JPL 100-USB Datasheet

Created on: Tuesday 27 April, 2021

JPL 100-USB Monoaural Headset (575-237-001)

Product Name: JPL 100-USB Monoaural Headset (575-237-001) Manufacturer: JPL Telecom Model Number: 575-237-001

JPL 100-USB Monoaural Headset (575-237-001) The JPL-100-USB-M is a direct plug-in, office headset designed to work with both office desk phones and DECT phones. Ideal for small offices and home users, providing better posture and flexibility throughout the day. JPL-100-USB-M Key Features

ï¿½ Single ear ï¿½ Left / right ear side compatible ï¿½ Supplied with USB 2.0 connector ï¿½ Surround Shield™ noise cancelling microphone ï¿½ Fully flexible microphone for exact positioning ï¿½ 300° adjustable microphone boom ï¿½ ‘Put and stay’ ratchet microphone boom arm ï¿½ Acoustic shock protection with Active Protection™ technology ï¿½ Overhead, sure-fit fully adjustable headband ï¿½ MS Lync Compatible ï¿½ In-line control with call accept, volume up/down and mute

JPL-100-USB-M Technical Specifications Microphone

ï¿½ Pattern: Electret ï¿½ Impedance: Max. 3.9KΩ ï¿½ Sensitivity: -43±3dB at 1kHz ï¿½ Directivity: Noise Cancelling ï¿½ Frequency Range: 100-10000Hz ï¿½ Operating Temp: -20°C~+60°C ï¿½ Storage Temp: -40°C~+70°C

Speaker

ï¿½ Pattern: Dynamic moving coil ï¿½ Impedance: 150Ω / 300Ω ï¿½ Sound Pressure: 94±3dB / 91±3dB at 1kHz ï¿½ Sound Intensity: 80mW / 40mW ï¿½ Frequency Range: 300~3.4 kHz ï¿½ Operating Temp: -20°C ~ +60°C ï¿½ Storage Temp: -40°C ~ +70°C

Other

ï¿½ What’s included: Headset fitted with 55mm leatherette ear cushions, spare 58mm foam ear cushions, clothing clip and Quick Start Guide ï¿½ Headset Weight: 44g ï¿½ Connection: USB-A direct plug-in ï¿½ Certifications: FCC, CE, RoHS, REACH ï¿½ Warranty: 1 Year repair or replacement warranty ï¿½ MOQ: Master Shipping Carton: 40 ï¿½ EAN: JPL-100-USB-M: 5060126955658, JPL-100-USB-B: 5060126955689 ï¿½ SKU: JPL-100-USB-M: 575-237-001, JPL-100-USB-B: 575-237-002

www.voipon.co.uk | help@voipon.co.uk | Page 1/2

Created on: Tuesday 27 April, 2021

JPL 100-USB Monoaural Headset (575-237-001)

Price: £31.00

www.voipon.co.uk | help@voipon.co.uk | Page 2/2
