Invacare HMV Highly 400, HMV Highly 300 User Manual

Owner’s Operator and Maintenance Manual
HMV™Highly
Maneuverable Vehicle
300 and 400
DEALER: This manual MUST be given to the user of the scooter.
USER:
manual and save for future reference.
BEFORE using this scooter, read this
For more information regarding
Invacare products, parts, and services,
WARNING
POWERED SCOOTER USERS: DO NOT SERVICE OR OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND UNDERSTANDING THE OWNER’S OPERATOR AND MAINTENANCE MANUAL. IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS, CAUTIONS, AND INSTRUCTIONS, CONTACT INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR OPERATE THIS EQUIPMENT - OTHERWISE INJURY OR DAMAGE MAY RESULT.
PROCEDURES OTHER THAN THOSE DESCRIBED IN THIS MANUAL MUST
DEALERS AND QUALIFIED TECHNICIANS: DO NOT SERVICE OR OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND UNDERSTANDING (1) THE OWNER’S OPERATOR AND MAINTENANCE MANUAL AND (2) THE SERVICE MANUAL (IF APPLICABLE). IF YOU ARE UNABLE TO UNDERSTAND THE
BE PERFORMED BY A QUALIFIED TECHNICIAN.
WARNINGS, CAUTIONS AND INSTRUCTIONS, CONTACT INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR OPERATE THIS EQUIPMENT - OTHERWISE, INJURY OR DAMAGE MAY RESULT.
NOTE: Updated versions of this manual are available on www.invacare.com.
300 and 400 2 Part No. 1118395
TABLE OF CONTENTS
TABLE OF CONTENTS
REGISTER YOUR PRODUCT................................................................ 6
SPECIAL NOTES ................................................................................ 9
TYPICAL PRODUCT PARAMETERS .................................................. 10
LABEL LOCATIONS ......................................................................... 11
On 300 ........................................................................................................................................................11
On 400 ........................................................................................................................................................12
SECTION 1—GENERAL GUIDELINES ................................................. 13
Repair or Service Information ...............................................................................................................13
Operation Information............................................................................................................................13
Tire Pressure .............................................................................................................................................15
Electrical .....................................................................................................................................................15
Grounding Instructions.......................................................................................................................16
Batteries......................................................................................................................................................16
Rain Test.....................................................................................................................................................16
Weight Training ........................................................................................................................................16
Weight Limitation.....................................................................................................................................17
SECTION 2—EMI INFORMATION ..................................................... 18
SECTION 3—SAFETY/HANDLING OF POWERED SCOOTERS ................ 20
Stability and Balance.................................................................................................................................20
Percentage of Weight Distribution ......................................................................................................20
Stairways.....................................................................................................................................................21
Escalators....................................................................................................................................................21
SECTION 4—SAFETY INSPECTION ................................................... 22
Safety Inspection Checklists...................................................................................................................22
Inspect/Adjust Initially .........................................................................................................................22
Inspect/Adjust Weekly........................................................................................................................23
Inspect/Adjust Monthly.......................................................................................................................23
Inspect/Adjust Every Six (6) Months ...............................................................................................23
Inspect/Adjust Periodically.................................................................................................................24
SECTION 5—MAINTENANCE AND TROUBLESHOOTING ................... 25
Suggested Maintenance Procedures .....................................................................................................25
Lubrication Points.....................................................................................................................................25
Troubleshooting........................................................................................................................................26
SECTION 6—OPERATION OF THE POWERED SCOOTER ..................... 27
Control Panel ............................................................................................................................................27
300 and 400 3 Part No. 1118395
TABLE OF CONTENTS
TABLE OF CONTENTS
Operating the Scooter ............................................................................................................................30
Brake Release Lever.................................................................................................................................31
Resetting the Circuit Breaker................................................................................................................32
Replacing the Fuse....................................................................................................................................33
SECTION 7—SEAT ........................................................................... 34
Removing/Installing the Seat...................................................................................................................34
Removing ...............................................................................................................................................34
Installing..................................................................................................................................................34
Removing/Installing the Seat Post .........................................................................................................35
Removing ...............................................................................................................................................35
Installing..................................................................................................................................................35
Adjusting Seat Height...............................................................................................................................36
Adjusting Seat Depth ...............................................................................................................................36
90° Seat Swivel Adjustment ...................................................................................................................37
Removing/Installing Seat Positioning Strap .........................................................................................38
SECTION 8—ARMS ......................................................................... 40
Removing/Installing/Adjusting Arms .....................................................................................................40
Removing/Installing ..............................................................................................................................40
Adjusting Arm Width..........................................................................................................................40
Adjusting Arm Angle ...........................................................................................................................41
Adjusting Arm Height .........................................................................................................................41
Replacing Armrest Pads ..........................................................................................................................42
SECTION 9—TILLER ADJUSTMENT ................................................... 43
Adjusting the Tiller Angle .......................................................................................................................43
SECTION 10—REAR SHROUD .......................................................... 44
Removing/Installing the Rear Shroud ...................................................................................................44
Removing ...............................................................................................................................................44
Installing .................................................................................................................................................44
SECTION 11—WHEELS AND CASTERS .............................................. 45
Removing/Installing the Drive Wheels ................................................................................................45
Removing ..............................................................................................................................................45
Installing..................................................................................................................................................45
Removing/Installing the Front Wheel ..................................................................................................47
Removing ...............................................................................................................................................47
Installing .................................................................................................................................................47
Part No. 1118395 4 300 and 400
TABLE OF CONTENTS
TABLE OF CONTENTS
Removing/Installing the Caster Assemblies ........................................................................................48
Removing ...............................................................................................................................................48
Installing..................................................................................................................................................48
SECTION 12—BATTERIES ................................................................ 49
Recommended Battery Type .................................................................................................................50
Removing/Installing the Batteries on 300............................................................................................50
Removing ...............................................................................................................................................51
Installing..................................................................................................................................................51
Removing/Installing the Batteries on 400............................................................................................53
Removing ...............................................................................................................................................53
Installing..................................................................................................................................................53
Connecting/Disconnecting the Battery Cables on the 400 ............................................................55
Connecting ............................................................................................................................................55
Disconnecting .......................................................................................................................................56
Charging the Batteries.............................................................................................................................58
On-Board Battery Charger................................................................................................................58
Battery Charger Operation - Charger Indicator Light on Tiller...............................................59
SECTION 13—TRANSPORTING ........................................................ 60
Transporting the Scooter .......................................................................................................................60
300...........................................................................................................................................................60
Disassembling ................................................................................................................................. 60
Assembling ...................................................................................................................................... 60
400...........................................................................................................................................................61
Disassembling ................................................................................................................................. 61
Assembling ...................................................................................................................................... 62
SECTION 14—SCOOTER ACCESSORIES ............................................. 64
Removing/Installing the Front Basket...................................................................................................64
Installing/Removing the Crutch/Cane Holder....................................................................................65
Installing..................................................................................................................................................65
Removing ...............................................................................................................................................65
Installing/Removing the Safety Flag .......................................................................................................66
Installing..................................................................................................................................................66
Removing ...............................................................................................................................................66
Installing/Removing/Using the Walker Holder .................................................................................66
Installing/Removing the Walker Holder .........................................................................................67
Using the Walker Holder...................................................................................................................67
300 and 400 5 Part No. 1118395
REGISTER YOUR PRODUCT
Installing/Removing the Rear Mounted Basket ..................................................................................68
Installing..................................................................................................................................................68
Removing ...............................................................................................................................................68
LIMITED WARRANTY ..................................................................... 71
REGISTER YOUR PRODUCT
The benefits of registering:
1. Safeguard your investment.
2. Ensure long term maintenance and servicing of your purchase.
3. Receive updates with product information, maintenance tips, and industry news.
4. Invacare can contact you or your provider, if servicing is needed on your product.
5. It will enable Invacare to improve product designs based on your input and needs.
Register ONLINE at www.invacare.com
- or -
Complete and mail the form on the next page
Any registration information you submit will be used by Invacare Corporation only, and
protected as required by applicable laws and regulations.
300 and 400 6 Part No. 1118395
PRODUCT REGISTRATION FORM
Register ONLINE at www.invacare.com - or -
Complete and mail this form
Name_______________________________________________________________
Address _____________________________________________________________
City ___________________State/Province __________
Zip/Postal Code ________
Email ___________________________________Phone No. _________________
Invacare Model No. ______________________ Serial No. __________________
Purchased From _________________________Date of Purchase:___________
1. Method of purchase: (check all that apply) Medicare Insurance Medicaid Other __________________________
2. This product was purchased for use by: (check one) Self Parent Spouse Other
3. Product was purchased for use at: Home Facility Other
4. I purchased an Invacare product because:
Cut Along Line
Price Features (list features) _________________________________________
5. Who referred you to Invacare products? (check all that apply)
Doctor Therapist Friend Relative Dealer/Provider Other_________Advertisement (circle one): TV, Radio, Magazine, Newspaper No Referral_____
6. What additional features, if any, would you like to see on this product?
7. Would you like information sent to you about Invacare products that may be available for a
__________________________________________________________________________
particular medical condition? Yes No If yes, please list any condition(s) here and we will send you information by email and/or mail about any available Invacare products that may help treat, care for or manage such condition(s):
__________________________________________________________________________
Fold here
Fold here
8. Would you like to receive updated information via email or regular mail about the Invacare home medical products sold by Invacare's dealers? Yes No
9. What would you like to see on the Invacare website?
__________________________________________________________________________
10. Would you like to be part of future online surveys for Invacare products? Yes No
11. User's Year of birth: ______________________________________________________
If at any time you wish not to receive future mailings from us, please contact us at Invacare Corporation, CRM Department, 39400 Taylor Parkway, Elyria, OH 44035, or fax to 877-619-7996 and we will remove you from our mailing list.
To find more information about our products, visit www.invacare.com.
Fold
here
Fold
here
Cut Along Line
Invacare Product Registration Form
Please Seal with
Tape Before Mailing
SPECIAL NOTES
SPECIAL NOTES
WARNING/CAUTION notices as used in this manual apply to hazards or unsafe practices which could result in personal injury or property damage.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE.
As a manufacturer of powered scooters, Invacare endeavors to supply a wide variety of powered scooters to meet many needs of the end user. However, final selection of the type of powered scooter to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.
TIE-DOWN RESTRAINTS AND SEAT RESTRAINTS
Powered scooter users should NOT be transported in vehicles of any kind while in the powered scooter. As of this date, the Department of Transportation has not approved any tie-down systems for transportation of a user while in a powered scooter, in a moving vehicle of any type.
It is Invacare’s position that users of powered scooters should be transferred into appropriate seating in vehicles for transportation and use be made of the restraints made available by the auto industry. Invacare cannot and does not recommend any powered scooter transportation systems.
SEAT POSITIONING STRAP
It is the obligation of the Dealers, Therapists and other Healthcare Professionals to determine if a seating restraint is required to ensure the safe operation of this equipment by the user. Serious injury can occur in the event of a fall from a powered scooter.
The seat positioning strap is a positioning belt ONLY. It is not designed for use as a safety device withstanding high stress loads such as auto or aircraft safety belts. If signs of wear appear, belt must be replaced immediately.
Part No. 1118395 9 300 and 400
TYPICAL PRODUCT PARAMETERS
TYPICAL PRODUCT PARAMETERS
300 400
OVERALL DIMENSIONS*
BASE LENGTH: BASE WIDTH: STEP HEIGHT (Floor Pan to Ground): SEAT HEIGHT (Floor Pan to Seat Cushion):
SEAT DIMENSIONS
WIDTH: DEPTH: BACK HEIGHT:
ARM DIMENSIONS
LENGTH: HEIGHT BETWEEN SEAT AND ARMS: WIDTH BETWEEN ARMS:
SPEED RANGE 0 - 4.5 m.p.h.
MAXIMUM WEIGHT LIMITATION 300 lbs 400 lbs
16 inches 18 inches
16, 17, 18 in. 16, 17, 18 in.
15 inches 17 inches
16 in. seat — 16-22 inches 18 in. seat — 18-24 inches
(Factory setting - 3.5 m.p.h.)
44 inches
22.5 inches
3.5 inches
17-19 inches
18 inches 20 inches
16, 17, 18 in. 18, 19, 20 in.
17 inches 19 inches
13 inches
7- 9 inches
18 in. seat — 18-24 inches 20 in. seat — 20-26 inches
(Factory setting - 5.5 m.p.h.)
46 inches 24 inches
4.5 inches
17-19 inches
13 inches
7- 9 inches
0 - 5.5 m.p.h.
MAXIMUM INCLINE CAPABILITY 8° Grade 8° Grade
WHEELS
FRONT WHEEL: DRIVE WHEEL: REAR CASTER:
TURNING RADIUS 29 inches 32 inches
WEIGHT OF PRODUCT
FRONT BASE SECTION (WITH BASKET): REAR BASE SECTION (WITH SHROUDS): ENTIRE BASE SECTION: SEAT (WITH ARMS): BATTERIES (QUANTITY - 2):
TOTAL WEIGHT OF PRODUCT:
(Including Batteries)
7 inches x 2 inches 8 inches x 3 inches
1 inch x 5 inches
N/A
N/A 71 lbs 31 lbs 18 lbs
120 lbs 185lbs
8 inches x 2 inches
10 inches x 3 inches
1 inch x 5 inches
53 lbs 48 lbs
38 lbs 46 lbs
*NOTE: 300 parameters are based on an 18-inch wide seat.
*NOTE: 400 parameters are based on an 20-inch wide seat.
300 and 400 10 Part No. 1118395
ON 300
LABEL LOCATIONS
LABEL LOCATIONS
NOTE: Warning Label 1118359 is located under the rear shroud.
! WARNING
Pinch Point.
1079203
NOTE: Warning Label 1079203 is also located on the other swingarm.
DO NOT operate the scooter unless the tiller is in the locked position.
DO NOT lean against or pull forward on the tiller while mounting or dismounting the scooter. Otherwise, injury may occur.
-------------------------------------------------------------------------------------------­DO NOT lift scooter up by the front or rear shroud. Otherwise injury or damage to the scooter may occur.
1118373 Rev A
Scooter Frame Assembly
Part No. 1118395 11 300 and 400
LABEL LOCATIONS
DO NOT operate the scooter unless the tiller is in the locked position.
DO NOT lean against or pull forward on the tiller while mounting or dismounting the scooter. Otherwise, injury may occur.
-------------------------------------------------------------------------------------------­DO NOT lift scooter up by the front or rear shroud. Otherwise injury or damage to the scooter may occur.
1118373 Rev A
! WARNING
Pinch Point.
1079203
! WARNING
Pinch Point.
1079203
ON 400
NOTE: Warning Label 1125362 is located under the rear shroud.
Rear Frame Assembly
Front Frame Assembly
300 and 400 12 Part No. 1118395
SECTION 1—GENERAL GUIDELINES
SECTION 1—GENERAL GUIDELINES
WARNING
SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and use of this product. DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as Owner’s Manuals, Service Manuals or Instruction Sheets supplied with this product or optional equipment. If you are unable to understand the Warnings, Cautions or Instructions, contact a healthcare professional, dealer or technical personnel before attempting to use this equipment - otherwise, injury or damage may occur.
REPAIR OR SERVICE INFORMATION
Set-up of the Electronic Control Unit is to be performed ONLY by individuals certified by Invacare. The final tuning adjustments of the controller may affect other activities of the powered scooter. Damage to the equipment could occur under these circumstances. If non-certified individuals perform any work on these units, the warranty is void.
DO NOT service or adjust your powered scooter while occupied, unless otherwise noted.
OPERATION INFORMATION
For safe product function, material compatibility, proper installation, operation and maintenance, you MUST only use parts, accessories and adapters manufactured or supplied by Invacare. DO NOT use any other parts, accessories, or adapters. Otherwise the warranty is void.
Performance adjustments should only be made by professionals of the healthcare field or persons fully conversant with this process and the driver's capabilities. Incorrect settings could cause injury to the driver, bystanders and damage to the chair and to surrounding property.
BEFORE using the scooter, verify that the motor is plugged into the harness.
DO NOT connect any medical devices such as ventilators, life support machines, etc., to the battery. This could cause unexpected failure of the device and the powered scooter.
DO NOT operate the powered scooter until you have checked that the surroundings are clear and that the area is safe for travel.
DO NOT make sharp turns in the FORWARD or REVERSE direction at excessive speed. Failure to observe the warning can cause the scooter to tip over and may result in injury to user and/or damage to the product.
DO NOT operate on roads, streets or highways.
DO NOT attempt to move up or down an incline with water, ice or oil film.
For 300 only, avoid operating the scooter in dark or poorly lit areas.
Part No. 1118395 13 300 and 400
SECTION 1—GENERAL GUIDELINES
DO NOT climb and/or go UP or DOWN ramps or traverse slopes greater than 8°.
When negotiating ramps, if the throttle control lever is released while in the FORWARD motion, the powered scooter will roll back approximately one (1) foot before the brake engages. If the throttle control lever is released while in the REVERSE motion, the powered scooter will roll back approximately three (3) feet before the brake engages.
DO NOT attempt to drive over curbs or obstacles. Doing so may cause your powered scooter to turn over and cause bodily harm and/or damage to the scooter.
DO NOT use an escalator to move a powered scooter between floors. Serious bodily injury may occur.
Powered scooter without the batteries can weigh between 90 to 200 lbs (depending on the model). Use proper lifting techniques (lift with your legs) to avoid injury.
Before attempting to sit in or exit the powered scooter, remove the key from the ignition. This will ensure that the power is off and the powered scooter will not drive.
DO NOT remove the key or shut off while the powered scooter is in motion.
Remove the key from the ignition while the powered scooter is not in use so as to avoid injury and/or damage to the scooter and surrounding areas.
DO NOT attempt to lift the powered scooter by any removable (detachable) parts. Lifting by means of any removable (detachable) parts of a powered scooter may result in injury to the user or damage to the powered scooter.
DO NOT attempt to lift the powered scooter by its tiller, seat or shrouds.
DO NOT stand on the frame of the powered scooter.
DO NOT stand on the shroud(s) of the powered scooter.
The rear shroud is designed to cover the batteries, controller, harness, motor connections and transaxle. DO NOT operate the powered scooter without the rear shroud installed, to avoid injury and/or damage to scooter.
On 400 only - BEFORE use, ensure that the frame lock lever is in the LOCKED position securing the front and rear frame assemblies together. Otherwise injury and/or damage may occur.
DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching between your knees.
DO NOT lean over the top of the back upholstery to reach objects from behind, as this may cause the powered scooter to tip over.
DO NOT shift your weight or sitting position toward the direction you are reaching as the powered scooter may tip over.
For individuals with balance problems, DO NOT attempt to transfer into or out of the powered scooter without assistance. Practice transferring activities with an assistant in the presence of a qualified healthcare professional.
Ensure that the seat is properly locked before use. Otherwise that user may fall from the scooter resulting in bodily harm. Attempting unsafe transfers may cause the user to fall, resulting in serious injury.
300 and 400 14 Part No. 1118395
SECTION 1—GENERAL GUIDELINES
Ensure that the seat is locked in the FORWARD position before and during the operation of the scooter. Otherwise, injury to the user and/or damage to the scooter may result.
DO NOT adjust the seat position outside the specifications recommended by the manufacturer.
Ensure that the tiller is properly adjusted before driving the scooter.
After making any tiller angle adjustment and before use, the tiller must be securely locked into position. Otherwise that user may fall from the scooter resulting in bodily harm and/ or damage to the scooter. Gently push/pull the tiller to ensure that the tiller is securely engaged.
DO NOT overtighten hardware attaching to the frame. This could cause damage to the frame tubing.
Do determine and establish your particular safety limits by practicing bending, reaching and transferring activities in the presence of a qualified healthcare professional BEFORE attempting active use of the powered scooter.
ALWAYS DO keep hands and fingers clear of moving parts to avoid injury.
ALWAYS DO wear your seat positioning strap.
The seat positioning strap is a positioning belt ONLY. It is not designed for use as a safety device withstanding high stress loads such as auto or aircraft safety belts. If signs of wear appear, belt must be replaced immediately.
ALWAYS DO check hand grips for looseness before using the powered scooter. If loose and/or worn, replace immediately.
Avoid storing or using the scooter near external flame or combustible products. Serious injury or damage to property may result.
TIRE PRESSURE
DO NOT use your powered scooter unless it has the proper tire pressure (P.S.I.). DO NOT overinflate the tires. Failure to follow these recommendations may cause the tire to explode and cause bodily harm. The recommended tire pressure is listed on the side wall of the tire.
ELECTRICAL
Check to ensure that all electrical connections are secure at all times.
Part No. 1118395 15 300 and 400
SECTION 1—GENERAL GUIDELINES
GROUNDING INSTRUCTIONS
DO NOT, under any circumstances, cut or remove the round grounding prong from any plug used with or for Invacare products. Some devices are equipped with three-prong (grounding) plugs for protection against possible shock hazards. Where a two-prong wall receptacle is encountered, it is the personal responsibility and obligation of the customer to contact a qualified electrician and have the two-prong receptacle replaced with a properly grounded three-prong wall receptacle in accordance with the National Electrical Code. If you must use an extension cord, use ONLY a three-wire extension cord having the same or higher electrical rating as the device being connected. In addition, Invacare has placed RED/ORANGE WARNING TAGS on some equipment. DO NOT remove these tags.
BATTERIES
The warranty and performance specifications contained in this manual are based on the use of deep cycle gel cell batteries. Invacare strongly recommends their use as the power source for this unit.
Carefully read battery/battery charger information prior to installing, servicing or operating your powered scooter.
RAIN TEST
INVACARE has tested its powered scooters in accordance with ISO 7176 “Rain Test”. This provides the end user or his/her attendant sufficient time to remove his/her power powered scooter from a rain storm and retain powered scooter operation.
DO NOT leave the powered scooter in a rain storm of any kind.
DO NOT use the powered scooter in a shower.
DO NOT leave the powered scooter in a damp area for any length of time.
Direct exposure to rain or dampness will cause the scooter to malfunction electrically and mechanically; may cause the wheelchair to prematurely rust.
Check to ensure that the battery covers are secured in place and that all electrical connections are secure at all times.
WEIGHT TRAINING
Invacare DOES NOT recommend the use of its powered scooters as a weight training apparatus. Invacare powered scooters have NOT been designed or tested as a seat for any kind of weight training. If occupant uses said powered scooter as a weight training apparatus, INVACARE SHALL NOT BE LIABLE FOR BODILY INJURY AND THE WARRANTY IS VOID.
300 and 400 16 Part No. 1118395
SECTION 1—GENERAL GUIDELINES
WEIGHT LIMITATION
The weight limitation for the 300 is 300 lbs.
The weight limitation for the 400 is 400 lbs.
If so equipped, the front basket is rated for a maximum loading capacity of 10 lbs.
Part No. 1118395 17 300 and 400
SECTION 2—EMI INFORMATION
SECTION 2—EMI INFORMATION
WARNING
CAUTION: IT IS VERY IMPORTANT THAT YOU READ THIS INFORMATION REGARDING THE POSSIBLE EFFECTS OF ELECTROMAGNETIC INTERFERENCE ON YOUR POWERED WHEELCHAIR.
Electromagnetic Interference (EMI) From Radio Wave Sources
Powered wheelchairs and motorized scooters (in this text, both will be referred to as powered wheelchairs) may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two way radios, and cellular phones. The interference (from radio wave sources) can cause the powered wheelchair to release its brakes, move by itself, or move in unintended directions. It can also permanently damage the powered wheelchair's control system. The intensity of the interfering EM energy can be measured in volts per meter (V/m). Each powered wheelchair can resist EMI up to a certain intensity. This is called its "immunity level." The higher the immunity level, the greater the protection. At this time, current technology is capable of achieving at least a 20 V/m immunity level, which would provide useful protection from the more common sources of radiated EMI.
There are a number of sources of relatively intense electromagnetic fields in the everyday environment. Some of these sources are obvious and easy to avoid. Others are not apparent and exposure is unavoidable. However, we believe that by following the warnings listed below, your risk to EMI will be minimized.
The sources of radiated EMI can be broadly classified into three types:
1) Hand-held Portable transceivers (transmitters-receivers with the antenna mounted directly on the transmitting unit. Examples include: citizens band (CB) radios, "walkie talkie", security, fire and police transceivers, cellular telephones, and other personal communication devices).
NOTE: Some cellular telephones and similar devices transmit signals while they are ON, even when not being used.
2) Medium-range mobile transceivers, such as those used in police cars, fire trucks, ambulances and taxis. These usually have the antenna mounted on the outside of the vehicle; and
3) Long-range transmitters and transceivers, such as commercial broadcast transmitters (radio and TV broadcast antenna towers) and amateur (HAM) radios.
NOTE: Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD players, cassette players, and small appliances, such as elec­tric shavers and hair dryers, so far as we know, are not likely to cause EMI problems to your powered wheelchair.
300 and 400 18 Part No. 1118395
SECTION 2—EMI INFORMATION
WARNING
Powered Wheelchair Electromagnetic Interference (EMI)
Because EM energy rapidly becomes more intense as one moves closer to the transmitting antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the powered wheelchair's control system while using these devices. This can affect powered wheelchair movement and braking. Therefore, the warnings listed below are recommended to prevent possible interference with the control system of the powered wheelchair.
Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones can affect powered wheelchairs and motorized scooters.
FOLLOWING THE WARNINGS LISTED BELOW SHOULD REDUCE THE CHANCE OF UNINTENDED BRAKE RELEASE OR POWERED WHEELCHAIR MOVEMENT WHICH COULD RESULT IN SERIOUS INJURY.
1) Do not operate hand-held transceivers (transmitters receivers), such as citizens band (CB) radios, or turn ON personal communication devices, such as cellular phones, while the powered wheelchair is turned ON;
2) Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming close to them;
3) If unintended movement or brake release occurs, turn the powered wheelchair OFF as soon as it is safe;
4) Be aware that adding accessories or components, or modifying the powered wheelchair, may make it more susceptible to EMI (NOTE: There is no easy way to evaluate their effect on the overall immunity of the powered wheelchair); and
5) Report all incidents of unintended movement or brake release to the powered wheelchair manufacturer, and note whether there is a source of EMI nearby.
Important Information
1) 20 volts per meter (V/m) is a generally achievable and useful immunity level against EMI (as of May 1994) (the higher the level, the greater the protection);
2) This device has been tested to a radiated immunity level of 20 V/m.
Modification of any kind to the electronics of this wheelchair as manufactured by Invacare may adversely affect the RFI immunity levels.
Part No. 1118395 19 300 and 400
SAFETY/HANDLING OF POWERED SCOOTERS
SECTION 3—SAFETY/HANDLING OF POWERED SCOOTERS
“Safety and Handling” of the powered scooter requires the close attention of the user. This manual points out the most common procedures and techniques involved in the safe operation and maintenance. It is important to practice and master these safe techniques until you are comfortable in maneuvering the powered scooter.
Use this information only as a “basic” guide. The techniques that are discussed have been used successfully by many. Individual users often develop skills to deal with daily living activities that may differ from those described in this manual. Invacare recognizes and encourages each individual to try what works best for him/her in overcoming obstacles that they may encounter; however, ALL WARNINGS and CAUTIONS given in this manual MUST be followed. Techniques in this manual are a starting point for the new powered scooter user with “safety” as the most important consideration for all.
STABILITY AND BALANCE
WARNING
DO NOT make sharp turns in the forward or reverse direction at excessive speed. Failure to observe the warning can cause the scooter to tip over and may result in injury to user and/ or damage to the product.
ALWAYS wear your seat positioning strap.
The seat positioning strap is a positioning belt ONLY. It is not designed for use as a safety device withstanding high stress loads such as auto or aircraft safety belts. If signs of wear appear, belt must be replaced immediately.
To assure stability and proper operation of your powered scooter, you MUST, at all times, maintain proper balance. Your powered scooter has been designed to remain upright and stable during normal daily activities.
PERCENTAGE OF WEIGHT DISTRIBUTION
WARNING
DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees.
Many activities require the powered scooter owner to reach, bend and transfer IN and OUT of the powered scooter. These movements cause a change to the normal balance, the center of gravity, and the weight distribution of the powered scooter. To determine and establish your particular safety limits, practice bending, reaching and transferring activities in several combinations in the presence of a qualified healthcare professional BEFORE attempting active use of the powered scooter.
300 and 400 20 Part No. 1118395
SAFETY/HANDLING OF POWERED SCOOTERS
Proper positioning is essential for your safety.
STAIRWAYS
WARNING
DO NOT attempt to move an occupied powered scooter between floors using a stairway. Use an elevator to move an occupied powered scooter between floors.
If moving a powered scooter between floors by means of a stairway, the occupant MUST be removed and transported independently of the powered scooter. Extreme caution is advised when it is necessary to move an UNOCCUPIED powered scooter up or down the stairs. Invacare recommends disassembling the scooter and transporting the components (five [5] components on 300 and six [6] components on 400) independently UP or DOWN the stairs. ONLY use secure, non-detachable parts on each component for hand-hold supports.
DO NOT attempt to lift a powered scooter by any removable (detachable) parts. Lifting by means of removable (detachable) parts may result in injury to the user or assistants or damage to the powered scooter.
ESCALATORS
WARNING
DO NOT use an escalator to move a powered scooter between floors. Serious bodily injury may occur.
Powered scooter without the batteries can weigh between 90 to 200 lbs (depending on the model). Use proper lifting techniques (lift with your legs) to avoid injury.
Follow this procedure for moving the powered scooter between floors when an elevator is NOT available:
1. Remove the occupant from the powered scooter.
2. Disassemble the scooter. Refer to Transporting the Scooter on page 60.
3. Carefully move the powered scooter components up or down the stairway.
4. Once all the components of the scooter are transported to the desired location reassemble the scooter. Refer to Transporting the Scooter
on page 60.
Part No. 1118395 21 300 and 400
SECTION 4—SAFETY INSPECTION
SECTION 4—SAFETY INSPECTION
NOTE: Every six (6) months take your powered scooter to a qualified technician for a thorough inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation of your powered scooter. To operate properly and safely, your powered scooter must be cared for just like any other vehicle. Routine maintenance will extend the life and efficiency of your powered scooter.
WARNING
Before performing any maintenance, adjustment or service, turn power OFF and remove key from ignition.
CAUTION
As with any vehicle, the wheels and tires should be checked periodically for cracks and wear, and should be replaced.
SAFETY INSPECTION CHECKLISTS
Initial adjustments should be made to suit your personal body structure needs and preference. Thereafter follow these maintenance procedures:
INSPECT/ADJUST INITIALLY
Ensure powered scooter drives straight (no excessive drag or pull to one side).
Check frame for damage and corrosion.
Ensure that the brake release lever is easy to engage/disengage.
Ensure that tiller adjustment handle engages and disengages properly and securely.
Ensure that the scooter stops completely when throttle is released (i.e., does not
continue to roll as if the throttle is activated).
Clean upholstery and armrests.
Ensure adjustable height arms operate and lock securely.
Ensure armrest pad sits flush against arm tube.
Inspect the seat upholstery for rips and tears.
Inspect seat swivel for release and engagement (seat locks into the determined swivel
positions).
Inspect for excessive side movement or binding when the drive wheels are raised or
turned.
Inspect front wheel/fork assembly for proper tension by spinning the wheel. The front
wheel should come to a gradual stop.
Check the front fork for damage or corrosion.
300 and 400 22 Part No. 1118395
Loading...
+ 50 hidden pages
