PN2A-128-8TB
InVid PN2A-128-8TB, PN2A-128, PN2A-128-80TB, PN2A-128-6TB, PN2A-128-48TB Specsheet
...
PN2A-128
128 Ch NVR, 512 Mbps, 16 HD Bays, 4K
Features
• Up to 8 Megapixel Resolution Recording
• 512 Mbs Bit Rate Input
• Dual Gigabit Network Interfaces
• Supports up to 16 channel simultaneous playback
• Works with ONVIF or other supported IP cameras
• Local HDMI main monitor output with 4K Support
• Local VGA main monitor output up to 1080p
• True P2P Connectivity with QR Code Connect
• Multiple video search options including Thumbnail
Search for quick retrieval of footage.
• H.265/H.264 video compression
• Free iOS & Android Apps for Smart Phones & Tablets
• Free Central Management Software (CMS) to manage
multiple units & sites from a single platform
• Free MAC client software to easily manage your system
from your Apple computer
Ordering Information
PN2A-128/2TB: 128 Ch NVR, 2 TB
Also available with: 4, 8, 16, 24, 32, 64, 128 TB
InVid Tech, reserves the right to make changes to improve our products at any time without notice; we are not responsible for misprints.
Model PN2A-128
System
Compression Standard H.265 / H.264
OS Embedded Linux
Video
Network Input 128 CH IPC input
Network Access Bandwidth
Network Access Format 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P@25 / 30fps
Output HDMI × 2 : 4K × 2K / 1920 × 1080 / 1280 × 1024, 1920 × 1080
Audio
Network Input 128 CH IPC audio input
2-way Audio RCA × 1
Local Output RCA × 1
Record
Record Stream Three-stream recording
Resolution 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
Mode Manual, timer, motion, sensor
Playback
Simultaneous Playback Max 16 CH
Search Time slice / time / event / tag search
Smart Search Highlighted color to display the camera record in a certain
Function Play, pause, FF, FB, digital zoom, etc.
Alarm
Mode Manual, sensor, motion, exception
Input 8 CH local alarm input, 128 CH IPC alarm input
Output 4 CH
Triggering Record, snap, preset, e-mail, etc.
Network
Interface RJ45 10 / 100 / 1000 Mbps × 2
Protocol TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Web Client Max 20 users online
Mobile Device
OS iOS, Andriod
Storage
HDD SATA × 16 ( support HDD hot swapping ), E-SATA × 1 ( sup-
Backup
Local Backup U disk, USB mobile HDD
Network Backup Yes
Port
USB USB 3.0 × 1 ( rear panel ), USB 2.0 × 2 ( front panel )
Other
Power Supply ATX
Consumption ≤ 30W ( without HDD )
Dimensions (mm) 437 × 483 × 143 ( W × D × H )
Work Environment -10 ～ 50 ℃～10% ～ 90% humidity
512Mbps
/ 1280 × 1024
VGA × 1 : 1920 × 1080 / 1280 × 1024
period of time, dierent colors refers to dierent record
events
port external storage )
Innovative Video Technology 355 Oser Avenue, Hauppauge, NY 11788 | 631-388-5700 | sales@invidtech.com | www.invidtech.com
