Joy-it DPS BT User guide

DPS BT

BT module

1. GENERAL INFORMATION

Dear customer,

thank you for choosing our product. In the following, we will show you how
to connect the BT module with the JT-DPS5005, JT-DPS5015 and the JT­DPH5005.

Should you encounter any unexpected problems during use, please do not
hesitate to contact us.

2. INSTALLATION

The lab power supplies can be expanded with the BT module which allows
you to control the power supply via your smartphone.

The module will be connected with
this port and is immediately ready for

use. This port is at a dierent

position depending on the power
supply.

Moreover, it is possible to mount the BT-module with one of the lab power
supplies in the JT-DPS-Case which is optionally purchaseable just like the
USB-Module.

First of all, attach the spacers at the
module with two nuts.

The module will be screwed tight from beneath the
case.

The module must be plugged in
the main board. The case can
decrease the range of the BT
module

3. DECLARATION OF CONFORMITY

Hereby, Simac Electronics Handel GmbH declares that the radio equipment
type JT-DPS-BT is in compliance with Directive 2014/53/EU. The full text
of the EU declaration of conformity is available at the following internet
address:

www.simac-gmbh.de/CE/jt-dps-bt.pdf
