JARLTECH Card Reader 1260 User Manual

ISO 9002 Certified

Lead with technology

Win customers with service

1260A

Magnetic Stripe Reader

OPERATION

MANUAL

©Jarltech International Inc. 2005. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part, without the written

consent of Jarltech.
Every effort has been made to ensure that the information in this manual is accurate. Jarltech is not

responsible for printing or clerical errors.
Jarltech International Inc.

3F, No. 1, Lane 538, Chung Cheng Road,
Hsin Tien, Taipei, Taiwan, R.O.C.

This equipment has been tested and found to comply with the limits for Class A digital device. Pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and if not installed and used
in accordance with the instructions may cause harmful interference will not occur in a particular
installation. If this equipment does cause harmful interference to Radio or television reception, which
can be determined by turning the equipment off and on. The user is encouraged to try correct
interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help. This booklet is available from the
U.S. government Printing Office, Washington, DC 20402, Stock NO.004-000-00345-4.

Caution:

Any changes of modifications not expressly
approved by the grantee of this device could void the
user authority to operate the equipment.

Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received including Interference that may cause undesired
operation.

2

1. Introduction

2. Installation

3. Custom Programming Tool

Appendix I: Specifications

3

Introduction

1260A is an advanced bi-directional, programmable magnetic stripe reader. Supports ISO
standard format card .

It is designed for use with credit authorization terminals, point-of-sale terminals, portable terminals,
personal computers and banking terminals.

Model 1260AK is designed to be used with IBM/AT compatible computer, entering data.
As if it were being generated though the Keyboard, no software modification, nor Programming of
input/output devices, nor Addition power supply is needed.

Model 1260AR operates as an on-line card reader which communicates with any computer via an
RS232 interface. The 1260AR requires +12v DC from either an external power supply or internal
power of your computer or terminal.

What’s in packing?

JC-1260AK includes:

o 1 pcs 1260A Card Reader
o 1 User’s Manual CD
o 1 keyboard interface communication cable

JC-1260AR includes:

o 1 pcs 1260A Card Reader
o 1 User’s Manual CD
o 1 RS232 interface communication cable
o 1 Internal power plate
o 1 power cable for internal power plate

4

Installation

JC-1260A KB series:

The MD-6M side of KB cable, shall be connected to PC PS/2 Keyboard port,
And then, connect RJ45 side to JC-1260A.
The MD-6F side of KB cable can be connected to normal PC keyboard, PC keyboard can work with
JC-1260A together.
