JBL ON AIR WEM-1 Quick Start Guide
JBL®ON AIR
WEM-1
OWNER’S GUIDE
IMPORTANT
SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade
or the third prong is provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket or table
specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, or the apparatus has been exposed to rain or moisture,
does not operate normally or has been dropped.
15. Do not expose this apparatus to dripping or splashing and ensure that no
objects filled with liquids, such as vases, are placed on the apparatus.
16. To completely disconnect this apparatus from the AC Mains, disconnect
the power supply cord plug from the AC receptacle.
17. The mains plug of the power supply cord shall remain readily operable.
18. Do not expose batteries to excessive heat such as sunshine, fire or the like.
FEDERAL COMMUNICATIONS
COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or modifications
not expressly approved by the party responsible for compliance could void
the user’s authority to operate this equipment. (Example – use only shielded
interface cables when connecting to computer or peripheral devices.)
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and operated
with a minimum distance of 20 centimeters between the radiator and your body.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the product.
WARNING: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
THANK YOU FOR CHOOSING
INPUTMUTE
VOL
1
2
0
3
A JBL
®
PRODUCT
For more than 60 years, JBL, Inc., has been involved in every aspect of music
and film recording and reproduction, from live performances to the recordings
you play in your home, car or office.
You can be confident that the JBL®system you have chosen will provide every
note of enjoyment that you expected – and that when you think about purchasing
additional audio equipment, you will once again choose a JBL product.
Please take a moment to register your product at www.jbl.com to stay posted
on the latest JBL advancements. This also facilitates a better understanding
of JBL customers, allowing JBL engineers to design products that meet their
needs and expectations.
The JBL On Air WEM-1 is an advanced wireless system that allows you to
enjoy your favorite music in remote locations around your home, using almost
any loudspeaker. To ensure trouble-free performance, please carefully read
these instructions completely before connecting or using the system.
UNPACKING THE SYSTEM
Carefully unpack the system. If you suspect damage from transit, report it immediately to your dealer and/or delivery service. Keep the shipping carton and packing materials for future use. Open the package and verify the following contents:
Included:
1 x Owner’s manual
1 x USA warranty sheet
1 x Receiver-amplifier module
1 x Power supply for receiver-amplifier
1 x 120V AC power cord for receiver-amplifier power supply
1 x 230V AC power cord for receiver-amplifier power supply – Shuko plug
1 x 230V AC power cord for receiver-amplifier power supply – UK plug
1 x Handheld remote control
2 x Wall-mount brackets for receiver
1 x Pedestal – to be attached on receiver’s left side if receiver is to be
used vertically
1 x Transmitter module
1 x Power supply for transmitter
1 x 120V AC power cord for transmitter power supply
1 x 230V AC power cord for transmitter power supply – Shuko plug
1 x 230V AC power cord for transmitter power supply – UK plug
1 x 6' (1.8m) Audio stereo cable, RCA-RCA
1 x Wall-mount bracket for transmitter
2 x Panhead M3 x 4 machine screws for attaching wall-mount bracket
to transmitter
4 x Small, round, self-adhesive feet – to be attached on transmitter’s
left-side panel if transmitter is to be used vertically
Remote Control
Wireless Transmitter
Wireless Receiver
3
