Page 1

Invacare

Infinity

™

Series Seating Products

Invacare

Infinity™Series

Seating Products

Page 2

Modifications

RLW, LLD

• Removable Leg Wedges (RLW) are foam wedges

which are easily removed to accommodate hamstring tightness or facilitate foot propulsion

• Leg Length discrepancies can be

accommodated with the LLD option, available on all Infinity cushions

*Option available December, 2002.

Invacare

Infinity

™

Series Cushions

Invacare®AirFlo™Cushion

AIR

• An excellent choice for

those with a history of, or considered to be at very high risk of developing skin breakdown

• Air flotation insert

inflates to provide optimal immersion of sensitive bony prominences

• Postural support layer provides support and

stability to the legs, assists in pressure redistribution and reduces shear due to sliding

• User-friendly inflation bulb allows one-handed

adjustment of inflation level, while quickdisconnection system seals air instantly when detached

• Moisture-proof, antimicrobial inner cover

protects foam, and highly stretchable outer cover provides maximum conformity to user’s shape

Lo, Gentle or Max Contour

ILC, IGC, IMC

• Choice of three contour options - Lo, Gentle or Max

• Lo Contour (LC) features non-contoured front end for very

active users or to accommodate “windswept” deformities

• Gentle Contour (GC) designed with mild abductor/adductor

contouring that helps provide neutral leg positioning

• Max Contour (MC) provides aggressive leg positioning and

enhanced pressure redistribution

Lo Contour.

FloGel.

ViscoFoam.

Max Contour.

Adjustable Pelvic Obliquity (APO).

AirFlo.

Removable Leg Wedge (RLW).

Gentle Contour.

Invacare®Infinity™Series: Versatile modular seating providing optimal rehab solutions.

t the heart of Infinity seating is a concept called Personal Product

Matching (PPM), which means that the highly versatile Infinity cushions are designed to meet not only an individual's clinical needs, but also accommodate personal seating preferences and lifestyle needs. The cushions offer three choices of pressure reduction support media combined with three contour choices, providing high-end skin protection and excellent support and positioning.

ViscoFoam*and FloGel*Cushions NEW

VF, FG

• Designed to provide high-end protection

for individuals considered to be at risk of developing skin breakdown

• Choice of FloGel or ViscoFoam molded into

ishial relief area to provide conformity to sensitive bony prominences

• Molded, viscoelastic foam Pelvic Support

Layer supports the hips and helps redistribute forces away from critical areas

• Adjustable pelvic obliquity (APO)

comes standard on all VF and FG cushions, allowing the pelvic support layer to be shifted within the postural support layer in order to accomodate or correct mild to moderate pelvic obliquities

• Postural support layer features choice of

contour for leg positioning and pre-ischial shelf to help control sliding

• Complete with moisture-proof, antimicrobial

inner cover and waterproof, breathable outer cover

Page 3

Quick Set™Hardware

• State-of-the-art Quick

Set

™

hardware allows installation and adjustment of the UniBack10 and DualFlex10 in under 10 minutes!

• Depth, recline and

hinge angle adjustments can be made to the back while user is seated

• Single hardware attachment point on wheelchair

back canes provides ease of installation and improved aesthetics

• One-hand, pull release cord/snap-on latch for

user-friendly portability

Invacare

Infinity

™

Series Backs

Invacare®DualFlex™10/UniBack™10

• Infinity™DualFlex™10 and UniBack™10 are formed

by two distinct support panels: the sacral panel and the thoracic panel (available in short 14", regular 16" or tall 19" heights)

• UniBack10 panels attach with a solid plate,

creating a single, straight back support

• DualFlex10 panels attach with a biangular

hinge, allowing adjustability to accommodate an infinite range of body positions - lordotic through kyphotic

• DualFlex10 hinges incorporate an elastomer,

providing dynamic “flex”to provide ease of upper-body mobility, facilitating wheelchair propulsion and helping prevent sliding due to tone

• All Infinity Backs are width adjustable, allowing

three sizes (small, medium and large) the flexibility to fit nine wheelchair widths 14" to 22"

nfinity™Backs can be configured an infinite number of ways to provide

support, stability and precise fit for a wide range of body sizes and types. They feature a highly modular design that allows a myriad of options to be created using only a few components. The backs are designed to provide outstanding support for users with a wide range of clinical needs, and are very easily adapted for growth and change. All of this in a comfortable, attractive backrest that can be installed and fitted to the client in under 10 minutes!

Mild, Max and Mixed Contour

• UniBack™10 and DualFlex™10 backs

come standard with width, height and angle-adjustable Pelvic Stabilizers and Lateral Supports

• Choice of Mild Contour for gentle

support, deeper Max Contour for more aggressive midline positioning, or Mixed Contour for a combination of Mild and Max Contour supports.

• Adjustable Laterals and Pelvic

Stabilizers provide an intimate fit to the shape of each individual, even those with postural asymmetries

• Growth and change are easily

accommodated through repositioning of Laterals and Pelvic Stabilizers

DualFlex™10. UniBack™10.

Invacare®LoBack

• 9" high back support complete with

mild or max contour pelvic stabilizers gives outstanding support to the lower pelvis for comfortable, balanced posture

• Depth-, height-, angle-adjustable

hardware allows precise placement within the wheelchair frame, optimizing users center of gravity and complimenting their active lifestyle

• Lightweight, attractive and portable

• Includes removable "modesty flap"

which helps keep the seat cushion securely in place

Page 4

Invacare Corporation

www.invacare.com

USA

One Invacare Way Elyria, Ohio 44035-4190 (800) 333-6900

Canada

570 Matheson Blvd. E. Unit 8 Mississauga, Ontario L4Z 4G4 Canada (800) 668-5324

Invacare is a registered trademark and AirFlo, DualFlex, DualFlex10, UniBack, UniBack10, Quick Set, Infinity, and Yes, you can. are trademarks of Invacare Corporation. Specifications are subject to change without notification.

Form No. 01-339 Rev. 10/02

Accessories and Options

ADJUSTABLE HEADRESTS

Model no. A) HR02S;B) HR03S;C) HR04S; D) HR01S

• Contoured head and neck

supports available in four styles

• Dual-ball swivel hardware

for multi-plane adjustment

• Durable steel reinforced

polyurethane pads - easily wiped clean

HEADREST ADAPTER

Model no. UHC, WHC

• Universal Headrest Clamp

(UHC) and Whitmyer Headrest Clamp(WHC) available to provide easy attachment of Invacare and some Whitmyer headrests

- no drilling required

• UHC and WHC mount

inside spinal relief area of UniBack10 and DualFlex10 backs for low profile and attractive attachment of headrests

BASIC HEADREST

Model no. BSNC, BSNA

• Padded to provide

comfortable occipital support

• Horizontal and vertical

adjustable hardware

• Outer cover easily removed

for laundering

Seat Accessories

Belts and Straps

CUSHION RIGIDIZER

Model no. CR

• Molded plastic solid seat

insert, very lightweight with slim profile

• Eliminates hammock effect

of sling upholstery

• Securely attaches to the

bottom of the cushion inside the cover

INFINITY™DROP BASE

Model no. IDB

• Width adjustable: Three

sizes fit wheelchairs from 14" to 22" wide

• Height-, angle-adjustable:

Up to 2" of drop provided

• Portable quick-release

hardware allows easy removal of base from wheelchair

BELTS AND STRAPS

A) SSSM, SSMD, SSLG

• Three sizes of shoulder

supports fit child, junior and adult

B) BPSSM, BPSMD, BPSLG

• Three sizes of padded lap

belts fit child, junior and adult - Pinch release buckles

C) SB05

• Push-button style release

provides secure attachment

D) 4PTSM, 4PTMD, 4PTLG

• Three sizes of four-point lap

belt to fit child junior and adult - Push button release buckle

FULL TRAY - HOOK AND LOOP MOUNT

Model no. LTACL, LTCCL

• Nearly unbreakable clear

polycarbonate tray surface

• Easily attaches to chair

armrest with hook and loop straps

• Removable trim allows

thorough cleaning

FULL TRAY - SLIDE-ON MOUNT

Model no. LT02A

• Nearly unbreakable clear

polyester resin tray surface

• Width adjustable

mounting hardware securely fastens tray to chair arm pads

• Molded-in rim helps keep

items on tray

HALF TRAY SWINGAWAY

Model no. LTUL, LTUR

• Nearly unbreakable clear

polycarbonate tray surface

• Tray securely bolts to

wheelchair armrest

• Tray easy to swing away

when not in use

Lap Trays

Headrests

‘‘Invacare says ‘Yes, you can™,’ and I couldn’t have said it better myself.’’
