JMA BT-SLIM User Manual
USER MANUAL
BT SLIM
2
The BT SLIM remote control has three functions:
1) A garage door remote control activated via a smartphone and the JMARemoteSlim app. *
2) A conventional garage door remote control activated by simply pressing the button on the remote. *
ENGLISH
3) A remote camera shutter button for smartphones.
(*) For the BT SLIM to work as a garage door remote control, the code from one or more original remote controls (maximum
of four) must be saved onto the device. We recommend that this be done by a duplication professional.
1. MODES OF USE
BLUETOOTH MODE
GREEN LED
For copying, reading and creating
the remote control. This mode is also used for
opening garage doors via a smartphone, as well
as for the remote camera shutter button function.
REMOTE CONTROL MODE
This mode is for use as a conventional garage
8
door remote control by pressing the button
RED LED
on the BT SLIM device.
To SWITCH BETWEEN BLUETOOTH MODE
AND CONVENTIONAL REMOTE CONTROL
MODE or vice-versa, press the button three or
four times in a row. The LED will change colour.
It will switch from green to red or from red to
green each time you do this.
