TECHNICAL SPECIFICATIONS
THE BLUETOOTH
WORD MARK AND LOGOS ARE OWNED BY THE BLUETOOTH SIG, INC. AND ANY USE OF SUCH MARKS BY GN NETCOM A/S IS UNDER LICENSE. DESIGN AND SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
JABRA ECLIPSETM
Bluetooth® Mono Headset
Compatible with any Bluetooth enabled device
Premium music-grade speaker
Our lightest headset ever
Charges in your pocket
FEATURE BENEFIT
What is Bluetooth® wireless technology? Bluetooth wireless technology is a radio technology developed to deliver short-range wireless
mobility. Bluetooth technology eliminates wires between devices, such as mobile phones and
headsets, and enables communication between devices that are in close proximity to one
another. Bluetooth facilitates fast, secure transmissions of both voice and data. More information
is available at www.bluetooth.com or www.bluetooth.org
Bluetooth compliance Bluetooth version 4.1
Supported Bluetooth profi les Headset profi le (v1.2), hands free profi le (v1.6), A2DP (v1.3), phone book access profi le (v1.0)
Supported modes EDR (2 and 3 Mb), SCO, eSCO, sniff mode
Security 128 bit encryption
Operating range Up to 30 meters (98 feet)*
Paired devices Up to 8, connected to two at the same time (multiuse™)
Talk time Up to 10 hours (up to 3 hours in headset and 7 hours in charging case)*
Standby time Up to 3 days*
Power Nap for extended standby time Up to 7 days*
Charging time Approx. 2 hours for charging the headset only, approx. 3 hours for charging the headset and the
charging case together
Wearing style In-ear wearing style
Weight Headset 5.5 grams (0.19 oz), charging case 35 grams (1.23 oz), total 40.5 grams (1.43 oz)
Dimensions Headset L 49.95 x W 17.58 x H 24.82 mm (1.97 x 0.69 x 0.98 in), charging case L 62.2 x W 54.0
x H 25.5 mm (2.45 x 2.13 x 1.00 in)
Speaker 6 mm dynamic speaker, RLR = -5 dB +/- 3 dB
Speaker sensitivity 94 dB SPL at 1 mW /1 kHz
Speaker impedance 16 Ω
Speaker max input power 5 mW
Speaker frequency range 20 Hz - 20 kHz
Microphone type 2 pcs omnidirectional MEMS microphone
Microphone frequency range 100 Hz - 8 kHz
Microphone sensitivity 14 dB +/- 3 dB (SWR)
Operating temperature -10° C to 55° C (14 F to 131 F)
Storage temperature -20° C to 70° C (-4 F to 158 F)
USB Charging Cable 5V, > 100mA
Charging plug dimensions Standard micro USB 5 pin / B Type / W 8.7 x L 5.0 x H 2.4 mm (W 0.35 x L 0.2 x H 0.1 in)
Jabra ECLIPSE materials Eargel materials: Thermoplastic Elastomer (TPE), Silicon Rubber. Headset and charging case mate-
rials: Polycarbonate/Acryl Butadien Styren (PC/ABS), Polycarbonate (PC), Silicon Rubber
Pairing passkey or PIN 0000
Features Answer/end call, reject call, voice dialling (activate Siri/Google Now voice commands)*, button-
free headset - tap/double tap headset, motion sensor, voice control (say “answer”/”ignore” to
answer/reject incoming calls)**, voice guidance**, multiuse™, automatic volume control, NFC on
charging case for easy pairing*, dual microphones for noise cancellation, HD voice compatibility*
and portable charging case
What’s in the box? 1 Jabra ECLIPSE headset, 1 Jabra ECLIPSE charging case, 1 USB charging cable, 3 sets of extra
eargels™ (XS, S and L) , 1 quick start guide, 1 warranty leafl et and 1 register paper
Certifi cation Bluetooth 4.1, CE, CB, FCC, IC, EAC, RoHS, REACH, IDA, NCC, TELEC, KCC, ACMA, RADCOMM, ETA,
SIRIM, SDPPI, NTC, ICASA
Warranty One year limited warranty
* Phone/network dependent
** 10 language options (Dutch, English, French, German, Italian, Japanese, Mandarin
Chinese, Polish, Russian & Spanish) available if using the Jabra Assist app
Jabra Assist app
For iOS and Android
®
JABRA.COM/ECLIPSE
