User's Manual

DP650

Flatbed Bill Printer

DP650 User’s Manual

- i -

Important Safety Instructions

1. Read all of these instructions carefully and thoroughly and save them for later reference.

2. Follow all warnings and instructions in the manual as well as marked on the product.

3. If the printer has been used just now, please not touch the print head for overheating.

4. Do not put your fingers under the tractor cover of the left and right tractor (optional) when install the tractor paper.

5. Unplug this product from the power outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

6. Do not use this product near water.

7. Do not place this product on an unstable cart, stand or table. The product may fall, causing serious damage to you or the product.

8. Slots and openings on the cabinet and the back or bottom are provided for air ventilation. To ensure reliable operation of the product and to protect it from overheating, do not block or cover these openings. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should never be placed near or over a radiator or heater. This product should not be placed in a built-in installation or kiosk stand unless proper ventilation is provided.

9. This product should be operated from the type of power source indicated on the rating label. If you are not sure of the type of power available, consult your local dealer or an electrician.

10. This product should never be placed near or over a radiator or heat origin, and should avoid of direct sunshine.

11. Do not allow anything to rest on the power cord. Do not locate this product in a location so that the power cord will be walked or driven over or on.

12. Do not locate this product where the cord will be walked on. When the cord or the plug is mangled, please stop using and get a new one replaced. Make sure the old one is far away from the printer, so it can avoid someone who does not know the inside story getting damage.

13. Be sure to use the specified power source. Connection to an improper power source may cause fire or shock.

14. Do not use in locations subject to high humidity or dust levels. Excessive humidity and dust may cause equipment damage or fire.

15. Never push objects of any kind into this product though cabinet slots as they may touch dangerous voltage dots or short out parts.

16. Don’t remove the printer’s out-cover and repair the printer. When needed, call or take it to the professional.

17. To ensure safety, please unplug this product prior to leaving it unused for an extended period. The wall outlet you plan to connect to should be nearby and unobstructed.

18. Unplug this product from the power outlet and leave servicing to qualified service personnel under the following conditions:

A. When the power cord or plug is damaged or frayed. B. If liquid has been spilled into the product. C. If the product has been exposed to rain or water. D. If the product does not operate normally when the operating instructions are followed. Adjust only

those controls that are covered by the operating instructions since importer adjustment of other controls may result in damage and will often require extensive work by a qualified technician to

restore the product to normal operation. E. If the product has been dropped or the cabinet has been damaged. F. If the product exhibits a distinct change in performance, indicating a need for service.

Note: The contents of this manual may be changed without prior notice.

* All parts of the printer can be recycled. When it is abandoned, Please contact us when you

abandon it.

DP650 User’s Manual

- ii -

TABLE OF CONTENTS

Important Safety Instructions

.....................................................................................................................i

Chapter 1 Overvie

w....................................................................................................................................1

1.1 Features..............................................................................................................................................1

Chapter 2 Prep

aration ................................................................................................................................3

2.1 Unpacking ...........................................................................................................................................3

2.2 Unpacking the Protect

ive Materials.....................................................................................................3

2.3 Parts Identification

...............................................................................................................................3

2.4 Installati

on ...........................................................................................................................................4

2.4.1 Installing the Front T

able...............................................................................................................4

2.4.2 Dismantling the Front T

able..........................................................................................................5

2.5 Installing and Replacing the Ribbon Cartridge

....................................................................................5

2.6 Testing the printer

................................................................................................................................6

2.7 Connecting the Interface Cable

...........................................................................................................6

2.7.1 Connecting to the Parallel Interface Cable

...................................................................................6

2.7.2 Connecting to the USB Interface Cable

........................................................................................7

2.7.3 Connecting to the Serial Interface Cable

......................................................................................7

2.7.4 Connecting to the Ethernet Interface Cable

..................................................................................7

2.8 Connecting to the Power Cord

............................................................................................................8

2.9 Installing Driver

...................................................................................................................................8

2.10 Network Set

tings ............................................................................................................................. 11

2.10.1 Connecting Printer

....................................................................................................................11

2.10.2 Setting IP Address

....................................................................................................................11

2.10.3 Installing Printer Network Driver

...............................................................................................13

Chapter 3 Loading p

aper..........................................................................................................................20

3.1 Paper Thickness Adjustment............................................................................................................. 20

3.2 Loading Cut Sheet

............................................................................................................................20

3.3 Using Tractor Paper ..........................................................................................................................22

3.4 Tearing off T

ractor Paper...................................................................................................................24

Chapter 4 Control Panel

........................................................................................................................... 26

4.1 Control Panel Keys and LEDs

...........................................................................................................26

4.2 Basic Control Panel Operations

........................................................................................................26

4.3 Bill Print Mode Function

....................................................................................................................27

4.4 Top of Form Adj

ustment Mode ..........................................................................................................27

4.5 Tear-off Adj

ustment Mode .................................................................................................................27

4.6 Using the Setup Menu System

..........................................................................................................28

4.6.1 Printing the Current Setting Report

.............................................................................................28

4.6.2 Entering the Setup Menu Syste

m and Changing the Settings....................................................30

4.6.3 Restoring Factory P

rinter Settings..............................................................................................30

4.6.4 Explaining Menu

Terms ..............................................................................................................31

4.6.5 Online-aptitude Parameter Setti

ngs............................................................................................32

4.7 Using the Self- T

est Functions...........................................................................................................33

4.7.1 ASCII T

est Mode.........................................................................................................................33

4.7.2 Maintenance Printing T

est (H pattern) ........................................................................................34

DP650 User’s Manual

- iii -

4.7.3 Hex Dump Mode.........................................................................................................................34

4.7.4 Alignment Adjust

Mode...............................................................................................................34

Appendix A Troubleshooting and M

aintenance.....................................................................................36

A.1 Cleaning the Printer ..........................................................................................................................36

A.2 Problems and Solutions

....................................................................................................................37

A.3 Error LED on the Control Panel

........................................................................................................37

Appendix B

................................................................................................................................................39

B.1 Specifications....................................................................................................................................39

B.1.1 General ......................................................................................................................................39

B.2 Printable

Area ...................................................................................................................................40

B.2.1 Parallel Interface

........................................................................................................................ 40

B.2.2 USB Interface

.............................................................................................................................41

B.2.3 Serial I

nterface...........................................................................................................................42

B.2.4 Ethernet Interface

....................................................................................................................... 43

B.3 Printable

Area ...................................................................................................................................44

B.4 Cautions of Printing

..........................................................................................................................45

Appendix C Command Code Summ

ary..................................................................................................46

C.1 Epson Emulation ..............................................................................................................................46

Print and Line Feed Execution.............................................................................................................46

Format Control

.....................................................................................................................................46

Print Mode

...........................................................................................................................................46

Character Set

......................................................................................................................................47

Download Character

............................................................................................................................47

Bit-Image.............................................................................................................................................47

Graphics Mode

....................................................................................................................................47

Input Data Control

...............................................................................................................................47

Miscellaneous......................................................................................................................................48

DP650 User’s Manual

- 1 -

Chapter 1 Overview

1.1 Features

Thank you for purchasing this Jolimark printer.

This versatile, 24-pin, flatbed High speed Bill printer is ideal for a wide range bill printing requirements, especially for tax, mail, telecom, police, hospital, insurance, finance, stock, customhouse, cabaret, aviation and transport etc.

106 Column Flatbed Paper-feed Mechanism

Newly-style 106 column flatbed printer can feed the paper smoothly. Special designed paper guide makes you reassure to print continuously. So that some document papers, such as multi-ply report form, multi-ply invoice, envelope, postcard and label and so on, can smoothly in and out without jam.

Easy Paper Installation

Paper installing design of this printer makes you install paper conveniently. Fast paper installing can also save your time.

Automatic paper Load/Eject Function

Cut sheet may be fed from the front of the printer automatically. Finish printing, the paper may be automatically fed back to the front of the printer. Tractor paper is installed on the tractor. Press LOAD/EJECT key, paper may be fed to print position automatically. Finish printing, the paper may be fed to the front of the printer in order to tear conveniently.

Zero tear-off Function

This causes tractor paper to be automatically fed to the tear-off position at the edge of the window cover, for easy tear-off at the perforations after printing. This zero tear-off capability helps eliminate paper wastage.

Facility switch between cut-sheet and tractor paper

Feed the tractor paper back to the installing position through LOAD/EJECT key on the control panel, pull the paper select lever to the cut-sheet position. Insert the cut-sheet from front to print. If you want to use tractor paper again, pull the paper select lever back to the tractor paper position after cut-sheet printing. Then press LOAD/EJECT key, tractor paper may be fed to the printer again.

Automatic Interface Switching

The DP650 includes a parallel interface, a USB interface, a serial interface or Ethernet interface. (According to specific interface standards) The printer automatically detects the type of data transfer received from the host computer and switches to the corresponding interface type.

High Resolution Graphics

A maximum resolution of 360 × 360 DPI enables the printer to produce fine, sharp graphics.

User- Friendly Control Panel

Current print status and access to all printer functions is available via simple commands from the control panel. In addition, the control panel is used to access the menu system (Setup Menu System) with complete control over the printer’s set-up functions.

Emulation

The printer supports the OKI5530SC and Epson ESC/P-K2 Emulations as standard.

Contain Letter Character Font

This printer contains variously fonts of Roman, Sans Serif, Courier, Prestige, Script, OCR-A&B, Orator and so on which making printed document prettier.

DP650 User’s Manual

- 2 -

Enhance Chinese Character Set

This printer contains GB18030 Chinese character set and also supports 4 bytes Chinese printing.

Compressing Printing

You can set compress print proportion through modifying the Menu System Setting of the printer. (Caution: High Speed mode and Super High mode is invalidated while the printer in Compress printing mode.) In addition, you can set the compress printing through driver. (Only set the compress printing through driver can High Speed printing mode and Super High Speed printing mode are valid.) The compress proportion of these two setting methods is compress relationship.

Facility Switch of High Speed Printing Function

This printer is special designed with one high speed button and one high speed indicator. In OFFLINE mode, the printer can switch among Normal speed, High speed and Super high speed when pressing SPEED key repeatedly. Use high speed key can switch to high speed mode directly. When High speed indicator in on, indicates that the printer is in High speed printing mode. When High speed indicator blinks, indicates the printer is in Super high speed printing mode. When High speed indicator is off, indicates the printer is in Normal speed printing mode. (In graphic printing mode, the printing efforts of High speed printing mode and Super high speed printing mode are the same.)

Facility Switch of Printing Mode

This printer is special designed with a COPY intelligent key. In OFFLINE mode, press COPY key on control panel and it can switch among NORMAL mode, “1+3” mode and “1+6” mode.

Facility Switch of Bill Print Mode

Facility switch of bill print mode is convenient for users to switch among different print modes quickly. According to different printing situations of “Invoice of value-added tax” and “Bill”, using this function can quickly switch to correspondent print mode. In ONLINE mode, holding COPY key for about 3 seconds, the printer enters “Invoice of value-added tax” print mode after beeping once. In ONLINE mode, holding SPEED key for about 3 seconds, the printer enters “Bill” print mode after beeping once.

Note: When the printer is in “Invoice of value-added tax” print mode, the original printing position

of the paper can not be adjusted.

Optional of Automatic Paper edge Detection, Any Position Paper feed Printing and Black Mark Detect Function

User can choose automatic paper edge detection, any position paper feed printing and black mark detect function optionally. Here, printer can detect the borderline of both sides automatically in order to ensure all the printing content is within the printable area. Also, it supports to feed the paper in any position of the paper feed path. Nevertheless, user can choose black mark detect function in the printer settings according to the type of print paper, the printer will carry out black mark detection.

Automatic Paper Skew Detection

The printer can detect the lean of the paper. If it is over the set lean, the printer will eject the paper automatically so that you can ensure the printing quality.

Contain Break Pin Compensation Function

User can set the printer to print using the pin which is in good condition to compensate the break pin.

Pin Switch Printing mode

User can set pins to switch while printing form transverse line in order to improve print head life.

DP650 User’s Manual

- 3 -

Chapter 2 Preparation

2.1 Unpacking

Check each item against the following packing list, if any of these items are missing, please contact your local dealer.

2.2 Unpacking the Protective Materials

1. Open the packing box, lift up the printer, open the top cover of the printer, and remove the packing materials as shown in Figure 2-2.

2. Save all the original packing materials, so that they can be used when transporting the printer.

2.3 Parts Identification

Figures 2-3 and 2-4 highlight the main components of the printer.

Protective materials

Figure 2-2 Unpacking the protective materials

: Printer E: Driver CD (Including user's manual and driver)

B: Front table F: Interface cable C: Ribbon cartridge JMR119 G: Facility user's guide D: Power cord

Figure 2-1 Packing list in the printer box

DP650 User’s Manual

- 4 -

★

According to specific interface standards

2.4 Installation

2.4.1 Installing the Front Table

1. Hold both ends of the front table, make sure the install groove aimed at the positioning pin of crust inside (as Figure2-5 shown), then push it forward.

2. Press downwards the front table, making install groove locked on the positioning pin of the top.

Figure 2-3 Main parts of printer (front view)

: Paper select lever G: Gap adjust lever B: Control panel H: Carriage shaft C: Power switch I: Ribbon cartridge D: Paper guide J: Print head E: Front table K: Top cover F: Sub friction lever

Figure 2-4 Main parts of printer (rear view)

: Paper feed knob B: Parallel interface C: USB interface D: Serial interface or Ethernet interface E: Paper guide slider F: Tractor G: Power supply inlet

DP650 User’s Manual

- 5 -

2.4.2 Dismantling the Front Table

Hold both ends of front table, press the front table or printer slant side, lift it up and then take it out.

2.5 Installing and Replacing the Ribbon Cartridge

1. Turn off the printer.

2. Hold the concaves of the printer cover to open the top cover.

3. Hold up the sub friction lever. (As Figure2-6 shown)

4. Move the gap adjust lever to the highest position.

5. Move the print head to the middle of the printer.

6. Turn the ribbon knob in the direction of the arrow to remove any slack from the ribbon so it is easier to install. (As shown below)

7. Hold both sides of the ribbon cartridge; aim the locking buckle at the install groove, push it front way until

it locked in place firmly . Then aim the ribbon guide frame at the two poles on the carriage frame, fix it with pressure as shown in Figure2-8.

Figure 2-5 Installing the front table

Figure 2-6 Opening the top cover and the sub friction lever

Ribbon knob

Ribbon cartridge (JMR119)

Ribbon core

Ribbon nip

Figure 2-7 Ribbon cartridge

Top cover

Sub friction lever

Print head

Positioning pin

Install groove

Front table

DP650 User’s Manual

- 6 -

8. Turn the ribbon knob in the direction of the arrow again to remove any slack from the ribbon. It should not

be twisted or creased.

9. Slide the print head from side to side to make sure it moves smoothly.

10. Having installed the ribbon, lower the sub friction lever and pull the gap adjust lever back to the former position. Then close the top cover.

Note: 1. When your print becomes faint, you need to replace the ribbon cartridge. Otherwise, the

print quality will be affected and the print head may be damage.

2. To remove the old ribbon cartridge, first make sure the power is turned off, move the print head to the center of the printer. Release the ribbon nip and then hold the ribbon cartridge handle on both sides and lift it out of the printer forwards. Install a new one as the above steps.

3. Never remove the print head when printer is on, or else the printer may get damaged. Besides, do not touch the print head at the time finishes using the printer for overheating.

4. Please use the Jolimark JMR119 ribbon cartridge, our comp any will not guarantee to keep

the printer in good repair, when it is damaged by unauthorized ribbon cartridge.

2.6 Testing the printer

Before connecting the printer and computer, Please use the self-test function to examine if the printer

working properly. Please refer to Chapter 4.7 Using the Self- Test Functions for details.

2.7 Connecting the Interface Cable

Your printer can be configured with parallel interface, USB interface, serial interface or Ethernet interface. (According to the specific interface standards) Connect the printer to your computer as described below. As Figures 2-9, 2-10, 2-11 and 2-12 show.

Caution: Make sure that the power switches of both printer and host computer are turned off before

you connect the parallel interface cable.

2.7.1 Connecting to the Parallel Interface Cable

1. Turn off both the computer and the printer. Plug the parallel interface cable securely into the printer's parallel interface. Squeeze the wire clips together until they lock in place on either side. (As Figure 2-9 shown)

2. Plug the other end of the cable into the computer's parallel interface, and then tighten the screws on

either side.

Carriage guide pole

Metal patch

Ribbon cartridge

The ribbon nip

Figure 2-8 Installing the ribbon cartridge

DP650 User’s Manual

- 7 -

2.7.2 Connecting to the USB Interface Cable

1. Plug the USB cable A end (flat shape) into the computer's USB interface. (As Figure 2-10 shown)

2. Plug the USB cable B end (square shape) into the printer's USB interface.

Note: Don't impact the plug after connecting to the USB cable.

2.7.3 Connecting to the Serial Interface Cable

1. Turn off both the computer and the printer. Plug the serial interface cable securely into the printer's serial interface. Tighten the screws on both sides of the connector. (As Figure 2-11 shown)

2. Plug the other end of the cable into the computer's serial interface; then tighten the screws on both sides of the connector.

2.7.4 Connecting to the Ethernet Interface Cable

Plug the RJ-45 crystal end of the Ethernet cable into the printer, and plug the other end into the LAN. (Shown as Figure 2-12)

Figure 2-11 Connecting to the serial interface

Serial interface cable

Serial interface

Screw

Parallel interface cable

Parallel interface

Wire clips

Figure 2-9 Connecting to the parallel interface cable

USB interface

USB interface cable

Figure 2-10 Connecting to the USB interface cable

DP650 User’s Manual

- 8 -

Note: The details of Ethernet interface printer’s net setting please refer to the User’s Manual.

2.8 Connecting to the Power Cord

1. Make sure the printer is turned off. (The pressed down side which marks “O” indicates the printer is off.)

2. Make sure the voltage required by the printer matches that of your electrical outlet.

3. If the power cord is attached to the printer, connect it to the AC inlet on the printer.

4. Plug the power cord into a properly grounded electrical outlet.

 To turn the printer ON, press the I mark at the side of the power switch.  To turn the printer OFF, press the O mark at the side of the power switch.

Caution: 1. If the rated voltage doesn’t match the outlet voltage, cont act your dealer for assistance.

Do not plug in the power cord.

2. Use the electrical outlet connecting the ground properly.

2.9 Installing Driver

Please use the cable to connect computer with printer, then turn on the computer and the printer, put the driver CD into the CD-ROM. Install driver by the following way:

Auto-install way

Double click the file "Setup.exe" in the driver disc, install driver by the following direction.

Note: Auto-install way just work in operating system of Windows2000 or above.

Hand-operated install way

Note: The hand-operated install ways of serial interface and parallel interface are the same.

Figure 2-12 Connecting to the Ethernet interface cable

Ethernet cable

Ethernet interface

Figure 2-13 Connecting the power cord to the printer

Power switch

Power supply inlet

Power cord

Electrical outlet

DP650 User’s Manual

- 9 -

The installing steps for Windows 2000/XP/Vista are as follows

1. Click "Start” → "Settings", select "Printers".

2. Click "Add Printer", then it will show a window of "Add Printer Wizard", click "Next", then please read the select direct carefully, Such as, select "Local printer” in the "Local or Network Printer" window, then click "next".

3. Come out a window of "Select the Printer Port”, select a usable port. Such as, select "LPT1: printer port", click "Next".

4. Come out a window of "Manufacturers/Printers", click "Have Disk...", click "Next".

5. Come out a window of "Install From Disk". Please according to the operating system environment, such

as Windows XP operating system you should select the path as follow: CD — ROM — "Driver" — "WIN2000 (XP-Vista-Win7)", that you can find a file named: DP650.inf, click "Open", then click "OK", click "Next".

6. Follow the direct click "Next" gradually till the installation is finished.

The installing steps for Windows 7 are as follows:

1. Click "Start" → "Devices and Printers".

2. Click "Add a printer", then it will show a window of "Add Printer", click "Add a local printer", and then click "Next".

3. Come out a window of "Choose a printer port", select "Use an existing port", Such as, select "LPT1:

Printer Port", click "Next".

4. Come out a window of "Manufacturers/Printers", click "Have Disk...", click "Next".

5. Come out a window of "Install From Disk". Please according to the operating system environment, such

as Windows 7 operating system you should select the path as follow: CD — ROM — "Driver" — "WIN2000 (XP-Vista-Win7) ", where you can find a file named: DP650.inf, click "Open", then click "OK" to return to the window of "Manufacturers/Printers", click "Next".

6. Follow the direct click "Next" gradually till the installation is finished.

The USB interface installing steps for Windows 2000/XP/Vista/Win7 are as follows:

The following steps are used Windows XP as example. There are slight differences among different operating systems.

1. Connect an USB cable and turn on the printer.

2. After the computer find out new hardware and finish searching, come out a window of "Found New Hardware Wizard", choose "Install from a list or specific location (Advanced), click "Next".

3. Come out a window of "Add New Hardware Wizard" — "Windows operation", choose "Don’t search, I will choose the driver to install", click "Next".

4. Come out a window of "Hardware Type”, select "Printer”, click "Next". Come out a window of

"Manufacturers/Printers", click "Have Disk...", click "Next”.

5. Come out a window of "Install From Disk". Please according to the operating system environment, you

should select the path as follow: CD — ROM — "Driver" — "WIN2000 (XP-Vista-Win7) ", where you can find a file named: DP650.inf, click "Open”, then click "OK" to return to the window of "Add printer wizard" , click "Next".

6. Follow the direct click "Next" gradually till the installation is finished.

The installing steps for Windows 98 are as follows:

（1）The installing steps with a parallel cable or a serial cable:

1. Click "Start" → "Settings" → "Printers".

2. Double click "Add Printer", then it will show a window of "Add Printer Wizard", click "Next", then please read the select direct carefully, Such as, select "Local printer" in the "Local or Network Printer" window, then click "Next".

DP650 User’s Manual

- 10 -

3. Come out a window of "Click the manufacturer and model of your printer", click "Have Disk...", please click "Browse", select the path as follow: CD — ROM — "Driver" — "WIN98 (WINME) ", where you can find a file named: DP650.inf, click "Open", then click "OK".

4. Come out a window of "Install From Disk", click "OK", return to a window of "Add Printer", then click

"Next".

5. Come out a window of "Printer port", select "Available ports", Such as, select "LPT1: Printer Port",

click "Next", and then show the printer’s name. If the system is not installed by other printer driver process, the printer is treated as default printer by the application process of Window98 environment, click "Next". Otherwise according to prompt, choose the printer is default: "Yes", click "Next", choose "Yes-(recommended)", click "Finish". Come out a window of "Printer test page completed!", click "Yes".

6. The printer driver process is installed successfully.

（2）The installing steps with an USB cable:

Note: 1. As the s ystem of Windows 98/ME doesn’t have integrated USB driver control, please

install USB driver before using USB interface printing. Then install USB printer driver.

2. If it has installed the USB driver, please install the USB printer driver directly as the following steps.

USB driver installing steps:

1. Connect an USB cable and turn on the printer.

2. After the computer find out new hardware and finish searching, come out a window of "Add New Hardware Wizard", click "Next".

3. Come out a window of "Add New Hardware Wizard" — "Windows operation", choose "Search the best driver for the device (recommended)", click "Next".

4. Come out a window of "Search for new drivers", check "Specify a location", click “Browse", select the path as follows: CD — ROM — "Driver" — "【WIN98（WINME）\USB driver】", then click "OK".

5. Return to a window of "Search for new drivers", click "Next"; Come out a window of "Windows driver file search for the device", click "Next".

6. After the system finishing installing the file automatically, come out a window of "USB print supported,

click "Finish".

7. The printer USB driver process is installed successfully.

USB printer driver installing steps:

1. Click "Start" → "Settings" → "Printers".

2. Click "Add Printer", then it will show a window of "Add Printer Wizard", click "Next".

3. Come out a window of "Click the manufacturer and model of your printer", click "Have Disk...", please

click "Browse", select the path as follow: CD — ROM — "Driver" — "WIN98 (WINME) ", where you can find a file named: DP650.inf "Open", and then click "OK".

4. Come out a window of "Install From Disk", click “OK”, return to a window of “Add Printer", then click

"Next".

5. Come out a window of "Printer port", select "Available ports", select "JMUSB", click "Next", and then show the printer’s name. If the system is not installed by other printer driver process, the printer is treated as default printer by the application process of Window98 environment, click "Next”. Otherwise according to prompt, choose the printer is default: "Yes", click "Next" choose "Yes-(recommended)", click "Finish". Come out a window of "Printer test page completed!", click “Yes".

The printer driver process is installed successfully.

DP650 User’s Manual

- 11 -

2.10 Network Settings

Please use Jolimark network setting software NetFinder to set the IP address for Jolimark printers, which can be found in the CD or downloaded from www.jolimark.com

Caution: The network printing function needs the operation system of Windows2000 or above.

2.10.1 Connecting Printer

Power on the printer, connect with the Ethernet cable which has been connected to LAN, and look into the information of Ethernet LED indicator to ensure the printer has entered into the normal connection.

2.10.2 Setting IP Address

1. Running NetFinder Software Double click NetFinder.exe in the PC which connects the printer in the same LAN. The figure of the

software is shown as follows:

2. Searching printer Click “Search” button in the main interface, the dialog box appearing will begin searching

automatically and show the state, listing a printer in the main interface if found. The time is counting down in the progress bar (10s in total) and the search will finish as soon as the time is over. When going on searching, press “search” button again.

Yello w LED Green LED Description

ON Blink Normal

OFF OFF Not connect to network

Button description: Exit — Exit from the software Search — Search printers in the same LAN Assign IP — Modify the IP address and other settings for the specified printer.

DP650 User’s Manual

- 12 -

If the printer still can not be found out when the network connection is correct and in the same network, Please check whether the network fire wall on the PC open or not. If there is fire wall, please close it temporarily, open again after finishing searching and setting a printer completely.

3. Setting printer’s IP address The printer’s information is listed in the main interface, the left side of which is the model and

description and the right is the IP and MAC address. What’s more, the assign mode (dynamic/static) is noted behind the IP address.

1) Correlative description for IP address settings

In order to search and set printer’s IP address conveniently for the first time, the factory default

setting is DHCP mode which assigns IP address dynamically. If there is no DHCP server in the connected LAN and printer is set to DHCP mode as well, then it will use the internal pre-set address (IP: 10.0.0.1, Subnet Mask: 255.255.255.0) automatically.

It is suggested that printer’s IP set to static in actual usage, which can cut down the time when

initializing the Ethernet interface as the printer is turned on and prevent IP conflicts (The dynamic address used in printer may conflict with another one). The network segment part of the IP address

DP650 User’s Manual

- 13 -

and Subnet Mask must be the same as those of PC connecting with a printer. For example, the address of working PC is 192.168.0.1/255.255.255.0 (IP/Subnet Mask), then which of printer should be set to 192.168.0.x/255.255.255.0（x=2~254 and should avoid the IP in used. It is not restricted for NetFinder to search printers in the same network but different segment parts (can not stride gateway). Relative glossary of IP address may refer to corresponding information.

2) Setting printer’s IP address Select the printer information to be modified (black frame appears), click “Assign IP” button. Set the

IP in the dialog box appearing.

Check the “Use DHCP” if need to assign dynamic address, the settings above will be disabled automatically. Please make sure there is a DHCP server in the network, or the printer can not receive an effective IP address.

When to specify static address, uncheck “Use DHCP” and fill in “IP address”, “Subnet Mask” and

“Default Gateway”. If there is no gateway in the network, fill 255.255.255.255 in the “Default gateway”. “IP address” and “Subnet Mask” should obey the assigning rules of local LAN (Ethernet), please enquire the administrator of networks which the printer connects to for more details. Click “OK” to send address setting information to the specified printer. The printer takes response after “Close this window on success” is checked, and then this dialog is closed automatically. Select “Reload Timer” then the software will wait for the printer’s response. Generally, printer will take response in a circle time if network connection is correct.

Click “Cancel” if you abandon the modification. Click “Search” in the main interface again to update printer information after modifying the printer’s

IP address.

3) Report printer’s IP address Report the printer’s IP address, which will be used in the section “Newly-install printer network

driver” or “Upgrade-install printer network driver (setting driver’s network port)”.

2.10.3 Installing Printer Network Driver

The ways of installing network driver are divided into Newly-install way and Upgrade-install way according to whether the PC installs the printer driver or not. If the printer driver hasn’t been installed on the PC, adopt newly-install way whose steps are shown in “Newly-install printer network driver”. If the printer driver has been installed on the PC, adopt Upgrade-install way whose steps are shown in “Upgrade-install printer network driver”.

1. Newly-install printer network driver

DP650 User’s Manual

- 14 -

1) Click “Start” → “Settings”, select “Printers”.

2) Click “Add printer”, then come out a window of “Add Printer Wizard”, click “next”,

3) Come out a window of “Add Printer Wizard”, then please read the select direct carefully. Such as,

select “local or Network Printer”, then click “next”.

4) Come out a window of “Select the Printer port”, select a port you want your printer to use. For

example, select “Create a new port”, select “Standard TCP/IP Port” in the port, click “next”.

5) Come out a window of “Add standard TCP/IP Printer Port Wizard”, click “Next”.

6) Come out a window of “Add Port”, enter the IP address reported by the “Setting printer’s IP address”

in the “Printer Name or IP Address” column. Take IP address “192.168.0.240” for example. “Port Name” is created automatically after finishing filling in IP address.

DP650 User’s Manual

- 15 -

7) Come out a window of “Additional Port Information Required”, select “Custom” in the “Device Type”,

and then click “Settings”.

8) Come out a window of “Port Settings”. Affirm that “Port name” and “Printer name or IP address” are

correct, “Protocol” is “RAW” and “Port Number” is “9100”, click “OK”.

DP650 User’s Manual

- 16 -

9) Return to “Additional Port Information Required”, click “Next”.

10) Come out a window of “Completing the Add Standard TCP/IP Printer Port Wizard”, click “Finish”.

11) In the selection of "Manufacturers/Printers", click “Have Disk”, and then click “Next”.

12) Come out a window of “Install From Disk”. Please according to the operating system environment,

such as Windows XP operating system you should select the path as follows: CD — ROM — “Driver” — “WIN2000 (XP-Vista-Win7)”, that you can find a file named: DP650.inf, click “open”, then click “OK”, then return to the window “install printer software”, click “next”.

13) Follow the direct click “next” gradually till the installation is finish. At this time, printer network driver

is installed completely.

2. Upgrade-install printer network driver (setting driver’s network port)

If PC has installed the printer’s driver, set driver’s network port to carry out network printing. The concrete steps are shown below:

1) Click “Start” → “Settings”, select “Printers”.

2) Right click DP650 driver, click “Properties” on the window coming out.

3) Come out a window of “Properties”, click “Ports” and “Add Ports”.

4) Come out a window of “Printer port”, select “Standard TCP/IP Port”, click “New port”.

DP650 User’s Manual

- 17 -

5) Come out a window of “Add Standard TCP/IP Printer Port Wizard”, click “Next”.

6) Come out a window of “Add a port”, import the IP address reported by the “Setting printer’s IP address” in the “Printer name or IP address” column. Take IP address “192.168.0.240” for example. “Port name” is created automatically after finishing filling in IP address. Click “Next”.

7) Come out a window of “Port information”, select “User-defined” in the “Equipment style”, then

click “setting”. Come out a window of “Additional Port Information Required”, select “Custom” in the “Device Type”, then click “settings”.

DP650 User’s Manual

- 18 -

8) Come out a window of “Port Settings”. Affirm that “Port name” and “Printer name or IP address”

are correct, “Protocol” is “RAW” and “Port Number” is “9100”, click “OK”.

DP650 User’s Manual

- 19 -

9) Return to “Additional Port Information Required”, click “Next”.

10) Come out a window of “Completing the Add Standard TCP/IP Printer Port Wizard”, click

“Finish”.

11) Return to “Printer Ports”, click “Close”.

12) Return to “Properties”, make sure the network port is selected, click “Apply”, and then click

“Close”. Thus, printer’s network port setting is finished.

DP650 User’s Manual

- 20 -

Chapter 3 Loading paper

3.1 Paper Thickness Adjustment

Before loading cut sheet or tractor paper, you have to adjust the gap adjust lever on the front right side of the printer.

To feed thicker papers through the printer, you need to move the gap adjust lever from its standard position. The lever moves the print head relative to the platen so that there is more room for the paper.

Adjusting the gap adjust lever

To obtain good quality printing and prevent problems (paper jam etc.), adjust the gap adjust lever as shown in Figure 3-1. The scale number # 1 shown in Figure 3-1 identifies the standard paper thickness setting. This is the recommended setting for most paper. Use Table 3-1 to find the recommended setting for other paper.

3.2 Loading Cut Sheet

1. Turn the printer on.

2. Set paper select lever toward the back of printer as shown in Figure 3-2. Make sure the cut sheet

symbol is aimed at the “△” symbol on the printer case.

Position Paper thickness

1 0.06 mm-0.12 mm

1.5 0.12 mm-0.22 mm 2 0.22 mm-0.32 mm

2.5 0.32 mm-0.42 mm 3 0.42 mm-0.52 mm

3.5 0.52 mm-0.62 mm 4 0.62 mm-0.70 mm

4.5 0.70 mm-0.78 mm 5 0.78 mm-0.85 mm

Gap adjust lever

Figure 3-1 Setting the gap adjust lever

Table 3-1 Paper thickness setting

Remark:

DP650 User’s Manual

- 21 -

3. Set the gap adjust lever for example to the position “1” for thin paper.

4. Position the paper guide by referring to the marking on the window cover. As shown in Figure 3-3, the “0” mark on the left side of the printer front cover indicates that is the horizontal printing start position.

5. Please pull out the small front table extension tabs if the size of paper is long and requires extra support, as shown in Figure 3-4.

6. Insert the paper (printing side is faced up) alongside the edge of the paper guide, push it into the

printer slowly until it reach resistance, as shown in Figure 3-5.

Figure 3-3 Adjusting the paper guide

Figure 3-2 Setting the paper select lever

Front table extension tabs

Figure 3-4 Pull out the small front table extension tabs

Cut sheet

Tractor paper

DP650 User’s Manual

- 22 -

7. Wait about 0.5 to 2 seconds, printer will feed paper to the printing home position automatically. Then

it is ready to print.

After finish printing one page, printer auto feed the paper back to the front table and the PAPER OUT

LED blinks while the ONLINE LED goes out. If you need to print multipage document, just remove the printed paper and load another page again, printer will feed paper automatically and go on printing.

3.3 Using Tractor Paper

Tractor paper is installed on the tractor. This printer feeds tractor paper from the rear of the printer to the front.

1. Turn the printer on.

2. Set paper select lever toward the front of printer as shown in Figure 3-7.

3. Move the paper guide to the far left as much as possible. (As shown in Figure 3-8)

Figure 3-5 Loading cut sheet

Figure 3-6 Feeding direction of tractor paper

Out

Figure 3-7 Setting the paper select lever

DP650 User’s Manual

- 23 -

4. Release the lock lever of tractor. (As shown in Figure 3-9)

5. Move the left tractor to the left proper position (The “0” position indicates the horizontal printing home position). Move the left tractor to the leftmost position, lock the left tractor. Moving the right tractor to the proper position, but do not lock it yet.

6. Move the paper guide slider to the center between the left and right tractor.

7. Open the tractor covers and place the paper on the sprocket pins. If you are using preprinted paper or labels, install them with the printed or labeled side facing upwards. (As Figure 3-12 shown)

Figure 3-8 Moving the paper guide to the far left

Figure 3-9 Releasing the lock lever of the right tractor

Figure 3-10 Adjusting the tractor position

Figure 3-11 Adjusting the paper guide slider position

DP650 User’s Manual

- 24 -

Caution: Please make sure the edge of the tractor paper is straight and smooth which

ensures the paper feeding is smoothly.

8. Close the tractor covers. (As shown in Figure 3-13)

9. Slide the right tractor to the right to take up any slack in the paper, and then fasten the lock lever to fix the tractor in position. (As shown in Figure 3-14) Ensure the tractor paper is in line with the printing home position. If the paper is not aligned with the printing home position, align the paper, and then fasten the lock lever to lock the tractors.

10. Turn on the printer. When starting a new print task, the printer will automatically load the paper

before the actual printing starts. (You can also press the LOAD/EJECT key to load the paper manually.)

3.4 Tearing off Tractor Paper

Tear off function is on when printer leaves factory. To tear off the paper, make sure that printed-paper is fed to the front table. If not, switch the printer offline then press the LOAD/EJECT key. Hold the edge of the paper and pull it towards the edge of the window cover as shown in Figure 3-15. If the perforation of the paper is not at the edge of the window cover, adjust the tear-off position (refer to chapter 4, Control Panel).

The lock lever

Figure 3-12 Setting paper on the sprocket pins

Figure 3-13 Close the tractor covers

Figure 3-14 Locking the position of the right tractor

DP650 User’s Manual

- 25 -

Figure 3-15 Tractor paper tear-off

DP650 User’s Manual

- 26 -

Chapter 4 Control Panel

4.1 Control Panel Keys and LEDs

The control panel consists of five keys and four LEDs as shown in Figure 4-1.

The following table details each indicator LED function:

4.2 Basic Control Panel Operations

You can use the five keys on the control panel to operate your printer.

ONLINE Press the ONLINE button, switch between ONLINE and OFFLINE modes. LOAD/EJECT

When offline, press LOAD/EJECT key can control cut sheet or tractor paper feeding. In cut sheet mode, if you press LOAD/EJECT key when offline, the paper will be ejected. In tractor paper mode, if you had fixed tractor chain wheel, press LOAD/EJECT key when offline, the printer will be fed to the printing home position. The printer now being in the online mode. You need to being in the offline mode again, then press LOAD/EJECT key, paper will be fed to the tear position. Press it one more time paper will again back to the ready position, repetition.

Indicator LED

On Blink Off

PAPER OUT (red)

Compounding reference (see Appendix A.3)

Paper out or malfunction

The printer is in the standard mode

ONLINE (green)

Lights when the printer is online.

The printer is offline

Compounding reference (see Appendix A.3)

COPY MODE ( green )

The printer is in the “1+3” mode.

The printer is in the “1+6” mode.

The printer is in the normal mode.

SPEED MODE (green)

Lights when the printer is in high speed mode.

The printer is in super high speed mode

The printer is in the letter quality mode.

Figure 4-1 The printer control panel

Table 4-1 LEDs on the control panel

DP650 User’s Manual

- 27 -

LF/FF

In the offline mode, press the LF/FF key to feed the paper line by line. Alternatively, hold the LF/FF key down, the printer will eject the cut sheet, or feed the tractor paper one page.

COPY

In the offline mode, press the COPY key, switch among the three modes: NORMAL,

COPY “1+3” MODE, and COPY “1+6” MODE.

SPEED

Pressing the SPEED key, switch among the HIGH SPEED mode, SUPER HIGH SPEED mode and NORMAL mode. If HIGH SPEED LED on, indicates that the printer is in HIGH

SPEED print mode: If HIGH SPEED LED blinks, indicates that the printer is in SUPER HIGH SPEED mode: If HIGH SPEED LED off, indicates that the printer is in LETTER QUALITY mode. (When printer in graphic print mode, the effects of high speed mode

and super high speed mode are the same.)

4.3 Bill Print Mode Function

In ONLINE mode, holding COPY key 3 seconds, after beep once, the printer enter “Invoice of

value-added tax” print mode.

In ONLINE mode, holding SPEED key 3 seconds, after beep once, the printer enter “Bill” print mode. Note: Under “Invoice of value-added tax” mode, the top of form position can not be adjusted.

Please in ONLINE mode, holding SPEED key 3 seconds, the printer enter “Bill” print mode after beep once. Then adjust the top of form position.

4.4 Top of Form Adjustment Mode

The top of form setting determines the margin between the top of paper and the first printed line (the top margin).

In the ONLINE mode, press the LF/FF key for about 3 seconds to enter the top of form adjustment mode. The ONLINE and PAPER OUT LED will blink alternating.

Use the LOAD/EJECT and LF/FF keys to alter the top of form setting (The maximum removable value of the printing home position is based on the default zero position.):

LOAD/EJECT: Increase the top of form by 1/60 inch. You can increase the margin to a maximum of +60

increments (+60/60 inch) from the factory setting.

LF/FF: Decrease the top of form by 1/60 inch. You can decrease the margin to a maximum of -10

(-10/60 inch) from the default setting.

Press the ONLINE key to exit and save your new setting. The PAPER OUT LED and ONLINE LED blink simultaneously twice with two beeps, and then the ONLINE LED will be on.

4.5 Tear-off Adjustment Mode

The tear-off setting determines the distance between the perforation of tractor paper and the tear-off bar. If the default distance is not suitable for you, you can adjust it by the printer’s tear-off adjustment feature.

With the printer online, press both the LOAD/EJECT and LF/FF keys for about 3 seconds to get the printer to enter the tear-off adjustment mode. When the printer enters this mode, the ONLINE LED and the PAPER OUT LED blink alternately.

Use the LOAD/EJECT and LF/FF keys to alter the tear-off setting (The maximum removable value of the tear off position is based on the default zero position.):

NOTE

To exit without saving, just turn the printer off.

DP650 User’s Manual

- 28 -

LOAD/EJECT: Press the LOAD/EJECT key to adjust the distance in 1/60 inch increments. You can

maximum increase to +15/60 inch

LF/FF: Press the LF/FF key to adjust the distance in 1/60 inch decrements. You can maximum

decrease to -15/60 inch

To exit and save your new setting, press ONLINE key. The PAPER OUT LED and the ONLINE LED blink simultaneously for 2 times with two beeps, then the POWER LED turns on. Your new tear-off setting value is saved.

4.6 Using the Setup Menu System

4.6.1 Printing the Current Setting Report

You can use the information in the current setting report to decide which setting you want to change.

To print the current settings:

1. Turn the printer off.

2. If using the tractor paper, please fix the tractor paper properly (At less 240 mm width)

3. Hold down both the LOAD/EJECT and LF/FF key at the same time. Turn the printer on.

The printer automatically loads paper and prints the current settings. An example print out is shown in Figure 4-2.

Caution: 1. The options whose color is printed contrarily are the current settings. If the

initialization of “Language” is “English”, saving the setting and operating the upper steps again, and it will print the current settings in English. The way of changing the settings is in the next section.

2. When the driver has compress printing scale function, If choose 80% compress mode in the driver, at the same time, choose 75% compress mode in the menu settings system. Then it will comes a result that the transverse compress will be 80% x 75% = 60%.

3. When choose 75% compress mode in the menu settings system, HIGH

SPEED/SUPER HIGH SPEED print mode will not be valid.

NOTE

To exit without saving, just turn off the printer.

DP650 User’s Manual

- 29 -

LANGUAGE CHINESE EMULATION OKI CHAR. MODE CHINA

FONT SANS SER COURIER PRESTIGE SCRIPT OCR-B OCR-A

ORATOR

ENG PITCH

12 CPI 15 CPI PROPORTIONAL

CHI PITCH 7.5 CPI SLASH ZERO ON INTL CHAR SET FRANCE GERMANY U.K. DENMARK1 SWEDEN ITALY

SPAIN 1 JAPAN NORWAY DENMARK2 SPAIN 2 LATIN AM KOREA LEGAL NETHER TURKEY

CHARACTER SET ITALICS CODE PAGE MULTI PORTUGAL CANADA NORWAY EAST EURO CYRILLIC RUSSIAN HUNGARY KAMENICKY TURKEY ICELAND BULGARIA MAZOVIA GRK 437 GRK 851 GRK8859-7 GRK 1253 ARAB NLS ARAB EXT WIN LAT1 WIN LAT2 ISO LTN1 ISO LTN2 TUR8859-9 ISO LTN9 KBL LATIN 7

LINE SPACING 8 LPI FORM LENGTH 3 INCH 3.5 INCH 11/3 INCH 4 INCH 5 INCH 5.5 INCH 6 INCH 7 INCH LETTER 12 INCH 14 INCH FORM LOCK ON PAGE SKIP ON COMPRESS PRT 75% 50% LEFT EDGE 1/10 INCH 2/10 INCH 3/10 INCH 4/10 INCH 5/10 INCH 6/10 INCH EDGE DETECT OFF BLACK MARK

LEFT RIGHT

PRINT DIR BI-DIR UNI-DIR QUIET MODE

AUTO LF

AUTO TEAR OFF OFF LOADING PUSH KEY 0.5 SEC. 2.0 SEC. EJECT REAR SKEW DETECTION ON SKEW LEVEL 001 002 004 005 006 007 008 009 010 PIN SWITCH ON

BAUD RATE 19200 BPS 4800 BPS 2400 BPS 1200 BPS PAR ITY ODD EVEN DATA BIT 7 BIT STOP BIT 2 BIT PRTOCOL XON/XOFF

24 23 22 21 20 19 18 17

16 15 14 13 12 11 10 09

08 07 06 05 04 03 02 01

Current Setting Report

Figure 4-2 Setup menu system

DP650 User’s Manual

- 30 -

Note: 1. Only after installed the subassembly of automatic edge detection, the current settings of

black mark detection and paper edge detection can be printed out.

2. If printer hasn’t installed Ethernet interface, it will not print out the relative Ethernet information of MAC and IP when it runs self-test or menu printing.

4.6.2 Entering the Setup Menu System and Changing the Settings

If need to use different fonts or printing formats, you can use the setup menu system to change the

settings.

The operating steps of changing the menu system

1. Turn on the printer.

2. Load the paper to the top of form position (make sure the paper is long enough) then switch the

printer ONLINE.

3. Keep pressing the LOAD/EJECT key for 3 seconds. The Power LED and Online LED blink 3 times at the same time to denote the printer has entered

Menu Setting Mode. Title and first menu is printed out primarily. (As Figure 4-3 shown) The default settings are

underlined. Print head stops under the default setting.

4. Make a selection from the menu with the keys on the control panel:

Press: To:

LOAD/EJECT

Select menu options or menu setting values.

LF/FF

Go to the next menu or save the menu settings. Note: Newly setting will be shown in fill character.

ONLINE Move to the upper menu (Holding on pressing ONLINE key will back to main

menu directly)

SPEED

Save the settings and exit the menu setting system

5. When you have made all of your settings (remember that you don’t have to go all the way through the menu system), holding on press COPY key, newly settings will be stored and exit the menu setting mode. If you do not want to store the settings, just switch off the printer directly.

6. Switch the printer off and then turn on again. New settings of the menu will take effect.

4.6.3 Restoring Factory Printer Settings

You can restore to the factory printer settings without having to work through the Setup Menu System to

Figure 4-3 Setup menu system

SETUP MENU SYSTEM

Use the LOAD/EJECT key to point the print head to the desired setting. Use the LF/FF key to confirm the current setting Use the ONLINE key to go back the previous menu (Press and hold the ONLINE key to go back to the main menu). Press and hold the COPY key to save settings and exit.

Current settings are

New settings will be FILLED.

SYSTEM SETUP CHARACTER PAGE LAYOUT PRINT SETUP SERIAL I/F HEAD PIN

DP650 User’s Manual

- 31 -

reset the menus.

To restore to the factory settings:

1. Make sure that the printer is ONLINE.

2. Press and hold down the ONLINE and COPY keys on the control panel for 3 seconds. The LEDs of the POWER and ONLINE on the control panel blink 2 times respectively at the same time

and the printer makes 3 beeps to confirm that the printer’s factory settings have been restored.

3. Release the keys and switch the printer off and reboot.

After these steps, the printer’s factory settings work.

Note: After restoring factory printer settings, the network settings also back to default.

4.6.4 Explaining Menu Terms

Options Description

SYSTEM SETUP

LANGUAGE

Choose the language in the menu, menu content will be printed according to setting language.

EMULATION Select the EPSON ESC/P-K2 or OKI 5530SC emulation. CHAR. MODE Select the ASCII (1 byte) or Chinese character (2 bytes) mode.

CHARACTER

FONT

Set the font for the printer to use in the absence of any font control instructions from your software.

ENG PITCH Set the pitch to determine the horizontal spacing of the printed ASCII. CHI PITCH Set the pitch to determine the horizontal spacing of the printed Chinese.

SLASH ZERO

Select or cancel the printing of a slash (/) through zero to distinguish it from the letter O.

INTL CHAR SET

Select interior character (only with EPSON compatible). (USA, France, Germany, Britain, Denmark I, Sweden, Italy, Spain I, Japan, Norway, Denmark II, Spain II, Latin America, Korea, LEGAL, Holland, Turkey )

CHARACTER SET Select character set into Italic Character Table or Graphic Character Table.

CODE PAGE Select a code page.

PAGE LAYO UT

LINE SPACING

Set the vertical spacing of the printed characters. You can set it to either 6 LPI (the default setting) or 8 LPI.

FORM LENGTH Set the length of your printer paper, for both cut sheets and tractor paper.

FORM LOCK

Select form lock function ON or OFF. When form lock function is on, form length setting in printing data is invalid.

PAGE SKIP Select (ON) or cancel (OFF, the default) a bottom margin of one inch.

COMPRESS PRT

Select 75% compressed print mode, 50% compressed print mode or normal print mode. High speed mode and Super speed mode are invalid when compressed print mode is on.

LEFT EDGE

Setting distance from the first print character to the left paper edge, unit is 1/10 inch.

EDGE DETECT Automatic edge detection (optional). BLACK MARK Whether or not to choose the black mark detection (optional).

PRINT SETUP

PRINT DIR

Print direction mode contains one-way, bidirectional and automatic mode. When default option is automatic mode, print printing direction of character is bidirectional while graphic is one-way, printing direction command is in effect. If

DP650 User’s Manual

- 32 -

choosing “one-way” or “bidirectional” mode, so that character and graphic printing directions are forced into one-way or bidirectional printing mode, print direction command is invalid.

QUIET MODE Select quiet mode ON or OFF.

AUTO LF

Select (ON) or cancel (OFF) the automatic advance of the paper by one line after every carriage return command.

AUTO TEAR OFF

Enable or disable AUTO TEAR OFF function. In enable state, when the printer receives paper feed command and print out no data, paper will be feed to tear off position after the set waiting time passed.

Choose (0.5sec, 1.0sec or 2.0sec) or choose LOAD/EJECT key to feed paper. When the insert wait time set to 0.5sec, 1.0sec or 2.0sec, after the corresponding time if the paper feed sensor detects there is paper, the printer will feed the paper automatically.

EJECT In the front feed mode, select the eject direction of cut sheet.

SKEW DETECT

Enable or disable the skew detection for cut sheets, if the pitch of paper is over the set value, printer will eject paper automatically. If you use this function, please refer the set value to skew level.

SKEW LEVEL

Skew level is in effect when skew detection is on. Skew level divides into 10 levels from 001-010. Skew level value (vertical error value of right and left form head) is from 1.0mm to 7.3mm, each level is 0.7mm discrepancy.

PIN SWITCH

Select pins switch mode. The printer auto switches the different pin to print table line.

SERIAL I/F

BAUD RATE Set the printer RS-232C interface speed.

PARITY Set the printer RS-232C interface parity error checking type.

DATA BIT Set the printers RS-232C data bits.

STOP BIT Set the printers RS-232C transmission stop bits.

PROTOCOL Set the printer serial interface as software control (XON/XOFF) or hardware

control (DTR).

HEAD PIN

Select broken-pin mode. The default setting is every root and printed needle is live. When the printer is printing, if user finds out broken-pin, please select broken-pin mode, then the printer can automatic compensate broken-pin position.

4.6.5 Online-aptitude Parameter Settings

DP650 supports the function of online-aptitude parameter settings, which can be set in the PC with the

driver installed in.

The concrete setting steps are shown as follows:

1. Make sure that the host and the printer are connected with a cable and both the host and the printer are turned on, the printer should be online as well.

2. Click “Start” → “Settings” → “Printers”.

3. Right click “Jolimark DP650” in the “Printers”, select “Properties”.

4. Click “Printer Settings” in the property page.

Table 4-2 Description of Options

DP650 User’s Manual

- 33 -

5. The setting way is corresponding with that of printer menu system. In the “Printer Settings” layout, select the first class menu in the combo box of “Select Printer Setting Class”, select the second class menu in the “Options” and select the parameter of that option.

6. Click the button “Reset All” to reset all the parameters to be the driver’s default, but not change the printer’s settings.

7.When setting the parameters: you can click “Set Item” to save the current settings after setting each item, or you can also click “Set All Items” after setting all parameters. After clicking “Set All Item” or “Set Item”, the parameter’s instruction will be sent to the printer.

8. The printer’s parameter settings are changed at once after receiving the instruction and the printer does not need to restart.

9. After finishing settings, click “OK”, exit the “Properties” window.

4.7 Using the Self- Test Functions

4.7.1 ASCII Test Mode

One page of ASCII pattern is performed by turning power on while pressing the ONLINE key. Continuous printing of ASCII pattern is performed by turning power on, while pressing the ONLINE key

and LOAD/EJECT key at the same time. Pressing the ONLINE key can stop printing, and turn off the printer to exit ASCII test mode.

DP650 User’s Manual

- 34 -

4.7.2 Maintenance Printing Test (H pattern)

One page printing of H pattern is performed by turning power on, while pressing the ONLINE and LF/FF keys.

Continuous printing of H pattern is performed by turning power on, while pressing the COPY key. Pressing the ONLINE key can stop printing, and turn off the printer to exit H pattern mode.

4.7.3 Hex Dump Mode

Turn power on while pressing the LOAD/EJECT key, which causes the printer to enter Hex Dump mode. In this mode, the data which are sent from computer will print with hex. Pressing the ONLINE key can stop printing, and turn off the printer to exit Hex Dump mode.

The results of the hex dump printing will be shown as follows.

4.7.4 Alignment Adjust Mode

Enter the alignment adjust mode to improve the print quality when the printer is used for a long time. In alignment adjust mode, different DPIs correspondingly adjust different printing speed alignments.

DPIs are divided into 80DPI, 120DPI, 180DPI, 240DPI and 360DPI. Use Speed key to select DPI circularly. Different DPIs should be adjusted correspondingly.

In DPI state, use COPY key to choose different copy modes, correspondingly adjust alignment in every mode. In the alignment adjust title, COPY 1 indicates the “1+4” mode while COPY 2 indicates the “1+6” mode which are distinguished from normal printing mode.

1. Make sure the printer is paper in and turn on the printer.

2. In the online mode, press and hold on the LF/FF key and COPY key until the POWER and ONLINE

indicators blink simultaneously, the printer enters the alignment adjust mode.

3. After entering the alignment adjust mode, press the following keys to adjust the degree of make

columns:

Figure 4-4 ASCII self-test

Figure 4-5 H pattern test

***** HEXADECIMAL DUMP *****

(0000) 1B 34 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4E, 4ABCDEFGHIJKLMN

(0010) 4F 50 51 52 53 54 55 56 57 58 59 5A 0D 0A 1B 35 OPQRSTUVWXYZ, , , 5

(0020) 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4E 4F 50 ABCDEFGHIJKLMNOP

(0030) 51 52 53 54 55 56 57 58 59 0D 0A QRSTUVWXYZ,

Figure 4-6 The hexadecimal dump printing

ASCII TEST MODE

Jolimark DP650 VX.X 20XX/XX/XX

!"#$%&’( )*+-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abc !"#$%&'( )*+-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abcd "#$%&'( )*+-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abcde

H PRINT MODE

Jolimark DP650 VX.X 20XX/XX/XX HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH

DP650 User’s Manual

- 35 -

EJECT/LOAD Each press this key, the even line will move left with one step (adjust value

increase).

Press ONLINE key to check the result. LF/FF Each press this key, the even line will move right with one step (adjust value

decrease).

Press ONLINE key to check the result.

COPY In the alignment adjust mode, press this key to the next copy mode. It can

switch among NORMAL print mode, “1+4” print mode and “1+6” print mode. Press ONLINE key to check the result.

SPEED Switch to the next DPI adjust state ONLINE Store and print the current settings

4. Restart the printer and exit the alignment adjust mode.

Note: Alignment adjust mode will affect the printing quality, think over before adjust it and

strict to the instructions while adjusting.

DP650 User’s Manual

- 36 -

Appendix A Troubleshooting and Maintenance

A.1 Cleaning the Printer

Cleaning periodically and the cleaning tool

Periodical cleaning: every six months or every 300 working hours once.

Cleaning tool: dry cloth (please use soft cloth to clean metal parts.)

Cleaning the paper feed platform and spare parts

Please wipe off wasted paper and clean dirt and dust. Clean the oil covered spare parts with a piece of dry cloth.

Cleaning the carriage shaft

There is a layer of oil covered on the carriage shaft which guarantees the carriage runs smoothly. But the oil is easy to absorb dust, please clean the dust with soft cloth first, and then add proper lube (NYE 180 lube of NYE Company is recommended), move print head back and forth to make lube scattered.

Cleaning the photoelectric sensor part

As the paper feed sensor use a correlation photoelectric sensor. You should clean the parts periodically.

1. Clean the light extinction patch every three months.

2. Clean the photoelectric sensor's protect cover every three months.

When the paper feed sensor can not detect the paper which makes the paper can not be fed, you may take following actions:

Figure A-1 Cleaning printer

Carriage shaft

Paper guide platform

Caution

z Do not open the printer top cover or rotate the paper feed knob while printing, z Do not place an y heav y object on the printer no matter the printer is printing or not.

z Turn off both the printer and the Host before connecting them. Not allow plug in the

power cord or the signal cord. Or it may burn out the chip and damage the printer interface or the power supply.

z Turn off the printer and pull out the plug before cleaning the printer.

DP650 User’s Manual

- 37 -

1. Clean the dust on the light extinction patch.

2. Clean the dust on the protect cover of the photoelectric sensor.

Note: 1. Turn off printer and pull out the power cord before cleaning.

2. Being used under dust circumstance, the carriage shaft may stack much dust and affect the print quality.

3. If you have just finished using the printer, let the print head cool for a few minutes before you touch it.

4. Please use a soft cloth for cleaning, do not use combustible solvent.

A.2 Problems and Solutions

No.

Problem Solution Note

Paper jammed while printing

Stop printing and take the jammed paper out. Then restart to print.

The carriage has no action while printing

Stop printing, check if the ribbon is blocked or the ribbon cartridge has been inserted properly.

The noise is too loud while printing

Stop printing, check if every part is in proper position or the mechanism has any malfunction.

Bugs in the print characters

Check whether the ribbon has been inserted properly, and then print out the current settings. Check if the print head pins have been broken.

Send to check

Nothing prints out while printing

Check if the ribbon is installed or the paper select lever in the right position

Paper do not feed or do not feed smoothly

Check if the gap adjust lever is in right position, or else send to check.

Carriage runs uneasy and has loud noise.

Stop printing and check, if there is strange things, takes them out; if there is a layer of dust on the carriage shaft, clean it and add some lube. (See A1 Cleaning the printer for reference).

Send to check

Print characters are too faint

Replace the ribbon carriage with a new one

A.3 Error LED on the Control Panel

In case of printer error, the printer enters offline state and indicates an alarm by blinking the LEDs as shown below.

LED Error Solution

The PAPER OUT LED blinks and the ONLINE LED is off.

Paper out or paper jam

Load paper or remove the jammed paper

The PAPER OUT LED and the ONLINE LED blink simultaneously quickly.

Paper slant

Re-insert the cut sheet paper correctly

The PAPER OUT LED and the ONLINE LED blink alternately quickly.

Home position error

Turn off the power and turn it on again. If an error still occurs, clean and lubricate the carriage shaft (see A.1 cleaning the printer)

DP650 User’s Manual

- 38 -

The PAPER OUT LED and the ONLINE LED blink alternately slowly.

Paper select lever error

Return the select lever to the correct position

The PAPER OUT LED is on and the ONLINE LED blinks. At the same time, the print head traverse automatically but nothing is printed.

Print head overheating

Automatically traverse when print head temperature too high. The printer will continue to work after it cool down.

DP650 User’s Manual

- 39 -

Appendix B

B.1 Specifications

B.1.1 General

Item Description

Type 24-Pin Flatbed Dot Matrix Impact Printer Print direction Bidirectional logic seeking printing Number of columns 106 columns (10 CPI) / 269.24mm

ASCII Chinese

Speed 10 CPI 12 CPI Speed 6.7 CPI 7.5 CPI

Super high speed 340 CPS 408 CPS Super high speed 184 CPS 206 CPS

High speed 300 CPS 360 CPS High speed 134 CPS 150 CPS

Print speed

Normal speed 150 CPS 180 CPS Normal speed 100 CPS 112 CPS

Diameter of wire: 0.22 mm

Print head

Life: 500 million dots/wire

Resolution 360 x 360 dpi (Max.)

ASCII: 17 international character sets (U.S.A, FRANCE, GERMANY, U.K, DENMARK1,

SWEDEN, ITALY, SPAIN1, JAPAN, NORWAY, DENMARK2, SPAIN2, LATIN AM, KOREA, LEGAL, NETHERLANDS, TURKEY)

Character set

Chinese: GB 18030

Code Page

28 types: U.S.A, MULTI, PORTUGAL, CANADA, NORWAY, EAST EURO, CYRILLIC,

RUSSIAN, HUNGARY, KAMENICKY, TURKEY, ICELAND, BULGARIA, MAZOVIA, GRK 437, GRK 851, GRK8859-7, GRK 1253, ARAB NLS, ARAB EXT, WIN LAT1, WIN LAT2, ISL LTN1, ISO LTN2, TUR8859-9, ISO LTN9, KBL, LATIN 7

ASCII: Draft, Roman, Sans Serif, Courier, Prestige, Script, OCR-A, OCR-B, Orator

Fonts set

Chinese: GB 18030 Song typeface

Bar code

EAN-13, EAN-8, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Code 39, Code 128 B, Code 128 C, NW-7

ASCII: 10 CPI, 12 CPI, 15 CPI, proportional

Character pitch

Chinese: 6.7 CPI, 75 CPI

Line space 1/6 inch, 1/8 inch, programmable in 1/360 inch increments

Paper feed speed (max.) 127mm per second or 5 inches per second (continuous feed)

Emulation

EPSON ESC/P-K2、OKI 5530SC

Interface

Parallel interface: Centronics (IEEE1284 NIBBLE) USB interface: USB 2.0 Full-Speed Serial interface: RS-232C Ethernet interface: 10/100Base-T Ethernet Interface * Only one serial interface or Ethernet interface is supplied, you can choose either according to

your requirement.

★ According to specific interface standards

Input Buffer 132 KB

Model: JMR119

Ribbon

Life: 8 million characters (draft mode)

Noise

＜55 dB (A) (ISO7779 standard)

Control Panel

5 keys and 4 indicator lights

Cut sheet: Load/eject from front, Load from front and eject from rear

Paper feed type

Tractor paper: Load front rear, eject from front

DP650 User’s Manual

- 40 -

Width: 70 ～ 340 mm Length: 56 ～ 536 mm Thickness: 0.06 ～ 0.85 mm Weight: 45 ～ 150 g/m2

Cut sheet

Multiple paper (Every page): 30 ～ 40 g/m2 Width: 65 ～ 335 mm Total Thickness: 0.06 ～ 0.85 mm Weight (Single paper) : 45 ～ 150 g/m2

Paper specification

Tractor paper

Multiple paper (Every page): 30 ～ 40 g/m2

Max paper thickness 0.85 mm

Copy

Original + 6 copies Normal print mode: Original + 2copies (print once) “1+3” print mode: Original + 2 to 4 copies (print once) “1+6” print mode: Original + 6 copies (print once)

STANDARD: Document Skew detection

Automatic function

OPTIONAL: Automatic document border detection, Black mark detection

Compress printing Support graph and character printing

Especial functions

Pin Break Compensation, Pin Rotation Replacement, Automatic Emulation Match, Online Parameter Setting, Full slot position paper loading and printing (OPTIONAL)

Physical dimensions 470 (width) × 252 (depth) × 207 height) mm (not include front table and paper feed knob)

Weight Approx. 7.8 Kg

Temperature: 5 ～ 40℃

Operating

environment

Humidity: 40%RH ～ 90%RH (No condensation)

Temperature: -40 ～ 55℃

Environmental conditions

Storage

environment

Humidity: ≤93%RH (40°, No condensation)

Rated voltage range: 198 ～ 242 V

Power requirements

Rated frequency range: 50 ～ 60 Hz

Power

① Working power: 45W; ② Largest power: 160W; ③ Waiting power: 0.05W.

Caution: Only when the product is unconnected with outer power supply, it can achieve zero energy consumption state.

Reliability MTBF≥15,000 hours (IEC 605.7standard)

Safety marks EN60950

Wireless disturbance Grade B

B.2 Printable Area

DP650 is configured with Centronics (IEEE1284 NIBBLE) parallel interface, 2.0 Full-Speed USB interface, RS-232 serial interface or 10/100Base-T Ethernet interface. You can connect to the computer according to your requirement.

B.2.1 Parallel Interface

Sequence and signal level

Sequence Diagram as B-1

Signal level

Input High level: 2 to 5V, Low level: 0 to 0.8V

Output High level: 2.4 to 5V, Low level: 0 to 0.4V

DP650 User’s Manual

- 41 -

Pin Assignments

Signal Pin No. Return Line Pin No. Signal Name Signal Direction

1 19 /STROBE

Printer ←Host

2 ～ 9 20 ～ 27

DATA

Printer ←Host

10 28 /ACK

Printer →Host

11 29 BUSY

Printer →Host

12 30 PE

Printer →Host

——

SELECT

Printer →Host

——

/AUTO FEED

Printer ←Host

——

NC NC

——

SIGNAL GND Printer↔ Host

——

CHASSIS GND Printer↔ Host

——

+5V

Printer →Host

——

/PRIME

Printer← Host

——

/ERROR

Printer →Host

——

SIGNAL GND Printer ↔Host

——

Printer →Host

——

PULLED UP 5V

Printer →Host

——

/SELECT IN

Printer← Host

B.2.2 USB Interface

USB 2.0 Full-Speed.

The following table provides the standardized contact terminating assignments by number and electrical value for Series “A” and Series “B” connectors.

Figure B-1 Sequence diagram

Figure B-2 Parallel interface connector pin number

DATA STROBE

BUSY

(Field number 77: MODE 1)

(Field number 77: MODE 2)

~ T3: Min.0.5us

: Approx.3.8us

Approx.2.1us

DP650 User’s Manual

- 42 -

Contact Number Signal Name Typical Wiring Assignment

1 VBUS Red 2 D- White 3 D+ Green 4 GND Black

B.2.3 Serial Interface

Serial Specification

Data input/output mode: 7-bit or 8-bit serial interface

Data input code: ASCII, JIS 7-bit or 8-bit, International character code, CG, Dot matrix graphic code

based on graphic symbol code (8-bit)

Data buffer: 132K bytes most Signal level: RS-232C: ±12V

Data transit speed (baud rate) RS-232C: 1200bps, 2400bps, 4800bps, 9600bps, 19200bps

Data transmission protocol RS-232C: READY/BUSY (DTR) or X-ON/X-OFF

Synchronous system: Original bit: 1 bit stop bit: 1~2 bit

Character length: 7~8 bits

Connector Pin Assignments

RS-232C default settings

PIN ABBREVIATION NAME DIRECTION RDY/BSY X-ON/X-OFF

1 FG Frame Ground —— O O 2 SD Transmitted Data OUT X O 3 RD Received Data IN O O 4 RTS Request to Send OUT * * 7 SG Signal Ground —— O O

20 DTR Data Terminal Ready OUT O O

O: USE X: NOT USE *: HIGH LEVEL

Stop bit

Data bit

Original bit Parity check bit

Figure B-3 USB-B Type connector

Figure B-4 Serial data format

2 1

3 4

DP650 User’s Manual

- 43 -

Signal description:

Prescription of signal level on RS-232C

1=Low (Mark): -25 ~ -3 V

0=High (Space):+3 ~ +25V

RDY/BSY protocol (RS-232C)

PIN 1 FG (Frame Ground --- connect to the printer rack)

Connect to the circuit frame ground

PIN 3 RD (Received Data)

Receive serial data from the computer through this pin. This pin is low level when it receives no

data.

PIN 7 SG (Signal Ground)

Connect to the signal ground

PIN 20 DTR (Data Terminal Ready)

This pin is high level when the printer is ready to receive data. It is low level when not ready to

receive data.

X-ON/X-OFF Protocol

PIN 1 FG (Frame Ground---connect to the printer rack)

Connect to the circuit frame ground.

PIN 2 SD (Transmitted Data)

Send serial data to the printer through this pin. This pin is low level when it receives no data.

PIN 3 RD (Received Data)

Receive serial data from the printer through this pin. This pin is low level when it receives no

data.

PIN 4 RTS (Request to Send)

Send Request to send signal from the printer. This pin is high level when the printer is turned

on.

PIN 7 SG (Signal Ground)

Connect to the signal ground.

PIN 20 DTR (Data Terminal Ready)

Output the signal from the printer. This pin is high level when the printer is turned on.

B.2.4 Ethernet Interface

10/100Base-T Ethernet interface, it can connect to 10/100M Ethernet.

Figure B-6 Ethernet Interface

Figure B-5 Serial interface connector pin number

DP650 User’s Manual

- 44 -

B.3 Printable Area

Caution: 1. To guarantee the print quality, please ensure the contents are all within printable

area.

2. If the print contents are out of the printable area, it may cause the print head to break pins.

Cut Sheet Printable Area:

Tractor Paper Printable Area:

Figure B-8 the printable area of tractor paper

Figure B-7 the printable area of cut sheet

Max.269.24 mm

≥15 mm

≥6 mm

≥15 mm

Printable Area

Max.269.24 mm

Printable Area

≥3 mm

≥4 mm

≥6 mm

≥3 mm

DP650 User’s Manual

- 45 -

B.4 Cautions of Printing

z The paper which inserted should not be collapsed, tore or carry any staple, clip or pin and so on. (As

shown in B-9) Or else, it will damage the printer seriously.

z Do not use the print paper which edges fall into disrepair.

z In cut sheet print mode, do not use the one page tractor paper or the one page copy paper. Because

the hole on the tractor paper edge and the impress at the copy paper edge will cause printing jam. (As shown in B-10)

Figure B-9

Figure B-10

One page tractor paper

One page copy paper

Tear

Clip

Staple

DP650 User’s Manual

- 46 -

Appendix C Command Code Summary

C.1 Epson Emulation

Name Code (Symbol) Code (Hex.) Code (Dec.)

Print and Line Feed Execution

Carriage Return CR 0Dh 13d Line Feed LF 0Ah 10d n/180” Line Feed ESC J 1Bh 4Ah 27d 74d n/180” Reverse Line Feed ESC j 1Bh 6Ah 27d 106d

Format Control

Set 1/8” Line Spacing ESC 0 1Bh 30h 27d 48d Set 1/6” Line Spacing ESC 2 1Bh 32h 27d 50d Set n/180” Line Spacing ESC 3 1Bh 32h 27d 51d Set n/60” Line Spacing ESC A 1Bh 41h 27d 65d Set n/360” Line Spacing ESC + 1Bh 2Bh 27d 43d Form Feed FF 0Ch 12 d Set Form Length in Lines ESC C 1Bh 43h 27d 67d Set Form Length in Inches ESC C NUL 1Bh 43h 00h 27d 67d 0d Set Form Length in Defined Unit ESC ( C 1Bh 28h 43h 27d 40d 67d Select Skip-Over-Perforation ESC N n 1Bh 4Eh 27d 78d

Cancel Skip-Over-Perforation ESC O 1Bh 4Fh 27d 79d

Vertical Tab VT 0Bh 11d Set Vertical Tab Positions ESC B 1Bh 42h 27d 66d Select a VFU Channel ESC / 1Bh 2Fh 27d 47d Select VFU Positions ESC b 1Bh 62h 27d 98d Set right Margin ESC Q 1Bh 51h 27d 81d Set Left Margin ESC l 1Bh 6Ch 27d 108d Horizontal Tab HT 09h 9

Set Horizontal Tab Positions ESC D 1Bh 44h 27d 68d Set Character Space ESC SP 1Bh 20h 27d 32d Set Absolute Horizontal Tab ESC $ 1Bh 24h 27d 36d Set Relative Dot Position ESC \ 1Bh 5Ch 27d 92d Define Unit ESC ( U 1Bh 28h 55h 27d 40d 85d Set Absolute Vertical Print Position ESC ( V 1Bh 28h 56h 27d 40d 86d Set Relative Vertical Print Position ESC ( v 1Bh 28h 76h 27d 40d 118d Set Form Format ESC ( c 1Bh 28h 63h 27d 40d 99d Set Horizontal Motion Index (HM) ESC c 1Bh 63h 27d 99d

Print Mode

Select Print Quality ESC x 1Bh 78h 27d 120d Select ELITE Width Mode (12CPI) ESC M 1Bh 4Dh 27d 77d Select PICA Width Mode (10CPI) ESC P 1Bh 50h 27d 80d Select 15CPI Mode ESC g 1Bh 67h 27d 103d Select/Cancel Proportional Mode ESC p 1Bh 70h 27d 112d Select Double Width Mode (one line) SO 0Eh 14d

DP650 User’s Manual

- 47 -

Name Code (Symbol) Code (Hex.) Code (Dec.)

Cancel Double Width Mode (one line) DC4 14h 20d Select/Cancel Double Width Mode ESC W 1Bh 57h 27d 87d Select Compressed Mode SI 0Fh 15d Cancel Compressed Mode DC2 12h 18d Select Emphasized Mode ESC E 1Bh 45h 27d 69d Cancel Emphasized Mode ESC F 1Bh 46h 27d 70d Select Double Strike Mode ESC G 1Bh 47h 27d 71d Cancel Double Strike Mode ESC H 1Bh 48h 27d 72d Select Italic Mode ESC 4 1Bh 34h 27d 52d Cancel Italic Mode ESC 5 1Bh 35h 27d 53d Select/Cancel Underline Mode ESC - n 1Bh 2Dh 27d 45d Select Superscript/Subscript Mode ESC S n 1Bh 53h 27d 83d Cancel Superscript/Subscript Mode ESC T 1Bh 54h 27d 84d Select Print Mode ESC ! n 1Bh 21h 27d 33d Select/Cancel Double Height Mode ESC w n 1Bh 77h 27d 119d Select/Cancel Quiet Print Mode ESC s n 1Bh 73h 27d 115d Select Justification Mode ESC a n 1Bh 61h 27d 97d Select Character Style ESC q n 1Bh 71h 27d 113d Define and Apply a Style of Scoring ESC ( - 1Bh 28h 2Dh 27d 40d 45d Print Data as Characters ESC ( ^ 1Bh 28h 5Eh 27d 40d 94d

Character Set

Select International Character Set ESC R 1Bh 52h 27d 82d Select Font Style ESC k 1Bh 6Bh 27d 107d Select Character Table ESC t n 1Bh 74h 27d 116d Enable Character Set 2 ESC 6 1Bh 36h 27d 54d Cancel command ESC 6 ESC 7 1Bh 37h 27d 55d Assign Character Table ESC ( t 1Bh 28h 74h 27d 40d 116d Select ASCII character width and height ESC X 1Bh 58h 27d 88d

Download Character

Select/Deselect User-Defined Set ESC % n 1Bh 25h 27d 37d

Define Downloaded Characters ESC & 1Bh 26h 27d 38d

Copy ROM Characters Set into RAM ESC: 1Bh 3Ah 27d 58d

Bit-Image

Select Single-Density Graphics Mode ESC K 1Bh 4Bh 27d 75d Select Double-Density Graphics Mode ESC L 1Bh 4Ch 27d 76d Select High-speed, Double-Density ESC Y 1Bh 59h 27d 89d Select Quadruple-Density ESC Z 1B

5Ah 27d 90d

Graphics Mode

Select Graphics Mode ESC * 1Bh 2Ah 27d 42d Reassign Graphics Mode ESC ? 1Bh 3Fh 27d 63d Select Graphics Mode ESC ( G 1Bh 28h 47h 27d 40d 71d Print Raster Graphics ESC . 1Bh 2Eh 27d 46d

Input Data Control

Cancel Line CAN 18h 24d

DP650 User’s Manual

- 48 -

Name Code (Symbol) Code (Hex.) Code (Dec.)

Delete Character DEL 7Fh 127d Select Printer DC1 11h 17d Deselect Printer DC3 13h 19d Cancel MSB Control Sequence ESC # 1Bh 23h 27d 35d Set MSB to 1 ESC > 1Bh 3Eh 27d 62d Reset MSB to 0 ESC = 1Bh 3Dh 27d 61d

Miscellaneous

Null NUL 00h 0

Beeper BEL 07h 7

Backspace BS 08h 8

Initialize Printer ESC @ 1Bh 40h 27d 64d Select Unidirectional Mode (online) ESC < 1Bh 3Ch 27d 60d Select Print Direction ESC U n 1Bh 55h 27d 85d

Jolimark DP650 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
