User’s Manual

N10

Thank you for purchasing the product. Please read the manual carefully before use.

I Quick Start I

Turning on/off the Player 2 Listening to music 2

Recording 3 Charging the Player 4

Chapter

Quick Start

Turning on/off the Player

Quick Start

Playing Music

Turning on the player

Press the PLAY/STOP button to turn the player on.

Press and hold

The player will power off after a period of time with no-activity (not playing music, etc.). Please see Page 46 to adjust this setting.

Selecting track

: Selects the previous track.

: Selects the next track.

Controlling volume

+ : Increases volume

- : Decreases volume

Playing music

Press the PLAY/STOP button to play music.

Connecting earphones

Connect the earphones as shown above.

Type A Type B

Turning off the player

Press and hold the PLAY/STOP button to turn the player off.

Press the PLAY/STOP button again to play music.

I 1 Quick Start I

Quick Start

Recording Voice

Starting recording

Press the MENU button.

- Recording will be started.

Finishing recording

Press the MENU button again.

- Recording will be finished.

Listening to recording file

Press the PLAY/STOP button after stopping recording to play the recorded file.

Quick Start

Recording Voice

Navigating menu

Press and hold the MENU button.

Press and hold

Recording Stand By

Press the PLAY/STOP button.

- The player will be in standby mode with displaying RECORD READY on LCD.

Selecting Voice Recording

Press the / button to select [Voice].

Quick Start Guide

Charging the Player

Charging with USB cable.

Push the "PUSH OPEN" on the back of your player to disconnect its cap as shown below. Connect the USB port and PC with USB cable to charge battery.

The player will charge automatically when the player is connected to the PC.

Player will charge even when powered off.

Charging time: Approx. 1.5 hours (At full discharge, Stop mode)

Note ...

I Getting started I

Greetings 6 Copyright and Certifications 6 Trademarks and Disclaims

Features 9

Accessories

9 Locating the Controls 10 LCD Display

Chapter

Getting started

Greetings

Getting started

Thank your for your iriver purchase.

Also, welcome to the world of N10, the market-leading MP3 player. We are sure that the iriver's N10 player may sufficiently satisfy you and make your life more enjoyable. This user's manual is provided to help you safely use the product. Please read this manual carefully before using it. Thank you.

http://www.iriver.co.kr

The iriver's home page provides the overview of company and products, other related information, and answers to common questions. Firmware and software updates are also available as well as the most recent information about your iriver product.

You may get useful information from "User's Forum" and FAQ. Register your ID and get any appropriate online customer support. Also, you can get newsletter such as newly announced product, firmware upgrade, various promotion events via email.

iriver Limited has all the rights of the patent, trademark, literary property and intellectual property related to this manual. You may not copy or reproduce any part of this manual unless authorized by iriver Limited. You can be punished by using any part of this manual illegally.

The software, audio and video which have an intellectual property are protected by copyright and international laws. It is user s responsibilities when he/she reproduce or distribute the contents created by this product.

The companies, institutions, products, people and events used in examples are not real data. We don't have any intension to be related with any companies, institutions, products, people and events through this manual and should not draw inferences. Users are responsible for observing the copyrights and intellectual properties.

Certifications

CE, FCC, MIC

I 2 Getting started I

Getting started

Trademarks and Limited Liability

Trademarks

Windows, Windows 98 SE, Windows ME, Windows 2000, Windows XP and Windows Media Player are registered trademarks of Microsoft Corp.

Limited Liability

Neither the Manufacturer, importers nor dealers is responsible for any accidental damage including bodily injury or any damage resulting from misuse or unsuitable operation by you.

The information on this manual is prepared with the current product specifications. The manufacturer, iriver Limited, is adding new features to the product and may persistently apply new technologies hereafter.

All standards may be changed at any time without notice.

Note ...

Getting started

Features

16 Gray Organic EL Display Supporting Multiple Languages

N10 series comes with 16 gray OELD which can support multiple languages (40 languages).

Necklace with Integrated Earphones

Direct Charging via USB

6 Preset EQ : Normal, Rock, Jazz, Classic, U Bass, Metal

Xtreme EQ and Xtreme 3D

Customize your own EQ with Xtreme EQ and enhance bass and surround sound with Xtreme 3D.

Voice Recording

Voice record level is automatically controlled by AGC function.

Firmware Upgrade

Provides the latest updated features via firmware upgrade.

Supports 100 folders total and up to 260 files at one time

Simple navigation makes it easy to find any song

I 2 Getting started I

Main unit

Getting started

Accessories Accessories subject to change without notice and may vary from image shown.

Earphone Covers

Mini USB Adapter / USB Cable

Installation CD

User Manual/Warranty Card/ Quick Start Guide

Type B Necklace, cap

Type A Necklace style earphone

Hold connection part of necklace and push it into the direction of arrow.

Hold the end of strap and pull it out to the direction of arrow to separate the connection part.

Put the separated end into the neck strap hole on the player. The connected part will be released.

Assemble the earphone in the opposite order after putting the strap in the connection hole of the player.

Getting started

Locating the Controls Actual player may differ slightly from images below.

Front View

Type A Type B

Rear View

OEL Screen

USB Connection

Port

OEL Screen

USB Connection

Port

Eject button

Cap

Getting started

Locating the Controls Actual player may differ slightly from images below.

Front View

Rear View

Earphone jack

Neck strap

Eject button

Cap

I 2 Getting started I

Getting started

Locating the Controls The images below can be different from the product.

Left side

Right side

PLAY / STOP / TURN ON / TURN OFF button

Long : MENU button Short : A-B Repeat

Volume – / Move to the Down button

Volume + / Move to the Up button

Next Track/ Move to the Left button

Previous Track/ Move to the Right button

Getting started

LCD Display

1 6

MUSIC mode

1 Clock 2 Progress Bar 3 Playback Mode / Status 4 Folder Name 5 Music Title 6 Battery Indicatorr 7 Play Time 8 Volume Level 9 EQ / File Format / Bit Rate /

Sample Rate

Getting started

LCD Display

IRM (iriver Rights Management) iriver Rights Management is a digital music format. Please visit our web site for details about this music format.

File format

ASF WMA MP3 IRM

Getting started

LCD Display

RECORD mode

[Before Recording]

[After Recording]

1 Recording Status 2 Recording Icon 3 Status Bar 4 Number of Files 5 Recording Time 6 Remaining Time

7 Recording Status Bar 8 Recording Folder Name 9 Recording File Name

I Basic Operation I

PC Software Installation 14 Connecting to the PC 17 Installation of "New Hardware" 18 Safely Removing the Player from the PC 19 Operate the Software 20 Learning the Basic Function 22 Toolbar Menu 22 File Managing Tools 23 File Menu 23 View Menu 24 Tools 24

Windows 25 Help 25 Downloading from the PC 26 Basic Operation 27 Navigation 27 MP3 28 Voice Recording 29 Menu Setting 31 Deleting File or Folder 32

Chapter

Basic Functions

PC Software Installation Install the software before connecting the player to PC.

On inserting software installation CD into CD-ROM drive located in PC, the following screen will appear.

- IIf the installation program does not automatically run in a few seconds, click My Computer icon to browse the CD-ROM drive and run SETUP.EXE manually.

- The software installation CD contains :

Device Driver Manager Program for PC Manager Program for Mac

System Requirements (Windows)

Pentium 133Mhz or higher CD-ROM drive USB port 10MB of free hard disk space or higher Windows 98 SE/ME/2000/XP

Basic Operation

PC Software Installation

Install the software before connecting the player to PC.

- The software enables you to save MP3 and other format files into your player.

- For Microsoft Windows 2000, login as Administrator to install the software.

- For Microsoft Windows 2000 user, login as Administrator to install the software.

I 3 Basic Operation I

Basic Operation

PC Software Installation Install software before connecting the player to PC.

Insert the installation CD into the CD-ROM drive. Installation starts automatically.

Select a language for iriver Music Manager and Click "Next" after selecting the language to install.

Basic Operation

PC Software Installation

Click "Next" to install iriver Music Manager.3Select a folder to install iriver Music Manager

and click [OK]. Select the folder to install. Click "Next"

Basic Operation

PC Software Installation

Basic Operation

PC Software Installation

Click “Next” to continue the installation.5Click “Install” to proceed.

Click “Finish” when installation is complete.

I 3 Basic Operation I

Basic Operation

Connecting to the PC

Push the "PUSH OPEN" on the back of your player to disconnect its cap as shown below. Connect the USB port and PC with USB cable.

Basic Operation

Connecting to the PC

"USB CONNECTED" will appear on the LCD screen of the player.

Connect the USB cable to the PC after playback stops to avoid errors.

Basic Operation

Installation of "New Hardware"

After connecting the player to your PC, "Found New Hardware" screen is displayed.

Information screen is displayed on the PC. New hardware is installed successfully and ready to use.

New hardware installation process starts after installing iriver Music Manager program.

Basic Operation

Installation of "New Hardware"

I 3 Basic Operation I

Right-click the "Safely Remove Hardware" icon in the taskbar.

Basic Operation

Safely Removing the Player from the PC

Basic Operation

Safely Removing the Player from the PC

If abnormally removed from PC, the player may be damaged or cause serious malfunction.

Select the device to remove and click “Stop”.

Click the"OK" after confirming the hardware to remove.

Click the "Close" after confirming the Safely Remove Hardware message. (Windows XP)

Basic Operation

Safely Removing the Player from the PC

Basic Operation

Operate the Software

Double click the iriver Music Manager icon. iriver Music Manager version installed is

displayed.

I 3 Basic Operation I

Basic Operation

Operate the Software

Initial iriver Music Manager window.

The right side of iriver Music Manager will display the contents of the your player. If nothing is displayed in the right screen, please be sure that the player is properly connected to the USB cable and to the PC.

It may be necessary to disconnect the player from the cable and reconnect it to activate the right side of iriver Music Manager.

Note ...

Basic Operation - Screen Details

Learning the Basic Function

Basic Operation - Screen Details

Toolbar Menu

1 Wizard 2 Image Viewer 3 Firmware Upgrade 4 File Managing Tools 5 Detail information on

selected music

6 Play the selected music with

Windows OS preferred player

7 Play selected music file.

(Uses system default player). 8 Remaining capacity of the player 9 Turner Setting

10 Format Player 11 iriver Home Page Link

File Transfer Wizard

To transfer files from PC to the player.

File Conversion Wizard

To convert recorded REC files to a format your PC can use.

Audio CD Extracting Wizard

To extract the file with OGG format from Audio CD.

Firmware Upgrade

To upgrade Firmware.

N10 does not support Audio CD Extracting Wizard, Image Viewer, and Tuner Setting functions.

N10 does not support Audio CD Extracting Wizard,

Image Viewer, and Tuner Setting functions.

I 3 Basic Operation I

Basic Operation - Screen Details

File Managing Tools

Searches for file(s) or folder(s) within current window.

Move to Parent Folder

Moves currently selected folder to parent folder.

Refresh

Refreshes information on file(s) or folder(s) within current window.

View

To change how to display the selected folder.

New Folder

Makes a new folder.

Properties

Displays detail information on currently selected file or folder.

Basic Operation - Screen Details

File Menu

New Folder

To make a new folder on the PC or the player.

Delete

To delete the selected folder or files on the PC or the player.

Rename

To rename the selected file or folder on the PC.

Properties

To display detailed information about the folder or file selected.

Exit

To exit the iriver Music Manager.

Basic Operation - Screen Details

View Menu

Basic Operation - Screen Details

Tools

File Transfer Wizard

To transfer files from PC to the player.

File Conversion Wizard

To convert recorded REC files to a format your PC can use.

Upgrade Firmware

To upgrade firmware.

N10 does not support CD Extraction Wizard, Image Viewer, and Turner Setting functions.

I 3 Basic Operation I

Basic Operation - Screen Details

Windows

Align Horizontally

To display the PC and player's windows horizontally.

Align Vertically

To display the PC and player's windows vertically.

Basic Operation - Screen Details

Help

About iriver Music Manager

To confirm the version of Manager.

iriver Music Manager Help

Opens iriver Manager Help.

Firmware Information

To see the information about your player.

iriver Homepage

To connect the iriver homepage.

Basic Operation

Downloading from the PC

Select the folders or files on the PC to transfer to the player. Drag and drop to move folders or files to the desired location on the player.

Basic Operation

Downloading from the PC

Once the music files appear on the right side of iriver Music Manager, they are on your MP3 player.

Files with over 127 characters in the file name will not be transferred.

Files with total path and filename over 512 characters will not be transferred.

The ROOT folder is limited to 1024 files and folders total. Subfolders do not have a limit to the number of files.

Press the / switch to select a mode.

- Navi - MP3 - Voice - Setup

I 3 Basic Operation I

Basic Operation

Press and hold the MENU button.

Press and hold

Press the MENU button to confirm.

- MP3 function is selected.

Basic Operation

Navigation Navigation function allows you to search music.

Navigation

Press and hold the MENU button.

Press and hold

Push the / switc h to select [Navi] and press the MENU button.

Select folder and file.

Press the <+ / - , / > button to move to the folder and file.

+ : To move up. - : To move down.

: To move to the upper folder. : To move to the lower folder.

+ 65 hidden pages
