IRIS Alfa L User Manual
User Manual
Iris Alfa L
User Manual
2 Model-iris Alfa L
1- WELCOME............................................................................... 4
1.1. Exciting Feature......................................................................... 4
1.2. Technical Specification .............................................................. 5
2- PHONE LAYOUT ....................................................................... 6
2.1. Keys and Parts ........................................................................... 6
2.2. Icons and Indicators .................................................................. 6
3- GETTING STARTED ................................................................... 7
3.1. Insert SIM Card.......................................................................... 7
3.2. Insert Memory Card .................................................................. 7
3.3. Unlock the Phone ...................................................................... 8
3.4. Using the Touch Screen ............................................................. 9
3.5. Using the Phone’s Buttons....................................................... 10
3.6. Context Menus ........................................................................ 11
3.7. Options Menus........................................................................ 11
3.8. Menu Icons.............................................................................. 12
4- PLACING AND RECEIVING CALLS ............................................ 13
4.1. Make a Call ............................................................................. 13
4.2. Disable Phone Calls (Airplane Mode) ...................................... 13
4.3. Disable SIM Card..................................................................... 14
5- THE HOME SCREEN................................................................ 15
5.1. Open and Close the Launcher.................................................. 16
5.2. Switch to Recently Used Application ....................................... 17
5.3. Customize Home Screen.......................................................... 17
6- MANAGING NOTIFICATIONS .................................................. 19
6.1. Open the Notifications Panel................................................... 19
6.2. Respond to Notifications ......................................................... 20
6.3. Close Notifications Panel......................................................... 20
7- MESSAGING .......................................................................... 21
7.1. Message Environment & Settings............................................ 21
7.2. Using the Onscreen Keyboard ................................................. 22
7.3. Create and Send Multimedia Message.................................... 24
User Manual
Model-iris Alfa L 3
7.4. Operation on a Message ......................................................... 24
7.5. Lock a Message....................................................................... 25
8- MULTIMEDIA......................................................................... 26
8.1. Camera.................................................................................... 26
8.2. Gallery..................................................................................... 26
8.3. Share an album ....................................................................... 27
8.4. Music....................................................................................... 27
8.5. FM Radio................................................................................. 27
8.6. Record Sounds......................................................................... 28
8.7. Make Screenshot..................................................................... 28
9- CONNECT TO NETWORKS AND DEVICES................................. 28
9.1. Transfer Data between Phone and PC..................................... 28
9.2. Use Data Services on Your Phone ............................................ 29
9.3. Connect to Wi-Fi Networks ..................................................... 30
9.4. Pair with Bluetooth Devices..................................................... 30
9.5. Connect to Internet on Your PC via Phone ............................... 31
10- DOWNLOAD APPLICATIONS............................................... 32
11- PHONE SETTINGS .............................................................. 33
12- HEALTH AND SAFETY INFORMATION.................................. 35
LAVA support and contact Information...................................... 38
LAVA warranty certificate.......................................................... 39
User Manual
4 Model-iris Alfa L
1- WELCOME
1.1. Exciting Feature
Congratulations on becoming a proud owner of the
iris Alfa L Android mobile phone. You have now joined the
millions of satisfied customers spread across the Globe.
Your iris Alfa L device offers you these exciting features and
much more:
Android 5.0
5.5 inch Screen
Cameras (front and back)
1.3GHz Quad Core Processor
External Memory (Expandable to 32 GB)
Dual SIM
Multimedia player
GPS
Gravity sensor
Wi-Fi
Bluetooth 4.0
User Manual
Model-iris Alfa L 5
1.2. Technical Specification
GENERAL:
Android 5.0
Dimensions: 152 x 78 x 9.35 mm
3000mAh Li-Pol battery
SCREEN:
5.5 IPS touch screen
540*960 pixels
HARDWARE:
1.2 GHz Quad Core Processor / 8GB RAM
8GB built-in memory
External SD-card slot up to 32GB
8 MP Back Camera + 2MP Front Camera
LED flash
Gravity Sensor
COMMUNICATION:
DUAL SIM
Support GPRS, EDGE networks. GSM850 / 900 /
1800 / 1900MHz. WCDMA 900 / 2100MHz
Support GPS
Bluetooth 4.0
Wi
-Fi 802.11 b/g/n
3.5mm Jack Plug
Micro-USB 2.0
User Manual
6 Model-iris Alfa L
2- PHONE LAYOUT
2.1. Keys and Parts
2.2. Icons and Indicators
Icons Indicators Icons Indicators
Signal strength
indicator
Alarm has been
set
New misses calls
Wi-Fi is activated
USB is connected
Bluetooth is on
The headphone
inserted
Battery charging
symbol
New message
Airplane mode is
activated
User Manual
Model-iris Alfa L 7
3- GETTING STARTED
3.1. Insert SIM Card
The iris alfa L is a Dual SIM mobile phone allowing you
to use the facility of two networks. To insert SIM card(s):
Switch off the mobile phone and remove the rear
cover and battery.
Insert the SIM card correctly in the card slot(s) (See
figure below).
Insert SIM card carefully!
Finally replace the battery and rear cover of the
mobile phone.
3.2. Insert Memory Card
The iris alfa L allows you to expand external memory
with a micro SD card, up to 32GB.
Power off the mobile phone, and then remove the
rear cover and battery.
Insert the memory card into the slot.
User Manual
8 Model-iris Alfa L
Finally replace the battery and rear cover of the
mobile phone.
Use only compatible memory cards approved by with
this device. Incompatible memory cards may damage the
card or the device will corrupt the data stored in the card.
3.3.
Unlock the Phone
You may need to provide PIN, Password, or draw a
pattern to unlock your phone.
To unlock the screen:
Press the power key to wake up the phone.
Hold and drag the unlock icon upwards to unlock.
User Manual
Model-iris Alfa L 9
You may be required to unlock your phone based on
the unlock method in settings.
To set the unlock method:
On the main menu, touch Settings > Security.
Touch Screen lock.
Choose the type of locking as desired. You can set
your screen lock on the basis of Swipe, Voice Unlock,
Pattern, PIN, Password, None.
3.4. Using the Touch Screen
You can use the touch screen in the following ways:
Touch: Acts on items on the screen, such as
application and settings icons, to type letters and
symbols using the onscreen keyboard, or to press
onscreen buttons.
Touch and hold: Touch and hold an item on the
screen until an action occurs.
User Manual
10 Model-iris Alfa L
Drag: Touch and hold an item and move your finger
on the screen until you reach the target position.
Swipe or slide: Quickly slide your finger across the
surface of the screen, (without dragging an item).
For example, slide the screen up or down to scroll a
list.
Double-tap: Tap quickly twice on a webpage, map,
or other screen to zoom. For example, double-tap a
section of a webpage in Browser to zoom that
section to fit the width of the screen. You can also
double-tap to control t zoom, in Maps, and in other
applications.
Pinch: In some applications (Such as Maps, Browser,
and Gallery) you can zoom in and out by placing two
fingers on the screen at once and pinching them
together (to zoom out) or spreading them apart (to
zoom in).
Rotate the screen: On most screens, the orientation
of the screen changes as you rotate it. You can turn
this feature on and off.
3.5. Using the Phone’s Buttons
Button Press
Menu: opens context menu with further options
and actions, content depends directly on
applications.
Home: returns to Home screen. Hold it to access
the list of last used applications.
Back: returns to the previous screen you were
working in, even if it was in a different application.
Can be used to hide the keyboard.
User Manual
Model-iris Alfa L 11
The phone provides you with Context menus and
Options menus for accessing the features in an intuitive
way.
3.6. Context Menus
You can open context menu by touching key.
Not all screens have context menus. If you touch key
inside application that has no context menu, nothing
happens.
Examples of context menu from contacts environment:
3.7. Options Menus
Options menus contain tools that apply to specific
items on the screen. You can open an option by touching
and holding an item on the screen. Not all items have
User Manual
12 Model-iris Alfa L
options menus.
When you touch and hold some items on a screen, an
Options menu opens.
3.8. Menu Icons
Opens the dialer
Opens the contacts list
Opens the main menu
Opens the message
Opens the browser
