STEREO CASSETTE PLAYER WITH AM/FM RADIO
MODEL: SCR-75
USER MANUAL
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING
THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Dear JENSEN Customer
Selecting fine audio equipment such as the unit you've just purchased is only the
start of your musical
fun and excitement your equipment offers. This manufacturer and the Electronic
Industries Association's Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the sound come through loud
and clear without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing. Sound can be deceiving. Over time your hearing "comfort level"
adapts to higher volumes of sound. So what
harmful to your hearing. Guard against this by setting your
BEFORE your hearing adapts.
To establish a safe level:
Start your volume control at a low setting.
Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level: Set the dial and leave it there.
Take a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
enjoyment. Now it's time to consider how you can maximize the
sounds "normal" can actually be loud and
equipment at a safe level
E-1
We Want You Listening for a Lifetime
Used wisely, your new sound equipment will provide a lifetime
of fun and enjoyment. Since hearing damage from loud noise
is often
the Electronic
undetectable until it is too late, this manufacturer and
Industries Association's Consumer Electronics
Group recommend you avoid prolonged exposure to excessive
noise.
Customer's Record:
The serial number of this product is found on its bottom. You should note the serial
number of this unit in the space provided as a permanent record of your purchase to aid in
identification in the event of theft of loss.
Model Number: SCR-75 Serial Number: ____________________
LOCATION OF CONTROLS
1 CASSETTE DOOR 8 STEREO HEADPHONE JACK
STOP BUTTON
2
9 LINE-OUT JACK
3 PLAY BUTTON 10 DETACHABLE BELT CLIP
4 FAST FORWARD BUTTON 11 TUNING CONTROL
5 VOLUME CONTROL 12 AM/FM BAND SELECTOR
6 FUNCTION SELECTOR 13
DC JACK
7 DIAL SCALE
E-2
POWER SOURCE
The SCR-75 operates on two 1.5V DC “AA” size (UM-3) alkaline batteries (Not Included)
or with an AC-DC adaptor with 3V DC ~ 600mA output (Not Included).
A. BATTERY OPERATION (BATTERIES NOT INCLUDED)
1. Open the battery door located on the back of the unit.
2. Follow the polarity diagram (+ and -) shown on the back of the cabinet, and insert 2
'AA' (UM-3) batteries (not included), and close the battery door.
IMPORTANT:
Notes:
1.) For best performance and longer operating time, we recommend the use of
2.) The batteries need to be replaced when if the volume level becomes
BATTERY WARNING
•
Be sure the batteries are installed correctly. Wrong polarity may damage the unit.
•
Use only the size and type of batteries specified.
•
Do not mix old and new batteries.
•
Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium)
batteries.
•
If the unit is not to be used for an extended period of time, remove the batteries. Old
or leaking batteries can cause damage to the unit and may void the warranty.
•
Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture. (Follow battery manufacturer’s directions).
•
Do not dispose of batteries in fire, batteries may leak or explode.
B. AC ADAPTOR OPERATION (AC ADAPTOR NOT INCLUDED)
1.
Plug the cord of the AC adaptor into the DC IN JACK (#13) of the SCR-75.
2.
Plug the AC adaptor into a household 120V/60Hz AC power outlet.
3.
The batteries will automatically disconnect when the AC adaptor is plugged into the
SCR-75 and the unit will operate using the AC adaptor power.
NOTE: Only use adaptor with an output voltage
rated at DC 3V 600mA with a
center positive plug.
Be sure that the batteries are installed correctly. Wrong polarity could
damage the unit and void the warranty.
good quality alkaline battery.
significantly lower, if the sound is distorted during operation or the unit no
longer functions properly.
E-3
RADIO OPERATION
1. Plug the included earbuds into the STEREO HEADPHONE JACK (#8) located on the
unit, and place the earbuds in your ears.
2. Switch the FUNCTION SELECTOR (#6) to “RADIO”.
3. Switch the AM/FM BAND SELECTOR (#12) to "AM" or "FM" for the desired band.
4. Rotate the TUNING CONTROL (#11) to select the desired radio station.
5. Adjust the VOLUME CONTROL (#5) to obtain the desired sound level.
6. To turn the radio off, switch the FUNCTION SELECTOR (#6) to “TAPE”.
TIPS FOR BEST RADIO RECEPTION
1. The cord of the earbuds works as an external FM antenna. To insure maximum FM
tuner reception, always keep the earbuds cord fully extended. Do not wind or fold the
earbuds cord while listening to the radio.
2. When tuning a station in AM band, be sure to place the unit in a vertical position. For
maximum AM tuner reception, keep turning the unit slowly while keeping it vertical
until the best reception is obtained.
CASSETTE PLAYER OPERATION
1. Plug the included earbuds into the STEREO HEADPHONE JACK (#8) located on the
unit, and place the earbuds in your ears.
2. Set the FUNCTION SELECTOR (#6) to “TAPE” if required.
3. Open the CASSETTE DOOR (#1) and insert a pre-recorded cassette tape with the
exposed tape facing upwards then close the CASSETTE DOOR (#1).
4. Press the PLAY
BUTTON (#3) and adjust the VOLUME CONTROL (#5) to obtain
the desired sound level.
5. Press the FAST FORWARD
BUTTON (#4) when you wish to rapidly advance the
tape.
6. Press the STOP
BUTTON (#2) to switch off.
AUTO STOP
To protect your cassette tapes and prevent unnecessary wear to the pinch roller of the
cassette mechanism, this unit is equipped with an Automatic Stop System. When the
tape ends during play or fast forwarding, the PLAY
BUTTON (#3) will automatically
release to stop the cassette from running.
CASSETTE TAPE OPERATING TIPS
1. High quality tapes are recommended to obtain maximum quality reproduction from
recordings.
2. Tapes with playing time of 120 minutes (C-120) are not recommended because they
contain thinner and longer tape that has a greater chance to malfunction and jam,
which may damage the cassette mechanism.
3. To obtain good reproduction, the head should be cleaned after every 10 to 20 hours of
use. It is also recommended that the cassette be kept away from excessive heat or
cold.
E-4
4. If there is slack in the tape, remove the slack prior
to inserting the cassette. To remove the slack,
insert a pencil into the hub and rotate clockwise as
shown:
5. A leader tape is provided at the beginning on each cassette. There is no recording on
this area, so it is necessary to let the tape run for about five seconds to clear the head.
6. Keep the tape head clean since a dirty head
can cause distorted sound or improper tape
speed. Depress the PLAY
BUTTON (#3)
and use a small cotton swab with tape head
cleaner or alcohol to clean the tape head,
capstan and pinch roller as shown:
READ THIS IMPORTANT INFORMATION BEFORE USING YOUR EARBUDS
1. Avoid extended play at very high volume as it may impair your hearing.
2. If you experience ringing in your ears, reduce the volume or shut off your unit.
3. Do not use while driving a motorized vehicle. This is dangerous and also illegal in
some states.
4. Keep the volume at a reasonable level even if your headset is an open-air type
designed to allow you to hear outside sounds. Please note excessively high volume
may still block outside sounds.
LINE-OUT CONNECTION
The SCR-75 features a 3.5mm stereo LINE-OUT JACK (#9) that allows you to connect it
to your home stereo system, or to external amplified speakers using a stereo audio cable
(not included).
The audio cable needed (not included) must have a 3.5mm stereo plug on one end for
plugging into the SCR-75. The other end of the cord should have a stereo plug or
individual left and right channel plugs that match the AUDIO LINE INPUTS on the device
you want to connect to.
Once the SCR-75 is connected to the external device, the volume control on the SCR-75
will not adjust the volume. Use the volume control on the external device for adjusting the
volume.
1. Clean your unit with a damp (never wet) cloth. Solvent or detergent should never be
used.
2. Avoid leaving your unit in direct sunlight or in hot, humid or dusty places.
3. Keep your unit away from heating appliances and sources of electrical noise such as
fluorescent lamps or motors.
CARE AND MAINTENANCE
E-5
TROUBLE SHOOTING GUIDE
If you experience difficulties in the use of this Cassette Player with AM/FM Radio, please
check the following or call 1-800-777-5331 for Customer Service and support
SYMPTOM
POSSIBLE
Low or no power
SOLUTION
Replace all batteries with
new ones. No sound
Volume set at minimum Increase Volume.
Sound appears distorted
at high volume setting
Noise or distorted sound
on FM broadcasts
Radio - no sound
Cassette Player - no
sound
Tape Sound distorted
Speed varies
Volume control is set to
maximum
Earbuds cord is not
extended
The unit is not in Radio
mode
Adjust Volume control to a
lower comfortable level
Unwrap and fully extend the
earbuds cord
Switch to Radio mode
The station is weak Retune the station again
The unit is not in TAPE mode
Volume at minimum
Defective tape or dirty tape
head
Tape old or worn
Dirty roller and capstan
Slide the function selector to
TAPE
Increase volume
Replace tape or clean tape
head
Replace the tape
Clean roller and capstan
SPECIFICATION
Power Requirement Battery: 2 x "AA"(UM-3) batteries (not included)
AC Adaptor (not included): Input: AC 120V ~ 60Hz
Output: DC 3V 600mA
AM Frequency 530 KHz – 1710 KHz
FM Frequency 88 MHz – 108 MHz
SPECTRA GREEN NOTICE
At Spectra, environmental and social responsibility
is a core value of our business. We are dedicated
to continuous implementation of responsible
initiatives with an aim to conserve and maintain the
environment through responsible recycling.
Please visit us at
http://www.spectraintl.com/green.htm
initiatives or to find a recycler in your area.
for more information on Spectra’s green
E-6
90 DAY LIMITED WARRANTY AND SERVICE VALID IN THE U.S.A. ONLY
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from
defective materials or
customer purchase and provided the
assignable or transferable. Our obligation under this
the defective unit or any part thereof, except batteries, when it is
Service Department, accompanied by proof of the date of original consumer purchase, such as a
duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for warranty service.
If the product is repaired or replaced under warranty, the return charges will be at SPECTRA’s
expense. There are no other express warranties other than those stated herein.
This warranty is valid only in accordance with the conditions set forth below:
1. The warranty applies to the SPECTRA product only while:
a. It remains in the possession of the original purchaser and proof of purchase is
demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage outside
the descriptions and warnings covered within the user manual or non-SPECTRA
approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical wiring not in
compliance with
provide reasonable care and
3. Warranty of all SPECTRA products applies to residential use only and is void when
products are used in nonresidential environment or installed outside the United States.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state. TO OBTAIN SERVICE please remove all batteries (if any) and pack the unit
carefully and send it freight prepaid to SPECTRA at the address shown below. IF THE UNIT IS
RETURNED WITHIN THE WARRANTY PERIOD
purchase (dated cash register receipt) so that we may establish your
service and repair of the unit without cost. Also include a note with a description explaining
the unit is defective. A customer service representative may need to contact you regarding the
status of your repair, so please include your name, address, phone number and email address
to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for $10.00 to
cover the cost of repair, handling and return postage. All out of warranty returns must be sent
prepaid.
It is recommended that you contact SPECTRA first at 1-800-777-5331 or by email at
custserv@spectraintl.com for updated information on the unit requiring service. In some cases,
the model you have may be discontinued, and SPECTRA reserves the right to offer alternative
options for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL60634, USA. 1-800-777-5331
To register your product, visit the link on the website below to enter your information.
http://www.spectraintl.com/wform.htm
0319 Printed in China
factory workmanship for a period of 90 days from the date of original
product is utilized within the U.S.A. This warranty is not
warranty is the repair or replacement of
returned to the SPECTRA
electrical codes or SPECTRA user manual specifications, or failure to
necessary maintenance as outlined in the user manual.
shown above, please include a proof of
eligibility for warranty
how
E-7
Loading...
