IRiver Story HD, EB-07 Instruction Manual

3rd IRIVER STORY

STORY HD

USER GUIDE

CONTENTS

01

Getting Started

Components

Locating the Controls

Power Management

Connecting the Product

Using Adobe Digital Editions

02

Using EB07

Home Screen

Viewing Books

Setting

03

04

06

08

11

13

15

19

03

Other Information

Important Safety Information

Troubleshooting

Copyrights

Certification

Registered Trademark

Exemption

21

23

24

35

35

35

Components

Components may be changed without prior notice for improvement of
product performance or quality.

EB07

Quick Start Guide

& Product warranty

USB Cables

Quick Start Guide: Explains how to use our device.
Product Warranty: Please keep this in a safe place for use during any
warranty repairs.
USB Cable: Connects device to the computer and recharges the battery.

Getting Started

03

Locating the Controls

The exterior and the contents printed or engraved may differ by model
or according to the name of each part.

1

2

3

4

EPD

1

SD Card Slot

2

USB Port

3

Power

4

Getting Started

04

It enables readers to feel as if they were
reading a paperback book.

Insert a SD card to view and replay the files
on the card.

Connect to computer or recharge the
battery using this port.

Turn off the power by pressing and holding.
Switch to standby mode by pressing briefly.

1 3 6542

11 12 13 14 15 16 17

7 8

9
10

HOME

1

BACK

2

Previous Page

3

Down

4

Up

5

Next page

6

ENTER

7

OPTION

8

DEL

9

ENTER

10

Shift

11

SYM(Symbol Key)

12

Zoom Out

13

Rotation

14

Space

15

BACK

16

Move

17

Getting Started

05

Move to the home screen.

Move to the previous screen.

Move to the previous page.

Move down in the list.

Move up in the list.

Move to the next page.

Confirm and execute the selected items.

Display Option window.

Delete entered letters and files on the list.

Confirm and execute the selected items.

Enter capital letters or double consonants.

Enter numbers or symbols.

Zoom letters.

Rotate the screen.

Set as Space bar / Favorite.

Move to previous screen.

Move to 4-way direction.

Power Management

Power on/off

1. Slide to the [Power] in the direction of arrow and the power comes on.

2. When the product is on, slide [Power] in the opposite direction of

arrow and the power goes off.

This model supports an automatic power-saving feature to minimize

battery consumption. Depending on [Option - Setting - System - Auto

Power off], the product will be automatically turned off when keys are not

operated for a specified time. (Refer to page 20)

Switching to Sleep Mode

1. If you press the [Power] when the product is on, you can switch to

Sleep Mode.

2. If you press the [Power] again, the Sleep Mode is terminated.

Getting Started

06

Using the Reset Function

1. If the product does not respond to key presses, reset it by pressing

and holding the [Power] for more than 14 seconds.

Even if you use reset function, current time and memory data will be preserved.

To avoid damaging the memory, do not use reset function while the device

is playing.

Charging then Battery Using Your Computer

1. Turn on the computer and connect the product with your computer.

The internal battery will charge automatically.

Replay Time

- Continuous Book Replay Time: Max. 14,000 page view

Do not use cables other than the USB cable provided. It may cause malfunction.

Verify that the product is connected to a high-power USB 2.0 port. Some low-power

USB ports built into certain peripheral devices, such as some types of keyboards

and USB hubs without internal power may not provide enough power to charge.

While the PC is switched to Sleep Mode, the product may not be charged.

Charge and store the product only at room temperature.

Do not expose the device to extremes in temperature while recharging.

The rechargeable battery is a consumable and the available usage time of

charged battery becomes shorter over time.

The battery will be fully charged within about 4.5 hours. (Based on fully

discharged, power Off).

Charging times may vary if device is used during recharge.

If the battery is completely discharged and has not been used for a long time,

power will not come on again until it has been charged for at least ten minutes.

Getting Started

07

Connecting the Product

Connecting to Your Computer

1. Turn on the device and computer.

2. If you connect the device to your computer, you will see the screen

where you can select connection mode.

- Charge Battery: The product is currently being charged.

- Connect Removable Disk: The connection between the product
and the computer is established and you can start transferring data.

Do not use cables other than the USB cable provided. It may cause malfunction.

For successful computer/USB connection, disable all functions.

Check that the product is connected to a high-power USB 2.0 port. Some low-power

USB ports built into certain peripheral devices, such as some types of keyboards

and USB hubs without internal power may not provide enough power to charge.

Disconnecting the Product

1. Safely disconnect the product from your computer by clicking the

icon on the taskbar of the computer screen.

2. Confirm the device disconnection by clicking [Confirm].

Getting Started

08

Depending on the operating system for example Windows XP, the icon may be

hidden from the taskbar. Hidden icons can be displayed by clicking indicator.

Safe disconnection may not be performed if application programs such as

Windows Explorer or Windows Media Player are being used.

Make sure that the product is safely disconnected after all the active

application programs are closed. If safe disconnection fails, try again later.

Failure to safely disconnect result in data loss.

Copying Files (Folders) to the Product

1. After selecting files/folders to copy from your computer, drag and

drop the selected file/folder to the added drive.

2. Files (or folders) will be transferred to folders below according to

their content type.

- E-Book : book - Comic Book : comic

Please connect the USB cable properly.

If the power of the computer or product is turned off or the USB cable is disconnected

while copying or moving files/folders, serious damage to the memory may result.

Transfer rate may differ depending on the computer or OS environment

available for your region.

Getting Started

09

Deleting Files (Folders) from the Product

1. Select the files/folders to be deleted, right-click on them and select

[Delete].

2. Click [Yes] when the [Confirm File/Folder Deletion] window pops up,

and the selected files/folders will be deleted.

Inserting/removing the SD card

1. Open the cover of SD Card slot.

2. Turn the power off, place the SD

card (see the figure below) in the

SD card slot, and press gently.

3. Press it in once more and the

card can be removed.

Getting Started

10

Recommended SD cards

Brand: SanDisk, Transcend

Insert/remove the SD card while the power is off.

Do not force the SD card. It may cause malfunction and damage to the SD card.

Do not remove the SD card when in use. It may delete data, cause

malfunction, or damage the SD card.

Please do not repeatedly insert/remove the SD card.

If the SD card is not positioned properly, the product may malfunction or

the card may become stuck.

Use only the recommended SD cards. The use of other Micro SD cards

may cause malfunction.

The transfer rate of the SD card may differ according to the computer status.

SD cards cannot be formatted using the product. Please format after

connecting the card reader or the product to the computer through UMS.

When formatting a SD card, all the data are deleted. Make sure that the

data is backed up before formatting.

It is recommended that you format a SD card to FAT 32 system.

If a SD card is not recognized or malfunctions, reformat and retry.

SD cards can be purchased separately.

It is recommended that you use a SD card up to 32GB.

Using Adobe Digital Editions

Transfer copyrighted e-book files onto the portable device easily by

using Adobe Digital Editions.

Getting Started

11
