i-tec Aduance series, U3HUBMETAL402, U3HUBSTAND7, PB8000, CARPA90W User Manual
...
i-tec USB 3.0 Metal Charging HUB
7 Port HUB
User’s guide Gebrauchsanweisung Uživatelská pøíruèka
Instrukcje obs³ugi Užívate¾ská príruèka
Vartotojo vadovas
EN
Read carefully the user manual before assembly - installation - commissioning.
Protect yourself and avoid damaging your equipment.
DE
Lesen Sie unbedingt die Gebrauchsanweisung vor Aufstellung – Installation –
Inbetriebnahme. Dadurch schützen Sie sich und vermeiden Schäden an Ihrem
Gerät.
CZ
Peèlivì si pøeètìte uživatelskou pøíruèku pøed montáží – instalací – uvedením do
provozu. Ochráníte tím sebe a vyvarujete se poškození Vašeho zaøízení.
PL
Przeczytaj uwa¿nie instrukcjê przed monta¿em / pod³¹czeniem / u¿ytkowaniem,
aby ustrzec siê przed obra¿eniami a urz¹dzenie przed uszkodzeniem.
SK
Každopádne si preèítajte užívate¾skú príruèku pred zložením - inštaláciou uvedením do prevádzky. Ochránite sa tým a vyvarujete sa škodám na Vašom
prístroji.
LT
Prieð montavimà-instaliavimà-eksploatavimà iðsamiai perskaitykite vartotojo
vadovà. Tuo apsaugosite save ir iðvengsite Jûsø árenginio paþeidimo.
i-tec USB 3.0 Metal HUB 7 Port
P/N: U3HUBSTAND7
?7x USB 3.0 port
?Compatible with USB 2.0 / 1.1
?USB charging detection
mechanism for mobile devices
for all 7 ports
?Plug & Play
?Power adapter
Recommended products
i-tec Metal Power Bank 8000 mAh with 3-in-1 Cable
P/N: PB8000
?A portable battery with a capacity of 8000 mAh
?For charging of mobile phones, GPS navigators,
tablets, music players and other digital devices
?Ideal solution for travelling where you cannot
recharge your devices from the mains
?4 LED diodes indicating the current battery
capacity level
?Control by a single ON/OFF button
?Slim design
?3-in-1 USB cable (Micro/Apple 8pin/Apple 30pin)
i-tec USB 3.0 Metal HUB 4 Port
P/N: U3HUBMETAL402
?4x USB 3.0 port
?Compatible with USB 2.0 / 1.1
?USB charging detection mechanism for
mobile devices for all 4 ports
?Plug & Play
?Passive HUB without power adapter
i-tec Car Slim Metal Adapter 90W
P/N: CARPA90W
?Universal automatic car adapter with 90 W
output
?Output voltage is set automatically by tips
?Ideal choice for the power supply of almost
any notebook or other equipment
?The advantage is an integrated USB
interface
?Supplied with 10 tips
i-tec Power Inverter 200 W 12/24 V
P/N: POWIN200
?Inverter transforms input DC voltage 12V/24V
to output AC 230V / 50Hz with power up to
200W
?Input voltage is recognized automatically
?It is suitable to power you home appliance in
your car, truck, caravan or boat or whenever
electric network is not available
?Inverter can be used to power TV, video
recorders, cell phone chargers, tablet/
notebook chargers and other similar devices
i-tec Bluetooth Music Receiver with AC 230V Adapter
P/N: BT2HIFI
?Wireless stereo audio receiver for playing the music
?Turn your favourite loudspeakers or stereo system
into a wireless system for your mobile phone, tablet
or computer
?Equipped with power adapter and compartment for
1x AAA battery allowing convenient use on your
travels
?Supplied with 3,5 mm audio cable and 3,5 mm / 2x
RCA cable
Recommended products
i-tec USB 3.0 Metal Charging HUB
7 Port HUB
ENGLISH ................................................................................... 05-06
DEUTSCH ................................................................................. 07-08
ÈESKY ...................................................................................... 09-10
POLSKI ...................................................................................... 11-12
SLOVENSKY ............................................................................. 13-14
LIETUVOS ................................................................................. 15-16
Declaration of Conformity ............................................................. 17
WEEE.............................................................................................. 18
INTRODUCTION
i-tec USB 3.0 Metal Charging HUB will immediately catch your attention thanks to its elegant
metallic design. It is an ideal companion for everybody who does not have enough USB ports in
his/her notebook, ultrabook or PC and who has to constantly connect and disconnect his/her favorite
USB equipment such as flash disks, mobile phones, tablets, digital cameras, MP3 players, printers,
etc.
This HUB offers 7 USB 3.0 ports with the Plug & Play function and standard USB charging – the
HUB will automatically detect connected equipment for USB charging. One of the advantages is that
thanks to their placement you have enough space even for connection of large pieces of equipment.
The USB 3.0 interface is important mainly for data transfers from USB 3.0 memory cards and flash
disks which will use its high transfer speed most.
The advantage is included external power adapter which you can use for backing up data on
external hard drives or for connecting high power consumption devices which are powered directly
from the USB port.
This HUB does not require installation of drivers. You will just connect it by the USB cable to your
computer and immediately you can start using it. This HUB has a built in overcurrent protection of
your computer in case of short connection on the peripheries. The interface is compatible with USB
2.0 / 1.1.
Thanks to its compact dimensions and low weight it is an ideal companion to your notebook when
traveling.
INSTALLATION IN WINDOWS XP/VISTA/7/8/8.1, MAC OS X AND HIGHER
The HUB is installed automatically, no need install drivers. Connect the connector of the power
adaptor to the HUB and connect the power adaptor to a socket outlet with 230V. Then plug the HUB
via USB cable into available USB port (USB 3.0, 2.0 or 1.1 standard) of your notebook / PC and follow
the on-screen instructions. The HUB will be installed and displayed in Device manager as “USB 3.0
HUB” and “USB 2.0 HUB”.
User’s guide
IENG
L
SH
EN
06
EN
07
i-tec USB 3.0 Metal Charging HUB
DESCRIPTION
1. Input for connecting the power adaptor
2. 1x input USB 3.0 port type A for connecting to a notebook / PC
3. 7x output USB 3.0 ports for connecting USB equipment
4. LED diode – the diode is ON when the HUB is connected to the power adaptor or to a USB port of
a notebook / PC
CHARGING
You can use external power adapter, if you connect printer, scanner or other high power consumption
devices to USB ports in HUB (power adapter is included). Respect the basic rules while using this
power adapter (for ex. do not let in reach of children, if the adapter is in 230 V circuit, do not put it into
the water and so on).
CHARGING
The HUB supports charging of the connected USB mobile equipment such as smartphones
(including iPhone and Samsung phones), e-book readers, multi-media players, GPS navigators, and
tablets (e.g., Asus, Toshiba, GoClever, Prestigio, Emgeton, Sencor). The HUB does not support
charging of iPad and Samsung tablets which require special identification circuits. Using the
original cable connect the equipment to be charged to the USB port of the HUB. At the same time the
power adaptor needs to be connected to the HUB as well.
SYSTEM REQUIREMENTS
Hardware requirements
Notebook / PC with one available USB port
Operating system
Windows XP, Windows Vista, Windows 7 32/64bit, Windows 8 32/64bit, Windows 8.1 32/64bit, Mac
OS X 10.x or higher
SPECIFICATION
?7x USB 3.0 port for connecting USB equipment
?1x USB 3.0 port for connecting the HUB to a notebook / PC
?Transfer rate up to 5 Gbps
?USB charging detection mechanism for mobile devices
?Plug & Play function
?Overload and overcurrent protection
?LED diode
?Storage temperature -10~85 °C
?Working temperature 0-40 °C
?Power adapter: input AC 100-240 V, 50-60 Hz, 0.8 A; output DC 12 V, 2.5 A
?OS Windows XP, Vista, 7 32/64bit, 8 32/64bit, 8.1 32/64bit, Mac OS X 10.x or higher
?Product dimensions 86 x 86 x 14 mm
?Product weight 96 g
ENGLISH
User’s guide
PACKAGE CONTENTS
?i-tec USB 3.0 Metal Charging HUB 7 Port
?USB 3.0 cable (90 cm)
?Power adapter (DC cable 120 cm)
?User's Guide
FAQ
Question: The HUB is not installed automatically immediatelly after connection.
Answer: Device should be installed automatically in supported OS. If installation doesn't start,
please restart your notebook / PC. After restarting the notebook / PC, the device installation starts.
Question: I have a problem with detection and installation of HUB.
Answer: Install the latest drivers for USB 3.0 interface of your notebook / PC.
Question: Will the HUB charge iPad or Samsung tablets?
Answer: No, charging of iPad and Samsung tablets, which require special identification circuits,
is not supported.
IENG
L
SH
EN
08
