INSTRUCTION MANUAL
Nano Tweezers
Ref. NP115-A
Packing List
The following items are included:
Nano Tweezers ....................................... 1 un it
Re f. NP115 - A
Sleeves
Ref . N1738
Features
Ref . N AE-1C
NAE-2C
NAE-9C
Manual ...................................................... 1 unit
Ref. 0020839
www.jbctools.com
INSTRUCTION MANUAL
Nano tweezers
Ref. NP115-A
Nano Tweezers
Re f. NP115 - AControl Unit
Main Switch
Power Socket
2
2,5
1
www.jbctools.com
Changing cartridges
Save time and change cartridges safely without switching the station off.
1. Removing 2. Inserting * Important
1
2
Place the tool in the slot and
pull to remove the cartridge.
Tip Alignment
Fit the tip into the aligner and
turn to the desired position.
2
1
Push the cartridge into the
tool to the mark*.
Mark
For a proper connection insert
the cartridges as far as the mark.
Compatible cartridges
The NP115-A works with C115 cartridges. Find the model that suits your needs in www.jbctools.com
Round Chisel Bevel KnifeRound
bent
Stainless
steel chisel
High thermal
performance
3
Specifications
- Weight: 50 gr (0.1 lb)
- Cable length: 120 cm (47.2 in)
Complies with CE standards.
ESD protected.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warrant y does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
Get 1 extra year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 3 0 days of purchase.
This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
www.jbctools.com
0020839-0419
