IRIS
From the company that introduced the first “tapeless” video recorder in 1994,
IRIS® Digital Video Systems announces its new ATM SiteWatch digital video
recorder. This “edge-recorder” was designed with ATM use in mind.
ATM SiteWatch is perfect for installation inside of ATMs and small facilities because of its compact size.
Both 3 and 4 channel systems are available.
Recorded images are stored internally on a “solid-state storage device” containing no moving parts.
Its chassis is designed to dissipate normal operational heat; its fan-less case ensures quiet operation.
Images are retrieved from the ATM SiteWatch using the proven and powerful IRIS Inquiry software.
Conventional cameras may be recorded after conversion using a single channel analog-to-IP
encoder (available separately.)
This product may also be
used for applications
other than ATMs.
DIGITAL VIDEO SYSTEMS
Key Features
• Standard “SSD” solid-state
storage device. System includes 1GB of RAM.
• Standard system may be programmed for 45 days
for all surveillance images and 90 days for transaction images.
• Storage may be increased even more with a 500GB conventional
“HDD” hard disk drive.
• Through-the-camera-lens ATM lighting compliance monitoring and reporting.
• Patented video image-motion masking.
• IRIS Inquiry software allows remote image retrieval by multiple users simultaneously.
• Embedded operating system (O.S.)
• Meets FBI guidelines for digital video storage devices.
• Fan-less chassis design - quiet operation with no fan noise.
• Compact Size: 2 5/8” H x 9 3/8” W x 5 3/8” D – Weight: 4.4 lbs.
• Operating temperature: -20º ~ 60ºC (SSD), 0º ~ 45ºC (HDD)
• Relative Humidity: 95% @ 40ºC
• Two-year product depot warranty.
Includes system-specific Uninterruptible Smart Power Supply (UPS) to ensure
system integrity during a power loss or power fluctuation.
10750 Forest Lane
Dallas, Texas 75243
888.451.4646 • F 214.349.9429
www.iris-dvs.com
IRIS products are
endorsed by leading
associations throughout
the United States!
At less than 10” long,
the compact-size of
the ATM SiteWatch
is perfect for “in-ATM”
installations.
Example ATM SiteWatch Configuration with I.P. and Analog Cameras
I.P. Camera
Customer’s
Network
Analog Cameras
Analog to Digital Converters
Up to 4 cameras (3 camera configuration represented)
Camera connections to Smart Power Supply not shown on diagram.
ATM SiteWatch
and Camera
Smart Power Supply
Note: As shown, camera types may be combined within each ATM SiteWatch system.
Ordering Information (Contact IRIS or your dealer for a complete product listing.)
Part Number Product Remarks
7010-80 ATM SiteWatch Digital Video Recorder 80GB SSD-recommended for 1 camera systems
7010-160 ATM SiteWatch Digital Video Recorder 160GB SSD-recommended for 2-3 camera systems
7010-500 ATM SiteWatch Digital Video Recorder 500GB HDD-for increased storage
7010-K1 ATM SiteWatch Kit - One I.P. Camera Includes one IRIS I.P. Camera (7100-01)
7010-K2 ATM SiteWatch Kit - Two I. P. Cameras Includes two IRIS I.P. Cameras (7100-01)
7010-K3 ATM SiteWatch Kit - Three I.P. Cameras Includes three IRIS I.P. Cameras (7100-01)
7010-160EX ATM SiteWatchEX Digital Video Recorder 160GB SSD-4 camera system
7010-55 ATM SiteWatchEX Storage Expansion 500GB HDD-for increased storage
ATM SiteWatch
7010-K4 ATM SiteWatchEX Kit - Four I.P. Cameras Includes four IRIS I.P. Cameras (7100-01)
7100-01 IRIS ATM I.P. Camera 12VDC
7910-01 IRIS Analog-to-Digital Video Signal Converter For use with standard analog cameras
Two-year product depot warranty provided by IRIS.
© February 2015 – IRIS Digital Video Systems, Dallas, Texas. All rights reserved. IRIS is a registered trademark of The Security Center, Inc.
Any other trademarks presented remain the property of their respective owners. IRIS products, including software and hardware,
are protected by one or more of the following U.S. Patents: #D524,834; and others pending. In the interest of
constant product improvement, features and options may change without notice.
ATM SW 04015-2.5K
