i-tec U3METALG3HUB User Manual

i-tec USB 3.0 Metal HUB 3 Port + Gigabit Ethernet Adapter

i-tec USB 3.0 Metal 3-Port HUB with
Gigabit Ethernet Adapter, 1x USB 3.0 to
RJ-45, 10/100/1000 Mbps, 3x USB 3.0
Port, LED, for laptop tablet PC, Windows
Mac Linux Android, Space Grey colour

PRODUCT DESCRIPTION

Combination of passive USB HUB with Gigabit Ethernet adapter, for easy and fast connection of your favorite
USB peripherals to your laptop, tablet, PC, and for fast network and Internet access with Gigabit Ethernet
connection. The HUB offers three USB 3.0 ports with the Plug & Play function and standard USB charging – it will
automatically detect connected equipment for USB charging. The USB 3.0 interface is important mainly for data
transfers from USB 3.0 memory cards and flash disks which will use its high transfer speed most.

The Gigabit Ethernet port allows you easy access to 10/100/1000 Mbps network. You can enjoy high-speed
internet access without any interruption. This HUB is powered from the USB bus and it has a built-in overcurrent
protection of your computer in case of short connection on the peripheries. It supports a wide range of
operating systems from Windows and Mac OS to Linux. Ethernet network connection can also be used in the
Android system. However, the support of this function must be included by the manufacturer directly in the
particular Android device. You can easily check this support in Network Connection Settings → Other Networks,
which must include Ethernet.

In case there are any problems with the installation, technical difficulties or incorrect function of
the equipment, please check first for the possible solution in detailed manual or in the FAQ tab.

PRODUCT FEATURES

Combination of passive USB HUB with Gigabit Ethernet adapter, for easy and fast connection of your
favorite USB peripherals to your laptop, tablet, PC, and for fast network and Internet access with Gigabit
Ethernet connection
1x USB 3.0 connector, for connecting to a laptop, tablet or PC
Fast network and Internet access with Gigabit Ethernet connection, 1x Ethernet GLAN RJ-45 port
supports 10/100/1000 Mbps speeds
3x USB 3.0 port for connecting the USB equipment and high-speed data transfer (5 Gbps)
LED indication for Ethernet connection
Supports Wake-on-LAN and Plug & Play function
Realtek 0411 Chipset – USB 3.0 HUB
Realtek 8153 Chipset – USB 3.0 to Gigabit Ethernet – supports standard IEEE 802.3, IEEE 802.3u, IEEE

802.3ab and IEEE 802.3az (Energy Efficient Ethernet)
Powered through USB-C bus, no power adapter is needed
OS: Windows 7 32/64bit, Windows 8 32/64bit, Windows 8.1 32/64bit, Windows 10 32/64bit, Mac OS,
Linux, Android

i-tec Technologies s.r.o. 1/3 https://www.i-tec.cz

Product dimensions: 96 x 30 x 21 mm
Product weight: 65 g
Packaging dimensions: 145 x 130 x 25 mm
Packaging weight: 101 g

SYSTEM REQUIREMENTS

Hardware requirements: laptop, tablet, PC with free USB port Operation system: Windows 7 32/64bit, Windows 8
32/64bit, Windows 8.1 32/64bit, Windows 10 32/64bit, Mac OS, Linux, Android

PACKAGE CONTENTS

i-tec USB 3.0 Metal HUB 3 Port + Gigabit Ethernet Adapter with cable (28 cm)
Quick Start

SPECIFICATION

Part Number Product Description & EAN

U3METALG3HUB i-tec USB 3.0 Metal HUB 3 Port + Gigabit Ethernet Adapter

EAN: 8595611701856

Hardware

Bus type USB-3.0

Ports/Connectors

USB 3.0 TYPE A 3

LAN RJ-45 1

System Requirements

Hardware Hardware requirements: laptop, tablet, PC with free USB port

Operating system Windows 7/8/8.1/10 (32/64 bit)

Mac OS X
Chrome OS
Linux Ubuntu 14.04/16.04
Android 5
Android 6, 7, 8Windows 10 - Automatic installation of OS drivers. Other
operating systems - manual driver installation. Firmware updates
automatically.

Other features

Colour Space Gray

Housing Material Aluminium

Product Dimensions 96 x 30 x 21 mm

Product Weight 65 g

Package Weight 101 g

Packaging Dimensions (LxWxH) 145 x 130 x 25 mm

Support

Warranty period 2 years

Technical support lifetime

Package contents
