JBL OnBeat™ VENUE LT
Quick Setup Guide
Welcome
Thank you for purchasing the JBL OnBeat™ Venue LT speaker dock. This quick setup guide will show you how to connect and set up your dock.
CONNECTIONS
1.If you are going to use your OnBeat Venue LT with another audio source, plug one end of a 3.5mm (1/8") stereo cable (not supplied) into the OnBeat Venue LT’s Aux In connector, and plug the other end into the audio source’s audio out or headphone out connector.
2.Plug the OnBeat Venue LT’s power supply into the Power connector on the unit and into a working AC power outlet. The OnBeat Venue LT will automatically turn on and go into the Bluetooth pairing mode (the Bluetooth LED will be flashing blue).
Power Aux
Connector Input
PLACEMENT
Place OnBeat Venue LT on a shelf or table with the rear of its enclosure is at least 3" (76mm) away from a wall or other surface to allow the bass ports to operate properly.
CONTROLS AND INDICATORS
Dock Input
LED
|
|
Movie |
Aux Input |
|
|
|
|
|
|
Bluetooth |
||||
|
|
Button |
|
LED |
|
|
|
|
|
|
LED |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Bass Boost |
|
|
Source |
|
|
|
|
|
Power |
|||||
Button |
|
|
|
|
Button |
|
|
|
|
|
Button |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Volume Up/Down |
Buttons |
Docking Slide (open)
LT Docking Connector
Bass Boost button: Press this button to enhance the bass performance. The button’s LED will illuminate when Bass Boost is on.
Movie button: Press this button to activate the Movie EQ mode, which creates an extra-wide sound field to compliment films and other video media. The button’s LED will illuminate when the Movie mode is on.
Source button: Press this button to cycle through the audio sources: Bluetooth, docked device and Aux Input. The input LED for the active source will illuminate.
•If you begin to stream audio from a paired Bluetooth device or play audio from a device connected to the dock while another source is playing, the OnBeat Venue LT will automatically switch to the new source.
Aux Input LED: This LED illuminates when the Aux Input is the active source.
Dock Input LED: This LED illuminates when the docked device is the active source.
Bluetooth LED: This LED flashes blue when the OnBeat Venue LT is in the Bluetooth pairing mode, and turns solid blue when it has successfully paired with a Bluetooth device.
Power button: When the OnBeat Venue LT is on, press the Power button to put it into the standby mode. The button’s LED will illuminate solid amber when the unit is in standby. When the OnBeat Venue LT is in standby, press the Power button to turn it on. The button’s LED will illuminate solid white when the unit is on.
