Invacare R2 jr, Ranger II, Excel User Manual

Download

Parts Catalog

Issued: May 27, 2008

Storm Series®

Ranger II™

Excel™

R2™ jr.

FWD

Powered Wheelchairs

Yes, you can. ™

Throughout this catalog you will notice letters to draw your attention to specific footnotes which are located at the bottom of the page or below specified charts.

Parts Catalog Usage Guide

To order call toll free 1-800-333-6900, or www.invacare.com

The information contained in this document is subject to change without notice. This catalog contains service parts for Form No. 98-289. If you have any questions regarding this catalog, please contact one of our Customer Service Representatives.

For Customer Service Support Call:

1-800-333-6900

For Faxed In Orders Call:

1-800-678-4682 or

1-440-366-0709

For Technical Service Call:

1-800-832-4707

Literature Can Be Found at:

www.invacare.com or

1-800-828-6272

SYMBOL DEFINITION

Examples:

A,B,C etc. NOTE: NLA

= Special Comments = General information pertaining to that specific page = No Longer Available

HARDWARE MEASUREMENTS

The measurements for the hardware will be listed as follows:

Screws, Bolts Washers Spacers

For your convenience, we have supplied an area for you to list your Invacare Representatives.

Corporation. Dynamic is a registered trademark of Dynamic Controls Limited. Tash is a registered trademark of Tash International Inc.. Therafin is a

Bussman is a registered trademark of Cooper Industries. MIDI is a registered trademark of Littelfuse Inc. Dynamic is a registered trademark of Dynamic

Diameter X Thread Count/Pitch X Length Inside Diameter X Outside Diameter X Thickness Inside Diameter X Outside Diameter X Length

Name Phone Numbers

registered trademark of W/R/ Medical Electronics Co..

Controls Limited.

Form No.

98-289

TABLE of CONTENTS

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

98-289

Description

Accessories - Power Wheelchair Tool Kit ................................................................................ 145

Accessories, Oxygen Holder Assembly Kit After 4/14/03 - Captain Seat ................................. 39

Accessories, Oxygen Holder Assembly Kit Before 4/15/03 - Captain Seat .............................. 37

Arms - Captain Seat and Hardware ......................................................................................... 43

Arms - Excel ............................................................................................................................ 48

Arms - Ranger II / R2 jr. ........................................................................................................... 45

Back Canes and Attaching Hardware - Sling Seat Only .......................................................... 20

Battery Boxes and Trays .......................................................................................................... 59

Battery Boxes and Trays - R2 jr. (14" Wide) ............................................................................ 61

Battery Chargers and Harness - R2 jr. (14" Wide) ................................................................... 65

Battery Chargers and Harnesses ............................................................................................. 63

Captain Seat Assembly After 8/31/02 ...................................................................................... 31

Captain Seat Assembly Before 9/1/02 ..................................................................................... 28

Captain Seat Frame and Actuator Hardware After 8/31/02 ...................................................... 35

Captain Seat Frame and Actuator Hardware Before 9/1/02 ..................................................... 33

Caster and Forks, Rear ............................................................................................................ 50

Crossbraces and Hardware - Captain Seat .............................................................................. 18

Crossbraces, Seat Extensions and Hardware - R2 jr. .............................................................. 16

Crossbraces, Seat Extensions and Hardware - Sling Seat ...................................................... 14

Drive Wheel (12-1/2 x 2-1/4"), 2-Pole Motor and Gearbox (Ranger II Basic, Excel and R2 jr.)

Drive Wheel (12-1/2 x 2-1/4"), 4-Pole Motor and Gearbox (Ranger II Standard) ..................... 54

TABLE of CONTENTS

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

98-289

Description

Drive Wheel (14 x 3") and Hub Mount ..................................................................................... 57

Electronics - COM12 and COM34 ............................................................................................ 136

Electronics - MKIV Controller, Programmer and Attaching Hardware ...................................... 133

Electronics - MKIV Displays ..................................................................................................... 138

Electronics - MKIV Joystick Mounting Hardware and Joystick Accessories ............................ 121

Electronics - MKIV Joystick Options ......................................................................................... 140

Electronics - MKIV Joysticks - Excel, RII, RX, A, A+, TCHJOY ............................................... 116

Electronics - MKIV Joysticks - PSF and PSR ........................................................................... 119

Electronics - MKIV Mid-Line Swing Bracket Assembly ............................................................ 125

Electronics - MKIV Recliner Control and Recliner Cable ......................................................... 137

Electronics - MKIV Sip-N-Puff/Digital Interface ........................................................................ 135

Electronics - MKIV Swivel Joystick Hardware .......................................................................... 123

Electronics - Quad Link Assembly (Before 4/07/06) ................................................................. 127

Electronics - Quad Link Assembly (QL) (After 4/06/06) ........................................................... 130

Electronics - Tash and Therafin Accessories ........................................................................... 143

Frame Finishes, Touch-Up Paint and Upholstery Options ....................................................... 6

Front Rigging - Adjustable Flip-Up Removable Footboard (After 2/29/00) ............................... 109

Front Rigging - Adjustable Flip-Up Removable Footboard (Before 3/1/00) .............................. 106

Front Rigging - Calf Pads and Attaching Hardware ................................................................. 96

Front Rigging - Footrest and Legrest Accessories ................................................................... 112

Front Rigging - Footrest Supports - P93M ............................................................................... 88

TABLE of CONTENTS

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

98-289

Description

Front Rigging - Footrest Supports - PW93 ............................................................................... 82

Front Rigging - Footrest Supports - PW93E ............................................................................. 84

Front Rigging - Footrest Supports - PW93ST .......................................................................... 86

Front Rigging - Legrest Release Handle and Ratchet .............................................................. 94

Front Rigging - Legrest Supports - P904A ............................................................................... 90

Front Rigging - Legrest Supports, Articulating PAS4A/PAL4A ................................................. 92

Front Rigging - Pivot/ Slide Tube and Footplate - PW93ST .................................................... 100

Front Rigging - Pivot/ Slide Tube and Footplate - P904, PAL4A, PAS4A ................................ 104

Front Rigging - Pivot/ Slide Tube and Footplate - P93M .......................................................... 102

Front Rigging - Pivot/ Slide Tube and Footplate - PW93, PW93E ........................................... 98

Front Rigging - Reference Chart .............................................................................................. 79

Headrest and Attaching Hardware - Sling Seat Only ............................................................... 21

Oxygen Holder Assembly Kit - Sling Seats Only ...................................................................... 41

Packaging, Literature and Decals - Sling Seat with Shrouds and Captain Seat ...................... 10

Packaging, Literature, and Decals - Sling Seat without Shrouds ............................................. 8

Shroud Covers - After 2/29/00 .................................................................................................. 71

Shroud Covers - Before 3/1/00 ................................................................................................. 67

Shroud Covers R2 jr. - After 2/29/00 ....................................................................................... 77

Shroud Covers R2 jr. - Before 3/1/00 ...................................................................................... 75

Side Frames and Hardware ..................................................................................................... 12

Solid Folding Seats and Inserts ................................................................................................ 26

TABLE of CONTENTS

Page

Number

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

98-289

Description

Upholstery, Carrying Pocket and Seat/Chest Positioning Straps ............................................. 23

Frame Finishes and Touch-Up Paint

Color

Number

Part

Number

Bottle

Size

Color

Pink Pearl.6 oz.103145202P

Super Teal.6 oz.103145406P

Deep Purple.6 oz.103145608P

Cobalt Blue.6 oz.104631917P

Anthracite.6 oz.103337622P Wet Black.6 oz.103145024P

White.6 oz.103144729P

Sunny Yellow.6 oz.103144830P

Red.6 oz.103145533P

Flat Black.6 oz.104632734P

Electric Red.6 oz.104632161P Electric Blue.6 oz.104632062P Metallic Blue.6 oz.104632464P Teflon Black.6 oz.1101320-NLA69P

Silver VeinN/AN/A71P

Evergreen with Navy.6 oz.107389280P

Dark Olive with Copper.6 oz.107389381P

Fruit Punch with Fucshia.6 oz.107389482P

Royal Blue with Grape.6 oz.107389583P

Lavender.6 oz.107389684P

Jeweled Green.6 oz.1101325101P

Denim Blue.6 oz.1101327102P Mocha Frost.6 oz.1101324103P Electric Teal.6 oz.1101316104P

Midnight Blue.6 oz.1101326105P

Frame Finishes, Touch-Up Paint and Upholstery Options

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Frame Finishes, Touch-Up Paint and Upholstery Options

Sparkle Frame Finishes

Color Number Color

Twilight Sparkle72P

Gold Sparkle73P

Green Sparkle74P

Blue Sparkle75P

Red Sparkle76P

Wet Black with Twilight Sparkle88P

Upholstery Options

Vinyl Colors Nylon Colors

U240 BlackU67 Black

U75 Dove Grey

U85 Dark Blue

U86 Ruby

U97 Sky Blue

U88 Camel

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Packaging, Literature and Decals

Sling Seat without Shrouds

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Packaging, Literature and Decals

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

40131X148 Carton, Hardware 1 11

1074356-NLA Insert, Carton 1 12

1023167 Carton, Battery Boxes 1 13

1074355-NLA Carton 1 14

40131X011 Carton, Front Riggings 1 15

1058833 Carton 1 16

1015592 Bag, Poly (72" L x 35" W x 19" D) 1 17 1043198-NLA Tube, Paper 1 18 1080739-NLA Insert, Carton 1 19

1090146 Decal, Invacare 3-D Logo (1-19/32" L) 1 210 A

1095224 Decal, Model, Ranger II (Black) 1 211 A,B

1095225 Decal, Model, Ranger II (White) 1 211 A

1095232 Decal, Model, Excel (Black) 1 211 A,B

1095233 Decal, Model, Excel (White) 1 211 A

1090273 Decal, Model, R2 jr. 1 211

1080267 Decal, Warning Motor 1 212

1080266 Decal, Warning Controller 1 113

40131X039 Insert 1 114 D 1097104-NLA Decal, 250-S 1 215 1080265-NLA Decal, FWD 1 2C 1065145-NLA Decal, Virtual Service 1 2C

1035900 Decal, Transportation 1 1C 1119281 Name Plate, Patent Numbers 1 1C 1095272 Manual, Instruction MKIV RII 1 1C 1080722 Owner's Manual - Ranger II and R2 jr. 1 1C 1080737 Owner's Manual - P9000 and Excel 1 1C

A - Invacare logo added and model decals changed 1/11/00. When replacing side frames before 1/11/00 order decals in pairs

to match.

B - Used for chairs with frame colors 02P, 29P, 30P, and 84P only.

C - Not Shown

D - R2 jr.

NOTE:

When adjusting or replacing parts, please refer to the Owner's Manual for assistance.

NOTE:

Sling Seat without Shrouds

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Packaging, Literature and Decals

Sling Seat with Shrouds and Captain Seat

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Packaging, Literature and Decals

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1030364 Carton, Cover 1 11 D 1031682 Carton, Cover 1 11 C

1043198-NLA Tube, Paper 1 12

40131X161 Insert, Plain Pad 1 13

See Note See Footnote -- --4 E

1030362 Carton, Tray 1 15 1015592 Bag, Poly (72" L x 35" W x 19" D) 1 16 1095225 Decal, Model, Ranger II (White) 1 27 A 1095233 Decal, Model, Excel (White) 1 27 A 1090273 Decal, Model, R2 jr. 1 27 1095489 Decal, Invacare 3-D Logo (2-1/2" L) 1 28 A

1076575-NLA Decal, Caution, Limit Switch 1 19 C

1080267 Decal, Warning Motor 1 210

1080266 Decal, Warning Controller 1 111 1097104-NLA Decal, 250-S 1 212 1080265-NLA Decal, FWD 1 2B 1065145-NLA Decal, Virtual Service 1 2B

1035900 Decal, Transportation 1 1B

1119281 Name Plate, Patent Numbers 1 1B

1095272 Manual, Instruction MKIV RII 1 1B

1080722 Owner's Manual - Ranger II and R2 jr. 1 1B

1080737 Owner's Manual - P9000 and Excel 1 1B

1085398 Service Manual - Ranger II & R2 jr. 1 1B

1085397 Service Manual - Excel 1 1B

A - Invacare logo added and model decals changed 1/11/00. When replacing shrouds before 1/11/00 order decals in pairs to

match.

B - Not Shown.

C - Used on High Back Captain Seats Only.

D - Sling Seat and Low Back Captain Seat.

E - Wooden skid is not provided.

NOTE:

When adjusting or replacing parts, please refer to your Owner's Manual for assistance.

NOTE:

Sling Seat with Shrouds and Captain Seat

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Side Frames and Hardware

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Side Frames and Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

8881080260 Side Frame with Hardware, Right 1 21 A,B,C 8881080261 Side Frame with Hardware, Left 1 21 A,B,C 8881080734 Side Frame with Hardware, Right 1 21 A,B,D 8881080735 Side Frame with Hardware, Left 1 21 A,B,D 8881085258 Side Frame with Hardware, Right 1 21 A,B,E 8881085259 Side Frame with Hardware, Left 1 21 A,B,E

1090768 Kit, Lock Handle w/Rivets (both LT & RT side) 2 12

47471X074 Spring, Arm Lock 1 23

1028594 Pin, Arm Lock 1 24

40117X006 Bearing (5/8") 1 45

1029501 Plug Button, Black (1") 1 26

1085124 Screw, Socket Flat Head (#10-32 x 1-3/4") 1 47

1007541 Seat Guide 1 48

7930304 Screw, Socket Head (1/4-20 x 1-1/4") 25 19

1060099 Front Rigging Hanger - Right 1 210

1060100 Front Rigging Hanger - Left 1 210

1027097 Plug Button, Black (3/4") 1 211

1025731 Locknut (#10-32) 1 312

7930333 Locknut (1/4-20) 25 113

1068039 Pin, Pull 1 214

1085134 Screw, Socket Flat Head C'Sunk (#10-32 x 1-5/8") 1 215

A - Specify frame color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

B - Decals not included with frames. See page titled, "Packaging, Literature and Decals."

C - Ranger II.

D - Excel.

E - Captain Seat.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Crossbraces, Seat Extensions and Hardware

Sling Seat

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Crossbraces, Seat Extensions and Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1080244 Crossbrace Assembly, 16" Wide, Right 1 21 A

1080245 Crossbrace Assembly, 16" Wide, Left 1 21 A

1080246 Crossbrace Assembly, 18" Wide, Right 1 21 A

1080247 Crossbrace Assembly, 18" Wide, Left 1 21 A

1080248 Crossbrace Assembly, 20" Wide, Right 1 21 A

1080249 Crossbrace Assembly, 20" Wide, Left 1 21 A

1028835 Cap, Hub (Black) 1 42

7930363 Package, Locknut (5/16"-24) 25 13

1028491 Washer, Caplugs (11/32" I.D. x 1" O.D.) 1 44

1056708 Plug, Pivot Tube 1 45

1038179 Screw, Hex Head (5/16-24 x 4-1/4") 1 26

1057830 Hardware, Crossbrace Pivot Tube 2 12-6 B,C

1024793 Screw, Hex Head (1/4-20 x 1-3/4") 1 27

7930333 Locknut (1/4-20) 25 18

1057382 Pivot Link, 16-18" Wide - Hemi 1 29

1057383 Pivot Link, 19-20" Wide - Hemi 1 29

1030949 Screw, Hex Head (1/4-20 x 1-1/2") 1 210

1057828 Strap, Pivot Link 1 211

7930323 Package, Locknut (1/4-20) 25 112

1029501 Plug Button, Black (1") 1 413

1025705 Screw, Hex Head (5/16-24 x 3-1/4") 1 114

1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 215

1016263 Spacer, Coved (3/4 x 1 x 1/2") 1 416

7930313 Washer, Nylon (5/16 x 7/8 x 1/8") 25 117

7930330 Locknut (5/16-24) 25 118

1086180 Hardware, Crossbrace Center Bolt Attaching 1 119 D

1035900 Decal, Transportation 1 120

1119281 Name Plate, Patent Numbers 1 121

1080728 Hardware, Crossbrace 1 122 F,G

1058616 Seat Extension Kit - 1" (Pair) 2 123 H

1058617 Seat Extension Kit - 2" (Pair) 2 123 I

1026298 Screws with Washers (#10 x 7/8") 2 124

1076284 Screw w/ washer (#10 x 7/8") 1 224

40163X003 Screw, Phillips Pan Head (#10 X 5/8") 1 224 E

A - Decals not included with frames. See page titled, "Packaging, Literature and Decals."

B - Not Shown.

C - Includes Items 2-6.

D - Includes items 14-18.

E - Solid Folding Seats Only.

F - Less items 1-9.

G - Includes items 2-8, 10-18, 20 and 21.

H - For 17" Depth.

I - For 18" Depth.

NOTE:

Sling Seat

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Crossbraces, Seat Extensions and Hardware

R2 jr. - 14" Wide - Sling Seat

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Crossbraces, Seat Extensions and Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1080253 Crossbrace Assembly, 14" Wide, Right 1 21 A

1080254 Crossbrace Assembly, 14" Wide, Left 1 21 A

1028835 Cap, Hub (Black) 1 42

7930363 Package, Locknut (5/16"-24) 25 13

1028491 Washer, Caplugs (11/32" I.D. x 1" O.D.) 1 44

1056708 Plug, Pivot Tube 1 45

1038179 Screw, Hex Head (5/16-24 x 4-1/4") 1 26

1057830 Hardware, Crossbrace Pivot Tube 2 12-6 B,E

1024793 Screw, Hex Head (1/4-20 x 1-3/4") 1 27

7930333 Locknut (1/4-20) 25 18

1057381 Pivot Link, 14-15" Wide - Hemi 1 29

1030949 Screw, Hex Head (1/4-20 x 1-1/2") 1 210

1057828 Strap, Pivot Link 1 211

7930323 Package, Locknut (1/4-20) 25 112

1029501 Plug Button, Black (1") 1 413

1025705 Screw, Hex Head (5/16-24 x 3-1/4") 1 114

1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 115

1016263 Spacer, Coved (3/4 x 1 x 1/2") 1 416

7930313 Washer, Nylon (5/16 x 7/8 x 1/8") 25 117

7930330 Locknut (5/16-24) 25 118

1086180 Hardware, Crossbrace Center Bolt Attaching 1 119 C

1086176 Bracket, Wire Connector Support 1 120

1035900 Decal, Transportation 1 121

1119281 Name Plate, Patent Numbers 1 122 1086177-NLA Crossbrace Hardware 1 123 D

1058616 Seat Extension Kit - 1" (Pair) 2 124 F

1058617 Seat Extension Kit - 2" (Pair) 2 124 G

1026298 Screws with Washers (#10 x 7/8") 2 125

1076284 Screw w/ washer (#10 x 7/8") 1 225

A - Decals not included with frames. See page titled, "Packaging, Literature and Decals."

B - Not Shown.

C - Includes Items 14-18.

D - Includes Items 2-8, 10-18, 20-22, Less Items 1 and 9.

E - Includes Items 2-6.

F - For 17" Depth.

G - For 18" Depth.

NOTE:

R2 jr. - 14" Wide - Sling Seat

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Crossbraces and Hardware

Captain Seat

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Crossbraces and Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1086798 Crossbrace, Captain Seat (18" Wide), Right 1 21 A

1086799 Crossbrace, Captain Seat (18" Wide), Left 1 21 A

7930323 Package, Locknut (1/4-20) 25 12

1057828 Strap, Pivot Link 1 23

1030949 Screw, Hex Head (1/4-20 x 1-1/2") 1 24

1026900 Washer (1/4 x 23/32 x 1/16") 1 25

1026154 Screw, Hex Head (1/4-20 x 2-1/4") 1 16

1024793 Screw, Hex Head (1/4-20 x 1-3/4") 1 27

1071604 Bumper, Nylon 1 48

1057382 Pivot Link, 16-18" Wide - Hemi 1 29

1031884 Bushing (9/32 x 3/8 x 11/32")

Black or Color Chairs

1 210

1071602 Pin, Anchor (Captain Seat) 1 411

1074142 Decal, Crossbrace 1 212

1086800 Bracket, Black Push 1 213 A

7930333 Locknut (1/4-20) 25 114

1024796 Screw, Hex Head (1/4-20 x 2") 1 115

1028835 Cap, Hub (Black) 1 416

7930363 Package, Locknut (5/16"-24) 25 117

1028491 Washer, Caplugs (11/32" I.D. x 1" O.D.) 1 418

1056708 Plug, Pivot Tube 1 419

1038179 Screw, Hex Head (5/16-24 x 4-1/4") 1 220

1057830 Hardware, Crossbrace Pivot Tube 2 116-20 B,C

1029501 Plug Button, Black (1") 1 221

1025705 Screw, Hex Head (5/16-24 x 3-1/4") 1 122

1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 223

1016263 Spacer, Coved (3/4 x 1 x 1/2") 1 424

7930313 Washer, Nylon (5/16 x 7/8 x 1/8") 25 125

7930330 Locknut (5/16-24) 25 126

1035900 Decal, Transportation 1 127

1119281 Name Plate, Patent Numbers 1 128

1086180 Hardware, Crossbrace Center Bolt Attaching 1 129 D

1082683 Hardware, Crossbrace 1 130 E

A - Decals not included with frames. See page titled, "Packaging, Literature and Decals."

B - Not Shown.

C - Includes Items 16-20.

D - Includes Items 22-26.

E - Includes Items 2-8 and 10-28. Less items 1 and 9.

NOTE:

Captain Seat

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1028372 Back Cane Assembly - 10 Degree Bend 1 21

1006229 Grip, Foam (8") 1 22 1071565-NLA Tube, Rear Upright, Black 1 23

1026907 Washer (1/4 x 1/2 x 1/16") 1 44

1057955 Screw, Hex Head (1/4-20 x 1-1/4") 1 45

7930323 Package, Locknut (1/4-20) 25 16

1055348 Screw, Hex Head (1/4-28 x 1-3/4") 1 47

1026900 Washer (1/4 x 23/32 x 1/16") 1 88

7930345 Locknut (1/4-28) 25 19 1071488-NLA Insert, Threaded 1 210

1079389 Hardware, Back Cane Mounting, Ranger II (Pair) 2 111 A

1057956 Hardware, Back Cane Mounting, Excel (Pair) 2 111 B

A - Includes items 3-10.

B - Includes Items 4-6.

NOTE:

Back Canes and Attaching Hardware

Sling Seat Only

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Headrest and Attaching Hardware

Sling Seat Only

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Headrest and Attaching Hardware

Item #1 Headrest Upholstery

Width Nylon Vinyl

8881054633

888105258614" W

See Note(s) A

8881054638

888105258816" W

See Note(s) A

8881054637

888105259018" W

See Note(s) A

8881054639

888105259220" W

See Note(s) A

A - Specify upholstery color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options." NOTE:

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

See Chart Item #1 Headrest Upholstery 1 11

1027095 Plug Button, Black (7/8") 1 22

1054605 Tube, Headrest Extension 1 23

1028756 Tube, Insert 1 24

1028752 Bracket, Headrest, Right 1 25

1028753 Bracket, Headrest, Left 1 25

1028484 Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 26

1076284 Screw w/ washer (#10 x 7/8") 1 47

Sling Seat Only

To order call toll free 1-800-333-6900, or www.invacare.com

Form No.

98-289

Seat/Chest Positioning Straps

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1034625. 0 1 1A 1034752 Positioning Strap, Seat/Chest w/ Airline Style Buckle

(Eyelet to Eyelet Length 61")

1 1B

1034753 Positioning Strap, Seat/Chest w/Airline Style Buckle

(Eyelet to Eyelet Length 70")

1 1C

1004310 Positioning Strap, Seat/Chest w/ Auto Style Push

Button Buckle (Eyelet to Eyelet Length 48")

1 1A

1034625 Positioning Strap, Seat/Chest w/ Auto Style Push

Button Buckle (Eyelet to Eyelet Length 61")

1 1B

1034622 Positioning Strap, Seat/Chest w/ Auto Style Push

Button Buckle (Eyelet to Eyelet Length 69")

1 1C

1034744 Positioning Strap, Seat/Chest w/ Hook and Loop

Style Buckle (Eyelet to Eyelet Length 45")

1 1A

1034745 Positioning Strap, Seat/Chest w/ Hook and Loop

Style Buckle (Eyelet to Eyelet Length 61")

1 1B

A - 14-18" Wide Chairs.

B - 20" Wide Chairs.

C - 22" Wide Chairs.

NOTE:

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

See Chart Seat Upholstery - Nylon (Standard on RII and Excel) 1 1A See Chart Seat Upholstery - Vinyl (Option on RII and Excel) 1 1A See Chart Back Upholstery (Nylon and Vinyl) 1 1A See Chart Attaching Hardware - Back and Seat Upholstery 1 1A See Chart Carrying Pocket (Nylon and Vinyl) 1 1A

A - Not Shown

NOTE:

Seat Upholstery - Nylon

Standard on RII and Excel

Width 16" Deep 17" Deep 18" Deep

10163171016316101631514" W 10163231016322101632116" W 10163291016328101632718" W 10176491017646101764320" W

Upholstery, Carrying Pocket and

Seat/Chest Positioning Straps

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Upholstery, Carrying Pocket and

Seat Upholstery - Vinyl

(Option on RII and Excel)

Width 16" Deep 17" Deep 18" Deep

8881024419

8881024418

8881024417

14" W

See Note(s) A See Note(s) A See Note(s) A

8881024134

8881024424

8881024423

16" W

See Note(s) A See Note(s) A See Note(s) A

8881024138

8881024137

8881024132

18" W

See Note(s) A See Note(s) A See Note(s) A

8881024142

8881024141

8881024129

20" W

See Note(s) A See Note(s) A See Note(s) A

A - Specify upholstery color when ordering. See page titled, "Frame Finishes, Touch-Up Paints and Upholstery Options." NOTE:

Seat/Chest Positioning Straps

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Back Upholstery

Width Nylon

Vinyl

See Note(s) B

8881058352

106061114" W

See Note(s) A

8881058353

106061216" W

See Note(s) A

8881058354

106061318" W

See Note(s) A

8881058355

106061420" W

See Note(s) A A - Specify frame color when ordering. See page titled, "Frame Finishes, Touch-Up Paints and Upholstery Options." B - Vinyl is optional on RII and Excel models

NOTE:

Carrying Pocket

Width

See Note(s) B

Nylon

Vinyl

See Note(s) B

8881047954

888104795614"

See Note(s) A

8881047957

888104795916-20"

See Note(s) A A - Specify frame color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options." B - Vinyl is optional on RII and Excel models

NOTE:

Attaching Hardware - Back and Seat Upholstery

Back Upholstery Hardware Seat Upholstery Hardware

10579501029850

Package consists of:

(8) ea. Screw with Washer (10 x 7/8")

Package consists of:

(2) ea. Screw with Washer (10 x 7/8")

(2) ea. Cable Ties

Upholstery, Carrying Pocket and

Seat/Chest Positioning Straps

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Solid Folding Seats and Inserts

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Solid Folding Seats and Inserts

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1016771 Hook, Seat 1 21 1016770 Bracket, Seat 1 22 1013218 Washer (#10 Flat) 1 83

7930360 Screw, Phillips Pan Head (#10-32 x 11/16") 25 14 8881110378 Solid Folding Seat w/Hdwr (16" W x 16" D) - Vinyl 1 15 A 8881110379 Solid Folding Seat w/Hdwr (18" W x 16" D) - Vinyl 1 15 A 8881110372 Solid Folding Seat w/Hdwr (20" W x 16" D) - Nylon 1 15 A 8881035936 Solid Folding Seat w/ Hardware (20" W x 18" D),

Nylon

1 15 A

See Chart Solid Seat Inserts 1 1B

A - Specify upholstery color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

B - Not Shown

NOTE

: Solid Folding Seats measure two inches narrower than actual seat width.

NOTE:

Solid Seat Inserts

Chair Upholstery Type Upholstery Type

VinylNylonWidth x Depth

8881034648

8881052563

16 x 16"

See Note(s) A See Note(s) A

8881034657

8881052564

16 x 17"

See Note(s) A See Note(s) A

8881034666

8881052565

16 x 18"

See Note(s) A See Note(s) A

8881034650

8881052569

18 x 16"

See Note(s) A See Note(s) A

8881034659

8881052570

18 x 17"

See Note(s) A See Note(s) A

8881034668

8881052571

18 x 18"

See Note(s) A See Note(s) A

8881034652

8881052575

20 x 16"

See Note(s) A See Note(s) A

8881034661

8881052576

20 x 17"

See Note(s) A See Note(s) A

8881034670

8881052577

20 x 18"

See Note(s) A See Note(s) A

A - Specify upholstery color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options." NOTE:

NOTE: Solid Folding Seats measure two inches narrower than actual seat width.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Assembly

Before 9/1/02

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Assembly

Item #1 - Extended Back Backrest

Extended Back Backrest

(E.B.)

Grey

Fabric/Vinyl

All Grey

Vinyl

Brunswick Buff

All Tan Vinyl

N/AN/A

1078997-NLA

E.B.

Before 8/4/99

and Forward Folding

Before 5/12/00

See Note(s) A

N/AN/A

1090374-NLA

E.B.

After 8/3/99

and Forward Folding

After 5/11/00

See Note(s) B

1086109

1081285

N/A

E.B.

Before 7/22/99

See Note(s) A See Note(s) A

1090376-NLA

1090375-NLA

N/A

E.B.

After 7/21/99

See Note(s) B See Note(s) B A - 9" Backrest Post Spacing. B - 4-3/4" Backrest/Headrest Post Spacing.

NOTE:

Item #2 - High Back Headrest

Headrest

Grey

Fabric/Vinyl

All Grey

Vinyl

Brunswick Buff

All Tan Vinyl

N/AN/A

1071576-NLA

Headrest, High Back

Before 8/16/99

See Note(s) C

N/AN/A

1090379-NLA

Headrest, High Back

After 8/15/99

See Note(s) B

N/A

1090380-NLA

N/AHeadrest, High Back

See Note(s) C B - 4-3/4" Backrest/Headrest Post Spacing. C - 4-23/32" Headrest Post Spacing.

NOTE:

Before 9/1/02

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Assembly

Item #3 - 18" Wide Extended Back Captain Seat

Captain Seat -

Extended Back

Grey

Fabric/Vinyl

All Grey

Vinyl

Brunswick Buff

All Tan Vinyl

N/AN/A

1078965-NLA

Before 8/4/99

See Note(s) D

N/AN/A

1090371-NLA

After 8/3/99

See Note(s) D, E

1086108-NLA

1081284-NLA

N/ABefore 7/22/99

See Note(s) D See Note(s) D

1090373-NLA

1090372-NLA

N/AAfter 7/21/99

See Note(s) D, E See Note(s) D, E

N/AN/A

1085104-NLA

and Forward Folding

Before 5/12/00

See Note(s) D

N/AN/A

1090370-NLA

and Forward Folding

After 5/11/00

See Note(s) D, E D - For Captain Seats marked NLA, use Captain Seats dated after 8/31/02 as replacements. E - Backrest/Headrest post spacing changed. When replacing seat assemblies made before the date specified, a new style backrest or headrest must be ordered as well to match.

NOTE:

NOTE: When converting between high back and extended back captain seats, the wiring harness will also need to be converted. See page titled "Battery Charger and Harnesses".

Item #3 - 18" Wide High Back Captain Seat

Captain Seat -

High Back

Grey

Fabric/Vinyl

All Grey

Vinyl

Brunswick Buff

All Tan Vinyl

N/AN/A

1070456-NLA

18" Wide High Back

Before 8/16/99

See Note(s) F, D

N/AN/A

1091068-NLA

18" Wide High Back

After 8/15/99

See Note(s) F, E, D

N/A

1091069-NLA

N/A18" Wide High Back

See Note(s) D, F D - For Captain Seats marked NLA, use Captain Seats dated after 8/31/02 as replacements. E - Backrest/Headrest post spacing changed. When replacing seat assemblies made before the date specified, a new style backrest or headrest must be ordered as well to match. F - High back 18" wide captain seats includes all actuator attaching hardware (LESS) the limit switch sensor harness #1074983. See page titled "Captain Seat Frame and Actuator Hardware".

NOTE:

NOTE: When converting between high back and extended back captain seats, the wiring harness will also need to be converted. See page titled "Battery Charger and Harnesses".

Before 9/1/02

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Assembly

After 8/31/02

Captain Seats recline approximately 90° - 114° for semi recline backs and 90° - 170° for full recline back

models. Adjustable depths are (16, 17, 18" deep for 18" wide seats). Recline release levers are standard on the right side. Semi recline left side release levers can be ordered as a special with a new captain seat. All full recline captain seats must be ordered as a "special order" to

have the limit switch sensor actuator hardware mounted on the right side.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Assembly

Backrest/Headrest Extensions and Captain Seat Assemblies

Item Number Description All Grey Fabric All Grey Vinyl All Tan Vinyl

110696811084081106969

Backrest -

For Semi Recline

110696611084091106967

Headrest -

For Full Recline

110924811092421109254

18" Wide -

Semi Recline

with Backrest

110925111092451109257

18" Wide -

Full Recline

with Backrest

NOTE: When converting from a semi recline to a full recline captin seat, a limit switch sensor harness part # 1074983 must be ordered as well. See page titled "Captain Seat Frame and Actuator Hardware. NOTE: Actuator mounting hardware is not included with captain seat, see page titled, "Captain Seat Frame and Actuator Hardware." NOTE: New seat mounting screws #1025713 in (4) are required when converting a captain seat available before 9/1/02 to a captain seat available after 8/31/02.

After 8/31/02

Captain Seats recline approximately 90° - 114° for semi recline backs and 90° - 170° for full recline back

have the limit switch sensor actuator hardware mounted on the right side.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Frame and Actuator Hardware

Before 9/1/02

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Frame and Actuator Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1070751 Frame, Seat 1 11 1071602 Pin, Anchor (Captain Seat) 1 42 1029501 Plug Button, Black (1") 1 23 1071603 Screw, Hex Head (M6 x 1" x 20MM) 1 44 B 1045267 Screw, Hex Head (1/4-20 x 3/4") 1 44 C 1026900 Washer (1/4 x 23/32 x 1/16") 1 65 7930333 Locknut (1/4-20) 25 26 1037610 Screw, Hex Head (1/4-20 x 1-5/8") 1 27 1074115 Seat Mounting Hardware, Extended Backs, 18"

Wide

1 18 B,D

1079207 Seat Mounting Hardware, Extended Backs and

Forward Folding Seat, 18" Wide

1 18 C,D

1076392 Bracket, Lower Limit Switch Sensor 1 19

1098624-NLA Clamp, Cable 1 110

1016289 Washer, Caplugs (15/32" I.D. x 1-3/32" O.D.) 1 111 1076568 Screw, Hex Head (7/16-20 x 1") 1 112 1016291 Hub Cap, Black 1 113 1024001 Sensor, Actuator Switch 1 114

16348X007 Rivet Washer (1/8 x 3/8 x 1/16") 1 215

1074128 Screw, Phillips Pan Head (#4-40 x 7/16") 1 216 7930322 Screw, Hex Head (M8 x 1-1/4" x 20MM) 25 117 7930358 Washer, Steel (5/16 x 3/4 x 1/16") 25 118 1076394 Bracket, Upper Limit Sensor Switch 1 119

P0870X000 Nut, Hex Keps (#4-40) 1 220

1025116 Screw, Slotted Hex Head (#4-3/8") 1 321 1008525 Washer, Internal Tooth Lock (#4-40) 1 322 1074983 Cable, Limit Switch Sensor 1 123 A

A - Item number 23 is not included with a high back seat assembly.

B - High Backs 18" Wide.

C - Extended Backs and Forward Folding Seats 18" Wide.

D - Includes Items 3-7.

NOTE:

Before 9/1/02

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Frame and Actuator Hardware

After 8/31/02

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Frame and Actuator Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1070751 Frame, Seat 1 11 1071602 Pin, Anchor (Captain Seat) 1 42 1029501 Plug Button, Black (1") 1 23 1025713 Screw, Hex Head (1/4-20 x 1") 1 44 1026900 Washer (1/4 x 23/32 x 1/16") 1 65 7930333 Locknut (1/4-20) 25 26 1037610 Screw, Hex Head (1/4-20 x 1-5/8") 1 27 1008525 Washer, Internal Tooth Lock (#4-40) 1 48 7930339 Screw, Phillips Pan Head (#4-40 x 3/8") 25 49

P0870X000 Nut, Hex Keps (#4-40) 1 210

1024001 Sensor, Actuator Switch 1 111 1107242 Hardware, Actuator Switch Sensor Mounting 1 112 A,B 1074983 Cable, Limit Switch Sensor 1 113 B

A - Includes Item 8-11.

B - Item 12 and 13 are not included with a high back seat assembly.

NOTE:

After 8/31/02

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Oxygen Holder Assembly Kit Before 4/15/03

Captain Seat, Low Back Models Only

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Oxygen Holder Assembly Kit Before 4/15/03

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1080865 Pin, Oxygen Holder 1 21 A 1035614 Plug Button, Black (5/8") 1 12 1080866 Decal, Oxygen Warning - English 1 13 1027684 Knob, Clamping (Black) 1 24 1086780 Package, Protective Caps 10 25 1073159 Pad, Non-Skid 1 16 1080872 Strap with Buckle 1 17 1083052 Carton, Shipper 1 18 2000454 Bag, Poly (33" W x 39" L) 1 19 1080869 Instruction Sheet, Oxygen Holder 1 110

1080870-NLA Oxygen Holder Assembly with Instruction Sheet 1 111 B,C

A - Oxygen holder pins are to be used when backrest is absent.

B - Includes items 1-10.

C - Due to product improvement, see oxygen holder assemblies dated after 4/14/03 that will accommodate both (exposed and

non-exposed) captain seat hinge assemblies. Special orders are no longer needed for exposed hinge assembly models.

NOTE:

Captain Seat, Low Back Models Only

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Oxygen Holder Assembly Kit After 4/14/03

All Captain Seat Models

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Oxygen Holder Assembly Kit After 4/14/03

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1116952 Oxygen Holder Assembly Kit 1 11 A 1116956 Assembly, Oxygen Holder (D or E Tanks) 1 11 B 1055304 Screw, Socket Button Head (1/4-28 x 5/8") 1 32 1025765 Locknut (1/4-28) 1 33 1028486 Locknut, Low Profile (3/8-16) 1 24 1118889 Washer, Steel (3/8 x 7/8 x 1/16") 1 65 1116954 Nut, Hex (3/8-16) 1 26 1118888 Screw, Hex Head (3/8-16 x 1-1/4") 1 27 1116953 Bracket, Oxygen Holder 1 18 1116948 Oxygen Holder 1 19 C 1080866 Decal, Oxygen Warning - English 1 110 1116950 Pad, Non-Skid 1 111 1116945 Spring, Oxygen Holder 1 112 1072319 Screw, Socket Button Head (#10-32 x 1/2") 1 113 1025735 Locknut (#10-32) 1 114 1116957 Instruction Sheet, Oxygen Holder 1 115 1021866 Bag, Poly (15" Wide x 26" Long) 1 116 1063960 Carton 1 117

A - For seats with an INTERNAL (Non-Visible) hinge assembly and includes items 2-17

B - For seats with an EXTERNAL (Visible) hinge assembly and includes items 9-17

C - Includes items 10-14

NOTE:

All Captain Seat Models

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Oxygen Holder Assembly Kit

Sling Seats Only

NOTE: Oxygen Holder Assembly Kit shown is not available for EXCEL models.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Oxygen Holder Assembly Kit

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1098857 Oxygen Holder, Assembly Kit 1 11 A 1098333 Instruction Sheet, Oxygen Holder 1 12 1021148 Bag, Poly Zip-Lip (6" Wide x 8-3/4" Long) 1 13 1021866 Bag, Poly (15" Wide x 26" Long) 1 14 1097276 Carton, Shipper 1 15 1096839 Screw, Hex Head (1/4-20 x 2-1/4") 1 16 1096838 Screw, Hex Head (1/4-20 x 2") 1 17 7930333 Locknut (1/4-20) 25 18 1027684 Knob, Clamping (Black) 1 49 1080866 Decal, Oxygen Warning - English 1 110 1072002 Pad, Non Skid 1 111

A - Includes Items 2-11.

NOTE:

Sling Seats Only

NOTE: Oxygen Holder Assembly Kit shown is not available for EXCEL models.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Arms and Hardware

18" Wide Models

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Captain Seat Arms and Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1117328 Arm Pad, Full Length, Urethane Waterfall with

Screws, Black (13" L x 2-5/8" W)

1 11 A

1071359 Plate, Armrest (Black) 1 12 1028755 Screw, Phillips Pan Head (#10-32 x 5/8") 1 23 1009837 Screw, Socket Button Head (1/4-20 x 1") 1 14 1025711 Nut, Hex (1/4-20) 1 15 1025704 Washer, Flat (5/16 x 5/8 x 1/16") 1 36 1070928 Arm Tube, Upper Height and Width Adjustable

(Black)

1 17

15680X013 Anti-Rattle (1") 1 18

7930304 Screw, Socket Head (1/4-20 x 1-1/4") 25 19 1026906 Locknut (5/16-24) 1 110 1102546 Screw, Phillips Pan Head (#10-32 x 7/8") 1 111 1070106 Insert, Armrest 1 112 1031026 Screw w/ Lug (5/16-24 x 1-3/8") 1 113 1074120 Kit, Armrest Attaching Hardware (Pair) 2 114 B 1073378 Kit, Arm Pad Attaching Hardware 2 115 C 1070756 Arm Tube Assembly, Upper Adjustable (Pair) 2 116 D

A - As of 1/3/02 upholstered waterfall armpads were replaced with black urethane waterfall armpads. Order in pairs for chairs

manufactured before 1/3/02.

B - Includes Items 2, 4, 5, 6, 10, and 13.

C - Includes Items 3, 11, and 12.

D - Includes Items 7-9.

NOTE:

18" Wide Models

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Arms - Ranger II / R2 jr.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Arms - Ranger II / R2 jr.

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

8881015932 Arm Pad, Vinyl, Full Length (14" L x 2" W) - Right 1 11 A 8881015933 Arm Pad, Vinyl, Full Length (14" L x 2" W) - Left 1 11 A

1117328 Arm Pad, Full Length, Urethane Waterfall with

Screws, Black (13" L x 2-5/8" W)

1 11 B,F

1110818 Arm Pads, Full Length, Urethane Waterfall

with Screws, Black (13" L x 2-5/8" W) (Pair)

2 11

8881011811 Arm Pad, Vinyl, Desk Length (9" L x 2" W) 1 11 A

1117327 Arm Pad, Desk Length, Urethane Waterfall with

Screws, Black (9" L x 2-5/8" W)

1 11 B,F

1110817 Arm Pads, Desk Length, Urethane Waterfall with

Screws, Black (9" L x 2-5/8" W) (Pair)

2 11

1055949 Screws, Phillips Pan Head (#10-32 x 1-1/8") 2 12 1094270 Screw, Phillips Pan Head (#10-32 x 1-1/4") (Pair) 2 12 D 1071253 Arm Top, Adjustable Height with Plug Buttons - Full

Length (Black)

1 13

1070859 Arm Tube, Upper with Plug Buttons (Black) - Desk

Length

1 13

1027095 Plug Button, Black (7/8") 1 24 1065936 Plug, Pivot 1 25

47471X074 Spring, Arm Lock 1 16

1028594 Pin, Arm Lock 1 17 1090768 Kit, Lock Handle w/Rivets (both LT & RT side) 2 18 1067734 Plug Button, Black (5/8") 1 29 1028645 Rivet 1 610

1064130 Clothing Guard 1 111 8881071554 Arm Base, Adjustable Height - Right 1 112 C 8881071555 Arm Base, Adjustable Height - Left 1 112 C

1068039 Pin, Pull 1 113

1019590 Screw, Socket Button Head (1/4-20 x 1-5/8") 1 114

1068025 Clevis, Pivot 1 115

7930323 Package, Locknut (1/4-20) 25 116

1090277 Hardware, Mounting, Swingaway Armrest 1 117 E 8881071517 Tube, Arm, Full Length, Right 1 118 C 8881071518 Tube, Arm, Full Length, Left 1 118 C 8881071519 Tube, Arm, Desk Length, Right 1 118 C 8881071520 Tube, Arm, Desk Length, Left 1 118 C

1025729 Screw, Self Tapping Pan Head (#8-32 x 3/8") 1 419

1035472 Clothing Guard, Desk Length 1 120 8881071550 Arm Assembly, Full Length, Right 1 121 C 8881071551 Arm Assembly, Full Length, Left 1 121 C 8881071552 Arm Assembly, Desk Length, Right 1 121 C 8881071553 Arm Assembly, Desk Length, Left 1 121 C

1027095 Plug Button, Black (7/8") 1 122

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Arms - Ranger II / R2 jr.

A - Specify upholstery color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

B - As of 1/3/02 upholstered waterfall armpads were replaced with black urethane waterfall armpads. Order in pairs with

screws for chairs manufactured before 1/3/02.

C - Specify frame finish when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

D - For Black Urethane Waterfall Arm Pads Only.

E - Includes Items 14, 15 and 16.

F - After 7/9/07 Invacare recommends ordering armpads in pairs to assure uniform appearance on chair

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Arms - Excel

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Arms - Excel

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

8881015932 Arm Pad, Vinyl, Full Length (14" L x 2" W) - Right 1 11 A 8881015933 Arm Pad, Vinyl, Full Length (14" L x 2" W) - Left 1 11 A

1117328 Arm Pad, Full Length, Urethane Waterfall with

Screws, Black (13" L x 2-5/8" W)

1 11 B,D

1110818 Arm Pads, Full Length, Urethane Waterfall

with Screws, Black (13" L x 2-5/8" W) (Pair)

2 11

8881011811 Arm Pad, Vinyl, Desk Length (9" L x 2" W) 1 11 A

1117327 Arm Pad, Desk Length, Urethane Waterfall with

Screws, Black (9" L x 2-5/8" W)

1 11 B,D

1110817 Arm Pads, Desk Length, Urethane Waterfall with

Screws, Black (9" L x 2-5/8" W) (Pair)

2 11

1055949 Screws, Phillips Pan Head (#10-32 x 1-1/8") 2 12

1094270 Screw, Phillips Pan Head (#10-32 x 1-1/4") (Pair) 2 12

1041522 Arm Tube, Upper with Plug Buttons (Black) - Full

Length

1 13

1070859 Arm Tube, Upper with Plug Buttons (Black) - Desk

Length

1 13

1027095 Plug Button, Black (7/8") 1 24 8881057741 Adjustable Height Base (Color) - Right 1 15 C 8881057742 Adjustable Height Base (Color) - Left 1 15 C

1090768 Kit, Lock Handle w/Rivets (both LT & RT side) 2 16

47471X074 Spring, Arm Lock 1 17

1028594 Pin, Arm Lock 1 18

1064130 Clothing Guard 1 19

1028645 Rivet 1 610 8881057723 Desk Length Arm Tube (Color), Right 1 111 C 8881057724 Desk Length Arm Tube (Color), Left 1 111 C 8881057715 Tube, Arm, Full Length (Color), Right 1 111 C 8881057716 Tube, Arm, Full Length (Color), Left 1 111 C

1035472 Clothing Guard, Desk Length 1 112

1044572 Clothing Guard, Full Length 16-19" Deep 1 112

1025729 Screw, Self Tapping Pan Head (#8-32 x 3/8") 1 413 8881057729 Arm, Desk Length without Armpad (Color), Right 1 114 C 8881057730 Arm, Desk Length without Armpad (Color), Left 1 114 C 8881057719 Arm, Full Length without Armpad (Color), Right 1 114 C 8881057720 Arm, Full Length without Armpad (Color), Left 1 114 C

A - Specify upholstery color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

B - As of 1/3/02 upholstered waterfall armpads were replaced with black urethane waterfall armpads. Order in parts with

screws for chairs manufactured before 1/3/02.

C - Specify frame finish when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

D - After 7/9/07 Invacare recommends ordering armpads in pairs to assure uniform appearance on chair

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Rear Casters, Forks, and Hardware

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Rear Casters, Forks, and Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1056739 Cap, Head Tube 1 11

1028550 Locknut (5/8-18) 1 12

1041444 Washer (5/8 x 1-5/16 x 1/8") 1 13

1057949 Fork Stem Hardware 1 14 C 8881071460 Fork and Stem - 6" Casters 1 15 A 8881071600 Caster Forks, Shock Fork (6") 1 15 A 8881058562 Caster Forks, Standard Fork (8") 1 15 A

1025726 Screw, Hex Head (7/16-20 x 3-1/4") 1 16 D

1058744 Screw, Hex Head (7/16-20 x 3-1/2") 1 16 E

7930329 Washer, Steel (15/32 x 5/8 x 3/64") 25 17

7930331 Locknut (7/16-20") 25 18

1042489 Caster Axle Hardware (1 Pair) 2 19 D,F

1058890 Hardware, Caster, Shock Fork (Pair) 2 19 E,F

1072014-NLA Wheel with Bearings - Semi Pneumatic (6" x 2") 1 110 G

1115179 Wheel with Bearings, 6 x 2" Urethane Deep Profile 1 110 H

1122066 Wheels with Bearings, 6 x 2" Urethane Deep Profile 2 110 H

1070811 Wheel/Caster, Semi-Pneumatic with Bearings

(8 x 1-3/4")

1 210

1002002 Wheel with Bearings - Pneumatic (8 x 2") 1 110

1006049 Bearing (7/16") 1 211

1020592 Spacer, Bearing (7/16 x 5/8 x 1-3/4") 1 112

40176X034 Tire, Pneumatic (8" x 2") 1 113

1034942 Tube, Pneumatic Inner (8" x 2") 1 114

40176X010 Tire Pump 1 1B

A - Specify frame finish when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

B - Not Shown.

C - Includes Items 1-3.

D - Standard Fork.

E - Shock Fork.

F - Includes items 6-8.

G - Service part No Longer Available 8/15/03. Due to product improvement, order (pair) part number 1122066 dated after

8/14/03 so each side matches. The deep profile caster has 2 tread grooves w/ round corners instead of 4 tread grooves w/

square corners.

H - Service part after 8/14/03

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Drive Wheel (12-1/2 x 2-1/4"), 2-Pole Motor

and Gearbox

(Ranger II Basic, Excel and R2 jr.)

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Drive Wheel (12-1/2 x 2-1/4"), 2-Pole Motor

Item Number Description Part Number

1071593Motor and Gearbox - Right1 1071594Motor and Gearbox - Left1 1055872Brake Repair Kit2 1038361Brake Cover with Screws (Pair)3

561-005Brushes (Pair)4

1064177

Drive Wheel, Foam Fill (12-1/2") with

Locking Tab

1064178

Drive Wheel, Pneumatic (12-1/2")

with Locking Tab

1011524Tire (12-1/2 x 2-1/4")6

1073936-NLA

Flat Free Insert7

See Note(s) A

1011525Tube (12-1/2 x 2-1/4")8 1023262Washer (11/32 x 13/16 x 1/8")9 1064179Washer, Locking Tab (Pair)10

7930322

Screw, Hex Head (M8 x 20MM)

(Pkg. of 25)

1098712

Clutch Lever - Right12

See Note(s) B

1098713

Clutch Lever - Left

See Note(s) B

1071567-NLABracket, Clutch Lever13

1071568Pin, Clevis14 1040060Tip, Plastic15 1071562Bushing, Snap16 1074114Clutch Lever Assembly - Right17 1074135Clutch Lever Assembly - Left 1080713Screw, Socket Head (M6 x 15MM)18 1080712Screw, Socket Head (M6 x 35MM)19 1023264Key20

10513X000Washer, Star (1/4")21

A - As of 10/20/99 the "solid" flat free insert was replaced by a "foam fill" process. When a flat free insert is requested, a complete wheel must be ordered. B - Short end of Clutch Lever was lengthened from 2" to 2-3/4" long as of 12/1/00. Replace in pairs for chairs made before 12/11/00.

NOTE:

NOTE: Light Duty, 250-S models use long cap motors.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

and Gearbox

(Ranger II Basic, Excel and R2 jr.)

Drive Wheel (12-1/2 x 2-1/4"), 4-Pole Motor

and Gearbox

(Ranger II Standard w/ Brake Lever)

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Drive Wheel (12-1/2 x 2-1/4"), 4-Pole Motor

Item Number Description Part Number

1086228

Gearbox - Right1

See Note(s) E

1086227

Gearbox - Left1

See Note(s) E

5165204-NLA

Coupling w/ Cup (1" Diameter)2

See Note(s) C

50000X007

Coupling w/ Cup (1-5/16" Diameter)2

See Note(s) D

1086788

Motor Assembly - Right

(Before 10/29/01)

1087218

Motor Assembly - Left

(Before 10/29/01)

1109229

Motor Assembly - Right

(After 10/28/01)

1109228

Motor Assembly - Left

(After 10/28/01)

1070295Brake Repair Kit - Right4 1070294Brake Repair Kit - Left4

See Item 5

Screw, Socket Pan Head (8-32 x

1/4")

1070297-NLA

Brake Cover with Screws

(Before 10/29/01)

1104402-NLA

Brake Cover (Black) with Screws

(After 10/28/01)

1070296Brushes with Caps (Set of 4)7 1082985Slotted Plate8

1082984

Plastic Tip

(Before 10/29/01)

1101725

Plastic Tip

(After 10/28/01)

1043594

Screw, SHC

(1/4-20 x 1-1/8")

See Note(s) E

1108978

Screw, SHC

(M6 x 1 x 20MM)

10.

See Note(s) E

1086218

Motor and Gearbox - Right

(Before 10/29/01)

See Note(s) F

1086217

Motor and Gearbox - Left

(Before 10/29/01)

See Note(s) F

1109170

Motor and Gearbox - Right

(After 10/28/01)

1109169

Motor and Gearbox - Left After

10/28/01

1064177

Wheel with Foam Fill (12-1/2) with

Locking Tab

See Note(s) A

and Gearbox

(Ranger II Standard w/ Brake Lever)

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Drive Wheel (12-1/2 x 2-1/4"), 4-Pole Motor

Item Number Description Part Number

1064178

Wheel, Pneumatic (12-1/2") with

Locking Tab

See Note(s) A

1011524Tire (12-1/2 x 2-1/4")13

1073936-NLA

Flat Tire Insert14

See Note(s) B

1011525Tube (12-1/2 x 2-1/4")15 1023264Key16 1023262Washer (11/32 x 13/16 x 1/8")17 1064179Washer, Locking Tab (Pair)18

7930322

Screw, Hex Head (M8 x 20MM)

(Pkg. of 25)

1074974-NLAShroud Cover - Black, Drive Wheel20

1080713Screw, Socket Head (M6 x 15MM)21 1080712Screw, Socket Head (M6 x 35MM)22

10513X000Washer, Star (1/4")23

A - Drive wheel comes with a locking tab and instruction sheet. B - As of 10/20/99, the "solid" flat free insert was replaced by a "foam fill" process. When a Flat Free Insert is requested, a complete wheel must be ordered. C - Coupling with Cup for chairs manufactured before 11/12/01 - Use part # 50000X007 as a direct replacement part. D - After 11/11/01 Coupling with Cup was resized from approximately 1" to 1-5/16" diameter and can be used as a direct replacement for part number 5165204 E - When a new gearbox or mounting screws are ordered, (2 ea.) metric and (2 ea.) non-metric screws (item 10) must be ordered. Invacare Corp. utilizes alternate suppliers for this part number. F - As of May 2008, the Metal Motor End Cap will be replaced with a Composite Motor End Cap. The change does not affect form, fit, function or aesthetics.

NOTE:

and Gearbox

(Ranger II Standard w/ Brake Lever)

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Drive Wheel (14 x 3") and Hub Mount

Optional on Chair As Of 10/15/99

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Drive Wheel (14 x 3") and Hub Mount

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1090649 Assembly, Drive Wheel, Pneumatic (14" x 3") 1 11

1090650 Drive Wheel Assembly w/ Flat Free Insert (14" x 3") 1 11

1101754 Tire with Flat Free (14" x 3") 1 12

1039652 Tire, Pneumatic (14" x 3") 1 13

1039651 Tube (14" x 3") 1 14

1090651 Rim, 8" with Hardware (14 x 3" Wheel) 1 15 A

1090648-NLA Hardware, Drive Wheel Mounting w/ Instruction

Sheet (14" x 3")

1 16 B

7930322 Screw, Hex Head (M8 x 1-1/4" x 20MM) 25 17

1064179 Kit, Locking Tab Washers with Instruction Sheet 2 18

1023262 Washer (11/32 x 13/16 x 1/8") 1 19

1024444 Locknut (5/16-24) 1 410

1086681 Hub, Wheel (14" x 3") 1 111

1023264 Key (6 MM x 6MM x 40 MM) 1 112

A - Hardware consists of: (8) ea. Screw, Hex Head Cap (1/4-20 x 3/4") and (8) ea. Locknut, High Profile (1/4-20").

B - Includes Items 7-12 and Instruction Sheet.

NOTE:

Optional on Chair As Of 10/15/99

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Battery Boxes and Trays

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Battery Boxes and Trays

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1026158 Locknut (5/16-18) 1 21

1080242 Bracket, Pivot, Right 1 12

1026032 Washer, Nylon (11/32 x 11/16 x 1/16") 1 23

1018739 Washer (1/4 x 5/8 x 3/32") 1 24

1042486 Screw, Hex Head (5/16-18 x 2-3/4") 1 25

1043627 Screw, Hex Head Cap with Patch (5/16-18 x 1-3/4") 1 16 K

1050161 Screw, Hex Head Cap with Patch (5/16-18 x 1") 1 36 L

1080240 Bracket, Pivot, Left 1 17

1058520 Fastener, Panel Snap-In 1 58

1079247 Washer, Flat (21/64 x 53/64 x 7/64") 1 19

1080255-NLA Tray, Battery Assembly w/ Hardware 1 110 H

1025752 Screw, Hex Head (1/4-20 x 1-1/2") 1 411

1080250-NLA Pin, Tray Pivot 1 212

7930323 Package, Locknut (1/4-20) 25 113

7930333 Locknut (1/4-20) 25 114

1080241 Support, Tray 1 115

1021406 Screw, Hex Head (1/4-20 x 1-1/4") 1 416

1080256 Pin, Tray 1 217

1080239 Tray w/ Buckle 1 218

1097003 Battery Box Top, Rear (22NF) 1 219 A,B,I

1057944 Battery Box Bottom with Strap 1 220 J

1057954 Battery Strap 1 1G

1041433 Pin, Handle 1 2G

1097007 Battery Box Assembly, Rear (22NF) 1 221 I

50000X166 Fuse, 60 Amp (Buss 2-1/4" Long) 1 2A,E,G

1089385 Fuse, 80 Amp, MIDI (Non-G/B & G/B) 1 2F,G

1060318 Hardware, Battery Terminal, UI Batteries (Pair) 2 1C,G

1058618 Hardware, Battery Terminal, 22NF Batteries (1 Pair) 2 1D,G

A - As of 11/05/99 the battery harness fuse changed from a Bussman 60AMP to a MIDI 80AMP fuse. This battery box top is

compatible for all chairs manufactured before 11/05/99 and must be ordered whenever a replacement Bussman 60AMP

fuse is replaced.

B - It is recommended that new terminal hardware be ordered when a new battery box top is ordered.

C - Hardware includes small battery terminal caps (gray and orange), 1/4-20 x 7/8" hex flange screws, 1/4-20 hex flange nuts,

cable ties, locking tab washers and instruction sheet for two batteries.

D - Hardware includes battery clamps, battery clamp caps (red and black), small battery terminal caps (red and black), 1/4-20

x 7/8" hex flange screws, 1/4-20 hex flange nuts, cable ties and locking tab washers for two batteries.

E - Before 11/5/99.

F - After 11/4/99.

G - Not Shown.

H - Includes Items 11-18.

I - 22NF and UI 250-S Models.

J - Includes: Battery Strap #105794 and Handle Pin #104133.

K - With One Piece Footboard.

L - Without One Piece Footboard.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Battery Boxes and Trays

R2 jr. (14" Wide)

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Battery Boxes and Trays

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1079203 Decal, Warning Pinch Point 1 11

1026032 Washer, Nylon (11/32 x 11/16 x 1/16") 1 22

1086166 Screw, Hex Head (5/16-18 x 3/4") 1 23

1074133 Washer (5/16 x 3/4 x 1/16") 1 24

1028769 Locknut (5/16-18) 1 25

1090275 Tray, Battery with Buckle and Warning Decal 1 16

1086160 Pivot Bracket-Right 1 17

1086167-NLA Battery Tray Assembly 1 18 A

1057941 Battery Box Top Assembly, Dual w/ Single

Extended Connector, UI

1 29 B,C

1009268 Battery Box Bottom Assembly 1 210

1057942 Battery Box Assembly, Dual w/ Single Extended

Connector, UI

1 211 D

1058520 Fastener, Panel Snap-In 1 512

1079247 Washer, Flat (21/64 x 53/64 x 7/64") 1 113

1090276 Pivot Bracket with Warning Decal, Left 1 114

1050161 Screw, Hex Head Cap with Patch (5/16-18 x 1") 1 315

1026158 Locknut (5/16-18) 1 216

1089385 Fuse, 80 Amp, MIDI (Non-G/B & G/B) 1 2C,F

1060318 Hardware, Battery Terminal, UI Batteries (Pair) 2 1E,F

A - Includes Items 2-7.

B - It is recommended that new terminal hardware be ordered when a new battery box top is ordered.

C - As of 11/05/99 the battery harness fuse changed from a Bussman 60AMP to a MIDI 80AMP fuse. This battery box top is

compatible for all chairs manufactured before 11/05/99 and must beordered whenever a replacement Bussman 60AMP

fuse is requested.

D - Includes Items 9 and 10.

E - Hardware includes small battery terminal caps (gray and orange), 1/4-20 x 7/8" hex flange screws, 1/4-20 hex flange nuts,

cable ties, locking tab washers and instruction sheet for two batteries.

F - Not Shown.

NOTE:

R2 jr. (14" Wide)

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Battery Chargers and Harnesses

NOTE: Light Duty, 250-S models use a 4 amp. charger #1061411.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Battery Chargers and Harnesses

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1053834 Harness, Wiring, Standard 1 11 D

1070590 Harness, Wiring 1 11 E

1088802-NLA Screw, Phillips Pan Head (6-32 x 1-1/4") 1 22 A

1088801 Washer, Nylon (3/16 x 1/2 x 3/8") 1 23 A

1011980 Screw, Phillips Pan Head (#6-32 x 3/4") 1 24

1095503 Package, Cable Ties (5-5/8" Long) 10 15

P0870X050 Nut, Keps (#6-32) 1 26 P0870X000 Nut, Hex Keps (#4-40) 1 27

7930318 Screw, Phillips Pan Head (#4-40 x 1/2") 25 18

1053837 Bracket, Charger Connector 1 19

1030949 Screw, Hex Head (1/4-20 x 1-1/2") 1 110

1086804 Bracket, Battery Charger Connector 1 111

1087226 Screw, Phillips Pan Head Tap (#4-24 x 3/8") 1 212

7930333 Locknut (1/4-20) 25 113

1095502 Package, Cable Ties (11-1/2" Long) 10 114

1083929 Cable, Charger Extension (24" Long Round Plug) 1 115

1053161 Battery Charger, 8 Amp. 115vac (Off Board)

Dual Mode Round Plug, Lester

1 116 B

1085678-NLA Battery Charger, 8 Amp. 115vac (Off Board)

Dual Mode Round Plug w/ AC Power Line Cord, Dynamic

1 116

1061411-NLA Battery Charger, 4 Amp. 115vac (Off Board)

Dual Mode Round Plug, Lester

1 116 H

1123249 Battery Charger, 8 Amp. 115vac (Off Board)

Single Mode Round Plug w/ AC Power Line Cord, CTE Corp.

1 116 I,I1

1089627 Cord, AC Power Line 115vac (2-prong off-board

11'6"L)

1 117

1090357 Wrap, Slit Wire Harness (1/2" O.D.) (36" Long Cut

To Length)

1 118 C

1098892 Fuse, 15 Amp. (Buss ATC-15) 1 119 F

1090117 Fuse, 15 Amp. (Buss Mini ATM-15) 1 119 G

A - Items 2 and 3 changed after 4/14/99. Order Items 2 and 3 together for chairs manufactured before 4/15/99.

B - On 7/18/01 Lester 8AMP battery charger was reinstated.

C - Plastic wire wrap replaced mesh fabric and heat shrink 9/1/99. Part #1090357 can be used for chairs manufactured

before 9/1/99 as well.

D - Sling Seats and Low Back Captain Seat.

E - High Back Captain Seat.

F - Before 4/1/03. Wiring Harnesses (2) required. Charger Extension Cable (1) required.

G - After 3/31/03. Wiring Harnesses (2) required. Charger Extension Cable (2) required.

H - CTE 8 Amp. charger replaced the obsoleted 4 Amp. charger as of 4/1/04.

I - CTE charger introduced 4/1/04. Used on Gel Cell or AGM (Absorbed Glass Mat) batteries. For wet cell batteries refer to the

8 amp. Lester charger.

I1 - CTE charger looks exactly the same as Dynamic’s charger except for the company name that is silk screened on the

narrow side panel, where the charger plug is (hard wired) attached. Serial number starts with 04A00000001.

NOTE:

NOTE: Light Duty, 250-S models use a 4 amp. charger #1061411.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Battery Chargers and Harness

R2 jr. (14" Wide)

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Battery Chargers and Harness

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1086168 Wiring Harness, R2 jr. 1 11

1088802-NLA Screw, Phillips Pan Head (6-32 x 1-1/4") 1 22

1088801 Washer, Nylon (3/16 x 1/2 x 3/8") 1 23

1011980 Screw, Phillips Pan Head (#6-32 x 3/4") 1 24

1090117 Fuse, 15 Amp. (Buss Mini ATM-15) 1 15

1090357 Wrap, Slit Wire Harness (1/2" O.D.) (36" Long Cut

To Length)

1 16

P0870X050 Nut, Keps (#6-32) 1 27

1030949 Screw, Hex Head (1/4-20 x 1-1/2") 1 18

1086804 Bracket, Battery Charger Connector 1 19

1087226 Screw, Phillips Pan Head Tap (#4-24 x 3/8") 1 110

7930333 Locknut (1/4-20) 25 111

1053161 Battery Charger, 8 Amp. 115vac (Off Board)

Dual Mode Round Plug, Lester

1 112 A

1085678-NLA Battery Charger, 8 Amp. 115vac (Off Board)

Dual Mode Round Plug w/ AC Power Line Cord, Dynamic

1 112

1123249 Battery Charger, 8 Amp. 115vac (Off Board)

Single Mode Round Plug w/ AC Power Line Cord, CTE Corp.

1 112 D,D1

1083929 Cable, Charger Extension (24" Long Round Plug) 1 113

1089627 Cord, AC Power Line 115vac (2-prong off-board

11'6"L)

1 114

1095502 Package, Cable Ties (11-1/2" Long) 10 115

1098892 Fuse, 15 Amp. (Buss ATC-15) 1 116 B

1090117 Fuse, 15 Amp. (Buss Mini ATM-15) 1 216 C

1101099 Fuse, 20 Amp. (Buss ATC-20) 1 117 B

1119230 Fuse, 20 Amp. (Buss Mini ATM-20) 1 117 C

A - On 7/18/01 Lester 8 AMP battery charger was reinstated.

B - Before 4/1/03

C - After 3/31/03

D - CTE charger introduced 4/1/04. Used on Gel Cell or AGM (Absorbed Glass Mat) batteries. For wet cell batteries refer to

the 8 amp. Lester charger.

D1 - CTE charger looks exactly the same as Dynamic’s charger except for the company name that is silk screened on the

narrow side panel, where the charger plug is (hard wired) attached. Serial number starts with 04A00000001.

NOTE:

R2 jr. (14" Wide)

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers - Before 3/1/00

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers - Before 3/1/00

Item #'s 1-4 Shroud Covers

Item

Number

Bright Silver

Metallic

Description

Bright

Plum

Metallic

Bright

Blue

Metallic

Blue

Green

Chameleon

Candy

Apple

Red

1087151

1087150

1087149

1087148

1087147

Side Panel with

Rubber Bushing

(Captain &

Sling Seat) -

Right

See Note(s) B See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1087156

1087155

1087154

1087153

1087152

Side Panel with

Rubber Bushing

(Captain &

Sling Seat) -

Left

See Note(s) B See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1086624-NLA

1085579-NLA

1085578-NLA

1085577-NLA

1085576-NLA

Battery Cover

Ranger II Only -

16" W

See Note(s) A, C See Note(s) C, A See Note(s) A, C See Note(s) C, A See Note(s) A, C

1086625-NLA

1085583

1085582

1085581-NLA

1085580-NLA

Battery Cover

Ranger II Only -

18" W

See Note(s) A, C See Note(s) C, A See Note(s) C See Note(s) C See Note(s) C, A

1086626-NLA

1085587

1085586-NLA

10855851085584

Battery Cover

Ranger II Only -

20" W

See Note(s) A See Note(s) A

1087161-NLA

1087160-NLA

1087159-NLA

1087158-NLA

1087157-NLA

Trunk Lid - 16"

See Note(s) A, C See Note(s) C, A See Note(s) A, C See Note(s) C, A See Note(s) A, C

1087166-NLA

1087165

1087164

1087163

1087162-NLA

Trunk Lid - 18"

See Note(s) C, A See Note(s) C See Note(s) C See Note(s) C See Note(s) C, A

1087171-NLA

1087170

1087169

1087168-NLA

1087167

Trunk Lid - 20"

See Note(s) C See Note(s) A See Note(s) C See Note(s) C See Note(s) C, A

10883091088309108830910883091088309

Filler w/o Plug

Button

(Captain) -

Black Only -

Right

1088310-NLA1088310-NLA1088310-NLA1088310-NLA1088310-NLA

Filler w/o Plug

Button

(Captain) -

Black Only -

Left

1088311-NLA1088311-NLA1088311-NLA1088311-NLA1088311-NLA

Filler w/o Plug

Button

(Sling Seat) -

Black Only -

Right

1088312-NLA1088312-NLA1088312-NLA1088312-NLA1088312-NLA

Filler w/o Plug

Button

(Sling Seat) -

Black Only -

Left

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers - Before 3/1/00

A - Shroud is No Longer Available. See Shroud pages dated "After 2/29/00" for color conversion options. B - Decals not included. See page titled, "Packaging, Literature and Decals." C - Captain seat shrouds in 18" wide only.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers - Before 3/1/00

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

See Chart Item #'s 1-4 Shroud Covers 1 11-4

1070587 Washer, Flat (3/16 x 5/8 x 1/16") 1 85 A

1028755 Screw, Phillips Pan Head (#10-32 x 5/8") 1 86 A

1089724 Plug Button, Black 1 27

7930332 Locknut, High Profile (#10-32) 25 18

1070594 Bushing, Rubber 1 19

1070575 Screw, Phillips Head (#10-32 x 7/8") 1 210

1088261 Bracket, Shroud, Right 1 111

1088262 Bracket, Shroud, Left 1 111

1050161 Screw, Hex Head Cap with Patch (5/16-18 x 1") 1 312

1070577 Plate, Trunk Clip 1 213

1070588 Screw, Truss Head (#10-32 x 1/2") 1 414

7930332 Locknut, High Profile (#10-32) 25 115

1088497-NLA Fastener, Panel (5/8 x 3/4" Long) 1 116 B

1070555 Fastener, Dual Lock (5/8" Wide x 2" Long) 1 217

1070556 Fastener, Dual Lock (1" Wide x 2" Long) 1 218

1087172 Hardware, Side Panel Attaching 1 1C,D

A - After 10/05/99 quantity changed from 8 to 6 when dual lock fastener was added to side panel shrouds and trunk lid. See

detail "A" on previous page.

B - Sling Seat Only.

C - Includes Items 5, 6, 10, 11, 12, 15 and 17.

D - Not Shown.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers - After 2/29/00

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers - After 2/29/00

Item #'s 1-4 Shroud Covers

Item

Number

Description

Ocean

Blue

Emerald

Green

Liquid Black

Candy

Apple

Red

1095406-NLA

1095407

1095409

1095408

Side Panel with

Rubber Bushing

(Captain & Sling

Seat) - Right

See Note(s) A See Note(s) A See Note(s) A See Note(s) A

1095410

1095411

1095413

1095412

Side Panel with

Rubber Bushing

(Captain & Sling

Seat) - Left

See Note(s) A See Note(s) A See Note(s) A See Note(s) A

1095390-NLA

1095391-NLA

1095393-NLA

1095392-NLA

Battery Cover

Ranger II Only -

16" W

See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1095394-NLA

1095395-NLA

1095397-NLA

1095396-NLA

Battery Cover

Ranger II Only -

18" W

See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1095398-NLA

1095399-NLA

1095401-NLA

1095400-NLA

Battery Cover

Ranger II Only -

20" W

See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1095414-NLA

1095415-NLA

1095417-NLA

1095416-NLA

Trunk Lid - 16" W3

See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1095418-NLA

1095419-NLA

1095421-NLA

1095420-NLA

Trunk Lid - 18" W3

See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1095422-NLA

1095423-NLA

1095425-NLA

1095424-NLA

Trunk Lid - 20" W3

See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1088309108830910883091088309

Filler without Plug

Button

(Captain) (Black

only)

- Right

1088310-NLA1088310-NLA1088310-NLA1088310-NLA

Filler without Plug

Button

(Captain) (Black

only)

- Left

1088311-NLA1088311-NLA1088311-NLA1088311-NLA

Filler without Plug

Button

(Sling Seat) (Black

only)

- Right

1088312-NLA1088312-NLA1088312-NLA1088312-NLA

Filler without Plug

Button

(Sling Seat) (Black

only)

- Left

1096897

1096898

1096900

1096899

Color Conversion

Package,

Ranger II - 16" W

See Note(s) B, A, C, D See Note(s) B, A, D, C See Note(s) B, D, C, A See Note(s) B, D, C, A

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers - After 2/29/00

Item #'s 1-4 Shroud Covers

Item

Number

Description

Ocean

Blue

Emerald

Green

Liquid Black

Candy

Apple

Red

1096893

1096894

1096896

1096895

Color Conversion

Package,

Ranger II - 18" W

See Note(s) B, C, A, D See Note(s) B, C, D, A See Note(s) B, A, D See Note(s) B, A, D

1096901

1096902

1096904

1096903

Color Conversion

Package,

Ranger II - 20" W

See Note(s) D, C See Note(s) D See Note(s) D, C See Note(s) D, C

1096913-NLA

1096914-NLA

1096916-NLA

1096915-NLA

Color Conversion

Package,

Excel - 16" W

See Note(s) D, C See Note(s) D, C See Note(s) D See Note(s) D

1096909-NLA

1096910-NLA

1096912-NLA

1096911-NLA

Color Conversion

Package,

Excel - 18" W

See Note(s) D, C See Note(s) D, C See Note(s) D, C See Note(s) B, A, C, D

1096917-NLA

1096918-NLA

1096920-NLA

1096919-NLA

Color Conversion

Package,

Excel - 20" W

See Note(s) B, C, D, A See Note(s) B, C, A, D See Note(s) B, A, D, C See Note(s) B, D, A, C A - Decals not included. See page titled, "Packaging, Literature and Decals." B - Captain seat shrouds in 18" wide only. C - Not Shown. D - Includes Items 1, 3, 5, 6, 8, 10, 16 and 17.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers - After 2/29/00

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

See Chart Item #'s 1-4 Shroud Covers 1 11-4

1070587 Washer, Flat (3/16 x 5/8 x 1/16") 1 65 1028755 Screw, Phillips Pan Head (#10-32 x 5/8") 1 66 1089724 Plug Button, Black 1 27 7930332 Locknut, High Profile (#10-32) 25 18 1070594 Bushing, Rubber 1 19 1070575 Screw, Phillips Head (#10-32 x 7/8") 1 210 1088261 Bracket, Shroud, Right 1 111 1088262 Bracket, Shroud, Left 1 111 1050161 Screw, Hex Head Cap with Patch (5/16-18 x 1") 1 312 1070577 Plate, Trunk Clip 1 213 1070588 Screw, Truss Head (#10-32 x 1/2") 1 414 7930332 Locknut, High Profile (#10-32) 25 115

1088497-NLA Fastener, Panel (5/8 x 3/4" Long) 1 116 C

1070555 Fastener, Dual Lock (5/8" Wide x 2" Long) 1 217 1070556 Fastener, Dual Lock (1" Wide x 2" Long) 1 218 1087172 Hardware, Side Panel Attaching 1 1A,B

A - Not Shown.

B - Includes Items 5, 6, 10, 11, 12, 15, and 17.

C - Sling Seat Only.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers

R2 jr. (14" Wide)

Before 3/1/00

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers

Item #'s 1-3 Shroud Covers

R2 jr. (14" Wide)

Item

Number

Bright Silver

Metallic

Description

Bright

Plum

Metallic

Bright

Blue

Metallic

Blue

Green

Chameleon

Candy

Apple

Red

1087151

1087150-NLA

1087149-NLA

1087148-NLA

1087147-NLA

Side Panel with

Rubber Bushing

(Sling Seat) -

Right

See Note(s) A, B See Note(s) A, B See Note(s) A, B See Note(s) A, B See Note(s) A, B

1087156-NLA

1087155-NLA

1087154-NLA

1087153-NLA

1087152

Side Panel with

Rubber Bushing

(Sling Seat) -

Left

See Note(s) A, B See Note(s) A See Note(s) A See Note(s) A See Note(s) A

1086623-NLA

1085575-NLA

1085574-NLA

1085573-NLA

1085572-NLA

Battery Cover2

See Note(s) B See Note(s) B See Note(s) B See Note(s) B See Note(s) B

1086185-NLA

1086184-NLA

1086183-NLA

1086182-NLA

1086181-NLA

Trunk Lid3

See Note(s) B See Note(s) B See Note(s) B See Note(s) B See Note(s) B A - Decals not included. See page titled, "Packaging, Literature and Decals." B - These Shrouds are no longer available. See page titled, "Shroud Covers - After 2/29/00" for color conversion options.

NOTE:

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

See Chart Item #'s 1-3 Shroud Covers 1 11-3

1070555 Fastener, Dual Lock (5/8" Wide x 2" Long) 1 24 1070587 Washer, Flat (3/16 x 5/8 x 1/16") 1 85 1028755 Screw, Phillips Pan Head (#10-32 x 5/8") 1 86 7930332 Locknut, High Profile (#10-32) 25 17 1070594 Bushing, Rubber 1 28 1070575 Screw, Phillips Head (#10-32 x 7/8") 1 29 1050161 Screw, Hex Head Cap with Patch (5/16-18 x 1") 1 310 1088261 Bracket, Shroud, Right 1 111 1088262 Bracket, Shroud, Left 1 111 1070577 Plate, Trunk Clip 1 212 1070588 Screw, Truss Head (#10-32 x 1/2") 1 413 7930332 Locknut, High Profile (#10-32) 25 114

1088497-NLA Fastener, Panel (5/8 x 3/4" Long) 1 115

1070556 Fastener, Dual Lock (1" Wide x 2" Long) 1 216 1086186 Hardware, Side Panel Attaching 1 1A,B

A - Not Shown.

B - Includes Items 4-7 and 9-11.

NOTE:

R2 jr. (14" Wide)

Before 3/1/00

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Shroud Covers

R2 jr. (14" Wide)

After 2/29/00

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Item #'s 1-3 Shroud Covers

R2 jr. (14" Wide)

After 2/29/00

Item

Number

Description

Ocean

Blue

Emerald

Green

Liquid Black

Candy

Apple

Red

1095406-NLA

1095407

1095409

1095408

Side Panel with

Rubber Bushing

- Right

See Note(s) A See Note(s) A See Note(s) A See Note(s) A

1095410

1095411

1095413

1095412

Side Panel with

Rubber Bushing

- Left

See Note(s) A See Note(s) A See Note(s) A See Note(s) A

1095386-NLA1095387-NLA1095389-NLA1095388-NLABattery Cover2 1095402-NLA1095403-NLA1095405-NLA1095404-NLATrunk Lid3

1096905

1096906

1096908

1096907

Color Conversion

Package

See Note(s) B, C, A See Note(s) A, C, B See Note(s) A, B, C See Note(s) B, C, A A - Decals not included. See page titled, "Packaging, Literature and Decals." B - Includes Items 1-7, 9, 15. C - Not Shown.

NOTE:

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

See Chart Item #'s 1-3 Shroud Covers 1 11-3

1088497-NLA Fastener, Panel (5/8 x 3/4" Long) 1 115

1070556 Fastener, Dual Lock (1" Wide x 2" Long) 1 216 1086186 Hardware, Side Panel Attaching 1 1A,B

A - Not Shown.

B - Includes Items 4-7 and 9-11.

NOTE:

Shroud Covers

R2 jr. (14" Wide)

After 2/29/00

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Support Assemblies

Riggings Color Right Color Left Chrome Right Chrome Left

N/AN/A88810707778881070776PW93 N/AN/A88810707858881070784PW93ST N/AN/A88810707698881070768PW93E N/AN/A88810378378881037836P93M N/A

N/A

8881058647

8881058646

P904A

(14-20" W)

See Note(s) A See Note(s) A See Note(s) A See Note(s) A

1058483

1058482

N/AN/A

PAS4A/PAL4A

(14-20" W)

See Note(s) A See Note(s) A

A - Calf pads and attaching hardware not included with legrest. See page titled "Calf Pads and Attaching Harware." NOTE:

Pivot/Slide Tube with Footplate

P93M

Side

Alumunim Footplate

(Standard - 1650)

Deluxe Aluminum Footplate

(1450)

Extra Large Aluminum

Footplate

(1350)

1031928N/A105857314"W - Right 1031929N/A105857414"W - Left 10319241028892105796916-20"W - Right 10319251028893105797016-20"W - Left 1086519N/AN/A16-20"W 2" Longer - Right 1086523N/AN/A16-20"W 2" Longer - Left 1086520N/AN/A16-20"W 4" Longer - Right 1086524N/AN/A16-20"W 4" Longer - Left

NOTE: The Pivot/Slide tube mounting hardware is not included.

Front Riggings Reference Chart

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Front Riggings Reference Chart

Pivot/Slide Tube with Footplate

PW93/PW93E

Side

Aluminum Footplate

(Standard - 1650)

Deluxe Aluminum

Footplate

(1450)

Extra Large Aluminum

Footplate

(1350)

Adjustable Angle Flip-up Footplate

(AT5543)

10604441086790N/A104154214"W - Right 10604451086791N/A104154314"W - Left 106275610263951074151107414916-20"W - Right 106275710263961074152107415016-20"W - Left

N/A1086515N/A1086494

16-20"W 2" Longer -

Right

N/A1086517N/A1086497

16-20"W 2" Longer -

Left

N/A1086516N/A1086495

16-20"W 4" Longer -

Right

N/A1086518N/A1086498

16-20"W 4" Longer -

Left

NOTE: The Pivot/Slide tube mounting hardware is not included.

Pivot/Slide Tube with Footplate

PW93ST

Side

Composite Footplate

(1651)

105785916-20"W - Right 105786016-20"W - Left

NOTE: The Pivot/Slide tube mounting hardware is not included.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Front Riggings Reference Chart

Pivot/Slide Tube with Footplate

PAS4A

Side

Aluminum Footplate

(Standard - 1650)

Extra Large Aluminum Footplate

(1350)

1035454102390514"W - Right 1035455102390614"W - Left

NOTE: The Pivot/Slide tube mounting hardware is not included.

Pivot/Slide Tube with Footplate

PAL4A

Side

Aluminum Footplate

(Standard - 1650)

Extra Large Aluminum Footplate

(1350)

1035456102390716-20"W - Right 1035457102390816-20"W - Left

NOTE: The Pivot/Slide tube mounting hardware is not included.

Pivot/Slide Tube with Footplate

P904A

Side

Aluminum Footplate

(Standard - 1650)

Deluxe Aluminum Footplate

(1450)

Extra Large Aluminum

Footplate

(1350)

1058828N/A105861214"W - Right 1058829N/A105861314"W - Left 10588301028723105860416-20"W - Right 10588311028724105860516-20"W - Left 1086541N/A108652916-20"W 2" Longer - Right 1086551N/A108653116-20"W 2" Longer - Left 1086542N/A108653016-20"W 4" Longer - Right 1086552N/A108653216-20"W 4" Longer - Left

NOTE: The Pivot/Slide tube mounting hardware is not included.

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

PW93 Footrest Supports

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

PW93 Footrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1020719 Anti-Rattle, Black 1 11

47565X057 Bushing (7/32 x 3/8 x 11/32") 1 12

7930328 Screw, Phillips Pan Head (#10-32 x 11/16") 25 13 7930335 Screw, Phillips Pan Head (#10-32 x 1/2") 25 14 1035539 Handle, Release (Black) - Right 1 15 1035540 Handle, Release (Black) - Left 1 15 7930332 Locknut, High Profile (#10-32) 25 16 1028846 Rivnut (#10-32) 1 17 1028707 Spring, Release - Right 1 18 1028708 Spring, Release - Left 1 18

15680X012 Collar, Anti-Rattle (7/8") 1 19

1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 110 1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 211 7930338 Nut, Acorn (1/4-20) 25 112 1020534 Insert, Threaded 1 113

1074143 Kit, Slide Tube Mounting Hardware 1 114 8881070776 Footrest Support Assembly, Adult, Color - Right 1 1A,B 8881070777 Footrest Support Assembly, Adult, Color - Left 1 1A,B

A - Not Shown.

B - Specify frame color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

PW93E Footrest Supports

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

PW93E Footrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

15680X012 Collar, Anti-Rattle (7/8") 1 21

1027095 Plug Button, Black (7/8") 1 22

1022874 Bumper 1 13

1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 14

1035539 Handle, Release (Black) - Right 1 15

1035540 Handle, Release (Black) - Left 1 15

1025716 Screw, Phillips Pan Head (#10-32 x 11/16") 1 16

47565X057 Bushing (7/32 x 3/8 x 11/32") 1 17

1026114 Screw, Phillips Pan Head (#10-32 x 1/2") 1 18

1028707 Spring, Release - Right 1 19

1028708 Spring, Release - Left 1 19

1028846 Rivnut (#10-32) 1 110

1025735 Locknut (#10-32) 1 111

1074108 Cap, End Tube (3/4") 1 112

1020534 Insert, Threaded 1 113

1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 114

1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 115

1044214 Nut, Hex with Nylon Cap (1/4-20) 1 116

1074143 Kit, Slide Tube Mounting Hardware 1 117 8881070768 Footrest Support Assembly, Adult, Color - Right 1 1A,B 8881070769 Footrest Support Assembly, Adult, Color - Left 1 1A,B

A - Not Shown.

B - Specify frame color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

PW93ST Footrest Support

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

PW93ST Footrest Support

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

7930328 Screw, Phillips Pan Head (#10-32 x 11/16") 25 11

7930335 Screw, Phillips Pan Head (#10-32 x 1/2") 25 12

1035539 Handle, Release (Black) - Right 1 13

1035540 Handle, Release (Black) - Left 1 13

1026107 Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 1A,B

1028485-NLA Nut, Hex (#10-32) 1 1A,B

7930332 Locknut, High Profile (#10-32) 25 14

1028846 Rivnut (#10-32) 1 15

1030434 Cushion, Tubular Foam 1 16

1030435 Cover, Foam Cushion 1 17

1028707 Spring, Release - Right 1 18

1028708 Spring, Release - Left 1 18

47565X057 Bushing (7/32 x 3/8 x 11/32") 1 19 15680X012 Collar, Anti-Rattle (7/8") 1 110

1070759 Screw, Hex Head (1/4-20 x 1-1/2") 1 111

1026099 Spacer, Coved (1/4 x 11/16 x 1/2") 1 212

7930338 Nut, Acorn (1/4-20) 25 113

1020534 Insert, Threaded 1 114

1074143 Kit, Slide Tube Mounting Hardware 1 115 D

1006490 Tip, Plastic, Black 1 1A,B 8881070784 Footrest Support Assembly, Adult, Color - Right 1 1B,C 8881070785 Footrest Support Assembly, Adult, Color - Left 1 1B,C

A - These items are only required on Release Handles for chairs Before 10/1/00.

B - Not Shown.

C - Specify frame color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

D - Per Side.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

P93M Footrest Supports

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

P93M Footrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

7930359 Screw, Phillips Pan Head (#10-32 x 1/2") 25 11

7930360 Screw, Phillips Pan Head (#10-32 x 11/16") 25 12

47565X057 Bushing (7/32 x 3/8 x 11/32") 1 13

1107321 Nut, Low Cap (5/16"-24) 1 14

1027095 Plug Button, Black (7/8") 1 25

11232X009 Screw, Lug (5/16-24 x 1-3/8") 1 16

1008935 Spring, Release - Right 1 17

1008936 Spring, Release - Left 1 17

1022874 Bumper 1 18

1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 19

67005X000 Rivnut (#10-32) 1 110

7930365 Locknut (#10-32) 25 111

1035539 Handle, Release (Black) - Right 1 112

1035540 Handle, Release (Black) - Left 1 112

1006490 Tip, Plastic, Black 1 113 8881037836 Footrest Support Assembly, Adult, Color - Right 1 1A,B 8881037837 Footrest Support Assembly, Adult, Color - Left 1 1A,B

A - Not Shown.

B - Specify frame color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

P904A Legrest Supports

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

P904A Legrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1027095 Plug Button, Black (7/8") 1 11

11919X000 Screw, Truss Head (3/8-16 x 1-1/2") 1 12

1058636 Washer, Nylon (25/64 x 7/8 x 1/32") 1 23

40363X000 Hex Nut (3/8"-16) 1 14

7930330 Locknut (5/16-24) 25 15

1026030 Screw, Lug (5/16-24 x 1-3/8") 1 16 8881048851 Tube, Elevating Support (Color) - Right 1 17 A 8881048852 Tube, Elevating Support (Color) - Left 1 17 A

1027097 Plug Button, Black (3/4") 1 18 8881058664 Tube, Legrest Support (Color) - Right 1 19 A 8881058665 Tube, Legrest Support (Color) - Left 1 19 A

1022874 Bumper 1 110

1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 111 8881058646 Legrest Support Assembly w/o Pad, Adult, Color -

Right

1 1A,B

8881058647 Legrest Support Assembly w/o Pad, Adult, Color -

Left

1 1A,B

A - Specify frame color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

B - Not Shown.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

PAS4A/PAL4A Articulating Legrest Supports

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

PAS4A/PAL4A Articulating Legrest Supports

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1058478 Tube, Legrest Support, Right 1 11

1058479 Tube, Legrest Support, Left 1 11

1027097 Plug Button, Black (3/4") 1 12

40363X000 Hex Nut (3/8"-16) 1 33

1022854 Screw, Slotted Head Shoulder (1/2 x 1-1/8") 1 14

1022877 Tube Support and Drive Link - Right 1 15

1022878 Tube Support and Drive Link - Left 1 15

1022848 Slide Tube, Articulating (Chrome) - Right 1 16

1022849 Slide Tube, Articulating (Chrome) - Left 1 16

1027377 Washer (#20) 1 17

7930363 Package, Locknut (5/16"-24) 25 18

11232X009 Screw, Lug (5/16-24 x 1-3/8") 1 19

1022866 Screw, Socket Button Head (3/8-16 x 3/4") 1 210

1049527 Washer, Nylon (3/8 x 3/4 x 1/16") 1 211

1022846 Bar, Link, Chrome 1 112

1058482 Legrest Support, Articulating (Chrome) - Right 1 1A

1058483 Legrest Support, Articulating (Chrome) - Left 1 1A

A - Not Shown.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Legrest Release Handle and Ratchet

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Legrest Release Handle and Ratchet

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

7930328 Screw, Phillips Pan Head (#10-32 x 11/16") 25 11

7930335 Screw, Phillips Pan Head (#10-32 x 1/2") 25 12

1026107 Screw, Phillips Pan Head (#10-32 x 1-3/8") 1 13 A

1028485-NLA Nut, Hex (#10-32) 1 14 A

1035539 Handle, Release (Black) - Right 1 15

1035540 Handle, Release (Black) - Left 1 15

1006490 Tip, Plastic, Black 1 16 A

47565X057 Bushing (7/32 x 3/8 x 11/32") 1 17

1028707 Spring, Release - Right 1 18

1028708 Spring, Release - Left 1 18

7930332 Locknut, High Profile (#10-32) 25 19

1028846 Rivnut (#10-32) 1 110

1040060 Tip, Black Plastic 1 111

7930310 Washer, Nylon (5/16 x 11/16 x 1/16") 25 112

42326X004 Bar, Ratchet - Right/Left 1 113 B

1023811 Bar, Ratchet - Right 1 113 C

1023812 Bar, Ratchet - Left 1 113 C

47330X003 Spacer (5/16 x 1/2 x 3/8") 2 214

1040831 Snap Ring 1 115

1037125 Cam, Legrest 1 116

1037485 Spring, Release 1 117

7930336 Nut, Acorn (5/16-24) 25 118

04528X002 Bracket, Release (Chrome) 1 119

1037126 Handle, Release 1 120

A - These items are only required on Release Handles for chairs built before 10/1/00.

B - 904 Legrest.

C - Articulating Legrest.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Calf Pads and Attaching Hardware

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Calf Pads and Attaching Hardware

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

88804529X003 Pad, Legrest Vinyl - Right 1 11 A,B 88804529X004 Pad, Legrest Vinyl - Left 1 11 A,B

8881091759 Pad w/Cover and Screws, Legrest Vinyl (Pair) 2 11 A,C,D 8881091764 Pad, Legrest Vinyl - Right/Left 1 11 A,C,E

01415X000-NLA Cover, Legrest Pad 1 11

04526X019 Plate, Legrest Pad 1 12

7930330 Locknut (5/16-24) 25 13

1025133 Spacer, Legrest Pad 1 14

1032267 Spacer, Legrest Pad Mounting 1 15

1037110 Screw, Hex Head (5/16-24 x 3-1/2") 1 16

1028514 Screw, Hex Head (5/16-24 x 1-1/2") 1 17

1066591 Screws, Phillips Head (#10-32 x 11/16") 2 18

48823X008 Spring, Leaf 1 19

7930363 Package, Locknut (5/16"-24) 25 110

1025104 Bracket, Legrest (Chrome) 1 111

1014807 Screw, Hex Head (5/16-24 x 3-1/4") 1 112

1032266 Bracket, Legrest Pad Mounting 1 113

A - Specify upholstery color when ordering. See page titled, "Frame Finishes, Touch-Up Paint and Upholstery Options."

B - 14" Wide - R2 jr.

C - 16-20" Wide.

D - Before 9/5/00.

E - After 9/4/00.

NOTE:

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Pivot/ Slide Tube and Footplate

PW93, PW93E

NOTE: Heel loops are not included. See page titled "Footrest and Legrest Accessories".

NOTE: For complete pivot/slide tube and footplate assemblies, see page titled "Front Riggings Reference

Chart".

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Pivot/ Slide Tube and Footplate

Item

Number

Part Number

DescriptionNote

Quantity Per

Package Assembly

1027097 Plug Button, Black (3/4") 1 11

1048834 Pivot/Slide Tube with Plug Button 1 12 A,B

1070762 Pivot/Slide Tube with Plug Button, Deluxe Aluminum 1 12 C

1098906 Pivot/Slide Tube with Plug Button - 2" Longer 1 12 B,C

1086482 Pivot/Slide Tube with Plug Button - 4" Longer 1 12 B,C

44200X059 Footplate, Aluminum - Small (6-3/4" W x 6" L) 1 13 D 44200X027 Footplate, Aluminum - Medium (7-3/4" W x 6" L) 1 13

1043659 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -

Right

1 13

1043660 Footplate, Aluminum - Deluxe (8" W x 5-3/4" L) -

Left

1 13

1002343 Footplate, Aluminum - Extra Large (7" W x 8-1/2" L)

- Right

1 13 D

1002344 Footplate, Aluminum - Extra Large (7" W x 8-1/2" L)

- Left

1 13 D

44200X025 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)

- Right

1 13

44200X026 Footplate, Aluminum - Extra Large (8" W x 8-1/2" L)

- Left

1 13

1016346 Cap, Tube End (7/8") 1 14 B

1027095 Plug Button, Black (7/8") 1 14 A

1006981 Spring, Leaf 1 15 B

1036120 Spring 1 25 C

1036123 Spring, Leaf 1 15 A

40120X001 Screw, Phillips Pan Head (#8-32 x 3/8") 1 16

1070168 Push Plug, Footplate 1 17

A - Extra Large Aluminium Footplate

B - Standard Aluminium Footplate

C - Deluxe Aluminium Footplate

D - 14" Wide (R2jr.)

NOTE:

PW93, PW93E

NOTE: Heel loops are not included. See page titled "Footrest and Legrest Accessories".

NOTE: For complete pivot/slide tube and footplate assemblies, see page titled "Front Riggings Reference

Chart".

Form No.

98-289

To order call toll free 1-800-333-6900, or www.invacare.com

Invacare R2 jr, Ranger II, Excel User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
