JABRA MOVE WIRELESS
User Manual
jabra.com/movewireless
1. WELCOME ........................................3
2. WHAT’S IN THE BOX ...................... 4
3. HOW TO WEAR ................................5
3.1 HEIGHT ADJUSTMENT
4. HOW TO CHARGE ........................... 6
4.1 BATTERY STATUS
5. HOW TO CONNECT ..........................7
5.1 BLUETOOTH CONNECT TO A NEW OR SECOND
MOBILE DEVICE
5.2 CONNECT TO 3.5 MM JACK CONNECTOR
6. HOW TO USE ................................. 9
6.1 MUSIC & CHAT
6.2 TURN HEADPHONES ON/OFF
6.3 MULTIPLE CALL HANDLING
6.4 VOICE GUIDANCE
7. SUPPORT .......................................13
7.1 FAQ
7.2 FACTORY RESET
7.3 HOW TO CARE FOR YOUR HEADPHONES
8. TECHNICAL SPECIFICATIONS ........14
jabra move wireless
2
1. WELCOME
Thank you for purchasing the Jabra Move Wireless.
We hope you will enjoy it!
JABRA MOVE WIRELESS FEATURES
Premium wireless sound experience - amplifies
without distortion. Brings out the depth and
clarity of your music
Seals the sound - angled earcups allow you to
hear all the music
Easily connect with any device via Bluetooth 4.0
Life proof - lightweight, comfortable
headphones built & tested for life on the move
Premium materials - stainless steel
Wired option - detachable cord for when you
need to be wired
jabra move wireless
3
2. WHAT’S IN THE BOX
Volume up
button
Multi-function
button
Volume down
button
Micro-USB cable
3.5 mm Jack
Connector
Adjustable
Headband
On/Off/
Pairing
switch
jabra move wireless
Battery and
Connection
Status Lights
Micro-USB Port
(charging only)
Audio cable
4
3. HOW TO WEAR
3.1 HEIGHT ADJUSTMENT
Get the perfect fit by adjusting the headband, as
illustrated.
jabra move wireless
5
4. HOW TO CHARGE
Plug the headphones into any available USB port
on your PC using any micro-USB cable.
4.1 BATTERY STATUS
Tap the Multi-function button when not on a call to
see the battery status. It takes 1-2 hours to fully
charge the headphones.
LED COLOR BATTERY LEVEL
Green Medium/High
Red Low
Flashing red Critically low
jabra move wireless
6
5. HOW TO CONNECT
The Jabra Move Wireless will automatically attempt
to Bluetooth connect to a mobile device whenever
it is powered on (unless already connected to a
Bluetooth device). Simply follow the voice-guided
connection instructions.
5.1 BLUETOOTH CONNECT TO A NEW OR SECOND MOBILE DEVICE
1. Hold the On/Off/Pairing switch in the Pairing
position for 3 secs.
2. Pairing mode will be announced in the
headphones, and the Bluetooth light will flash
blue.
3. Follow the voice-guided instructions to connect
to your Bluetooth device.
jabra move wireless
7
NOTE: If two mobile phones have been connected to the
Jabra Move Wireless, you may need to select which
phone will be used for calls/music. Simply open the
Bluetooth menu on the mobile phone you wish to use
for calls/music and select the Jabra Move Wireless from
the list of devices.
5.2 CONNECT TO 3.5 MM JACK CONNECTOR
Connect the headphones to a 3.5 mm jack
connector on your mobile device or PC using the
supplied audio cable.
NOTE: Bluetooth connections are disabled when
connected to the 3.5 mm Jack Connector.
jabra move wireless
8
6. HOW TO USE
Volume up
button
Multi-function
button
Volume down
button
6.1 MUSIC & CHAT
The buttons on the headphones enable you to
control your music and phone calls.
jabra move wireless
On/Off/
Pairing
switch
9
FUNCTION HOW TO DO IT
Multi-function
Pause/play music
Adjust volume
Tap the
button
Tap the
Volume up or
Volume down button
Skip track
Battery status
Answer/end call
Reject call
Redial last number
jabra move wireless
Press and hold either the
Volume up or Volume
down button
Volume up or
Tap the
Volume down button,
when not on a call
Multi-function
Tap the
button
Press and hold (1 sec) the
Multi-function button
Double-tap the
Multi-
function button
10
6.2 TURN HEADPHONES ON/OFF
Slide the On/Off/Pairing switch to On or Off.
6.3 MULTIPLE CALL HANDLING
The headphones can accept and handle multiple
calls simultaneously.
FUNCTION HOW TO DO IT
Put current call on hold
and answer incoming
call
Press (2 secs) the
function button
Multi-
Switch between held
call and active call
Reject incoming call
jabra move wireless
Press (2 secs) the
function button
Double-tap the
function button
Multi-
Multi-
11
6.4 VOICE GUIDANCE
CLICK TO LISTEN WHAT YOU HEAR
To connect Move, go to the Bluetooth menu
on your phone and select it from the list.
Connected
Disconnected
Connection cancelled
Two devices connected
No device connected
Recharge battery
Battery level low
Battery level medium
Battery level full
Voice prompts off
Voice prompts on
Redialing
jabra move wireless
12
7. SUPPORT
7.1 FAQ
View the full FAQ at jabra.com/movewireless
7.2 FACTORY RESET
To factory reset the headphones and clear the
pairing list, press and hold (5 secs) both the
Volume up button and the Multi-function button
at the same time.
7.3 HOW TO CARE FOR YOUR HEADPHONES
Always store the headphones with the power
off and safely protected.
Avoid storage at extreme temperatures (above
85°C/185°F or below -20°C/-4°F). This can
shorten battery life and may affect operation.
High temperatures may also degrade
performance.
Do not expose the headphones to rain or other
liquids.
jabra move wireless
13
8. TECHNICAL
SPECIFICATIONS
JABRA MOVE HEADPHONES SPECIFICATION
Weight: 150 grams
Dimensions: H 172 mm x W 146.1 mm x L 59 mm
Microphone: 4 mm Omni-directional microphone
Speaker: 40 mm dynamic speaker
Operating range: Up to 10 meters (33 feet)
Bluetooth version: 4.0
Paired devices:
Supported Bluetooth profiles:
Talk time: Up to 8 hours
Standby time: Up to 12 days
Operating temperature: -10° C to 60° C (14 F to 140 F)
Storage temperature: -20° C to 85° C (-4 F to 185 F)
Pairing passkey or PIN: 0000
jabra move wireless
Up to 8 devices, connected to 2 at
same time (MultiUse
Headset profile v1.2, Handsfree
profile v1.6, A2DP v1.2, AVRCP v1.4
TM
)
14
