i-tec TB3CDUALDPDOCKPD User Manual

i-tec Thunderbolt3/USB-C Dual DisplayPort 4K Docking Station +
Power Delivery 85W

i-tec Thunderbolt3/USB-C Dual
DisplayPort 4K Docking Station + Power
Delivery 85W

PRODUCT DESCRIPTION

The latest, second-generation Thunderbolt 3 technology, has arrived. Outstanding performance, ultra-fast data
transfer rate and up to 8K* resolution support. This is one of the most powerful docking stations available in the
market today.

Enjoy unrivalled image quality, fast internet, and the ability to transfer data at a rate of over 1 GB per second,
even when using multiple USB ports simultaneously. You can also connect your headphones or speaker and
charge your notebook (85W) while working , all via a single port.

Thanks to the integrated DP 1.4 protocol, you can connect this docking station to a monitor with up to 8K (7680
x 4320)* with a 30 Hz refresh rate, which is comparable to four 4K monitors side by side. An ideal solution for
professional graphic designers, data analysts, engineers, film editors or enthusiasts.

Second generation Thunderbolt 3 technology means the docking station is compatible with Thunderbolt 3 and
USB-C, making it a flexible and versatile option for companies with a mixed estate of Thunderbolt 3 and USB-C
notebooks or tablets.

Connect dual 4K/60Hz external displays, or a single 8K/30Hz*.
Power delivery: 85W
Features two DisplayPort outputs
2x USB 3.0, 1x USB 3.1 Gen 2 with fast charge support and 2x USB-C Gen 2 ports (10Gbps) make it easy
to connect all of your existing USB devices and peripherals.
Gigabit Ethernet RJ-45 port provides reliable, robust and high-speed internet connection, supporting
10/100/1000 Mbps speeds.
Combo audio & microphone in/out jack on the front panel.
Kensington lock slot provides additional security, especially for those working regularly in shared offices
or public spaces.
Power saving On/Off switch on the top panel.
Supports i-tec docking station VESA bracket for vertical installation behind a VESA-compliant monitor.
Supports Windows 10, macOS X
Supplied with 135W (20V, 6,75A) professional quality power supply and 70 cm Thunderbolt 3 cable.

* 8K resolution must be supported by the host notebook or tablet.

PRODUCT FEATURES

1x Thunderbolt 3 port for connecting to a device with Thunderbolt 3 or USB-C
Power Delivery: 85 W

i-tec Technologies s.r.o. 1/3 https://www.i-tec.cz

Video ports:

2x DisplayPort

Resolution:

Thunderbolt 3 host:

1 monitor – 1x Display Port → up to 8K/30 Hz*
2 monitors – 2x Display Port → up to 2x 4K/60 Hz

USB-C host:

1 monitor – 1x Display Port → up to 4K/30 Hz

2 monitors – 2x Display Port → up to 1920 x 1080/60 Hz
2x USB-C Gen 2 port (10 Gbps, for data only)
1x USB 3.1 Gen 2 port (10 Gbps) with quick charging support (BC 1.2)
2x USB 3.0 port
1x Ethernet GLAN RJ-45 port
1x 3.5 mm combined audio and microphone input
1x input for power supply (DC 20 V/6.75 A)
ON/OFF switch for the docking station
Kensington lock support
Thunderbolt 3 cable (70 cm)
OS: Windows 10, macOS X (Sierra and higher) with latest updates
Product dimensions: 197 x 78 x 31 mm
Product weight: 385 g
Package dimensions: 269 x 210 x 48 mm
Package weight: 1279 g

* 8K resolution must be supported by the connected laptop or tablet.

SYSTEM REQUIREMENTS

Hardware Requirements:

Device with a free Thunderbolt 3 or USB-C port

Requirements for Power Delivery function:

Device with a free Thunderbolt 3 or USB-C port with Power Delivery support.

Requirements for video output:

Device with a free Thunderbolt 3 or USB-C port with DisplayPort Alternate Mode support.

Operating system:

Windows 10, macOS X (Sierra and higher) with latest updates

SPECIFICATION

Part Number Product Description & EAN
