NEED MORE HELP?
For all support go to jabra.com/support
jabra.com/pro930
81-04027 E
Jabra
PRO 930 Duo
Quick start guide
© 2015 GN Audio A/S (GN Netcom A/S). All rights reserved. Jabra® is a trademark
of GN Audio A/S.
MADE IN CHINA
MODEL: WHB003BS/ WHB003HS
www.jabra.com
LANGUAGES
ENGLISH / EN 2
FRANÇAIS / FR 6
DEUTSCH / DE 10
ESPAÑOL / ES 14
繁體中文 / CHT 18
PACKAGE CONTENTS
JABRA PRO 930 DUO HEADSET
Multi-function button
Speaker volume up
Mute
Speaker volume down
Microphone boom arm
LED indicator
Speaker
Noise-cancelling
microphone
2
JABRA PRO 930 DUO BASE
1
Foldable base
stand
Battery indicator Mute indicator Audio link
indicator
Icon Event
Battery charging (slow ash)
Full battery
Medium battery
Low battery
Very low battery (fast ash)
Sleep mode (slow ash)
Unknown battery status
Microphone muted
Active audio link between
headset and base
Searching for headset
EN
Speaker
USB port
CLICK
Power adapter port
3
STEP 1: CONNECT TO PC
1. Plug the supplied USB cable into the
port marked on the base.
2. Connect the USB cable to any free
USB slot on the PC.
3. Install Jabra Direct software from
www.jabra.com/direct
STEP 2: CONNECT TO POWER
1. Plug the supplied power adapter
into the port marked on the
base.
2. Connect the power adapter to the
mains power socket.
4
