i-tec U3GL3SLIM User Manual
i-tec USB 3.0 Slim HUB 3 Port
+ Gigabit Ethernet Adapter
User’s guide Gebrauchsanweisung Uživatelská příručka
Instrukcje obsługi Užívateľská príručka
Vartotojo vadovas
Recommended products
Recommended products
i-tec USB 3.0 Metal Charging HUB 10 Port
P/N: U3HUBMETAL10
i-tec USB 3.0 Metal Charging HUB 7 Port
P/N: U3HUBMETAL7
i-tec USB 3.0 Metal Charging HUB 4 Port
P/N: U3HUBMETAL4
10x / 7x / 4x USB 3.0 port
Compatible with USB 2.0 / 1.1
USB charging detection mechanism for
mobile devices for all 10 / 7 / 4 ports
Plug & Play
Power adapter
i-tec USB 3.0 Metal HUB 3 Port
with Gigabit Ethernet Adapter
P/N: U3GLAN3HUB
3x USB 3.0 port
1x Ethernet 10/100/1000 Mbps LAN
RJ-45 port
LED indication for charging status
and Ethernet connection
Inte rface USB 3.0, backw ard
compatible with USB 2.0
Plug & Play
i-tec USB 2.0 Metal Mini Audio Adapter
P/N: U3AMETAL
1x 3.5 mm audio output for earphones /
loudspeakers – 2-channel output 44.1/48
kHz at 16 bit (STEREO)
1x 3.5 mm input for a microphone (MONO)
Interface USB 2.0
Plug & Play
i-tec USB 3.0 Dual Docking Station
+ USB Charging Port
P/N: U3HDMIDVIDOCK
1x DVI-I port
1x HDMI port
1x Fast USB 3.0 port for charging
of USB devices
1x USB 3.0 port type A
4x USB 2.0 port type A
1x USB 3.0 port type B
1x Ethernet 10 / 100 / 1000 Mb/s GLAN
RJ-45 port
1x 3.5 mm audio output for
earphones / loudspeakers
1x 3.5 mm input for a microphone
i-tec Metal Power Bank 8000 mAh with 3-in-1 Cable
P/N: PB8000
A portable battery with a capacity of 8000 mAh
For charging of mobile phones, GPS navigators,
tablets, music players and other digital devices
Ideal solution for travelling where you cannot
recharge your devices from the mains
4 LED diodes indicating the current battery
capacity level
Control by a single ON/OFF button
Slim design
3-in-1 USB cable (Micro/Apple 8pin/Apple 30pin)
i-tec USB Power Quatro Charger 4 Port
P/N: CHARGER-FB4
Network-based USB charger
Fast and efficient charging of mobile equipment
Charging up to 4 pieces of USB equipment
simultaneously
Special identification circuits for the iPad/iPhone
and Samsung phones and tablets
Recommended products
EN
Read carefully the user manual before assembly - installation - commissioning.
Protect yourself and avoid damaging your equipment.
DE
Lesen Sie unbedingt die Gebrauchsanweisung vor Aufstellung – Installation –
Inbetriebnahme. Dadurch schützen Sie sich und vermeiden Schäden an Ihrem
Gerät.
CZ
Pečlivě si přečtěte uživatelskou příručku před montáží – instalací – uvedením do
provozu. Ochráníte tím sebe a vyvarujete se poškození Vašeho zařízení.
PL
Przeczytaj uważnie instrukcję przed montażem / podłączeniem / użytkowaniem,
aby ustrzec się przed obrażeniami a urządzenie przed uszkodzeniem.
SK
Každopádne si prečítajte užívateľskú príručku pred zložením - inštaláciou uvedením do prevádzky. Ochránite sa tým a vyvarujete sa škodám na Vašom
prístroji.
LT
Prieš montavimą-instaliavimą-eksploatavimą išsamiai perskaitykite vartotojo
vadovą. Tuo apsaugosite save ir išvengsite Jūsų įrenginio pažeidimo.
i-tec USB 3.0 Slim HUB 3 Port
+ Gigabit Ethernet Adapter
ENGLISH ................................................................................... 05-06
DEUTSCH ................................................................................. 07-08
ČESKY ...................................................................................... 09-10
POLSKI ...................................................................................... 11-12
SLOVENSKY ............................................................................. 13-14
LIETUVOS ................................................................................. 15-16
Declaration of Conformity ............................................................. 17
WEEE ............................................................................................. 18
PRODUCT OVERVIEW
1. USB 3.0 cable type A for connecting to a notebook / PC
2. 3x output USB 3.0 ports for connecting USB equipment
3. 1x Ethernet GLAN RJ-45 port supports 10 / 100 / 1000 Mbps speed,
for fast network and Internet access with Gigabit Ethernet
connection
i-tec USB 3.0 Slim HUB 3 Port + Gigabit Ethernet Adapter
INTRODUCTION
Thank you for purchasing „i-tec USB 3.0 Slim HUB 3 Port + Gigabit Ethernet Adapter“. This is a
product that combines the functions of 3-port USB 3.0 HUB with Gigabit Ethernet adapter.
The HUB offers three USB 3.0 ports with Plug & Play option. The USB 3.0 interface is important
ENGLISH
mainly for data transfers from USB 3.0 memory cards and flash disks which will use its high transfer
speed most. HUB is powered from the USB bus and has a built-in surge protection for your computer
in the event of a short circuit on the peripheral devices. The interface is backward compatible with
USB 2.0. You will just connect the HUB by the USB cable to your computer and immediately you can
start using it. It is an ideal companion for everybody who does not have enough USB ports in his/her
notebook, ultrabook or PC and who has to constantly connect and disconnect his/her favorite USB
equipment such as flash disks, mobile phones, tablets, digital cameras, MP3 players, printers, etc.
The Gigabit Ethernet port allows user's computer instantly connect to a 10/100/1000Mbps network.
No need to purchase an extra Gigabit network card and share a PCI or Cardbus slot. With compliance
with USB 3.0 specification, this adapter ensures true 10/100/1000Mbps network speed without any
compromise. Besides, compact and bus-powered design means external power is not required.
SPECIFICATION
3x USB 3.0 port Type-A for connecting USB equipment
1x USB connector Type-A for connecting to a notebook / PC
1x Ethernet 10/100/1000Mb/s LAN RJ-45 port with function MDI/MDIX and self-correction
VIA VL813 chipset compliant with USB 3.0 specification, revision 1.0
ASIX AS88179 USB 3.0 to Gigabit Ethernet Adapter chipset – supports standard IEEE 802.3,
IEEE 802.3u, IEEE 802.3ab and IEEE 802.3az (Energy Efficient Ethernet)
Interface USB 3.0, backward compatible with USB 2.0
LED indication for Ethernet connection
Supports Wake-on-LAN
Operation temperature: 0-40°C
Storage temperature: -10 to +80°C
Humidity: up to 85%
Dimensions: 123 x 29 x 19 mm
Weight: 50 g
SYSTEM REQUIREMENTS
Hardware requirements: notebook / PC with free USB 3.0 / 2.0 port. If you connect to USB 2.0 transfer
speed and some function can be limited. CPU Processor Intel Pentium 1.2GHz and higher, 512MB
RAM.
Operation System: Windows XP SP3 / Vista / 7 / 8 / 8.1 / 10 32/64 bit, Mac OS X, Linux, Android
DRIVER INSTALLATION*
*The driver version is subject to change due to the driver updated.
Note: DO NOT connect the device to your computer before completing the installation of driver!
EN
05
