JBL SOUNDGEAR User Manual [nl]

Wearable wireless sound

PERSONAL SOUND ZONE MOBILE VIRTUAL REALITY

ENTERTAINMENT

Life at home has a soundtrack.

Introducing a totally new way of experiencing sound at home – by wearing it. Thanks to the JBL Signature Sound wireless performance and the Quad transducers with Bass boost, the Soundgear BTA creates your own personal sound zone while allowing you to remain fully aware of your surroundings. The around-the-neck construction, ergonomic shape, intuitive controls, and soft touch fabric ﬁnish provide a hands-free and ears-free audio experience unlike any you’ve ever had before. Bluetooth the JBL Soundgear BTA offers 6 hours of playback time, a quick recharge time of 2 hours and an echo-cancelling dual mic for crystal clear calls. The included Bluetooth® wireless audio transmitter enables a convenient connection to the TV to better immerse yourself in a movie. Whether you want to give your VR experience a boost with immersive audio, watch a video, add music to your daily activities around the house or take a conference call, the JBL Soundgear provides you with an exciting, pervasive sound experience with total freedom and comfort.

-enabled for sound streaming from compatible devices,

HANDS-FREE & EARS-FREE CALLS

Features

JBL Signature Sound

Dual mic conferencing

Hands-free and ears-free

6-hour battery life

BTA, Wireless Audio Transmitter

Comfort-ﬁt design

Intuitive controls

Seamlessly switch between devices

Wearable wireless sound

Features and Beneﬁ ts

JBL Signature Sound

Enjoy an enriched and immersive audio experience that only JBL sound can provide, thanks also to the Quad transducers with Bass boost.

Dual mic conferencing

Hands-free, crystal clear voice calls make your conference calls easy and convenient, free from echo and noise.

Hands-free and ears-free

Cut the cords and conveniently stream all your content wirelessly and hands-free, staying aware of your surroundings, without disturbing the others.

6-hour battery life

Micro USB charging built-in battery provides 6 hours of playing time, with a quick recharge in just 2 hours.

BTA, Wireless Audio Transmitter

Enables a convenient Bluetooth Enjoy a synchronized audio experience as a result of AptX low latency. Using either input optical or auxiliary audio available makes your Soundgear compatible with most TVs.

Comfort-ﬁ t design

An ergonomic shape that rests gently on your shoulders and soft touch materials that ﬁ t all sizes combine to create an unbelievably comfortable audio experience.

Intuitive controls

Easily take control of your music or calls without taking off the Soundgear.

Seamlessly switch between devices

Allows you to effortlessly switch from one Bluetooth from a video on your tablet to a call on your mobile phone, so that you’ll never miss a call.

connection to the TV to better immerse yourself in a movie.

device to the other. You can simply switch

What’s in the box:

Soundgear BTA20 Charging cable x2 Optical cable

3.5mm Audio cable Warning card Warranty card Safety sheet Quick start guide

Technical Speciﬁ cations:

Driver size: 4 x 31mm Dynamic frequency response range:

100Hz – 20kHz (-6dB)

Sensitivity: 96dB Maximum SPL: 111dB Microphone sensitivity @1kHz dB v/pa:

-42

Impedance: 32 ohm Rated power: 2 x 3W Battery type: Polymer Li-ion battery

(3.7V, 800mAh)

Charging time: 2 hours Music play time with BT on: 6 hours Talk time with BT on: 6 hours Bluetooth Bluetooth

GFSK, π/4DQPSK, 8DPSK

Bluetooth

2.402GHz-2.48GHz

Bluetooth

HSP V1.2, A2DP V1.3, AVRCP V1.5

Bluetooth Weight: 350g

transmitter power: 0-4dBm

transmitter modulation:

transmitter frequency:

proﬁ les: HFP V1.6,

version: V4.0

HARMAN International Industries, Incorporated 8500 Balboa Boulevard, Northridge, CA 91329 USA www.jbl.com

© 2017 HARMAN International Industries, Incorporated. All rights reserved. JBL is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. Features, speciﬁ cations and appearance are subject to change without notice.
