The Intermec CK60 Handheld Computer Bumpers (p/n: 203-710-001) help protect
your CK60 from the normal bumps and occassional drops that happen during its
use.
1 To remove the damaged bumpers use a T-10 driver and remove the top and
bottom screws from each of the four corner Bumpers.
2 Attach the new bumpers using the replacement black #6-32 x 3/4 cap screws on
the back side and #6-32 x 3/16 silver cap head screws on the top side. Use the
T-10 driver to tighten the screws. The recomm ended torque is 5 in-lbs. Ensure
that the honeycomb part of the bumper is on the back side of your CK60.
.
The Intermec CK60 Handheld Computer Bumpers (p/n: 203-710-001) help protect
your CK60 from the normal bumps and occassional drops that happen during its
use.
1 To remove the damaged bumpers use a T-10 driver and remove the top and
bottom screws from each of the four corner Bumpers.
2 Attach the new bumpers using the replacement black #6-32 x 3/4 cap screws on
the back side and #6-32 x 3/16 silver cap head screws on the top side. Use the
T-10 driver to tighten the screws. The recommended torque is 5 in-lbs. Ensure
that the honeycomb part of the bumper is on the back side of your CK60.
.
The Intermec CK60 Handheld Computer Bumpers (p/n: 203-710-001) help protect
your CK60 from the normal bumps and occassional drops that happen during its
use.
1 To remove the damaged bumpers use a T-10 driver and remove the top and
bottom screws from each of the four corner Bumpers.
2 Attach the new bumpers using the replacement black #6-32 x 3/4 cap screws on
the back side and #6-32 x 3/16 silver cap head screws on the top side. Use the
T-10 driver to tighten the screws. The recommended torque is 5 in-lbs. Ensure
that the honeycomb part of the bumper is on the back side of your CK60.
.
Instructions
Corporate Headquarters
6001 36th Avenue West
Everett, Washington 98203 U.S.A.
tel 425.348.2600
www.intermec.com
© 2005 Intermec Technologies
Corporation. All rights reserved.
CK60 Handheld Computer Bumper Replacement Instructions
*962-000-055A*
P/N 962-000-055A
Instructions
Corporate Headquarters
6001 36th Avenue West
Everett, Washington 98203 U.S.A.
tel 425.348.2600
www.intermec.com
© 2005 Intermec Technologies
Corporation. All rights reserved.
CK60 Handheld Computer Bumper Replacement Instructions
*962-000-055A*
P/N 962-000-055A
Instructions
Corporate Headquarters
6001 36th Avenue West
Everett, Washington 98203 U.S.A.
tel 425.348.2600
www.intermec.com
© 2005 Intermec Technologies
Corporation. All rights reserved.
CK60 Handheld Computer Bumper Replacement Instructions
*
962-000-055A*
P/N 962-000-055A
CK60 Handheld Computer Bumpers
CK60 Handheld Computer Bumpers CK60 Handheld Computer Bumpers
Instructions
Bumper
honeycomb on
bottom side
T-10 Driv er
Screws (8) to
attach
Bumpers
Instructions
Bumper
honeycomb on
bottom side
T-10 Driv er
Screws (8) to
attach
Bumpers
Instructions
Bumper
honeycomb on
bottom side
T-10 Driv er
Screws (8) to
attach
Bumpers
