OWNER'S MANUAL
Ceiling Speaker
Ceiling Speaker
T-205A/206A/208A
T-205A/206A/208A
Safety Tips
Readers
Warning
Such as the inappropriate use of staff will cause
injury, death and property damage.
Please be sure to use the former reading detailed notes.
Really pay attention to this manual and a safety with the important warning.
Recommend that you keep this manual for future reference.
When installed loudspeakers
Definitely will not be allowed to speakers and any exposure in the rain-wet
or water, may be inconsistent with ,or fire.
Restricted by the provisions of the speakers on the voltage, such as the
use of high voltage may cause electric shock or fire disaster. Is no pruning,
distorted, or replacement of damaged wires.
Avoid instability in the installation or set up speakers, such as shaking the
table or flat surface , the speaker can avoid falling caused personal injury
or property damage.
Speakers will be installed in support of the speaker or the weight of a solid
shelf. Speaker swap can be avoided caused personal injury or property
damage.
Wet hands must not be admitted into or plugs, may lead to electric shocks.
The allocation of plugs, make sure that pull plugs, rather than pull wires.
The use of a damaged power line of machinery may cause fire or electric
shock.
Mobile speaker, you plug the prior allocated. If the speaker and plugs may
be moving together will cause fire or electric shock.For plugs,identified as
plugs for grip.
Will not be allowed to speakers on the vent cover. May cause internal
heating caused by the fire.
Avoid speakers installed in the humidity or dust, direct contact with the sun,
from the near-electric, or smoke or steam, may cause fire or electric shock.
Common warning signs and security
The manual shown warning signs and security is to prevent the improper
operation due to personal injury arising from the loss of property, please
read before using this product must understand that this manual security
symbols and Warning to indicate fully aware of potential risks.
Dear customers,your use of the broadcasting company speaker series. We
would like to extend my heartfelt thanks to all of the Company manufactured
products have been tested before, the commitment to keep its quality. Loud speakers broadcast Pan-for hotels, commercial buildings, supermarkets,
schools, leisure and entertainment venues, is your ideal choice. For your
installation, commissioning and use of this product, the installation please
read this note.
T-205A
CEILING SPEAKER
1.25W
2.5W
5W
COM
Frequency Response(-10dB): 80-20KHz
SPL(1W/1M) 89dB
100Volt
Cutout Size: 180mm
10W
Black-------COM
1K ---------10W
2K -----------5W
4K ---------2.5W
8K -------1.25W
53.00 mm
T-206A
CEILING SPEAKER
2.5W
5W
10W
COM
Frequency Response(-10dB): 70-20KHz
SPL(1W/1M) 92dB
100Volt
Cutout Size: 208mm
20W
Black-------COM
500 --------20W
1K--- ------10W
2K--- -------5W
4K--- -----2.5W
64.00 mm
73.00 mm
T-208A
CEILING SPEAKER
3.75W
7.5W
15W
COM
Frequency Response(-10dB): 60-20KHz
SPL(1W/1M) 94dB
100Volt
Cutout Size: 245mm
30W
Black-------COM
330 --------30W
670 --------15W
1.3K ------7.5W
2.6K ----3.75W
Step 1 With measurement tools needed to detect speaker hole, and then
open a hole in the ceiling, and then through the open well hole wiring
connected to the speaker on.
Step 2 Of the mask opening speaker.
Step 3 Speakers installed in the ceiling and fixed. So close to the edge of
the ceiling speakers, rotating clockwise and tighten the screws.
Dimension
Specifications
Label stickersInstallation
T-206A
T-208A
T-205A
Model
Power Taps@100V
Power Taps@70V
SPL(1W/1M)
Freq Response
Weight
Cutout Size
Dimensions
Impedance
T-205A
1.25/2.5/5/10W
0.65/1.25/2.5/5W
89dB
Black:COM/1K
/2K /4K /8K
80-20KHz
180mm
215X75mm
0.8Kg
T-206A
2.5/5/10/20W
1.25/2.5/5/10W
92dB
70-20KHz
208mm
240X78mm
1.2Kg
T-208A
3.75/7.5/15/30W
1.87/3.75/7.5/15W
94dB
60-20KHz
245mm
280X80mm
1.6Kg
Black:COM/500
/1K /2K /4K
Black:COM/330 /
670 /1.3K /2.6K
5 215
6 240
8 280
5 180
6 208
8 245
T-205A/206A/208A
5 75 mm
6 78 mm
8 80 mm
5 215 mm
6 240 mm
8 280 mm
5 215 mm
6 240 mm
8 280 mm
5 75 mm
6 78 mm
8 80 mm
