Z720A
1
11
14
10
2
3
4
9
8
22
13
19
6
21
17
18
20
12
7
5
21
16
15
part
no.
key description key
1 AM125424........ ENGINE OIL FILTER
2 M144100.......... AIR FILTER - PRIMARY
3 M144098.......... AIR FILTER - SECONDARY
4 AM116304 ........ FUEL FILTER
5 MIA881446....... TRANSMISSION FILTER
6 MIU11299......... SPARK PLUG
7 TCU26349........ V-BELT - TRACTION DRIVE
8 TY25878 .......... BATTERY
9 TCA15075........ IGNITION SWITCH
10 AM125504........ IGNITION KEY
11 TCA17834........ PTO SWITCH
12 TCA19813........ PTO CLUTCH
part
no.
14 AM106305 ........ RELAY
15 AM117324 ........ SWITCH - HEADLIGHT (OPTIONAL)
16 R136239........... HEADLIGHT BULB - (OPTIONAL)
17 AM125447 ........ HEADLIGHT - (OPTIONAL)
18 TCA16216 ........ FILLER CAP
19 TCA16958 ........ MUFFLER
M149198 ..........GASKET
20 TCA13769 ........ CASTER WHEEL ASSY
TCU15970 ........ TIRE - CASTER - 13X5.00-6 SMOOTH
21 TCA19832 ........ TIRE & WHL ASSY - REAR - 60”
22 TCA18026 ........ SEAT ASSEMBLY
23 AM103119 ........ SEAT SWITCH
13 MIA11473......... STARTER
“
Parts Needed in First 250 hours of Operation
Qty Part No Item Capacity Interval In Hours
3 AM125424 Engine Oil Filter 5/100/200
6 TY22029 1 qt Turf Gard 10W30 Engine Oil 2.0 qt 5/100/200
3 TY6341 Multi Purpose SD Polyurea Grease (14 oz) As Needed
"As Needed" Parts
Qty Part Number Item
1 M144100 Air Filter - Precleaner
1 M144098 Air Filter
2 MIU11299 Spark Plug
1 TCU26349 Belt - Traction Drive
1 TCA16216 Filler Cap
1 AM125504 Ignition Key
1 AM130907 Mower Deck Leveling Gauge
1 TY26183 Grease Gun
description
60 in deck
3
(Z720A)
2
4
1
5
3
5
18
5
6
7
8
9
10
11
12
13
12
14
15
16
17
19
20
21
22
part
no.
key description key
1 TCU26293........ BELT
2 TCU24629........ EXTENSION SPRING
3 AM106627........ IDLER
4 TCA19530........ IDLER
5 TCU26967........ SHEAVE ASSEMBLY
6 JD7849............. LUBRICATION FITTING
14 M127198 .......... SEAL
15 M133398 .......... WASHER
16 M134382 .......... SPINDLE
17 M134305 .......... DEFLECTOR
18 TCA17517 ........ SPINDLE
19 M128485 .......... BLADE - 60” (3 - MED LIFT (STD))
7 M123569.......... FLANGE NUT
8 TCU23180........ HUB
9 M123581.......... DEFLECTOR
10 M125913 .......... BUSHING
11 M88251 ............ BALL BEARING
20 M123522 .......... WASHER
21 M123520 .......... WASHER
22 19M7489 .......... CAP SCREW
12 M85699 ............ SEAL
13 M127517 .......... SPACER
"As Needed" Parts
Qty Part Number Item
3 M128485 Blade - 60 in - Med Lift
3 TCU15881 Blade - 60 in - Hi Lift
3 M131958 Blade - 60 in - Mulching
1 TCU26293 Belt - 60 in
part
no.
description
TCU15881........ BLADE - 60” (3) - HI LIFT
M131958 .......... BLADE - 60” (3) - MULCHING
