JBL LSR6325P User Manual

LSR6325P

ed Studio Monitor System

Owner’s Manual

Important Safety Instructions

The IEC fuse symbol pictured at the left represents an approved, user replaceable fuse. When replacing a
fuse, make sure to replace with only the correct type and fuse rating.

1. Read lnstructions - Before operating your new JBL product, please read all safety and operating
instructions.

2. Keep these instructions - For future reference and troubleshooting purposes, retain these instructions.

3. Heed all warnings - All warnings in this user manual should be followed.

4. Follow Instructions - By following instructions presented in this guide, you should be able to quickly

enjoy an accurate and safe monitoring system.

5. Water and Moisture - Do not use this apparatus near water or plumbing fixtures.

6. Cleaning - Clean with a lint-free cloth - Do not use any solvent based cleaners on the finish. A slightly

damp cloth can also be used on the enclosure surfaces and woofer surrounds.

7. Ventilation - Do not block any ventilation opening, including the Linear Dynamics Aperture Port on the
monitor systems. Install these products in accordance with manufacturers instructions. Do not install near
any heat sources such as radiators, heat registers, stoves or other apparatus that produce heat.

8. Grounding and Power Cords - The power cord supplied with your powered product has a 3-pin plug.
Do not cut off or damage the grounding pin. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet. Dress the power cords so that they will not be inadvertently
walked on or pinched, particularly at plugs, convenience receptacles and the points where they exit the ap­paratus.

All powered products are fitted with a detachable power cord (supplied) which connects to the chassis AC
connector. The power cord has an IEC female connector on one end and a male mains connector on the other
end. This cord is supplied specifically to accommodate the different safety and electrical code requirments
of individual countries. If you are traveling abroad with your system, test the power mains and be aware of
any specific voltage requirements before operating your system.

9. Options - Only use attachments or accessories specified by the manufacturer. .

10. Non-use Periods - Unplug this apparatus during lightning storms or when it will be unused for long

periods of time.

11. Servicing - Refer all servicing to qualified service personnel. Servicing is required when the apparatus
does not work, or has been damaged in any way, including: damage to power cord or plug, water or other
liquid damage to the electronics, or damage due to falling or dropping.

12. Wall or Ceiling Mounting - The appliance should be mounted on a wall or ceiling only as recommend­ed by the manufacturer. [See Pages 6 – 7]

13. Carts and Stands - The appliance should be used only with carts or stands that are sturdy and well
balanced. All appliance and cart combinations should be moved with care. Quick stops, excessive force, and
uneven surfaces may cause the appliance and cart combination to overturn.

2

Explanation of Graphic Symbols

The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the product.

The lightning flash with the arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of insulated "dangerous voltage" within the product's enclo-

sure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

DO NOT REMOVE COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK

ATTENTlON: POUR EVITER LES RISQUES DE CHOC
ELECTRIQUE, NE PAS ENLEVER LE COUVERCLE. AUCUN ENTRETIEN
DE PIECES INTERRIEURES PAR L’USAGER. CONFIER L’ENTRETIEN AU
PERSONNEL QUALIFIE. AVIS: POUR EVITER LES RISQUES D’INCENDIE
OU D’ELECTROCUTION, N’EXPOSEZ PAS CET ARTICLEA A LA PLUIE OU
A L’HUMIDITE.

its contents, in part of it whole, to any party without prior written authorization is a violation of the copyright.

dential and the copyright of JBL Professional. To convey

© JBL Professional 2004

3

Table of Contents

Important Safety Instructions ................................................................................... 2-3

Table of Contents

Introduction

LSR6325P Features ................................................................................................... 5-6

Rear Panel Drawing .................................................................................................... 7

Set-Up

Unpacking .................................................................................................................. 6

Placement .................................................................................................................. 6

Audio Connections ..................................................................................................... 8

AC Power Connections ............................................................................................... 8

Making Sound

Audio Level Adjustment .............................................................................................. 8

Frequency Response Adjustment ................................................................................ 8-9

80 Hz High Pass Filter ................................................................................................ 9

Boundary Compensation ............................................................................................ 9

LED Indication ............................................................................................................ 9

Mounting ................................................................................................................... 9-10

LSR6325P Systems with the LSR6312SP Subwoofer ............................................................... 10

Specifications

System Specifications ............................................................................................... 11

Performance Graphs .................................................................................................. 13

Appendix: Wiring Recommendations ......................................................................................... 14-15

Warranty Statement ................................................................................................................... 16

........................................................................................................................ 4

Front Panel Drawing

Transducer Specifications ......................................................................................... 12

................................................................................................... 7

JBL Professional Contact Information ....................................................................................... 17

4

Introduction

Congratulations on your purchase of the LSR6325P Bi-Amplifi ed Studio Monitor, the newest member of the

LSR6300 Series product line. The LSR6325P system incorporates patented JBL transducer and system
technologies designed to provide ultra-accurate response and exceptional SPL capability in a very compact
form-factor. THX® pm3™ approved for use in the most demanding production applications and environ­ments, the LSR6325P is ideal for stereo and surround sound recording, post production, and broadcast sys­tems where space is limited but accuracy and high-output are a requirement. Because production rooms are
acoustically less-than-perfect, JBL Professional has incorporated technologies in the LSR6325P to overcome
problems in the room. The result: clear accurate sound at the listening position in any room.

LSR6325P Features

5.25” Woofer with JBL Symmetrical Field Geometry (SFG) ® technology – Excursion is maximized by
using a massive 1.5” drive coil, while maintaining excellent distortion characteristics. The heavy magnetic
structure keeps power compression to a minimum reducing spectral shift as power levels increase. The
result is exceptional low frequency output and accurate spectral response at all listening levels.

1” Titanium Composite High Frequency Transducer – Using patented technology, the high frequency
device incorporates titanium and composite materials to improve transient response and reduce distortion.
By reducing distortion in the lower operating range, where the ear is most sensitive, ear fatigue is radically
reduced.

Elliptical Oblate Spheroidal (EOS) Waveguide – Designed for a targeted listening window of +/- 15º verti­cally, the EOS provides a frequency response through the entire window of 1.5 dB from on-axis response.

Di-cast aluminum enclosure – The rigid aluminum enclosure provides a high-inertial ground for optimum
transducer performance and low resonance.

Linear Dynamics Aperture – Contoured ports virtually eliminate high-end turbulence found in traditional
port designs. This provides more accurate low frequency performance at higher output levels.

THX® pm3™ approved – The LSR6325P is THX approved for use in the most demanding production ap­plications and environments

Balanced XLR and unbalanced RCA inputs – Allows connection of professional and consumer audio equip­ment and computer recording workstations.

High Frequency Adjustment with three settings – allows you to tailor high frequency response to taste,
environmental conditions and program requirements.

80 Hz High Pass Filter – allows use with sub woofers without bass management.

Front-panel volume control – provides conveniently located volume adjustment in computer recording and

table-top production applications.

5

LSR6325P Features to Tackle the Problems in the Room

LSR – Linear Spatial Reference Te chnology
JBL Developed Linear Spatial Reference Te chnology to optimize mid and high frequency accuracy at the
listening position where relected sound comes into play. Meeting frequency response criteria for seventy-two
off-axis measurements, the LSR6325P ensures that not just the direct sound,
reaches you at the listening position is also smooth and accurate.

Boundary Compensation - A Boundary Compensation switch restores accurate bass response when the
loudspeaker is wall mounted, positioned close to walls, corners, placed on work surfaces or console meter
bridge.

Magnetic Shielding – The LSR6325P is magnetically shielded to allow use in close proximity to CRT video
and computer displays.

Mounting Options – The LSR6325P enclosure includes mounting points to provide flexibility and allow you to
optimize placement, particularly in small environments. Mounting points are compatible with industry-stan­dard mounting hardware.

Optional LSR6312SP Subwoofer with Room Mode Correction - The use of an optional LSR6312SP
powered subwoofer in your LSR6325P system adds the powerful bene t of Room Mode Correction. The RMC
circuit in the LSR6312SP and the included RMC Calibration Kit allow you to identify and compensate for
troublesome low frequency standing waves. The result is clear extended bass response at the mix position in
any size room.

but reflected sound that

Set Up

Unpacking – Caution: The high-frequency transducer is unprotected and can be damaged if touched while
unpacking the speaker. An easy way to safely unpack your monitors is to open the top of the box, keep the

ller piece on and roll the box upside down. The box can then be slipped off. This also works in reverse for

repacking the system.

Placement – Speaker Placement
Listening Distance: In a stereo close-field application the speaker is typically placed 1 to 1.5 meters (3-5 feet)
from the listening position. In mid- eld or surround sound applications, 2-3 meters is typical. The field in a
stereo listening application is optimized by arranging the speakers to form an equilateral triangle where the
distance between the two speakers equals the distance of each speaker to the listening position. Vertical vs.
Horizontal Placement: The LSR6325P system is designed for vertical orientation which provides broad lateral
dispersion and controlled vertical dispersion to optimize the size of the listening window and minimize reflec­tions off the work surface and the ceiling. Horizontal placement will limit the size of the listening window and

increase reflections which can result in cancella

Angling towards the listening position: The LSR6325P should be angled so the center of the high frequency
transducer points directly at the listener’s ears.

tion at high frequencies.
