Involight SBL2000 User Manual [ru]

DMX LED Octo-par system, 8*3*Tri-3W
There are six working modes: build-in programs, auto running, DMX mode, slave mode, sound activity, and static color mode. Press “mode” to choose working mode, enter each working mode, press “setup” to setup of this mode. “Up” or “down” to adjust the Corresponding parameters.
A. SPECIFICATION
1. Weight: 9.1(includes footswitch)
3. Voltage: 100~240VAC
4. Power consumption: 90W
5. LEDs: 24*Tri-3W
6. Beam angle: 25 degree
7. Auto running, built-in programs, DMX, slave mode, sound active and foot switch
8. DMX channel: 7CH, 26CH
9. LED display for easier operation
10. Very compact design with such a high power consumption
11. Very good for bands, home party, bar, disco, club, KTV…
12. Rich dynamic chasing effects to achieve amazing body shadow effects
13. T-Bar, carrying bag, foot switch, stand combined as a complete set
14. Inner box: 105*38*18cm
15. Master carton: 107*40*38cm
16. 2 pcs/ctn
B. OPERATION
1. Build-in programs
Press “MODE”, when the LED display: Prxx, then it is build-in programs, press UP” or “DOWN” to choose 22
Pr01Pr22effects in the build-in programsPr01—Pr22 When it is pr02-pr22,first time to press “SETUP” to enter the choose which can control the speed of each mode, second
time to press the “SETUP” can choose the strobe(FSxxspeed. When it is Pr01, press “enter” to setup 7 build-in single color, second time to press the “SETUP” to choose the single color
strobe speed.
2. Auto running mode
Press MODE”, when the LEDs display: AUTO, it is auto running mode, press the “SETUP” to enter the menu of running time, speed, strobe speed. Then press “UP” or “DOWN” to adjust the corresponding parameters.
3. DMX mode
There are two kinds of DMX modes, channel: 7CH, 26CH Press “MODE”, when the LEDs display: d.xxx, then it is the DMX mode, press the “UP” or “DOWN” to set up the address of the DMX, then press the “SETUP”, it will show: x-ch , press the “UP” or “DOWN” to choose the mode:7-ch/26ch.when there is no DMX signal,chwill strobe for each one second, when received DMX signal, it will stop strobe and keep lighting .
DMX two modes’ deal like below
DMX mode17-ch
CH1
CH2
CH3
CH4
CH5
CH6
CH7
Master
dimmer
R G B
NO.
DMX
value
FUNCTION
SPEED
Strobe
0255
dimming
(0 =
OFF)
0255
dimming
0=OFF
0255
dimming
0=OFF
0255
dimming
0=OFF
1
07
OFF
NO USE
NO USE
2
815
red
SPEED 0255
0-9 no
use
10-255
Strobe
3
1623
Yellow
4
2431
Green
5
3239
Cyan
6
4047
Blue
7
4855
Purple
8
5663
White
9
6471
PROGRAM01
10
7279
PROGRAM02
11
80--87
PROGRAM03
12
8895
PROGRAM04
13
96103
PROGRAM05
14
104111
PROGRAM06
15
112119
PROGRAM07
16
120127
PROGRAM08
17
128135
PROGRAM09
18
136143
PROGRAM10
19
144151
PROGRAM11
20
152159
PROGRAM12
21
160167
PROGRAM13
22
168175
PROGRAM14
23
176183
PROGRAM15
24
184191
PROGRAM16
25
192199
PROGRAM17
26
200207
PROGRAM18
27
208215
PROGRAM19
28
216223
PROGRAM20
29
224231
PROGRAM21
30
232--255
Sound Mode
Sensitivity
0--255
CH1
CH2
CH3
CH4
CH5
CH6
CH7
CH8
CH9
Master
dimmer
R G B R G B R
G
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
dimming
025
dimming
0255
dimming
0255
dimming
0255
dimming
CH10
CH11
CH12
CH13
CH14
CH15
CH16
CH17
CH18 B R G B R G B R
G
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
dimming
DMX mode226ch
CH19
CH20
CH21
CH22
CH23
CH24
CH25
CH26 B R G B R G B
strobe
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
dimming
0255
Dimming
0-9
no use
10-255
Strobe
4. Slave mode
Press the “MODE”, when the LED display showSLAu, then it is the slave mode. Under this mode, the slave fixture will follow the master’s fixture running which connecting through DMX signal at the same time. Under this mode, there is only
one master in the whole line.
5. Sound active mode
Press the “MODE”, when the LED display showSUXX, then it is the sound activity mode, press the UP” or “DOWN” to adjust the sound activity’s sensitivity SU00—SU31
Press the “SETUP” to setup the sound activity’s speed, you can choose the speed “SP01~SP10” which you prefer. When it
is “SP01”, the sound effect fit for light music, the sound activity rhythm is the slowest. When it is “SP10”, the sound activity rhythm is the fastest, speed is the fastest, and it is fit for fast DJ music.
6. Static color mode
Press the “MODE”, when the LED display show::Colr, then it is static color mode, press the “SETUP”, it will shows r255 g255, b255, press “UP” or “DOWN” to adjust the RGB brightness value .
7. Footswitch control
1) Blackout
When you step on blackout button, it will turn off the fixture; Step this button again, restore the last operation mode.
2) Sound Controlled
When you step on sound button, it will enter into the sound active mode.
3) Program
When you step on program button, the fixture will enter into built-in programs mode, step this button again to change programs segment.
4) Color
When you step the color button, it will enter into static color mode, step this button to change static colors.
Remarks: The LED display will turn off if you don’t press any buttons within 20 seconds. If press any button at this time, the LED display will recover the situation before the turn off. Then every button will recover their function.
а
ООО «ИНВАСК»
Адрес: 143406, Московская область, Красногорск, ул. Ленина, дом 3-Б
Тел. (495) 565-0161 (многоканальный)
Факс (495) 565-0161, доб. 105
http://www.invask.ru e-mail: invask@invask.ru
Сервис-центр «ИНВАСК»
Адрес: 143400, Московская область, Красногорск, Коммунальный квартал,
дом. 20
Тел. (495) 563-8420, (495) 564-5228
e-mail: service@invask.ru
