CCRP.
If some kind of functions set scanner position to outside of the PPI range, these data except Target
Tracking and AIS data are displayed with reference to scanner position.
For how to setting CCRP, see the section 7.1.9.

3-3

3.1.5 End the Operation and Stop the System

Exit 1 Press the [STBY] key.

The radar will stop transmission and the antenna will stop rotating.
Transmit upper left of the display changes to Standby .

Maintain the standby state if radar observation is restarted in a relatively short time.
Only pressing the [TX / PRF] key starts observation.

2 Press the [STBY] key and the [TX / PRF] key together.

The system will be turned off.

3.1 Operation Flow

y y

y

3

3-4

3.2 OBSERVE AND ADJUST VIDEO

3.2.1 Adjust Monitor Brilliance [BRILL]

Procedures 1 Obtain the best-to-see display with optimum brilliance by turning the

[BRILL] dial at the lower right of the LCD monitor.

Turning the [BRILL] dial clockwise increases the brilliance of the entire display.
Conversely, turning the [BRILL] dial counterclockwise decreases the brilliance of the
entire display.
In consideration of the ambient brightness, adjust display brilliance that is high
enough to easily observe the radar display but does not glare.

3.2.2 Change Observation Range [RANGE + / - ]

Procedures 1 When increasing the observation range, press the [RANGE+] key.

Increasing the observation range will enable a wider range to be observed.
However, a video image is small and the ability to detect targets near own ship
decreases. Therefore, when observing the vicinity of own ship, use the smaller
observation range.

2 When decreasing the observation range, press the [RANGE-] key.

Decreasing the observation range will enable the vicinity of own ship to be enlarged.
However, caution must be taken because video images of the area beyond the
observation range cannot be displayed.

3-5
