OMMU NI CATIO NS TEST & M EA SUREMEN T SO LUTIONS
C
MAP Variable Optical Attenuator
(mVOA-A2)
Applications
• Transmitter dispersion testing and
eye mask testing
• Receiver sensitivity testing
• EDFA noise figure and gain
flatness testing
• Power meter calibration
• Loss simulation
Safety Information
• The MAP Variable Optical
Attenuator, when installed in a
MAP chassis, complies to CE,
CSA/UL/IEC61010-1, plus LXI
Class C requirements.
Key Features
The Multiple Application Platform (MAP) Variable Optical Attenuator
(mVOA-A2) is optimized for the industry-leading JDSU MAP-200 platform.
Based on the previous-generation Multiple Application Platform (MAP), the
MAP-200 is the first photonic layer lab and manufacturing platform that is LAN
Extensions for Instrumentation (LXI)-compliant by conforming to the required
physical attributes, Ethernet connectivity, and interchangeable virtual instrument
(IVI) drivers. The MAP-200 platform is optimized for density and maximum
configurability to meet specific application requirements in the smallest possible
foot print.
The mVOA-A2 is a stepper motor and filter based attenuator that takes advantage
of the latest available technologies to provide the highest performance optical
power level control solution with the lowest optical impairments.
– Ultra low insertion loss to minimize loss budget utilization
– High accuracy and high repeatability to reduce measurement uncertainty
– Fast transition speed to reduce testing time
– Flat spectral response to reduce wavelength dependent uncertainty in
multi-wavelength applications (CWDM, DWDM)
– Low backreflection to reduce instabilities due to reflected light
– Optional built-in wavelength calibrated power meter reduces the uncertainty
by reducing external connections
– High input power capability for EDFA testing and multi-wavelength applications
• Ultra low insertion loss (<1.0 dB) and outstanding
spectral uniformity
• Fastest transition speed in its class (up to 25 dB/s)
• Configurable by user at time of order (fiber type, density,
built-in options, high power option)
• Optional built-in power monitor provides comprehensive
closed-loop power control settings
• Optional higher power capability can withstand up to 2W
input power for single-mode fiber (500 mW for MMF)
• Can be automated when used with MAP-200
LXI-compliant interfaces and IVI drivers
WE BS ITE : w ww.jdsu.com /tes t
Insertion Loss vs Wavelength
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
1250 1350 1450 1550 1650
Wavelength [nm]
Insertion Loss [dB]
Relative Attenuation (dB)
Spectral Uniformity Relative to 0 dB Attenuation
-0.1
-0.08
-0.06
-0.04
-0.02
0
0.02
0.04
0.06
0.08
0.1
1250 1350 1450 1550 1650
Wavelength [nm]
10 dB
20 dB
30 dB
AP VARIABL E OPTI CAL AT TE NUATOR
M
2
The MAP Variable Optical Attenuator is a hot-pluggable cassette designed for use within the Multiple Application Platform
(MAP). The MAP is a general purpose high density test and measurement platform for lab or production environments. Up
to 16 independently controlled attenuators can be installed in a single MAP chassis.
Figure 1: Example of insertion loss of the MAP Variable Optical Attenuator with single-mode fiber
Figure 2: Example of spectral uniformity relative to 0 dB attenuation
σ
AP VARIABL E OPTI CAL AT TE NUATOR
M
3
Optical Specifications
Parameter Single-mode Multimode
No power control With power control No power control With power control
1
0
Insertion loss at minimum attenuation
1, 2, 3
<1.0 dB
4, 5
<1.7 dB
5
<1.5 dB
4
<2.2 dB
Maximum input power +23 dBm/+33 dBm +23 dBm/+27 dBm
(Standard power/High power option)
13
Wavelength range 1260 to 1650 nm 750 to 1350 nm
Attenuation range
Attenuation flatness
1
8, 9
70 dB 65 dB
±0.04 dB from 0 to 30 dB N/A
Attenuation slew rate (nominal) 25 dB/s typical 20 dB/s typical
Attenuation setting resolution 0.001 dB 0.001 dB
Attenuation accuracy
Attenuation repeatability, 2
1, 3, 12, 14
3, 11, 12, 14
±0.1 dB ±0.1 dB
±0.01 dB ±0.01 dB
Closed loop output power range N/A –49 to +11 dBm @ N/A –40 to +5 dBm @
(In-line power monitor option) 1310/1550 ±15 nm 850/1310 ±15 nm
Relative power meter uncertainty
Power setting repeatability
3, 5, 9
5, 9
N/A ±0.03 dB N/A ±0.03 dB
N/A ±0.015 dB N/A ±0.015 dB
Power setting resolution N/A 0.001 dBm N/A 0.001 dBm
Polarization dependent loss (from 0 to 25 dB)
Return loss
7
3, 6
<0.08 dB <0.15 dB N/A N/A
>55dB typical APC/45dB typical PC >30 dB typical (PC connector)
Shutter isolation 100 dB typical
Warm up time 30 minutes
Calibration period 2 years
Operating temperature 0 to 50°C
Storage temperature –30 to 60°C
Operating humidty (relative, non-condensing) <90% @ 23°C, <20% @ 50°C
Dimensions (W x H x D) 4.06 x 13.26 x 37.03 cm (1.6 x 5.22 x 14.58 in)
Weight 1.1 kg (2.43 lb) single/1.3 kg (2.87 lb) dual
1. At 1310 ±15 nm and 1550 ±15 nm for SM unit and at 850 ±15 nm and 1300 ±15 nm for MM unit
2. Including one mated pair of connectors
3. At 23 ±5°C
4. Not including tap coupler loss, if installed. Add 0.7 dB for tap coupler option
5. Value shown is for 1550 nm. For 1300/1310 nm the value is typical
6. At 1550 nm ±15 mm only
7. At 1550 nm ±15 nm for SMF, 1300 nm ±15 nm for MMF
8. From 1480 nm to 1640 nm relative to 0 dB attenuation
9. For unpolarized light
10. Multimode specifications are valid for category 4 CPR
11. Constant wavelength, constant temperature, constant state of polarization
12. Measured using low coherence laser source
13. Damage at high optical power due to scratched or poorly cleaned connectors may result. For high power applications, incident light must be applied from “IN” port to
“OUT” port. JDSU assumes no responsibility for these user conditions
14. From 0 to 45 dB attenuation
AP VARIABL E OPTI CAL AT TE NUATOR
Without Options
In
Out
Attenuator
With Tap Option
In
MON
Out
Attenuator
Tap
With In-line Power Monitor Option
In
Out
Attenuator
Tap Power
Meter
M
4
Ordering Information
For more information on this or other products and their availability, please contact your local JDSU account manager or
JDSU directly at 1-800-498-JDSU (5378) in North America and +800-5378-JDSU worldwide or via e-mail at
customer.service@jdsu.com.
The MAP Variable Optical Attenuators are defined by selecting the required options from the product configurator in the
table below. Select one option from each of the three categories (Base, Fiber Type, and Connector Type Options).
Product Code Description
Base Options (Required, select one)
MVOA-A2SS0 Single Attenuator, standard power, no built-inoptions
MVOA-A2SS1 Single Attenuator, standard power, 10/90 splitter for external power monitor
MVOA-A2SSM Single Attenuator, standard power, with integrated power monitor
MVOA-A2SH0 Single Attenuator, high power, no built-in options
MVOA-A2SH1 Single Attenuator, high power, 10/90 splitter
MVOA-A2SHM Single Attenuator, high power, with integrated power monitor
MVOA-A2DS0 Dual Attenuator, standard power, no built-in options
MVOA-A2DS1 Dual Attenuator, standard power, 10/90 splitter
MVOA-A2DSM Dual Attenuator, standard power, with integrated power monitor
MVOA-A2DH0 Dual Attenuator, high power, no built-in options
MVOA-A2DH1 Dual Attenuator, high power, 10/90 splitter
MVOA-A2DHM Dual Attenuator, high power, with integrated power monitor
Fiber Type Options (Required, select one)
M100 9/125 fibertype
M101 50/125 fibertype
M102 62.5/125 fibertype
Connector Type Options (Required, select one)
MFP FC/PC connector type
MFA FC/APC connector type
MSC SC/PC connector type
MSU SC/APC connector type
Sample Configuration
The following configuration specifies a single
attenuator, standard power, no built-in
options, 9/125 fiber type, and FC/PC
connector type.
MVOA-A2SS0 with options M100 andMFP
