JENN-AIR® DETAILED PLANNING DIMENSIONS
BUILT-IN SIDE BY SIDE W/DISPENSER
MODEL NAME: JS42PPDUDB
A*
B*
F
E
D
C
G
K
M
L
N
M
Q
O
P
110º 110º
42" SIDE-BY-SIDE REFRIGERATORS WITH DISPENSER
JS42PPDUDE – 423⁄8" x 833⁄8" x 273⁄4" (with handles)
JS42SSDUDE – 423⁄8" x 833⁄8" x 271⁄8" (with handles)
PRODUCT DIMENSIONS
1 of 3
A B
C
D
FRONT VIEW
K
L
M
110º 110º
TOP VIEW
JS42PPDUDE
MODEL #
E
F
G
H
I
Width of freezer door (including hinge
A
side offset)
Width of refrigerator door (including
B
hinge side offset)
Space between doors
C
Overall width (including side trim) 423⁄8 107.6
D
Height of top grille 85⁄8 21.7
E
Space between doors and top grille
F
Height of handles
Pro-Style® Stainless
G
JS42SSDUDE
in cm
171⁄2 44.4
231⁄2 59.7
3
3
459⁄16 115.7
⁄8 1.0
⁄8 1.0
Euro Style Stainless 50 127.1
Height to top of handles
Pro-Style® Stainless
H
Euro Style Stainless 653⁄4 167.0
Height of doors 71 180.2
I
Height of bottom grille 3 7.6
J
J
Width of recessed refrigerator 41 104.1
K
Width from side of refrigerator to
freezer handle – door fully open 110°
L
Pro-Style® Stainless
6311⁄16 163.5
71⁄8
18.1
Euro Style Stainless 63⁄4 17.1
Width from side of refrigerator to
handle – door open 90°
M
Pro-Style® Stainless
Euro Style Stainless 2 5.1
O
P
N
M
Q
R
Width from side of refrigerator to
refrigerator handle – door fully open 110°
N
Pro-Style® Stainless
Euro Style Stainless 91⁄8 23.1
Depth without doors 221⁄8 56.2
O
Depth with doors 251⁄8 63.8
P
Depth with handles
Pro-Style® Stainless
Q
25⁄8
6.7
95⁄8
24.4
273⁄4 70.5
Euro Style Stainless 271⁄8 68.8
Depth with refrigerator door open 90° 475⁄16 120.1
R
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation or Use & Care Guide
before selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air® appliances are appropriately UL, CUL or CSA approved.
8115AdZw915
JENN-AIR® DETAILED PLANNING DIMENSIONS
K
M
N
M
Q
O
P
R
110º 110º
42" SIDE-BY-SIDE REFRIGERATORS WITH DISPENSER
JS42PPDUDE – 423⁄8" x 833⁄8" x 273⁄4" (with handles)
JS42SSDUDE – 423⁄8" x 833⁄8" x 271⁄8" (with handles)
DIMENSIONS AS INSTALLED
2 of 3
C
D
E
F
G
A*
B*
MODEL #
Height without compressor (min.) 743⁄8 188.9
A*
Height of recessed refrigerator (min.) 833⁄8 211.8
B*
Depth with refrigerator door open 90° (min.) 471⁄4 120.0
C
Depth with handles (min.)
Pro-Style® Stainless
D
Euro Style Stainless 271⁄8 68.8
Depth with doors (min.) 251⁄8 63.8
E
Depth without doors (min.) 221⁄8 56.2
F
Depth of compressor (min.) 197⁄8 50.6
G
* Add 11⁄4" (3.2 cm) to the height dimension when leveling legs are fully extended.
JS42PPDUDE
JS42SSDUDE
in cm
273⁄4 70.5
SIDE VIEW
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation or Use & Care Guide
before selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air® appliances are appropriately UL, CUL or CSA approved.
8115AdZw915
JENN-AIR® DETAILED PLANNING DIMENSIONS
A*
B*
F
E
D
C
G
K
M
L
N
M
Q
O
P
R
110º 110º
F
42" SIDE-BY-SIDE REFRIGERATORS WITH DISPENSER
JS42PPDUDE – 423⁄8" x 833⁄8" x 273⁄4" (with handles)
JS42SSDUDE – 423⁄8" x 833⁄8" x 271⁄8" (with handles)
OPENING/CLEARANCE DIMENSIONS
MODEL #
Width (min.) 411⁄2 105.4
A
Width of recommended electrical
B
location
Distance from side of cabinet to
recommended water connection
C
location
Height (min.) 84 213.4
D
Height to recommended electrical
E
location
Depth of recommended water
F
connection location (max.)
e
Recommended electrical connection location
w
Recommended water connection location
ELECTRICAL REQUIREMENTS
115 volt, 60 Hz, AC only, 15- or 20-amp fused, grounded circuit is
required. A dedicated circuit is recommended. Use an outlet that cannot
be turned off by a switch.
Minimum length of power cord is 84" (213.4 cm). Do not use an extension
cord.
WATER PRESSURE REQUIREMENTS
A cold water supply with water pressure between 30 and 120 psi (207 and
827 kPa) is required to operate the water dispenser and ice maker. Call a
licensed, qualified plumber with any questions about the water pressure.
Reverse Osmosis Water Supply
IMPORTANT: The pressure of the water coming out of a reverse osmosis
system going to the water inlet valve of the refrigerator needs to be
between 30 and 120 psi (207 and 827 kPa).
If a reverse osmosis water filtration system is connected to the cold water
supply, the water pressure to the reverse osmosis system needs to be a
minimum of 40 to 60 psi (276 to 414 kPa).
LOCATION REQUIREMENTS
Floor must be able to support refrigerator (more than 600 lb [272 kg])
and contents of the refrigerator and must be at the same level as flooring
in the room.
FRONT VIEW
A
e
B
D
E
Water
Shutoff
C
w
C
3 of 3
JS42PPDUDE
JS42SSDUDE
in cm
71⁄2 19.1
6 15.2
77 195.6
1 2.5
BACK VIEW
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation or Use & Care Guide
before selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air® appliances are appropriately UL, CUL or CSA approved.
